HIGH VOLTAGE GENERAL PURPOSE

DESCRI PTIO N

The 2N720A is a silicon planarepitaxial NPN tran­sistorinJedec TO-18 metal case. It is suitable for a
wide variety of amplifier and switchingapplications.

2N720A

TO-18

INTERNAL SCHEMATIC DIAGRAM

ABSOLUTEMAXIMUMRATINGS

Symbol Parameter Value Unit

V

CBO

V

CEO

V

EBO

I

P

T

stg,Tj

C

tot

Collector-base Voltage (IE=0) 120 V
Collector–emitter Voltage (IR=0) 80 V
Emitter–base Voltage (IC=0) 7 V
Collector Current 500 mA
Total Power Dissipation at T

at T

Storage and Junction Temperature – 65 to 200 °C

amb
case

≤ 25 °C

≤ 25 °C

0.5

1.8

W
W

October 1988

1/4

2N720A

THERMAL DATA

R

th j-case

R

th j-amb

ELECTRICAL CHARACTERISTICS(T

Thermal Resistance Junction-case
Thermal Resistance Junction-ambient

=25°C unless otherwise specified)

amb

Max
Max

97.2
350

Symbol Parameter Test Conditions Min. Typ. Max. Unit

I

CBO

Collector Cutoff Current

VCB=90V 10 nA

(IE=0)

V

(BR)CBO

Collector–base Breakdown

=100µA 120 V

I

C

Voltage
(I

=0)

E

V

(BR)CEO

* Collector–emitter Breakdown

=30mA 80 V

I

C

Voltage
(I

=0)

B

V

(BR)EB O

Emitter–base Breakdown

=100µA7 V

I

E

Voltage
(I

=0)

E

I

EBO

Emitter Cuttoff Current

VEB=5V 10 nA

(IE=0)

V

V

* Collector–emitter Saturation

CE(sat)

Voltage

* Base–emitter Saturation

BE(sat)

Voltage

h

* DC Current Gain IC=100µA

FE

IC=50mA
I

C

IC=50mA
I

C

IC=10mA
IC=150mA

h

fe

C

CBO

High Frequency Current
Gain

IC=50mA
f=20MHz

Collector–base Capacitance IE=0

=150mA

=150mA

=5mA

I

B

I

=15mA

B

=5mA

I

B

I

=15mA

B

VCE=10V
VCE=10V
VCE=10V

20
35
40 120

1.2
5

0.9

1.3

VCE= 10 V 2.5 –

VCB=10V 15 pF

f = 1 MHz

C

EBO

Emitter–base Capacitance IC=0

VEB= 0.5 V 85 pF

f = 1 MHz

* Pulsed : pulse duration = 300 µs, duty cycle = 1 %.

°C/W
°C/W

V
V

V
V

–
–
–

2/4

TO-18 MECHANICAL DATA

2N720A

DIM.

MIN. TYP. MAX. MIN. TYP. MAX.

A 12.7 0.500

B 0.49 0.019

D 5.3 0.208

E 4.9 0.193

F 5.8 0.228

G 2.54 0.100

H 1.2 0.047

I 1.16 0.045

L45

o

mm inch

o

45

G

I

H

DA

F

E

L

B

C

0016043

3/4

2N720A
