RET2000 MD
Electronic digital thermostat with LCD, delayed start
Danfoss Heating
User Guide
For a large print version of these instructions
please call Marketing on 0845 121 7400.
Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other
printed material. All trademarks in this material are property of the respective companies.
Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
2
RET1000 MD
Thank you for buying a Danfoss product
GB
GB
Danfoss Heating
3
GBGB
What is a room thermostat?
... an explanation for householders. A room thermostat simply switches
the heating system on and o as necessary. It works by sensing the
air temperature, switching on the heating when the air temperature
falls below the thermostat setting, and switching it o once this set
temperature has been reached.
Turning a room thermostat to a higher setting will not make the
room heat up any faster. How quickly the room heats up depends on
the design of the heating system, for example, the size of boiler and
radiators.
Neither does the setting a ect how quickly the room cools down.
Turning a room thermostat to a lower setting will result in the room
being controlled at a lower temperature, and saves energy.
4
RET1000 MD
The heating system will not work if a timeswitch or programmer has
switched it o .
The way to set and use your room thermostat is to nd the lowest
temperature setting that you are comfortable with, and then leave it
alone to do its job. The best way to do this is to set the room thermostat
to a low temperature – say 18°C – and then turn it up by one degree
each day until you are comfortable with the temperature. You won’t
have to adjust the thermostat further. Any adjustment above this
setting will waste energy and cost you more money.
If your heating system is a boiler with radiators, there will usually
be only one room thermostat to control the whole house. But you
can have di erent temperatures in individual rooms by installing
thermostatic radiator valves (TRVs) on individual radiators. If you don’t
have TRVs, you should choose a temperature that is reasonable for the
whole house. If you do have TRVs, you can choose a slightly higher
setting to make sure that even the coldest room is comfortable, then
GBGB
prevent any overheating in other rooms by adjusting the TRVs.
Room thermostats need a free ow of air to sense the temperature,
so they must not be covered by curtains or blocked by furniture.
Nearby electric res, televisions, wall or table lamps may prevent the
thermostat from working properly.
Danfoss Heating
5
GBGB
Display
The LCD displays actual room temperature until the Λ or V button
is pressed more than once. To activate the unit’s backlight press
the Λ or V button once, if no further buttons are pressed the
backlight will remain on for 6 seconds.
Temperature
6
RET1000 MD
Flame: shows when heating output is on
Standby: shows when unit is manual set to standby
Padlock: indicates keyboard lock has been set at
installation
GBGB
Danfoss Heating
7
GBGB
Setting the temperature
Press either the Λ or V buttons, the product backlight will come
on.
Press either the Λ or V button again within 6 seconds, the display
will ash with the current set temperature. While the display is
ashing press the Λ arrow to increase the set temperature to the
required setting or the V arrow to decrease the set temperature.
If no buttons are pressed the display will return to actual
temperature after 4 seconds and the backlight will go out after
6 seconds.
Thermostat status
A ame symbol will be lit whenever the thermostat is calling for
heat.
8
RET1000 MD
Delayed Start
An energy saving feature which automatically delays the heating
start time, depending on how close to set-point the ambient
room temperature already is. If the ame symbol is ashing,
the delayed start function is in operation. Delayed start can be
cancelled by pressing the Λ or V button twice. Delayed start will
operate again on timer control next ON time.
Thermostat standby
To place the thermostat into standby (o ), press the V arrow to
enter the temperature setting mode. Press and hold the V arrow
GBGB
until the set temperature disappears and the standby symbol
appears.
When in standby the thermostat will have no control of the
heating. To exit standby press and hold the Λ arrow until the
required set temperature is ashing on the display.
Danfoss Heating
9
GBGB
10
RET1000 MD
GBGB
Danfoss Heating
11
Danfoss Ltd
Ampthill Road
Bedford MK42 9ER
Tel: 01234 364621
Fax: 01234 219705
Email: ukheating@danfoss.com
Website: www.heating.danfoss.co.uk
Part No 44075v01 03/15
