Ordering number : ENN*6719

CMOS IC

LC877264A/56A/48A

8-Bit Single Chip Microcontroller with

64/56/48 KB ROM and 2048-Byte RAM On Chip

Preliminary
Overview

The LC877264A, LC877256A and LC877248A are 8 bit single chip microcontrollers with the following on-chip functional
blocks :

- CPU: operable at a minimum bus cycle time of 100 ns

- On-chip ROM Maximum Capacity : LC877264A 64K bytes
LC877256A 56K bytes
LC877248A 48K bytes

- On-chip RAM capacity: 2048 bytes

- LCD controller / driver

- 16 bit timer / counter (can be divided into two 8 bit timers)

- 16 bit timer / PWM (can be divided into two 8 bit timers)

- Timer fo r use as date / time clock

- Synchronous serial I/O port (with automatic block transmit / receive function)

- Asynchronous / synchronous serial I/O port

- 12-channel × 8-bit AD converter

- Small signal detector

- 14-sour ce 10-vectored interrup t s yst em

All of the above functions are fabricated on a single chip.

Ver.1.04
70899

91400 RM (IM) SK No.6719-1/24

LC877264A/56A/48A

Features

(1) Read-Only Memory (ROM)

- 65536 × 8bits (LC877264A)

- 57344 × 8bits (LC877256A)

- 49152 × 8bits (LC877248A)

(2) Random Access Memory (RAM): 2048 × 9 bits (LC877264A, LC877256A, LC877248A)

(3) Minimum Bus Cycle Time: 100 ns (10 MHz)

Note: The bus cycle time indicates ROM read time.

(4) Minimum Instruction Cycle Time: 300 ns (10MHz)

(5) Ports

- Input/output ports
Data direction programmable for each bit individually : 26 (P1n, P30-P35, P70-P7 3, P 8n)
Data direction programmable in nibble units : 8 (P0n)
(When N-channel open drain output is selected, data can be input in bit units.)

- Input ports : 2 (XT1,XT2)

- LCD ports
Segment output : 48 (S00-S47)
Common output : 4 (COM0-COM3)
Bias terminals for LCD driver 3 (V1-V3)

Other functions

Input/output ports : 48(PAn,PBn,PCn,PDn,P En,P Fn)
Input ports : 7 (PLn)

- Oscillator pins : 2 (CF1,CF2)

- Reset pin : 1 (

- Power supply : 6 (VSS1-3,VDD1-3)

(6) LCD controller

- Seven display modes are available (static, 1/2, 1/3, 1/4 duty × 1/2, 1/3 bias)

- Segment output and common output can be switched to general purpose input/output ports.

(7) Small signal detection (MIC signals etc)

- Counts pulses with the level which is greater than a preset value

- 2 bit counter

(8) Timers

- Timer 0: 16 bit timer / counter with capture register
Mode 0: 2 channel 8-bit timer with programmable 8 bit prescaler and 8 bit capture register
Mode 1: 8 bit timer with 8 bit programmable prescaler and 8 bit capture register + 8 bit
Counter with 8-bit capture register
Mode 2: 16 bit timer with 8 bit programmable prescaler and 16 bit capture register
Mode 3: 16 bit counter with 16 bit capture register

- Timer 1: PWM / 16 bit timer with toggle output function
Mode 0: 2 channel 8 bit timer (with toggle output)
Mode 1: 2 channel 8 bit PWM
Mode 2: 16 bit timer (with toggle output) Toggle output from lower 8 bits is also possible.
Mode 3: 16 bit timer (with toggle output) Lower order 8 bits can be used as PWM.

RES

)

No.6719-2/24

LC877264A/56A/48A

- Base Timer

1) The clock signal can be selected from any of the following :

Sub-clock (32.768kHz crystal oscillator), system clock, and prescaler output from timer 0

2) Interrupts of five different time intervals are possible.

(9) Serial-interface

- SIO 0: 8 bit synchronous serial interface

1) LSB first / MSB first is selectable

2) Internal 8 bit baud-rate generator (fastest clock period 4 / 3 Tcyc)

3) Consecutive automatic data communication (1-256 bits)

- SIO 1: 8 bit asynchronous / synchronous serial interface
Mode 0: Synchronous 8 bit serial IO (2-wire or 3-wire, transmit clock 2–512 Tcyc)
Mode 1: Asynchronous serial IO (half duplex, 8 data bits, 1 stop bit, baud rate 8–2048Tcyc)
Mode 2: Bus mode 1 (start bit, 8 data bits, transmit clock 2–512 Tcyc)
Mode 3: Bus mode 2 (start detection, 8 data bits, stop detection)

(10) AD converter

-8 bits × 12 channels

(11) Re mo te contro l receiver circuit ( connecte d to P73 / I NT3 / T0IN termina l )

-Noise rejection function (noise rejection filter’s time constant can be selected from 1 / 32 / 128 Tcyc)

(12) Watchdog timer

- The watching time period is determined by an external RC.

- Watchdog timer can produce interrupt or system reset

(13) Interrupts: 14 sources, 10 vectors

1) Three priority (low, high a nd highest) multiple inter rupts are supported. During interrupt handling, an eq ual or

lower priority interrupt request is postponed.

2) If interrupt requests to two or more vector addresses occur at once, the higher priority interrupt takes precedence.

In the case of equal priority levels, the vector with the lowest address takes precedence.

No. Vector Selectable Level Interrupt signal

1 00003H X or L INT0
2 0000BH X or L INT1
3 00013H H or L INT2/T0L
4 0001BH H or L INT3/Base timer
5 00023H H or L T0H
6 0002BH H or L T1L/ T1H
7 00033H H or L SIO0
8 0003BH H or L SIO1
9 00043H H or L ADC/MIC

10 0004BH H or L Port 0

• Priority Level : X > H > L

• For equal priority levels, vector with lowest address takes precedence.

(14) Subroutine stack levels: 1024 levels max. Stack is located in RAM.

(15) Multiplication and division

- 16 bit × 8 bit (executed in 5 cycles)

- 24 bit × 16 bit (12 cycles)

- 16 bit ÷ 8 bit (8 cycles)

- 24 bit ÷ 16 bit (12 cycles)

No.6719-3/24

LC877264A/56A/48A

(16) Oscillation circuits

- On-chip RC oscillation for system clock use.

- CF oscillation for system clock use. (Rf built in, Rd external)

- Crystal oscillation low speed system clock use. (Rf built in, Rd external)

(17) Standby function

- HALT mode
HALT mode is used to reduce power consumption. During the HALT mode, program execution is stopped but
peripheral circuits keep operating (some parts of serial transfer operation stop.)

1) Oscillation circuits are not stopped automatically.

2) Released by the system reset or interrupts.

-HOLD mode
HOLD mode is used to reduce power consumption. Program execution and peripheral circuits are stopped.

1) CF, RC and crystal oscillation circuits stop automatically.

2) Released by any of the following conditions.
(1) Low level input to the reset pin
(2) Specified level input to one of INT0, INT1, INT2
(3) Port 0 interrupt

-X’tal HOLD made
X’tal HOLD mode is used to reduce power consumption. Program execution is stopped.
All peripheral circuits except the base timer are stopped.

1) CF and RC oscillation circuits stop automatically.

2) Crystal oscillator operation is kept in its state at HOLD mode inception.

3) Released by any of the following conditions
(1) Low level input to the reset pin
(2) Specified level input to one of INT0, INT1, INT2
(3) Port 0 interrupt
(4) Base-timer interrupt

(18) Package

- QIP100E

- SQFP100

(19) Development tools

- Evaluation chip : LC876096

- Emulator: EVA62S + ECB876500 (Evaluation chip board) + SUB877200 + POD100QIP
or POD100SQFP (Type B)

- Flash ROM version: LC87F72C8A

No.6719-4/24

Pin Assignment

L

Z

N

N

N

V2/PL5

V1/PL4
COM0/PL0
COM1/PL1
COM2/PL2
COM3/PL3

P30
P31

VSS3

VDD3

P32
P33
P34
P35
P00
P01
P02
P03
P04
P05

Package Dimension

(unit : mm)

3151

LC877264A/56A/48A

V3/PL6

S47/PF7

S46/PF6

S45/PF5

S44/PF4

S43/PF3

S42/PF2

S41/PF1

S40/PF0

S39/PE7

S38/PE6

S37/PE5

S36/PE4

S35/PE3

S34/PE2

S33/PE1

S32/PE0

S31/PD7

S30/PD6

S29/PD5

S28/PD4

S27/PD3

S26/PD2

S25/PD1

8079787776757473727170696867666564636261605958575655545352
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100

1 2 3 4 5 6 7 8 9

P06

P07

P10/SO0

P13/SO1

P12/SCK0

P11/SI0/SB0

P14/SI1/SB1

P15/SCK1

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

CF1

RES

XT1/AN10

P16/T1PWM

P17/T1PWMH/BU

CF2

VSS1

VDD1

P80/AN0

P81/AN1

P82/AN2

P83/AN3

P84/AN4

P85/AN5

XT2/AN11

P86/AN6

S24/PD0

25

P87/AN7/MICI

VSS2

26

VDD2

S23/PC7

S22/PC6

S21/PC5

51

50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31

27

28

29

30

S0/PA0

P73/INT3/T0I

P72/INT2/T0I

P70/INT0/T0LCP/AN8

P71/INT1/T0HCP/AN9

S20/PC4
S19/PC3
S18/PC2
S17/PC1
S16/PC0
S15/PB7
S14/PB6
S13/PB5
S12/PB4
S11/PB3
S10/PB2
S9/PB1
S8/PB0
S7/PA7
S6/PA6
S5/PA5
S4/PA4
S3/PA3
S2/PA2
S1PA1

SANYO : QIP-100E

SANYO : QIP-100E

No.6719-5/24

LC877264A/56A/48A

L

Z

0

6

N

N

Pin Assignment

S47/PF7

V3/PL6
V2/PL5

V1/PL4
COM0/PL0
COM1/PL1
COM2/PL2
COM3/PL3

P30
P31

VSS3

VDD3

P32
P33
P34
P35
P00
P01
P02
P03
P04
P05
P06
P07

P10/SO0

Package Dimension

(unit : mm)

3181B

S46/PF6

S45/PF5

S44/PF4

S43/PF3

S42/PF2

S41/PF1

S40/PF0

S39/PE7

S38/PE6

S37/PE5

S36/PE4

S35/PE3

S34/PE2

S33/PE1

S32/PE0

S31/PD7

S30/PD6

S29/PD5

S28/PD4

S27/PD3

S26/PD2

75747372717069686766656463626160595857565554535251
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100

1 2 3 4 5 6 7 8 9

P13/SO1

P12/SCK0

P14/SI1/SB1

P15/SCK1

P16/T1PWM

P11/SI0/SB0

10

11

12

13

14

15

16

17

18

19

20

21

CF1

RES

XT1/AN10

P17/T1PWMH/BU

CF2

VSS1

VDD1

P81/AN1

P82/AN2P83/AN3

P84/AN4P85/AN5

XT2/AN11

P80/AN

P86/AN

S25/PD1

22

P87/AN7/MICI

S24/PD0

23

P70/INT0/T0LCP/AN8

VSS2

24

P71/INT1/T0HCP/AN9

VDD2

25

P72/INT2/T0I

50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26

S23/PC7
S22/PC6
S21/PC5
S20/PC4
S19/PC3
S18/PC2
S17/PC1
S16/PC0
S15/PB7
S14/PB6
S13/PB5
S12/PB4
S11/PB3
S10/PB2
S9/PB1
S8/PB0
S7/PA7
S6/PA6
S5/PA5
S4/PA4
S3/PA3
S2/PA2
S1PA1
S0/PA0
P73/INT3/T0IN

SANYO : SQFP-100

SANYO : SQFP-100

No.6719-6/24

System Bl ock Diagram

SIO0

SIO1

Timer 0

Timer 1

Base Timer

LCD Controller

INT0 - 3

Noise Rejection Filter

Interrupt Control

Stand-by Control

CF

RC

X’tal

LC877264A/56A/48A

Clock

Generator

Bus Interface

Port 0

Port 1

Port 3

Port 7

Port 8

ADC

Weak Signa Detector

IR PLA

ROM

PC

ACC

B Register

C Register

ALU

PSW

RAR

RAM

Stack Pointer

Watch Dog Timer

No.6719-7/24

LC877264A/56A/48A

Pin Assignment

Pin name I/O Function Option

VSS1
VSS2
VSS3
VDD1
VDD2
VDD3
PORT0
P00 to P07

PORT1
P10 to P17

PORT3
P30 to P35

PORT7
P70 to P73

- • Power supply (-) No

- • Power supply (+) No

I/O • 8bit input/output port

• Data direction programmable in nibble units

• Use of pull-up resistor can be specified in nibble units

• Input for HOLD release

• Input for port 0 interrupt

I/O • 8bit input/output port

• Data direction pr ogrammable for each bit

• Use of pull-up resistor can be specified for each bit individually

• Other pin functions
P10 SIO0 data output
P11 SIO0 data input or bus input/output
P12 SIO0 clock input/output
P13 SIO1 data output
P14 SIO1 data input or bus input/output
P15 SIO1 clock input/output
P16: Timer 1 PWML output
P17: Timer 1 PWMH output/Buzzer output

I/O • 6bit Input/output port

• Data direction can b e specified for each bit

• Use of pull-up resistor can be specified for each bit individually

• 4bit Input/output port

I/O

• Data direction can b e specified for each bit

• Use of pull-up resistor can be specified for each bit individually

• Other fu nc tions
P70: INT0 input/HOLD release input/Timer0L capture input/output for watchdog

timer
P71: INT1 input/HOLD release input/Timer0H capture input
P72: INT2 input/HOLD release input/timer 0 event input/Timer0L capture input
P73: INT3 input(noise rejection filter attached)/timer 0 event input/Timer0H capture

input

AD input port: AN8(P70), AN9(P71)

• Interrupt detection selection

INT0
INT1
INT2
INT3

Rising Falling

Yes
Yes
Yes
Yes

Yes
Yes
Yes
Yes

Rising and

falling

No

No
Yes
Yes

H level L level

Yes
Yes
No
No

Yes
Yes

No
No

Yes

Yes

Yes

No

No.6719-8/24

LC877264A/56A/48A

Pin name I/O Function description Option

PORT8

P80 to P87

S0/PA0 to

S7/PA7

S8/PB0 to

S15/PB7

S16/PC0 to

S23/PC7

S24 /PD0to

S31/PD7

S32/PE0 to

S39/PE7

S40/PF0 to

S47/PF7

COM0/PL0 to

COM3/PL3

V1/PL4 to

V3/PL6

RES

XT1 I • Input for 32.768kHz crystal oscillation

XT2 I/O • Output for 32.768kHz crystal oscillation

CF1 I Input terminal for ceramic oscillator No
CF2 O Output terminal for ceramic oscillator No

I/O • 8bit Input/output port

• Input/out put can be specified for each bit individually

• Other func tions:
AD input port: AN0 to AN7
Small signal detector input port: MICIN(P87)

I/O • Seg ment output for LC D

• Can be used as general purpose input/output port (PA)

I/O • Seg ment output for LC D

• Can be used as general purpose input/output port (PB)

I/O • Seg ment output for LC D

• Can be used as general purpose input/output port (PC)

I/O • Seg ment output for LC D

• Can be used as general purpose input/output port (PD)

I/O • Seg ment output for LC D

• Can be used as general purpose input/output port (PE)

I/O • Seg ment output for LC D

• Can be used as general purpose input/output port (PF)

I/O • Com mon output for LCD

• Can be used as general purpose input port (PL)

I/O • LCD output bias power supply

• Can be used as general purpose input port (PL)

I Reset terminal No

• Other func tions:
General purpose input port

AD input port: AN10

• When not in use, connect to VDD1

• Other func tions:
General purpose input port

AD input port: AN11

• When not in use, set to oscillation mode and leave open

No

No

No

No

No

No

No

No

No

No

No

No.6719-9/24

LC877264A/56A/48A

Port Configuration

Port form and pull-up resistor options are shown in the following table.
Port status can be read even when port is set to output mode.

Terminal Option applies to: Options Output Form Pull-up resistor

P00 to P07 each bit

P70 – None Nch-open drain Programmable
P71 to P73 – None CMOS Programmable
P80 to P87 – None Nch-open drain None
S0/PA0 to

S47/PF7

COM0/PL0 to

COM3/PL3

V1/PL4 to

V3/PL6

XT1 – None Input only None

– None CMOS Programmable

– None Input only None

– None Input only None

1 CMOS Programmable

2 Nch-open drain None
1 CMOS Programmable P10 to P17 each bit
2 Nch-open drain Programmable
1 CMOS Programmable P30 to P35 each bit
2 Nch-open drain None

(Note 1)

XT2 – None Output for 32.768kHz crystal

oscillation

None

Note 1 Attachment of Port0 programmable pull-up resistors is controllable in nibble units (P00-03, P04-07).

* Note 1: Connect as follows to reduce noise on VDD.

VSS1, VSS2 and VSS3 must be connected together and grounded.

*Note 2 : The power supply for the internal memory is VDD1 but it uses the VDD3 as the power supply for ports. When the

VDD3 is not backed up, the port level does not become “H” even if the port latch is in the “H” level. Therefore,
when the VDD3 is no t backed up and the p ort latc h is “H” level , the por t level is unstabl e in the HOLD mode, and
the back up time becomes shorter because the through current runs from VDD to GND in the input buffer.

If VDD3 is not backed up, output “L” by the program or pull the port to “L” by the external circuit in the HOLD

mode so that the port level becomes “L” level and unnecessary current consumption is prevented.

Power
supply

Back-up capacitors *2

LSI

VDD1

VDD2

VDD3

VSS2 VSS1

VSS3

No.6719-10/24

LC877264A/56A/48A

V

1. Absolute Mximum Ratings at Ta=25°C and VSS1=VSS2=VSS3=0V

Parameter Symbol Pins Conditions

Supply voltage VDDMAX VDD1,VDD2,VDD3 VDD1=VDD2

=VDD3

Supply voltage

for LCD

Input voltage VI Port L

Input/Output

voltage
High
level
output
current

Low
level
output
current

consumption
Operating

temperature
range
Storage
temperature
range

Peak
output
current

Total
output
current

Peak
output
current

Total
output
current

VLCD V1/PL4, V2/PL5,

V3/PL6

XT1,XT2,CF1,

VI0(1) •Port0, 1, 3, 7, 8

•Port A, B, C, D, E, F

IOPH(1) Port 0, 1, 3 •CMOS output

IOPH(2) Port 7 1 ,72,73 Current at each pin -3
IOPH(3) Port A, B, C, D, E, F Current at each pi n -5

IOAH(1) Port 0, 1, 32, 33, 34, 35 Total of all pins -40

Σ

IOAH(2) Port 30, 31 Total of all pins -10

Σ

IOAH(3) Port 7 Total of all pins -5

Σ

IOAH(4) Port A, B, C Total of all pins -25

Σ

IOAH(5) Port D, E, F Total of all pins -25

Σ

IOPL(1) Port 0, 1, 32-3 5 Current at each pin 20
IOPL(2) Port 30, 31 Current at each pin 30
IOPL(3) Port 7,8 Current at each pin 5
IOPL(4) Port A, B,C, D, E, F Current at each pin 15

IOAL(1) Port 0, 1, 32, 33, 34, 35 Total of all pins 60

Σ

IOAL(2) Port 30, 31 Total of all pins 60

Σ

IOAL(3) Port 7,8 Total of all pins 20

Σ

IOAL(4) Port A,B,C Total of all pins 40

Σ

IOAL(5) Port D, E, F Total of all pins 40

Σ

Pdmax

Topg -30 70

Tstg -55 125

QIP100E 500 Maximum power
SQFP100

RES

VDD1=VDD2
=VDD3

-0.3 VDD+0.3

-0.3 VDD+0.3

selected

•Current at each pin

Ta = -30 to +70°C

Ratings

[V]

DD

min. typ. max.

-0.3 +7.0

-0.3 VDD

-10

400

unit

V

mA

mW

C

°

No.6719-11/24

LC877264A/56A/48A

2. Recommended Oerating Range at Ta=-30°C to +70°C, VSS1=VSS2=VSS3=0V

Parameter Symbol Pins Conditions

CYC

CYC

supply voltage
range

VDD(1) 0.294µs≤ t

VDD1=VDD2=VDD3

200µs

VDD(2)

0.735µs ≤ t
200µs

Supply voltage

range in Hold
mode

Input high

voltage

VHD VDD1 Keep RAM and

register data in
HOLD mode.

VIH(1) •Port 0, 3, 8

Output disable 2.5–6.0 0.3VDD

•Port A,B,C,D,E,F,L

VIH(2) •Port 1

Output disable 2.5-6.0 0.3VDD

•Port 71,72, 73

•P70 port input/interrupt
VIH(3) P87 small signal input Output disable 2.5-6.0 0.75VDD VDD
VIH(4) Port 70

Output disable 2.5-6.0 0.9VDD VDD

Watchdog timer

Input low

voltage

VIH(5) XT1, XT2, CF1,
VIL(1) •Port 0, 3, 8

•Port A,B,C,D,E,F,L
VIL(2) •Port 1

2.5-6.0 0.75VDD VDD

RES

Output disable 2.5-6.0 VSS 0.15VDD

Output disable 2.5-6.0 VSS 0.1VDD

•Port 71,72, 73

•P70 port input/interrupt
VIL(3) Port 87 small signal input Output disable 2.5-6.0 VSS 0.25VDD
VIL(4) Port 70

Output disable 2.5-6.0 VSS 0.8VDD

Watchdog timer

VIL(5)

CYC

t

XT1,XT2,CF1,

RES

2.5-6.0 VSS 0.25VDD

cycle time
External system

clock
frequency

FEXCF(1) CF1

•system clock
divider :1/1

•external clock
DUTY = 50±5%

•CF2 open

•system clock
divider :1/2

≤

≤

Ratings

[V]

VDD

min. typ. max.

4.5 6.0 Operating

2.5 6.0

2.0 6.0

+0.7

+0.7

4.5–6.0 0.294 200 Operation

2.5-6.0 0.735 200

4.5–6.0 0.1 10 •CF2 open

2.5-6.0 0.1 4

4.5–6.0 0.2 20

2.5-6.0 0.2 8

Continued/

VDD

VDD

+0.4

+0.4

-1.0

unit

V

s

µ

MHz

No.6719-12/24

LC877264A/56A/48A

Parameter Symbol Pins Conditions

Oscillation

frequency
range

(Note 1)

FmCF(1) CF1, CF2 10MHz ceramic resonator

oscillation

Refer to figure 1

FmCF(2) CF1, CF2 4MHz ceramic resonator

oscillation

Refer to figure 1

FmRC RC oscillation 2.5-6.0 0.3 1.0 2.0

Ratings

VDD[V] min. typ. max.

4.5–6.0 10

2.5–6.0 4

unit

MHz

FsX’tal XT1, XT2 32.768kHz crystal resonator

oscillation

Refer to figure 2

(Note 1) The port value of oscillation circuit is shown in table 1 and table 2.

2.5-6.0 32.768 kHz

No.6719-13/24

LC877264A/56A/48A

3. Electrical Charact er i stics at Ta=-30°C to +70°C, VSS1=VSS2=VSS3=0V

Parameter Symbol Pins Conditions

High level

input
current

IIH(1) •Port 0,1,3,7,8

•Port A,B,C,D,E,F,L

•Output disabled

•Pull-up resister OFF.

•VIN=VDD
(including OFF state leak
current of the output Tr.)

IIH(2)

RES

VIN=VDD 2.5-6.0 1

IIH(3) XT1,XT2 When configured as an input

port

VIN=VDD

IIH(4) CF1 VIN=VDD 2.5-6.0 15

Low level

input

current

IIH(5) P87/AN7/MICIN

small signal input

IIL(1) •Port 0,1,3,7,8

•Port A,B,C,D,E,F,L

VIN=V
(V

+0.5V

BIS

: Bias voltage)

BIS

•Output disabled

•Pull-up resister OFF.

•VIN=VSS

(includi ng OFF state leak

current of the output Tr.)

IIL(2)

RES

VIN=VSS 2.5-6.0 -1

IIL(3) XT1,XT2 When configured as an input

port

VIN=VSS

IIL(4) CF1 VIN=VSS 2.5-6.0 -15

-0.5V

BIS

: Bias voltage)

BIS

High level

output

voltage

Low level

output

voltage

IIL(5) P87/AN7/MICIN

small signal input
VOH(1) IOH=-1.0mA 4.5-6.0 VDD-1
VOH(2)

Port 0,1,3: CMOS

output option

VIN=V
(V

IOH=-0.1mA 2.5–6.0 VDD-0.5
VOH(3) Port 7 IOH=-0.4mA 2.5-6.0 VDD-1
VOH(4) IOH=-1.0mA 4.5–6.0 VDD-1
VOH(5)
VOL(1) IOL=10mA 4.5–6.0 1.5
VOL(2)

Port A,B,C,D,E,F

IOH=-0.1mA 2.5–6.0 VDD-0.5

Port 0,1,3

IOL=1.6mA 2.5–6.0 0.4
VOL(3) Port 30,31 IOL=30mA 4.5–6.0 1.5
VOL(4) IOL=1mA 4.5–6.0 0.4
VOL(5)
VOL(6) IOL=8mA 4.5–6.0 1.5
VOL(7)

Port 7,8

IOL=0.5mA 2.5–6.0 0.4

Port A,B,C,D,E,F

IOL=1.4mA 2.5-6.0 0.4
VODLS S0–S47 I0=0mA

voltage
regulation

VLCD, 2/3VLC D,

1/3VLCD level output

Refer to figure 8
VODLC COM0–COM3 I0=0mA

VLCD, 2/3VLC D, 1/2VLCD

1/3VLCD level output

Refer to figure 8

resistor

RLCD(1) Resistance per one

bias resistor

RLCD(2) •Resistance per one

Refer to figure 8 2.5–6.0 60 LCD bias

Refer to figure 8 2.5–6.0 30

bias resistor

•1/2R mod e

Ratings

VDD[V] min. typ. max.

2.5-6.0 1

2.5-6.0 1

2.5-6.0 4.2 8.5 15

2.5-6.0 -1

2.5-6.0 -1

2.5-6.0 -15 -8.5 -4.2

2.5–6.0 0 ±0.2 LCD output

2.5–6.0 0 ±0.2

unit

A

µ

V

kΩ

Continued/

No.6719-14/24

LC877264A/56A/48A

Parameter Symbol Pins Conditions

pull-up
MOS Tr.

voltage

Pin
capacitance

Input
sensitivity

Rpu •Port 0,1,3,7

•Port A,B,C,D,E,F

VHIS(1) •Port 1,7

RES

•

VHIS(2) Port 87 small signal

input

CP All pins •All other terminals connected

Vsen Port 87 small signal

input

VOH=0.9VDD

2.5-6.0

2.5-6.0

to VSS.

•f=1MHz
=25°C

•

T

a

2.5-6.0 0.12VDD Vpp

VDD[V] min. typ. max.

4.5–6.0 15 40 70 Resistance of

2.5-4.5 25 70 150

2.5-6.0 10 pF

Ratings

0.1VDD

0.1VDD

unit

kΩ

V

Hysterisis

No.6719-15/24

LC877264A/56A/48A

4. Serial Input / Output Characteristics at Ta=-30°C to +70°C, VSS1=VSS2=VSS3=0V

Parameter Symbol Pins Conditions

Cycle time tSCK(1) 4/3

SCK0(P12) Refer to figure 6 2.5-6.0

VDD[V] min. typ. max.

Ratings

unit

CYC

t

pulse width

pulse width

Input clock

Cycle time tSCK(2)

Low level
pulse width
High level
pulse width
Cycle time tSCK(3)

Serial clock

pulse width

pulse width

Output clock

Cycle time tSCK(4)

Low level
pulse width
High level
pulse width

Data set-up time

Data hold time t

Serial input

Output delay
time

Serial output

tSCKL(1)

tSCKLA(1)

tSCKH(1)

tSCKHA(1)

SCK1(P15) Refer to figure 6 2.5-6.0

tSCKL(2)

tSCKH(2)

SCK0(P12) •CMOS output

tSCKL(3)

tSCKLA(2)

tSCKH(3)

tSCKHA(2)

SCK1(P15) •CMOS output

tSCKL(4)

tSCKH(4)

sDI

t

hDI

tdDO SO0(P12),

SI0(P10),
SI1(P13),
SB0(P11),
SB1(P14)

SO1(P15),
SB0(011),
SB1(P14)

•Refer to figure 6

•Refer to figure 6

•Measured with resp ect
to SI0CLK leading
edge.

•Refer to figure 6

•When Port is open
drain:

Time delay form

SIOCLK trailing edge
to the SO data chan ge

•Refer to figure 6

2/3 Low level

2/3

2/3 High level

3

2

1

1

2.5-6.0

2.5-6.0

4.5–6.0 0.03

2.5-6.0 0.1

4.5–6.0 0.03

2.5-6.0 0.1

4.5–6.0 1/3

2.5-6.0 1/3

4/3

1/2 Low level

3/4

1/2 High level

2

2 tCYC

1/2

1/2

tSCK

tSCK

tCYC
+0.05

tCYC
+0.25

s

µ

No.6719-16/24

LC877264A/56A/48A

5. Pulse Input Conditions at Ta=-30°C to +70°C, VSS1=VSS2=VSS3=0V

Parameter Symbol Pins Conditions

•Condition that interrupt is
accepted

•Condition that event input
to timer 0 is accepted

•Condition that interrupt is
accepted

•Condition that event input
to timer 0 is accepted

•Condition that interrupt is
accepted

•Condition that event input
to timer 0 is accepted

•Condition that interrupt is
accepted

•Condition that event input
to timer 0 is accepted

accepted to small signal
detection counter.

•Condition that reset is
accepted

pulse width

tPIH(1)
tPIL(1)

tPIH(2)
tPIL(2)

tPIH(3)
tPIL(3)

tPIH(4)
tPIL(4)

tPIL(5)
tPIL(5)

tPIL(6)

INT0(P70),
INT1(P71),
INT2(P72)

INT3(P73)
(Noise rejection ratio

is 1/1.)

INT3(P73)
(Noise rejection ratio

is 1/32.)

INT3(P73)
(Noise rejection ratio

is 1/128.)

MICIN(P87) •Condition that signal is

RES

VDD[V] min. typ. max.

2.5-6.0 1

2.5-6.0 2

2.5-6.0 64

2.5-6.0 256

2.5-6.0 1

2.5-6.0 200 µs

Ratings

unit

CYC

t

High/low level

6. AD Converter Characteristics at Ta=-30°C to + 70°C, VSS1=VSS2=VSS3=0V

Parameter Symbol Pins Conditions

Resolution N 3.0–6.0 8 bit
Absolute precision ET (Note2) 3.0-6.0
Conversion time TCAD

Analog input

voltage range

current

VAIN 3.0-6.0 VSS VDD V

IAINH VAIN=VDD 3.0-6.0 1 Analog port input
IAINL

AN0(P80)

–AN7(P87)
AN8(P70)
AN9(P71)
AN10(XT1)
AN11(XT2)

AD conversion time

= 32 × tCYC
(ADCR2=0)
(Note 3)

AD conversion time

= 64 × tCYC
(ADCR2=1)
(Note 3)

VAIN=VSS 3.0-6.0 -1

Ratings

VDD[V] min. typ. max.

4.0-6.0 15.62
(tCYC=

0.488µs)

3.0-6.0 23.52
(tCYC=

0.735µs)

4.5-6.0 18.82
(tCYC=

0.294µs)

3.0-6.0 47.04
(tCYC=

0.735µs)

97.92
(tCYC=

3.06µs)

97.92
(tCYC=

3.06µs)

97.92
(tCYC=

1.53µs)

97.92
(tCYC=

1.53µs)

unit

1.5 LSB

±

µ

s

µ

A

(Note 2) Abso lute precision does not include quantizing error (±1/2 LSB).
(Note 3) Conversion time means time from executing AD conversion instruction to loading complete digital value to register.

No.6719-17/24

LC877264A/56A/48A

7. Current Consumption Characte r istics at Ta=-30°C to +70°C, VSS1=VSS2=VSS3=0V

Parameter Symbol Pins Conditions

Current consumption
during normal
operation
(Note 4)

IDDOP(1) •FmCF=10MHz

IDDOP(2) •CF1=20MHz external

IDDOP(3) 4.5–6.0 5.8 17

IDDOP(4)

IDDOP(5) 4.5–6.0 1 10

IDDOP(6)

IDDOP(7) 4.5–6.0 40 140

IDDOP(8)

VDD1=
VDD2=
VDD3

Ceramic resonator

oscillation

•FsX’tal=32.768kHz
crystal oscillation

•System clock: CF
10MHz oscillation

•Internal RC oscillation
stopped.

•Divider : 1/1

clock

•FsX’tal=32.768kHz

crystal oscillation

•System clock: CF1
oscillation

•Internal RC oscillation
stopped.

•Divider :1/ 2

•FmCF=4M Hz Ceramic
resonator oscillation

•FsX’tal=32.768kHz
crystal oscillation

•System clock: CF
4MHz oscillation

•Internal RC oscillation
stopped.

•Divider :1/ 1

•FmCF=0Hz (No
oscillation)

•FsX’tal=32.768kHz
crystal oscillation

•System clock: RC
oscillation

•Divider :1/ 2

•FmCF=0Hz (No
oscillation)

•FsX’tal=32.768kHz
crystal oscillation

•System clock:

32.768kHz

•Internal RC oscillation
stopped.

•Divider :1/ 2

Ratings

VDD[V] min. typ. max

4.5–6.0 12.5 30

4.5–6.0 14 31

2.5–4.5 2.7 11

2.5–4.5 0.5 6

2.5–4.5 16 60

Continued/

unit

mA

A

µ

No.6719-18/24

LC877264A/56A/48A

V
V
V

Parameter Symbol Pins Conditions

Current

consumption

during
HALT mode
(Note 4)

IDDHALT(1) HALT mode

IDDHALT(2) HALT mode

IDDHALT(3) 4.5–6.0 2.2 6
IDDHALT(4)

IDDHALT(5) 4.5–6.0 500 1600
IDDHALT(6)

IDDHALT(7) 4.5–6.0 25 100
IDDHALT(8)

DD1=

•FmCF=10MHz Ceramic

DD2=
DD3

HALT mode

HALT mode

resonator oscillation

•FsX’tal=32.768kHz
crystal oscillation

•System clock :
CF 10MHz oscillation

•Internal RC oscillation
stopped.

•Divider: 1/1

•CF1=20MHz for extern al
clock

•FsX’tal=32.768kHz

crystal oscillation

•System clock :
CF1 oscillation

•Internal RC oscillation
stopped.

•Divider :1/2

HALT mode

•FmCF=4M Hz Ceramic
resonator oscillation

•FsX’tal=32.768kHz
crystal oscillation

•System clock :
CF 4MHz oscillation

•Internal RC oscillation
stopped.

•Divider: 1/1

•FmCF=0Hz
(Oscillation stop)

•FsX’tal=32.768kHz
crystal oscillation

•System clock :
RC oscillation

•Divider: 1/2

•FmCF=0Hz
(Oscillation stop)

•FsX’tal=32.768kHz
crystal oscillation

•System clock : 32.768kHz

•Internal RC oscillation
stopped.

•Divider: 1/2

Ratings

VDD[V] min. typ. max.

4.5–6.0 5 12

4.5–6.0 6 13

2.5–4.5 1.2 5

2.5–4.5 250 1300

2.5–4.5 12 60

unit

mA

A

µ

Continued/

No.6719-19/24

LC877264A/56A/48A

Parameter Symbol Pins Conditions

during HOLD mode

during Date/time
clock HOLD mode

IDDHOLD(1) 4.5–6.0 0.015 25 Current consumption
IDDHOLD(2)

IDDHOLD(3) 4.5–6.0 20 90 Current consumption
IDDHOLD(4)

VDD1 HOLD mode

•CF1=VDD or open
(when using external
clock)

VDD1 Date/time clock HOLD

mode

•CF1=VDD or open
(when using external
clock)

•FmX’tal=32.768kHz
crystal oscillation

Ratings

VDD[V] min. typ. max.

2.5–4.5 0.015 20

2.5–4.5 8 50

(Note 4) The currents through the output transistors and the pull-up MOS transistors are ignored.

unit

A

µ

No.6719-20/24

LC877264A/56A/48A

Main system clock osci llation circuit characteristics

The characteristics in the table bellow is based on the following conditions:

1. Use the standard evaluation board SANYO has pro vided.

2. Use the peripheral parts with indicated value externally.

3. The peripheral parts value is a recommended value of oscillator manufacturer

Table 1. Main system clock oscillation circuit cha racteris tics using ceramic resonator

Oscillation

stabilizing time

typ max

Notes

Frequency Manufacturer Oscillator

10MHz

4MHz

CSA10.0MTZ 33pF 33pF 470Ω 4.5 – 6.0V 0.06ms 0.3ms Murata

CST10.0MTW (30pF) (30pF) 470Ω 4.5 – 6.0V 0.06ms 0.3ms Built in C1,C2

CSA4.00MG 33pF 33pF 680Ω 2.5 – 6.0V 0.05ms 0.2ms Murata

CST4.00MGW (30pF) (30pF) 680Ω 2.5 – 6.0V 0.05ms 0.2ms Built in C1,C2

Circuit parameters

C1 C2 Rd1

supply voltage

Operating

range

The oscillation stabilizing time is a period until the oscillation becomes stable after VDD becomes higher than minimum
operating voltage. (Refer to Figure4)

Subsystem clock osci lla tion circuit characteristics

The characteristics in the table bellow is based on the following conditions:

1. Use t he sta nda rd evaluation board SANYO has provided.

2. Use the peripheral parts with indicated value externally.

3. The peripheral parts value is a recommended value of oscillator manufacturer

Table 2. Subsystem clock oscillation circuit characteristics using crystal oscillator

Oscillation

stabilizing time

typ max

Notes

Frequency Manufacturer Oscillator

C-002RX 32.768MHz Seiko EPSON

MC-306

Circuit parameters

C3 C4 Rf Rd2

18pF 18pF OPEN 390kΩ 2.5 – 6.0V 1.0s 3.0s

Operating

supply voltage

range

The oscillation stabilizing time is a period until the oscillation becomes stable after executing the instruction which starts the
sub-clock oscillation or after releasing the HOLD mode. (Refer to Figure4)

(Notes) • Since the circuit pattern affects the oscillation frequency, place the oscillation-related parts as close to

the oscillation pins as possible with the shortest possible pattern length.

CF2 CF1

Rd1

Rf

C1

CF

C2

C3

X’tal

XT2 XT1

Rd2

C4

Figure 1 Ceramic oscillation circuit Figure 2 Crystal oscillation circuit

No.6719-21/24

LC877264A/56A/48A

,

,

0.5VDD

Figure 3 AC timing measurement poi nt

Power Supply

RES

Reset time

Internal RC

Resonator oscillation

CF1

CF2

XT1

XT2

tmsCF

tmsXtal

Operation mode

Unfixed

Reset Instruction execution mode

Reset time and oscillation stable time

HOLD release signal

Without HOLD

Release signal

HOLD release signal VALID

Internal RC

Resonator oscillation

CF1,CF2

XT1,XT2

tmsCF

tmsXtal

Operation mode

HOLD HALT

HOLD release signal and oscillation stable time

VDD
VDD limit
0V

Figure 4 Oscillation stabilizing time

No.6719-22/24

LC877264A/56A/48A

SIOCLK

DATAIN

DATAOUT

SIOCLK

DATAIN

DATAOUT

SIOCLK

DATAIN

DATAOUT

VDD

(Note)
Select

C

RES

and

R

RES

value to assure that at least
200µs reset time is genera ted after th e VDD beco mes
higher than the minimum operating voltage.

RES

RES

R

C

RES

Figure 5 Reset circuit

DI0 DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8

DO0 DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8

Data RAM

transmission period

(only SIO0)

tSCK

tSCKL tSCKH

tsDI thDI

tdDO

Data RAM

transmission period

(only SIO0)

tSCKLA tSCKHA

tsDI thDI

tdDO

Figure 6 Serial input / output wave form

No.6719-23/24

LC877264A/56A/48A

(

tPIL tPIH

Figure 7 Pulse input timing

VDD

SW : ON/OFF(programmable)

4R

2R

R

R

2R

GND

SW : ON

VLCD

2/3VLCD

1/2VLCD

1/3VLCD

VLCD=VDD)

Figure 8 LCD bias resistor

No.6719-24/24

PS
