NTE701
Integrated Circuit
Video Signal Processor
Description:
The NTE701 is a monolithic integrated circuit TV signal processor in a 16–Lead DIP type package
designed for use in color or monochrome receivers. Circuit functions include a horizontal oscillator
with AFC, a sync separator, and a key AGC system. The AGC system provides output signals for
IF (reverse) and tuner (forward and/or reverse). The wide frequency–range horizontal oscillator has
high stability at 503.3kHz.
Features:
D Horizontal Oscillator with AFC
D Sync Separator with Noise Immunity
D Strobed AGC System
D IF AGC Output
D Delayed Outputs for Forward or Reverse AGC Tuners
D Internal Noise Threshold
D High–Impedance Video Input
D RF AGC Delay Externally Controlled
D Output Short–Circuit Protection
Absolute Maximum Ratings:
DC Supply Voltage 15V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Device Dissipation (Up to T
Derate Linearly Above +55°C 7.9mW/°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Ambient Temperature Range –40° to +85°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Temperature Range –65° to +150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead Temperature (During Soldering, 1/16” from case, 10sec max) +265°C. . . . . . . . . . . . . . . . . . . .
= +55°C) 750mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A
Page 2
Electrical Characteristics: (TA = +25°C, Pin 5 to GND, Pin9 to12V unless otherwise specified)
Test Conditions
Parameter Symbol
Power Supply Current I
Video Inverter Voltage V
Sync Separator Output Voltage,
V
High
Sync Separator Output Voltage,
V
Low
Video Noise Clamp Voltage V
AGC Discharge Current I
AGC Charge Current I
AGC Comparator Leakage
Current
AGC Threshold Voltage V
Minimum IF AGC V
Forward Tuner AGC Leakage
Current
Reverse Tuner Leakage Current I
IF AGC High Voltage V
Forward Tuner AGC Voltage,
V
Low
Reverse Tuner AGC Voltage,
V
Low
Maximum IF AGC Voltage V
Phase Detector Leakage Cur-
I
rent
Phase Detector Bias Voltage V
Oscillator Output Voltage V
Oscillator Free–Running
f
Frequency
9
2
3H
3L
3
15
15
I
15
1TH
13L
I
11
12
13H
11L
12L
13H
10L
4
6
6FR
(Pins connected as Shown)
Measure Pin9 10 – 22 mA
Pin1 to 14V, Pin2: 12kΩ to GND,
Pin3: 27kΩ to GND, Measure Pin2
Pin1 to 14V, Pin2: 12kΩ to GND,
Pin3: 27kΩ to GND, Measure Pin2
Pin1 to 4V, Pin3: 27kΩ to GND,
Measure Pin3
Pin1 to 3.1V, Pin3: 27kΩ to GND,
Measure Pin3
Pin1 to 4.4V, Pin2: 10kΩ to GND,
Pin15: 470Ω to 6V, Pin16: 27kΩ to 12V,
Measure Pin15
Pin1 to 3.45V, Pin2: 10kΩ to GND,
Pin15: 470Ω to 6V, Pin16: 27kΩ to 12V,
Measure Pin15
Pin1 to 3.45V, Pin2: 10kΩ to GND,
Pin15: 4.7kΩ to 6V, Measure Pin15
Adjust Pin1 for I15 = 0±0.1mA,
Pin2: 10kΩ to GND, Pin15: 4.7kΩ to 6V,
Pin16: 27kΩ to 12V, Measure Pin1
Pin11: 10kΩ to GND, Pin12: 40kΩ to 12V,
Pin13: 22kΩ to 5V, Pin14: 1kΩ to 2.95V,
Pin16: 1kΩ to 2.2V, Measure Pin15
Pin11: 10kΩ to GND, Pin12: 10kΩ to 12V,
Pin13: 2.2kΩ to 5V, Pin14: 1kΩ to 2.95V,
Pin15: 1kΩ to 5.3V, Measure Pin11
Pin11: 10kΩ to GND, Pin12: 10kΩ to 12V,
Pin13: 2.2kΩ to 5V, Pin14: 1kΩ to 2.95V,
Pin15: 1kΩ to 5.3V, Measure Pin12
Pin11: 10kΩ to GND, Pin12: 10kΩ to 12V,
Pin13: 2.2kΩ to 5V, Pin14: 1kΩ to 2.95V,
Pin15: 1kΩ to 5.3V, Measure Pin13
Pin11: 3.6kΩ to GND, Pin12: 3.16kΩ to 12V,
Pin13: 2.2kΩ to 5V, Pin14: 1kΩ to 2.95V,
Pin15: 1kΩ to 7.9V, Measure Pin11
Pin11: 3.6kΩ to GND, Pin12: 3.16kΩ to 12V,
Pin13: 2.2kΩ to 5V, Pin14: 1kΩ to 2.95V,
Pin15: 1kΩ to 7.9V, Measure Pin12
Pin11: 10kΩ to GND, Pin12: 10kΩ to 12V,
Pin13: 2.2kΩ to 5V, Pin14: 1kΩ to 2.95V,
Pin15: 1kΩ to 7.9V, Measure Pin13
Pin2: 10kΩ to GND, Pin2 to GND,
Pin4: 5kΩ to 3.8V, Pin10: 10kΩ to 6V,
Limit GND at Pin3 to 10sec, Measure Pin10
Connect OSC–loop to Pin6, Pin7, & Pin8,
Pin3 to GND for 10sec max, Measure Pin6
Connect OSC–loop to Pin6, Pin7, & Pin8,
Pin3 to GND for 10sec max, Measure Pin6
Min Typ Max Unit
5.2 – 6.4 V
10.7 – – V
– 1.3 V
10.7 – – V
0.6 – 1.4 mA
–2.1 – –4.8 mA
–20 – +20 µA
3.8 4.0 4.3 V
0.75 – 1.25 V
–20 – +20 µA
–10 – +10 µA
3.65 – 4.15 V
0.8 – 3.2 V
1.65 – 3.25 V
4.85 – 5.20 V
–5 – +5 µA
2.65 – 3.10 V
0.6 – 1.6 V
P–P
475 – 535 kHz
Page 3
Electrical Characteristics (Cont’d): (TA = +25°C, Pin 5 to GND, Pin9 to12V unless otherwise
specified)
Test Conditions
Parameter Symbol
Oscillator Frequency, High f
(Pins connected as Shown)
Connect OSC–CKT to Pin10, Pin7, & Pin8,
6H
Pin2: 10kΩ to GND, Pin4: 5kΩ to 18V,
Measure Pin6
Min Typ Max Unit
520 – – kHz
Oscillator Frequency, Low f
Connect OSC–CKT to Pin10, Pin7, & Pin8,
6L
– – 485 kHz
Pin2: 10kΩ to GND, Pin4: 5kΩ to 3.8V,
Measure Pin6
Sync Separator Short Circuit I3Max Pin3: 10Ω to GND 10sec max – – 40 mA
Oscillator Output Short Circuit I8Max Pin8: 10Ω to GND for 10sec max,
– – 130 mA
Pin3: 10Ω to GND for 10sec max
Pin Connection Diagram
Video Input
Sync Sep
Comp Sync Input
Horiz Sawtooth Input
1
2
3
4
5GND
6OSC Phase Input
7OSC Quad Input
8OSC Output
Horiz Pulse Input
16
AGC Filter
15
IF Gain Clamp
14
IF AGC
13
12 Tuner Rev AGC
11 Tuner Fwd AGC
10 Horiz AFC Filter
9
V
CC
16 9
18
.260
.870 (22.0)
Max
(6.6)
Max
.200 (5.08)
Max
.100 (2.54)
.099 (2.5) Min
.700 (17.78)
