Danfoss RX-C Roof Clips Data sheet

Data Sheet RX-C Roof Clips

General
Information

Ordering Information

The Danfoss RX-C Roof Clips are suitable for use with
the RX-C Self Regulating Cables. The clips are de­signed to secure the cables to asphalt shingles, metal
seam roofs, and gutters.

Materials Required:

• RX-C Roof Clip Glue (or other recommended
adhesive)

• pliers

• caulking gun

Recommended Adhesives:

See roong supply distributors for recommendations.

Part No. Description Qty

088L3001 RX-C Roof Clips

Accessories:

Part No. Description Qty

Roof Clip Glue RX-C Roof Clip Adhesive

50 per bag

10.3 . oz.
cartridge

Instructions

1. Apply Adhesive:

• Apply 0.2 oz. of adhesive to back of clip.

• (Please note required application
temperatures when applying glue.)

3. Install Cables/Close Clamps

• Allow proper cure time (typically 24
hours- refer to adhesive.)

• Install RX-C de-icing cable.

• Use pliers to close clamps (ensuring not
to damage cable).

2. Press Clip to Roof Surface:

• Lift shingle & orient clip.

• Press down (ensure adhesive ows
through holes).

• Do not trim back adhesive beads.

• Press shingle down.

© Copyright 2016 Danfoss VDLWA222 . 04/16 TEL: [phone], FAX: [phone] 1

Datasheet RX-C Roof Clips

Dimensions

.74”

1.97”

1.97”

1.97”

.39”

1.18”

Thickness

.049”

1.48”

1.18”

Notes

• Shingles must be clean and dry

• Note adhesive application temperature limits

• Allow proper cure time for adhesive (typically 24 hours)

• Not recommended for rubber/membrane roof

• Do not use screw/nail with clip

• Consult roong supplier for recommended adhesives

© Copyright 2016 Danfoss VDLWA222 . 04/16 TEL: [phone], FAX: [phone] 2

Datasheet RX-C Roof Clips

Warning

Technical
Services

• Roof clips must be installed properly to ensure proper operation and to prevent the
risk of electrical hazard or re. Follow all design, installation, assembly, and test instructions
carefully.

• Arcing may not be stopped by conventional circuit protection.

• Do not use clip for installation on slate or tile roofs as damage may occur to roof material.
Consult roong manufacturer for components approved for use on specic roof material.

• De-energize all power circuits before installation or servicing.

• Keep ends of heating devices and kit components dry before and during installation.

• While using pliers to close clamps on heating cable, heating cable should not be crushed or
altered structurally in any way.

• The cable should not be twisted during installation.

• Heating cable should not be embedded in the thermal insulation.

For technical questions, please contact Danfoss Heating Division North America at 1-866-676-8062.
More information on Danfoss Electric Heating products is available at www.LX.Danfoss.com.

Danfoss can accept no responsibility for possible errors in catalogs, brochures, other printed materials, and website information. Danfoss reserves the right to alter its
products without notice. This also applies to products already on order provided that such alteration can be made without subsequent changes being necessary in

specications already agreed upon. All trademarks in this material are property of the respective companies. Danfoss and Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.

Danfoss
Toronto

Toll Free: 1-866-676-8062
Tel.: [phone]
Fax: [phone]
www.LX.Danfoss.com

© Copyright 2016 Danfoss VDLWA222 . 04/16 TEL: [phone], FAX: [phone] 3
