Danfoss GBC 6s Fact sheet

Fact Sheet

Shut-o ball valve, type GBC 6s Code number 009L7020

Inlet connection type: SOLDER, ODF, Outlet connection type: SOLDER, ODF, Inlet size [in]: 1/4 IN, Outlet size [in]: 1/4 IN

Factsheet for code number 009L7020

Product speci€cation

Table 1: Product details for code number 009L7020

Name	Value
Gross weight	0.27 kg
Net weight	0.1 kg
EAN	5702428659246
Access port	NO
Approval	CE, EAC, LLC CDC EURO-TYSK
Body material	Brass
Connection material	Copper
Cv value [gal/min]	2.1 gal/min
Direction	Straightway
EN13463-3 ignit. source assess	Yes
Equipment	Cap w. wire seal (EN 378 comp)
Flow direction	Bi-€ow
Flow direction indicator	Embossed 2-way arrow
Inlet connection type	SOLDER, ODF
Inlet size [in]	1/4 IN
Kv value [m³/h]	1.83 m³/h
Max. media temp. Oil free [°C]	80 °C
Max. test pressure [bar]	81 bar
Max. test pressure [psig]	1175 psig
Max. Working Pressure [bar]	49 bar
Max. Working Pressure [psig]	710 psig
Medium temp. range note	Liquid line/ suction line use
Oil free refrigerants	R516A
Outlet connection type	SOLDER, ODF
Outlet size [in]	1/4 IN
Packing format	Multi pack
Panel mounting option	M4 × 0.7 (2 PC)
Product accessories	BM/GBC valve accessories
Product family name	GBC E
Product group	Shut-o„ and regulating valves
Product name	Shut-o„ ball valve
Quantity per packing format	25 pc
Refrigerants	R1234yf, R290, R32, R452B, R454B, R454C, R455A, R516A, R454A
Serviceable	BM/GBC valve spare parts
Temperature range [°C] [Max]	100 °C
Temperature range [°C] [Min]	-40 °C
Temperature range [°F] [Max]	210 °F
Temperature range [°F] [Min]	-40 °F
Type	GBC 6s E
UL approved refrigerants	R516A

Product identi€cation

Figure 1: Box label for product
