74HC/HCT10
Triple 3-input NAND gate
Product specification
File under Integrated Circuits, IC06
December 1990
Page 2
Philips Semiconductors Product specification
Triple 3-input NAND gate 74HC/HCT10
FEATURES
• Output capability: standard
• ICC category: SSI
GENERAL DESCRIPTION
The 74HC/HCT10 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL).
They are specified in compliance with JEDEC standard no. 7A.
The 74HC/HCT10 provide the 3-input NAND function.
QUICK REFERENCE DATA
GND = 0 V; T
=25°C; tr=tf= 6 ns
amb
SYMBOL PARAMETER CONDITIONS
t
PHL
C
C
I
PD
/ t
PLH
propagation delay nA, nB, nC to nY CL= 15 pF; VCC=5V 9 11 ns
input capacitance 3.5 3.5 pF
power dissipation capacitance per gate notes 1 and 2 12 14 pF
Notes
1. C
is used to determine the dynamic power dissipation (PD in µW):
PD
PD=CPD× V
2
× fi + ∑ (CL× V
CC
2
× fO) where:
CC
fi= input frequency in MHz
fo= output frequency in MHz
CL= output load capacitance in pF
VCC= supply voltage in V
∑ (CL× V
2. For HC the condition is VI= GND to V
2
× fo) = sum of outputs
CC
CC
For HCT the condition is VI= GND to VCC− 1.5 V.
ORDERING INFORMATION
“74HC/HCT/HCU/HCMOS Logic Package Information”
See
.
TYPICAL
UNIT
HC HCT
December 1990 2
Page 3
Philips Semiconductors Product specification
Triple 3-input NAND gate 74HC/HCT10
PIN DESCRIPTION
PIN NO. SYMBOL NAME AND FUNCTION
1, 3, 9 1A to 3A data inputs
2, 4, 10 1B to 3B data inputs
13, 5, 11 1C to 3C data inputs
12, 6, 8 1Y to 3Y data outputs
7 GND ground (0 V)
14 V
CC
positive supply voltage
Fig.1 Pin configuration. Fig.2 Logic symbol.
Fig.4 Functional diagram. Fig.5 Logic diagram (one gate).
Fig.3 IEC logic symbol.
FUNCTION TABLE
INPUTS OUTPUT
nA nB nC nY
LLL H
LLH H
LHL H
LHH H
HLL H
HLH H
HHL H
HHH L
Notes
1. H = HIGH voltage level
L = LOW voltage level
December 1990 3
Page 4
Philips Semiconductors Product specification
Triple 3-input NAND gate 74HC/HCT10
DC CHARACTERISTICS FOR 74HC
For the DC characteristics see
“74HC/HCT/HCU/HCMOS Logic Family Specifications”
Output capability: standard
ICC category: SSI
AC CHARACTERISTICS FOR 74HC
GND = 0 V; t
= 6 ns; CL= 50 pF
r=tf
SYMBOL PARAMETER
t
PHL
/ t
propagation delay
PLH
nA, nB, nC to nY
t
THL
/ t
output transition time 19 75 95 110
TLH
(°C)
T
amb
74HC
+25 −40 to + 85 −40 to + 125
min. typ. max. min. max. min. max.
30 95 120 145
9 16 20 25 6.0
6 13 16 19 6.0
.
UNIT
ns
ns
TEST CONDITIONS
WAVEFORMS
V
CC
(V)
2.0
Fig.611 19 24 29 4.5
2.0
Fig.67 15 19 22 4.5
December 1990 4
Page 5
Philips Semiconductors Product specification
Triple 3-input NAND gate 74HC/HCT10
DC CHARACTERISTICS FOR 74HCT
For the DC characteristics see
“74HC/HCT/HCU/HCMOS Logic Family Specifications”
.
Output capability: standard
ICC category: SSI
Note to HCT types
The value of additional quiescent supply current (∆I
) for a unit load of 1 is given in the family specifications.
CC
To determine ∆ICC per input, multiply this value by the unit load coefficient shown in the table below.
INPUT UNIT LOAD COEFFICIENT
nA, nB, nC 1.5
AC CHARACTERISTICS FOR 74HCT
GND = 0 V; tr=tf= 6 ns; CL= 50 pF
T
amb
(°C)
TEST CONDITIONS
74HCT
SYMBOL PARAMETER
+ 25 −40 to + 85 −40 to +125
UNIT
V
(V)
CC
min. typ. max. min. max. min. max.
t
PHL
/ t
propagation delay
PLH
14 24 30 36 ns 4.5 Fig.6
nA, nB, nC to nY
t
THL
/ t
output transition time 7 15 19 22 ns 4.5 Fig.6
TLH
WAVEFORMS
AC WAVEFORMS
(1) HC : VM= 50%; VI= GND to VCC.
= 1.3 V; VI= GND to 3 V.
HCT: V
M
Fig.6 Waveforms showing the input (nA, nB, nC) to output (nY) propagation delays and the output transition times.
PACKAGE OUTLINES
See
“74HC/HCT/HCU/HCMOS Logic Package Outlines”
.
December 1990 5
