Datasheet RS1B, RS1D, RS1G, RS1J, RS1K DATASHEETS (Philips)

DISCRETE SEMICONDUCTORS

DATA SH EET

ook, halfpage

M3D168

RS1 series

SMA fast soft-recovery
controlled avalanche rectifiers

Product specification 2000 Feb 14

Philips Semiconductors Product specification

SMA fast soft-recovery
controlled avalanche rectifiers

FEATURES

• Glass passivated

• High maximum operating temperature

• Ideal for surface mount automotive applications

• Low leakage current

• Excellent stability

• Guaranteed avalanche energy absorption capability

• UL 94V-O classified plastic package

• Shipped in 12 mm embossed tape

• Marking: cathode, date code, type code

• Easy pick and place.

RS1 series

DESCRIPTION

DO-214AC surface mountable package with glass
passivated chip.

The well-defined void-free case is of a transfer-moulded
thermo-setting plastic. The small rectangular package
has two J bent leads.

lumns

ka

Top view Side view

Fig.1 Simplified outline (DO-214AC) and symbol.

cathode
band

MSA474

LIMITING VALUES

In accordance with the Absolute Maximum Rating
System (IEC 134).

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

V

RRM

repetitive peak reverse voltage

RS1A − 50 V
RS1B − 100 V
RS1D − 200 V
RS1G − 400 V
RS1J − 600 V
RS1K − 800 V
RS1M − 1000 V

V

R

continuous reverse voltage

RS1A − 50 V
RS1B − 100 V
RS1D − 200 V
RS1G − 400 V
RS1J − 600 V
RS1K − 800 V
RS1M − 1000 V

2000 Feb 14 2

Philips Semiconductors Product specification

SMA fast soft-recovery

RS1 series

controlled avalanche rectifiers

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

V

RMS

I

F(AV)

I

FSM

T

stg

T

j

root mean square voltage

RS1A − 35 V
RS1B − 70 V
RS1D − 140 V
RS1G − 280 V
RS1J − 420 V
RS1K − 560 V
RS1M − 700 V

average forward current averaged over any 20 ms period;

− 1A

Ttp= 110 °C; see Fig.2

non-repetitive peak forward current t = 8.3 ms half sine wave;

− 25 A
Tj=25°C prior to surge;
VR=V

RRMmax

storage temperature −65 +175 °C
junction temperature See Fig.3 −65 +175 °C

ELECTRICAL CHARACTERISTICS

Tj=25°C unless otherwise specified.

SYMBOL PARAMETER CONDITIONS TYP. MAX. UNIT

V

F

I

R

t

rr

forward voltage IF= 1 A; see Fig.4 − 1.3 V
reverse current VR=V

V

R=VRRMmax

; see Fig.5 − 5 µA

RRMmax

; Tj= 165 °C; see Fig.5 − 50 µA

reverse recovery time when switched from IF= 0.5 A to IR=1A;

RS1A to RS1J − 250 ns

measured at IR= 0.25 A; see Fig.9

RS1K and RS1M − 300 ns

C

d

diode capacitance VR= 4 V; f = 1 MHz; see Fig.6 7 − pF

THERMAL CHARACTERISTICS

SYMBOL PARAMETER CONDITIONS VALUE UNIT

R
R

th j-tp
th j-a

thermal resistance from junction to tie-point; see Fig.7 27 K/W
thermal resistance from junction to ambient note 1 100 K/W

note 2 150 K/W

Notes

1. Device mounted on Al

printed-circuit board, 0.7 mm thick; thickness of copper ≥35 µm.

2O3

2. Device mounted on epoxy-glass printed-circuit board, 1.5 mm thick; thickness of copper ≥40 µm. For more
information please refer to the

‘General Part of associated Handbook’

.

2000 Feb 14 3

Philips Semiconductors Product specification

SMA fast soft-recovery
controlled avalanche rectifiers

GRAPHICAL DATA

handbook, halfpage

2

I

F(AV)

(A)

1.5

1

0.5

0

0 40 200

VR=V

; δ= 0.5; a = 1.57.

RRMmax

80

120 160

Fig.2 Maximum permissible average forward

current as a function of tie-point
temperature (including losses due to
reverse leakage).

MCD822

Ttp (°C)

RS1 series

200

handbook, halfpage

T

j

(°C)

160

120

80

DG JKM

40

0

0 400 1200

Device mounted as shown in Fig.8.
Solid line: Al2O3 printed-circuit board.
Dotted line: epoxy printed-circuit board.

800

Fig.3 Maximum permissiblejunction temperature

as a function of reverse voltage.

MGD483

VR (V)

2

10

handbook, halfpage

I

F

(A)

10

1

−1

10

−2

10

−3

10

Tj=25°C.

10

MCD791

VF (V)

Fig.4 Forward current as a function of forward

voltage; typical values.

VR (%V

MCD803

Rmax

1000 20 40

)

2

10

handbook, halfpage

I

R

(µA)

10

1

−1

10

−2

10

−3

32

10

Tj = 165 °C

Tj = 25 °C

60 80

Fig.5 Reverse current as a function of reverse

voltage; typical values.

2000 Feb 14 4

Philips Semiconductors Product specification

SMA fast soft-recovery
controlled avalanche rectifiers

2

10

handbook, halfpage

C

d

(pF)

10

1

−2

10

−1

10

1

10 10

VR (V)

MCD800

RS1 series

2

10

handbook, halfpage

Z

th j-tp

(K/W)

10

2

1

110

2

10

MBL120

3

10

tp (ms)

4

10

f = 1 MHz; Tj=25°C.

Fig.6 Diode capacitance as a function of reverse

voltage; typical values.

50

4.5

50

2.5

1.25

MSB213

Fig.7 Transient thermal impedance as a function

of pulse width.

Dimensions in mm.
Material: Al2O3 or epoxy-glass.

Fig.8 Printed-circuit board for surface mounting.

2000 Feb 14 5

Philips Semiconductors Product specification

SMA fast soft-recovery
controlled avalanche rectifiers

handbook, full pagewidth

10 Ω

25 V

DUT

+

1 Ω

50 Ω

I

(A)

0.25

R

I

(A)

0.5

0.5

1.0

RS1 series

F

t

rr

0

t

MAM057

Input impedance oscilloscope: 1 MΩ, 22 pF; tr≤ 7 ns.
Source impedance: 50 Ω; tr≤ 15 ns.

Fig.9 Test circuit and reverse recovery time waveform and definition.

2000 Feb 14 6

Philips Semiconductors Product specification

SMA fast soft-recovery
controlled avalanche rectifiers

PACKAGE OUTLINE

Transfer-moulded thermo-setting plastic small rectangular surface mounted package;
2 connectors

H
D

A

A

1

c

Q

RS1 series

SOD124

E

b (1)

DIMENSIONS (mm are the original dimensions)

UNIT bA

mm

Note

1. The marking band indicates the cathode.

A

1

2.3

2.0

OUTLINE
VERSION

SOD124 99-10-22DO-214AC

cD

1.6

1.4

IEC JEDEC EIAJ

4.5

0.20.05

4.3

0 2.5 5 mm

scale

Q

H

E

2.8

5.5

5.1

3.3

2.7

2.4

REFERENCES

EUROPEAN

PROJECTION

ISSUE DATE

2000 Feb 14 7

Philips Semiconductors Product specification

SMA fast soft-recovery

RS1 series

controlled avalanche rectifiers

DEFINITIONS

Data sheet status

Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.

Limiting values

Limiting valuesgiven are in accordance withtheAbsolute Maximum Rating System (IEC 60134).Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information

Where application information is given, it is advisory and does not form part of the specification.

LIFE SUPPORT APPLICATIONS

These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in suchapplications do so at their ownrisk and agree to fullyindemnify Philips for any damages resultingfrom such
improper use or sale.
