Linear Integrated Systems
FEATURES
Direct Replacement for Intersil IT130 Series
Pin for Pin Compatible
ABSOLUTE MAXIMUM RATINGS NOTE 1
(TA= 25°C unless otherwise noted)
I
C
Collector Current 10mA
IT130A IT130 IT131 IT132
MONOLITHIC DUAL
PNP
TRANSISTORS
C1 C2
E1 E2
35
2 6
B1 B2
Maximum Temperatures
Storage Temperature Range -65°C to +200°C
Operating Junction Temperature +150°C
Maximum Power Dissipation ONE SIDE BOTH SIDES
Device Dissipation @ Free Air 250mW 500mW
B1 E1 E2 B2
26 X 29 MILS
1 7
C1 C2
BOTTOM VIEW
Linear Derating Factor 2.3mW/°C 4.3mW/°C
ELECTRICAL CHARACTERISTICS TA= 25°C (unless otherwise noted)
SYMBOL CHARACTERISTICS IT130A IT130 IT131 IT132 UNITS CONDITIONS
BV
BV
BV
BV
h
CBO
CEO
EBO
CCO
FE
Collector to Base Voltage 45 45 45 45 MIN. V IC = 10µAIE = 0
Collector to Emitter Voltage 45 45 45 45 MIN. V IC = 10µAIB = 0
Emitter-Base Breakdown Voltage 6.2 6.2 6.2 6.2 MIN. V IE = 10µAI
Collector to Collector Voltage 60 60 60 60 MIN. V IC = 10µAI
DC Current Gain 200 200 80 80 MIN. IC = 10µAV
225 225 100 100 MIN. IC = 1.0mA V
= 0 NOTE 2
C
= 0
E
CE
CE
= 5V
= 5V
VCE(SAT) Collector Saturation Voltage 0.5 0.5 0.5 0.5 MAX. V IC = 0.5mA IB = 0.05mA
I
EBO
I
CBO
C
OBO
C
C1C2
I
C1C2
f
T
Emitter Cutoff Current 1 1 1 1 MAX. nA I
Collector Cutoff Current 1 1 1 1 MAX. nA I
Output Capacitance 2 2 2 2 MAX. pF IE = 0 V
Collector to Collector Capacitance 4 4 4 4 MAX. pF V
= 0 V
C
= 0 V
E
= 0
CC
EB
CB
CB
= 3V
= 45V
= 5V
Collector to Collector Leakage Current 10 10 10 10 MAX. nA VCC= ±60V
Current Gain Bandwidth Product 110 110 90 90 MIN. MHz IC = 1mA VCE = 5V
NF Narrow Band Noise Figure 3 3 3 3 MAX. dB IC = 100µAVCE = 5V
BW = 200Hz, RG = 10 KΩ
f=1KHz
Linear Integrated Systems
4042 Clipper Court, Fremont, CA 94538 • TEL: (510) 490-9160 • FAX: (510) 353-0261
Page 2
MATCHING CHARACTERISTICS @ 25°C (unless otherwise noted)
SYMBOL CHARACTERISTICS IT130A IT130 IT131 IT132 UNITS CONDITIONS
|V
BE1-VBE2
∆|(V
| Base Emitter Voltage Differential 1 2 3 5 MAX. mV I
BE1-VBE2
)|/∆T Base Emitter Voltage Differential 3 5 10 20 MAX. µV/°CI
= 10 µAVCE = 5V
C
= 10 µAVCE = 5V
C
Change with Temperature T = -55°C to +125°C
- IB2| Base Current Differential 2.5 5 25 25 MAX. nA I
|I
B1
= 10 µAVCE = 5V
C
0.195
0.175
6 LEADS
0.019
0.016
45°
0.046
0.036
TO-71
Six Lead
DIA.
0.030
MAX.
DIA.
0.100
TO-78
(8.13)
0.320
0.290
0.405
(10.29)
MAX.
0.188
0.197
(7.37)
C1 1
B1
E1
N/C
N/C
0.150
0.158
(4.78)
(5.00)
0.230
DIA.
0.209
0.150
0.115
0.500 MIN.
0.050
3
2
4
5
1
8
6
7
0.048
0.028
0.016
0.019
DIM. A
0.016
0.021
DIM. B
45°
0.029
0.045
0.305
0.335
1
0.028
0.034
0.200
3
2
8
7
0.335
0.370
4
5
6
MAX.
0.040
MIN. 0.500
SEATING
PLANE
0.100
0.100
0.165
0.185
P-DIP
C2
8
2
3
45
B2
7
E2
6
N/C
SOIC
(3.81)
(4.01)
C1 1
2
B1
3
E1
N/C
45
0.228
0.244
(5.79)
(6.20)
C2
8
B2
7
6
E2
N/C
NOTES:
1. These ratings are limiting values above which the serviceability of any semiconductor may be impaired.
2. The reverse base-to-emitter voltage must never exceed 6.2 volts; the reverse base-to-emitter current must never exceed 10 µA.
