Datalogic has taken reasonable measures to provide information in this manual that is complete and accurate, however, Datalogic
reserves the right to change any specification at any time without prior notice.
Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U.
All other brand and product names may be trademarks of their respective owners.
Magellan is a registered trademark of Datalogic ADC, Inc. in many countries, including the U.S.A. and All-Weighs, FirstStrike and
SurroundScan are registered trademarks of Datalogic ADC, Inc. in the U.S.A. OmegaTek, Produce Rail, Productivity Index Reporting
and SmartSentry are all trademarks of Datalogic ADC, Inc.
-
This product may be covered by one or more of the following patents:
About This Manual .............................................................................................................................................................................1
Connecting the Scanner .....................................................................................................................................................................2
Using the Programming Barcodes ........................................................................................................................................... 3
Resetting the Standard Product Defaults .......................................................................................................................................3
LED and Beeper Indicators ................................................................................................................................................................4
Chapter 2. General Features..................................................................................................................................................................... 7
Double Read Timeout for Linear Labels ...........................................................................................................................................7
Double Read Timeout for 2D Labels ................................................................................................................................................. 9
Productivity Index Reporting (PIR) ..................................................................................................................................................10
LED and Beeper Indicators ..............................................................................................................................................................13
Power On Alert ......................................................................................................................................................................... 13
ERI Active State High ............................................................................................................................................................... 13
ERI Timeout .............................................................................................................................................................................. 14
Good Read: When to Indicate .................................................................................................................................................15
Good Read Beep Control ......................................................................................................................................................... 16
Good Read Beep Frequency ....................................................................................................................................................16
Good Read Beep Length .......................................................................................................................................................... 17
Good Read Beep Volume ........................................................................................................................................................ 18
Green Spot ................................................................................................................................................................................ 18
Scanning Features ............................................................................................................................................................................20
Target Mode Active Time ........................................................................................................................................................ 20
Target Mode Linger Time ........................................................................................................................................................ 21
Wake Up Intensity ................................................................................................................................................................... 22
How to Capture an Image ....................................................................................................................................................... 23
Interface Features ............................................................................................................................................................................35
RS-232 Interface Features ..................................................................................................................................................... 37
Hardware Flow Control ..................................................................................................................................................................................39
Software Flow Control ....................................................................................................................................................................................41
Signal Voltage: Normal/TTL ..........................................................................................................................................................................43
Beep on ASCII BEL ............................................................................................................................................................................................44
Beep on Not on File .........................................................................................................................................................................................44
ACK Character .................................................................................................................................................................................................... 46
NAK Character ................................................................................................................................................................................................... 46
Retry on ACK NAK Timeout .......................................................................................................................................................................... 47
ACK NAK Timeout Value ................................................................................................................................................................................ 47
USB-OEM Interface Features .................................................................................................................................................50
IBM ............................................................................................................................................................................................51
IBM Transmit Labels in Code 39 Format ..................................................................................................................................................51
USB Keyboard ...........................................................................................................................................................................52
Caps Lock State .................................................................................................................................................................................................54
USB COM Interface Set-up .............................................................................................................................................................. 58
Chapter 4. Data Editing........................................................................................................................................................................... 59
Data Editing Overview ..................................................................................................................................................................... 59
Please Keep In Mind... .............................................................................................................................................................59
Global Prefix/Suffix ......................................................................................................................................................................... 60
AIM ID ................................................................................................................................................................................................ 62
Label ID ............................................................................................................................................................................................. 63
Case Conversion ............................................................................................................................................................................... 70
Character Conversion ...................................................................................................................................................................... 71
Expand UPC-A to EAN-13 .......................................................................................................................................................74
Number System Transmission ..............................................................................................................................................75
Number System Digit .............................................................................................................................................................. 78
Expand to UPC-E to UPC-A ..................................................................................................................................................... 78
Expand UPC-E to EAN13 .........................................................................................................................................................79
Expand UPC/EAN to GTIN .......................................................................................................................................................80
EAN-13 Flag 1 Character ........................................................................................................................................................82
ISBN ...........................................................................................................................................................................................82
EAN Two-Label Type 1 ............................................................................................................................................................86
EAN Two-Label Type 2 ............................................................................................................................................................87
EAN Two-Label Type 3 ............................................................................................................................................................88
EAN Two-Label Type 4 ............................................................................................................................................................89
Length Control .......................................................................................................................................................................100
Coupon Read Control .............................................................................................................................................................103
Check Character Calculation .................................................................................................................................................106
Check Character Transmit ....................................................................................................................................................107
Code 39 Full ASCII ..................................................................................................................................................................108
Length Control .......................................................................................................................................................................109
Quiet Zones ............................................................................................................................................................................110
Code 32 Italian Pharmacode — continued .........................................................................................................................113
Check Character Transmit ....................................................................................................................................................113
Transmit Function Characters .............................................................................................................................................115
Length Control .......................................................................................................................................................................116
Length Control .......................................................................................................................................................................121
Check Character Verification ................................................................................................................................................ 125
Check Character Transmit ....................................................................................................................................................126
Length Control .......................................................................................................................................................................127
Quiet Zones .....................................................................................................................................................................................................128
Start/Stop Character Type ....................................................................................................................................................129
Start/Stop Character Transmission ....................................................................................................................................129
Start/Stop Character Match .................................................................................................................................................130
Length Control .......................................................................................................................................................................133
Number of Check Characters ................................................................................................................................................137
Length Control .......................................................................................................................................................................138
Standard 2 of 5 ............................................................................................................................................................................... 142
Disable/Enable Standard 2 of 5 ...........................................................................................................................................142
Length Control .......................................................................................................................................................................144
Standard 2 of 5 Length 1, Length 2 Programming Instructions .......................................................................................145
Standard 2 of 5 Stitching ......................................................................................................................................................146
2D Decode Time Max .............................................................................................................................................................149
PDF 417 ...................................................................................................................................................................................150
Disable/Enable PDF 417 ...............................................................................................................................................................................150
Length Control ................................................................................................................................................................................................151
PDF 417 Length 1, Length 2 Programming Instructions .................................................................................................................152
Micro PDF 417 ........................................................................................................................................................................153
Disable/Enable Micro PDF 417 ..................................................................................................................................................................153
Length Control ................................................................................................................................................................................................154
Micro PDF 417 Length 1, Length 2 Programming Instructions .....................................................................................................155
Length Control ................................................................................................................................................................................................157
QR Code ...................................................................................................................................................................................159
Disable/Enable QR Code ..............................................................................................................................................................................159
Length Control ................................................................................................................................................................................................160
QR Code Length 1, Length 2 Programming Instructions ................................................................................................................161
Length Control ................................................................................................................................................................................................163
Length Control ................................................................................................................................................................................................166
Appendix A. Product Specifications....................................................................................................................... 173
Optical and Read Performance Parameters ............................................................................................................................... 173
Other Parameters .......................................................................................................................................................................... 174
Chapter B. Cable Pinouts ...................................................................................................................................................................... 175
Standard Cable Pinouts (Primary Interface Cables) ................................................................................................................... 175
IBM Port 5B/9B/17 ...............................................................................................................................................................175
USB, USB Keyboard & USB COM ........................................................................................................................................... 176
Appendix C. Alpha-Numeric Pad ............................................................................................................................ 177
Appendix D. Default Settings ................................................................................................................................. 179
Defaults by Symbology ................................................................................................................................................................. 179
IBM Interfaces ........................................................................................................................................................................180
Appendix G. Sample Symbols................................................................................................................................. 193
1D Symbol Samples ....................................................................................................................................................................... 193
The Magellan
easily handled items and handheld scanning for bulkier items. Its aggressive imaging performance and intuitive operation reduces user training and speeds checkout for better customer
ser
vice.
About This Manual
This manual presents advanced user information which includes connection, programming,
product and cable specifications, and other useful references. For additional information, such
as installation, maintenance, troubleshooting and warranty information, see the Quick Reference Guide (QRG). Copies of other publications for
charge from the website listed on the back cover of this manual.
Chapter 1
Getting Started
TM
1100i Omni-Directional Imaging Scanner offers hands-free scanning for small,
this product are downloadable free of
On leaving the factory, units are programmed for the most comm
tions settings. If you need to change these settings, custom programming can be accompli
by scanning the barcodes in this guide.
Bold text and a yellow-highlighted background indicates the most common default setting for a
featur
e/option.
Manual Conventions
The symbols listed below are used in this manual to notify the reader of key issues or procedures
that must be observed when using the scanner:
CAUTION
NOTE
Notes contain information necessary
f
or properly diagnosing, repairing and
operating the scanner.
The CAUTION symbol advises you of
ac
tions that could damage equipment
or property.
on terminal and communica-
shed
Product Reference Guide
1
Getting Started
I/F Cable
Connect
Here
A/C Adapter
(if needed)
For 220-230 VAC
adapters, the
cord must be
facing down as
shown in the
illustration. If
installed upwards,
it will pose an
undue strain on the
socket outlet.
To Host/Terminal
U
S
B
I
B
M
K
e
y
b
o
a
r
d
W
e
d
g
e
or...
or...
Connecting the Scanner
The scanner kit you ordered to match your interface should provide a compatible cable for your
installation. Use the appropriate instructions below to connect the scanner to the terminal, PC
or other host device.
Upon completing the connection via the appropriate inter
Interface Related Features section of this manual and scan the barcode to select the correct
the
face instructions below, proceed to
interface type.
RS-232 Serial Connection —
to the terminal/PC serial port via the RS-232 cable as shown in
Turn off power to the terminal/PC and connect the scanner
Figure 1. If the terminal will not
support POT (Power Off the Terminal) to supply scanner power, use the approved power supply
(A
C Adapter). Plug the AC Adapter barrel connector into the socket on the RS-232 cable con-
nector and the AC Adapter plug into a standar
Figure 1
USB Connection —
. RS-232 Serial or USB Connection using A/C Adapter
Connect the scanner to a USB port on the terminal/PC using the correct
USB cable for the interface type you ordered. Reference
d power outlet.
Figure 1 and Figure 2.
USB installations may require a power connection via an
proved A/C Adapter as shown in
ap
Figure 1. For example, this
would be the case if the scanner is connected along with a
mber of other devices to a non-powered USB hub.
NOTE
nu
Figure 2. Other Connection Types
2
MagellanTM 1100i
Programming
Standard Product Default Set-
IBM Connection —
Connect the scanner to the IBM port on the terminal/PC using the cor-
rect IBM cable. Reference
Keyboard Wedge Connection —
The Keyboard Wedge cable has a ‘Y’ connection from the scanner. Connect the female to the
male end from the keyboard and the remaining end at the keyboard port at the terminal/PC.
Reference
Figure 2.
Programming
The scanner is typically factory-configured with a set of default features standard to the interface
type you ordered. After scanning the interface barcode from the
tion, you can select other options and customize y
and programming barcodes available in that section and also the
chapters of this manual.
Using the Programming Barcodes
This manual contains feature descriptions and barcodes which allow you to reconfigure your
scanner. Some programming barcode labels, like the label below for resetting defaults, require
only the scan of that single label to enact the change. Most of the programming labels in this
manual, however, require the scanner to be placed in Programming Mode prior to scanning
them. Scan a START/END barcode once to enterProgramming Mode. Once the scanner is in
Programming Mode, you can scan a number of parameter settings before scanning the START/
END barcode a second time, which will then accept your changes, exit Programming Mode and
return the scanner to normal operation.
Figure 2.
Before connection, turn off power to the terminal/PC.
Interface Related Features sec-
our scanner through use of the instructions
Data Editing and Symbologies
Resetting the Standard Product Defaults
If you are unsure of what programming options are in your scanner, or you’ve changed some
options and want the factory settings restored, scan the Standard Product Default Settings bar-
code below. This will copy the factory configuration for the currently active interface to the current configuration
The programming section lists the factory default settings for each
the standard RS-232 interface in
tings for the other interfaces can be found in
.
BOLD text on the following pages. Exceptions to default set-
of the menu commands for
Appendix D, Default Settings.
Product Reference Guide
3
Getting Started
LED and Beeper Indicators
The scanner’s beeper sounds and its green LED illuminates to indicate various functions or
errors on the scanner. The tables below list these indications. One exception to the behaviors
listed in the tables is that the scanner’s functions are programmable, and may or may not be
turned on. For example, certain indications, such as the power-up beep can be disabled using
programming barcode labels.
Green LED Indications
LED
INDICATION
Power-on
indication
Good Read
Indication
Scanner
Ready
Sleep Mode
Host Disable
Diagnostics
Prog. ModeSee
Bright green flash
Bright green flashIndicates a barcode has been read and decoded.
Constant dim greenThe scanner is ready for operation.
Constant green flash
(100mS on, 1900mS off)
Constant green flash at 1 Hz
100mS on, 900mS off)
(
Varies (see
page 1-5
Host Disable above.The scanner is in Programming Mode.
BEEPER FUNCTIONS
INDICATIONCOMMENT
Indicates the scanner has finished all its power up tests
d is now ready for operation.
an
The scanner is in Sleep Mode. To wake the scanner up,
ve an object in front of its window or press the button
mo
atop the unit.
The scanner is disabled due to receiving a disble command from the POS terminal.
Error Codes on
for more information)
The LED can provide diagnostic feedback if the scanner
d
iscovers a problem during SelfTest.
BEEPER
INDICATION
Power On
Beep
Good Read
Indication
Diagnostics
Programming
de
Mo
Indications
4
INDICATIONCOMMENT
Single beep
Single beep
Varies (see
page 1-5
Varies depending upon the feature(s) being configured.
Error Codes on
for more information)
The Power-On LED indication is a configurable feature
which can b
beep Indicates the scanner has finished all its power up
tests and is now ready for operation.
The good read beep indication is configurable. Options
de: Enable/disable, frequency, duration and vol-
inclu
ume. See the Product Reference Guide (PRG) for
re information.
mo
The Beeper can provide diagnostic feedback if the
sc
anner discovers a problem during SelfTest.
The Beeper will sound as programming barc
are scanned, indicating progress during scanner configuration.
e enabled or disabled. When enabled, this
ode labels
MagellanTM 1100i
Error Codes
Error Codes
Upon startup, if the scanner flashes its indicator LED or sounds an unexpected series of beep
tones (other than normal power-up indications), this means the scanner has not passed its auto-
1
matic Selftest and has entered FRU
isolation mode. If the scanner is reset or the trigger is
pulled, the sequence will be repeated. The following table describes the LED flashes/beep codes
associated with
an error found.
NUMBER OF
LED
FLASHES/
ERRORCORRECTIVE ACTION
BEEPS
1
2
6
10
12
13
14
Configuration
Interface PCB
Main PCB
Button Error
Contact Helpdesk for assistance
Imager Module
Software ID
Failure
CPLD/Code
Mismatch
1. Field Replaceable Unit (FRU)
Product Reference Guide
5
Getting Started
NOTES
6
MagellanTM 1100i
Double Read Timeout for Linear Labels
This Double Read Timeout feature sets a time limit that determines how much time must
pass before reading the same linear label again (e.g. two identical items in succession).
PROGRAMMING BARCODES
0.1 Second
Chapter 2
General Features
START / END
0.3 Second
0.5 Second
0.2 Second
0.4 Second
DEFAULT
0.6 Second
Product Reference Guide
7
General Features
Double Read Timeout for Linear Labels — cont.
START / END
PROGRAMMING BARCODES
0.7 Second
0.8 Second
0.9 Second
1 Second
8
MagellanTM 1100i
Double Read Timeout for 2D Labels
This Double Read Timeout feature specifies the minimum allowable time between consecutive good reads of the same PDF 417, Micro P
Aztec or Composite label.
PROGRAMMING BARCODES
1.5 Seconds
Double Read Timeout for 2D Labels
DF 417 Data Matrix, QR Code, Maxicode,
START / END
1.65 Seconds
1.8 Seconds
DEFAULT
2 Seconds
1.95 Seconds
2.55 Seconds
Product Reference Guide
9
General Features
Label Gone Timeout
This feature sets the time after the last label segment is seen before the scanner prepares for
a new label.
START / END
PROGRAMMING BARCODES
Sets the label gone timeout duration using hex
(10ms or 0.01 seconds). To configure this feature, scan the “START/END” barcode above to place the unit in
Programming Mode, then the “Set Linear Label Gone Timeout,” followed by the three digits (zero padded)
from the Alphanumeric table in
gramming mode by scanning the “START/END” barcode again.
DEFAULT SETTING FOR THIS FEA
Appendix C, Alpha-Numeric Pad representing the desired time value. Exit pro-
values from 000 to 255 in increments of ten milliseconds
TURE: 320 milliseconds (032)
Set Linear Label Gone Timeout
Productivity Index Reporting (PIR)
When PIR is enabled, label quality data is appended to decoded data before being presented
to the POS. The PIR feature allows the scanner to provide information to an external computer, indicating how easy the
This value-added feature is a factory-programmed option. Contact your dealer for
ormation about upgrading your system
inf
NOTE
Disable
DEFAULT
to include this advanced capability.
PROGRAMMING BARCODES
label was to read.
START / END
10
Enable
MagellanTM 1100i
Sleep Mode
Sleep Mode
This feature specifies the amount of time with no barcode reads before the scanner enters
sleep mode.
START / END
PROGRAMMING BARCODES
Disable Sleep Mode
15 Seconds
30 Seconds
1 Minute
3 Minutes
5 Minutes
2 Minutes
4 Minutes
Product Reference Guide
11
General Features
Sleep Mode — cont.
START / END
7 Minutes
PROGRAMMING BARCODES
6 Minutes
8 Minutes
9 Minutes
12 Minutes
30 Minutes
10 Minutes
DEFAULT
15 Minutes
1 Hour
12
MagellanTM 1100i
LED and Beeper Indicators
Power On Alert
Disables or enables the indication (a single beep) that the scanner has finished all its power
up tests and is now ready for operation.
Disable
LED and Beeper Indicators
START / END
PROGRAMMING BARCODES
Enable
DEFAULT
ERI Active State High
This setting specifies the active-state polarity of the External Read Indicator signal to High;
the inactive state is the opposite polarity.
START / END
NOTE
Contact Technical Support for assistance in changing the ERI Active State
t
o Low if needed. Configuration of this
feature is available only through use of
a special cable.
PROGRAMMING BARCODES
ERI Active State = High
Product Reference Guide
13
General Features
ERI Timeout
Specifies the amount of time the External Read Indicator (ERI) signal is held active for a
good read.
START / END
PROGRAMMING BARCODES
Sets the ERI timeout duration using hex
0.01 seconds). To configure this feature, scan the “START/END” barcode above to place the unit in Programming Mode, then the “Set ERI Timeout,” followed by the two digits (zero padded) from the Alphanumeric
able in
t
Appendix C, Alpha-Numeric Pad representing the desired time value. Exit programming mode by scan-
ning the “START/END” barcode again.
DEFAULT SETTING FOR THIS FEA
values from 000 to 255 in increments of ten milliseconds (10ms or
TURE: 20 milliseconds (02)
Set ERI Timeout
14
MagellanTM 1100i
Good Read: When to Indicate
This feature specifies when the scanner will provide indication (beep and/or flash its green
LED) upon successfully reading a barcode. Choices are:
•Good Read = Indicate after decode
•Good Read = Indicate after transmit
LED and Beeper Indicators
•Good Read = Indicate after CTS goes inactive, then activ
This option (Indicate after CTS goes inactive,
t
hen active), which uses CTS, is only valid for
RS-232 interfaces.
NOTE
START / END
PROGRAMMING BARCODES
After Decode
DEFAULT
After Transmit
e
After CTS goes inactive, then active
Product Reference Guide
15
General Features
Good Read Beep Control
This feature enables/disables the scanner’s ability to beep upon a successful decode of a barcode.
Disable
START / END
PROGRAMMING BARCODES
Enable
DEFAULT
Good Read Beep Frequency
Adjusts the good read beep to sound at a selectable low, medium or high frequency, selectable from the list below. (Control
Low
High
s the beeper’s pitch/tone.)
START / END
PROGRAMMING BARCODES
Medium
DEFAULT
16
MagellanTM 1100i
Good Read Beep Length
Specifies the duration of a good read beep.
60msec
100msec
LED and Beeper Indicators
START / END
PROGRAMMING BARCODES
80msec
DEFAULT
140msec
180msec
120msec
160msec
200msec
Product Reference Guide
17
General Features
Good Read Beep Volume
Selects the beeper volume (loudness) upon a good read beep. There are three selectable volume levels.
Low
High
DEFAULT
START / END
PROGRAMMING BARCODES
Medium
Green Spot
This feature enables / disables the green spot activation when good read is activated.
START / END
PROGRAMMING BARCODES
Disable
DEFAULT
Enable
18
MagellanTM 1100i
Aiming Pointer Settings
Enabes/disables Aiming Pointer for all symbologies.
Disable
DEFAULT
LED and Beeper Indicators
START / END
PROGRAMMING BARCODES
Enable
Product Reference Guide
19
General Features
Scanning Features
Targeted Scanning Mode
Upon pressing the button, the scanner will project an aiming pattern to assist in centering
over the barcode. Scanning then takes place as soon as the button is released.
Configuration options for Targeted Scanning Mode are:
•Target Mode Active Time
NOTE
When add-ons are enabled and a barcode
is being read
position the pointer at or near the end of
the base label to ensure the scanner will
read both the base and add-on label.
Targeted Scanning Mode will read barcodes in any orientation.
The scanner will return to full pattern
ni-directional Mode after
Om
Active Time
while in Targeted Mode,
Target Mode
has elapsed.
•Target Mode Linger Time
Target Mode Active Time
Specifies the time duration the scanner attempts to decode labels while in the targeted mode
of operation.
Extra Short Duration
Medium Duration
DEFAULT
START / END
PROGRAMMING BARCODES
Short Duration
20
Long Duration
MagellanTM 1100i
Target Mode Linger Time
Specifies the time duration the scanner remains in the targeted mode of operation after reading a barcode before reverting to Omni-directional Mode.
START / END
Medium Duration
DEFAULT
Scanning Features
PROGRAMMING BARCODES
Short Duration
Long Duration
Product Reference Guide
21
General Features
Wake Up Intensity
This feature indicates the percentage of ambient light change which will trigger the scanner
to wake up from Sleep Mode. Lower settings provide greater sensitivity. The seelectable
range for this setting is 5% to 15%.
START / END
PROGRAMMING BARCODES
5%
6%
7%
9%
11%
8%
10%
DEFAULT
12%
22
MagellanTM 1100i
Wake Up Intensity — cont.
PROGRAMMING BARCODES
13
%
15%
Image Capture
START / END
14%
Image Capture
This function is ONLY available for scanners having a button.
Image capture requires that the scanner use the Standard RS232 or USB COM interface
NOTE
The scanner reverts to default reading mode after image capture
nd transfer.
a
How to Capture an Image
To initiate an Image Capture, scan the IMAGE CAPTURE label below, and press the button.
A targeting “pointer” will be illuminated while the button is pressed.
Upon release of the button, the image is
not pushed within 30 seconds, the scanner will return to barcode reading (scanning) mode.
By default, images are captured as 752 x 480 JPEG format with
ratio, and are displayed via the host application software.
ONLY.
captured and transmitted to the host. If the button is
a minimum compression
IMAGE CAPTURE
Product Reference Guide
23
General Features
Image Compression
Specifies the starting image compression factor for JPEG images. A higher number specifies
a higher quality image with less compression than a relative lower number for the same
image.
Image Size
A value of 100 means minimal compression. A value
of 1 means maximum compression at
a loss of quality. Follow these steps to program this feature:
1. Scan the START barcode.
2. Scan the Set Image Compression barcode.
3. Turn to
Alpha-Numeric Pad and scan the two digits (zero-padded) representing the
desired compression. The configurable range is 01-0x64 by increments of 01.
4. Scan the END barcode.
START / END
PROGRAMMING BARCODES
Set Image Compression
DEFAULT SETTING IS
100 (minimal compression — higher quality)
Specifies the size of the image capture. Choices are:
•WVGA
•VGA
START / END
PROGRAMMING BARCODES
Image Size = VGA
Image Size = WVGA
DEFAULT
24
MagellanTM 1100i
Image Brightness
This feature sets the image brightness value. Follow these instructions to configure this feature:
1. Scan the START barcode.
2. Scan the Set Image Brightness barcode.
Image Capture
Image Contrast
3. Turn to
Alpha-Numeric Pad and scan the two digits (zero-padded) representing the
desired brightness in decimal notation. The configurable range is 01-0x0A by increments of 01.
4. Scan the END barcode.
START / END
PROGRAMMING BARCODES
Set Image Brightness
DEFAULT SETTING FOR THIS FEATURE: 09
This feature sets the image contrast value. Follow these instructions to configure this feature:
1. Scan the START barcode.
2. Scan the Set Image Contrast barcode.
3. Turn to
desired contrast in decimal notation. The configurable
Alpha-Numeric Pad and scan the two digits (zero-padded) representing the
range is 01-0x0A by increments
of 01.
4. Scan the END barcode.
START / END
PROGRAMMING BARCODES
Set Image Contrast
DEFAULT SETTING FOR THIS FEATURE: 09
Product Reference Guide
25
General Features
Cell Phone Mode
Cell Phone Mode enables the scanner to read barcodes on a cell phone display.
Cell Phone Mode Enable
Enables/disables Cell Phone Mode.
START / END
Cell Phone Mode = Enable
PROGRAMMING BARCODES
Cell Phone Mode = Disable
DEFAULT
26
MagellanTM 1100i
Cell Phone Detection Sensitivity
These settings control various pixel characteristics in order to optimize cell phone detection.
Follow these instructions to configure this feature:
Cell Phone Mode
1. Determine which sensitivity level is desired (high, medium or
2. Scan the START barcode to place the scanner in
3. Scan the three barcodes for the detection sensiti
Unlike typical feature settings, Cel
requires the scanning of THREE barcodes to set the level. For
example, to set a high detection sensitivity level, scan barcodes
NOTE
HIGH #1, HIGH #2 and HIGH #3.
Programming Mode.
vity desired.
l Phone Detection Sensitivity
4. Scan the END barcode.
START / END
PROGRAMMING BARCODES
Cell Phone Detection Sensitivity = HIGH
HIGH #1
low).
HIGH #2
HIGH #3
Product Reference Guide
27
General Features
Cell Phone Detection Sensitivity — continued
START / END
PROGRAMMING BARCODES
Cell Phone Detection Sensitivity = MEDIUM
[This is the DEFAULT setting]
MEDIUM #2
MEDIUM #1
LOW #2
MEDIUM #3
Cell Phone Detection Sensitivity = LOW
LOW #1
LOW #3
28
MagellanTM 1100i
Cell Phone in Target Mode
This feature sets the reader’s Cell Phone Mode when it is in Target Mode:
NOTE
Cell Phone Mode
This feature is only available when Cell Phone Mode is enabled.
No Cell Phone Mode —
Auto Detection Cell Phone Mode —
Will not read cell phone labels when in Target Mode.
Automatically detects cell phone labels and shifts to
Cell Phone Mode when in Target Mode.
Always Enter Cell Phone Mode —
The reader will always enter Cell Phone Mode when-
ever it is in Target Mode.
Follow these instructions to configure this feature:
1. Determine which mode is desired from the
2. Scan the START barcode to place the scanner in
selections above.
Programming Mode.
3. Scan the two barcodes which configure the desired mode.
4. Scan the END barcode.
START / END
PROGRAMMING BARCODES
Cell Phone in Target Mode = No Cell Phone Mode
[
This is the DEFAULT setting]
No Cell Phone Mode #1
No Cell Phone Mode #2
Product Reference Guide
29
General Features
Cell Phone in Target Mode — continued
START / END
PROGRAMMING BARCODES
Cell Phone in Target Mode = Auto Detection Cell Phone Mode
Auto Detection Cell Phone Mode #2
Cell Phone in Target Mode = Always Enter Cell Phone Mode
Auto Detection Cell Phone Mode #1
Always Enter Cell Phone Mode #2
Always Enter Cell Phone Mode #1
30
MagellanTM 1100i
Chapter 3
Interface Related Features
At the time of this writing, the reader supports the interfaces listed in Table 3-1. Select the
desired interface type from the table, then
able features section associated with each interface. See
Keyboard Wedge interface type (A thro
Table 3-1. Interfaces Supported
RS-232Page Keyboard Wedge3-34
RS-232 Standard
RS-232 Wincor-Nixdorf
IBM3-34
IBM 4683 Port 5B
IBM 4683 Port 9B
IBM 4683 Port 17
USB3-34
USB-OEM
USB Keyboard
USB COM Interface
a. Consult Table 3-2 for more information regarding keyboard interface
S
FPS/2 25 and 30 w/Standard Key Encoding
GIBM 3xxx w/122 keyboard
HIBM 3xxx w/102 keyboard
IPS/55 5530T w/104 keyboard
JNEC 9801
Reference
Mappings
Appendix E, Keyboard Function Key
for more information about key-
boards.
Encoding
32
MagellanTM 1100i
Interface Selection
START / END
RS-232 Wincor-Nixdorf
Interface Selection
PROGRAMMING BARCODES
RS-232 Standard
IBM 4683 Port 5B
IBM 4683 Port 9B
USB-OEM
USB COM Interface
IBM 4683 Port 17
USB Keyboard
Product Reference Guide
33
Interface Related Features
Interface Selection — cont.
START / END
PROGRAMMING BARCODES
Keyboard Wedge A
Keyboard Wedge C
Keyboard Wedge B
Keyboard Wedge E
Keyboard Wedge G
Keyboard Wedge I
Keyboard Wedge D
Keyboard Wedge F
\
Keyboard Wedge H
34
Keyboard Wedge J
MagellanTM 1100i
Interface Features
Obey/Ignore Host Commands
When set to ignore host commands, the scanner will ignore all host commands except for the
minimum set necessary to keep the interface active and transmit labels For normal operation
of the interface, select Obey Host Commands.
START / END
Interface Features
PROGRAMMING BARCODES
Obey Host Commands
DEFAULT
Ignore Host Commands
Product Reference Guide
35
Interface Related Features
Interface Features — cont.
Host Transmission Buffers
Specifies the number of host transmission(s) that may be buffered. By buffering data from a
barcode, the scanner can continue to read a new barcode while the old one is being transmitted to the host. Selecting BUFFERS = 1 means that
before a new one can be read. A selection of BUFFERS = 2 means that a new barcode can be
read while data from the first barcode is transmitted.
When a DISABLE SCANNER command is received from the
tinue to transmit all data that
START / END
PROGRAMMING BARCODES
the first barcode must be transmitted
host, the scanner will con-
is buffered.
Host Transmission Buffers = 1
Host Transmission Buffers = 2
DEFAULT
36
MagellanTM 1100i
RS-232 Interface Features
START / END
2400 Baud
9600 Baud
DEFAULT
Interface Features
PROGRAMMING BARCODES
1200 Baud
4800 Baud
38400 Baud
115200 Baud
19200 Baud
57600 Baud
Product Reference Guide
37
Interface Related Features
RS-232 Interface Features — cont.
START / END
PROGRAMMING BARCODES
8 Data Bits
DEFAULT
7 Data Bits
1 Stop Bit
DEFAULT
2 Stop Bits
Parity = Even
Parity = None
DEFAULT
Parity = Odd
38
MagellanTM 1100i
RS-232 Interface Features — cont.
Hardware Flow Control
Interface Features
Disable Hardware Control—
The scanner transmits to the host regardless of any activity
on the CTS line.
Enable CTS Flow Control—
Enable CTS Scan Control—
The CTS signal controls transmission of data to the host.
The CTS line must be active for the scanner to read and transmit data. While the CTS line is inactive, the scanne
ing a successful label transmission, the CTS signal must tra
active to enable scanning for the next label.
START / END
PROGRAMMING BARCODES
Enable CTS Flow Control
r remains in a host-disabled state; follow-
nsition to inactive and then to
Disable Hardware Control
DEFAULT
Enable CTS Scan Control
Product Reference Guide
39
Interface Related Features
RS-232 Interface Features — cont.
Intercharacter Delay
This delay is inserted after each data character transmitted. If the transmission speed is too
high, the system may not be able to receive all characters. You may need to adjust the delay
to make the system work properly.
START / END
PROGRAMMING BARCODES
Interchar Delay = 10 msec
Inter-Char Delay = No Delay
DEFAULT
Interchar Delay = 30 msec
Interchar Delay = 50 msec
Interchar Delay = 70 msec
Interchar Delay = 20 msec
Interchar Delay = 40 msec
Interchar Delay = 60 msec
40
MagellanTM 1100i
Intercharacter Delay — cont.
START / END
PROGRAMMING BARCODES
Interchar Delay = 80 msec
Interchar Delay = 90 msec
Software Flow Control
Disables/Enables software control using XON/XOFF characters.
START / END
Interface Features
PROGRAMMING BARCODES
Enable Software Flow Control
Disable Software Flow Control
DEFAULT
Product Reference Guide
41
Interface Related Features
RS-232 Interface Features — cont.
Host Echo Quiet Interval
This setting specifies the time interval of RS-232 channel inactivity which must transpire
before the scanner will break the host echo loop to transmit the barcode data that has just
been scanned to the host.
START / END
PROGRAMMING BARCODES
Host Echo Quiet Interval = 10msec
DEFAULT
Host Echo Quiet Interval = 0msec
Host Echo Quiet Interval = 30msec
Host Echo Quiet Interval = 50msec
Host Echo Quiet Interval = 70msec
Host Echo Quiet Interval = 20msec
Host Echo Quiet Interval = 40msec
Host Echo Quiet Interval = 60msec
42
MagellanTM 1100i
Host Echo Quiet Interval — cont.
START / END
PROGRAMMING BARCODES
Host Echo Quiet Interval = 90msec
Interface Features
Host Echo Quiet Interval = 80msec
Host Echo Quiet Interval = 100msec
Signal Voltage: Normal/TTL
Specifies whether the RS-232 interface provides TTL levels on the output pins TxD and
RTS.
START / END
PROGRAMMING BARCODES
Signal Voltage: Normal RS-232
DEFAULT
Signal Voltage: TTL
Product Reference Guide
43
Interface Related Features
Beep on ASCII BEL
Enables/disables ability of scanner to beep (sound a good read tone) on receiving an ASCII
BEL (07 hex).
Disable Beep on ASCII BEL
Beep on Not on File
START / END
PROGRAMMING BARCODES
Enable Beep on ASCII BEL
DEFAULT
Select for the host to beep (or not) when a not-on-file (host command) condition is detected
by the host.
START / END
PROGRAMMING BARCODES
Disable Beep on Not On File
Enable Beep on Not On File
DEFAULT
44
MagellanTM 1100i
Interface Features
ACK NAK Options
This enables/disables the ability of the scanner to support the RS-232 ACK/NAK protocol.
When configured, the scanner and/or host sends an “ACK” when it receives data properly,
and sends “NAK” when the data is in error. Selections for this option are:
•Disable
•Enable for label transmission — the scanner expects an ACK
host when a label is sent
•Enable for host-command acknowledge —
when the host sends a command
•Enable for label transmission and host-command acknowledge
START / END
PROGRAMMING BARCODES
Enable ACK NAK for Transmission
/NAK response from the
the scanner will respond with ACK/NAK
Disable ACK NAK
DEFAULT
Enable ACK NAK for transmission and host command
Enable ACK NAK for host command acknowledge
Product Reference Guide
45
Interface Related Features
RS-232 Interface Features — cont. — cont.
ACK Character
START / END
PROGRAMMING BARCODES
Sets the ACK character from the set of ASCII characters or any decimal value from 000 to 255. Pad entries
f less than three digits with zeros, as in “005”. To configure this feature, scan the “START/END” barcode
o
above to place the unit in Programming Mode, then the “Set ACK Character,” followed by the digits from the
Alphanumeric table in
mode by again scanning the “START/END” barcode above.
Appendix C, Alpha-Numeric Pad representing your desired character. Exit programming
DEFAULT SETTING FOR THIS FEATURE: 006
Set ACK Character
NAK Character
START / END
PROGRAMMING BARCODES
Sets the NAK character from the set of ASCII characters or any decimal value from 000 to 255. Pad entries
f less than three digits with zeros, as in “005”. To configure this feature, scan the “START/END” barcode
o
above to place the unit in Programming Mode, then the “Set NAK Character,” followed by the digits from the
Alphanumeric table in
mode by again scanning the “START/END” barcode above.
Appendix C, Alpha-Numeric Pad representing your desired character. Exit programming
DEFAULT SETTING FOR THIS FEATURE: 021
Set NAK Character
46
MagellanTM 1100i
RS-232 Interface Features — cont.
Retry on ACK NAK Timeout
Enables/disables retry after the configurable ACK NAK Timeout Value (set in the following
feature) has expired.
START / END
PROGRAMMING BARCODES
Enable Retry on ACK NAK Timeout
DEFAULT
Interface Features
Disable Retry on ACK NAK Timeout
ACK NAK Timeout Value
START / END
PROGRAMMING BARCODES
This item specifies the time the scanner
mission.
000 = Infinite timeout
001 - 075 = Timeout in 200-millis
To configure this feature, scan the “START/END” barcod
then the “Set ACK NAK Timeout Value,” followed by the three digits (zero padded) from the Alphanumeric
table in
scanning the “START/END” barcode above.
Appendix C, Alpha-Numeric Pad representing your desired value. Exit programming mode by again
DEFAULT SETTING FOR THIS FEATURE: 001 (200 msec)
econd increments
will wait for an ACK character from the host following a label trans-
e above to place the unit in Programming Mode,
Set ACK NAK Timeout Value
Product Reference Guide
47
Interface Related Features
RS-232 Interface Features — cont.
ACK NAK Retry Count
START / END
PROGRAMMING BARCODES
This feature sets the number of times for the scanner to retry a label transmission under a retry condition.
000 = No retry
001 - 254 = Retry for the specified number of times
255 = Retry forever
To configure this feature, scan the “START/END” barcod
then the “Set ACK NAK Retry Count,” followed by the three digits (zero padded) from the Alphanumeric table
Appendix C, Alpha-Numeric Pad representing your desired retry count. Exit programming mode by again
in
scanning the “START/END” barcode above
DEFAULT SETTING FOR THIS FEATURE: 003
e above to place the unit in Programming Mode,
Set ACK NAK Timeout Value
48
MagellanTM 1100i
RS-232 Interface Features — cont.
ACK NAK Error Handling
This item specifies the method the scanner will use to handle errors detected while waiting
to receive the ACK character from the host. Errors include unrecognized host commands
and communication errors such as parity or framing errors. Choices are:
00 = Ignore errors detected (recommended setting)
01 = Process error as valid ACK character (risk of lost label data)
02 = Process error as valid NAK character (risk of duplicate label data)
START / END
PROGRAMMING BARCODES
Interface Features
Ignore Errors Detected
DEFAULT
Process error as valid ACK character
Process error as valid NAK character
Product Reference Guide
49
Interface Related Features
RS-232 Interface Features — cont.
Transmission Failure Indication
Enables/disables bad-label indication upon transmission failure.
START / END
PROGRAMMING BARCODES
Enable Transmission Error Indication
DEFAULT
Disable Transmission Error Indication
USB-OEM Interface Features
USB-OEM Device usage
The USB-OEM protocol allows for the scanner to be identified as one of two different types
of barcode scanners. Depending on what other scanners you may already have connected to
a USB-OEM POS, you may need to change this setting to enable all devices to communicate. Options are:
•Table Top Scanner
•Handheld Scanner
START / END
Configure as Handheld Scanner
PROGRAMMING BARCODES
Configure as Table Top Scanner
DEFAULT
50
MagellanTM 1100i
IBM
Interface Features
IBM Transmit Labels in Code 39 Format
This feature enables/disables scanner's ability to set a symbology identifier for a specified
label to Code 39 before transmitting that label data to an IBM host. This applies to: Code
128, Codabar and Code 93 for USB-OEM; Code 128, Codabar and Code 93 for IBM Port
5B; and Codabar and Code 93 for IBM Port 9B.
START / END
PROGRAMMING BARCODES
Disable Convert to Code 39
DEFAULT
Enable Convert to Code 39
Product Reference Guide
51
Interface Related Features
Keyboard Wedge
and
USB Keyboard
As a keyboard interface, the scanner supports most popular PCs and IBM terminals. The
installation of the wedge is a fairly simple process that doesn’t require any changes of software or hardware.
Keyboard Layout
The Keyboard Layout option supports many countries. For details about Keyboard Layout,
please refer to your operating system manual.
NOTE
START / END
All of the options in this section apply to the
board Wedge, however, only some
Key
apply to USB Keyboard.
PROGRAMMING BARCODES
Belgium
Denmark
Germany
USA
DEFAULT
Britain
France
52
MagellanTM 1100i
Keyboard Wedge — cont.
START / END
Norway
Interface Features
PROGRAMMING BARCODES
Italy
Portugal
Spain
Switzerland
Hungary
Sweden
Japan 106 Key
Czech Republic
Product Reference Guide
53
Interface Related Features
Keyboard Wedge — cont.
START / END
Romania
Poland
PROGRAMMING BARCODES
Slov
akia
Croatia
Caps Lock State
Specifies the format in which the scanner sends character data.
START / END
PROGRAMMING BARCODES
Disable Caps Lock
DEFAULT
Caps Lock “ON”
Shift Lock “ON”
54
MagellanTM 1100i
Keyboard Wedge — cont.
Power-On Simulation
This feature does not apply to the USB Keyboard interface.
NOTE
All PCs check the keyboard status during the power-on Selftest. It is recommended that you
enable this function if you are working without a keyboard installation. It simulates keyboard timing and passes the keyboard sta
START / END
Interface Features
tus to the PC during power-on.
PROGRAMMING BARCODES
Disable Power-on Simulation
DEFAULT
Enable Power-on Simulation
Product Reference Guide
55
Interface Related Features
Control Characters
Specifies how the scanner transmits ASCII control characters to the host. Choices are:
•Disable Control Characters
•Enable transmission of control cha
•Send characters between 00H and 1FH according to
table. (This is used to send keys that are not in the normal ASCII set; a unique set is
provided for each available scancode set. Reference
Mappings
START / END
Enable Transmission of Control Characters
.)
PROGRAMMING BARCODES
racters to host
a special function-key mapping
Appendix E, Keyboard Function Key
Disable Control Characters
DEFAULT
Enable Function Key Mapping
56
MagellanTM 1100i
Interface Features
Keyboard Wedge — cont.
Wedge Quiet Interval
This feature does not apply to the USB Keyboard interface.
NOTE
Quiet Interval is the amount of time to look for keyboard activity before the scanner breaks
the keyboard connection in order to transmit data to the host.
START / END
PROGRAMMING BARCODES
Selectable from 001 to 100 in 10 msec increments. To configure this feature, scan the “START/END” bar
e above to place the unit in Programming Mode, then the
cod
the three digits (zero padded) from the Alphanumeric table in
your desired length. Exit programming mode by a
DEFAULT SETTING FOR THIS FEATURE:
gain scanning the “START/END” bar code above.
10 (100 msec)
0
Set Wedge Quiet Interval bar code followed by
Appendix C, Alpha-Numeric Pad representing
Set Wedge Quiet Interval
Product Reference Guide
57
Interface Related Features
Keyboard Wedge — cont.
Intercharacter Delay
START / END
PROGRAMMING BARCODES
One-half of the delay specified below is inserted between scancodes within each character. If the transmission speed is too high, the system may not be able to receive all characters. You may need to adjust the
to make the system work properly. Selectable from 00 to 99 in 10msec increments.
delay
To configure this feature, scan the “START/END” barcode above to place the unit in Programming Mode,
en the “Set Intercharacter Delay,” followed by the three digits (zero padded) from the Alphanumeric table in
th
Appendix C, Alpha-Numeric Pad representing your desired length. Exit programming mode by again scanning
the “START/END” barcode above/
DEFAULT SETTING FOR THIS FEATURE:
0 (No Delay)
0
Set Intercharacter Delay
USB COM Interface Set-up
This interface uses the Microsoft Windows USB COM driver. Before plugging your reader
into the host PC, please ensure you have already copied the DLS_EUG_CDC_ACM.inf file
provided by Datalogic to your PC and the reader’s interface is set to USB COM.
1. When you first plug the scanner into the PC, W
Hardware Wizard.” Select “Install from a list” and click on “Next.”
2. Click on “Include this location in the
DLS_EUG_CDC_ACM.inf file is stored. Click on “Next.”
3. If a message appears that says the software has not
“Continue” anyway.
4. Click on “Finish.”
5. Once the install is complete, reboot the PC.
indows will bring up the “Found New
search” and enter the path where the file
passed Windows logo testing, press
58
MagellanTM 1100i
Data Editing Overview
It is not recommended to use these features
wi
th IBM interfaces.
CAUTION
When a barcode is scanned, additional information can be sent to the host computer along
with the barcode data. This combination of barcode data and supplementary user-defined
data is called a “message string.” The features in this chapter can be used to build specific
user-defined data into a message string.
Chapter 4
Data Editing
There are several types of selectable data characters that ca
data. You can specify if they should be sent with all symbologies, or only with specific symbologies.
Figure 4-1. Breakdown of a Message String
Please Keep In Mind...
•Modifying a message string is not a mandatory requirement. Data editing is sophisti-
cated feature allowing highly customizable ou
settings for data editing is typically set to NONE.
n be sent before and after scanned
Figure 4-1 shows the available elements you can add to a message string:
Label ID Transmission:
Enable this option to
transmit the Label ID you
configure for the scanned
symbology.
OR...
PrefixSuffixAIM IDLabel IDLabel IDBar Code Data
AIM ID: This function is used to identify and display the
common label identifier for its symbology. When enabled,
this ID code will be transmitted before the scanned bar
code data.
00 - 20 Characters (ASCII)
tput for advanced users. Factory default
•A prefix or suffix may be applied
•You can add any character from the
•Enter prefixes and suffixes in t
Product Reference Guide
(reference the Symbologies chapter for these settings)
across all symbologies (set via the Global features in this chapter).
ASCII Chart (from 00-7F) on the inside back cover
of this manual as a prefix, suffix or Label ID.
he order in which you want them to appear on the out-
put.
59
Data Editing
Global Prefix/Suffix
Up to 20 ASCII characters may be added as a prefix (in a position before the barcode data)
and/or as a suffix (in a position following the barcode data) as indicated in
Figure 4-2. Prefix and Suffix Positions
Example: Setting a Prefix
In this example, we’ll set a prefix for all symbologies.
Figure 4-2.
OR...
PrefixSuffixAIM IDLabel IDLabel IDBar Code Data
00 - 20 Characters (ASCII)
AND
OR
1. Determine which ASCII character(s) are to be ad
ded to scanned barcode data. In this
example, we’ll add a dollar sign (‘$’) as a prefix.
2. Scan the START barcode.
3. Scan the SET PREFIX barcode.
4. Reference the
ASCII Chart on the inside back cover of this manual, to find the hex value
assigned to the desired character. The corresponding hex numbe
is 24. To enter this selection code, scan the ‘2’ and ‘4’ barcodes from
Numeric Pad
5. Scan the END barcode once to finish the s
.
tring, then scan END again to exit Program-
ming Mode.
If all 20 characters will be
suffix, do not scan the END barcode to finish
the string. It is done automatically.
NOTE
used in the prefix or
6. The resulting message string would appear as follows:
Sets up to 20 characters each from the set of ASCII characters or any hex value from 00 to 7F. To configure
this feature, scan the “START/END” barcode above to place the unit in Programming Mode, then the “Set
Prefix” or “Set Suffix,” followed by the digits from the Alphanumeric table in
representing your desired character(s). Reference the section,
tion. Exit programming mode by scanning the “START/END” barcode again (scan “START/END” twice if less
than 20 characters have been selected).
DEFAULT SETTING PREFIX: 00 (None)
DEFAULT SETTING SUFFIX: 0D (CR)
"Example: Setting a Prefix", for more informa-
Appendix C, Alpha-Numeric Pad
Set Prefix
Set Suffix
Product Reference Guide
61
Data Editing
PrefixSuffixLabel IDLabel IDBar Code DataAIM ID
AIM ID
AIM (Automatic Identification Manufacturers) label identifiers are assigned from a globally
standardized list — as opposed to custom label ID characters you select yourself — and can
be included with scanned barcode data. AIM label identifiers consist of three characters as
follows:
•A close brace character (ASCII ‘]’), followed by...
•A code character (see the table below), followed by...
•
A modifier character (the modifier character is symbol dependent)
SYMBOLOGY
UPC/EANECode 128/EAN 128C
Code 39AMSI/PlesseyM
CodabarF
Interleaved 2 of 5IStandard 2 of 5S
Code 93
a. ISBN (X with a 0 modifier character)
Figure 4-3. AIM ID
CHA
R
RSS (GS1 Omnidirectional, GS1 Expanded)
GISBN
SYMBOLOGY
CHA
R
e
a
X
62
START / END
PROGRAMMING BARCODES
Disable AIM ID
DEFAULT
Enable AIM ID
MagellanTM 1100i
Label ID
Label ID
A Label ID is used to identify a barcode (symbology) type. See Appendix D, Default Settings,
for a listing for common symbologies. It can be
mitted barcode data depending upon
how this option is enabled. This feature provides
appended previous to or following the trans-
options for configuring custom Label IDs individually per symbology. If you wish to program the scanner to always include
types, see the previous feature,
an industry standard label identifier for ALL symbology
AIM ID.
The Label ID is a customizable code of up to thre
e ASCII characters (each of which are 007F) followed by a control character (00-01), This control character, when set to zero, does
nothing. When set to one, it appends the symbology’s AIM ID to the Label ID.
When the control character is set to 01 for
-A and UPC-E, it expands the label to
UPC
EAN-13 and thus follows the EAN-13 Label ID
NOTE
settings.
To configure a Label ID:
1. Scan the START barcode.
2. Select Label ID position as either BEFORE or AFTER by scanning
the appropriate
barcode.
3. Scan a barcode to select the symbology for whic
h you wish to configure a custom
Label ID.
4. Determine the desired character(s) (you may
the Label ID for the selected symbology. Next, turn to the
back cover of this manual and find the equivalent hex digits associate
choose up to three) which will represent
ASCII Chart on the inside
d with your
choice of Label ID. For example, if you wish to select an equal sign (=) as a Label ID,
the chart indicates its associated hex characters as 3D.
5. Turn to
acters determined in the previous step. For example
Appendix C, Alpha-Numeric Pad and scan the barcodes representing the hex char-
, to make an equal sign (=), scan
‘3’ and ‘D’ followed by ‘0’ six times. Since this is a three-character buffer, ‘00’ is
scanned for character two, ‘00’ for character three and ‘00’ for the control character.
(‘00’ indicates no character.)
6. Scan the END barcode to exit programming mode.
Figure 4-4. Label ID Position
PrefixSuffixLabel IDLabel IDBar Code DataAim ID
Product Reference Guide
Options
OR
63
Data Editing
Label ID — cont.
START / END
Label ID Position: Before Barcode Data
DEFAULT
PROGRAMMING BARCODES
Label ID Transmission: Disable
Label ID Position: After Barcode Data
Set UPC-A Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: A (41 hex)
Set UPC-A w/P5 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: A (41 hex)
Set UPC-E Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: A (41 hex)
Set UPC-A w/P2 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: A (41 hex)
Set UPC-A w/C128 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: E (45 hex)
64
MagellanTM 1100i
Label ID — cont.
START / END
DEFAULT SETTING FOR THIS FEATURE: E (45 hex)
Set UPC-E w/P5 Addon Label ID Character(s)
Label ID
PROGRAMMING BARCODES
Set UPC-E w/P2 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: E (45 hex)
Set UPC-E w/C128 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: E (45 hex)
Set EAN-8 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: FF (4646 hex)
Set EAN-8 w/P5 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: FF (4646 hex)
Set EAN-13 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: FF (4646 hex)
Set EAN-8 w/P2 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: FF (4646 hex)
Set EAN-8 w/C128 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: F (46 hex)
Product Reference Guide
65
Data Editing
Label ID — cont.
START / END
DEFAULT SETTING FOR THIS FEATURE: F (46 hex)
Set EAN-13 w/P5 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: F (46 hex)
PROGRAMMING BARCODES
Set EAN-13 w/P2 Addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: F (46 hex)
Set EAN-13 w/C128 Addon Label ID Character(s)
Set ISBN Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: IA (4941 hex)
Set GTIN Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: G2 (4732 hex)
Set GTIN w/P5 addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: I (49 hex)
Set IATA Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: G (47 hex)
Set GTIN w/P2 addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: G5 (4735 hex)
66
MagellanTM 1100i
Label ID — cont.
START / END
PROGRAMMING BARCODES
DEFAULT SETTING FOR THIS FEATURE: G8 (4738 hex)
Set GS1 Omnidirectional Label ID Character(s)
Label ID
Set GTIN w/C128 addon Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: R4 (5234 hex)
Set GS1 Expanded Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: RX (5258 hex)
Set Code GS1 DataBar Limited Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: * (2A hex)
Set Pharmacode 39 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: # (23 hex)
DEFAULT SETTING FOR THIS FEATURE: * (524C0000 hex)
Set Code 39 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: A (41 hex)
Set Code 128 Label ID Character(s)
Set I 2 of 5 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: i (69 hex)
Product Reference Guide
67
Data Editing
Label ID — cont.
START / END
DEFAULT SETTING FOR THIS FEATURE: % (25 hex)
Set Code 93 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: @ (40 hex)
PROGRAMMING BARCODES
Set Codabar Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: & (26 hex)
Set Code 11 Label ID Character(s)
Set MSI/Plessey Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: s (73 hex)
Set EAN UCC Composite Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: P (5000
a
hex)
Set Datamatrix Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: @ (40 hex)
Set Std 2 of 5 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: 0
Set PDF 417 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: Dm (446D hex)
68
a.
Default setting exceptions for PDF 417 Label ID are as follows: Default for RS-232 WN is ‘Q’ (0x5100). Default for USB-HIDPOS is ‘P ‘ (0x5020), or ‘P-Space’.
MagellanTM 1100i
Label ID — cont.
NOTE
START / END
Label ID
For the 2D symbologies on this page, the
Label ID is 4 bytes. The first 3 bytes are characters for the label ID. A 00 (hex) value in the
first 3 bytes indicates the end of the label ID
characters. The 4th byte is a control byte.
The use of the control byte is as follows:
bit 0-if set to 1, the AIM Id is appended for that
label type
PROGRAMMING BARCODES
Set Micro PDF 417 Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: mP (6D500000 hex)
Set QR Code Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: MC (4D430000 hex)
Set Aztec Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: R4 (52340000 hex)
Set GS1 DataBar Limited 2D Composite
Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: QR (51520000 hex)
Set Maxicode Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: Az (417A0000 hex)
Set GS1 DataBar Omnidirectional 2D Composite
Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: RL (524C0000 hex)
Set GS1 DataBar Expanded 2D Composite
Label ID Character(s)
DEFAULT SETTING FOR THIS FEATURE: RX (52340000 hex)
Product Reference Guide
69
Data Editing
Case Conversion
This feature can convert scanned barcode data to either all lower case (a through z) or all
upper case (A through Z) characters.
NOTE
START / END
Case conversion affects ONLY scanned barcode data, and does not affect Label ID, Prefix, Suffix, or other appended data.
PROGRAMMING BARCODES
Disable
DEFAULT
Convert to Upper Case
Convert to Lower Case
70
MagellanTM 1100i
Character Conversion
Character conversion is an eight byte configuration item. The eight bytes are 4 character
pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to. If
e character to convert in a pair is FF, then no conversion is done.
th
Character Conversion
For example, if you have the chara
cter conversion configuration item set to the following:
41423132FFFFFFFF
The first pair is 4
142 or AB (41 hex is an ASCII capital A, 42 hex is an ASCII capital B)
and the second pair is 3132 or 12 (31 hex is an ASCII 1, 32 is an ASCII 2). The other two
pairs are FFFF and FFFF.
With the label, AG15TA81, it would look as follows afte
r the character conversion:
BG25TB82.
The A characters were converted to the B character and the 1 characters were converted to
the
numeral 2 character. Nothing is done with the last two character pairs, since they are all
FF.
To set Character Conversion:
1. Scan the START/END barcode.
2. Scan the Character Conversion barcode.
3. Determine the desired string. Up to sixteen positions
example. Next, turn to the
ASCII Chart on the inside back cover of this manual and find
can be determined as in the above
the equivalent hex digits needed to fulfill the string.
The positions not used must be filled with the
aracter ‘F’.
ch
NOTE
4. Turn to Appendix C, Alpha-Numeric Pad and scan the barcodes representing the hex characters determined in the previous step. When the
last character is scanned, the scanner
will sound a triple beep.
5. Scan the START/END barcode to exit Programming Mode.
START / END
PROGRAMMING BARCODES
Character Conversion
DEFAULT SETTING FOR THIS FEATURE:
FFFFFFFFFFFFFFFF hex (no conversion)
Product Reference Guide
71
Data Editing
NOTES
72
MagellanTM 1100i
Chapter 5
Symbologies
The scanner supports the following symbologies (barcode types). Options for each symbology
are included in this chapter.
• UPC-A
• UPC-E• Code 128
• EAN-13• Interleaved 2 of 5
• EAN-8• Codabar
• GS1 DataBar Omnidirectional /
Stacked Omnidirectional
• GS1 DataBar Expanded /
Expanded Stacked
• GS1 DataBar Limited• Standard 2 of 5
• Code 39
Factory Defaults—
this section. Reference
UPC-A
Disable/Enable UPC-A
When disabled, the scanner will not read UPC-A barcodes.
START / END
• Code 32 Italian
Pharmacode
• Code 93
• MSI/Plessey
for the standard RS-232 interface are indicated in bold text throughout
Appendix D, Default Settings for default exceptions for your interface.
Enable UPC-A
Product Reference Guide
PROGRAMMING BARCODES
Disable UPC-A
DEFAULT
73
Symbologies
UPC-A — continued
Check Digit Transmission
Enable this option to transmit the check digit along with UPC-A barcode data.
START / END
Send Check Digit
DEFAULT
PROGRAMMING BARCODES
Don’t Send Check Digit
Expand UPC-A to EAN-13
Expands UPC-A data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13.
START / END
Expand to EAN-13
PROGRAMMING BARCODES
Don’t Expand to EAN-13
DEFAULT
74
MagellanTM 1100i
UPC-A — continued
Number System Transmission
This feature enables/disables transmission of UPC-A System Number.
START / END
Enable Number System Transmission
DEFAULT
UPC-A
PROGRAMMING BARCODES
Disable Number System Transmission
UPC-A Minimum Reads
This feature specifies the minimum number of consecutive times a UPC-A label must be
decoded before it is accepted as good read.
START / END
Minimum = 2 Reads
PROGRAMMING BARCODES
Minimum = 1 Read
DEFAULT
Minimum = 3 Reads
Minimum = 4 Reads
Product Reference Guide
75
Symbologies
UPC-A — continued
UPC-A In-store Minimum Reads
This feature specifies the minimum number of consecutive times an in-store printed label must
be decoded before it is accepted as good read.
START / END
PROGRAMMING BARCODES
Minimum = 2 Reads
Minimum = 1 Read
DEFAULT
Minimum = 4 Reads
Minimum = 3 Reads
76
MagellanTM 1100i
UPC-E
The following options apply to the UPC-E symbology.
Disable/Enable UPC-E
When disabled, the scanner will not read UPC-E barcodes.
START / END
Enable UPC-E
DEFAULT
UPC-E
PROGRAMMING BARCODES
Disable UPC-E
Check Digit Transmission
Enable this option to transmit the check digit along with UPC-E barcode data.
START / END
Send Check Digit
DEFAULT
PROGRAMMING BARCODES
Don’t Send Check Digit
Product Reference Guide
77
Symbologies
UPC-E — continued
Number System Digit
The Number System Digit (NSD) which is always a zero (0) in the leading position can be
optionally included (or not) with scanned barcode data.
START / END
Include Number System Digit
PROGRAMMING BARCODES
Exclude Number System Digit
DEFAULT
Expand to UPC-E to UPC-A
Enables/disables expansion of UPC-E labels to UPC-A. Selecting this feature also changes the
symbology ID to match those required for UPC-A.
START / END
Expand UPC-E to UPC-A
PROGRAMMING BARCODES
Don’t Expand UPC-E to UPC-A
DEFAULT
78
MagellanTM 1100i
UPC-E — continued
Expand UPC-E to EAN13
Enables/disables expansion of UPC-E labels to EAN-13. Selecting this feature also changes the
symbology ID to match those required for EAN-13.
START / END
Expand UPC-E to EAN-13
UPC-E
PROGRAMMING BARCODES
Don’t Expand UPC-E to EAN-13
DEFAULT
Minimum Reads
This feature specifies the minimum number of consecutive times a UPC-E label must be
decoded before it is accepted as good read.
Minimum = 2 Reads
START / END
PROGRAMMING BARCODES
Minimum = 1 Read
DEFAULT
Minimum = 3 Reads
Minimum = 4 Reads
Product Reference Guide
79
Symbologies
GTIN
The following options apply to the GTIN label data format.
Expand UPC/EAN to GTIN
When this feature is enabled, the scanner will translate UPC/EAN labels to the 14 digit GTIN
format.
START / END
Expand to GTIN
PROGRAMMING BARCODES
Don’t Expand to GTIN
DEFAULT
80
MagellanTM 1100i
EAN-13
The following options apply to the EAN-13 symbology.
Disable/Enable EAN-13
When disabled, the scanner will not read EAN-13 barcodes.
START / END
Enable EAN-13
DEFAULT
EAN-13
PROGRAMMING BARCODES
Disable EAN-13
Check Digit Transmission
Enable this option to transmit the check digit along with EAN-13 barcode data.
START / END
Send Check Digit
DEFAULT
PROGRAMMING BARCODES
Don’t Send Check Digit
Product Reference Guide
81
Symbologies
EAN-13 — continued
EAN-13 Flag 1 Character
Enables/disables transmission of an EAN/JAN13 Flag1 character.
START / END
Transmit EAN-13 Flag 1 Char
DEFAULT
PROGRAMMING BARCODES
Don’t Transmit EAN-13 Flag 1 Char
ISBN
When enabled, this feature truncates the leading three digits from labels that contain ISBN
(International Standard Book Number) and appends an ISBN check character to the end of the
label. These codes are used for books and magazines. Labels with ISBN codes start with "978".
Example:
Barcode data:“9789572222720”
Output:“9572222724”
START / END
PROGRAMMING BARCODES
Disable ISBN
DEFAULT
Enable ISBN
82
MagellanTM 1100i
EAN-13 — continued
Minimum Reads
This feature specifies the minimum number of consecutive times an EAN-13 label must be
decoded before it is accepted as good read.
START / END
Minimum = 2 Reads
EAN-13
PROGRAMMING BARCODES
Minimum = 1 Read
DEFAULT
Minimum = 4 Reads
Minimum = 3 Reads
Product Reference Guide
83
Symbologies
EAN-8
The following options apply to the EAN-8 symbology.
Disable/Enable EAN-8
When disabled, the scanner will not read EAN-8 barcodes.
START / END
Enable EAN-8
DEFAULT
PROGRAMMING BARCODES
Disable EAN-8
Check Digit Transmission
Enable this option to transmit the check Digit along with EAN-8 barcode data.
START / END
Send Check Digit
DEFAULT
PROGRAMMING BARCODES
Don’t Send Check Digit
84
MagellanTM 1100i
EAN-8 — continued
EAN-8
Expand EAN-8 to EAN-13—
this feature also changes the symbology ID to match those required for EAN-13.
Expand to EAN-13
Minimum Reads
This feature specifies the minimum number of consecutive times an EAN-8 label must be
decoded before it is accepted as good read.
Expands EAN-8 data to the EAN-13 data format. Selecting
START / END
PROGRAMMING BARCODES
Don’t Expand to EAN-13
DEFAULT
START / END
Minimum = 2 Reads
Minimum = 4 Reads
PROGRAMMING BARCODES
Minimum = 1 Read
DEFAULT
Minimum = 3 Reads
Product Reference Guide
85
Symbologies
EAN Two-Label
Enables/disables the ability of the scanner to decode EAN two-label pairs.
START / END
Enable EAN Two-Label
EAN Two-Label Type 1
Specifies label types and number of flag digits for EAN/JAN two-label pair 1. Options are:
PROGRAMMING BARCODES
Disable EAN Two-Label
•EAN/JAN13, EAN/JAN13 - 2 flag digits each
•EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
•EAN/JAN13, EAN/JAN8 - 1 flag digit each
•Disable pairs
START / END
PROGRAMMING BARCODES
EAN Two-Label Type 1 =
EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
EAN Two-Label Type 1 =
EAN/JAN13, EAN/JAN13 - 2 flag digits each
DEFAULT
EAN Two-Label Type 1 =
EAN/JAN13, EAN/JAN8 - 1 flag digit each
EAN Two-Label Type 1 = Disable pairs
86
MagellanTM 1100i
EAN Two-Label — continued
EAN Two-Label Type 2
Specifies label types and number of flag digits for EAN/JAN two-label pair 2. Options are:
•EAN/JAN13, EAN/JAN13 - 2 flag digits each
•EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
•EAN/JAN13, EAN/JAN8 - 1 flag digit each
•Disable pairs
START / END
PROGRAMMING BARCODES
EAN Two-Label
EAN Two-Label Type 2 =
EAN/JAN13, EAN/JAN13 - 2 flag digits each
DEFAULT
EAN Two-Label Type 2 =
EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
EAN Two-Label Type 2 = Disable pairs
EAN Two-Label Type 2 =
EAN/JAN13, EAN/JAN8 - 1 flag digit each
Product Reference Guide
87
Symbologies
EAN Two-Label — continued
EAN Two-Label Type 3
Specifies label types and number of flag digits for EAN/JAN two-label pair 3. Options are:
•EAN/JAN13, EAN/JAN13 - 2 flag digits each
•EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
•EAN/JAN13, EAN/JAN8 - 1 flag digit each
•Disable pairs
START / END
PROGRAMMING BARCODES
EAN Two-Label Type 3 =
EAN/JAN13, EAN/JAN13 - 2 flag digits each
DEFAULT
EAN Two-Label Type 3 =
EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
EAN Two-Label Type 3 = Disable pairs
EAN Two-Label Type 3 =
EAN/JAN13, EAN/JAN8 - 1 flag digit each
88
MagellanTM 1100i
EAN Two-Label — continued
EAN Two-Label Type 4
Specifies label types and number of flag digits for EAN/JAN two-label pair 4. Options are:
•EAN/JAN13, EAN/JAN13 - 2 flag digits each
•EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
•EAN/JAN13, EAN/JAN8 - 1 flag digit each
•Disable pairs
START / END
PROGRAMMING BARCODES
EAN Two-Label
EAN Two-Label Type 4 =
EAN/JAN13, EAN/JAN13 - 2 flag digits each
EAN Two-Label Type 4 =
EAN/JAN13 - 2 flag digits, EAN/JAN8 - 1 flag digit
EAN Two-Label Type 4 = Disable pairs
EAN Two-Label Type 4 =
EAN/JAN13, EAN/JAN8 - 1 flag digit each
DEFAULT
Product Reference Guide
89
Symbologies
EAN Two-Label — continued
EAN Two-Label Combined Transmission
Enables/disables the transmitting of an EAN two label pair as one label.
START / END
PROGRAMMING BARCODES
EAN Two-Label Combined Transmission = Disable
EAN Two-Label Combined Transmission = Enable
DEFAULT
90
MagellanTM 1100i
EAN Two-Label — continued
EAN Two-Label Minimum Reads
This feature specifies the minimum consecutive decodes of an EAN two-label pair before it is
accepted as good read..
START / END
PROGRAMMING BARCODES
Minimum = 2 Reads
EAN Two-Label Combined Transmission
Minimum = 1 Read
DEFAULT
Minimum = 4 Reads
Minimum = 3 Reads
Product Reference Guide
91
Symbologies
Price Weight Check Digit
Enables/disables calculation and verification of price/weight check digits.
NOTE
Here are the available options for this feature:
•Disable
•Enable 4-digit price/wt check-digit calculation
•Enable 5-digit price/wt check-digit calculation
Applies to all UPC-A labels with a number-system character of 2 and EAN/JAN 13 labels with a Flag1 digit of 2
