Waterproof meter incorporates a highly accurate multi-ranging sensor that measures
four parameters - Conductivity, TDS, Salinity, and Temperature
WIth calibration standards, sample plastic cups and
carrying case included for easy travel
ExStik®II Conductivity Kit
Features:
• Autoranging meter offers 3 ranges with 8 units of measure including
μS/cm, mS/cm, ppm, ppt, mg/L, g/L, °F, and °C
• Simultaneous display of Conductivity or TDS
plus Temperature and bargraph
• Memory stores up to 15 labeled readings
• Adjustable Conductivity to TDS ratio factor from 0.4 to 1.0
• Self calibration on power up
• Waterproof to IP57
• Large 3-1/2 digit (2000 count) Digital display
with analog bargraph to indicate sample trends
• Data Hold, Auto Power Off and low battery indication
• Automatic Temperature Compensation of 2% per °C
• Auto standard recognition for calibration
(84μS/cm, 1413μS/cm, and 12880μS/cm)
• Easy to replace Conductivity cell module
• Plastic sample cup and iron cast weighted base
allows for hands-free operation while holding up
the meter during measurement stage
• EC410 kit includes EC400 ExStik® Conductivity/TDS/ Salinity
Temperature Meter, with sensor, protective cap,
84μS/cm, 1413μS/cm and 12880μS/cm calibration standards
(30mL bottle each), weighted base, 3 sample plastic cups
with caps, four 3V CR-2032 batteries, 48" (1.2m) neckstrap,
and carrying case
Patents Pending
Specifications Ranges Max. Resolution Basic Accuracy
Conductivity 0 to 199.9μS/cm 0.1μS/cm ±2% FS
200 to 1999μS/cm 1μS/cm
2.00 to 19.99mS/cm 0.01mS/cm
TDS 0 to 99.9ppm (mg/L) 0.1ppm (mg/L) ±2% FS
100 to 999ppm (mg/L) 1ppm (mg/L)
1.00 to 9.99ppt (g/L) 0.01ppt (g/L)
Salinity 0 to 99.9ppm (mg/L) 0.1ppm (mg/L) ±2% FS
100 to 999ppm (mg/L) 1ppm (mg/L)
1.00 to 9.99ppt (g/L) 0.01ppt (g/L)
Temperature 32° to 149°F (0° to 65°C) 0.1° ±1.8°F/1°C
Power Four SR44W button batteries
Dimensions Meter: 1.4 x 6.8 x 1.6" (36 x 173 x 41mm)
Kit: 9.5 x 6.8 x 2.8" (241 x 173 x 71mm)
Weight Meter: 3.8 oz (110g)
Kit: 1.56 lbs (708g)
Ordering Information:
EC410 ............ExStik®Conductivity/TDS/Salinity Kit
EC400 ............ExStik
®
Conductivity/TDS/Salinity Meter
EC405 ............Spare Conductivity Cell
EC-84-P..........84μS Conductivity Standard (2 bottles - 1 pint each)
EC-1413-P......1413μS Conductivity Standard (2 bottles - 1 pint each)
EC-12880-P....12880μS Conductivity Standard (2 bottles - 1 pint each)
EX007 ............Spare sample solution cups (24pk)
EX010 ............Extension Cable, 3ft (1 Meter) with probe weight for ExStik
EX050 ............Extension Cable, 16ft (5 Meters) with probe weight for ExStik
*ExStik
®
Conductivity cell is not interchangeable with other ExStik®meters
