Product Datasheet Date: 08/02/2015
High pressure mercury lamp HRL 250W/230/E40
Logistic Data
Article No. 32208922
Code HRL 250W/230/E40
Product EAN 4008597089220
Customs tariff no. 85393220
Box quantitiy (pcs.) 12
EAN Box 4008597489228
Gross weight of box in kg 3.289
Length of box in m 0.43
Width of box in m 0.35
Height of box in m 0.26
Pieces per palette 432
EAN Palett 4008597689222
ETIM class EC000056
ETIM class name High pressure mercury lamp
Electric Parameters
Lamp nominal wattage 250 W
Rated wattage 242.4 W
Mains voltage 230 V
Supply frequency 50
Lamp's nominal current 2,2
Nominal choke current 2.15 A
Running up current max. 140%
Compensation capacitor for 50Hz
operation
Energy Consumption kWh/1000h 275
Fuse Daelay-action; min. double nominal current
18 µF
Light Application Parameters
Luminous flux 13000 lm
Rated lamp luminous flux 13000 lm
Luminous efficiency of lamp 53.63 lm/W
Colour temperature 4000 K
Colour rendering index Ra 46
Colour rendering group 40-59 (Klasse 3)
Radium Lampenwerk GmbH · P.O. Box 1440 · 51678 Wipperfürth/Germany · Dr.-Eugen-Kersting-Str. 6 · 51688 Wipperfürth/Germany
Managing Director: Andreas Steinert · Chairman of the Supervisory Board: Peter Mannhart
Registry Court: Köln HRB 37474 · WEEE-Reg-Nr. DE 36655118
Page 2
Service Life
Mean service life 20000 h
Info about service life 12B50, 50Hz
Lamp survival factor at 2000h 0.99
Lamp survival factor at 4000h 0.99
Lamp survival factor at 6000h 0.99
Lamp survival factor at 8000h 0.99
Lamp survival factor at 12000h 0.99
Lamp survival factor at 16000h 0.97
Lamp survival factor at 20000h 0.92
Lumen maintenance at 2000h 0.95
Lumen maintenance at 4000h 0.92
Lumen maintenance at 6000h 0.91
Lumen maintenance at 8000h 0.89
Lumen maintenance at 12000h 0.84
Lumen maintenance at 16000h 0.78
Lumen maintenance at 20000h 0.77
Operation mode for LLMF/LSF 50 Hz
Specification
Diameter max. 91 mm
Length max. 226 mm
Overall length 226 mm
Controllable (in suitable circuit) up to 50% (run-up at nominal power)
dimmable nein
Energylabel from 2013 B
Mercury content 39.1 mg
Base E40
Lamp shape ellipsoidal
Notes on Operation
Starter / Ingnitor not rquired
Ignition assured down to about (°C) -20
Operation with CCG (choke coil) +
Re-ignition behaviour after 3-10min. Cooling normal ignition
Burning position hs30
possible
Miscellaneous
EU Directive TIM
EU-date of phase-out 13.04.2015
ILCOS name QE-250-H-E40
LBS name HME250W E40
Notes:
High pressure mercury vapour lamp, no CE-marking for newly made product
after Apr 13th 2015
Radium Lampenwerk GmbH · P.O. Box 1440 · 51678 Wipperfürth/Germany · Dr.-Eugen-Kersting-Str. 6 · 51688 Wipperfürth/Germany
Managing Director: Andreas Steinert · Chairman of the Supervisory Board: Peter Mannhart
Registry Court: Köln HRB 37474 · WEEE-Reg-Nr. DE 36655118
Page 3
Please, refer to www.radium.de/recycling for notes on disposal of burned-out lamps as well as lamp breakage.
The field 'info about service life' contains the frame conditions according to standards based on which the specific service
life has been determined. So, for example, "12B50, 50Hz" means that the mean service life (B50) has been determined
with a 12h switching cycle at mains (frequency 50Hz), "3B50, HF" is based on a 3h switching cycle at electronic control
gear (high frequency).
Radium Lampenwerk GmbH · P.O. Box 1440 · 51678 Wipperfürth/Germany · Dr.-Eugen-Kersting-Str. 6 · 51688 Wipperfürth/Germany
Managing Director: Andreas Steinert · Chairman of the Supervisory Board: Peter Mannhart
Registry Court: Köln HRB 37474 · WEEE-Reg-Nr. DE 36655118
Page 4
Notes
Base
E40
IEC/EN 60061-1
sheet 7004-24-6
Spectrum
Natural daylight is a mixture of direct sunlight and the light of the sky. Therefore, its spectral composition
changes permanently due to the changing time of day. The standardised light classification D65 corresponds
to a daylight with a colour temperature of approximately 6500 K.
Every discharge lamp type has got an individual spectral power distribution according to its chemical filling.
From this result important properties light colour or colour rendering.
Should the spectral lines be very close together the lamp presumably has got a very good colour rendering
index, so, Ra might be near 100. Does the spectrum rather look like single lines or frayed out the colour
rendering of the lamp will probably be not as good.
If number and height of the spectral lines within the blue range (around 400 nm) prevails it might be a lamp
with a rather cold light colour like for example daylight. On the other hand, should the red (around 700 nm) or
the red and yellow (around 600 nm) range be dominant one can assume that the lamp will be a rather warm
light colour like WDL.
After the lamp start a mercury vapour lamp needs about 5 minutes time to reach its full luminous flux.
Visible region from 380 to 780 nm; height of graph corresponding with relative spectral emission (400mW/klm)
per 10nm.
HRL (4200K) daylight(D 65)
Radium Lampenwerk GmbH · P.O. Box 1440 · 51678 Wipperfürth/Germany · Dr.-Eugen-Kersting-Str. 6 · 51688 Wipperfürth/Germany
Managing Director: Andreas Steinert · Chairman of the Supervisory Board: Peter Mannhart
Registry Court: Köln HRB 37474 · WEEE-Reg-Nr. DE 36655118
Page 5
Circuit diagram(s)
Standard circuit HID with internal ignitor
Key:
L. = lamp
VG = ballast electromagnetic (KVG/VVG)
P = phase
N = zero potential
K = p. f. correction capacitor
The required control gear (here ballast only) for the lamp’s
operation is usually mounted in the suitable luminaire in an
appropriate electric circuit. Changes of any kind are to be
conducted by qualified and specialised staff, only. Thus, this
circuit example is to be understood merely as a technical
background information for interested users.
Special features
Please, dump as special waste, no ordinary household
waste!
From last due date April 13th 2015, product does not
comply with EU directives regarding energy efficiency any
more.
Please, choose alternative product or look for remainders
(sale of articles in stock is still allowed).
General notes
The technical design data in accordance with DIN and IEC. The producer does not take any responsibility for
damage to persons or property in case of unsuitable operation or handling of the product. Operating data and
dimensions are valid within the usual tolerances. Related lamp types (different bases, mains voltages) may be
available on request. Sale and delivery are effected in accordance with the Radium Terms of Delivery and
Payment valid on the day of conclusion of contract. Packing units offer economical advantages to the purchase
and logistic department. Please match your quantity volume accordingly. For orders of a minimum quantity
(clefts) with a lamp model the amount lower than the volume of each packaging unit, we will invoice 10 %
additional charge per lamp type. Technical changes and terms of delivery are reserved. Manipulation of any
kind to packaging or product is not permissible as this will violate Radium brand rights. Furthermore, technical
properties of the product can change to its disadvantage or even destruction. Therefore, Radium cannot be
responsible for consequential damages.
® = Registered trademark
Subject to change without notice. Errors and omissions excepted.
Radium Lampenwerk GmbH · P.O. Box 1440 · 51678 Wipperfürth/Germany · Dr.-Eugen-Kersting-Str. 6 · 51688 Wipperfürth/Germany
Managing Director: Andreas Steinert · Chairman of the Supervisory Board: Peter Mannhart
Registry Court: Köln HRB 37474 · WEEE-Reg-Nr. DE 36655118
Page 6
All technical data without guarantee.
