Danfoss Link™ Room Sensor
www.danfoss.com
Installation Guide Danfoss Link™ RS
Quick guide for getting started
Danfoss Li nk™ RS is a batter y
operate d room device. It
measures t he ambient room
temper ature and allows you to
control heating
^
^
Mount in
height of
80 -150 c m
^
^
^
^
Mount max . 5 to
6m from living
connect®
^
IP21
+-+
-
Mount at le ast 50 cm from
windows /doors th at will be
^
Danfoss Link™ RS
left open occasionally
Avoid direct
sunlight to
^
^
Turn the
device
around
08/2013 VIFZA602 Danfoss Heating Solutions
2
Remove the back
panel by gently
pressing your thumbs
on the panel and pull
downwards
Tamper-proof,
locked
^
21,5
^
Fix the back
panel to the
Adding Danfoss Link™ RS to
a system is m ade from the
Danfoss Li nk™ CC. For furthe r
information, see separate
instruction.
wall
Install the front
by gently letting
it slide on the
back panel again
^
^
Installation Guide Danfoss Link™ RS
Display information
Ambient temperature
Floor temperature
Short green ash Not included in network
Green fast ash Inclusion in progress
Red ash +
for 5 seconds
Inclusion failed
ON
Red ash +
for 5 seconds
ON + Red LED
ash every 2½ min.
ON + Red LED
ash every 30 seconds
Link test in progress
Link test failed
Low batter y level
Critical battery level
E5 Floor sensor short circuited
E6 Floor sensor lost
ON
Flash
Danfoss Heating Solutions VIFZA602 08/2013
Tamper-proof enabled by
Danfoss Link™ CC
Limited by Danfoss Link™ CC
3
Installation Guide Danfoss Link™ RS
Technical specications
Battery Alkaline 2 x AA, 1.5 V
Battery lifetime Up to 4-5 years
Backlight Green LED
Ambient temperature 0 to +40 ˚C
The sensor has a built-in
Battery monitoring
monitoring circuit,
which will detect low or
critical battery level
Transmission
frequency
Transmission range in
normal buildings
868.42 MHz
Up to 30 m
Transmission power Max. 1 mW
IP class 21
Dimensions (mm)
75 x 75 x 24
08/2013 VIFZA602 Danfoss Heating Solutions
4
Danfoss A/S
Heating Solutions
Ulvehavevej 61
7100 Ve jle
Denmark
Phone: +45 7488 850 0
Fax: +45 7488 8501
Email: heating.solutions@danfoss.com
www.heating.danfoss.com
VIFZA602
088N3046 | 08.2013 | Version 00
