DataCard Tru Specifications

COST-EFFECTIVE FINGERPRINT CAPTURE
AND VERIFICATION

Advanced security technology

Choose the powerful yet

easy-to-operate Tru Fingerprint

solution for fully integrated

fingerprint capture and verification.

• Works seamlessly with Datacard

ID Works and ViaNet software

• Captures fingerprint templates

and Automated Fingerprint

Identification System (AFIS)

quality images with equal ease

• Adds advanced identity

verification to any operation

• Printed fingerprints help deter

identity theft

• Available exclusively from

Datacard Group

The Datacard®Tru™Fingerprint solution combines the intuitive Tru™Fingerprint

software and an advanced fingerprint reader. The solution can enable biometric

enrollment and verification and/or capture and storage of fingerprint images.

• Powerful enrollment and verification. When used with Datacard®ID Works

®

Enterprise identification software, the Tru Fingerprint solution allows you to scan

a fingerprint, create a mathematical representation of it and store this digital

template in a biometric database. This makes it easy to perform one-to-one

fingerprint matching required for sophisticated biometric identity verification.

• AFIS quality images. Capture an AFIS quality image and save it to a database,

2D bar code or smart chip. Images are captured at 500 ppi for higher accuracy in

reading, verifying and matching a fingerprint image.

• Convenient capture and storage. When used with any edition of Datacard

®

ID Works®software, or with Datacard®ViaNet®identity information software,

the Tru Fingerprint solution can capture a photographic image of a cardholder’s

fingerprint, then print it on a secure photo ID card to help deter identity theft.

• Easy setup and operation. The Tru Fingerprint solution is easy to install and

simple to use. After installing ID Works or ViaNet software, just install the Tru

Fingerprint software, connect the reader and you are ready to scan fingerprints.

DATACARD

®

TRU™FINGERPRINT SOLUTION

Standard features

Key capabilities

Capture, print and store fingerprint
images

AFIS quality images
Enroll and verify biometric fingerprint

templates (with ID Works Enterprise
software)

One-to-one verification (with
ID Works Enterprise software)

Solution components

Datacard Tru Finger print Software
Identix®BioTouch®500 USB

Fingerprint Reader
USB license key
Installation instructions
User documentation

Specifications (reader)

Size

2.4 in.W x 3.8 in. L x 1.2 in. H
(60 mm x 96 mm x 31 mm)

Weight

5.3 oz. (150.0 g)

Image capture surface

0.79 x 0.98 in. (20 x 25 mm)

Interface

USB2

Power

Available through USB port

Operating temperature

50° to 104° F (10° to 40° C)

Agency approvals

FCC
CE
RoHS Compliant

Image format

500 ppi

System requirements

For fingerprint image capture

ID Works Enterprise identification
software
ID Works Standard identification
software

ID Works Basic identification software
ID Works Lite identification software
ViaNet identity information software

For enrollment and verification

ID Works Enterprise
identification software

For fingerprint solution

Two free USB ports

Datacard, ID Works, Tru and ViaNet are
registered trademarks, trademarks and/or
service marks of DataCard Corporation in
the United States and/or other countries.
Identix and BioTouch are registered
trademarks of Identix Incorporated.

©2006-2007 DataCard Corporation.
All rights reserved.

DC7-7003

11111 Bren Road West

Minnetonka, MN 55343-9015

[phone]

[phone] FAX

www.datacard.com

DATACARD

®

TRU™FINGERPRINT
SOLUTION

The powerful, intuitive Datacard®Tr u™Fingerprint solution allows organizations to take advantage of advanced biometric
verification and/or print fingerprint images on photo IDs.
