Datasheet BGE887BO-FC Datasheet (Philips)

DATA SH EET

Product specification
File under Discrete Semiconductors, SC16

1998 Jul 17

DISCRETE SEMICONDUCTORS

BGE887BO/FC

Optical receiver module

ook, halfpage

M3D112

1998 Jul 17 2

Philips Semiconductors Product specification

Optical receiver module BGE887BO/FC

FEATURES

• Excellent linearity

• Extremely low noise

• Excellent flatness

• Standard CATV outline

• Rugged construction

• Gold metallization ensures excellent reliability

• FC/APC connector (JDS version).

APPLICATIONS

• CATV systems operating in the 40 to 860 MHz
frequency range.

DESCRIPTION

Hybrid high dynamic range optical receiver module in a
SOT115N package operating at a voltage supply of
24 V (DC). The module contains a monomode optical
input suitable for wavelengths from 1290 to 1600 nm, a
terminal to monitor the pin diode current and an electrical
output with an impedance of 75 Ω. The optical fibre is
terminated by an FC/APC connector (JDS version) and
partly reinforced by a 3 mm diameter Kevlar buffer.

PINNING - SOT115N

PIN DESCRIPTION

1 monitor current
2 common
3 common
5+V

B

7 common
8 common
9 output

Fig.1 Simplified outline.

handbook, halfpage

789

2

351

Side view

MBK045

QUICK REFERENCE DATA

HANDLING

Fibreglass optical coupling: maximum tensile strength = 5 N; minimum bending radius = 35 mm.

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

f frequency range 40 860 MHz
S

22

output return losses f = 40 to 860 MHz 11 − dB
optical input return losses 40 − dB

d

2

second order distortion f = 324.25 MHz −−70 dBc
F equivalent noise input f = 40 MHz − 7 pA/√Hz
I

tot

total current consumption (DC) VB= 24 V 175 205 mA

CAUTION

This product is supplied in anti-static packing to prevent damage caused by electrostatic discharge during transport
and handling. For further information, refer to Philips specs.: SNW-EQ-608, SNW-FQ-302A and SNW-FQ-302B.

1998 Jul 17 3

Philips Semiconductors Product specification

Optical receiver module BGE887BO/FC

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

CHARACTERISTICS

Bandwidth 40 to 860 MHz; V

B

= 24 V; Tmb=30°C; ZL=75Ω.

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

f frequency range 40 860 MHz
T

stg

storage temperature −40 +85 °C

T

mb

operating mounting base temperature −20 +85 °C

P

in

optical input power continuous − 5mW

ESD ESD sensitivity human body model; R = 1.5 kΩ;

C = 100 pF

500 − V

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

S responsivity λ = 1300 nm 750 − V/W
FL flatness of frequency response −±0.5 dB
S

22

output return losses f1= 40 to 860 MHz 11 − dB
optical input return losses 45 − dB

OBR

C

connector optical return losses 70 − dB

IL

C

connector optical insertion losses − 0.5 dB

d

2

second order distortion note 1 −−70 dB

d

3

third order distortion note 2 −−80 dB

F equivalent noise input f

1

=40MHz − 7 pA/√Hz

s

λ

spectral sensitivity λ = 1310 ±20 nm 0.85 − A/W

λ = 1550 ±20 nm 0.9 − A/W

λ optical wavelength 1290 1600 nm

L length of optical fibre buffered fibre; SM type; 9/125 µm;

Kevlar buffer: 3 mm

577 627 mm

I

tot

total current consumption (DC) note 3 175 205 mA

Notes

1. Two laser test; each laser with 40% modulation index:
fp= 135 MHz; Pp= 0.5 mW;
fq= 189.25 MHz; Pq= 0.5 mW;
measured at fp+fq= 324.25 MHz.

2. Three laser test; each laser with 40% modulation
index:
fp= 326.25 MHz; Pp= 0.33 mW;
fq= 333.25 MHz; Pq= 0.33 mW;
fr= 335.25 MHz; Pr= 0.33 mW;
measured at fp+fq−fr= 324.25 MHz.

3. The module normally operates at VB= 24 V, but is
able to withstand supply transients up to 30 V.

Fig.2 Monitor current pin.

handbook, halfpage

MLB151

10 kΩ

1 kΩ

Pin 1


current

1998 Jul 17 4

Philips Semiconductors Product specification

Optical receiver module BGE887BO/FC

Fig.3 FC/APC connector.

handbook, halfpage

MBH776

50.0

3.85

± 0.1

∅ 10.3

∅ 2.50

∅ 2.0

∅ 3.0

∅ 2.50

0.40

anti-rotation nozzle

anti-rotation nozzle

R 20

8.0°

1998 Jul 17 5

Philips Semiconductors Product specification

Optical receiver module BGE887BO/FC

PACKAGE OUTLINE

UNIT

A

2

max.

c

ee

1

q

Q

max.

q

1

q

2

U

1

max.

U

2

W

REFERENCES

OUTLINE
VERSION

EUROPEAN

PROJECTION

ISSUE DATE

98-03-06

IEC JEDEC EIAJ

mm 20.8 9.1

0.51

0.38

0.25 27.2 2.54 13.75 2.54 5.08 12.7 8.8

627
577

4.15

3.85

2.4 38.1 25.4

10.2

4.2

44.75 8 0.25 0.1

connector

12

bF

2.5M1.6

M

1

0.9

M

2

3

M

3

N

127

77

N

1

10.7

8.7

N

2

5
1

N

3

16.7

16.1

S

1

4.95

4.55

S

2

∅ P

6-32

UNC

yw

S

DIMENSIONS (mm are the original dimensions)

SOT115N

0 5 10 mm

scale

A

max.

D

max.dmax.

L

min.

E

max.

Z

max.

Rectangular single-ended flat package; aluminium flange;
2 vertical mounting holes; 2 x 6-32 UNC and 2 extra horizontal mounting holes;
optical input with connector; 7 gold-plated in-line leads

SOT115N

D

U

1

q

q

2

q

1

b

F

S

S

1

S

2

A

Z P

N

N

1

N

2

N

3

M

M

1

M

2

M

3

E

A

2

L

c

d

Q

U

2

M

w

78923

W

e

e

1

5

P

1

yM

B

yM

B

yM

B

B

1998 Jul 17 6

Philips Semiconductors Product specification

Optical receiver module BGE887BO/FC

DEFINITIONS

LIFE SUPPORT APPLICATIONS

These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.

Data Sheet Status

Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.

Limiting values

Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information

Where application information is given, it is advisory and does not form part of the specification.
