2021-25
25 Watts, 24 Volts, Class C
Microwave 2000 - 2130 MHz
GENERAL DESCRIPTION
The 2021-25 is a COMMON BASE transistor capable of providing 25 Watts,
Class C output power over the band 2000-2130 MHz. The transistor includes
input and output prematching for full Broadband capability. Gold
metalization and diffused ballasting are used to provide high reliability and
supreme ruggedness. The transistor uses a fully hermetic High Temperature
Solder Sealed package.
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25 C 58 Watts
Maximum Voltage and Current
BVces Collector to Emitter Voltage 40 Volts
BVebo Emitter to Base Voltage 3.5 Volts
Ic Collector Current 3.0 Amps
Ma xi mum Te mperatures
Storage Temperature - 65 to + 200 C
Operating Junction Temperature + 200 C
ELECTRICAL CHARACTERISTICS @ 25 C
SYMBOL CHARACTERISTICS TEST
o
o
o
O
CONDITIONS
CASE OUTLINE
55AW, STYLE 1
MIN TYP MAX UNITS
Pout
Pin
Pg
η
c
VSWR1
BVces
BVebo
Hfe
Cob
θ
jc
* Not measureable due to internal prematch network
