Sequence Valves Technical Information
40
10
15
20
25
[2.46]
[2.54]
3-Way
VDP 06/4201
OPERATION
SPECIFICATIONS
DIMENSIONS
mm [in]
This is a direct-acting, spool-type sequence valve with external pilot and atmospheric
vent.
Schematic
Theoretical performance
psi
bar
0
0
0
0
50
0
26 cSt [125 SUS] hyd.oil @ 20° C [68° F]
20
15
10
5
0
0
0 2468
Pressure drop
3
10 20 30
l/min
US gal/min
4
Specications
Rated pressure 315 bar [4500 psi]
Rated ow at 7 bar
[100 psi]
10
Weight 0.28 kg [0.62 lb]
Cavity NCS06/4
22 l/min
[6 US gal/min]
Cross-sectional view
27 mm
44-50 Nm
[32-37 lbf ft]
62.5
M22x1.5
4
A
3
P
64.5
2
B
Pil.
1
ORDERING
INFORMATION
VDP 06 / 42 01 - M - 1 - 00 -V
Seals
Adjustment
E = Internal screw
EN = External screw
M = Handwheel
Setting range
1 = 15- 40 bar [220-580 psi]
2 = 30 - 120 bar
3 = 105 - 190 bar
[430-1740 psi]
[1520-2750 psi]
Housing and po rtsHousing P/N
00 =No Housing No Housing
L3/8 =AL, 3/8 BSP NCS06/4-L-3/8
L1/2 =AL,½ BSP NCS06/4-L-1/2
L6S=AL,#6 SAE NCS06/4-L-6S
L8S=AL,#8 SAE NCS06/4-L-8S
Other housings available
V =Viton
Omit = Buna-N
To order this valve with a specic factory setting,contact your Danfoss ICS representative
Seal ki t
230000350
230000080
BC332375508106en-000101 • February 2020
SQ - 19
