Datasheet RURD6120, RURD6120S Datasheet (Intersil)

RURD6120, RURD6120S

Data Sheet January 2000

6A, 1200V Ultrafast Diodes

The RURD6120 and RURD6120S are ultrafast diodes with
soft recovery characteristics (t

< 70ns). They have low

rr

forward voltage drop and are silicon nitride passivated ion­implanted epitaxial planar construction.

These devices are intended for use as freewheeling/
clamping diodes and rectifiers in a variety of switchingpower
supplies and other power switching applications. Their low
stored charge and ultrafast soft recovery minimize ringing
and electrical noise in many power switching circuits
reducing power loss in the switching transistors.

Formerly development type TA49039.

Ordering Information

PART NUMBER PACKAGE BRAND

RURD6120 TO-251 UR6120
RURD6120S TO-252 UR6120

NOTE: Whenordering, usethe entirepart number.Add the suffix 9A
to obtain the TO-252 variant in the tape and reel, i.e.,
RURD6120S9A.

File Number 3962.2

Features

• Ultrafast with Soft Recovery . . . . . . . . . . . . . . . . . . .<70ns

• Operating Temperature. . . . . . . . . . . . . . . . . . . . . . .175

o

• Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . .1200V

• Avalanche Energy Rated

• Planar Construction

Applications

• Switching Power Supplies

• Power Switching Circuits

• General Purpose

Packaging

JEDEC STYLE TO-251

ANODE

CATHODE

CATHODE
(FLANGE)

C

Symbol

K

A

Absolute Maximum Ratings T

Peak Repetitive Reverse Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .V

Working Peak Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

DC Blocking Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

Average Rectified Forward Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

(TC = 140oC)

Repetitive Peak Surge Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .I

(Square Wave, 200kHz)

Nonrepetitive Peak Surge Current. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .I

(Halfwave, 1 Phase, 60Hz)

Maximum Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P

Avalanche Energy (See Figures 10 and 11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E

Operating and Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T

Maximum Lead Temperature for Soldering

(Leads at 0.063 in. (1.6mm) from case for 10s). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .T

Package Body for 10s, see Tech Brief 334. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T

= 25oC, Unless Otherwise Specified

C

JEDEC STYLE TO-252

CATHODE

ANODE

RRM

RWM

F(AV)

FRM

FSM

STG

PKG

CATHODE
(FLANGE)

RURD6120

RURD6120S UNITS

1200 V
1200 V
1200 V

6A

12 A

60 A

50 W
10 mJ

-65 to 175

300
260

AVL

, T

R

D

J

L

o

C

o

C

o

C

1

1-888-INTERSIL or 321-724-7143 | Copyright © Intersil Corporation 2000

RURD6120, RURD6120S

Electrical Specifications T

= 25oC, Unless Otherwise Specified

C

SYMBOL TEST CONDITION MIN TYP MAX UNITS

V

F

IF = 6A - - 2.1 V
IF = 6A, TC = 150oC - - 1.9 V

I

R

VR = 1200V - - 100 µA
VR = 1200V, TC = 150oC - - 500 µA

t

rr

IF = 1A, dIF/dt = 200A/µs--70ns
IF = 6A, dIF/dt = 200A/µs--90ns

t

a

t

b

Q

RR

C

J

R

θJC

IF = 6A, dIF/dt = 200A/µs - 45 - ns
IF = 6A, dIF/dt = 200A/µs - 30 - ns
IF = 6A, dIF/dt = 200A/µs - 400 - nC
VR = 10V, IF = 0A - 22 - pF

--3oC/W

DEFINITIONS

VF = Instantaneous forward voltage (pw = 300µs, D = 2%).

IR = Instantaneous reverse current.
trr = Reverse recovery time (See Figure 9), summation of ta + tb.

ta = Time to reach peak reverse current (See Figure 9).
tb = Time from peak IRM to projected zero crossing of IRM based on a straight line from peak IRM through 25% of IRM (See Figure 9).

QRR = Reverse recovery charge.

CJ = Junction Capacitance.

R

= Thermal resistance junction to case.

θJC

pw = Pulse width.

D = Duty cycle.

Typical Performance Curves

30

10

100oC

, FORWARD CURRENT (A)

F

I

1

0.5
0 0.5 2.5121.5

175oC

VF, FORWARD VOLTAGE (V)

25oC

3

FIGURE 1. FORWARD CURRENT vs FORWARD VOLTAGE FIGURE 2. REVERSE CURRENT vs REVERSE VOLTAGE

500

100

10

1

0.1

, REVERSE CURRENT (µA)

R

0.01

I

0.001
0 1200800600400

175oC

100oC

25oC

200 1000

V

, REVERSE VOLTAGE (V)

R

2

RURD6120, RURD6120S

Typical Performance Curves (Continued)

90

TC = 25oC, dIF/dt = 200A/µs

75

60

t

45

30

t, RECOVERY TIMES (ns)

15

0

0.5 6

rr

t

a

t

b

1
IF, FORWARD CURRENT (A)

125

TC = 100oC, dIF/dt = 200A/µs

100

75

50

t, RECOVERY TIMES (ns)

25

0

0.5 6

t

rr

t

a

t

b

1

IF, FORWARD CURRENT (A)

FIGURE 3. trr,taAND tbCURVES vs FORWARD CURRENT FIGURE 4. trr,taAND tbCURVES vs FORWARD CURRENT

150

125

100

TC = 175oC, dIF/dt = 200A/µs

t

rr

75

6

DC

5

SQ. WAVE

4

3

50

t, RECOVERY TIMES (ns)

25

0

0.5 6

t

a

t

b

1
IF, FORWARD CURRENT (A)

2

1

, AVERAGE FORWARD CURRENT (A)

F(AV)

I

0

115 130 160100 175145

T

, CASE TEMPERATURE (oC)

C

FIGURE 5. trr,taAND tbCURVES vs FORWARD CURRENT FIGURE 6. CURRENT DERATING CURVE

100

80

60

40

20

, JUNCTION CAPACITANCE (pF)

J

C

0

0 50 100 150 200

VR, REVERSE VOLTAGE (V)

FIGURE 7. JUNCTION CAPACITANCE vs REVERSE VOLTAGE

3

Test Circuits and Waveforms

VGE AMPLITUDE AND
RG CONTROL dIF/dt
t

V

GE

I = 1A
L = 20mH
R < 0.1Ω
E

Q

1 ANDt2

= 1/2LI2 [V

AVL

= IGBT (BV

1

CONTROL I

t

1

R(AVL)

CES

F

R

t

2

FIGURE 8. trr TEST CIRCUIT FIGURE 9. trr WAVEFORMS AND DEFINITIONS

/(V

R(AVL)

> DUT V

R(AVL)

L

DUT

G

IGBT

- VDD)]
)

RURD6120, RURD6120S

CURRENT

SENSE

LR

+

V

DD

-

dI

F

I

F

dt

0

t

rr

t

a

V

AVL

t

b

0.25 I

RM

I

RM

CURRENT

Q

1

SENSE

DUT

+
V

DD

V

DD

-

IV

t

0

I

L

I

L

t

1

t

2

FIGURE 10. AVALANCHE ENERGY TEST CIRCUIT FIGURE 11. AVALANCHE CURRENT AND VOLTAGE

WAVEFORMS

t
