PLUS+1 CAN I/O Module Communications Protocol Technical Information

About this Manual

Organization and Headings

To help you quickly find information in this manual, the material is divided into sections, topics, subtopics, and details, with descriptive headings set in red type. Section titles appear at the top of every page in large red type.

In the PDF version of this document, clicking an item underlined in blue italic type you to the referenced page in the document.

Special Text Formatting Controls and indicators are set in bold black type.

Table of Contents

A Table of Contents (TOC) appears on the next page. In the PDF version of this document, the TOC entries are hyperlinked.

Revision History

Date Change Remarks

15 December 2005 —— Draft

22 December 2005 Add SUBCMD 19 Draft, protocol version 2.00

23 December 2005 Config values only 8 bit and not 16 bit in SUBCMD 19 Draft, protocol version 2.00

30 January 2006 Add IO_TYPE 6 for digital inputs on SUBCMD 19 Draft, protocol version 2.00

20 April 2006 —— Released

28 September 2007 Add current change limit—SUBCMD 20

Add recovery times—SUBCMD 21

New values in NV—SUBCMD 22

12 November 2007 Corrected Message Name—Configuration Type Definition table

Updated description of recover times—Bus Off Rcvr Time and CAN Drv Error Rcvr Time

23 November 2007

16 January 2008

31 January 2008 —— Released

3 June 2008 Renamed SUBCMD 18 and edited comments ——

21 October 2008 Corrected shown CMD values—CMD69 and CMD70 ——

26 February 2009 Corrected shown parameter list—CMD 71 (includes Digital ,Digital_AnIn, and Rheo

23 March 2009 Use correct names for CMD69 and CMD70

25 March 2009 Extended Request Configuration message to backwards compatatible for CRC—

31 March 20009 —— Released

26 March 2010 Added Non-Volatile Memory Storage—SUBCMD 22 Draft, protocol version 2.05

14 April 10 Added CMD71, CMD72, CMD73, and CMD74 Draft, protocol version 2.06

27 July 2010 Clarification on Mask—Configuration Type Definition table ——

27 October 2010 Further clarification on Mask—Configuration Type Definition table ——

1 December 2010 —— Reformat, Rev AA

Extended CRC message for backwards compatibility—SUBCMD 18 Draft, protocol version 2.02

inputs)

Changed wording for SUBCMD 18

SUBCMD 255

Draft, protocol version 2.01

Draft, protocol version 2.04

jumps

2

11005130 · AA · December 2010

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Sauer-Danfoss accepts no responsibility for possible errors in catalogs, brochures and other printed material.

Sauer-Danfoss reserves the right to alter its products without prior notice. This also applies to products already

ordered provided that such alterations can be made without affecting agreed specifications.

All trademarks in this material are properties of their respective owners.

PLUS+1, GUIDE, and Sauer-Danfoss are trademarks of the Sauer-Danfoss Group. The PLUS+1 GUIDE, PLUS+1

Compliant, and Sauer-Danfoss logotypes are trademarks of the Sauer-Danfoss Group.

11005130 · AA · December 2010

3

PLUS+1 CAN I/O Module Communications Protocol Technical Information

(This page is intentionally blank.)

4

11005130 · AA · December 2010

T Adobe Reader links entries in this table of contents. To follow a link, click an entry.

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Message Timing Information

In the following section on message structures, the repetition time is specified. If the repetition time is set to zero, then the message is disabled and is not sent. If the repetition time is not zero, then the message is active and is transmitted periodically at the interval specified by the repetition time. (The following tables identify the repetition time as the Rate.)

To change the repetition time, use the Configure Timing message (SUBCMD 12.)

Some of the messages are referred to as optimized and others are not. Optimized messages have the designation OPT in the title of the message. Optimized messages have the data for several inputs or outputs of a certain type contained in the message. This minimizes the number of messages needed to be sent on the CAN bus in order to reduce bus traffic.

Non-optimized (regular) messages typically have only the data for a single input or output. In general optimized messages are used as the default so that all data can be communicated between the I/O module and the controller. A system designer has the option of turning off optimized messages and using regular messages instead. Typically, the default set of messages is adequate for most systems.

11005130 · Rev AA · December 2010

7

Supply (CMD 0)

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

This frame is transmitted from the I/O device continuously with a default cycle time.

CMD

CAN B 0

0x00 Supp* (LSB) Supp* (MSB) Sensor† (LSB) Sensor† (MSB) Shield‡ (LSB) Shield‡ (MSB) —— 500 ms SUPPLY

*

Measured supply voltage in mV.

†

Measured sensor voltage in mV.

‡

Measured shield voltage in mV.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Dig_In (CMD 16)

This frame is transmitted from the I/O device continuously with a default cycle time. This message has to be activated. By default, packed frames are used.

CMD

CAN B 0

0x10 Channel* DigIn† —— —— —— —— —— 0 ms D_IN

*

Identifies the channel.

†

Actual pin status.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Ana/Temp/Rheo (CMD 32)

This frame is transmitted from the I/O device continuously with a default cycle time. This message has to be activated. By default the packed frames are used.

CMD

CAN B 0

0x20 Channel* Value† (LSB) Value† (MSB) —— —— —— —— 0 ms RHEO

*

Identifies the channel.

†

Actual measured value. mV in an analogue configuration; otherwise an Ω value.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

8

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

Dig and Ana/Temp/Rheo Opt I (CMD 33)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device are set to zero.

CMD

CAN B 0

0x21 Value 0* (LSB) Value 0* (MSB) Value 1† (LSB) Value 1† (MSB) Dig 0_7‡ Dig 8_15§ Dig 16_23# 20 ms RHEO_OPTI

*

Actual measured value of the first channel; mV in an analogue configuration; otherwise an Ω value.

†

Actual measured value of the second channel; mV in an analogue configuration; otherwise an Ω value.

‡

Bit pattern for the first 8 digital inputs; bit 0 is channel 0.

§

Bit pattern for the next 8 digital inputs; bit 0 is channel 8.

#

Bit pattern for the next 8 digital inputs; bit 0 is channel 16.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Dig and Ana/Temp/Rheo Opt II (CMD 34)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default. Only input devices with more than two Ana/Temp/Rheo will transmit this message or if the device has more than 24 digital

inputs. Values not available on the I/O device are set to zero.

CMD

CAN B 0

0x22 Value 2* (LSB) Value 2* (MSB) Value 3† (LSB) Value 3† (MSB) Dig 24_31‡ Dig 32_39§Dig 40_47# 20 ms RHEO_OPTII

*

Actual measured value of the third channel; mV in an analogue configuration; otherwise an Ω value.

†

Actual measured value of the fourth channel; mV in an analogue configuration; otherwise an Ω value.

‡

§

Bit pattern for the next 8 digital inputs; bit 0 is channel 32.

#

Bit pattern for the next 8 digital inputs; bit 0 is channel 40.

Data 0

CAN B 1

Bit pattern for the first 8 digital inputs; bit 0 is channel 24.

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Dig/Ana (CMD 48)

This frame is transmitted from the I/O device continuously with a default cycle time. This message will only be transmitted if the device does have this type of input. This message has to be activated; by default the packed frames are used.

CMD

CAN B 0

0x20 Channel* Value† (LSB) Value† (MSB) —— —— —— —— 0 ms RHEO

*

Identifies the channel.

†

Actual measured value in mV.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

9

Dig/Ana Opt I (CMD 49)

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x31 Value 0* (LSB) Value 0* (MSB) Value 1† (LSB) Value 1† (MSB) Value 2‡ (LSB) Value 2‡ (MSB) Dig 0_2§ 20 ms Dig_ANA_OPTI

*

Actual measured value of the first channel in mV.

†

Actual measured value of the second channel in mV.

‡

Actual measured value of the third channel in mV.

§

Bit pattern for the first 3 digital inputs; bit 0 is channel 0.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Dig/Ana Opt II (CMD 50)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x32 Value 3* (LSB) Value 3* (MSB) Value 4† (LSB) Value 4† (LSB) Value 5‡ (LSB) Value 5‡ (LSB) Dig 3_5§ 20 ms Dig_ANA_OPTII

*

Actual measured value of the fourth channel in mV.

†

Actual measured value of the fifth channel in mV.

‡

Actual measured value of the sixth channel in mV.

§

Bit pattern for the next 2 digital inputs; bit 0 is channel 3.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Dig/Ana/Freq (CMD 64)

This frame is transmitted from the I/O device continuously with a default cycle time. This message will only be transmitted if the device does have this type of input. This message has to be activated; by default the packed frames are used.

CMD

CAN B 0

0x40 Channel* Value† (LSB) Value† (MSB) Freq‡ (LSB) Freq‡ (MSB) DigIn§ —— 0 ms DIG_ANA_FREQ

*

Indicates the channel.

†

Actual measured value in mV.

‡

Actual measured frequency.

§

Status of the digital input.

10

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Dig/Ana/Freq Opt I (CMD 65)

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x41 Value 0* (LSB) Value 0* (MSB) Value 1†(LSB) Value 1†(MSB) Value 2‡(LSB) Value 2‡(MSB) Dig 0_2§ 50 ms DIG_ANA_FREQ_OPTI

*

Actual measured value in mV on the first analogue input.

†

Actual measured value in mV on the second analogue input.

‡

Actual measured value in mV on the third analogue input.

§

Bit pattern of the first 3 digital inputs; bit 0 is channel 0.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Dig/Ana/Freq Opt II (CMD 66)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x42 Value 3*(LSB) Value 3*(MSB) Value 4†(LSB) Value 4†MSB) Value 5‡(LSB) Value 5§(MSB) Dig 3_5# 50 ms DIG_ANA_FREQ_OPTI

*

Actual measured value in mV on the fourth analogue input.

†

Actual measured value in mV on the fifth analogue input.

‡

Actual measured value in mV on the sixth analogue input.

#

Bit pattern of the fourth, fifth, and sixth digital input; bit 0 is channel 4.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Dig/Ana/Freq Opt III (CMD 67)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x43 Freq 0* (LSB) Freq 0* (MSB) Freq 1† (LSB) Freq 1† (MSB) Freq 2‡ (LSB) Freq 2‡ (MSB) 50 ms DIG_ANA_FREQ_OPTIII

*

Actual measured frequency in Hz on the first input.

†

Actual measured frequency in Hz on the second input.

‡

Actual measured frequency in Hz on the third input.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

11

Dig/Ana/Freq Opt IV (CMD 68)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

CMD

CAN B 0

0x44 Freq 3* (LSB) Freq 3* (MSB) Freq 4† (LSB) Freq 4† (MSB) Freq 5‡ (LSB) Freq 5‡ (MSB) —— 50 ms DIG_ANA_FREQ_OPTIV

*

Actual measured frequency in Hz on the fourth input.

†

Actual measured frequency in Hz on the fifth input.

‡

Actual measured frequency in Hz on the sixth input.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Dig/Ana/Freq Opt V(CMD 69)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x45 Value 6* (LSB) Value 6* (MSB) Value 7† (LSB) Value 7† (MSB) Value 8‡ (LSB) Value 8‡ (MSB) Dig 6_8§ 50 ms DIG_ANA_FREQ_OPTV

*

Actual measured value in mV on the seventh analogue input.

†

Actual measured value in mV on the eighth analogue input.

‡

Actual measured value in mV on the ninth analogue input.

§

Bit pattern of the seventh, eighth, and ninth digital input; bit 0 is channel 7.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Dig/Ana/Freq Opt VI (CMD 70)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x46 Freq 6* (LSB) Freq 6* (MSB) Freq 7† (LSB) Freq 7† (MSB) Freq 8‡ (LSB) Freq 8‡ (MSB) —— 50 ms DIG_ANA_FREQ_OPTVI

*

Actual measured frequency in Hz on the seventh input.

†

Actual measured frequency in Hz on the eighth input.

‡

Actual measured frequency in Hz on the ninth input.

12

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

Dig/Ana/Freq Opt VII (CMD 71)

This frame is transmitted from the I/O device continuously with a default cycle time. This message will only be transmitted if the device does have this type of input. This message has to be activated; by default the packed frames are used.

CMD

CAN B 0

0x47 Channel* Value†(LSB) Value† (MSB) Freq‡ (LSB) Freq‡ (MSB) Period§ (LSB) Period (MSB) DigIn# 0 ms DIG_ANA_FREQ_OPTVII

*

Indentifies the channel.

†

Actual measured value in mV.

‡

Actual measured frequency.

§

Actual measured period (15-bit).

#

Status of the digital input (MSB of CAN B 7).

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Dig/Ana/Freq Opt VIII (CMD 72)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and has to be activated if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x48 Per 0* (LSB) Per 0* (MSB) Per 1† (LSB) Per 1† (MSB) Per 2‡ (LSB) Per 2‡ (MSB) —— 0 ms DIG_ANA_FREQ_OPTVIII

*

Actual measured period, value in ms on the first input.

†

Actual measured period, value in ms on the second input.

‡

Actual measured period, value in ms on the third input.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Dig/Ana/Freq Opt IX(CMD 73)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and has to be activated if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x49 Per 3* (LSB) Per 3* (MSB) Per 4† (LSB) Per 4† (MSB) Per 5‡ (LSB) Per 5‡ (MSB) —— 0 ms DIG_ANA_FREQ_OPTIX

*

Actual measured period, value in ms on the fourth input.

†

Actual measured period, value in ms on the fifth input.

‡

Actual measured period, value in ms on the sixth input.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

13

Dig/Ana/Freq Opt X(CMD 74)

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and has to be activated if the device does have these inputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x4A Per 6* (LSB) Per 6* (MSB) Per 7† (LSB) Per 7† (MSB) Per 8‡ (LSB) Per 8‡ (MSB) —— 0ms DIG_ANA_FREQ_OPTX

*

Actual measured period, value in ms on the seventh input

†

Actual measured period, value in ms on the eighth input

‡

Actual measured period, value in ms on the ninth input

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Digital Out Status (CMD 80)

This frame is transmitted from the I/O device continuously with a default cycle time. This message will only be transmitted if the device does have this type of output. This message has to be activated; by default the packed frames are used.

CMD

CAN B 0

0x50 Channel* DigOutStat† —— —— —— —— —— 0 ms DIG_OUT_STAT

*

Identifies the channel.

†

Status of the digital output.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Digital/PVG Out Status (CMD 81)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these outputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x51 Channel* Value† (LSB) Value† (LSB) PvgOut_Stat‡ —— —— —— 0 ms PVG_STAT

*

Identifies the channel.

†

Actual measured value in mV.

‡

Status of the digital output.

14

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

Digital/PVG Out Status Opt I (CMD 82)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these outputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x52 Value 0*

*

Identifies the channel.

†

Actual measured value of first PVG channel in mV.

†

Actual measured value of second PVG channel in mV.

‡

Actual measured value of third PVG channel in mV.

§

Status of the digital output of digital and PVG outputs; bit 0 = digital channel 0.

Data 0

CAN B 1

(LSB)

Data 1

CAN B 2

Value 0*

(MSB)

Data 2

CAN B 3

Value 1†

(LSB)

Data 3

CAN B 4

Value 1†

(MSB)

Data 4

CAN B 5

Value 2

(LSB)

Data 5

CAN B 6

‡

Value 2

(MSB)

Data 6

CAN B 7

‡

DigOut_Stat 0_5

Rate Name

§

20 ms PVG_STAT_OPTI

Multifunction Out Status (CMD 96)

This frame is transmitted from the I/O device continuously with a default cycle time. This message will only be transmitted if the device does have this type of output. This message has to be activated; by default the packed frames are used.

CMD

CAN B 0

0x60 Channel* Value† (LSB) Value† (MSB) ActPWM‡ (LSB) ActPWM‡ (MSB) Status§ —— 0 ms MF_OUT

*

Indicates the channel.

†

Actual measured feedback value in 0.1 mA.

‡

PWM duty cycle.

§

Status of the output.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

Multifunction Out Status Opt I (CMD 97)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these outputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x61 Value 0* (LSB) Value 0* (MSB) Value 1† (LSB) Value 1† (MSB) Value 2‡ (LSB) Value 2‡ (MSB) Status§ 20 ms MF_OUT_OPTI

*

Actual measured feedback value of channel 0 in 0.1 mA.

†

Actual measured feedback value of channel 1 in 0.1 mA.

‡

Actual measured feedback value of channel 2 in 0.1 mA.

§

Status of the output; Status of channel 0 is bit 0 and bit 1, status of channel 1 is bit 2 and bit 3, status of channel 3 is bit 4 and bit 5.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Rate Name

15

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

Multifunction Out Status Opt II (CMD 98)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these outputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x62 Value 3* (LSB) Value 3* (MSB) Value 4† (LSB) Value 4† (MSB) Value 5‡ (LSB) Value 5‡ (MSB) Status§ 20 ms MF_OUT_OPTII

*

Actual measured feedback value of channel 3 in 0.1 mA.

†

Actual measured feedback value of channel 4 in 0.1 mA.

‡

Actual measured feedback value of channel 5 in 0.1 mA.

§

Status of the output; Status of channel 3 is bit 0 and bit 1, channel 4 bit 2 and bit 3, channel 5 bit 4 and bit 5.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Multifunction Out Status Opt OPT III (CMD 99)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these outputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x63 Value 6* (LSB) Value 6* (MSB) Value 7† (LSB) Value 7† (MSB) Value 8‡ (LSB) Value 8‡ (MSB) Status§ 20 ms MF_OUT_OPTIII

*

Actual measured feedback value of channel 6 in 0.1 mA.

†

Actual measured feedback value of channel 7 in 0.1 mA.

§

Status of the output; Status of channel 6 is bit 0 and bit 1, channel 7 bit 2 and bit 3, channel 8 bit 4 and bit 5.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Multifunction Out Status Opt IV (CMD 100)

This frame is transmitted from the I/O device continuously with a default cycle time. This message is a packed frame and is activated by default if the device does have these outputs. Values not available on the I/O device will be set to zero.

CMD

CAN B 0

0x64 Value 9* (LSB) Value 9* (MSB) Value 10† (LSB) Value 10† (MSB) Value 11‡ (LSB) Value 11‡ (MSB) Status§ 20 ms MF_OUT_OPTIV

*

Actual measured feedback value of channel 9 in 0.1 mA.

†

Actual measured feedback value of channel 10 in 0.1 mA.

‡

Actual measured feedback value of channel 11 in 0.1 mA.

§

Status of the output; Status of channel 9 is bit 0 and bit 1, channel 10 bit 2 and bit 3, channel 11 bit 4 and bit 5.

16

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Rate Name

Digital Out (CMD 128)

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined. For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the PLUS+1 CAN I/O Module Communications Technical Information document (SauerDanfoss part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. DIGOUT is interpreted as False for a value of zero and True for all other values.

CMD

CAN B 0

0x80 Channel* DigOut† —— —— —— —— —— 0 ms DIG_OUT_REQ

*

Identifies the channel.

†

Requested output state.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Timeout Name

Digital/PVG Out (CMD 129)

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined. For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the PLUS+1 CAN I/O Module Communications Technical Information document (SauerDanfoss part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. DIGOUT is interpreted as False for a value of zero and True for all other values.

CMD

CAN B 0

0x81 Channel* PVGOut† —— —— —— —— —— 0 ms PVG_REQ

*

Identifies the channel.

†

Requested output state.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Timeout Name

11005130 · Rev AA · December 2010

17

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

Digital/PVG Out Opt I (CMD 130)

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined. For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the PLUS+1 CAN I/O Module Communications Technical Information document (SauerDanfoss part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. DIGOUT is interpreted as False for a corresponding bit of zero and True for a corresponding bit of one.

CMD

CAN B 0

0x82 DigOut 0_7* DigOut 8_15† PVGOut 0_7‡ PVGOut 8_15§—— —— —— 100 ms DIGPVG_OPT1

*

Requested state for DIGOUT 0 to 7; Channel 0 is bit 0.

†

Requested state for DIGOUT 8 to 15; Channel 8 is bit 0.

‡

Requested state for PVGOUT 0 to 7; Channel 0 is bit 0.

§

Requested state for DIGOUT 8 to 15; Channel 8 is bit 0.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7

Timeout Name

Multifunction Out (CMD 144)

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined. For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the PLUS+1 CAN I/O Module Communications Technical Information document (SauerDanfoss part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. OUTPUT is interpreted based on the pin configuration. Please see the corresponding device API for more details of proper values. If configured as a digital output is interpreted as False for a value of zero and True for all other values.

CMD

CAN B 0

0x90 Channel* Output† (LSB) Output† (MSB) —— —— —— —— 0 ms MF_OUT_REQ

*

Identifies the channel.

†

Requested state.

Data 0

CAN B 1

Data 1

CAN B 2

Data 2

CAN B 3

Data 3

CAN B 4

Data 4

CAN B 5

Data 5

CAN B 6

Data 6

CAN B 7 Timeout Name

18

11005130 · Rev AA · December 2010

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

Multifunction Out Opt I (CMD 145)

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined. For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the PLUS+1 CAN I/O Module Communications Technical Information document (SauerDanfoss part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. OUTPUT is interpreted based on the pin configuration. Please see the corresponding device API for more details of proper values. If configured as a digital output is interpreted as False for a value of zero and True for all other values.

CMD

CAN B 0

0x91 Output 0*

*

Requested output for channel 0.

†

Requested output for channel 1.

‡

Requested output for channel 2.

Data 0

CAN B 1

(LSB)

Data 1

CAN B 2

Output 0*

(MSB)

Data 2

CAN B 3

Output 1†

(LSB)

Multifunction Out Opt II (CMD 146)

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the

PLUS+1 CAN I/O Module Communications Technical Information document (Sauer-Danfoss

part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. OUTPUT is interpreted based on the pin configuration. Please see the corresponding device API for more details of proper values. If configured as a digital output is interpreted as False for a value of zero and True for all other values.

CMD

CAN B 0

0x92 Output 3*

*

Requested output for channel 3.

†

Requested output for channel 4.

‡

Requested output for channel 5.

Data 0

CAN B 1

(LSB)

Data 1

CAN B 2

Output 3*

(MSB)

Data 2

CAN B 3

Output 4†

(LSB)

Data 3

CAN B 4

Output 1†

(MSB)

Data 3

CAN B 4

Output 4†

(MSB)

Data 4

CAN B 5

Output 2‡

(LSB)

Data 4

CAN B 5

Output 5‡

(LSB)

Data 5

CAN B 6

Output 2‡

(MSB)

Data 5

CAN B 6

Output 5‡

(MSB)

Data 6

CAN B 7 Timeout Name

—— 100 ms MF_OUT_REQ_OPTI

Data 6

CAN B 7 Timeout Name

—— 100 ms MF_OUT_REQ_OPTII

11005130 · Rev AA · December 2010

19

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Identifier

Multifunction Out Opt III (CMD 147)

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined. For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the PLUS+1 CAN I/O Module Communications Technical Information document (SauerDanfoss part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. OUTPUT is interpreted based on the pin configuration. Please see the corresponding device API for more details of proper values. If configured as a digital output is interpreted as False for a value of zero and True for all other values.

CMD

CAN B 0

0x93 Output 6*

*

Requested output for channel 6.

†

Requested output for channel 7.

‡

Requested output for channel 8.

Data 0

CAN B 1

(LSB)

Data 1

CAN B 2

Output 6*

(MSB)

Data 2

CAN B 3

Output 7†

(LSB)

Multifunction Out Opt IV (CMD 148)

This frame is transmitted to the I/O device continuously with a default cycle time. If the message does not arrive in the predefined cycle time, the slave will set the output to a default value. The default value and the timeout time can be defined. For more information see Configure Timing (SUBCMD 12) and Configure Output Default (SUBCMD 13) in the PLUS+1 CAN I/O Module Communications Technical Information document (SauerDanfoss part 520L1029). If no default values have been defined, the shown timeout value will be used. If no default output value is defined, the I/O slaves will use a zero as a default value. This message will be interpreted from the slave in packed and unpacked data transmission mode. Commands for non-existing outputs will be ignored. OUTPUT is interpreted based on the pin configuration. Please see the corresponding device API for more details of proper values. If configured as a digital output is interpreted as False for a value of zero and True for all other values.

Data 3

CAN B 4

Output 7†

(MSB)

Data 4

CAN B 5

Output 8‡

(LSB)

Data 5

CAN B 6

Output 8‡

(MSB)

Data 6

CAN B 7 Timeout Name

—— 100 ms MF_OUT_REQ_OPTIII

CMD

CAN B 0

0x94 Output 9*

*

Requested output for channel 9.

†

Requested output for channel 10.

‡

Requested output for channel 11.

20

Data 0

CAN B 1

(LSB)

Data 1

CAN B 2

Output 9*

(MSB)

Data 2

CAN B 3

Output 10†

(LSB)

11005130 · Rev AA · December 2010

Data 3

CAN B 4

Output 10†

(MSB)

Data 4

CAN B 5

Output 11‡

(LSB)

Data 5

CAN B 6

Output 11‡

(MSB)

Data 6

CAN B 7 Timeout Name

—— 100 ms MF_OUT_REQ_OPTIV

Ack (SUBCMD 0)

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Time uncritical messages are mapped to the subcommand messages. This area is entered by using 0xFF for the main CMD page. This means that 0xFF will be in the first data byte of the CAN-Message.

This frame is transmitted from the I/O device after It can be used for further diagnostics.

reception of one of the CMD messages.

CMD

CAN B 0

0xFF 0x00 Error* Req Subcmd† No‡ —— —— —— None ACK

*

Possible error information: 0 = no error; 1 = wrong index; 2 = function not supported.

†

Gives information to which the ACK corresponds.

‡

This is the N0 from the requestor.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Request Protocol Version (SUBCMD 1)

This frame can be transmitted from the MC to ask for the protocol version.

CMD

CAN B 0

0xFF 0x01 —— —— —— —— —— —— None REQ_PROT

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Protocol Version (SUBCMD 2)

This frame is transmitted from the slave after reception of a REQ_PROT message.

CMD

CAN B 0

0xFF 0x02 Ver* (LSB) Ver* (MSB) UnitL† (LSB) UnitL† (MSB) UnitH† (LSB) UnitH† (MSB) None PROT_VER

*

Version of the communication protocol.

†

Unit ID (high, low) number that describes the type of IO hardware

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Configure DIG Input (SUBCMD 3)

This frame configures the digital inputs of an input device. All inputs are by default configured as no pull up/no pull down. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x03 Channel* Config† —— —— —— —— None CMD_CONF_DIGIN

*

Identifies the channel.

†

Requested configuration.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

11005130 · Rev AA · December 2010

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

21

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Configure Analogue Input (SUBCMD 4)

This frame configures the analogue inputs of an input device. All inputs are by default configured as analogue inputs. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x04 Channel* Config† —— —— —— —— None CMD_CONF_ANIN

*

Identifies the channel.

†

Requested configuration as specified in the corresponding Application Interface.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Configure Multifunction Input Dig/Ana (SUBCMD 5)

This frame configures the digital/analogue inputs of an input device. All inputs are by default configured as no pull up/no pull down and with the 5.250 V range. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x05 Channel* Config 0† Config 1‡ —— —— —— None CMD_CONF_DIGANIN

*

Indentifies the channel to configure.

†

Requested configuration as specified in the corresponding Application Interface for the biasing.

‡

Requested configuration as specified in the corresponding Application Interface for the voltage range.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

Configure Multifunction Input Dig/Ana Switch Point (SUBCMD 6)

This frame configures the digital input switch point. Default for the low value is 2000. Default for the high value is 3000. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x06 Channel* Low† (LSB) Low† (MSB) High‡ (LSB) High‡ (MSB) —— None CMD_CONF_DIGANIN_SWITCH

*

Indentifies the channel to configure.

†

Requested low switch point as specified in the corresponding Application Interface.

‡

Requested high switch point as specified in the corresponding Application Interface.

22

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

11005130 · Rev AA · December 2010

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Configure Multifunction Input Dig/Ana/Freq (SUBCMD 7)

This frame configures the digital/analogue inputs of an input device. All inputs are by default configured as no pull up/ no pull down and with the 5.250 V range. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x07 Channel* Config 0† Config 1‡ —— —— —— None CMD_CONF_DIGANFREQIN

*

Indicates the channel to configure.

†

Requested configuration as specified in the corresponding Application Interface for the biasing.

‡

Requested configuration as specified in the corresponding Application Interface for the voltage range.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

Configure Multifunction Input Dig/Ana/Freq Switch Point (SUBCMD 8)

This frame configures the digital input switch point. The default for low value is 2000. The default for the high value is 3000. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x08 Channel* Low†(LSB) Low† (MSB) High‡ LSB) High‡ (MSB) —— None CMD_CONF_DIGANFREQIN_SWITCH

*

Indicates the channel to configure.

†

Requested low switch point as specified in the corresponding Application Interface.

‡

Requested high switch point as specified in the corresponding Application Interface.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Configure Multifunction Output (SUBCMD 9)

This frame configures the multifunction output of an output device.

All outputs are by default configured as:

• Digital Output (push/pull).

• Dither Freq = 0.

• Dither Amp = 0.

The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x09 Channel* Config† D_Freq‡ (LSB) D_Freq‡ (MSB) D_Amp§ (LSB) D_Amp§ (MSB) None CMD_CONF_MF_OUT

*

Indicates the channel to configure.

†

Requested configuration as specified in the corresponding Application Interface.

‡

Requested value for dither frequency.

§

Requested value for dither amplitude.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

11005130 · Rev AA · December 2010

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

23

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Configure Multifunction Output Frequency (SUBCMD 10)

This frame configures the PWM frequency of a set of outputs. Default is 4000. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x0A Channel* Freq† (LSB) Freq† (MSB) —— —— —— None CMD_CONF_MF_OUT_FREQ

*

Indicates the group to configure.

†

Requested output frequency; if it is out of range, the device will select the nearest possible.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Freeze N1 (SUBCMD 11)

On reception of this frame the I/O device will rescan the analogue input and will calculate N1 and save this parameter. The I/O device will also change to predefined CAN-identifier mode with fixed N1. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x0B —— —— —— —— —— —— None CMD_FREEZE_N1

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

Configure Timing (SUBCMD 12)

This frame can be used to configure the timing of the cyclic transmit messages of the I/O slave. It can also be used to set new values for the cyclic receive messages of the I/O slave. The I/O device responds with the ACK message. A value of 0x0000 for time totally disables a message transmitted from the I/O slave. Otherwise, the time value is entered in milliseconds.

CMD

CAN B 0

0xFF 0x0C Sub-identifier* Channel† Time‡ (LSB) Time‡ (MSB) —— —— None CMD_TIME

†

If the message being enabled or disabled has a “channel” value associated with it, please enter the value here.

*

Identifies the communication message gets a new timing value.

‡

New timing value, which can be the new cycle or the new timeout value, depending on the message.

24

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

11005130 · Rev AA · December 2010

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Configure Output Default (SUBCMD 13)

This frame can be used to configure the default output values of the output slaves. After start up these values are set to zero. These default values will be used if a timeout occurs on the cyclic CMD messages. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x0D Output Type* Channel† Value‡ (LSB) Value‡ (MSB) —— —— None CMD_OUT_DEFAULT

*

The output type:

– 0 = Digital output. – 1 = PVG power output. – 2 = Multifunction output.

†

The channel on which the new default value has to be set.

The new default value used in case the communication breaks down.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

Set AddrMode (SUBCMD 14)

This frame sets the CAN-ID mode with N1 and MASK and the baud rate for the I/O device. The I/O device responses with the ACK message.

CMD

CAN B 0

0xFF 0x0E AddrMode* N1† Mask‡ Baud§ 0_7 Baud§ 8_15 Baud§ 16_23 None CMD_ADDR_MODE

*

Sets the addressing mode; ignored if 0xFF.

†

N1 to set; ignored if 0xFF otherwise only the last four significant bits will be used.

‡

Mask value to set; ignored if 0xFF otherwise only the three least significant bits are used.

§

The requested power up baud rate, ignored if 0xFFffff.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Set Fixed Tx ID (SUBCMD 15)

This frame sets a fixed Tx ID. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x0F Tx* LW (LSB) Tx* LW (MSB) Tx* HW (LSB) Tx* HW (MSB) Frame† —— None CMD_FIX_Tx _ID

*

ID for the Tx message of the fixed CAN-ID.

†

Defines if 11 bit or 29 bit identifiers should be used, 0 = 11 bit and 1 = 29 bit ID.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

11005130 · Rev AA · December 2010

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

25

Set Fixed Rx ID (SUBCMD 16)

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

This frame sets a fixed Rx ID. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x10 Rx* LW (LSB) Rx* LW (MSB) Rx* HW (LSB) Rx* HW (MSB) —— —— None CMD_FIX_Rx _ID

*

ID for the Rx message of the fixed CAN-ID, it will use the same frame type as for the Tx message.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeou

t Name

Set KWP2000 Net (SUBCMD 17)

This frame sets the Net Number for Keyword Protocol 2000. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x11 Net* —— —— —— —— —— None CMD_NET_NMB

*

Value for the KWP NET number.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeou

t

Name

Configuration CRC (SUBCMD 18)

This message contains the Configuration CRC number out of an I/O device in response to a request using SUBCMD 255.

CMD

CAN B 0

0xFF 0x12 CRC* (LSB) CRC* (MSB) CRC Mode† CRC Param‡ —— —— None CMD_GET_CRC

*U16 configuration CRC number.

†

Optional value; if not existing or if zero, then the CRC value is over parameters from protocol version 2.00 and the parameter CRC Param has no

effect.

‡

If CRC Mode = 1 this value describes over which range the CRC is calculated. 0 = Parameters from version 2.00; 1 = All parameters as defined by

version 2.01 including earlier versions.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

26

11005130 · Rev AA · December 2010

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Temporary IO Configuration (SUBCMD 19)

This frame can be used to configure the configuration of IOs. This configuration is lost after power cycle. After start up these values are set to the default values. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x13 IO_Type* Channel† Value 0‡ Value 1§ —— —— None CMD_CONF_TEMP

*

Input/output type:

– 0 = Digital output. – 1 = PVG power output. – 2 = Multifunction output. – 3 = Analogue input. – 4 = Digital/analogue input. – 5 = Multifunction input. – 6 = Digital input.

†

The channel on which the new configuration value has to be set.

‡

The new configuration value 0.

§

The new configuration value 1.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

Configure Current Change Limit (SUBCMD 20)

This frame configures the current change limit of a multifunction output of an output device. The default value is 111. The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x14 Channel* Limit† (LSB) Limit† (MSB) —— —— —— None CMD_CONF_CURCHGLIM

*

Identifies the channel to configure.

†

Requested current change limit as specified in the corresponding Application Interface.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7

Timeout Name

11005130 · Rev AA · December 2010

27

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Configure Recover Times (SUBCMD 21)

This frame configures the bus off and can driver recover time. The default value for both parameters is 10000, which means in case of a recovery situation the device will try to recover every 10 seconds.

The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x15 Channel* Bus† (LSB) Bus† (MSB) Driver‡ (LSB) Driver‡ (MSB) —— None CMD_CONF_RCVR_TIME

*

Identifies the channel to configure.

†

Requested time value for Bus OFF recover in ms.

‡

Requested time value for CAN driver recover in ms.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Non-Volatile Memory Storage (SUBCMD 22)

This frame allows access to the data storage provided by the expansion module. Data can be written to 16 individual 32-bit memory segments. Each 32-bit segment allows the storage of an 8-bit checksum in addition to the 32-bit data, this allows validity checks. The 8-bit checksum will be handled by the master device, not the expansion module. This allows the master to implement it’s own checksum algorithm.

Data loss will occur if a power failure occurs during a write to a 32-bit memory segment.

Maximum number of writes: 10,000

The I/O device responds with the ACK message.

CMD

CAN B 0

0xFF 0x16 8-bit

*

The lower 4-bits of DATA 0 are used to select which 32-bit segment will be written (0-15).

†

8-bit field to allow the master to write a checksum for data validation.

‡

32-bit data segment for storage.

SUBCMD

CAN B 1

Data 0

CAN B 2

segment address

Data 1

CAN B 3

8-bit

*

checksum†

Data 2

CAN B 4

32-bit

data‡

Data 3

CAN B 5

32-bit

data‡

Data 4

CAN B 6

32-bit

data‡

Data 5

CAN B 7 Timeout Name

32-bit

data‡

None CMD_DATA_STORAGE

28

11005130 · Rev AA · December 2010

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Messages Based on the Sub-Command

Request Configuration (SUBCMD 255)

This frame can be used to request the configuration state of a certain input or output. In addition, the configuration of the messages can be requested with this frame. The I/O device responds with the corresponding configuration message in a positive case else with an ACK message containing the error.

CMD

CAN B 0

0xFF 0xFF Configuration Type* Channel† or CRC Mode‡CRC Param§ —— —— —— None CMD_REQ_CONF

*

See the following Configuration Type Definition table.

†

The channel from which the information is requested.

‡

If zero, the CRC value is over parameters from protocol version 2.00 and the parameter CRC Param has no effect.

§

Optional value—ff CRC Mode = 1 this value describes the range over which the CRC is calculated. 0 = Parameters from version 2.00; 1 = All

parameters as defined by version 2.01 including earlier versions.

SUBCMD

CAN B 1

Data 0

CAN B 2

Data 1

CAN B 3

Data 2

CAN B 4

Data 3

CAN B 5

Data 4

CAN B 6

Data 5

CAN B 7 Timeout Name

Configuration Type Definition

Configuration Type Value Type of Configurable Input/Output Positive Response Message of the Slave

0 Digital input Configure dig input (SUBCMD 3)

1 Analogue input Configure analogue input (SUBCMD 4)

2 Multifunction input Dig/Ana Configure multifunction input Dig/Ana (SUBCMD 5)

3 Multifunction input Dig/Ana switch point Configure multifunction input Dig/Ana switch point (SUBCMD 6)

4 Multifunction input Dig/Ana/Freq Configure multifunction input Dig/Ana/Freq (SUBCMD 7)

5 Multifunction input Dig/Ana/Freq switch point Configure multifunction input Dig/Ana/Freq switch point (SUBCMD8)

6 Multifunction output Configure multifunction output (SUBCMD 9)

7 Multifunction output frequency Configure multifunction output frequency (SUBCMD 10)

8 Timing Configure timing (SUBCMD 12)

9 Output defaults Configure output default (SUBCMD 13)

10 Set AddrMode Set AddrMode (SUBCMD 14)

11 Set Tx Set fixed Tx ID (SUBCMD 15)

12 Set Rx Set fixed Rx ID (SUBCMD 16)

13 Set KWP NET number Set KWP2000 NET (SUBCMD 17)

14 Configuration CRC Configuration CRC (SUBCMD 18)

15 Current change limit Configure current change limit (SUBCMD 20)

16 Recover time Configure recover times (SUBCMD 21)

17 Non-volatile memory storage Non-volatile memory storage (SUBCMD 22)

11005130 · Rev AA · December 2010

29

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Parameters Stored in Non-Volatile Memory

Several parameters of the system have to be stored in the non-volatile memory so that the parameters are available after a power cycle. These parameters can always be accessed and modified with the diagnostic tool. Besides communication parameters some predefined start up values for the outputs and the configuration values for the outputs and the inputs are stored in the non volatile memory.

Parameter Overview

Parameter Data Type Default Value Range Protocol Version

PwrUpBaud U32 250 000 1 000 000

500 000

250 000

125 000

100 000

AddrMode U16 0 0 = Variable ID

1= Predefined ID fixed N1

2 = Fixed ID

Tx U32 0x400 0x00–0x1FFFFFFF 2.00

Rx U32 0x500 0x00–0x1FFFFFFF 2.00

Frame U16 0 0 = 11 bid ID

1= 29 bit ID

N1 U16 0 0–15 2.00

Mask U16 0 0–7 2.00

Net U16 0 0–255 2.00

Out Default [NMBChannel] U16 0 0xFFFF 2.00

Out Default Config [NMBChannel] U16 0 0xFFFF 2.00

DigOut Default [NMBChannel] U16 0 0xFFFF 2.00

PVE Default [NMBChannel] U16 0 0xFFFF 2.00

Digital Default Config [NMBChannel] U16 0 0xFFFF 2.00

In Default Config 0 [NMBChannel] U16 0 0xFFFF 2.00

In Default Config 1 [NMBChannel] U16 0 0xFFFF 2.00

Rheo Default Config [NMBChannel] U16 0 0xFFFF 2.00

Digital Anin Default Config 0 [NMBChannel] U16 0 0xFFFF 2.00

Digital Anin Default Config 1 [NMBChannel] U16 0 0xFFFF 2.00

Bus Off Error Rcvr Time [NMBChannel] U16 0x2710 0xFFFF 2.01

CAN Drv Error Rcvr Time [NMBChannel] U16 0x2710 0xFFFF 2.01

2.00

11005130 · Rev AA · December 2010

30

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Parameters Stored in Non-Volatile Memory

Power-Up Baud Rate (PwrUpBaud) Parameter

This parameter defines the power up baud rate of the device. The I/O device will initialize the CAN-Bus with the baud rate given by this parameter after power up. Changing this parameter will take affect only after the next power cycle.

Addressing Mode (AddrMode) Parameter

The addressing mode select

• Variable CAN-Identifiers based on the CAN-Shield input

• Predefined CAN-Identifiers with fixed N1

• Fixed identifiers

For more information, refer to CAN-Identifier Usage in the PLUS+1 CAN I/O Module

Communications Technical Information document (Sauer-Danfoss part 520L1029).

s one of the following:

Fixed Tx ID (Tx) Parameter

This parameter is only used in the case of fixed identifi the ID for the Tx message of the device.

For more information, refer to Fixed Identifier Usage in the PLUS+1 CAN I/O Module

Communications Technical Information document (Sauer-Danfoss part 520L1029).

Fixed Rx ID (Rx) Parameter

This parameter is only used in the case of fixed identifi the ID for the Rx message of the device.

For more information, refer to Fixed Identifier Usage in the PLUS+1 CAN I/O Module

Communications Technical Information document (Sauer-Danfoss part 520L1029).

Fixed ID Frame Format (Frame) Parameter

This parameter is only used in the case of fixed identifi the message frame format (11-bit or 29 bit identifier.)

For more information, refer to Fixed Identifier Usage in the PLUS+1 CAN I/O Module

Communications Technical Information document (Sauer-Danfoss part 520L1029).

N1 (N1) Parameter

This parameter is only used in the case of pred contains the value for N1.

er addressing mode and describes

efined CAN-Identifier addressing mode and

Mask (Mask) Parameter

This parameter contains the

mask for the CAN-Messages being received. It is used to set the mask of the receiving CAN-Mailbox. This parameter applies to all addressing modes. A value of 1 means don’t care for the corresponding bit position.

11005130 · Rev AA · December 2010

31

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Parameters Stored in Non-Volatile Memory

KWP2000 Net Number (Net) Parameter

This parameter contains the power up KWP2000 net number.

Default Output Value (Out Default) Parameter

This parameter contains the as many default values as the unit has outputs. This default value will be used, if the corresponding CAN-Frame has a timeout.

Default Output Configuration (Out Default Config) Parameter

This parameter contains the values as the unit has outputs. This default value will be used at start up of the unit.

Default DigOut Value (DigOut Default) Parameter

This parameter contains the default values as the unit does have these outputs. This default value will be used if the corresponding CAN-Frame has a timeout.

default output value for the multifunction outputs. There are

default output configuration value. There are as many default

default output value for the digital outputs. There are as many

Default PVE Value (PVE Default) Parameter

This parameter contains the

default output value for the PVE power outputs. There are as many default values as the unit has outputs. This default value will be used if the corresponding CAN-Frame has a timeout.

Digital Input Configuration (DigitalDefault Config) Parameter

This parameter contains the default configuration value for the biasing of the digital inputs. T

here are as many default values as the unit has inputs. This default value will be

used at start up of the unit.

Input Configuration 0 (In Default Config 0) Parameter

This parameter contains the

default configuration value for the biasing of the multifunction inputs. There are as many default values as the unit has inputs. This default value will be used at start up of the unit.

Input Configuration 1 (In Default Config 1) Parameter

This parameter contains the default con multifunction inputs. There are as many default values as the unit has inputs. This default value will be used at start up of the unit.

Digital Analogue Input Configuration 0 (Digital AnIn Default

This parameter contains the default configuration value for the biasing of the digital/analogue inputs. There are as many default values as the unit has inputs. This default value will be used at start up of the unit.

figuration value for the voltage divider of the

Config 0) Parameter

32

11005130 · Rev AA · December 2010

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Parameters Stored in Non-Volatile Memory

Digital Analogue Input Configuration 1 (Digital AnIn Default Config 1) Parameter

This parameter contains the default configuration value for the voltage divider of the digital/analogue inputs. There are as many default values as the unit has inputs. This default value will be used at start up of the unit.

Rheostat Input Configuration 1 (Rheo Default Config 1) Parameter

This parameter contains the analogue and rheostat measurement for the rheostat inputs. There are as many default values as the unit has inputs. This default value will be used at start up of the unit.

Bus OFF Recover Time (Bus Off Rcvr Rate) Parameter

This parameter contains the The unit will try to recover from the Bus off condition until it succeeds. The time between two attempts is given by this value. There are as many recover times as the unit has CAN channels.

default configuration value for mode switching between

default time value for the CAN Bus OFF recover time in ms.

CAN Driver Error Recover time (CAN Drv Error Rcvr Time) Parameter

This parameter contains the

default time value for the CAN driver error recover time in ms. The unit will try to recover from the CAN driver error condition until it succeeds. The time between two attempts is given by this value. There are as many recover times as the unit has CAN channels.

11005130 · Rev AA · December 2010

33

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Index

T Adobe Reader links entries in this index. To follow a link, click an entry page number.

A

Ack (SUBCMD 0), 21 Addressing Mode (AddrMode) Parameter, 31 Ana/Temp/Rheo (CMD 32), 8

B

Bus OFF Recover Time (Bus Off Rcvr Rate) Parameter, 33

C

CAN Driver Error Recover time (CAN Drv Error Rcvr

Time) Parameter, 33 CMD 0—Supply, 8 CMD 100—Multifunction Out Status Opt IV, 16 CMD 128—Digital Out, 17 CMD 129—Digital/PVG Out, 17 CMD 130—Digital/PVG Out Opt I, 18 CMD 144—Multifunction Out, 18 CMD 145—Multifunction Out Opt I, 19 CMD 146—Multifunction Out Opt II, 19 CMD 147—Multifunction Out Opt III, 20 CMD 148—Multifunction Out Opt IV, 20 CMD 16—Dig_In, 8 CMD 32—Ana/Temp/Rheo, 8 CMD 33—Dig and Ana/Temp/Rheo Opt I, 9 CMD 34—Dig and Ana/Temp/Rheo Opt II, 9 CMD 48—Dig/Ana, 9 CMD 49—Dig/Ana Opt I, 10 CMD 50—Dig/Ana Opt II, 10 CMD 64—Dig/Ana/Freq, 10 CMD 65—Dig/Ana/Freq Opt I, 11 CMD 66—Dig/Ana/Freq Opt II, 11 CMD 67—Dig/Ana/Freq Opt III), 11 CMD 68—Dig/Ana/Freq Opt IV, 12 CMD 69—Dig/Ana/Freq Opt V, 12 CMD 70—Dig/Ana/Freq Opt VI, 12 CMD 71—Dig/Ana/Freq Opt VII, 13 CMD 72—Dig/Ana/Freq Opt VIII, 13 CMD 73—Dig/Ana/Freq Opt IX, 13 CMD 74—Dig/Ana/Freq Opt X, 14 CMD 80—Digital Out Status, 14

11005130 · Rev AA · December 2010

CMD 81—Digital/PVG Out Status, 14 CMD 82—Digital/PVG Out Status Opt I, 15 CMD 96—Multifunction Out Status, 15

CMD 97—Multifunction Out Status Opt I, CMD 98—M CMD 99—Multifunction Out Status Opt OPT III, 16 Configuration CRC (SUBCMD 18), 26 Configure Analogue Input (SUBCMD 4), 22 Configure Current Change Limit (SUBCMD 20), 27 Configure DIG Input (SUBCMD 3), 21 Configure Multifunction Input Dig/Ana (SUBCMD 5), 22 Configure Multifunction Input Dig/Ana Switch Point

(SUBCMD 6), 22

Configure Multifunction Input Dig/Ana/Freq (SUBCMD

7), 23

Configure Multifunction Input Dig/Ana/Freq Switch

Point (SUBCMD 8), 23 Configure Multifunction Output (SUBCMD 9), 23 Configure Multifunction Output Frequency (SUBCMD

10), 24 Configure Output Default (SUBCMD 13), 25 Configure Recover Times (SUBCMD 21), 28 Configure Timing (SUBCMD 12), 24

ultifunction Out Status Opt II, 16

15

D

Default DigOut Value (DigOut Default) Parameter, 32 Default Output Configuration (Out Default Config)

Parameter, 32 Default Output Value (Out Default) Parameter, 32 Default PVE Value (PVE Default) Parameter, 32 Dig and Ana/Temp/Rheo Opt I (CMD 33), 9 Dig and Ana/Temp/Rheo Opt II (CMD 34), 9 Dig/Ana (CMD 48), 9 Dig/Ana Opt I (CMD 49), 10 Dig/Ana Opt II (CMD 50), 10 Dig/Ana/Freq (CMD 64), 10 Dig/Ana/Freq Opt I (CMD 65), 11 Dig/Ana/Freq Opt II (CMD 66), 11 Dig/Ana/Freq Opt III (CMD 67), 11 Dig/Ana/Freq Opt IV (CMD 68), 12 Dig/Ana/Freq Opt IX(CMD 73), 13 Dig/Ana/Freq Opt V(CMD 69), 12 Dig/Ana/Freq Opt VI (CMD 70), 12

34

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Index

Dig/Ana/Freq Opt VII (CMD 71), 13 Dig/Ana/Freq Opt VIII (CMD 72), 13 Dig/Ana/Freq Opt X(CMD 74), 14 Dig_In (CMD 16), 8 Digital Analogue Input Configuration 0 (Digital AnIn

Default Config 0) Parameter, 32

Digital Analogue Input Configuration 1 (Digital AnIn

Default Config 1) Parameter, 33

Digital Input Configuration (DigitalDefault Config)

Parameter, 32 Digital Out (CMD 128), 17 Digital Out Status (CMD 80), 14 Digital/PVG Out (CMD 129), 17 Digital/PVG Out Opt I (CMD 130), 18 Digital/PVG Out Status (CMD 81), 14 Digital/PVG Out Status Opt I (CMD 82), 15

F

Fixed ID Frame Format (Frame) Parameter, 31 Fixed Rx ID (Rx) Parameter, 31 Fixed Tx ID (Tx) Parameter, 31 Freeze N1 (SUBCMD 11), 24

I

Input Configuration 0 (In Default Config 0) Parameter,

32

Input Configuration 1 (In Default Config 1) Parameter,

32

K

KWP2000 Net Number (Net) Parameter, 32

M

Mask (Mask) Parameter, 31 Messages Based on the Sub-identifier, 8 Multifunction Out (CMD 144), 18 Multifunction Out Opt I (CMD 145), 19 Multifunction Out Opt II (CMD 146), 19 Multifunction Out Opt III (CMD 147), 20 Multifunction Out Opt IV (CMD 148), 20 Multifunction Out Status Opt I (CMD 97), 15 Multifunction Out Status Opt II (CMD 98), 16

11005130 · Rev AA · December 2010

Multifunction Out Status Opt IV (CMD 100), 16 Multifunction Out Status Opt OPT III (CMD 99), 16

N

N1 (N1) Parameter, 31 Non-Volatile Memory Storage (SUBCMD 22), 28

P

Parameter—Addressing Mode (AddrMode), 31 Parameter—Bus OFF Recover Time (Bus Off Rcvr Rate),

33

Parameter—CAN Driver Error Recover time (CAN Drv

Error Rcvr Time), 33 Parameter—Default DigOut Value (DigOut Default), 32 Parameter—Default Output Configuration (Out Default

Config), 32 Parameter—Default Output Value (Out Default), 32 Parameter—Default PVE Value (PVE Default), 32 Parameter—Digital Analogue Input Configuration 0

(Digital AnIn Default Config 0), 32 Parameter—Digital Analogue Input Configuration 1

(Digital AnIn Default Config 1), 33 Parameter—Digital Input Configuration (DigitalDefault

Config), 32 Parameter—Fixed ID Frame Format (Frame), 31 Parameter—Fixed Rx ID (Rx), 31 Parameter—Fixed Tx ID (Tx), 31 Parameter—Input Configuration 0 (In Default Config 0),

32

Parameter—Input Configuration 1 (In Default Config 1),

32

Parameter—KWP2000 Net Number (Net), 32 Parameter—Mask (Mask), 31 Parameter—N1 (N1), 31 Parameter—Power-Up Baud Rate (PwrUpBaud), 31 Parameter—Rheostat Input Configuration 1 (Rheo

Default Config 1), 33 Power-Up Baud Rate (PwrUpBaud) Parameter, 31 Protocol Version (SUBCMD 2), 21

R

Request Configuration (SUBCMD 255), 29 Request Protocol Version (SUBCMD 1), 21 Rheostat Input Configuration 1 (Rheo Default Config 1)

35

PLUS+1 CAN I/O Module Communications Protocol Technical Information

Index

Parameter, 33

S

Set AddrMode (SUBCMD 14), 25 Set Fixed Rx ID (SUBCMD 16), 26 Set Fixed Tx ID (SUBCMD 15), 25 Set KWP2000 Net (SUBCMD 17), 26 SUBCMD 0—Ack, 21 SUBCMD 10—Configure Multifunction Output

Frequency, 24 SUBCMD 11—Freeze N1, 24 SUBCMD 12—Configure Timing, 24 SUBCMD 13—Configure Output Default, 25 SUBCMD 14—Set AddrMode, 25 SUBCMD 15—Set Fixed Tx ID, 25 SUBCMD 16—Set Fixed Rx ID, 26 SUBCMD 17—Set KWP2000 Net, 26 SUBCMD 18—Configuration CRC, 26 SUBCMD 19—Temporary IO Configuration, 27 SUBCMD 1—Request Protocol Version, 21

SUBCMD 20—Configure Current Change Limit, 27 SUBCMD 21—Configure Recover Times, 28 SUBCMD 22—Non-Volatile Memory Storage, 28 SUBCMD 255—Request Configuration, 29 SUBCMD 2—Protocol Version, 21 SUBCMD 3—Configure DIG Input, 21 SUBCMD 4—Configure Analogue Input, 22 SUBCMD 5—Configure Multifunction Input Dig/Ana, 22 SUBCMD 6—Configure Multifunction Input Dig/Ana

Switch Point, 22

SUBCMD 7—Configure Multifunction Input

Dig/Ana/Freq, 23

SUBCMD 8—Configure Multifunction Input

Dig/Ana/Freq Switch Point, 23 SUBCMD 9—Configure Multifunction Output, 23 Supply (CMD 0), 8

T

Temporary IO Configuration (SUBCMD 19), 27

36

11005130 · Rev AA · December 2010

PLUS+1 CAN I/O Module Communications Protocol Technical Information

(This page is intentionally blank.)

p

Products we offer:

• Bent Axis Motors

• Closed Circuit Axial Piston Pumps

and Motors

• Displays

• Electrohydraulic Power Steering

• Electrohydraulics

• Hydraulic Power Steering

• Integrated Systems

• Joysticks and Control Handles

• Microcontrollers and Software

• Open Circuit Axial Piston Pumps

• Orbital Motors

• PLUS+1™ GUIDE

• Proportional Valves

• Sensors

• Steering

Sauer-Danfoss is a global manufacturer and supplier of highquality hydraulic and electronic components. We specialize in providing state-of-the-art technology and solutions that excel in the harsh operating conditions of the mobile off-highway market. Building on our extensive applications expertise, we work closely with our customers to ensure exceptional performance for a broad range of off-highway vehicles.

We help OEMs around the world speed up system development, reduce costs and bring vehicles to market faster. Sauer-Danfoss—Your Strongest Partner in Mobile Hydraulics.

Go to www.sauer-danfoss.com for further product information.

Wherever off-highway vehicles are at work, so is Sauer-Danfoss.

We offer expert worldwide support for our customers, ensuring the best possible solutions for outstanding performance. And with an extensive network of Global Service Partners, we also provide comprehensive global service for all of our components.

Transit Mixer Drives

•

Members of the Sauer-Danfoss Group:

Comatrol

www.comatrol.com

Schwarzmüller-Inverter www.schwarzmueller-inverter.com

Turolla www.turollaocg.com

Hydro-Gear www.hydro-gear.com

Sauer-Danfoss-Daikin www.sauer-danfoss-daikin.com

Please contact the Sauer-Danfoss re

Local address: Sauer-Danfoss Inc. 3500 Annapolis Lane North Minneapolis, MN 55447, USA Phone: +1 763 509-2000 Fax: +1 763 559-5769

Sauer-Danfoss (US) Company 2800 East 13th Street Ames, IA 50010, USA

ne: +1 515 239-6000

Fax: +1 515 239-6618

resentative nearest you.

Sauer-Danfoss ApS DK-6430 Nordborg, Denmark Phone: +45 7488 4444 Fax: +45 7488 4400

Sauer-Danfoss GmbH & Co. OHG Postfach 2460, D-24531 Neumünster Krokamp 35, D-24539 Neumünster, Germany Phone: +49 4321 871-0 Fax: +49 4321 871 122

Sauer-Danfoss-Daikin LTD Shin-Osaka TERASAKI 3rd Bldg. 6F 1-5-28 Nishimiyahara, Yodogawa-ku Osaka 532-0004, Japan Phone: +81 6 6395 6066 Fax: +81 6 6395 8585

11005130 z Rev AA z December 2010

www.sauer-danfoss.com

Danfoss PLUS 1 CAN I/O User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Message Timing Information

Supply (CMD 0)

Messages Based on the Sub-Identifier

Dig_In (CMD 16)

Ana/Temp/Rheo (CMD 32)

Dig and Ana/Temp/Rheo Opt I (CMD 33)

Dig and Ana/Temp/Rheo Opt II (CMD 34)

Dig/Ana (CMD 48)

Dig/Ana Opt I (CMD 49)

Dig/Ana Opt II (CMD 50)

Dig/Ana/Freq (CMD 64)

Dig/Ana/Freq Opt I (CMD 65)

Dig/Ana/Freq Opt II (CMD 66)

Dig/Ana/Freq Opt III (CMD 67)

Dig/Ana/Freq Opt IV (CMD 68)

Dig/Ana/Freq Opt V(CMD 69)

Dig/Ana/Freq Opt VI (CMD 70)

Dig/Ana/Freq Opt VII (CMD 71)

Dig/Ana/Freq Opt VIII (CMD 72)

Dig/Ana/Freq Opt IX(CMD 73)

Dig/Ana/Freq Opt X(CMD 74)

Digital Out Status (CMD 80)

Digital/PVG Out Status (CMD 81)

Digital/PVG Out Status Opt I (CMD 82)

Multifunction Out Status (CMD 96)

Multifunction Out Status Opt I (CMD 97)

Multifunction Out Status Opt II (CMD 98)

Multifunction Out Status Opt OPT III (CMD 99)

Multifunction Out Status Opt IV (CMD 100)

Digital Out (CMD 128)

Digital/PVG Out (CMD 129)

Digital/PVG Out Opt I (CMD 130)

Multifunction Out (CMD 144)

Multifunction Out Opt I (CMD 145)

Multifunction Out Opt II (CMD 146)

Multifunction Out Opt III (CMD 147)

Multifunction Out Opt IV (CMD 148)

Ack (SUBCMD 0)

Messages Based on the Sub-Command

Request Protocol Version (SUBCMD 1)

Protocol Version (SUBCMD 2)

Configure DIG Input (SUBCMD 3)

Configure Analogue Input (SUBCMD 4)

Configure Multifunction Input Dig/Ana (SUBCMD 5)

Configure Multifunction Input Dig/Ana Switch Point (SUBCMD 6)

Configure Multifunction Input Dig/Ana/Freq (SUBCMD 7)

Configure Multifunction Input Dig/Ana/Freq Switch Point (SUBCMD 8)

Configure Multifunction Output (SUBCMD 9)

Configure Multifunction Output Frequency (SUBCMD 10)

Freeze N1 (SUBCMD 11)

Configure Timing (SUBCMD 12)

Configure Output Default (SUBCMD 13)

Set AddrMode (SUBCMD 14)

Set Fixed Tx ID (SUBCMD 15)

Set Fixed Rx ID (SUBCMD 16)

Set KWP2000 Net (SUBCMD 17)

Configuration CRC (SUBCMD 18)

Temporary IO Configuration (SUBCMD 19)

Configure Current Change Limit (SUBCMD 20)

Configure Recover Times (SUBCMD 21)

Non-Volatile Memory Storage (SUBCMD 22)

Request Configuration (SUBCMD 255)

Parameters Stored in Non-Volatile Memory

Power-Up Baud Rate (PwrUpBaud) Parameter

Addressing Mode (AddrMode) Parameter

Fixed Tx ID (Tx) Parameter

Fixed Rx ID (Rx) Parameter

Fixed ID Frame Format (Frame) Parameter

N1 (N1) Parameter

Mask (Mask) Parameter

KWP2000 Net Number (Net) Parameter

Default Output Value (Out Default) Parameter

Default Output Configuration (Out Default Config) Parameter

Default DigOut Value (DigOut Default) Parameter

Default PVE Value (PVE Default) Parameter
