Data sheet
Danfoss Power Pack |
||
PPH 10 - 12.5 |
Nessie® Wood Concept, |
|
type NWC |
||
|
|
Danfoss Power Pack PPH 10 -12.5 is a compact |
|
|
|
|
|
and flexible supply unit designed for tap water |
|
|
hydraulic systems. |
|
|
PPH 10 - 12.5 is primarily designed for the opera- |
|
|
tion of cylinder and motor functions. PPH |
|
|
10 - 12.5 distinguishes itself by its suitability for |
|
|
use in surroundings where a high degree of cor- |
|
|
rosion resistance is required or where safety or |
|
|
environmental considerations require the use of |
|
|
an alternative pressure media. |
|
|
PPH 10 - 12.5 can also be used for applications |
|
|
as water mist system, high pressure cleaning |
|
|
system or other applications where high pressure |
|
|
water is used. |
|
|
|
|
|
|
Design and function |
PPH 10 - 12.5 includes a fixed displacement |
|
axial piston pump driven by an IEC electric |
|
motor, a plastic water tank, a return filter for the |
|
pressure medium, and a VPH 15 E Power |
|
Pack Valve containing the following functions: |
|
relief valve (for setting the required pressure), |
|
a normally open, electrically activated 2/2-way |
|
valve (to provide a bypass function). The water |
|
tank contains monitors for temperature and |
|
level. (Electric switch for minimum level + refill |
|
level). The water level can also be checked |
|
visually (sight glass). |
PPH 10 - 12.5 is supplied with a flexible coupling and bell housing to suit an IEC (BF5 flange) electric motor. This size of motor provides a flexible Power Pack and thus makes it easier to optimise the hydraulic system. The Power Pack is supplied without a coil for the electrically activated bypass function. The coil has to be ordered separately. The performance of the electric motors which may be used with the power pack PPH 10 - 12.5 is:
IEC 100 = 0.75 kW - 3 kW, 750 - 3000 rpm. IEC 112 = 1.5 kW - 4 kW, 750 - 3000 rpm. IEC 132 = 3.0 kW - 7.5 kW, 750 - 3000 rpm.
Performance |
PPH 10 - 12.5 is available in the following ver- |
|
sions: |
|
• 10 cc/rev. 750 - 1500 rpm ** => 6.7 - 13.5 l/ |
|
min |
|
• 12.5 cc/rev 750 - 1500 rpm ** => 8.6 - 17.2 l/ |
|
min |
|
** For speeds outside this range, please contact |
|
the Danfoss Sales Company. |
© Danfoss | HPP (im) | 2021.08 |
AI388238070204en-000101 | 1 |
Data sheet | Danfoss Power Pack PPH 10 - 12.5
Description
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
No. |
Item |
|
Description |
|||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||
1 |
Flexible coupling |
|
For motor type IEC 100/112/132 - B5 flange** |
|||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||
2 |
PAH pump |
|
Type PAH 10 or PAH 12.5 |
|||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||
3 |
Bell housing |
|
For motor IEC 100 /112 /132 and pump flange ISO 3019/2 - 80 A2 HW |
|||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||
4 |
VPH 15 E (15 l/min) |
|
Power-pack-valve - 2/2-way directional valve* incl. pressure relief valve |
|||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||
5 |
FRH |
|
Return filter (10 µm) incl. pressure gauge, bypass and breather (3 µm) |
|||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||
6 |
Monitor device |
|
Temperatur and level monitoring |
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||
7 |
Tank |
|
Volume 60 l (net volume between min. and max. level:19 l), |
|||||||||||||||||||||
|
|
Material: plastic |
||||||||||||||||||||||
|
|
|
|
|
|
|
|
|||||||||||||||||
8 |
Hose (transparent) |
|
Tank drain, visual tank level monitoring |
|||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||
9 |
Ball valve |
|
Filling device |
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
*Directional valve without coil - please order seperatly
**Special adapter + flex coupling necessary with electric motor IEC 132.
See section Code numbers.
Technical data |
|
|
|
|
|
|
|
Variants |
|
Performance |
|
||
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
Power Pack |
Motor |
Max. flow |
Pressure |
|
|
|
|
|
|
|
|
|
|
Type |
rev.** |
l/min. |
barg |
|
|
|
|
|
|
|
|
|
PPH |
|
10 |
750 |
6.7 |
25 - 140 |
|
|
|
|
|
|
|
|
PPH |
|
10 |
1000 |
9.0 |
25 - 140 |
|
|
|
|
|
|
|
|
PPH |
|
10 |
1500 |
13.5 |
25 - 140 |
|
|
|
|
|
|
|
|
PPH |
|
12.5 |
750 |
8.6 |
25 - 140 |
|
|
|
|
|
|
|
|
PPH |
|
12.5 |
1000 |
11.5 |
25 - 140 |
|
|
|
|
|
|
|
|
PPH |
|
12.5 |
1500 |
17.2 |
25 - 140 |
|
|
|
|
|
|
|
**For speeds until 3000 rpm, please contact th Danfoss Sales Company.
Media temperature |
: min. +3 °C - +50 °C |
Storage temperature |
: min. -40 °C - +70 °C |
In transport temperatures lower than -10 °C, consideration must given to the reduced strength of plastic materials.
