Philips Semiconductors FAST Products Product specification

74F410Register stack – 16×4 RAM 3-State output register

1

January 8, 1990 853-1310 98498

FEATURES

•Edge triggered output register

•ypical access time of 19.5ns

•Optimize for register stack operation

•3–state outputs

•18–pin package

DESCRIPTION

The 74F410 is a register oriented high speed
64–bit read/write memory organized as
16–words by 4–bits. An edge–triggered 4–bit
output register allows new input data to be
written while previous data is held. 3–state
outputs are provided for maximum versatility.

The 74F410 is fully compatible with all TTL
families.

TYPE

TYPICAL
ACCESS

TIME

TYPICAL
SUPPLY

CURRENT

( TOTAL)

74F410 19.5ns 45mA

FUNCTIONAL DESCRIPTION

Write operation – When the three control

inputs, write enable (WE

), chip select (CS),
and clock (CP), are low the information on
the data inputs (D0–D3) is written into the
memory location selected by the address
inputs (A0–A3). If the input data changes

while WE

, CS, and CP are low, the contents
of the selected memory location follow these
changes provided setup and hold time criteria
are met.

Read operation – When CS

is low, WE is
high, and CP goes from low–to–high, the
contents of the memory location selected by
the address inputs (A0–A3) are edge–
triggered into the output register.
When WE

is low, CS is low, CP goes from
low–to–high, the data at the data inputs is
edge–triggered into the output register. The
OE

input controls the output buffers. When

OE

is high the four outputs (Q0–Q3) are in a

high impedance or off state; when OE

is low,

the outputs are determined by the state of the
output register.

ORDERING INFORMATION

ORDER CODE

DESCRIPTION COMMERCIAL RANGE

VCC = 5V ±10%, T

amb

= 0°C to +70°C

18–pin plastic DIP (300mil) N74F410N

INPUT AND OUTPUT LOADING AND FAN OUT TABLE

PINS DESCRIPTION 74F (U.L.)

HIGH/LOW

LOAD VALUE

HIGH/LOW

D0 – D3 Data inputs 1.0/1.0 20µA/0.6mA
A0 – A3 Address inputs 1.0/1.0 20µA/0.6mA

CP Clock pulse input (active rising edge) 1.0/2.0 20µA/1.2mA
CS Chip select input (active low) 1.0/2.0 20µA/1.2mA
OE Output enable input (active low) 1.0/1.0 20µA/0.6mA

WE Write enable input (active low) 1.0/1.0 20µA/0.6mA

Q0 – Q3 Data outputs 150/40 3mA/24mA

NOTE: One (1.0) FAST unit load is defined as: 20µA in the high state and 0.6mA in the low state.

PIN CONFIGURATION LOGIC SYMBOL IEC/IEEE SYMBOL

18
17
16

15
14

13
127

6

5

4

3

2

1

A1

Q1

Q2

D3

D2

D0
Q0

CS

WE

CP

A0

A3

OE

3
4

5
6

11

10

D0 D2 D3D1

Q0 Q1 Q2 Q3

16 14 12 10

15 13 11

118

A2

V

CC

VCC = Pin 18

GND = Pin 9

D1

17

A0
A1
A2
A3
CS

WE

CP

OE

3
4
5
6
1
2
7
8

13

12

15

14

17

16

2
1

A1,2D A3

&

0

1

A

0

15

Q3

GND

109

7

8

&

G1

G2

1C

EN3

Philips Semiconductors FAST Products Product specification

74F410Register stack – 16×4 RAM 3-State output register

January 8, 1990

2

LOGIC DIAGRAM

V

CC

= pin

18
GND = pin 9

Address
decoder

A0
A1
A2
A3

3
4
5
6

RAM

16

4

D0
D1
D2
D3

17
15
13
11

Data

inputs

16

Register

Q0

Q1

Q2

Q3

16

14

12

10

WE
CS
CP

OE

8

15
13
11

ABSOLUTE MAXIMUM RATINGS

(Operation beyond the limit set forth in this table may impair the useful life of the device. Unless otherwise noted these limits are over the
operating free air temperature range.)

SYMBOL

PARAMETER RATING UNIT

V

CC

Supply voltage –0.5 to +7.0 V

V

IN

Input voltage –0.5 to +7.0 V

I

IN

Input current –30 to +5 mA
Voltage applied to output in high output state –0.5 to V

CC

V

I

OUT

Current applied to output in low output state 48 mA

T

amb

Operating free air temperature range 0 to +70

°C

T

stg

Storage temperature range –65 to +150

°C

V

OUT

Philips Semiconductors FAST Products Product specification

74F410Register stack – 16×4 RAM 3-State output register

January 8, 1990

3

RECOMMENDED OPERATING CONDITIONS

SYMBOL PARAMETER LIMITS

T

UNIT

MIN NOM MAX

V

CC

Supply voltage 4.5 5.0 5.5 V

V

IH

High–level input voltage 2.0 V

V

IL

Low–level input voltage 0.8 V

I

Ik

Input clamp current –18 mA

I

OH

High–level output current –3 mA

I

OL

Low–level output current 24 mA
Operating free air temperature range 0 +70

°C

DC ELECTRICAL CHARACTERISTICS

(Over recommended operating free-air temperature range unless otherwise noted.)

SYMBOL

PARAMETER TEST CONDITIONS

1

LIMITS UNIT

MIN TYP

2

MAX

V

OH

High-level output voltage VCC = MIN, VIL = MAX

±10%V

CC

2.4 V

VIH = MIN, IOH = MAX

±5%V

CC

2.7 V

V

OL

Low-level output voltage VCC = MIN, VIL = MAX

±10%V

CC

0.35 0.50 V

VIH = MIN, I

OL

= MAX

±5%V

CC

0.35 0.50 V

V

IK

Input clamp voltage VCC = MIN, II = I

IK

-0.73 -1.2 V

I

I

Input current at maximum input voltage VCC = MAX, VI = 7.0V 100

µA

I

IH

High–level input current VCC = MAX, VI = 2.7V 20

µA

I

IL

Low–level input current others VCC = MAX, VI = 0.5V -0.6 mA

CP, CS -1.2 mA

I

OZH

Offset–output current,
high–level voltage applied

VCC = MAX, VI = 2.7V 50 µA

I

OZL

Offset–output current,
low–level voltage applied

VCC = MAX, VI = 0.5V –50 µA

I

OS

Short-circuit output current

3

VCC = MAX -60 -150 mA

I

CC

Supply current (total) VCC = MAX 45 70 mA

NOTES:

1. For conditions shown as MIN or MAX, use the appropriate value specified under recommended operating conditions for the applicable type.

2. All typical values are at V

CC

= 5V, T

amb

= 25°C.

3. Not more than one output should be shorted at a time. For testing IOS, the use of high-speed test apparatus and/or sample-and-hold
techniques are preferable in order to minimize internal heating and more accurately reflect operational values. Otherwise, prolonged shorting
of a high output may raise the chip temperature well above normal and thereby cause invalid readings in other parameter tests. In any
sequence of parameter tests, I

OS

tests should be performed last.

T

amb

Philips Semiconductors FAST Products Product specification

74F410Register stack – 16×4 RAM 3-State output register

January 8, 1990

4

AC ELECTRICAL CHARACTERISTICS

LIMITS

T

amb

= +25°C T

amb

= 0°C to +70°C

SYMBOL PARAMETER TEST VCC = +5.0V

VCC = +5.0V ± 10%

UNIT

CONDITION

CL = 50pF, RL = 500Ω CL = 50pF, RL = 500Ω

MIN TYP MAX MIN MAX

t

PLH

t

PHL

Waveform 1

4.0

4.5

6.5

6.5

8.5

9.0

3.5

4.0

9.5

10.0

ns

t

PZH

t

PZL

to Qn

Waveform 3, 4

3.0

4.5

4.5

6.0

7.5

9.0

2.5

3.5

8.5

9.5

ns

t

PHZ

t

PHL

to Qn

Waveform 3, 4

2.0

2.0

3.5

3.5

6.0

6.5

1.5

2.0

6.5

7.0

ns

AC SETUP REQUIREMENTS FOR READ MODE

LIMITS

T

amb

= +25°C T

amb

= 0°C to +70°C

SYMBOL PARAMETER TEST VCC = +5.0V

VCC = +5.0V ± 10%

UNIT

CONDITION

CL = 50pF, RL = 500Ω CL = 50pF, RL = 500Ω

MIN TYP MAX MIN MAX

tsu(L)

to CP

1

Waveform 1 4.0 4.5 ns

th(L) Hold time, low, CS to CP

1

Waveform 1 3.5 4.5 ns

tsu(H)
t

su

(L)

Waveform 1

13.0

13.0

15.0

15.0

ns

th(H)
t

h

(L)

Hold time, high or low
An to CP

1

Waveform 1

0
0

0
0

ns

tsu(H)

to CP

1

Waveform 1 13.0 15.0 ns

th(H)

to CP

1

Waveform 1 0 0 ns

tw(L) CP pulse width, low Waveform 1 5.0 6.0 ns

NOTE:

1. Low–to–high clock transition.

AC SETUP REQUIREMENTS FOR WRITE MODE

LIMITS

T

amb

= +25°C T

amb

= 0°C to +70°C

SYMBOL PARAMETER TEST VCC = +5.0V

VCC = +5.0V ± 10%

UNIT

CONDITION

CL = 50pF, RL = 500Ω CL = 50pF, RL = 500Ω

MIN TYP MAX MIN MAX

tsu(H)
t

su

(L)

, CS, CP

Waveform 2

0
0

0
0

ns

th(H)
t

h

(L)

Hold time, high or low
An to WE

, CS, CP

Waveform 2

0
0

0
0

ns

tsu(H)
t

su

(L)

, CS, CP

Waveform 2

6.0

6.0

8.0

8.0

ns

th(H)
t

h

(L)

Hold time, high or low
Dn to WE

, CS, CP

Waveform 2

0
0

0
0

ns

tw(L) WE pulse width, low Waveform 2 7.0 8.0 ns
tw(L) CS pulse width, low Waveform 2 6.0 7.0 ns
tw(L) CP pulse width, low Waveform 2 7.0 8.0 ns

Propagation dealy
CP to Qn

Output enable time
OE

Output disable time
OE

Setup time, low, CS

Setup time, high or low
An to CP

1

Setup time, high, WE
Hold time, high, WE

Setup time, high or low
An to WE

Setup time, high or low
Dn to WE

Philips Semiconductors FAST Products Product specification

74F410Register stack – 16×4 RAM 3-State output register

January 8, 1990

5

AC WAVEFORMS

Waveform 1. Read cycle timing

CP

VMV

M

V

M

V

M

V

M

V

M

tsu(H)

th(H)

An

V

M

tw(H)

tsu(L)

t

h

(L)

V

M

V

M

Qn

t

w

(L)

t

PLH

Waveform 2. Write cycle timing

WE

V

M

V

M

V

M

V

M

V

M

V

M

CS

tsu(H)

th(H)

tsu(L)

th(L)

tsu(L)

th(L)

V

M

tsu(H)

t

h

(H)

V

M

V

M

V

M

V

M

V

M

tsu(H) th(H)

An,
Dn

t

su

(L)

t

h

(L)

V

M

V

M

V

M

V

M

CS
WE
CP

Waveform 3. 3-State output enable time to high level

and output disable time from high level

V

M

V

M

V

M

t

PHZ

t

PZH

VOH -0.3V

0V

OE

Qn

Waveform 4. 3-State output enable time to low level

and output disable time from low level

V

M

V

M

V

M

t

PLZ

t

PZL

VOL +0.3V

Qn

OE

t

PHL

NOTES:

1. For all waveforms, VM = 1.5V.

2. The shaded areas indicate when the input is permitted to change for predictable output performance.

TEST CIRCUIT AND WAVEFORM

t

W

90%

V

M

10%

90%

V

M

10%

90%

V

M

10%

90%

V

M

10%

NEGATIVE
PULSE

POSITIVE
PULSE

t

W

AMP (V)

0V

0V

t

THL (tf

)

INPUT PULSE REQUIREMENTS

rep. rate

t

W

t

TLHtTHL

1MHz 500ns 2.5ns

2.5ns

Input pulse definition

V

CC

family

74F

D.U.T.

PULSE

GENERATOR

R

L

C

L

R

T

V

IN

V

OUT

Test circuit for 3–state outputs

DEFINITIONS:

R

L

= Load resistor; see AC electrical characteristics for

value.

C

L

= Load capacitance includes jig and probe

capacitance; see AC electrical characteristics for
value

R

T

= Termination resistance should be equal to Z

OUT

of

pulse generators.

t

THL (tf

)

t

TLH (tr

)

t

TLH (tr

)

AMP (V)

amplitude

3.0V

1.5V

V

M

R

L

7.0V

SWITCH POSITION

TEST SWITCH

closed

openAll other

t

PLZ

, t

PZL
