Danfoss RET230P User guide

MAKING MODERN LIVING POSSIBLE

Danfoss Heating

RET230P

Electronic Thermostat

For a large print version of these instructions

please call Marketing on 0845 121 7400.

®

Certification Mark

Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other
printed material. All trademarks in this material are property of the respective companies.
Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.

2

RET230P

4-6 GB - Specifi cation 12 GR - Προδιαγραφή
7 F - Spécifi cations 13 PL - Specyfi kacja
8 D - Tecnishe Daten 14 LT - Specifi kacija
9 ES - Especifi caciones 15 I - Specifi cazioni
10 DK - Specifi kation 16-17 TR - Teknik Özellikleri
11 NL - Technische Specifi caties 18 RUS - Технические характеристики

19-20 GB - Mounting, F- Montage, D - Befestigung, ES - Montaje,

GB

F

D

ES

DK - Montering, NL - Montage, GR - Εγκατάσταση, PL - Montaż,
LT - Montavimas, I - Montaggio, TR - Teknik Özellikleri,
RUS - Монтаж
21-22 GB - Wiring, F- Câblage, D - Verkabelung, ES - Cableado,
DK - Ledningsføring, NL - Aansluitingen, GR - Συρμάτωση,
PL - Podłączanie przewodów, LT - Laidai, I - Cablaggio, TR - Baglantılar,
RUS - Электропроводка
23 GB - Mounting, F - Montage, D - Befestigung,
DK - Montering, NL - Montage, GR - Εγκατάσταση, PL - Montaż,
LT - Montavimas, I - Montaggio, TR - Teknik Özellikleri, RUS - Монтаж
24 GB - Locking & limiting, F - Verrouillage & Limitation,
D - Sperren & Begrenzen, ES - Bloquear y Limitar,
DK - Låsning og begrænsning, NL - Blokkeren & Begrenzen,
GR - Ασφάλιση και περιορισμός, PL - Zamknięcie i ograniczenie,
LT - Blokavimas ir ribojimas, I - Bloccaggio e esclusioni,
TR - Ayar butonu, RUS - Блокировка и ограничения

Danfoss Heating

ES - Montaje

DK

NL

GR

PL

LT

I

TR

RUS

3

GB

F

D

ES

DK

NL

GR

PL

LT

TR

RUS

What is a room thermostat?

... an explanation for householders
A room thermostat simply switches the heating system on and off as
necessary. It works by sensing the air temperature, switching on the
heating when the air temperature falls below the thermostat setting,
and switching it off once this set temperature has been reached.
Turning a room thermostat to a higher setting will not make the
room heat up any faster. How quickly the room heats up depends

I

4

on the design of the heating system, for example, the size of boiler
and radiators.
Neither does the setting aff ect how quickly the room cools down.
Turning a room thermostat to a lower setting will result in the room
being controlled at a lower temperature, and saves energy.

RET230P

The heating system will not work if a timeswitch or programmer has

GB

switched it off .
The way to set and use your room thermostat is to fi nd the lowest
temperature setting that you are comfortable with, and then leave
it alone to do its job. The best way to do this is to set the room
thermostat to a low temperature – say 18°C – and then turn it up by
one degree each day until you are comfortable with the temperature.
You won’t have to adjust the thermostat further. Any adjustment
above this setting will waste energy and cost you more money.
If your heating system is a boiler with radiators, there will usually
be only one room thermostat to control the whole house. But you
can have diff erent temperatures in individual rooms by installing
thermostatic radiator valves (TRVs) on individual radiators. If
you don’t have TRVs, you should choose a temperature that is
reasonable for the whole house. If you do have TRVs, you can choose
a slightly higher setting to make sure that even the coldest room

F

D

ES

DK

NL

GR

PL

LT

is comfortable, then prevent any overheating in other rooms by
adjusting the TRVs.
Room thermostats need a free fl ow of air to sense the temperature,
so they must not be covered by curtains or blocked by furniture.
Nearby electric fi res, televisions, wall or table lamps may prevent the
thermostat from working properly.

Danfoss Heating

I

TR

RUS

5

GB

F

Specifi cation

Specifi cations

D

ES

DK

NL

GR

PL

LT

Temperature range 5-30°C

Construction BS EN60730-2-9

Maximum Ambient Temperature 45°C

IP Rating IP20

Supply Voltage 230Vac ±15%, 50/60Hz

Switch Rating 3(1)A

Switch Type 1B

Control Pollution Situation Degree 2

I

Rated Impulse Voltage

2.5kV

TR

RUS

Ball Pressure Test 75°C

6

RET230P

Spécifi cations

Spécifi cations

GB

F

Plage de températures 5-30°C

Normes de fabrication BS EN60730-2-9

Température ambiante maximale 45°C

Indice de protection IP20

Tension d’alimentation 230Vac ±15%, 50/60Hz

Caractéristique de commutateur 3(1)A

Type de commutateur 1B

Etat du contrôle de pollution Degré 2

Essai à la bille

2.5kV

D

ES

DK

NL

GR

PL

LT

I

Tension assignée de tenue au choc 75°C

Danfoss Heating

TR

RUS

7

GB

F

Tecnishe Daten

Technische Daten

D

ES

DK

NL

GR

PL

LT

Temperaturbereich 5-30°C

Bauart BS EN60730-2-9

Maximale Umgebungstemeratur 45°C

Schutzart IP20

Betriebsspannung 230Vac ±15%, 50/60Hz

Nominaler Kontaktstrom 3(1)A

Schalterart 1B

Emissionswerte Grad 2

I

Nennimpulsspannung

2.5kV

TR

RUS

Kugeldruckprüfung 75°C

8

RET230P

Especifi caciones

Especifi caciones

GB

F

Rango de temperatura 5-30°C

Fabricación BS EN60730-2-9

Temperatura ambiente máxima 45°C

Protección IP IP20

Alimentación 230Vac ±15%, 50/60Hz

Carga del interruptor 3(1)A

Tipo de interruptor 1B

Estado de control de polución Grado 2

Tensión del impulso

2.5kV

D

ES

DK

NL

GR

PL

LT

I

Ensayo de presión con bola 75°C

Danfoss Heating

TR

RUS

9

GB

F

Specifi kation

Specifi kation

D

ES

DK

NL

GR

PL

LT

Temperaturområde 5-30°C

Konstruktionsnorm BS EN60730-2-9

Maks. omgivende temperatur 45°C

Tæthedsgrad IP20

Forsyningsspænding 230Vac ±15%, 50/60Hz

Kontaktbelastning 3(1)A

Kontakttype 1B

Forureningssituation Grad 2

I

Nominel Impuls Spænding

2.5kV

TR

RUS

10

Kugle tryk test 75°C

RET230P

Technische Specifi caties

Technische Specifi caties

GB

F

Temperatuurbereik 5-30°C

Fabrikage norm BS EN60730-2-9

Maximale omgevingstemperatuur 45°C

Beschermingsfaktor IP20

Voedingsspanning 230Vac ±15%, 50/60Hz

Kontakt belasting 3(1)A

Kontakt type 1B

Emissie waarde Niveau 2

Nominale piekspanning

2.5kV

D

ES

DK

NL

GR

PL

LT

I

Kogeltest 75°C

Danfoss Heating

TR

RUS

11

GB

F

Προδιαγραφή

Προδιαγραφή

D

ES

DK

NL

GR

PL

LT

Περιοχή θερμοκρασιών 5-30°C

Προδιαγραφές σχεδιασμού BS EN60730-2-9

Μέγιστη θερμοκρασία

45°C

περιβάλλοντος

Ονομαστική τιμή IP

Τάση τροφοδότησης

Ονομαστική τιμή διακόπτη

Τύπος διακόπτη

Κατάσταση ελέγχου ρύπανσης Βαθμού 2

I

IP20

230Vac ±15%, 50/60Hz

3(1)A

1B

TR

RUS

12

Ονομαστική τάσης ώθησης 2.5kV

Δοκιμή σφαιρικής πίεσης 75°C

RET230P

Specyfi kacja

Specyfi kacja

GB

F

Zakres temperatury

Zgodność z normą

Maksymalna temperatura
otoczenia

Stopień ochrony

Napięcie zasilania

Obciążalność styków

Typy wbudowanych przekaźników

Znamionowe napiecie impulsu

IP20

5-30°C

BS EN60730-2-9

D

ES

DK

45°C

NL

GR

230Vac ±15%, 50/60Hz

3(1)A

1B

2.5kV

PL

LT

I

Danfoss Heating

TR

RUS

13

GB

F

Specifi kacija

Specifi kacija

D

ES

DK

NL

GR

PL

LT

Temperatūros diapazonas 5-30°C

Atitinka standartus BS EN60730-2-9

Didžiausia aplinkos temperatūra

IP parametras

Maitinimo įtampa

Jungiklio parametras

Jungiklio tipas

Kontroliuojama tarša

I

Nominali impulso átampa

IP20

1B

45°C

230Vac ±15%, 50/60Hz

3(1)A

2 lygis

2.5kV

TR

RUS

14

Rutulinio slëgio bandymas 75°C

RET230P

Specifi cazioni

Specifi cazioni

GB

F

Intervallo temperatura 5-30°C

Standard di progetto BS EN60730-2-9

Temperatura ambiente massima

Grado di protezione

Tensione di alimentazione

Corrente nominale interruttore

Tipo di interruttore

Livello antinquinamento Livello 2

Tensione nominale impulsi

230Vac ±15%, 50/60Hz

45°C

IP20

3(1)A

1B

2.5kV

D

ES

DK

NL

GR

PL

LT

I

Prova di pressione con sfere 75°C

Danfoss Heating

TR

RUS

15

GB

F

Teknik Özellikleri

Teknik Özellikleri

D

ES

DK

NL

GR

PL

LT

Sıcaklık aralıgı 5-30°C

Dizayn standardı BS EN60730-2-9

Maksimum ortam sıcaklıgı 45°C

Besleme 230Vac ±15%, 50/60Hz

Röle çıkıı 3(1)A

Röle tipi SPDT 1B

Kirlilik standartı

Test gerilimi

I

Sertlik testi

2. derece

2.5kV

75°C

TR

RUS

16

RET230P

GB

F

D

ES

DK

NL

GR

PL

Kullanıcı hatalarından kaynaklanan arızalar garanti kapsamı dışında kalmaktadır. Ürünün kullanım ömrü 10 yıldır.

Danfoss Heating

LT

I

TR

RUS

17

GB

F

Технические характеристики

Технические характеристики

D

ES

DK

NL

GR

PL

LT

Диапазон температур 5-30 °C

Конструкция BS EN60730-2-9

Максимальная температура

45 °C

внешней среды

Тип IP IP20

Питающее напряжение 230 В ± 15%, 50/60 Гц

Режим переключения 3(1) A

Тип переключателя 1 B

Контроль загрязнения

I

окружающей среды

Степень 2

TR

RUS

18

Макс. мгновенное напряжение

Тест на жёсткость по Бринелю 75 °C

2,5 кВ

RET230P

GB - Mounting / F- Montage / D - Befestigung / ES - Montaje
DK - Montering / NL - Montage / GR - Εγκατάσταση
PL - Montaż / LT - Montavimas / I - Montaggio / TR - Montajı

GB

F

RUS - Монтаж

(5FT)

D

ES

DK

NL

GR

PL

LT

I

Danfoss Heating

TR

RUS

19

GB

F

GB - Mounting / F- Montage / D - Befestigung / ES - Montaje
DK - Montering / NL - Montage / GR - Εγκατάσταση
PL - Montaż / LT - Montavimas / I - Montaggio / TR - Montajı

D

ES

DK

NL

GR

PL

LT

RUS - Монтаж

I

8

TR

RUS

20

9

RET230P

GB - Wiring / F- Câblage / D - Verkabelung / ES - Cableado
DK - Ledningsføring / NL - Aansluitingen / GR - Συρμάτωση
PL - Podłączanie przewodów / LT - Laidai / I - Cablaggio

GB

F

TR - Baglantılar / RUS - Электрическая монтажная схема

D

ES

DK

NL

GR

PL

LT

I

Danfoss Heating

TR

RUS

21

GB

F

D

ES

DK

GB - Wiring / F- Câblage / D - Verkabelung / ES - Cableado
DK - Ledningsføring / NL - Aansluitingen / GR - Συρμάτωση
PL - Podłączanie przewodów / LT - Laidai / I - Cablaggio
TR - Baglantılar / RUS - Электропроводка

NL

GR

PL

LT

TR

RUS

22

2

OFF

NC

3

COM

RET230P

NO

ELECTRONICS

Link terminals L
and COM/3 for
230V output

I

Note: The RET230P is an electronic room thermostat and requires

N

230 Volt AC

50/60Hz

a 3 wire connection.

L1

ON

OUTPUT

GB - Mounting / F- Montage / D - Befestigung / ES - Montaje
DK - Montering / NL - Montage / GR - Εγκατάσταση
PL - Montaż / LT - Montavimas / I - Montaggio / TR - Montajı

GB

F

RUS - Монтаж

D

ES

DK

NL

GR

PL

LT

I

Danfoss Heating

TR

RUS

23

GB

F

D

GB - Locking & limiting / F - Verrouillage & Limitation
D - Sperren & Begrenzen / ES - Bloquear y Limitar
DK - Låsning og begrænsning / NL - Blokkeren & Begrenzen
GR - Ασφάλιση και περιορισμός
PL - Zamknięcie i ograniczenie / LT - Blokavimas ir ribojimas

ES

DK

NL

GR

PL

LT

TR

I - Bloccaggio e esclusioni / TR - Ayar butonu /
RUS - Блокировка и ограничения

I

RUS

24

RET230P

Danfoss Heating

25

26

RET230P

Danfoss Heating

27

Danfoss Randall Ltd.

Ampthill Road
Bedford MK42 9ER

Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.danfoss-randall.co.uk

Part No 18078v05 07/09
