MAKING MODERN LIVING POSSIBLE

Programming Guide

VLT® Micro Drive

Contents

1 Safety

1.1.1 High Voltage Warning 3

1.1.2 Safety Instructions 3

1.1.3 Software Version and Approvals 3

1.1.4 General Warning 3

1.1.5 IT Mains 4

1.1.6 Avoid unintended Start 4

1.1.8 Before Commencing Repair Work 4

2 Introduction

2.1.1 FC Identification 5

2.1.2 Type Code 6

3 Programming

3.1 How to Programme

3.1.1 Programming with MCT 10 Set-up Software 8

3.1.2 Programming with the LCP 11 or LCP 12 8

3.2 Status Menu

3.3 Quick Menu

3.4 Main Menu

4 Parameter Descriptions

4.1 Parameter Group 0: Operation/Display

4.2 Parameter Group 1: Load/Motor

4.3 Parameter Group 2: Brakes

4.4 Parameter Group 3: Reference/Ramps

4.5 Parameter Group 4: Limits/Warnings

4.6 Parameter Group 5: Digital In/Out

4.7 Parameter Group 6: Analog In/Out

4.7.3 6-1* Analog Input 1 32

4.8 Parameter Group 7: Controllers

4.9 Parameter Group 8: Communication

4.9.6 8-8* Bus communication diagnostics 39

4.10 Parameter Group 13: Smart Logic

4.10.1 13-** Programming Features 40

4.11 Parameter Group 14: Special Functions

4.12 Parameter Group 15: Drive Information

4.12.2 15-4* Drive Identification 47

4.13 Parameter Group 16: Data Readouts

Contents

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 1

5 Parameter Lists

5.1.1 Conversion Index 54

5.1.2 Change during operation 54

5.1.3 2-Set-up 54

5.1.4 Type 54

5.1.5 0-** Operation/Display 55

5.1.6 1-** Load/Motor 56

5.1.7 2-** Brakes 57

5.1.8 3-** Reference/Ramps 57

5.1.9 4-** Limits/Warnings 58

5.1.10 5-** Digital In/Out 58

5.1.11 6-** Analog In/Out 59

5.1.12 7-** Controllers 59

5.1.13 8-** Comm. and Options 60

5.1.14 13-** Smart Logic 60

5.1.15 14-** Special Functions 61

5.1.16 15-** Drive Information 61

5.1.17 16-** Data Readouts 62

6 Troubleshooting

6.1.1 Alarm, Warning and Extended Status Word 65

Index

Contents

VLT® Micro Drive FC 51 Programming Guide

2 MG02C602 - VLT® is a registered Danfoss trademark

1 Safety

1.1.1 High Voltage Warning

WARNING

The voltage of the frequency converter is dangerous whenever it is connected to mains. Incorrect installation of the motor or frequency converter may cause damage to the equipment, serious injury or death. Consequently, it is essential to comply with the instructions in this manual as well as local and national rules and safety regulations.

1.1.2 Safety Instructions

CAUTION

Before using functions directly or indirectly influencing personal safety (e.g. Safe Stop, Fire Mode or other functions either forcing the motor to stop or attempting to keep it functioning) a thorough risk analysis and system test must be carried through. The system tests must include testing failure modes regarding the control signaling (analog and digital signals and serial communication.

NOTE

Before using Fire Mode, contact Danfoss

•

Make sure the frequency converter is properly connected to earth.

•

Do not remove mains connections, motor connections or other power connections while the frequency converter is connected to power.

•

Protect users against supply voltage.

•

Protect the motor against overloading according to national and local regulations.

•

The earth leakage current exceeds 3.5 mA.

•

The [Off] key is not a safety switch. It does not disconnect the frequency converter from mains.

1.1.3

Software Version and Approvals

Software Version

Programming Guide

VLT® Micro Drive

FC 51 Series

This Programming Guide can be used for all VLT

Micro Drive frequency converters with software

version 2.7X.

The software version number can be read in

15-43 Software Version.

Table 1.1

1.1.4

General Warning

WARNING

ELECTRICAL SHOCK HAZARD Touching the electrical parts may be fatal - even after the equipment has been disconnected from mains. Also make sure that other voltage inputs have been disconnected (linkage of DC intermediate circuit). Be aware that there may be high voltage on the DC link even when the LEDs are turned off. Before touching any potentially live parts of the frequency converter, wait at least 4 min for all sizes. Shorter time is allowed only if indicated on the nameplate for the specific unit.

Safety

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 3

1 1

CAUTION

Leakage Current The earth leakage current from the frequency converter exceeds 3.5 mA. According to IEC 61800-5-1 a reinforced Protective Earth connection must be ensured by means of a min. 10 mm² Cu or an additional PE wire - with the same cable cross section as the Mains wiring - must be terminated separately. Residual Current Device This product can cause a DC current in the protective conductor. Where a residual current device (RCD) is used for extra protection, only an RCD of Type B (time delayed) shall be used on the supply side of this product. See also Danfoss Application Note on RCD, MN90GX. Protective earthing of the frequency converter and the use of RCDs must always follow national and local regulations.

CAUTION

Motor overload protection is possible by setting 1-90 Motor Thermal Protection to the value ETR trip. For the North American market: ETR functions provide class 20 motor overload protection, in accordance with NEC.

WARNING

Installation in high altitudes: For altitudes above 2 km, please contact Danfoss regarding PELV.

1.1.5 IT Mains

CAUTION

IT Mains Installation on isolated mains source, i.e. IT mains. Max. supply voltage allowed when connected to mains: 440 V.

As an option, Danfoss offers line filters for improved harmonics performance.

1.1.6

Avoid unintended Start

While the frequency converter is connected to mains, the motor can be started/stopped using digital commands, bus commands, references or via the Local Control Panel.

•

Disconnect the frequency converter from mains to avoid unintended start of any motors.

•

To avoid unintended start, always press the [Off] key before changing parameters.

1.1.7

Disposal Instruction

Equipment containing electrical components must not be disposed of together with domestic waste. It must be separately collected with electrical and electronic waste according to local and currently valid legislation.

Table 1.2

1.1.8 Before Commencing Repair Work

1. Disconnect FC 51 from mains (and external DC supply, if present).

2. Wait for 4 minutes (M1, M2 and M3) and 15 min (M4 and M5) for discharge of the DC-link.

3. Disconnect DC bus terminals and brake terminals (if present)

4. Remove motor cable

Safety

VLT® Micro Drive FC 51 Programming Guide

4 MG02C602 - VLT® is a registered Danfoss trademark

2 Introduction

2.1.1 FC Identification

The nameplate sticker is located on the top of each frequency converter and shows the ratings, serial number, warnings catalog number, and other relevant data for each unit. See Table 2.1 for details, how to read the type code string.

Illustration 2.1 This Example Shows the Nameplate Sticker

Introduction

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 5

2 2

2.1.2 Type Code

Illustration 2.2

Description Pos. Possible choice Product group 1-3 Frequency converters Series and product type 4-6 Micro Drive Power size 7-10 0.18-7.5 kW Mains voltage 11-12 S2: Single phase 200-240 V AC

T 2: Three phase 200-240 V AC

T 4: Three phase 380-480 V AC Enclosure 13-15 IP20/Chassis RFI filter 16-17 HX: No RFI filter

H1: RFI filter class A1/B

H3:RFI filter A1/B (reduced cable length*) Brake 18 B: Brake chopper included (from 1.5 kW and up)

X: No brake chopper included Display 19 X: No Local Control Panel

N: Numerical Local Control Panel (LCP)

P: Numerical Local Control Panel (LCP)) with potentiometer Coating PCB 20 C: Coated PCB

X. No coated PCB Mains option 21 X: No mains option Adaptation A 22 X: No adaptation Adaptation B 23 X: No adaptation Software release 24-27 SXXX: Latest release - std. software

Table 2.1 Type Code Description

*See VLT® Micro Drive Design Guide, MG02K

Introduction

VLT® Micro Drive FC 51 Programming Guide

6 MG02C602 - VLT® is a registered Danfoss trademark

2.1.3 Warnings and Approvals

Symbols used in this Programming Guide.

Symbols The following symbols are used in this manual.

WARNING

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices.

CAUTION

Indicates a situation that may result in equipment or property-damage-only accidents.

2.1.4 Abbreviations and Standards

Abbreviations Terms SI-units I-P units

a Acceleration

m/s

ft/s

AWG American wire gauge

Auto Tune Automatic Motor Tuning

°C

Celsius

I Current A Amp

LIM

Current limit

IT mains Mains supply with star point in transformer floating to ground

Joule Energy J=N∙m ft-lb, Btu

°F

Fahrenheit

FC frequency converter

f Frequency Hz Hz kHz Kilohertz kHz kHz LCP Local Control Panel mA Milliampere

ms Millisecond

min Minute

MCT Motion Control Tool

M-TYPE Motor Type Dependent

Nm Newton Metres in-lbs I

M,N

Nominal motor current

M,N

Nominal motor frequency

M,N

Nominal motor power

M,N

Nominal motor voltage PELV Protective Extra Low Voltage Watt Power W Btu/hr, hp

Pascal Pressure Pa = N/m² psi, psf, ft of water

INV

Rated Inverter Output Current

RPM Revolutions Per Minute

s Second

SR Size Related

T Temperature C F t Time s s,hr

LIM

Torque limit

U Voltage V V

Table 2.2 Abbreviation and Standards Table

Introduction

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 7

2 2

3 Programming

3.1 How to Programme

3.1.1 Programming with MCT 10 Set-up Software

The frequency converter can be programmed from a PC via RS-485 com-port by installing the MCT 10 Set-up Software.

This software can either be ordered using code number 130B1000 or downloaded from the Danfoss Web site:

www.danfoss.com/BusinessAreas/DrivesSolutions/softwaredownload

Refer to the manual for Motion Control Tools MG10R.

3.1.2

Programming with the LCP 11 or LCP 12

The LCP is divided into four functional groups:

1. Numeric display.

2. Menu key.

3. Navigation keys.

4. Operation keys and indicator lights (LEDs).

Illustration 3.1 LCP 12 with Potentiometer

Illustration 3.2 LCP 11 without Potentiometer

The display Different information can be read from the display.

Set-up number shows the active set-up and the edit setup. If the same set-up acts as both active and edit set-up, only that set-up number is shown (factory setting). When active and edit set-up differ, both numbers are shown in the display (Set-up 12). The number flashing, indicates the edit set-up.

Illustration 3.3 Indicating Set-up

The small digits to the left are the selected parameter number.

Illustration 3.4 Indicating Selected Parameter Number

The large digits in the middle of the display show the value of the selected parameter.

Illustration 3.5 Indicating Value of Selected Parameter

The right side of the display shows the unit of the selected parameter. This can be either Hz, A, V, kW, HP, %, s or RPM.

Illustration 3.6 Indicating Unit of Selected Parameter

Programming

VLT® Micro Drive FC 51 Programming Guide

8 MG02C602 - VLT® is a registered Danfoss trademark

Motor direction is shown to the bottom left of the display

- indicated by a small arrow pointing either clockwise or

counterclockwise.

Illustration 3.7 Indicating Motor Direction

Press the [Menu] key to select one of the following menus

Status Menu The Status Menu is either in Readout Mode or Hand on Mode. In Readout Mode the value of the currently selected readout parameter is shown in the display.

In Hand on Mode the local LCP reference is displayed.

Quick Menu Displays Quick Menu parameters and their settings. Parameters in the Quick Menu can be accessed and edited from here. Most applications can be run by setting the parameters in the Quick Menus.

Main Menu Displays Main Menu parameters and their settings. All parameters can be accessed and edited here.

Indicator lights

•

Green LED: The frequency converter is on.

•

Yellow LED: Indicates a warning. See 6 Trouble- shooting.

•

Flashing red LED: Indicates an alarm. See 6 Troubleshooting.

Navigation Keys [Back]: For moving to the previous step or layer in the navigation structure. [▲] [▼]: For maneuvering between parameter groups, parameters and within parameters. [OK]: For selecting a parameter and for accepting changes to parameter settings.

Pressing [OK] for more than 1 s enters 'Adjust' mode. In 'Adjust' mode, it is possible to make fast adjustment by pressing [▲] [▼] combined with [OK].

Press [▲] [▼] to change value. Press [OK] to shift between digits quickly.

To exit 'Adjust' mode, press [OK] more than 1 s again with changes saving or press [Back] without changes saving.

Operation Keys A yellow light above the operation keys indicates the active key. [Hand On]: Starts the motor and enables control of the frequency converter via the LCP. [Off/Reset]: The motor stops except in alarm mode. In that case the motor will be reset. [Auto On]: The frequency converter is controlled either via control terminals or serial communication. [Potentiometer] (LCP 12): The potentiometer works in two ways depending on the mode in which the frequency converter is running. In Auto Mode the potentiometer acts as an extra programmable analog input. In Hand on Mode the potentiometer controls local reference.

3.2 Status Menu

After power up the Status Menu is active. Press [Menu] to toggle between Status, Quick Menu and Main Menu.

[▲] and [▼] toggles between the choices in each menu.

The display indicates the status mode with a small arrow above “Status”.

Illustration 3.8 Indicating Status Mode

Programming

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 9

3.3 Quick Menu

The Quick Menu gives easy access to the most frequently used parameters.

1. To enter the Quick Menu, press [Menu] key until

indicator in display is placed above Quick Menu.

Press [▲] [▼] to select either QM1 or QM2, then press [OK].

Press [▲] [▼] to browse through the parameters in the Quick Menu.

4. Press [OK] to select a parameter.

Press [▲] [▼] to change the value of a parameter setting.

6. Press [OK] to accept the change.

To exit, press either [Back] twice to enter Status, or press [Menu] once to enter Main Menu.

Illustration 3.9 Indicating Quick Menu Mode

3.4 Main Menu

The Main Menu gives access to all parameters.

1. To enter the Main Menu, press [Menu] key until

indicator in display is placed above Main Menu.

Press [▲] [▼] to browse through the parameter groups.

3. Press [OK] to select a parameter group.

Press [▲] [▼] to browse through the parameters in the specific group.

5. Press [OK] to select the parameter.

Press [▲] [▼] to set/change the parameter value.

7. Press [OK] to accept the value.

To exit, press either [Back] twice to enter Quick Menu, or press [Menu] once to enter Status.

Illustration 3.10 Indicating Main Menu Mode

Programming

VLT® Micro Drive FC 51 Programming Guide

10 MG02C602 - VLT® is a registered Danfoss trademark

4 Parameter Descriptions

4.1 Parameter Group 0: Operation/Display

0-03 Regional Settings

Option: Function:

In order to meet the needs for different default settings in different parts of the world, 0-03 Regional Settings, is implemented in the frequency converter. The selected setting influences the default setting of the motor nominal frequency.

[0 ] * Interna-

tional

Sets default of 1-23 Motor Frequency, to 50 Hz, shows 1-20 Motor Power in kW.

[1] US

Sets default of 1-23 Motor Frequency, to 60 Hz, shows 1-20 Motor Power in HP.

NOTE

This parameter cannot be changed while motor runs.

0-04 Operating State at Power-up (Hand Mode)

Option: Function:

This parameter controls whether or not the frequency converter start running the motor when powering up after a power down in Hand mode.

NOTE

If LCP with potentiometer is mounted, reference is set according to actual potentiometer value.

[0] Resume Frequency converter starts in same Hand or

Off State as when powered off. Local reference is stored and used after power-up.

[1] * Forced

Stop, Ref=Old

Frequency converter powers up in Off State meaning that motor is stopped after power up. Local reference is stored and used after power-up.

[2] Forced

Stop, Ref=0

Frequency converter powers up in Off State meaning that motor is stopped after power up. Local reference is set to 0. Thus motor will not start running before local reference has been increased.

4.1.1 0-1* Set-up Handling

User-defined parameters and miscellaneous external inputs (eg. bus, LCP, analog/digital inputs, feedback, etc.) controls the functionality of the frequency converter.

A complete set of all parameters controlling the frequency converter is called a set-up. The frequency converter contains 2 set-ups, Set-up 1 and Set-up 2. Furthermore, a fixed set of factory settings can be copied into one or more set-ups.

Some of the advantages of having more than one set-up in the frequency converter are

•

Run motor in one set-up (Active Set-up) while updating parameters in another set-up (Edit Setup)

•

Connect various motors (one at a time) to frequency converter. Motor data for various motors can be placed in different set-ups.

•

Rapidly change settings of frequency converter and/or motor while motor is running (eg. ramp time or preset references) via bus or digital inputs.

The Active Set-up can be set as Multi Set-up where the active set-up is selected via input on a digital input terminal and/or via the bus control word.

NOTE

Factory Set-up cannot be used as Active Set-up.

0-10 Active Set-up

Option: Function:

Active Set-up controls the motor. Shifts between set-ups can only happen when

•

the motor is coasted

•

the set-ups between which the shift happens are linked to each other (see 0-12 Linked Set-ups).

If changing between set-ups that are not linked, the change will not happen before motor is coasted.

NOTE

The motor is only considered stopped when it is coasted.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 11

4 4

0-10 Active Set-up

Option: Function:

[1 ] * Set-up 1

Set-up 1 is active.

[2] Set-up 2

Set-up 2 is active.

[9] Multi

Set-up

Select the active set-up via digital input and/or bus, see 5-1* Digital Inputs choice [23].

0-11 Edit Set-up

Option: Function:

The Edit Set-up is for updating parameters in the frequency converter from either LCP or bus. It can be identical or different from the Active Set-up. All set-ups can be edited during operation, independently of the active set-up.

[1 ] * Set-up 1

Update parameters in Set-up 1.

[2] Set-up 2

Update parameters in Set-up 2.

[9] Active Set-upUpdate parameters in set-up selected as

Active Set-up (see 0-10 Active Set-up).

0-12 Link Set-ups

Option: Function:

The link ensures synchronizing of the “not changeable during operation” parameter values enabling shift from one set-up to another during operation. If the set-ups are not linked, a change between them is not possible while the motor is running. Thus the set-up change does not occur until the motor is coasted.

[0] Not

linked

Leaves parameters unchanged in both set-ups and cannot be changed while motor runs.

[1 ] * Linked Copy parameters “not changeable during

operation” parameter values into presently selected Edit Set-up.

NOTE

This parameter cannot be changed while motor runs.

0-31 Custom Readout Min Scale

Range: Function:

0.00 * [0.00–

9999.00 ]

It is possible to create a customized readout related to the output frequency of the unit. The value entered in 0-31 Custom Readout Min Scale will be shown at 0 Hz. The readout can be shown in the LCP display when in Status Mode or it can be read in 16-09 Custom Readout

0-32 Custom Readout Max Scale

Range: Function:

100.0* [0.00–

9999.00]

It is possible to create a customized readout related to the output frequency of the unit. The value entered in 0-32 Custom Readout Max Scale will be shown at the frequency programmed in 4-14 Motor Speed High Limit. The readout can be shown in the LCP display when in Status Mode or it can be read in 16-09 Custom Readout

4.1.2 0-4* LCP

The frequency converter can operate in the following three modes: Hand, Off and Auto. Hand: The frequency converter is locally operated and does not allow any remote control. By activating Hand a start signal is given. OFF: The frequency converter stops with a normal stop ramp. When Off is chosen the frequency converter can only be started by pressing either Hand or Auto on the LCP. Auto: In Auto-mode the frequency converter can be remote controlled (bus/digital).

0-40 [Hand On] Key on LCP

Option: Function:

[0] Disabled [Hand On] key has no function. [1 ] * Enabled [Hand On] key is functional.

0-41 [Off/Reset] Key on LCP

Option: Function:

[0] Disable Off/Reset [Off/Reset] key has no function. [1 ] * Enable Off/Reset Stop signal and reset of any faults. [2] Enable Reset Only Reset only. Stop (Off) function is

disabled.

0-42 [Auto On] Key on LCP

Option: Function:

[0] Disabled [Auto On] key has no function. [1 ] * Enabled [Auto On] key is functional.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

12 MG02C602 - VLT® is a registered Danfoss trademark

4.1.3 0-5* Copy/Save

0-50 LCP Copy

Option: Function:

The detachable LCP of the frequency converter can be used for storing setups, and thus for transferring data when moving parameter settings from one frequency converter to another.

NOTE

LCP Copy can only be activated from the LCP and ONLY when the motor is coasted.

[1] All to LCP Copy all setups from the frequency

converter into the LCP.

[2] All from LCP Copy all setups from LCP to frequency

converter.

[3] Size independent

from LCP

Copy non motor size dependent data from LCP to frequency converter.

0-51 Set-up Copy

Option: Function:

Use this function to copy a set-up content into the Edit Set-up. In order to be able to make a set-up copy ensure that

•

the motor is coasted

•

0-10 Active Set-up, Active Set-up, is set to either [1] Set-up 1 or [2] Set-

up 2

NOTE

The keyboard/parameter database are blocked while Set-up Copy is running.

[0 ] * No Copy Copy function is inactive [1] Copy from

Set-up 1

Copy from Set-up 1 to edit set-up chosen in 0-11 Edit Set-up.

[2] Copy from

Set-up 2

Copy from Set-up 2 to edit set-up chosen in 0-11 Edit Set-up.

[9] Copy from

Factory Setup

Copy from Factory Settings to edit set-up chosen in 0-11 Edit set-up.

4.1.4 0-6* Password

0-60 (Main) Menu Password

Range: Function:

Use password for protection against unintended change of sensitive parameters, eg. motor parameters.

0 * [0-999] Enter the password for access to Main Menu via

the [Main Menu] key. Select the number that should allow for changing other parameter values. 0 means there is no password.

NOTE

A password has affect on the LCP - not on the bus communication.

NOTE

Pressing [Menu], [OK] and [▼] will unlock the password. This will automatically enter the parameter editing screen in Quick Menu or Main Menu.

0-61 Access to Main/Quick Menu w/o Password

Option: Function:

[0] * Full access

Select [0] Full Access to disable the password in 0-60 (Main) Menu Password.

[1] LCP: Read Only

Select [1] Read Only to block unauthorized editing of Main/Quick menu parameter.

[2] LCP: No Access

Select [2] No Access to block unauthorized editing and viewing of Main/Quick menu parameter.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 13

4 4

4.2 Parameter Group 1: Load/Motor

1-00 Configuration Mode

Option: Function:

Use this parameter for selecting the application control principle to be used when a Remote Reference is active.

NOTE

Changing this parameter will reset 3-00 Reference Range, 3-02 Minimum Reference and 3-03 Maximum Reference to their default values.

NOTE

This parameter cannot be adjusted while motor runs.

[0 ] * Speed

Open Loop

For normal speed control (References).

[3] Process

Closed Loop

Enables process closed loop control. See parameter group 7-3* Process PI Control for further information on PI-controller.

1-01 Motor Control Principle

Option: Function:

[0] U/f Is used for parallel connected motors and/or special

motor applications. The U/f settings are set in 1-55 U/f Characteristic -U and 1-56 U/f Characteristic -F.

NOTE

When running U/f control slip- and load compensations are not included.

[1] * VVC+ Normal running mode, including slip- and load

compensations.

1-03 Torque Characteristics

Option: Function:

With more torque characteristics it is possible to run low energy consuming, as well as high torque applications.

[0 ] * Constant

Torque

Motor shaft output provides constant torque under variable speed control.

[2] Automatic

Energy Optimisation

This function automatically optimizes energy consumption in centrifugal pump and fan applications. See 14-41 AEO Minimum Magnetisation.

1-05 Hand Mode Configuration

Option: Function:

This parameter is only relevant when 1-00

Configuration Mode is set to [3] Process Closed Loop. The parameter is used for determining

the reference or setpoint handling when changing from Auto Mode to Hand Mode on the LCP.

[0] Speed

Open Loop

In Hand Mode the drive always runs in Open Loop configuration regardless of setting in 1-00 Configuration Mode. Local potentiometer (if present) or Arrow up/down determines output

1-05 Hand Mode Configuration

Option: Function:

frequency limited by Motor Speed High/Low Limit (4-14 Motor Speed High Limit and 4-12 Motor Speed Low Limit).

[2] * As config-

uration in

1-00 Configuration Mode.

If 1-00 Configuration Mode is set to [1] Open Loop function is as described above. If 1-00 Configuration Mode is set to [3] Process Closed Loop changing from Auto mode to Hand

mode results in a setpoint change via local potentiometer or Arrow up/down. The change is limited by Reference Max/Min (3-02 Minimum Reference and 3-03 Maximum Reference).

4.2.1 1-2* Motor Data

Enter the correct motor nameplate data (power, voltage, frequency, current and speed). Run AMT, see 1-29 Automatic Motor Tuning (AMT). Factory settings for advanced motor data, parameter group 1-3* Adv. Motor Data, are automatically calculated.

NOTE

Parameters in parameter group 1-2* Motor Data cannot be adjusted while motor runs.

1-20 Motor Power [kW]/[HP] (P

m.n

)

Option: Function:

Enter motor power from nameplate data. Two sizes down, one size up from

nominal VLT rating. [1] 0.09 kW/0.12 HP [2] 0.12 kW/0.16 HP [3] 0.18kW/0.25 HP [4] 0.25 kW/0.33 HP [5] 0.37kW/0.50 HP [6] 0.55 kW/0.75 HP [7] 0.75 kW/1.00 HP [8] 1.10 kW/1.50 HP [9] 1.50 kW/2.00 HP [10] 2.20 kW/3.00 HP [11] 3.00 kW/4.00 HP [12] 3.70 kW/5.00 HP [13] 4.00 kW/5.40 HP [14] 5.50 kW/7.50 HP [15] 7.50 kW/10.0 HP [16] 11.00 kW/15.00 HP [17] 15.00 kW/20.00 HP [18] 18.50 kW/25.00 HP [19] 22.00 kW/29.50 HP [20] 30.00 kW/40.00 HP

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

14 MG02C602 - VLT® is a registered Danfoss trademark

NOTE

Changing this parameter affects parameters 1-22 Motor

Voltage to 1-25 Motor Frequency, 1-30 Stator Resistance, 1-33 Stator Leakage Reactance and 1-35 Main Reactance.

1-22 Motor Voltage (U_

m.n

)

Range: Function:

230/400 V [50-999 V] Enter motor voltage from nameplate

data.

1-23 Motor Frequency (f_

m.n

)

Range: Function:

50 Hz* [20-400 Hz] Enter motor frequency from nameplate

data.

1-24 Motor Current (I_

m.n

)

Range: Function:

M-type dependent* [0.01-100.00 A] Enter motor current from

nameplate data.

1-25 Motor Nominal Speed (n_

m.n

)

Range: Function:

M-type Dependent* [100-9999 RPM] Enter motor nominal

speed from nameplate data.

1-29 Automatic Motor Tuning (AMT)

Option: Function:

Use AMT to optimize motor performance.

NOTE

This parameter cannot be changed while motor runs.

1. Stop the frequency converter - make sure motor is at standstill

Choose [2] Enable AMT

3. Apply start signal

- Via LCP: Press [Hand On]

- Or in Remote On mode: Apply start signal on terminal 18

[0] * Off AMT function is disabled. [2] Enable

AMT

AMT function starts running.

NOTE

To gain optimum tuning of the frequency converter, run AMT on a cold motor.

4.2.2 1-3* Adv. Motor Data

Adjust advanced motor data using one of these methods:

1. Run AMT on cold motor. The frequency converter measures value from motor.

2. Enter X1 value manually. Obtain value from motor supplier.

3. Use Rs, X1, and X2 default setting. The frequency converter establishes setting based on motor nameplate data.

NOTE

These parameters cannot be changed while the motor runs.

130BA375.11

P 1-30

P1-35

Illustration 4.1

1-30 Stator Resistance (Rs)

Range: Function:

Depending on motor data* [Ohm] Set stator resistance value.

1-33 Stator Leakage Reactance (X1)

Range: Function:

Depending on motor data*

[Ohm] Set stator leakage reactance

of motor.

1-35 Main Reactance (X2)

Range: Function:

Depending on motor data* [Ohm] Set motor main reactance.

4.2.3 1-5* Load Independent Setting

This parameter group is for setting the load independent motor settings.

1-50 Motor Magnetization at Zero Speed

Range: Function:

This parameter enables different thermal load on motor when running at low speed.

100 %* [ 0-300%] Enter a percentage of rated magnetizing

current. If setting is too low, motor shaft torque may be reduced.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 15

4 4

1-52 Min. Speed Normal Magnetizing [Hz]

Range: Function:

Use this parameter along with 1-50 Motor Magnetizing at Zero Speed.

0.0 Hz* [0.0-10.0 Hz] Set frequency required for normal magnetizing current. If frequency is set lower than motor slip frequency, 1-50 Motor Magnetizing at Zero Speed is inactive.

Magn. current

130BD016.10

Par.1-50

Par.1-51

100%

Par.1-52 RPM

Illustration 4.2

1-55 U/f Characteristic - U

Range: Function:

This parameter is an array parameter [0-5] and is only functional when 1-01 Motor Control Principle is set to [0] U/f.

0.0 V* [0.0-999.9 V] Enter voltage at each frequency point to

manually form a U/f characteristic matching motor. Frequency points are defined in 1-56 U/f characteristics - F.

1-56 U/f Characteristic - F

Range: Function:

This parameter is an array parameter [0-5] and is only functional when 1-01 Motor Control Principle is set to [0] U/f.

0.0

Hz*

[0.0-1000.0 Hz]

Enter frequency points to manually form a U/f characteristic matching motor. Voltage at each point is defined in 1-55 U/f Characteristic - U. Make a U/f characteristic based on 6 definable voltages and frequencies, see Illustration 4.3. Simplify U/f characteristics by merging 2 or more points (voltages and frequencies), respectively, are set equal.

Motor Voltage Par 1-55 [x]

Output Frequency Par 1-56 [x]

1-55[5]

1-55[4]

1-55[3]

1-55[2]

1-55[1] 1-55[0]

1-56 [0]

1-56 [1]

1-56 [2]

1-56 [3]

1-56 [4]

1-56 [5]

130BD017.10

Illustration 4.3 U/f Characteristics

NOTE

For 1-56 U/f characteristics - F the following applies [0] ≦ [1] ≦ [2] ≦ [3] ≦ [4] ≦ [5]

4.2.4 1-6* Load Dependent Setting

Parameters for adjusting the load-dependent motor settings.

1-60 Low Speed Load Compensation

Range: Function:

Use this parameter to gain optimum U/f characteristic when running at low speed.

100 %* [0-199 %] Enter percentage in relation to load when

motor runs at low speed. Change-over point is automatically calculated based on motor size.

130BD018.10

60%

100%

Changeover

out

Par.1-60 Par.1-61

Illustration 4.4

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

16 MG02C602 - VLT® is a registered Danfoss trademark

1-61 High Speed Load Compensation

Range: Function:

Use this parameter to obtain optimum load compensation when running at high speed.

100 %* [0-199 %] Enter percentage to compensate in relation

to load when motor runs at high speed. Change-over point is automatically calculated based on motor size.

1-62 Slip Compensation

Range: Function:

100 %* [-400-399%]Compensation for load dependent motor

slip. Slip compensation is calculated automatically based on rated motor speed, n

M,N

NOTE

This function is only active when

1-00 Configuration Mode, is set to [0] Speed Open Loop and when 1-01 Motor Control Principle, is set to [1] VVC

plus

1-63 Slip Compensation Time

Range: Function:

0.10 s [0.05-5.00 s] Enter slip compensation reaction speed. A

high value results in slow reaction whereas a low value results in quick reaction. If low-frequency resonance problems arise, use longer time setting.

4.2.5 1-7* Start Adjustments

Considering the need for various start functions in different applications, it is possible to select a number of functions in this parameter group.

1-71 Start Delay

Range: Function:

The start delay defines the time to pass from a start command is given until the motor starts accelerating. Setting start delay to 0.0 s disables 1-72 Start Function, when start command is given.

0.0 s* [0.0-10.0s]Enter the time delay required before

commencing acceleration.

1-72 Start Function is active during Start delay time.

1-72 Start Function

Option: Function:

[0] DC Hold/Delay

Time

Motor is energised with DC holding current (2-00 DC Hold Current) during start delay time.

[1] DC Brake/Delay

Time

Motor is energised with DC braking current (2-01 DC Brake Current) during start delay time.

[2] * Coast/Delay

Time

Inverter is coasted during start delay time (inverter off).

1-73 Flying Start

Option: Function:

The Flying Start parameter is used to catch a spinning motor after eg. mains drop-out.

NOTE

This function is not suitable for hoisting applications.

[0] * Disabled Flying start is not required. [1] Enabled Frequency converter enabled to catch spinning

motor.

NOTE

When flying start is enabled 1-71 Start Delay, and 1-72 Start Function, have no function.

4.2.6 1-8* Stop Adjustments

To meet the need for various stop functions in different application these parameters offer some special stop features for the motor.

1-80 Function at Stop

Option: Function:

The selected function at stop is active in following situations:

•

Stop command is given and output speed is ramped down to Min. Speed for Function at Stop.

•

Start command is removed (standby), and output speed is ramped down to Min. Speed for Function at Stop.

•

DC-brake command is given, and DCbrake time has passed

•

While running and calculated output speed is below Min. Speed for Function at Stop.

[0] * Coast The inverter is coasted. [1] DC

hold

The motor is energised with a DC current. See 2-00 DC Hold Current for more information.

1-82 Min. Speed For Function at Stop [Hz]

Range: Function:

0.0 Hz* [0.0-20.0 Hz]

Set the speed at which to activate 1-80 Function at Stop.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 17

4 4

4.2.7 1-9* Motor Temperature

With an estimated motor temperature monitor the frequency converter is able to estimate motor temperature without having a thermistor mounted. It is thus possible to receive a warning or an alarm, if motor temperature exceeds upper operational limit.

1-90 Motor Thermal Protection

Option: Function:

Using ETR (Electronic Terminal Relay) the motor temperature is calculated based on frequency, speed and time. Danfoss recommends using The ETR function, if a thermistor is not present.

NOTE

ETRElectronic Overload calculation is based on motor data from parameter group 1-2* Motor Data.

[0] * No Protection Disables temperature monitoring. [1] Thermistor

Warning

A thermistor connected to either digital or analog input gives a warning if upper limit of motor temperature range is exceeded, (see 1-93 Thermistor Resource).

[2] Thermistor

Trip

A thermistor connected to either digital or analog input gives an alarm and makes the frequency converter trip if upper limit of motor temperature range is exceeded, (see 1-93 Thermistor Resource.

[3] ETR Warning If calculated upper limit of motor

temperature range is exceeded, a warning occurs.

[4] ETR Trip If 90% of calculated upper limit of motor

temperature range is exceeded, an alarm occurs and the frequency converter trips.

NOTE

When the ETR function has been selected the drive will store the recorded temperature at power down and this temperature will resume at power up regardless of the elapsed time. Changing 1-90 Motor Thermal Protection back to [0] No Protection will reset the recorded temperature.

1-93 Thermistor Resource

Option: Function:

Select the thermistor input terminal. [0] * None No thermistor is connected. [1] Analog

Input 53

Connect thermistor to analog input terminal

53.

NOTE

Analog input 53 cannot be selected for

other purposes when selected as

thermistor resource.

[6] Digital

input 29

Connect thermistor to digital input terminal 29.

While this input functions as thermistor input,

it will not respond to the function chosen in

5-13 Digital Input 29. The value of 5-13 Digital

Input 29 remains however unchanged in

parameter database while function is inactive.

Input Digital/

Analog

Supply

Voltage

Threshold Cut-

out

Values

Digital 10 V

<800 Ω ⇒ 2.9 kohm

Analog 10 V

<800 Ω ⇒ 2.9 kohm

Table 4.1

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

18 MG02C602 - VLT® is a registered Danfoss trademark

4.3 Parameter Group 2: Brakes

4.3.1 2-** Brakes

4.3.2 2-0* DC-Brake

The purpose of DC-brake function is to brake a rotating motor by applying DC-current to the motor.

2-00 DC Hold Current

Range: Function:

This parameter either holds the motor (holding torque) or pre-heats the motor. The parameter is active if DC Hold has been selected in either 1-72 Start Function or 1-80 Function at Stop.

50%* [0-100%] Enter a value for holding current as a

percentage of the rated motor current set in 1-24 Motor Current. 100% DC holding current corresponds to I

M,N

NOTE

Avoid 100% current too long as it may overheat the motor.

2-01 DC Brake Current

Range: Function:

50%* [0-150%] Set DC-current needed to brake rotating

motor. Activate DC-brake in one of the four following ways:

DC-brake command, see 5-1* Digital Inputs choice [5]

DC Cut-in function, see 2-04 DC-Brake

Cut-in Speed

3. DC-brake selected as start function,

see 1-72 Start Function

DC-brake in connection with Flying Start, 1-73 Flying Start.

2-02 DC-Braking Time

Range: Function:

DC-braking time defines the period during which DC-brake current is applied to the motor.

10.0 s* [0.0-60 s]

Set the time DC-braking current, set in 2-01 DC Brake Current, must be applied.

NOTE

If DC-brake is activated as start function, DC-brake time is defined by start delay time.

2-04 DC-Brake Cut-in Speed

Range: Function:

0.0 Hz* [0.0-400.0 Hz] Set DC-brake cut-in speed to activate

DC braking current, set in 2-01 DC Brake Current, when ramping down. When set to 0 the function is off.

4.3.3 2-1* Brake Energy Function

Use the parameters in this group for selecting dynamic braking parameters.

2-10 Brake Function

Option: Function:

Resistor Brake: The resistor brake limits voltage in the intermediate circuit when the motor acts as generator. Without brake resistor, the frequency converter eventually trips. The resistor brake consumes surplus energy resulting from motor braking. A frequency converter with brake, stops a motor faster than without a brake, which is used in many applications. Requires connection of external brake resistor. An alternative to the resistor brake is the AC brake.

NOTE

Resistor brake is only functional in frequency converters with integrated dynamic brake. An external resistor must be connected.

AC Brake: The AC brake consumes surplus energy by creating power loss in the motor. It is important to keep in mind that an increase in power loss causes motor temperature to rise.

[0]

* Off No brake function.

[1] Resistor

Brake

Resistor brake is active.

[2] AC Brake AC brake is active.

2-11 Brake Resistor (Ohm)

Range: Function:

5 Ω* [5-5000 Ω] Set brake resistor value.

2-16 AC Brake, Max Current

Range: Function:

100.0%* [0.0-150.0%] Enter max. permissible current for AC-

braking to avoid overheating of motor. 100% equals motor current set in 1-24 Motor Current.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 19

4 4

2-17 Over-Voltage Control

Option: Function:

Use Over-voltage Control (OVC) to reduce the risk of the frequency converter tripping due to an over voltage on the DC link caused by generative power from the load. An over-voltage occurs eg. if the ramp down time is set too short compared to the actual

load inertia. [0] * Disabled The OVC is not active/required. [1] Enabled, not

at stop

OVC is running unless a stop signal is active.

[2] Enabled OVC is running, also when a stop signal is

active.

NOTE

If Resistor Brake has been chosen in 2-10 Brake Function the OVC is not active even though enabled in this parameter.

4.3.4 2-2* Mechanical Brake

For hoisting applications an electro-magnetic brake is required. The brake is controlled by a relay, which releases the brake when activated.

The brake activates if the frequency converter trips or a coast command is given. Furthermore, it activates when motor speed is ramped down below the speed set in 2-22 Active Brake Speed.

2-20 Release Brake Current

Range: Function:

0.00 A* [0.00-100 A] Select motor current at which mechanical

brake releases.

CAUTION

If start delay time has passed, and motor current is below Release brake current, frequency converter trips.

2-22 Activating Mechanical Brake

Range: Function:

If the motor is stopped using ramp, the mechanical brake is activated when motor speed is less than Active Brake Speed. Motor is ramped down to stop in the following situations:

•

A start command is removed (stand by)

•

A stop command is activated

•

Quick-stop is activated (Q-stop ramp is used)

0 Hz* [0-400

Hz]

Select motor speed at which mechanical brake activates when ramping down. Mechanical brake automatically activates if frequency converter trips or reports an alarm.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

20 MG02C602 - VLT® is a registered Danfoss trademark

4.4 Parameter Group 3: Reference/Ramps

4.4.1 3-** Reference/Ramps

Parameters for reference handling, definition of limitations, and configuration of the frequency converter's reaction to changes

4.4.2 3-0* Reference Limits

Parameters for setting the reference unit, limits and ranges.

3-00 Reference Range

Option: Function:

Select the range of reference and feedback signals.

[0] * Min to

Max

Reference setpoint ranges can have positive values only. Select this if running in Process Closed Loop.

[1] -Max to

+Max

Ranges can have both positive and negative values. If potentiometer is used to adjust motor running in both direction, set reference range to –Max Reference to Max Reference by par.=[1] Choose hand on mode by LCP. Adjust the potentiometer to minimum, the motor can run in anti-clockwise with max speed. Then adjust the potentiometer to maximum, the motor will ramp down to 0 and run clockwise with max speed.

3-02 Minimum Reference

Range: Function:

0.00* [-4999-4999] Enter value for minimum reference.

The sum of all internal and external references are clamped (limited) to the minimum reference value, 3-02 Minimum Reference.

3-03 Maximum Reference

Range: Function:

Maximum Reference is adjustable in the range Minimum Reference -4999.

50.00* [-4999-4999] Enter value for Maximum Reference.

The sum of all internal and external references are clamped (limited) to the maximum reference value, 3-03 Maximum Reference.

4.4.3 3-1* References

Parameters for setting up the reference sources. Select the preset references for the corresponding digital inputs in parameter group, 5-1* Digital Inputs.

3-10 Preset Reference

Option: Function:

Each parameter set-up contains 8 preset references which are selectable via 3 digital inputs or bus.

[18] Bit2

[17] Bit1

[16] Bit0

[16]

Bit0 0 0 0 0 0 0 1 1 0 1 0 2 0 1 1 3 1 0 0 4 1 0 1 5 1 1 0 6 1 1 1 7

Table 4.2 Parameter Group 5-1* Digital Inputs Option [16], [17] and [18]

[0.00]*-100.00-100.00% Enter the different preset references

using array programming. Normally, 100% = value set in 3-03 Maximum Reference. However, there are exceptions if 3-00 Reference Range is set to [0] Min - Max. Example 1:

3-02 Minimum Reference is set to 20 and 3-03 Maximum Reference is set to 50. In

this case 0%=0 and 100%=50. Example 2: 3-02 Minimum Reference is set to -70 and 3-03 Maximum Reference is set to

50. In this case 0%=0 and 100%=70.

3-11 Jog Speed [Hz]

Range: Function:

Jog speed is a fixed output speed and overrules the selected reference speed, see parameter group 5-1* Digital Inputs option [14]. If the motor is stopped while in jog mode, the jog signal acts as a start signal. Removing the jog signal makes the motor run according to the selected configuration.

5.0Hz [0.0-400.0 Hz]

Select speed to function as jog speed.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 21

4 4

3-12 Catch Up/Slow Down Value

Range: Function:

0% * [0-100%]

The Catch-up/Slowdown function is activated by an input command (see 5-1* Digital Inputs, choice [28]/[29]). If the command is active, the Catch-up/Slowdown value (in %) is added to the reference function as follows:

Reference

Catchup Slowdown

100

Reference

−

Reference

Catchup Slowdown

100

When the input command is inactivated, the reference returns to its original value ie. Reference=Reference + 0.

3-14 Preset Relative Reference

Range: Function:

0.00% [-100.00-100.00%] Define fixed value in % to be added

to variable value defined in 3-18 Relative Scaling Reference Source. The sum of fixed and variable values (labeled Y in illustration below) is multiplied with actual reference (labeled X in illustration). This product is added to actual reference

+ X ×

100

Relative Z=X+X*Y/100

Resulting actual reference

130BA059.12

Illustration 4.5

3-15 Reference 1 Source

Option: Function:

3-15 Reference 1 Source, 3-16 Reference 2 Source and 3-17 Reference 3 Source define

up to three different reference signals. The sum of these reference signals defines

the actual reference. [0] No Function No reference signal is defined. [1] * Analog Input53Use signals from analog input 53 as

reference, see parameter group 6-1*

Analog Input 1. [2] Analog Input60Use signals from analog input 60 as

reference, see parameter group 6-2*

Analog Input 2. [8] Pulse input 33 Use signals from pulse input as reference,

see parameter group 5-5* Pulse Input. [11] Local Bus

Reference

Use signals from local bus as reference,

see parameter group 8-9* Bus Feedback. [21] LCP Potenti-

ometer

Use signals from LCP potentiometer as

reference, parameter group 6-8* LCP

Potentiometer.

3-16 Reference 2 Source

Option: Function:

See 3-15 Reference 1 Source for

description. [0] No Function No reference signal is defined. [1] Analog Input 53 Use signals from analog input 53 as

reference. [2] * Analog Input 60 Use signals from analog input 60 as

reference. [8] Pulse input 33 Use signals from pulse input as

reference, see parameter group 5-5*

Pulse Input. [11] Local Bus

Reference

Use signals from local bus as

reference. [21] LCP Potentiometer Use signals from LCP potentiometer as

reference.

3-17 Reference 3 Source

Option: Function:

See 3-15 Reference 2 Source for

description. [0] No Function No reference signal is defined. [1] Analog Input 53 Use signals from analog input 53 as

reference. [2] Analog Input 60 Use signals from analog input 60 as

reference. [8] Pulse input 33 Use signals from pulse input as

reference, see parameter group 5-5*

Pulse Input. [11] * Local Bus

Reference

Use signals from local bus as

reference. [21] LCP Potentiometer Use signals from LCP potentiometer

as reference.

3-18 Relative Scaling Reference Source

Option: Function:

Select the source for a variable value to be added to the fixed value defined in 3-14 Preset Relative Reference.

[0] * No Function The function is disabled [1] Analog Input 53 Select analog input 53 as relative

scaling reference source.

[2] Analog Input 60 Select analog input 60 as relative

scaling reference source.

[8] Pulse Input 33 Select pulse input 33 as relative scaling

reference source.

[11] Local Bus

Reference

Select local bus ref. as relative scaling reference source.

[21] LCP Potentiometer Select LCP potentiometer as relative

scaling reference source.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

22 MG02C602 - VLT® is a registered Danfoss trademark

4.4.4 3-4* Ramp 1

A linear ramp is characterized by ramping up at a constant speed until the desired motor speed has been reached. Some overshoot may be experienced when reaching speed, which may cause speed jerks for a short while before stabilizing. An S-ramp accelerates more smoothly thus compensating for jerks when the speed is reached.

See Illustration 4.6 for a comparison of the two ramp types.

130BA168.10

Ramp (X) S-Ramp Ratio at Accel.End

Jerk compensated

Ramp (X)

Up Time

Ramp (X) S-Ramp Ratio at Accel.End

Linear

Speed

Ramp (X)

Down Time

Ramp (X) S-Ramp Ratio at Dec.End

Illustration 4.6

Ramp Times Ramp up: Acceleration time from 0 to nominal motor frequency (1-23 Motor Frequency). Deceleration time from nominal motor frequency (1-23 Motor Frequency) to 0.

Limitation Too short ramp up time can result in Torque limit warning (W12) and/or DC over voltage warning (W7). Ramping is stopped when the frequency converter has reached Torque limit motor mode (4-16 Torque Limit in Motor Mode). Too short ramp down time can result in Torque limit warning (W12) and/or DC over voltage warning (W7). Ramping is stopped when the frequency converter reaches the Torque limit generator mode (4-17 Torque Limit in Generator Mode) and/or the internal DC over voltage limit.

3-40 Ramp1 Type

Option: Function:

[0] * Linear Constant acceleration/deceleration. [2] S-ramp Smooth jerk compensated acceleration/

deceleration.

3-41 Ramp1 Ramp-up Time

Range: Function:

Size related*

[0.05-3600.00 s] Enter ramp-up time from 0 Hz to

rated motor frequency (f

M,N

) set

in 1-23 Motor Frequency. Choose a ramp-up time ensuring that torque limit is not exceeded, see 4-16 Torque Limit in Motor Mode.

3-42 Ramp1 Ramp-down Time

Range: Function:

Size related*

[0.05-3600.00s]Enter ramp down time from rated

motor frequency (f

M,N

) in 1-23

Motor Frequency to 0 Hz. Choose a ramp down time that does not cause over-voltage in inverter due to regenerative operation of motor. Furthermore, regenerative torque must not exceed limit set in 4-17 Torque Limit in Generator Mode.

4.4.5 3-5* Ramp2

See parameter group 3-4* Ramp 1 for a description of ramp types.

NOTE

Ramp2 - alternative ramp times: Changing from Ramp1 to Ramp2 is done via the digital input. See 5-1* Digital Inputs, option [34].

3-50 Ramp2 Type

Option: Function:

[0] * Linear Constant acceleration/deceleration. [2] S-ramp Smooth jerk compensated acceleration/

deceleration.

3-51 Ramp2 Ramp-up Time

Range: Function:

Size related*

[0.05-3600.00 s] Enter ramp-up time from 0 Hz to

rated motor frequency (f

M,N

) set

in 1-23 Motor Frequency. Choose a ramp-up time ensuring that torque limit is not exceeded, see 4-16 Torque Limit in Motor Mode.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 23

4 4

3-52 Ramp2 Ramp-down Time

Range: Function:

Size related

[0.05-3600.00s]Enter ramp down time from rated

motor frequency (f

M,N

) in 1-23 Motor

Frequency to 0 Hz. Choose a ramp down time that does not cause over-voltage in inverter due to regenerative operation of motor. Furthermore, regenerative torque must not exceed limit set in 4-17 Torque Limit in Generator Mode.

4.4.6 3-8* Other Ramps

This section contains parameters for Jog and Quick Stop Ramps.

With a Jog Ramp it is possible to both ramp up and down whereas, it is only possible to ramp down with the Quick Stop Ramp.

3-80 Jog Ramp Time

Range: Function:

Size related*

[0.05-3600.00s]A linear ramp applicable when Jog

is activated. See parameter group 5-1* Digital Inputs, option [14]. Ramp up time = Ramp down time. Jog Ramp time starts upon activation of a jog signal via a selected digital input or serial communication port.

3-81 Quick Stop Ramp Time

Range: Function:

Size related* [0.05-3600.00 s] A linear ramp applicable when

Q-stop is activated. See parameter group 5-1* Digital Inputs, option [4].

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

24 MG02C602 - VLT® is a registered Danfoss trademark

4.5 Parameter Group 4: Limits/Warnings

4.5.1 4-** Motor Limits

Parameter group for configuring limits and warning.

4.5.2 4-1* Motor Limits

Use these parameters for defining the speed, torque and current working range for the motor.

4-10 Motor Speed Direction

Option: Function:

If terminals 96, 97 and 98 are connected to U, V and W respectively, the motor runs clockwise when seen from the front.

NOTE

This parameter cannot be adjusted while the motor is running

[0] * Clockwise The motor shaft rotates in clockwise direction.

This setting prevents the motor from running in counterclockwise direction. If 1-00 Configu-

ration Mode is set to close loop control, 4-10 Motor Speed Direction will be automatically set

to clockwise.

[1] Counter-

clockwise

The motor shaft rotates in counterclockwise direction. This setting prevents the motor from running in clockwise direction.

[2] * Both With this setting the motor can run in both

directions. However, the output frequency is limited to the range: Motor Speed Low Limit (4-12 Motor Speed Low Limit) to Motor Speed High Limit (4-14 Motor Speed High Limit). If 1-00 Configuration Mode is set to open loop control, 4-10 Motor Speed Direction will be automatically set to both direction

4-12 Motor Speed Low Limit

Range: Function:

0.0 Hz* [0.0-400.0 Hz]

Set the Minimum Motor Speed Limit corresponding to the minimum output frequency of the motor shaft.

NOTE

As the minimum output frequency is an absolute value, it cannot be deviated from.

4-14 Motor Speed High Limit

Range: Function:

65.0 Hz* [0.0-400.0 Hz]

Set the Maximum Motor Speed corresponding to the maximum output frequency of the motor shaft.

NOTE

As the maximum output frequency is an absolute value, it cannot be deviated from.

4-16 Torque Limit in Motor Mode

Range: Function:

150 %* [0-400%] Set the torque limit for motor operation.

The setting is not automatically reset to default when changing settings in 1-00 Configuration Mode to 1-25 Load & Motor.

4-17 Torque Limit in Generator Mode

Range: Function:

100 %* [0-400%] Set the torque limit for generator mode

operation. The setting is not automatically reset to default when changing settings in 1-00 Configuration Mode to 1-25 Load & Motor.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 25

4 4

4.5.3 4-4* Adjustable Warnings 2

4-40 Warning Frequency Low

Range: Function:

0.00 Hz*

[0.0 HzDepend on the value of 4-41

Warning Frequency High]

Use this parameter to set a lower limit for the frequency range. When the motor speed falls below this limit, the display reads SPEED LOW. Warning bit 10 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter set limit is reached.

4-41 Warning Frequency High

Range: Function:

400.0 Hz*

[Depend on the value of

4-40 Warning Frequency Low

-400.0 Hz]

Use this parameter to set a higher limit for the frequency range. When the motor speed exceeds this limit, the display reads SPEED HIGH. Warning bit 9 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter set limit is reached.

4.5.4 4-5* Adjustable Warnings

Parameter group containing adjustable warning limits for current, speed, reference and feedback.

Warnings are shown in display, programmed output or serial bus.

4-50 Warning Current Low

Range: Function:

Use this parameter to set a lower limit for the current range. If current drops below the set limit, warning bit 8 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter's set limit is reached.

0.00A* [0.00-26.00A]Set value for low current limit.

4-51 Warning Current High

Range: Function:

Use this parameter to set an upper limit for the current range. If current exceeds the set limit, warning bit 7 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter's set limit is reached.

26.00A* [0.00-26.00A]Set upper current limit.

4-54 Warning Reference Low

Range: Function:

-4999.000* [-4999.000-

Depend on the value of 4-55

Warning Reference High]

Use this parameter to set a lower limit for the reference range. When the actual reference falls below this limit, the display reads Reference Low. Warning bit 20 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter set limit is reached.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

26 MG02C602 - VLT® is a registered Danfoss trademark

4-55 Warning Reference High

Range: Function:

4999.000* [Depend on the value of

4-54 Warning Reference Low-

4999.000]

Use this parameter to set a higher limit for the reference range. When the actual reference exceeds this limit, the display reads Reference High. Warning bit 19 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter set limit is reached.

4-56 Warning Feedback Low

Range: Function:

-4999.000* [-4999.000-

Depend on the value of 4-57

Warning Feedback High]

Use this parameter to set a lower limit for the feedback range. When the feedback falls below this limit, the display reads Feedback Low. Warning bit 6 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter set limit is reached.

4-57 Warning Feedback High

Range: Function:

4999.000* [Depend on the value of 4-56

Warning Feedback Low

-4999.000]

Use this parameter to set a higher limit for the feedback range. When the feedback exceeds this limit, the display reads Feedback High. Warning bit 5 is set in 16-94 Ext. Status Word. Output Relay can be configured to indicate this warning. LCP warning light does not light when this parameter set limit is reached.

4-58 Missing Motor Phase Function

Option: Function:

A missing motor phase causes the motor torque to drop. This monitor may be disabled for special purposes (eg. small motors running pure U/f mode), but as there is a risk of overheating the motor, Danfoss strongly recommends that the function is On. A missing motor phase causes the frequency converter to trip and report an alarm.

NOTE

This parameter cannot be changed while motor runs.

[0] Off Function is disabled. [1] * On Function is enabled.

4.5.5 4-6* Speed Bypass

In some applications mechanical resonance may occur. Avoid resonance points by creating a bypass. The frequency converter ramps through the bypass area thereby passing mechanical resonance points quickly.

4-61 Speed Bypass From [Hz]

Array [2]

Range: Function:

0.0 Hz* [0.0-400.0 Hz] Enter either the lower or upper limit of the speeds to be avoided. It does not matter whether Bypass From or Bypass To is the upper or lower limit, however the Speed Bypass function is disabled if the two parameters are set to the same value.

4-63 Speed Bypass To [Hz]

Array [2]

Range: Function:

0.0 Hz* [0.0-400.0 Hz] Enter either the upper or lower limit of the speed area to be avoided. Make sure to enter the opposite limit of that in 4-61 Speed Bypass From [Hz].

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 27

4 4

4.6 Parameter Group 5: Digital In/Out

4.6.1 5-** Digital In/Out

The following describes all digital input command functions and signals.

4.6.2 5-1* Digital Inputs

Parameters for configuring the functions for the input terminals. The digital inputs are used for selecting various functions in the frequency converter. All digital inputs can be set to the following:

[0] No Operation The frequency converter will not react to

signals transmitted to the terminal.

[1] Reset Reset the frequency converter after a Trip/

Alarm. Not all alarms can be reset.

[2 ] Coast Inverse Coasting stop, inverted input (NC). The

frequency converter leaves the motor in free mode.

[3] Coast and

reset inv.

Reset and coasting stop inverted input (NC). The frequency converter resets and leaves the motor in free mode.

[4] Quick stop

inverse

Inverted input (NC). Generates a stop in accordance with the quick-stop ramp time set in 3-81 Quick Stop Ramp Time. When motor stops, shaft is in free mode.

[5] DC-brake inv. Inverted input for DC braking (NC). Stops

motor by energizing it with DC current for a certain time period, see 2-01 DC Brake Current. Function is only active when value in 2-02 DC-Braking Time is different from 0.

[6] Stop inv. Stop inverted function. Generates stop

function when selected terminal goes from logical level “1” to “0”. Stop is performed according to selected ramp time.

[8] Start Select start for a start/stop command.

1 = Start, 0 = stop.

[9] Latched start Motor starts if a pulse is applied for min. 2

ms. Motor stops when Stop inverse is activated.

[10] Reversing Change direction of motor shaft rotation.

Reversing signal only changes direction of rotation; it does not activate start function. Select [2] Both directions in 4.10 Motor Speed Direction. 0 = normal, 1 = reversing.

[11] Start

reversing

Use for start/stop and for reversing at the same time. Signals on start [8] are not allowed at the same time. 0 = stop, 1 = start reversing.

[12] Enable start

forward

Use if motor shaft must rotate clockwise at start.

[13] Enable start

reverse

Use if motor shaft must rotate counterclockwise at start.

[14] Jog

Use for activating jog speed. See 3-11 Jog Speed.

[16] Preset

reference bit 0

Preset reference bit 0, 1 and 2 enables a choice between one of the eight preset references according to below.

[17] Preset

reference bit 1

Same as preset reference bit 0 [16], see 3-10 Preset Reference.

[18] Preset

reference bit 2

Same as preset reference bit 0 [16].

[19] Freeze

reference

Freeze actual reference. The frozen reference is now the point of enable/condition for Speed up and Speed down to be used. If Speed up/down is used, speed change always follows ramp 2 (3-51 Ramp2 Ramp-up Time and 3-52 Ramp2 Ramp-down Time) in the range 3-02 Minimum Reference - 3-03 Maximum Reference.

[20] Freeze output Freeze the actual motor frequency (Hz). The

frozen motor frequency is now the point of enable/condition for Speed up and Speed down to be used. If Speed up/down is used, the speed change always follows ramp 2 in the range 4-12 Motor Speed Low Limit - 4-14 Motor Speed High Limit.

NOTE

When freeze output is active, the frequency converter cannot be stopped via a low [8] Start signal. Stop the frequency converter via a terminal programmed for Coasting Inverse [2] or Coast and reset, inverse [3].

[21] Speed up Select Speed up and Speed down if digital

control of the up/down speed is desired (motor potentiometer). Activate this function by selecting either Freeze reference or Freeze output. When Speed-up is activated for less than 400 ms. the resulting reference will be increased by 0.1%. If Speed-up is activated for more than 400 ms. the resulting reference will ramp according to ramp 2 in 3-51 Ramp2 Ramp-up Time.

[22] Speed down Same as Speed-up [21]. [23] Setup select

bit 0

Set 0-10 Active set-up to Multi set-up. Logic 0 = set up 1, Logic 1 = Set up 2.

[26] Precise stop

inverse (only terminal 33)

Prolong the stop signal to give a precise stop independent of scan time. The function is available for terminal 33 only.

[27] Start, precise

stop (only terminal 33)

As [26], but including Start.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

28 MG02C602 - VLT® is a registered Danfoss trademark

[28] Catch up Select Catch up/Slow down to increase or

reduce the resulting reference value by the percentage set in 3-12 Catch Up/Slow Down

Value

[29] Slow down Same as Catch up [28] [32] Pulse input

(only terminal

33)

Select Pulse input when using a pulse sequence as either reference or feedback. Scaling is done in parameter group 5-5*

Pulse Input

[34] Ramp bit 0

Logic 0=Ramp1, see parameter group 3-4*

Ramp1 Logic 1=Ramp2, see parameter group 3-5* Ramp2.

[60] Counter A

(up)

Input for counter A.

[61] Counter A

(down)

Input for counter A.

[62] Reset counterAInput for reset of counter A.

[63] Counter B

(up)

Input for counter B.

[64] Counter B

(down)

Input for counter B.

[65] Reset counterBInput for reset of counter B.

5-10 Terminal 18 Digital Input

Option: Function:

[8] * Start Select function from available digital input range.

See parameter group 5-1* Digital Inputs for choices.

5-11 Terminal 19 Digital Input

Option: Function:

[10] * Reversing Select function from available digital input

range. See parameter group 5-1* Digital Inputs for choices.

5-12 Terminal 27 Digital Input

Option: Function:

[1] * Reset Select function from available digital input range.

See parameter group 5-1* Digital Inputs* for choices.

5-13 Terminal 29 Digital Input

Option: Function:

[14] * Jog Select function from available digital input range.

See parameter group 5-1* Digital Inputs for choices.

5-15 Terminal 33 Digital Input

Option: Function:

[16] * Preset bit 0 Select function from available digital input

range. See parameter group 5-1* Digital Inputs for choices.

4.6.3 5-3* Digital Outputs

5-34 On delay, Terminal 42 Digital Output

Range: Function:

0.01 s* [0.00-600.00 s]

5-35 Off delay, Terminal 42 Digital Output

Range: Function:

0.01 s* [0.00-600.00 s]

4.6.4 5-4* Relays

Parameter group for configuring timing and output functions for relays.

[0] No Operation Default for all digital and relay outputs. [1] Control Ready Control board receives supply voltage. [2] Drive Ready Frequency converter is ready for

operation and applies supply signal on control board.

[3] Drive Ready,

Remote

Frequency converter is ready for operation in Auto On-mode.

[4] Enable/No

Warning

Frequency converter is ready for operation. No start or stop command is

given. No warnings are present. [5] Drive Running Motor is running. [6] Running/No

Warning

Motor runs, and no warning are

present. [7] Run in Range/No

Warning

Motor runs within programmed current

ranges, see 4-50 Warning Current Low

and 4-51 Warning Current High. No

warnings are present. [8] Run on ref/No

Warning

Motor runs at reference speed.

[9] Alarm An alarm activates output. [10] Alarm on Warning An alarm or warning activates output. [12] Out of Current

Range

Motor current is outside range set in

4-50 Warning Current Low and 4-51

Warning Current High.

[13] Below Current,

low

Motor current is lower than set in 4-50

Warning Current Low. [14] Above Current,

high

Motor current is higher than set in 4-51

Warning Current High. [16] Below Frequency,

low

Motor speed is lower than set in 4-40

Warning Frequency Low. [17] Above Frequency,

high

Motor speed is higher than set in 4-41

Warning Frequency High. [19] Below Feedback,

low

Feedback is lower than set in 4-56

Warning Feedback Low. [20] Above Feedback,

high

Feedback is higher than set in 4-57

Warning Feedback High. [21] Thermal Warning Thermal warning is present when

temperature exceeds limit in motor,

frequency converter, brake resistor or

thermistor.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 29

4 4

[22] Ready, No

Thermal Warning

Frequency converter is ready for operation and no over-temperature warning is present.

[23] Remote Ready, No

Thermal Warning

Frequency converter is ready for operation in Auto mode, and no overtemperature warning is present.

[24] Ready, Voltage OK Frequency converter is ready for

operation and mains voltage is within specified voltage range.

[25] Reverse Motor runs/is ready to run clockwise

when logic = 0 and counter clockwise when logic = 1. Output changes as soon as reversing signal is applied.

[26] Bus OK Active communication (no time-out) via

serial communication port.

[28] Brake, No Warn Brake is active, and no warnings are

present.

[29] Brake Ready/No

Fault

Brake is ready for operation, and no faults are present.

[30] Brake Fault (IGBT) Protects frequency converter if fault on

brake modules is present. Use relay to cut out main voltage from frequency converter.

[32] Mech. Brake

Control

Enables control of external mechanical brake, see parameter group 2-2* Mechanical Brake.

[36] Control Word Bit11Bit 11 in control word controls relay.

[41] Below Reference,

low

Reference is lower than set in 4-54 Warning Reference Low.

[42] Above Reference,

high

Reference is higher than set in 4-55 Warning Reference High.

[51] Local Reference

Active

[52] Remote Reference

Active [53] No Alarm [54] Start Cmd Active [55] Running Reverse [56] Drive in Hand

Mode [57] Drive in Auto

Mode [60] Comparator 0

See parameter group 13-1* Comparators. If comparator 0 is evaluated as TRUE, output goes high. Otherwise, it is low.

[61] Comparator 1

See parameter group 13-1* Comparators. If comparator 1 is evaluated as TRUE, output goes high. Otherwise, it is low.

[62] Comparator 2

See parameter group 13-1* Comparators. If comparator 2 is evaluated as TRUE, output goes high. Otherwise, it is low.

[63] Comparator 3

See parameter group 13-1* Comparators. If comparator 3 is evaluated as TRUE, output goes high. Otherwise, it is low.

[70] Logic Rule 0

See parameter group 13-4* Logic Rules. If Logic Rule 1 is evaluated as TRUE, output goes high. Otherwise, it is low.

[71] Logic Rule 1

See parameter group 13-4* Logic Rules. If Logic Rule 2 is evaluated as TRUE, output goes high. Otherwise, it is low.

[72] Logic Rule 2

See parameter group 13-4* Logic Rules. If Logic Rule 3 is evaluated as TRUE, output goes high. Otherwise, it is low.

[73] Logic Rule 3

See parameter group 13-4* Logic Rules. If Logic Rule 3 is evaluated as TRUE, output goes high. Otherwise, it is low.

[81] SL Digital Output

See 13-52 SL Control Action. When Smart Logic Action [39] Set dig. out. A high is executed, input goes high. When Smart Logic Action [33] Set dig. out. A low is executed, input goes low.

5-40 Function Relay

Option: Function:

[0] * No Operation Select function from available relay output

range.

5-41 On delay, Relay

Option: Function:

[0.01 s] * [0.00-600.00 s] Enter the delay of the relay cut-in time.

If the Selected Event condition changes before the On delay timer expires, the relay output is unaffected. The function to control the relay see 5-40 Function Relay.

5-42 Off delay, Relay

Option: Function:

[0.01 s] * [0.00-600.00 s] Enter the delay of the relay cut-off

time. If the Selected Event condition changes before the off delay timer expires, the relay output is unaffected. The function to control the relay see 5-40 Function Relay.

4.6.5 5-5* Pulse Input

Set 5-15 Terminal 33 Digital Input to choice [32] pulse input. Now terminal 33 handles a pulse input in the range from Low frequency, 5-55 Terminal 33 Low Frequency, to 5-56

Terminal 33 High Frequency. Scale frequency input via 5-57 Terminal 33 Low Ref./Feedb. Value and 5-58 Terminal 33 High Ref./Feedb. Value.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

30 MG02C602 - VLT® is a registered Danfoss trademark

5-55 Terminal 33 Low Frequency

Range: Function:

20 Hz* [20-4999 Hz] Enter low frequency corresponding to low

motor shaft speed (i.e. low reference value) in 5-57 Terminal 33 Low Ref./Feedb. Value.

5-56 Terminal 33 High Frequency

Range: Function:

5000 Hz* [21-5000 Hz] Enter high frequency corresponding to

high motor shaft speed (i.e. high reference value) in 5-58 Terminal 33 High Ref./Feedb. Value.

5-57 Terminal 33 Low Ref./Feedb. Value

Range: Function:

0.000* [-4999-4999] Set reference/feedback value

corresponding to low pulse frequency value set in 5-55 Terminal 33 Low Frequency.

5-58 Terminal 33 High Ref./Feedb. Value

Range: Function:

50.000* [-4999-4999] Set reference/feedback value

corresponding to high pulse frequency value set in 5-56 Terminal 33 High Frequency.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 31

4 4

4.7 Parameter Group 6: Analog In/Out

4.7.1 6-** Analog In/Out

Parameter group for configuring analog inputs and outputs.

4.7.2 6-0* Analog I/O Mode

Parameter group for setting up the analog I/O configuration.

6-00 Live Zero Timeout Time

Range: Function:

The Live Zero function is used for monitoring the signal on an analog input. If the signal disappears, a Live Zero warning is reported.

10 s* [1-99 s]

Set delay time before Live Zero Timeout Function is applied (6-01 Live Zero Timeout Time). If the signal reappears during the set delay, timer will be reset. When live zero is detected, the frequency converter freezes output frequency and starts Live Zero Timeout timer.

6-01 Live Zero Timeout Function

Option: Function:

Function is activated if input signal is below 50% of value set in 6-10 Terminal 53 Low

Voltage, 6-12 Terminal 53 Low Current or 6-22 Terminal 60 Low Current.

[0] * Off Function is disabled. [1] Freeze

output

Output frequency remains at value it had when live zero was detected.

[2] Stop Frequency converter ramps down to 0 Hz.

Remove live zero error condition before restarting frequency converter.

[3] Jogging Frequency converter ramps to jog speed, see

3-11 Jog Speed.

[4] Max Speed Frequency converter ramps to Motor Speed

High Limit, see 4-14 Motor Speed High Limit.

[5] Stop and

Trip

Frequency converter ramps down to 0 Hz and then trips. Remove live zero condition and activate reset before restarting the frequency converter.

4.7.3 6-1* Analog Input 1

Parameters for configuring scaling and limits for analog input 1 (terminal 53).

NOTE

Micro switch 4 in position U:

6-10 Terminal 53 Low Voltage and 6-11 Terminal 53 High Voltage are active.

Micro switch 4 in position I:

6-12 Terminal 53 Low Current and 6-13 Terminal 53 High Current are active.

Illustration 4.7

Ref./Feedback

[RPM]

Analog input

High Ref./

Feedb. Value'

Low Ref./

Feedb. Value'

'Low Voltage'or

'Low Current'

'High Voltage'or

'High Current'

130BD019.10

1 V 5 V 10 V

300

600

900

1200

1500

[V]

150

Par 6-xx

Illustration 4.8

6-10 Terminal 53 Low Voltage

Range: Function:

This scaling value should correspond to minimum reference value set in 6-14 Terminal 53 Low Ref./Feedb. Value. See also 4.4 Parameter Group 3: Reference/ Ramps.

0.07 V* [0.00-9.90 V] Enter low voltage value.

CAUTION

The value must be set to min. 1 V in order to activate the Live Zero Timeout function in 6-01 Live Zero Timeout Function.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

32 MG02C602 - VLT® is a registered Danfoss trademark

6-11 Terminal 53 High Voltage

Range: Function:

This scaling value should correspond to maximum reference value set in 6-15 Terminal 53 High Ref./Feedb. Value.

10.0 V* [0.10-10.00 V] Enter high voltage value.

6-12 Terminal 53 Low Current

Range: Function:

This reference signal should correspond to minimum reference value set in 6-14 Terminal 53 Low Ref./Feedb. Value.

0.14 mA* [0.00-19.90 mA] Enter low current value.

CAUTION

The value must be set to min. 2 mA in order to activate the Live Zero Timeout function in 6-01 Live Zero Timeout Function.

6-13 Terminal 53 High Current

Range: Function:

This reference signal should correspond to the maximum reference value set in 6-15 Terminal 53 High Ref./Feedb. Value.

20.00 mA* [0.10-20.00 mA] Enter high current value.

6-14 Terminal 53 Low Ref./Feedb. Value

Range: Function:

The scaling value corresponding to the low voltage/low current set in 6-10

Terminal 53 Low Voltage and 6-12 Terminal 53 Low Current.

0.000* [-4999-4999] Enter analog input scaling value.

6-15 Terminal 53 High Ref./Feedb. Value

Range: Function:

The scaling value corresponding to the high voltage/high current set in 6-11 Terminal 53 High

Voltage and 6-13 Terminal 53 High Current.

50.000* [-4999.000-4999.000] Enter analog input scaling value.

6-16 Terminal 53 Filter Time Constant

Range: Function:

A first-order digital low pass filter time constant for suppressing electrical noise in terminal 53. A high time constant value improves dampening but also increases time delay through the filter.

0.01 s* [0.01-10.00 s] Enter time constant.

6-19 Terminal 53 Mode

Option: Function:

Select the input to be present on terminal

53.

CAUTION

6-19 Terminal 53 Mode MUST be set according to Micro switch 4 setting.

[0] * Voltage Mode [1] Current Mode

4.7.4 6-2* Analog Input 2

Parameters for configuring scaling and limits for analog input 2, terminal 60.

6-22 Terminal 60 Low Current

Range: Function:

This reference signal should correspond to minimum reference value set in 6-24 Terminal 60 Low Ref./Feedb. Value.

0.14 mA* [0.00-19.90 mA] Enter low current value.

CAUTION

The value must be set to min. 2 mA in order to activate the Live Zero Timeout function in 6-01 Live Zero Timeout Time.

6-23 Terminal 60 High Current

Range: Function:

This reference signal should correspond to the high current value set in 6-25 Terminal 60 High Ref./Feedb. Value.

20.00 mA* [0.10-20.00 mA] Enter high current value.

6-24 Terminal 60 Low Ref./Feedb. Value

Range: Function:

The scaling value corresponding to the low current set in 6-22 Terminal 60 Low Current.

0.000* [-4999-4999] Enter analog input scaling value.

6-25 Terminal 60 High Ref./Feedb. Value

Range: Function:

The scaling value corresponding to the high current set in 6-23 Terminal 60 High Current.

50.00* [-4999-4999] Enter analog input scaling value.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 33

4 4

6-26 Terminal 60 Filter Time Constant

Range: Function:

A first-order digital low pass filter time constant for suppressing electrical noise in terminal 60. A high time constant value improves dampening, but also increases time delay through the filter.

NOTE

This parameter cannot be changed while motor runs.

0.01 s* [0.01-10.00 s] Enter time constant.

4.7.5 6-8* LCP Potentiometer

The LCP potentiometer can be selected either as Reference Resource or Relative Reference Resource.

NOTE

In Hand mode the LCP potentiometer functions as local reference.

6-80 LCP Potmeter Enable

Option: Function:

If LCP Potmeter is disabled, [▲] [▼] can adjust local reference, and Potmeter value does not give

any reference in Auto/Hand mode. [0] Disabled [1] * Enable

6-81 LCP Potentiometer Low Ref. Value

Range: Function:

The scaling value corresponding to 0.

0.000* [-4999-4999] Enter low reference value.

The reference value corresponding to potentiometer turned fully counterclockwise (0 degrees).

6-82 LCP Potentiometer High Ref. Value

Range: Function:

The scaling value corresponding to the maximum reference feedback value set in 3-03 Maximum Reference.

50.00* [-4999-4999] Enter high reference value.

The reference value corresponding to potentiometer turned fully clockwise (200 degrees).

4.7.6 6-9* Analog Output

These parameters are for configuring the analog outputs of the frequency converter.

6-90 Terminal 42 Mode

Option: Function:

[0] * 0-20 mA Range for analog outputs is 0-20 mA [1] 4-20 mA Range for analog outputs is 4-20 mA [2] Digital output Functions as slow reacting digital output.

Set value to either 0 mA (off) or 20 mA (on), see 6-92 Terminal 42 Digital Output.

6-91 Terminal 42 Analog Output

Option: Function:

Select the function for terminal

42 as an analog output. [0] * No Operation [10] Output Frequency [0-100

Hz]

[11] Reference (REF min-max)

3-02 Minimum Reference to 3-03

Minimum Reference.

[12] Feedback (FB min-max) [13] Motor Current (0-I

max

)

16-37 Inv. Max. Current is I

max

[16] Power (0-P

nom

)

1-20 Motor Power is P

nom

(motor). [19] DC Link Voltage (0-1000

[20] Bus Reference [0.0%

-100.0%]

The analog output will follow

the reference value set on the

RS-485 bus.

6-92 Terminal 42 Digital Output

Option: Function:

See parameter group 5-4* Relays, for

choices and descriptions. [0] * No Operation [80] SL Digital

Output A

See 13-52 SL Control Action. When Smart

Logic Action [38] Set dig. out. A high is

executed, input goes high. When Smart

Logic Action [32] Set dig. out. A low is

executed, input goes low.

6-93 Terminal 42 Output Min. Scale

Range: Function:

0.00% [0.00-200.0%] Scale minimum output of selected analog

signal at terminal 42 as percentage of maximum signal value. E.g. if 0 mA (or 0 Hz) is desired at 25% of maximum output value, program 25%. Scaling values up to 100% can never be higher than corresponding setting in 6-94 Terminal 42 Output Min. Scale.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

34 MG02C602 - VLT® is a registered Danfoss trademark

130BD020.10

(mA)

0/4

100%

Current

Analogue output Min Scale par. 6-93

Variable for output example: Speed (RPM)

Analogue Output Max Scale par. 6-94

Illustration 4.9

6-94 Terminal 42 Output Max. Scale

Range: Function:

100.00%* [0.00-200.00%]

Scale maximum output of selected analog signal at terminal 42. Set value to maximum value of current signal output. Scale output to give a current lower than 20 mA at full scale; or 20 mA at an output below 100% of maximum signal value. If 20 mA is the desired output current at a value between 0-100% of the fullscale output, programme percentage value in the parameter, i.e. 50% = 20 mA. If a current between 4 and 20 mA is desired at maximum output (100%), calculate percentage value as follows:

desired maximum current

× 100 %

i.e.

10 mA =

20 10

× 100 = 200 %

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 35

4 4

4.8 Parameter Group 7: Controllers

4.8.1 7-** Controllers

Parameters group for configuring application controls.

4.8.2 7-2* Process Ctrl. Feedback

Select feedback sources and handling for Process PI Control.

NOTE

Set 3-15 Reference 1 Source to [0] No Function in order to use Analog Input as a feedback signal. In order to use analog input as a feedback resource, do not use the same resource as reference resource in 3-15, 3-16 and 3-17.

7-20 Process CL Feedback Resources

Option: Function:

Select input to function as feedback

signal. [0] * No Function [1] Analog Input 53 [2] Analog Input 60 [8] Pulse Input 33 [11] Local Bus Ref.

4.8.3 7-3* Process PI Control

7-30 Process PI Normal/Inverse Control

Option: Function:

[0] * Normal Feedback larger than setpoint result in a speed

reduction. Feedback less than setpoint result in a speed increase.

[1] Inverse Feedback larger than setpoint result in a speed

increase. Feedback less than setpoint result in a speed reduction.

7-31 Process PI Anti Windup

Option: Function:

[0] Disable Regulation of a given error will continue even

when the output frequency cannot be increased/ decreased.

[1] * Enable PI-controller ceases from regulating a given error

when the output frequency cannot be increased/ decreased.

7-32 Process PI Start Speed

Range: Function:

0.0 Hz* [0.0-200.0 Hz] Until the set motor speed has been

reached the frequency converter operates in Open Loop mode.

7-33 Process PI Proportional Gain

Option: Function:

[0.01] * 0.00-10.00 Enter the value for the P proportional gain,

i.e. the multiplication factor of the error between the set point and the feedback signal.

NOTE

0.00 = Off.

7-34 Process PI Integral Time

Range: Function:

9999.00 s* [0.10-9999.00 s] The integrator provides an increasing gain at a constant error between the set point and the feedback signal. The integral time is the time needed by the integrator to reach the same gain as the proportional gain.

7-38 Process Feed Forward Factor

Range: Function:

0%* [0-400%] The FF factor sends a part of the reference

signal around the PI controller which then only affects part of the control signal. By activating the FF factor less overshoot and high dynamics are gained when changing the setpoint. This parameter is always active when 1-00 Configuration Mode is set to [3] Process.

7-39 On Reference Bandwidth

Range: Function:

5% [0-200% ] Enter the value for the On Reference Bandwidth.

The PI control error is the difference between setpoint and feedback and when this is less than the value set in this parameter the On Reference is active.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

36 MG02C602 - VLT® is a registered Danfoss trademark

4.9 Parameter Group 8: Communication

4.9.1 8-** Communication

Parameter group for configuring communication.

4.9.2 8-0* General Settings

Use this parameter group for configuring the general settings for communication.

8-01 Control Site

Option: Function:

[0] * Digital and

Control Word

Use both digital input and control word

as control. [1] Digital Only Use digital input as control. [2] Control Word

Only

Use control word only as control.

NOTE

The setting in this parameter

overrules settings in 8-50 Coasting

Select to 8-56 Preset Reference Select.

8-02 Control Word Source

Option: Function:

[0] None Function is inactive [1] * FC RS-485 Monitoring control word source is done via

serial communication port RS-485.

8-03 Control Word Timeout Time

Range: Function:

1.0 s* [0.1-6500 s] Enter time to pass before control word

timeout function (8-04 Control Word Timeout Function) must be carried out.

8-04 Control Word Timeout Function

Option: Function:

Select the action to be taken in case of a

timeout. [0] * Off No function. [1] Freeze Output Freeze output until communication

resumes. [2] Stop Stop with auto restart when communication

resumes. [3] Jogging Run motor at jog frequency until communi-

cation resumes. [4] Max. Speed Run motor at max. frequency until

communication resumes. [5] Stop and Trip Stop motor, then reset frequency converter

in order to restart either via LCP or digital

input.

8-06 Reset Control Word Timeout

Option: Function:

Resetting the control word timeout will

remove any timeout function. [0] * No Function Control word timeout is not reset. [1] Do Reset Control word timeout is reset, and parameter

goes into [0] No Function state.

4.9.3 8-3* FC Port Settings

Parameters for configuring the FC Port.

8-30 Protocol

Option: Function:

Select the protocol to be used. Note that changing protocol will not be effective until

after powering off the frequency converter. [0] * FC [2] Modbus RTU

8-31 Address

Range: Function:

Select the address for the bus.

1* [1 - Protocol-dependent] FC-bus range is 1-126.

Modbus range is 1-247.

8-32 FC Port Baud Rate

Option: Function:

Select baud rate for FC Port.

NOTE

Changing baud rate will be effective after responding to any ongoing bus-requests.

[0] 2400 Baud [1] 4800 Baud [2] * 9600 Baud When choosing FC bus in 8-30 [3] * 19200 Baud When choosing Modbus in 8-30 [4] 38400 Baud

8-33 FC Port Parity

Option: Function:

This parameter only affects Modbus

as FC bus always has even parity. [0] * Even Parity (1 stopbit) [1] Odd parity [2] No Parity (1 stopbit) Select this for Modbus RTU [3] No Parity (2 stopbit)

8-35 Minimum Response Delay

Range: Function:

0.010 s* [0.001-0.500 s] Specify minimum delay time between

receiving a request and transmitting a response.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 37

4 4

8-36 Max Response Delay

Range: Function:

5.000 s* [0.010-10.00 s] Specify maximum permissible delay time between transmitting a request and receiving a response. Exceeding this time delay causes control word timeout.

4.9.4 8-4* FC MC Protocol Set

8-43 FC Port PCD Read Configuration

Array [16]

Option: Function:

[0] * None [1] 1500 Operation Hours [2] 1501 Running Hours [3] 1502 kWh Counter [4] 1600 Control Word [5] 1601 Reference [Unit] [6] 1602 Reference % [7] 1603 Status Word [8] 1605 Main Actual Value [%] [9] 1609 Custom Readout [10] 1610 Power [kW] [11] 1611 Power [hp] [12] 1612 Motor Voltage [13] 1613 Frequency [14] 1614 Motor Current [15] 1615 Frequency [%] [16] 1618 Motor Thermal [17] 1630 DC Link Voltage [18] 1634 Heatsink Temp. [19] 1635 Inverter Thermal [20] 1638 SL Controller State [21] 1650 External Reference [22] 1651 Pulse Reference [23] 1652 Feedback [Unit] [24] 1660 Digital Input 18,19,27,33 [25] 1661 Digtial Input 29 [26] 1662 Analog Input 53(V) [27] 1663 Analog Input 53(mA) [28] 1664 Analog Input 60 [29] 1665 Analog Output 42 [mA] [30] 1668 Freq. Input 33 [Hz] [31] 1671 Relay Output [bin] [32] 1672 Counter A [33] 1673 Counter B [34] 1690 Alarm Word [35] 1692 Warning Word [36] 1694 Ext. Status Word

Select the parameters to be assigned to PCD's of telegrams. The number of available PCDs depends on

8-43 FC Port PCD Read Configuration

Array [16]

Option: Function:

the telegrams. This table is not for [0] array and [1] array . For these two arrays, index 1 is fixed to [7] and index 2 is fixed to [8]. These two arrays cannot be changed by end user.

4.9.5 8-5* Digital/Bus

Parameters for configuring control word Digital/Bus merging.

NOTE

Parameters are only active when 8-01 Control Site, is set to [0] Digital and control word.

8-50 Coasting Select

Option: Function:

Select control of coasting function via digital

input and/or bus. [0] Digital Input Activation via a digital input. [1] Bus Activation via serial communication port. [2] LogicAnd Activation via serial communication port and

a digital input. [3] * LogicOr Activation via serial communication port or a

digital input.

8-51 Quick Stop Select

Option: Function:

Select control of quick stop function via

digital input and/or bus. [0] Digital Input Activation via a digital input. [1] Bus Activation via serial communication port. [2] LogicAnd Activation via serial communication port and

a digital input. [3] * LogicOr Activation via serial communication port or a

digital input.

8-52 DC Brake Select

Option: Function:

Select control of DC brake via digital input

and/or bus. [0] Digital Input Activation via a digital input. [1] Bus Activation via serial communication port. [2] LogicAnd Activation via serial communication port and

a digital input. [3] * LogicOr Activation via serial communication port or a

digital input.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

38 MG02C602 - VLT® is a registered Danfoss trademark

8-53 Start Select

Option: Function:

Select control of start function via digital

input and/or bus. [0] Digital Input Activation via a digital input. [1] Bus Activation via serial communication port. [2] LogicAnd Activation via serial communication port and

a digital input. [3] * LogicOr Activation via serial communication port or a

digital input.

8-54 Reversing Select

Option: Function:

Select control of reversing function via digital

input and/or bus. [0] Digital Input Activation via a digital input. [1] Bus Activation via serial communication port. [2] LogicAnd Activation via serial communication port and

a digital input. [3] * LogicOr Activation via serial communication port or a

digital input.

8-55 Set-up Select

Option: Function:

Select control of set-up selection via digital

input and/or bus. [0] Digital Input Activation via a digital input. [1] Bus Activation via serial communication port. [2] LogicAnd Activation via serial communication port and

a digital input. [3] * LogicOr Activation via serial communication port or a

digital input.

8-56 Preset Reference Select

Option: Function:

Select control of Preset Reference selection

via digital input and/or bus. [0] Digital Input Activation via a digital input. [1] Bus Activation via serial communication port. [2] LogicAnd Activation via serial communication port and

a digital input. [3] * LogicOr Activation via serial communication port or a

digital input.

4.9.6 8-8* Bus communication diagnostics

These parameters are used for monitoring the Bus communication via the Port.

8-80 Bus Message Count

Range: Function:

0 N/A* [0-0 N/A] This parameter shows the number of valid

telegrams detected on the bus.

8-81 Bus Error Count

Range: Function:

0 N/A* [0-0 N/A] This parameter shows the number of

telegrams with faults (e.g. CRC fault), detected on the bus.

8-82 Slave Messages Rcvd

Range: Function:

0 N/A* [0-0 N/A] This parameter shows the number of valid

telegrams addressed to the slave, sent by the frequency converter.

8-83 Slave Error Count

Range: Function:

0 N/A* [0-0 N/A] This parameter shows the number of error

telegrams, which could be executed by the frequency converter.

4.9.7 8-9* Bus Feedback

Parameter for configuring bus feedback.

8-94 Bus Feedback 1

Range: Function:

0* [0x8000-0x7FFF] Bus feedback is delivered via FC or

Modbus by writing the feedback value into this parameter.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 39

4 4

4.10 Parameter Group 13: Smart Logic

4.10.1 13-** Programming Features

Smart Logic Control (SLC)is a sequence of user-defined actions (13-52 SL Controller Action [X]) executed by the SLC when the associated user-defined event (13-51 SL Controller Event [X]) is set to True.

Events and actions are linked in pairs, meaning that when an event is true, the linked action is carried out. After this the next event is evaluated and its belonging action carried out and so on. Only one event is evaluated at the time.

If an event is evaluated as False, the SLC takes no action during the scan interval and no other events are evaluated.

It is possible to programme from 1 to 20 events and actions. When the last event/action has been executed, the sequence starts again from event/action [0].

130BD021.10

State 1 Event 1/ Action 1

State 2 Event 2/ Action 2

Start event P13-01

State 3 Event 3/ Action 3

State 4 Event 4/ Action 4

Stop event P13-02

Illustration 4.10 Example with Three Events/Actions

Starting and stopping the SLC Start the SLC by selecting [1] On in 13-00 SL Controller Mode The SLC starts evaluating Event 0, and if this is evaluated as TRUE, the SLC continues its cycle.

The SLC stops when the Stop Event, 13-02 Stop Event, is TRUE. The SLC can also be stopped by selecting [0] Off in 13-00 SL Controller Mode.

To reset all SLC parameters select [1] Reset SLC in 13-03 Reset Smart Logic Controller and start programming from scratch.

4.10.2

13-0* SLC Settings

Use SLC settings to activate, deactivate and reset the Smart Logic Control.

13-00 SL Controller Mode

Option: Function:

[0] * Off Function is disabled. [1] On SLC is active.

13-01 Start Event

Option: Function:

Select input to activate Smart Logic Control.

[0] False

Enters False in logic rule.

[1] True

Enters True in logic rule.

[2] Running

See parameter group 5-4* Relays [5] for description.

[3] InRange

See parameter group 5-4* Relays [7] for description.

[4] OnReference

See parameter group 5-4* Relays [8] for description.

[7] Out of Current

Range

See parameter group 5-4* Relays [12] for description.

[8] BelowILow

See parameter group 5-4* Relays [13] for description.

[9] AboveIHigh

See parameter group 5-4* Relays [14] for description.

[16] ThermalWarning

See parameter group 5-4* Relays [21] for description.

[17] MainsOutOfRange Mains voltage is outside the

specified voltage range.

[18] Reversing

See parameter group 5-4* Relays [25]

for description. [19] Warning A warning is active. [20] Alarm_Trip A trip alarm is active. [21] Alarm_TripLock A trip lock alarm is active. [22] Comparator 0 Use result of comparator 0 in logic

rule. [23] Comparator 1 Use result of comparator 1 in logic

rule. [24] Comparator 2 Use result of comparator 2 in logic

rule. [25] Comparator 3 Use result of comparator 3 in logic

rule. [26] LogicRule 0 Use result of logic rule 0 in logic

rule. [27] LogicRule 1 Use result of logic rule 1 in logic

rule. [28] LogicRule 2 Use result of logic rule 2 in logic

rule. [29] LogicRule 3 Use result of logic rule 3 in logic

rule. [33] DigitalInput_18 Use value of DI 18 in logic rule. [34] DigitalInput_19 Use value of DI 19 in logic rule. [35] DigitalInput_27 Use value of DI 27 in logic rule.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

40 MG02C602 - VLT® is a registered Danfoss trademark

13-01 Start Event

Option: Function:

[36] DigitalInput_29 Use value of DI 29 in logic rule. [38] DigitalInput_33 [39] * StartCommand

This event is True, if frequency converter is started by any means (digital input or other).

[40] DriveStopped

This event is True, if frequency converter is stopped or coasted by any means (digital input or other).

13-02 Stop Event

Option: Function:

Select input to activate Smart Logic Control.

[0] False

Enters False in logic rule.

[1] True

Enters True in logic rule.

[2] Running

See parameter group 5-4* Relays [5] for description.

[3] InRange

See parameter group 5-4* Relays [7] for description.

[4] OnReference

See parameter group 5-4* Relays [8] for description.

[7] Out of Current

Range

See parameter group 5-4* Relays [12] for description.

[8] BelowILow

See parameter group 5-4* Relays [13] for description.

[9] AboveIHigh

See parameter group 5-4* Relays [14] for description.

[16] ThermalWarning

See parameter group 5-4* Relays [21] for description.

[17] MainsOutOfRange Mains voltage is outside the

specified voltage range.

[18] Reversing

See parameter group 5-4* Relays [25]

for description. [19] Warning A warning is active. [20] Alarm_Trip A trip alarm is active. [21] Alarm_TripLock A trip lock alarm is active. [22] Comparator 0 Use result of comparator 0 in logic

rule. [23] Comparator 1 Use result of comparator 1 in logic

rule. [24] Comparator 2 Use result of comparator 2 in logic

rule. [25] Comparator 3 Use result of comparator 3 in logic

rule. [26] LogicRule 0 Use result of logic rule 0 in logic

rule. [27] LogicRule 1 Use result of logic rule 1 in logic

rule. [28] LogicRule 2 Use result of logic rule 2 in logic

rule. [29] LogicRule 3 Use result of logic rule 3 in logic

rule. [30] SL Timeout0 Use result of timer 0 in logic rule.

13-02 Stop Event

Option: Function:

[31] SL Timeout1 Use result of timer 1 in logic rule. [32] SL Timeout2 Use result of timer 2 in logic rule. [33] DigitalInput_18 Use value of DI 18 in logic rule. [34] DigitalInput_19 Use value of DI 19 in logic rule. [35] DigitalInput_27 Use value of DI 27 in logic rule. [36] DigitalInput_29 Use value of DI 29 in logic rule. [38] DigitalInput_33 [39] StartCommand

This event is True, if frequency converter is started by any means (digital input or other).

[40] * DriveStopped

This event is True, if frequency converter is stopped or coasted by any means (digital input or other).

13-03 Reset SLC

Option: Function:

[0] * Do Not Reset Retains all settings programmed in

parameter group 13.

[1] Reset SLC Reset all group 13 parameters to default

settings.

4.10.3 13-04 Comparators

Comparators are used for comparing continuous variables (i.e. output frequency, output current, analog input etc.) to fixed preset values.

Par. 13-11 Comparator Operator

TRUE longer than.

. . .

Par. 13-10 Comparator Operand

Par. 13-12 Comparator Value

130BD022.10

Illustration 4.11

In addition, there are digital values that will be compared to fixed time values. See explanation in 13-10 Comparator Operand. Comparators are evaluated once in each scan interval. Use the result (TRUE or FALSE) directly. All parameters in this parameter group are array parameters with index 0 to 5. Select index 0 toprogramme Comparator 0, select index 1 to programme Comparator 1, and so on.

13-10 Comparator Operand

Array [4]

Option: Function:

Select variable to be monitored by

comparator. [0] * Disabled Comparator is disabled. [1] Reference Resulting remote reference (not local) as a

percentage.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 41

4 4

13-10 Comparator Operand

Array [4]

Option: Function:

[2] Feedback Feedback in [Hz]. [3] MotorSpeed Motor speed in Hz. [4] MotorCurrent Motor current in [A]. [6] MotorPower Motor power in either [kW] or [hp]. [7] MotorVoltage Motor voltage in [V]. [8] DCLinkVoltage DC-link voltage in [V]. [12] AnalogInput53 Expressed as actual value. [13] AnalogInput60 Expressed as actual value. [18] PulseInput33 Expressed as actual value. [20] AlarmNumber Shows number of the alarm. [30] CounterA Number of counts. [31] CounterB Number of counts.

13-11 Comparator Operator

Array [4]

Option: Function:

Select operator to be used in comparison.

[0] Less Than <

Result of evaluation is True if variable selected in 13-10 Comparator Operand is smaller than fixed value in 13-12 Comparator Value. Result is False if variable selected in 13-10 Comparator Operand is greater than fixed value in 13-12 Comparator Value.

[1] * Approxi-

mately equals

≈

Result of evaluation is True if variable selected in 13-10 Comparator Operand is approximately equal to fixed value in 13-12 Comparator Value.

[2] Greater Than>Inverse logic of option [0].

13-12 Comparator Value

Array [4]

Range: Function:

0.0* [-9999-9999] Enter “trigger level” for variable monitored by this comparator.

4.10.4 13-2* Timers

Use the timer results to define an event (13-51 SL Controller

Action) or as boolean input in a logic rule (13-40 Logic Rule Boolean 1, 13-42 Logic Rule Boolean 2 or 13-44 Logic Rule Boolean 3).

When timer value has elapsed timer changes state from False to True.

13-20 SLC Controller Timer

Array [3]

Range: Function:

0.0 s* [0.0-3600 s]

Enter value to define duration of the False output from programmed timer. A timer is only False if it is started by an action and until the given timer value has elapsed.

4.10.5 13-4* Logic Rules

Combine up to three boolean inputs (TRUE/FALSE inputs) from timers, comtors, digital inputs, status bits and events using the logical operators AND, OR, and NOT. Select boolean inputs for the calculation in 13-40 Logic Rule

Boolean 1, 13-42 Logic Rule Boolean 2 and 13-44 Logic Rule Boolean 3. Define the operators used to logically combine the selected inputs in 13-41 Logic Rule Operator 1 and 13-43 Logic Rule Operator 2.

. . . . . .

Par. 13-43 Logic Rule Operator 2

Par. 13-41 Logic Rule Operator 1

Par. 13-40 Logic Rule Boolean 1

Par. 13-42 Logic Rule Boolean 2

Par. 13-44 Logic Rule Boolean 3

130BD023.10

Illustration 4.12

Priority of calculation The results of 13-40 Logic Rule Boolean 1, 13-41 Logic Rule Operator 1 and 13-42 Logic Rule Boolean 2 are calculated first. The outcome (TRUE/FALSE) of this calculation is combined with the settings of 13-43 Logic Rule Operator 2 and 13-44 Logic Rule Boolean 3, yielding the final result (TRUE/FALSE) of the logic rule.

13-40 Logic Rule Boolean 1

Array [4]

Option: Function:

Select first boolean input for selected logic rule.

[0] * False

Enters False in logic rule.

[1] True

Enters True in logic rule.

[2] Running

See parameter group 5-4* Relays [5] for description.

[3] InRange

See parameter group 5-4* Relays [7] for description.

[4] OnReference

See parameter group 5-4* Relays [8] for description.

[7] Out of Current

Range

See parameter group 5-4* Relays [12] for description.

[8] BelowILow

See parameter group 5-4* Relays [13] for description.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

42 MG02C602 - VLT® is a registered Danfoss trademark

13-40 Logic Rule Boolean 1

Array [4]

Option: Function:

[9] AboveIHigh

See parameter group 5-4* Relays [14] for description.

[16] ThermalWarning

See parameter group 5-4* Relays [21] for description.

[17] MainsOutOfRange Mains voltage is outside the specified

voltage range.

[18] Reversing

See parameter group 5-4* Relays [25]

for description. [19] Warning A warning is active. [20] Alarm_Trip A trip alarm is active. [21] Alarm_TripLock A trip lock alarm is active. [22] Comparator 0 Use result of comparator 0 in logic

rule. [23] Comparator 1 Use result of comparator 1 in logic

rule. [24] Comparator 2 Use result of comparator 2 in logic

rule. [25] Comparator 3 Use result of comparator 3 in logic

rule. [26] LogicRule 0 Use result of logic rule 0 in logic rule. [27] LogicRule 1 Use result of logic rule 1 in logic rule. [28] LogicRule 2 Use result of logic rule 2 in logic rule. [29] LogicRule 3 Use result of logic rule 3 in logic rule. [30] SL Timeout0 Use result of timer 0 in logic rule. [31] SL Timeout1 Use result of timer 1 in logic rule. [32] SL Timeout2 Use result of timer 2 in logic rule. [33] DigitalInput_18 Use value of DI 18 in logic rule. [34] DigitalInput_19 Use value of DI 19 in logic rule. [35] DigitalInput_27 Use value of DI 27 in logic rule. [36] DigitalInput_29 Use value of DI 29 in logic rule. [38] DigitalInput_33 Use value of DI 33 in logic rule [39] StartCommand

This event is True, if frequency

converter is started by any means

(digital input or other). [40] DriveStopped

This event is True, if frequency

converter is stopped or coasted by

any means (digital input or other).

13-41 Logic Rule Operator 1

Array [4]

Option: Function:

Select first logical operator to use on boolean inputs from 13-40 Logic Rule Boolean 1 and 13-42 Logic Rule Boolean 2.

[0] * Disabled

Ignores 13-42 Logic Rule Boolean 2, 13-43 Logic

Rule Operator 2 and 13-44 Logic Rule Boolean

[1] And Evaluates expression [13-40] AND [13-42]. [2] Or Evaluates expression [13-40] OR [13-42]. [3] And not Evaluates expression [13-40] AND NOT [13-42]. [4] Or not Evaluates expression [13-40] OR NOT [13-42]. [5] Not and Evaluates expression NOT [13-40] and [13-42].

13-41 Logic Rule Operator 1

Array [4]

Option: Function:

[6] Not or Evaluates expression NOT [13-40] OR [13-42]. [7] Not and not Evaluates expression NOT [13-40] AND NOT

[13-42].

[8] Not or not Evaluates expression NOT [13-40] OR NOT

[13-42].

13-42 Logic Rule Boolean 2

Array [4]

Option: Function:

Select second boolean input for selected logic rule. See 13-40 Logic Rule Boolean 1 for choices and descriptions.

13-43 Logic Rule Operator 2

Array [4]

Option: Function:

Select second logical operator to use on boolean inputs calculated in 13-40 Logic Rule

Boolean 1, 13-41 Logic Rule Operator 1, and 13-42 Logic Rule Boolean 2 and the boolean

input from 13-42 Logic Rule Boolean 2.

[0] * Disabled

Ignores 13-44 Logic Rule Boolean 3.

[1] And Evaluates expression [13-40/13-42] AND

[13-44]. [2] Or Evaluates expression [13-40/13-42] OR [13-44]. [3] And not Evaluates expression [13-40/13-42] AND NOT

[13-44]. [4] Or not Evaluates expression [13-40/13-42] OR NOT

[13-44]. [5] Not and Evaluates expression NOT [13-40/13-42] and

[13-44]. [6] Not or Evaluates expression NOT [13-40/13-42] OR

[13-44]. [7] Not and not Evaluates expression NOT [13-40/13-42] AND

NOT [13-44]. [8] Not or not Evaluates expression NOT [13-40/13-42] OR

NOT [13-44].

13-44 Logic Rule Boolean 3

Array [4]

Option: Function:

Select third boolean input for selected logic rule. See 13-40 Logic Rule Boolean 1 for choices and descriptions.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 43

4 4

4.10.6 13-5* States

13-51 SL Controller Event

Array [20]

Option: Function:

Select boolean input to define Smart Controller Event. See 13-40 Logic Rule Boolean 1 for choices and descriptions.

13-52 SL Controller Action

Array [20]

Option: Function:

Select action corresponding to SLC event. Actions are executed when corresponding event (13-51 SL Controller Event) is evaluated as True.

[0] * Disabled Function is disabled. [1] No Action No action is taken. [2] Select Set-up1 Changes active set-up to Set-up 1. [3] Select Set-up2 Changes active set-up to Set-up 2. [10] SelectPresetRef0 Selects preset reference 0 [11] SelectPresetRef1 Selects preset reference 1 [12] SelectPresetRef2 Selects preset reference 2 [13] SelectPresetRef3 Selects preset reference 3 [14] SelectPresetRef4 Selects preset reference 4 [15] SelectPresetRef5 Selects preset reference 5 [16] SelectPresetRef6 Selects preset reference 6 [17] SelectPresetRef7 Selects preset reference 7 [18] SelectRamp1 Selects ramp 1 [19] SelectRamp2 Selects ramp 2 [22] Run Issues start command to frequency

converter.

[23] RunReverse Issues start reverse command to

frequency converter.

[24] Stop Issues stop command to frequency

converter.

[25] Qstop Issues quick stop command to frequency

converter.

[26] DCstop Issues DC stop command to frequency

converter.

[27] Coast frequency converter coasts immediately.

All stop commands including coast

command stop the SLC. [28] Freeze Output Freezes output frequency. [29] StartTimer0 Starts timer 0. [30] StartTimer1 Starts timer 1 [31] StartTimer2 Starts timer 2 [32] SetDO42Low Set Digital output 42 low. [33] SetRelayLow Set Relay low. [38] SetDO42High Set Digital output 42 high. [39] SetRelayHigh Set Relay high. [60] ResetCounterA Resets counter A to 0. [61] ResetCounterB Resets counter B to 0.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

44 MG02C602 - VLT® is a registered Danfoss trademark

4.11 Parameter Group 14: Special Functions

4.11.1 14-** Special Functions

Parameter group for configuring special frequency converter functions.

4.11.2 14-0* Inverter Switching

14-01 Switching Frequency

Option: Function:

Select the switching frequency in order to minimize e.g. acoustic noise and power loss or

maximizing efficiency. [0] 2 KHz [1] * 4 KHz [2] 8 KHz [4] 16 KHz

NOTE

For 18.5 kW and 22 kW frequency converter, the option [4] is not available.

14-03 Overmodulation

Option: Function:

This feature allows more accurate speed control near and over nominal speed (50/60 Hz). Another advantage with overmodulation is the ability of staying at a constant speed even though main is dropping.

[0] Off Disables the overmodulation function to avoid torque

ripple on the motor shaft.

[1] * On Connects the overmodulation function to obtain an

output voltage up to 15% greater than mains voltage.

4.11.3 14-1* Mains Monitoring

This parameter group supplies functions for handling imbalance on mains.

14-12 Functions at Mains Imbalance

Option: Function:

Operation under severe mains imbalance conditions reduces drive lift time. Select function to take place when severe mains

imbalance is detected. [0] * Trip Frequency converter trips. [1] Warning Frequency converter issues a warning. [2] Disabled No action taken.

Parameters for configuring auto reset handling, special trip handling and control card self test or initialisation.

14-20 Reset Mode

Option: Function:

Select reset function after tripping. Once reset, the frequency converter can be

restarted. [0] * Manual Reset Perform reset via [Reset] or digital inputs. [1] AutoReset 1 Performs one automatic reset after

tripping. [2] AutoReset 2 Performs two automatic resets after

tripping. [3] AutoReset 3 Performs three automatic resets after

tripping. [4] AutoReset 4 Performs four automatic resets after

tripping. [5] AutoReset 5 Performs five automatic resets after

tripping. [6] AutoReset 6 Performs six automatic resets after

tripping. [7] AutoReset 7 Performs seven automatic resets after

tripping. [8] AutoReset 8 Performs eight automatic resets after

tripping. [9] AutoReset 9 Performs nine automatic resets after

tripping. [10] AutoReset 10 Performs ten automatic resets after

tripping. [11] AutoReset 15 Performs fifteen automatic resets after

tripping. [12] AutoReset 20 Performs twenty automatic resets after

tripping. [13] Infinite auto

reset

Performs an infinite number of automatic

resets after tripping. [14] Reset at

power-up

Trip-lock alarm can be reset at power up.

CAUTION

Motor may start without warning.

14-21 Automatic Restart Time

Range: Function:

10 s* [0-600 s] Enter time interval from trip to start of

automatic reset function. This parameter is active when 14-20 Reset Mode, is set to [1] to [13] Automatic Reset.

14-22 Operation Mode

Option: Function:

Use this parameter for specifying normal operation or to initialize all parameters, except 15-03 Power Ups, 15-04 Over Temps and 15-05 Over Volts.

[0] * Normal

Operation

Frequency converter runs normal operation.

[2] Initialization Resets all parameters to default settings,

except for 15-03 Power Ups, 15-04 Over Temps and 15-05 Over Volts. Frequency converter resets during next power-up.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 45

4 4

14-22 Operation Mode

Option: Function:

14-22 Operation Mode also reverts to default setting [0] Normal Operation.

14-26 Action at Inverter Fault

Option: Function:

[0] Trip When the frequency converter detects an over-

voltage, it will trip immediately.

NOTE

It is recommended to choose [0] Trip in hoisting applications.

[1] * Warning When the frequency converter detects an over-

voltage, it will give warning immediately. After protection filter, it will trip.

NOTE

It is recommended to disable protection mode in hoisting applications.

4.11.4 15-4* Drive Identification

Parameters containing read only information about the hardware and software configuration of the frequency converter.

14-41 AEO Minimum Magnetization

Range: Function:

66%* [40-75%] Enter the minimum allowable magnetization

for AEO. Selecting a low value reduces energy loss in the motor, but may also reduce resistance to sudden load changes.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

46 MG02C602 - VLT® is a registered Danfoss trademark

4.12 Parameter Group 15: Drive Information

Parameter group containing information on operating data, hardware configuration, software version, etc.

15-00 Operating Time

Range: Function:

0 days* [0-65535

days]

View how many days the frequency converter has been powered up. The value is saved at power off and cannot be reset.

15-01 Running Hours

Range: Function:

0* [0- 2147483647] View running hours of motor.

The value is saved at power off and can be reset in 15-07 Reset Running Hours Counter.

15-02 kWh Counter

Range: Function:

0 [0-65535] View power consumption in kWh as a mean value

over one hour. Reset counter in 15-06 Reset kWh Counter.

15-03 Power Ups

Range: Function:

0 [0-2147483647] View number of times frequency converter

has been powered up. Counter cannot be reset.

15-04 Over Temps

Range: Function:

0 [0-65535] View number of times frequency converter has

tripped due to over temperature. Counter cannot be reset.

15-05 Over Volts

Range: Function:

0* [0-65535] View number of times frequency converter has

tripped due to over voltage. Counter cannot be reset.

15-06 Reset kWh Counter

Option: Function:

[0] * Do Not Reset Counter is not reset. [1] Reset Counter Counter is reset.

15-07 Reset Running Hours Counter

Option: Function:

[0] * Do Not Reset Counter is not reset. [1] Reset Counter Counter is reset.

4.12.1 15-3* Fault Log

This parameter group contains a fault log showing reasons for the ten latest trips.

15-30 Fault Log: Error Code

Range: Function:

0 [0-255]

View error code and look it up in VLT Micro Quick Guide, MG02B.

4.12.2 15-4* Drive Identification

Parameters containing read only information about the hardware and software configuration of the frequency converter.

15-40 FC Type

Option: Function:

View FC type.

15-41 Power Section

Option: Function:

View power section of frequency converter.

15-42 Voltage

Option: Function:

View voltage of frequency converter.

15-43 Software Version

Option: Function:

View software version of frequency converter.

15-46 Frequency Converter Ordering No

Option: Function:

View ordering number for re-ordering frequency converter in its original configuration.

15-48 LCP ID No

Option: Function:

View LCP ID number.

15-51 Frequency Converter Serial Number

Option: Function:

View frequency converter serial number.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 47

4 4

4.13 Parameter Group 16: Data Readouts

16-00 Control Word

Range: Function:

0* [0-65535] View latest valid control word sent to frequency

converter via serial communication port.

16-01 Reference [Unit]

Range: Function:

0.000* [-4999.000-4999.000] View total remote reference. Total reference is sum of pulse, analog, preset, LCP potentiometer, local bus and freeze reference.

16-02 Reference %

Range: Function:

0.0* [-200.0-200.0%] View total remote reference in percent.

Total reference is sum of pulse, analog, preset, LCP potentiometer, local bus and freeze reference.

16-03 Status Word

Range: Function:

0* [0-65535] View status word sent to frequency converter via

serial communication port.

16-05 Main Actual Value %

Range: Function:

0.00* [-100.00-100.00%] View two-byte word sent with status

word to bus Master reporting main actual value.

16-09 Custom Readout

Range: Function:

0.00* [0.00-9999.00%]

Customized readout based on the settings of 0-31 Custom Readout Min Scale, 0-32 Custom Readout Max Scale and 4-14 Motor Speed High Limit

4.13.1 16-1* Motor Status

16-10 Power [kW]

Range: Function:

0 kW* [0-99 kW] View output power in kW.

16-11 Power [hp]

Range: Function:

0 hp [0-99 hp ] View output power in hp.

16-12 Motor Voltage

Range: Function:

0.0* [0.0-999.9 V] View motor phase voltage.

16-13 Frequency

Range: Function:

0.0 Hz* [0.0-400.0 Hz] View output frequency in Hz.

16-14 Motor Current

Range: Function:

0.00 A* [0.00-655 A] View motor phase current.

16-15 Frequency [%]

Range: Function:

0.00* [-100.00-100.00%] View a two-byte word reporting actual motor frequency as a percentage of

4-14 Motor Speed High Limit

16-18 Motor Thermal

Range: Function:

0%* [0-100%] View calculated thermal motor load as

percentage of estimated thermal motor load.

4.13.2 16-3* Drive Status

16-30 DC Link Voltage

Range: Function:

0 V* [0-10000 V] View DC-link voltage.

16-34 Heat Sink Temp.

Range: Function:

[0-255°C]

View heat sink temperature of frequency converter.

16-35 Inverter Thermal

Range: Function:

0%* [0-100%] View calculated thermal load on frequency

converter in relation to estimated thermal load on frequency converter.

16-36 Inv. Nom. Current

Range: Function:

0.00 A* [0.01-655A] View continuous nominal inverter current.

16-37 Inv. Max. Current

Range: Function:

0.00 A* [0.1-655A] View intermittent maximum inverter current

(150%).

16-38 SL Controller State

Range: Function:

0* [0-255] View number of active SLC state.

4.13.3 16-5* Ref. & Feedb.

16-50 External Reference

Range: Function:

0.0%* [-200.0-200.0%] View sum of all external references in

percent.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

48 MG02C602 - VLT® is a registered Danfoss trademark

16-51 Pulse Reference

Range: Function:

0.0 %* [-200.0-200.0%] View actual pulse input converted to a reference in percent.

16-52 Feedback

Range: Function:

0.000* [-4999.000-4999.000] View analog or pulse feedback in

Hz.

4.13.4 16-6* Inputs and Outputs

16-60 Digital Input 18, 19, 27, 33

Range: Function:

0* [0-1111] View signal states from active digital inputs.

16-61 Digital Input 29

Range: Function:

0* [0-1] View signal state on digital input 29.

16-62 Analog Input 53 (volt)

Range: Function:

0.00* [0.00-10.00 V] View input voltage on analog input

terminal.

16-63 Analog Input 53 (current)

Range: Function:

0.00* [0.00-20.00 mA] View input current on analog input

terminal.

16-64 Analog Input 60

Range: Function:

0.00* [0.00-20.00 mA] View actual value at input 60 either as

reference or protection value.

16-65 Analog Output 42 [mA]

Range: Function:

0.00 mA* [0.00-20.00 mA] View output current on analog

output 42.

16-68 Pulse Input

Range: Function:

20 Hz* [20-5000 Hz] View input frequency on pulse input

terminal.

16-71 Relay Output [bin]

Range: Function:

0* [0-1] View relay setting.

16-72 Counter A

Range: Function:

0* [-32768-32767] View present value of Counter A.

16-73 Counter B

Range: Function:

0* [-32768-32767] View present value of Counter B.

4.13.5 16-8* FC Port

Parameter for viewing references from FC Port.

16-86 FC Port REF 1

Range: Function:

0* [0x8000-0x7FFF] View currently received reference from FC

Port.

4.13.6 16-9* Diagnosis Read-Outs

16-90 Alarm Word

Range: Function:

0* [0-0xFFFFFFFF] Via alarm word sent via serial communi-

cation port in hex code.

16-92 Warning Word

Range: Function:

0* [0-0xFFFFFFFF] View warning word sent via serial communi-

cation port in hex code.

16-94 Ext. Status Word

Range: Function:

0* [0-0xFFFFFFFF] View extended warning word sent via serial

communication port in hex code.

Parameter Descriptions

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 49

4 4

5 Parameter Lists

Parameter Overview

0-** Operation/Display 0-0/ Basic Settings

0-03 Regional Settings *[0] International [1] US 0-04 Oper. State at Power-up (Hand) [0] Resume [1] Forced stop, ref=f”old [2] Forced stop, re=0

0-1* Set-up Handling

0-10 Active Set-up *[1] Setup 1 [2] Setup 2 [9] Multi Setup 0-11 Edit Set-up *[1] Setup 1 [2] Setup 2 [9] Active Setup 0-12 Link Setups [0] Not Linked *[20] Linked 0-31 Custom Readout Min Scale

0.00–9999.00

*0.00 0-32 Custom Readout Max Scale

0.00–9999.00

*100.0

0-4* LCP Keypad

0-40 [Hand on] Key on LCP [0] Disabled *[1] Enabled 0-41 [Off / Reset] Key on LCP [0] Disable All *[1] Enable All [2] Enable Reset Only 0-42 [Auto on] Key on LCP [0] Disabled *[1] Enabled

0-5* Copy/Save

0-50 LCP Copy *[0] No copy [1] All to LCP [2] All from LCP [3] Size indep. from LCP 0-51 Set-up Copy *[0] No copy [1] Copy from setup 1 [2] Copy from setup 2 [9] Copy from Factory setup

0-6* Password

0-60 (Main) Menu Password 0-999 *0 0-61 Access to Main/Quick Menu w/o Password *[0] Full access [1] LCP: Read Only [2] LCP: No Access

1-** Load/Motor 1-0* General Settings

1-00 Configuration Mode *[0] Speed open loop [3] Process 1-01 Motor Control Principle [0] U/f *[1] VVC

plus

1-03 Torque Characteristics *[0] Constant torque [2] Automatic Energy Optim. 1-05 Local Mode Configuration [0] Speed Open Loop *[2] As config in par. 1-00

1-2* Motor Data

1-20 Motor Power [kW] [HP] [1] 0.09 kW/0.12 HP [2] 0.12 kW/0.16 HP [3] 0.18 kW/0.25 HP [4] 0.25 kW/0.33 HP [5] 0.37 kW/0.50 HP [6] 0.55 kW/0.75 HP [7] 0.75 kW/1.00 HP [8] 1.10 kW/1.50 HP [9] 1.50 kW/2.00 HP [10] 2.20 kW/3.00 HP [11] 3.00 kW/4.00 HP [12] 3.70 kW/5.00 HP [13] 4.00 kW/5.40 HP [14] 5.50 kW/7.50 HP [15] 7.50 kW/10.00 HP [16] 11.00 kW/15.00 HP [17] 15.00 kW/20.00 HP [18] 18.50 kW/25.00 HP [19] 22.00 kW/29.50 HP [20] 30.00 kW/40.00 HP 1-22 Motor Voltage 50-999 V * 230-400 V 1-23 Motor Frequency 20-400 Hz *50 Hz 1-24 Motor Current

0.01-100.00 A *Motortype dep. 1-25 Motor Nominal Speed 100-9999 rpm * Motortype dep.

1-29 Automatic Motor Tuning (AMT) *[0] Off [2] EnableAMT

1-3* Adv. Motor Data

1-30 Stator Resistance (Rs) [Ohm] * Dep. on motor data 1-33 Stator Leakage Reactance (X1) [Ohm] * Dep. on motor data 1-35 Main Reactance (Xh) [Ohm] * Dep. on motor data

1-5* Load Indep. Setting

1-50 Motor Magnetisation at 0 Speed 0-300% *100% 1-52 Min Speed Norm. Magnet. [Hz]

0.0-10.0 Hz *0.0 Hz 1-55 U/f Characteristic - U 0-999.9 V 1-56 U/f Characteristic - F 0-400 Hz

1-6* Load Depen. Setting

1-60 Low Speed Load Compensation 0-199% Load CompensationLoad Compensation *100% 1-61 High Speed Load Compensation 0-199% *100% 1-62 Slip Compensation

-400-399% *100% 1-63 Slip Compensation Time Constant

0.05-5.00 s *0.10 s

1-7* Start Adjustments

1-71 Start Delay

0.0-10.0 s * 0.0 s 1-72 Start Function [0] DC hold/delay time [1] DC brake/delay time *[2] Coast/delay time 1-73 Flying Start *[0] Disabled [1] Enabled

1-8* Stop Adjustments

1-80 Function at Stop *[0] Coast [1] DC hold

1-82 Min Speed for Funct. at Stop [Hz]

0.0-20.0 Hz *0.0 Hz

1-9* Motor Temperature

1-90 Motor Thermal Protection *[0] No protection [1] Thermistor warning [2] Thermistor trip [3] Etr warning [4] Etr trip 1-93 Thermistor Resource *[0] None [1] Analog input 53 [6] Digital input 29

2-** Brakes 2-0* DC-Brake

2-00 DC Hold Current 0-150% *50% 2-01 DC Brake Current 0-150% *50% 2-02 DC Braking Time

0.0-60.0 s *10.0 s 2-04 DC Brake Cut In Speed

0.0-400.0 Hz * 0.0 Hz

2-1* Brake Energy Funct.

2-10 Brake Function *[0] Off [1] Resistor brake [2] AC brake 2-11 Brake Resistor (ohm) 5-5000 *5 2-16 AC Brake, Max current 0-150% *100% 2-17 Over-voltage Control *[0] Disabled [1] Enabled (not at stop) [2] Enabled

2-2* Mechanical Brake

2-20 Release Brake Current

0.00-100.0 A *0.00 A 2-22 Activate Brake Speed [Hz]

0.0-400.0 Hz * 0.0 Hz

3-** Reference / Ramps 3-0* Reference Limits

3-00 Reference Range *[0] Min to Max [1] -Max to+Max 3-02 Minimum Reference

-4999-4999 *0.000 3-03 Maximum Reference

-4999-4999 *50.00

Table 5.1

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

50 MG02C602 - VLT® is a registered Danfoss trademark

3-1* References

3-10 Preset Reference

-100.0-100.0% *0.00%

3-11 Jog Speed [Hz]

0.0-400.0 Hz *5.0 Hz

3-12 Catch up/slow Down Value

0.00-100.0% *0.00%

3-14 Preset Relative Reference

-100.0-100.0% *0.00%

3-15 Reference Resource 1 [0] No function *[1] Analog Input 53 [2] Analog input 60 [8] Pulse input 33 [11] Local bus ref [21] LCP Potentiometer 3-16 Reference Resource 2 [0] No function [1] Analog Input 53 *[2] Analog input 60 [8] Pulse input 33 *[11] Local bus ref [21] LCP Potentiometer 3-17 Reference Resource 3 [0] No function [1] Analog Input 53 [2] Analog input 60 [8] Pulse input 33 *[11] Local bus ref [21] LCP Potentiometer 3-18 Relative Scaling Ref. Resource *[0] No function [1] Analog Input 53 [2] Analog input 60 [8] Pulse input 33 [11] Local bus ref [21] LCP Potentiometer

3-4* Ramp 1

3-40 Ramp 1 Type *[0] Linear [2] Sine2 ramp 3-41 Ramp 1 Ramp up Time

0.05-3600 s *3.00 s (10.00 s1))

3-42 Ramp 1 Ramp Down Time

0.05-3600 s *3.00 s (10.00 s 1))

3-5* Ramp 2

3-50 Ramp 2 Type *[0] Linear [2] Sine2 ramp 3-51 Ramp 2 Ramp up Time

0.05-3600 s *3.00 s (10.00 s 1))

3-52 Ramp 2 Ramp down Time

0.05-3600 s *3.00 s (10.00 s1))

3-8* Other Ramps

3-80 Jog Ramp Time

0.05-3600 s *3.00 s (10.00 s1)) 3-81 Quick Stop Ramp Time

0.05-3600 s *3.00 s(10.00 s1))

4-** Limits/Warnings 4-1* Motor Limits

4-10 Motor Speed Direction [0] Clockwise if Par. 1-00 is set to [3] [1] CounterClockwise *[2] Both if Par. 1-00 is set to [0] 4-12 Motor Speed Low Limit [Hz]

0.0-400.0 Hz * 0.0 Hz 4-14 Motor Speed High Limit [Hz]

0.1-400.0 Hz *65.0 Hz 4-16 Torque Limit Motor Mode 0-400% *150% 4-17 Torque Limit Generator Mode 0-400% *100%

4-4* Adj. Warnings 2

4-40 Warning Frequency Low

0.00-Value of 4-41 Hz *0.0 Hz 4-41 Warning Frequency High Value of 4-40-400.0 Hz *400.0 Hz

4-5* Adj. Warnings

4-50 Warning Current Low

0.00-100.00 A *0.00 A 4-51 Warning Current High

0.00-100.00 A *100.00 A 4-54 Warning Reference Low

-4999.000-Value of 4-55 *-4999.000 4-55 Warning Reference High Value of 4-54-4999.000 *4999.000 4-56 Warning Feedback Low

-4999.000-Value of 4-57 *-4999.000 4-57 Warning Feedback High Value of 4-56-4999.000 *4999.000 4-58 Missing Motor Phase Function [0] Off *[1] On

4-6* Speed Bypass

4-61 Bypass Speed From [Hz]

0.0-400.0 Hz * 0.0 Hz 4-63 Bypass Speed To [Hz]

0.0-400.0 Hz * 0.0 Hz

5-1* Digital Inputs

5-10 Terminal 18 Digital Input [0] No function

[1] Reset [2] Coast inverse [3] Coast and reset inv. [4] Quick stop inverse [5] DC-brake inv. [6] Stop inv *[8] Start [9] Latched start [10] Reversing [11] Start reversing [12] Enable start forward [13] Enable start reverse [14] Jog [16-18] Preset ref bit 0-2 [19] Freeze reference [20] Freeze output [21] Speed up [22] Speed down [23] Setup select bit 0 [28] Catch up [29] Slow down [34] Ramp bit 0 [60] Counter A (up) [61] Counter A (down) [62] Reset counter A [63] Counter B (up) [64] Counter B (down) [65] ResetCounter B 5-11 Terminal 19 Digital Input See par. 5-10. *[10] Reversing 5-12 Terminal 27 Digital Input See par. 5-10. * [1] Reset 5-13 Terminal 29 Digital Input See par. 5-10. * [14] Jog 5-15 Terminal 33 Digital Input See par. 5-10. * [16] Preset ref bit 0 [26] Precise Stop Inverse [27] Start, Precise Stop [32] Pulse Input

5-3* Digital Outputs

5-34 On Delay, Terminal 42 Digital Output

0.00-600.00 s *0.01 s 5-35 Off Delay, Terminal 42 Digital Output

0.00-600.00 s *0.01 s

5-4* Relays

5-40 Function Relay *[0] No operation [1] Control ready [2] Drive ready [3] Drive ready, Remote

[4] Enable/No warning [5] Drive running [6] Running/No warning [7] Run in range/No warning [8] Run on ref/No warning [9] Alarm [10] Alarm or warning [12] Out of current range [13] Below current, low [14] Above current, high [16] Below frequency, low [17] Above frequency, high [19] Below feedback, low [20] Above feedback, high [21] Thermal warning [22] Ready, No thermal warning [23] Remote ready, No thermal warning [24] Ready, Voltage ok [25] Reverse [26] Bus ok [28] Brake,NoWarn [29] Brake ready/NoFault [30] BrakeFault (IGBT) [32] Mech.brake control [36] Control word bit 11 [41] Below reference, low [42] Above reference, high [51] Local ref. active [52] Remote ref. active [53] No alarm [54] Start cmd active [55] Running reverse [56] Drive in hand mode [57] Drive in auto mode [60-63] Comparator 0-3 [70-73] Logic rule 0-3 [81] SL digital output B 5-41 On Delay, Relay

0.00-600.00 s *0.01 s 5-42 Off Delay, Relay

0.00-600.00 s *0.01 s

5-5* Pulse Input

5-55 Terminal 33 Low Frequency 20-4999 Hz * 20 Hz 5-56 Terminal 33 High Frequency 21-5000 Hz *5000 Hz 5-57 Term. 33 Low Ref./Feedb. Value

-4999-4999 *0.000 5-58 Term. 33 High Ref./Feedb. Value

-4999-4999 *50.000

6-** Analog In/Out

M4 and M5 only

Table 5.2

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 51

5 5

6-0* Analog I/O Mode

6-00 Live Zero Timeout Time 1-99 s *10 s 6-01 Live Zero TimeoutFunction *[0] Off [1] Freeze output [2] Stop [3] Jogging [4] Max speed [5] Stop and trip

6-1* Analog Input 1

6-10 Terminal 53 Low Voltage

0.00-9.99 V *0.07 V

6-11 Terminal 53 High Voltage

0.01-10.00 V *10.00 V

6-12 Terminal 53 Low Current

0.00-19.99 mA *0.14 mA

6-13 Terminal 53 High Current

0.01-20.00 mA *20.00 mA

6-14 Term. 53 Low Ref./Feedb. Value

-4999-4999 *0.000

6-15 Term. 53 High Ref./Feedb. Value

-4999-4999 *50.000

6-16 Terminal 53 Filter Time Constant

0.01-10.00 s *0.01 s

6-19 Terminal 53 mode *[0] Voltage mode [1] Current mode

6-2* Analog Input 2

6-22 Terminal 60 Low Current

0.00-19.99 mA *0.14 mA

6-23 Terminal 60 High Current

0.01-20.00 mA *20.00 mA

6-24 Term. 60 Low Ref./Feedb. Value

-4999-4999 *0.000

6-25 Term. 60 High Ref./Feedb. Value

-4999-4999 *50.00

6-26 Terminal 60 Filter Time Constant

0.01-10.00 s *0.01 s

6-8* LCP potentiometer

6-80 LCP LCP Potmeter Enable [0] Disabled [1] * Enable 6-81 LCP potm. Low Reference

-4999-4999 *0.000

6-82 LCP potm. High Reference

-4999-4999 *50.00

6-9* Analog Output xx

6-90 Terminal 42 Mode *[0] 0-20 mA

[1] 4-20 mA [2] Digital Output 6-91 Terminal 42 Analog Output *[0] No operation [10] Output Frequency [11] Reference [12] Feedback [13] Motor Current [16] Power [20] Bus Reference 6-92 Terminal 42 Digital Output See par. 5-40 *[0] No Operation [80] SL Digital Output A 6-93 Terminal 42 Output Min Scale

0.00-200.0% *0.00% 6-94 Terminal 42 Output Max Scale

0.00-200.0% *100.0%

7-** Controllers 7-2* Process Ctrl. Feedb

7-20 Process CL Feedback 1 Resource *[0] NoFunction [1] Analog Input 53 [2] Analog input 60 [8] PulseInput33 [11] LocalBusRef

7-3* Process PI

Ctrl. 7-30 Process PI Normal/ Inverse Ctrl *[0] Normal [1] Inverse 7-31 Process PI Anti Windup [0] Disable *[1] Enable 7-32 Process PI Start Speed

0.0-200.0 Hz *0.0 Hz 7-33 Process PI Proportional Gain

0.00-10.00 *0.01 7-34 Process PI Integral Time

0.10-9999 s *9999 s 7-38 Process PI Feed Forward Factor 0-400% *0% 7-39 On Reference Bandwidth 0-200% *5%

8-** Comm. and Options 8-0* General Settings

8-01 Control Site *[0] Digital and ControlWord [1] Digital only [2] ControlWord only

8-02 Control Word Source [0] None *[1] FC RS485 8-03 Control Word Timeout Time

0.1-6500 s *1.0 s 8-04 Control Word Timeout Function *[0] Off [1] Freeze Output [2] Stop [3] Jogging [4] Max. Speed [5] Stop and trip 8-06 Reset Control Word Timeout *[0] No Function [1] Do reset

8-3* FC Port Settings

8-30 Protocol *[0] FC [2] Modbus 8-31 Address 1-247 *1 8-32 FC Port Baud Rate [0] 2400 Baud [1] 4800 Baud *[2] 9600 Baud For choosing FC bus in 8-30 * [3] 19200 Baud For choosing FC bus in 8-30 *[4] 38400 Baud 8-33 FC Port Parity *[0] Even Parity, 1 Stop Bit [1] Odd Parity, 1 Stop Bit [2] No Parity, 1 Stop Bit [3] No Parity, 2 Stop Bits 8-35 Minimum Response Delay

0.001-0.5 *0.010 s 8-36 Max Response Delay

0.100-10.00 s *5.000 s 8-4* FC MC protocol set 8-43 FC Port PCD Read Configuration *[0] None Expressionlimit [1] [1500] Operation Hours [2] [1501] Running Hours [3] [1502] kWh Counter [4] [1600] Control Word [5] [1601] Reference [Unit] [6] [1602] Reference % [7] [1603] Status Word [8] [1605] Main Actual Value [%] [9] [1609] Custom Readout [10] [1610] Power [kW] [11] [1611] Power [hp] [12] [1612] Motor Voltage

[13] [1613] Frequency [14] [1614] Motor Current [15] [1615] Frequency [%] [16] [1618] Motor Thermal [17] [1630] DC Link Voltage [18] [1634] Heatsink Temp. [19] [1635] Inverter Thermal [20] [1638] SL Controller State [21] [1650] External Reference [22] [1651] Pulse Reference [23] [1652] Feedback [Unit] [24] [1660] Digital Input 18,19,27,33 [25] [1661] Digtial Input 29 [26] [1662] Analog Input 53(V) [27] [1663] Analog Input 53(mA) [28] [1664] Analog Input 60 [29] [1665] Analog Output 42 [mA] [30] [1668] Freq. Input 33 [Hz] [31] [1671] Relay Output [bin] [32] [1672] Counter A [33] [1673] Counter[34] [1690] Alarm Word [34] [1690] Alarm Word [35] [1692] Warning Word [36] [1694] Ext. Status Word

8-5* Digital/Bus

8-50 Coasting Select [0] DigitalInput [1] Bus [2] LogicAnd *[3] LogicOr 8-51 Quick Stop Select See par. 8-50 * [3] LogicOr 8-52 DC Brake Select See par. 8-50 * [3] LogicOr 8-53 Start Select See par. 8-50 * [3] LogicOr 8-54 Reversing Select See par. 8-50 * [3] LogicOr 8-55 Set-up Select See par. 8-50 * [3] LogicOr 8-56 Preset Reference Select See par. 8-50 * [3] LogicOr

8-8X Bus communication Diagnostics

8-80 Bus Message Count 0-0 N/A *0 N/A 8-81 Bus Error Count 0-0 N/A *0 N/A 8-82 Slave Messages Rcvd 0-0 N/A *0 N/A 8-83 Slave Error Count 0-0 N/A *0 N/A

Table 5.3

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

52 MG02C602 - VLT® is a registered Danfoss trademark

8-9* Bus Jog / Feedback

8-94 Bus feedback 1 0x8000-0x7FFF *0

13-** Smart Logic 13-0* SLC Settings

13-00 SL Controller Mode *[0] Off [1] On 13-01 Start Event [0] False [1] True [2] Running [3] InRange [4] OnReference [7] OutOfCurrentRange [8] BelowILow [9] AboveIHigh [16] ThermalWarning [17] MainOutOfRange [18] Reversing [19] Warning [20] Alarm_Trip [21] Alarm_TripLock [22-25] Comparator 0-3 [26-29] LogicRule0-3 [33] DigitalInput_18 [34] DigitalInput_19 [35] DigitalInput_27 [36] DigitalInput_29 [38] DigitalInput_33 *[39] StartCommand [40] DriveStopped 13-02 Stop Event See par. 13-01 * [40] DriveStopped 13-03 Reset SLC *[0] Do not reset [1] Reset SLC

13-1* Comparators

13-10 Comparator Operand *[0] Disabled [1] Reference [2] Feedback [3] MotorSpeed [4] MotorCurrent [6] MotorPower [7] MotorVoltage [8] DCLinkVoltage [12] AnalogInput53 [13] AnalogInput60 [18] PulseInput33 [20] AlarmNumber [30] CounterA [31] CounterB 13-11 Comparator Operator [0] Less Than

*[1] Approximately equals [2] Greater Than 13-12 Comparator Value

-9999-9999 *0.0

13-2* Timers

13-20 SL Controller Timer

0.0-3600 s *0.0 s

13-4* Logic Rules

13-40 Logic Rule Boolean 1 See par. 13-01 * [0] False [30]-[32] SL Time-out 0-2 13-41 Logic Rule Operator 1 *[0] Disabled [1] And [2] Or [3] And not [4] Or not [5] Not and [6] Not or [7] Not and not [8] Not or not 13-42 Logic Rule Boolean 2 See par. 13-40 13-43 Logic Rule Operator 2 See par. 13-41 * [0] Disabled 13-44 Logic Rule Boolean 3 See par. 13-40

13-5* States

13-51 SL Controller Event See par. 13-40 13-52 SL Controller Action *[0] Disabled [1] NoAction [2] SelectSetup1 [3] SelectSetup2 [10-17] SelectPresetRef0-7 [18] SelectRamp1 [19] SelectRamp2 [22] Run [23] RunReverse [24] Stop [25] Qstop [26] DCstop [27] Coast [28] FreezeOutput [29] StartTimer0 [30] StartTimer1 [31] StartTimer2 et Digital Output B High [32] Set Digital Output A Low [33] Set Digital Output B Low [38] Set Digital Output A High [39] Set Digital Output B High [60] ResetCounterA [61] ResetCounterB

14-** Special Functions 14-0*Inverter Switching

14-01 Switching Frequency [0] 2 kHz *[1] 4 kHz [2] 8 kHz [4] 16 kHz not available for M5 14-03 Overmodulation [0] Off *[1] On

14-1* Mains monitoring

14-12 Function at mains imbalance *[0] Trip [1] Warning [2] Disabled

14-2* Trip Reset

14-20 Reset Mode *[0] Manual reset [1-9] AutoReset 1-9 [10] AutoReset 10 [11] AutoReset 15 [12] AutoReset 20 [13] Infinite auto reset [14] Reset at power up 14-21 Automatic Restart Time 0-600 s * 10 s 14-22 Operation Mode *[0] Normal Operation [2] Initialisation 14-26 Action At Inverter Fault *[0] Trip [1] Warning

14-4* Energy Optimising

14-41 AEO Minimum Magnetisation 40-75% *66%

15-** Drive Information 15-0* Operating Data

15-00 Operating Days 15-01 Running Hours 15-02 kWh Counter 15-03 Power Ups 15-04 Over Temps 15-05 Over Volts 15-06 Reset kWh Counter *[0] Do not reset [1] Reset counter 15-07 Reset Running Hours Counter *[0] Do not reset [1] Reset counter

15-3* Fault Log

15-30 Fault Log: Error Code

15-4* Drive Identification

15-40 FC Type

15-41 Power Section 15-42 Voltage 15-43 Software Version 15-46 Frequency Converter Order. No 15-48 LCP Id No 15-51 Frequency Converter Serial No

16-** Data Readouts 16-0* General Status

16-00 Control Word 0-0XFFFF 16-01 Reference [Unit]

-4999-4999 16-02 Reference %

-200.0-200.0 % 16-03 Status Word 0-0XFFFF 16-05 Main Actual Value [%]

-200.0-200.0 % 16-09 Custom Readout Dep. on par. 0-31, 0-32 and 4-14

16-1* Motor Status

16-10 Power [kW] 16-11 Power [hp] 16-12 Motor Voltage [V] 16-13 Frequency [Hz] 16-14 Motor Current [A] 16-15 Frequency [%] 16-18 Motor Thermal [%]

16-3* Drive Status

16-30 DC Link Voltage 16-34 Heatsink Temp. 16-35 Inverter Thermal 16-36 Inv.Nom. Current 16-37 Inv. Max. Current 16-38 SL Controller State

16-5* Ref. / Feedb.

16-50 External Reference 16-51 Pulse Reference 16-52 Feedback [Unit]

16-6* Inputs/Outputs

16-60 Digital Input 18,19,27,33 0-1111 16-61 Digital Input 29 0-1 16-62 Analog Input 53 (volt) 16-63 Analog Input 53 (current) 16-64 Analog Input 60 16-65 Analog Output 42 [mA]16-68 Pulse Input [Hz] 16-71 Relay Output [bin] 16-72 Counter A 16-73 Counter B

16-8* Fieldbus/FC Port

16-86 FC Port REF 1 0x8000-0x7FFFF

Table 5.4

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 53

5 5

16-9* Diagnosis Readouts

16-90 Alarm Word 0-0XFFFFFFFF

16-92 Warning Word 0-0XFFFFFFFF 16-94 Ext. Status Word 0-0XFFFFFFFF

18-** Extended Motor Data 18-8* Motor Resistors

18-80 Stator Resistance (High resolution)

0.000-99.990 ohm *0.000 ohm

18-81 Stator Leakage Reactance (High resolution)

0.000-99.990 ohm *0.000 ohm

Table 5.5

5.1.1 Conversion Index

The various attributes of each parameter are displayed in the section Factory Settings. Parameter values are transferred as whole numbers only. Conversion factors are therefore used to transfer decimals according to Table 5.6.

Example:

1-24 Motor Current has a conversion index of -2 (i.e. conversion factor of 0.01 according to Table 5.6). To set the parameter to 2.25 A, transfer the value 225 via Modbus. The Conversion Factor of 0.01 means that the value transferred is multiplied by 0.01 in the frequency converter. The vale 225 transferred on the bus is thus perceived as

2.25 A in the frequency converter.

Conversion index Conversion factor 2 10 1 100 0 1

-1 0.1

-2 0.01

-3 0.001

-4 0.0001

-5 0.00001

Table 5.6 Conversion Table

5.1.2 Change during operation

“TRUE” means that the parameter can be changed while the frequency converter is in operation and “FALSE” means that the frequency converter must be stopped before a change can be made.

5.1.3 2-Set-up

“All set-up”: The parameter can be set individually in each of the two set-ups, i.e. one single parameter can have two different data values. ”1 set-up”: Data value will be the same in both set-ups.

5.1.4 Type

Data Type Description Type 2 Integer 8 Int8 3 Integer 16 Int16 4 Integer 32 Int32 5 Unsigned 8 Uint8 6 Unsigned 16 Uint16 7 Unsigned 32 Uint32 9 Visible string VisibleString

Table 5.7

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

54 MG02C602 - VLT® is a registered Danfoss trademark

5.1.5 0-** Operation/Display

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

0-03 Regional Settings [0] International 1 set-up FALSE - Uint8

0-04

Operating State at Power-up

(Hand) [1] Forced stop ref=old All set-ups TRUE - Uint8 0-10 Active Set-up [1] Set-up 1 1 set-up TRUE - Uint8 0-11 Edit Set-up [1] Set-up 1 1 set-up TRUE - Uint8 0-12 Link Setups [20] Linked All set-ups FALSE - Uint8 0-31 Custom Readout Min Scale 0 1 set-up TRUE -2 Int32 0-32 Custom Readout Max Scale 0 1 set-up TRUE -2 Int32 0-40 [Hand On] Key on LCP [1] Enabled All set-ups TRUE - Uint8 0-41 [Off / Reset] Key on LCP [1] Enable All All set-ups TRUE - Uint8 0-42 [Auto on] Key on LCP [1] Enabled All set-ups TRUE - Uint8 0-50 LCP Copy [0] No copy 1 set-up FALSE - Uint8 0-51 Set-up Copy [0] No copy 1 set-up FALSE - Uint8 0-60 Main Menu Password 0 1 set-up TRUE 0 Uint16

0-61

Access to Main/Quick menu w/o

Password 0 1 set-up TRUE - Uint8

Table 5.8

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 55

5 5

5.1.6 1-** Load/Motor

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

1-00 Configuration Mode [0] Speed open loop All set-ups TRUE - Uint8 1-01 Motor Control Principle [1] VVC+ All set-ups FALSE - Uint8 1-03 Torque Characteristics [0] Constant torque All set-ups TRUE - Uint8

1-05 Hand Mode Configuration

[2] As mode 1-00 Configuration

Mode

All set-ups TRUE - Uint8 1-20 Motor Power All set-ups FALSE - Uint8 1-22 Motor Voltage All set-ups FALSE 0 Uint16 1-23 Motor Frequency All set-ups FALSE 0 Uint16 1-24 Motor Current All set-ups FALSE -2 Uint16 1-25 Motor Nominal Speed All set-ups FALSE 0 Uint16 1-29 Automatic Motor Tuning (AMT) [0] Off 1 set-up FALSE - Uint8 1-30 Stator Resistance (Rs) All set-ups FALSE -2 Uint16 1-33 Stator Leakage Reactance (X1) All set-ups FALSE -2 Uint32 1-35 Main Reactance (Xh) All set-ups FALSE -2 Uint32

1-50

Motor Magnetisation at Zero Speed 100% All set-ups TRUE 0 Uint16

1-52

Min Speed Normal Magnetising

[Hz] 0 Hz All set-ups TRUE -1 Uint16 1-55 U/f Characteristic-U All set-ups TRUE 0 Uint16 1-56 U/f Characteristic-F All set-ups TRUE 0 Uint16 1-60 Low Speed Load Compensation 100% All set-ups TRUE 0 Uint16 1-61 High Speed Load Compensation 100% All set-ups TRUE 0 Uint16 1-62 Slip Compensation 100% All set-ups TRUE 0 Int16

1-63

Slip Compensation Time

Constant 0.1 s All set-ups TRUE -2 Uint16 1-71 Start Delay 0 s All set-ups TRUE -1 Uint8 1-72 Start Function [2] Coast/delay time All set-ups TRUE - Uint8 1-73 Flying Start [0] Disabled All set-ups FALSE - Uint8 1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8

1-82

Min Speed for Function at Stop

[Hz] 0 Hz All set-ups TRUE -1 Uint16 1-90 Motor Thermal Protection [0] No protection All set-ups TRUE - Uint8 1-93 Thermistor Resource [0] None All set-ups FALSE - Uint8

Table 5.9

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

56 MG02C602 - VLT® is a registered Danfoss trademark

5.1.7 2-** Brakes

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

2-00 DC Hold Current 50% All set-ups TRUE 0 Uint16 2-01 DC Brake Current 50% All set-ups TRUE 0 Uint16 2-02 DC Braking Time 10 s All set-ups TRUE -1 Uint16 2-04 DC Brake Cut In Speed 0 Hz All set-ups TRUE -1 Uint16 2-10 Brake Function [0] Off All set-ups TRUE - Uint8 2-11 Brake Resistor (Ω) All set-ups TRUE 0 Uint16 2-16 AC Brake, Max current 100% All set-ups TRUE 0 Uint16 2-17 Over-voltage Control [0] Disabled All set-ups TRUE - Uint8 2-20 Release Brake Current 0 A All set-ups TRUE -2 Uint32 2-22 Activate Brake Speed [Hz] 0 Hz All set-ups TRUE -1 Uint16

Table 5.10

5.1.8

3-** Reference/Ramps

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

3-00 Reference Range [0] Min to Max All set-ups TRUE - Uint8 3-02 Minimum Reference 0 All set-ups TRUE -3 Int32 3-03 Maximum Reference 50 All set-ups TRUE -3 Int32 3-10 Preset Reference 0% All set-ups TRUE -2 Int16 3-11 Jog Speed [Hz] 5 Hz All set-ups TRUE -1 Uint16 3-12 Catch up/slow Down Value 0% All set-ups TRUE -2 Int16 3-14 Preset Relative Reference 0% All set-ups TRUE -2 Int16 3-15 Reference Resource 1 [1] Analog in 53 All set-ups TRUE - Uint8 3-16 Reference Resource 2 [2] Analog in 60 All set-ups TRUE - Uint8 3-17 Reference Resource 3 [11] Local bus reference All set-ups TRUE - Uint8

3-18

Relative Scaling Reference

Resource [0] No function All set-ups TRUE - Uint8 3-40 Ramp 1 Type [0] Linear All set-ups TRUE - Uint8 3-41 Ramp 1 Ramp up Time 3 s All set-ups TRUE -2 Uint32 3-42 Ramp 1 Ramp Down Time 3 s All set-ups TRUE -2 Uint32 3-50 Ramp 2 Type [0] Linear All set-ups TRUE - Uint8 3-51 Ramp 2 Ramp up Time 3 s All set-ups TRUE -2 Uint32 3-52 Ramp 2 Ramp down Time 3 s All set-ups TRUE -2 Uint32 3-80 Jog Ramp Time 3 s All set-ups TRUE -2 Uint32 3-81 Quick Stop Ramp Time 3 s 1 set-up TRUE -2 Uint32

Table 5.11

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 57

5 5

5.1.9 4-** Limits/Warnings

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

4-10 Motor Speed Direction [2] Both directions All set-ups FALSE - Uint8 4-12 Motor Speed Low Limit [Hz] 0 Hz All set-ups FALSE -1 Uint16 4-14 Motor Speed High Limit [Hz] 65 Hz All set-ups FALSE -1 Uint16 4-16 Torque Limit Motor Mode 150% All set-ups TRUE 0 Uint16 4-17 Torque Limit Generator Mode 100% All set-ups TRUE 0 Uint16 4-40 Warning Frequency Low 0Hz All set-ups TRUE -1 Uint16 4-41 Warning Frequency High 400Hz All set-ups TRUE -1 Uint16 4-50 Warning Current Low 0 A All set-ups TRUE -2 Uint32 4-51 Warning Current High 26 A All set-ups TRUE -2 Uint32 4-54 Warning Reference Low -4999 All set-ups TRUE -3 Int32 4-55 Warning Reference High 4999 All set-ups TRUE -3 Int32 4-56 Warning Feedback Low -4999 All set-ups TRUE -3 Int32 4-57 Warning Feedback High 4999 All set-ups TRUE -3 Int32 4-58 Missing Motor Phase Function [1] On All set-ups FALSE - Uint8 4-61 Bypass Speed From [Hz] 0 Hz All set-ups TRUE -1 Uint16 4-63 Bypass Speed To [Hz] 0 Hz All set-ups TRUE -1 Uint16

Table 5.12

5.1.10

5-** Digital In/Out

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi

Index

Type

5-10 Terminal 18 Digital Input [8] Start All set-ups TRUE - Uint8 5-11 Terminal 19 Digital Input [10] Reversing All set-ups TRUE - Uint8 5-12 Terminal 27 Digital Input [1] Reset All set-ups TRUE - Uint8 5-13 Terminal 29 Digital Input [14] Jog All set-ups TRUE - Uint8 5-15 Terminal 33 Digital Input [16] Preset ref bit 0 All set-ups TRUE - Uint8 5-34 On Delay, Terminal 42 Digital Output 0.01s All set-ups TRUE -2- Uint16 5-35 Off Delay, Terminal 42 Digital Output 0.01s All set-ups TRUE -2 Uint16 5-40 Function Relay [0] No operation All set-ups TRUE - Uint8 5-41 On Delay, Relay 0.01s All set-ups TRUE -2 Uint16 5-42 Off Delay, Relay 0.01s All set-ups TRUE -2 Uint16 5-55 Terminal 33 Low Frequency 20 Hz All set-ups TRUE 0 Uint16 5-56 Terminal 33 High Frequency 5000 Hz All set-ups TRUE 0 Uint16 5-57 Terminal 33 Low Ref./Feedb. Value 0 All set-ups TRUE -3 Int32 5-58 Terminal 33 High Ref./Feedb. Value 50 All set-ups TRUE -3 Int32

Table 5.13

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

58 MG02C602 - VLT® is a registered Danfoss trademark

5.1.11 6-** Analog In/Out

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

6-00 Live Zero Timeout Time 10 s All set-ups TRUE 0 Uint8 6-01 Live Zero TimeoutFunction [0] Off All set-ups TRUE - Uint8 6-10 Terminal 53 Low Voltage 0.07 V All set-ups TRUE -2 Uint16 6-11 Terminal 53 High Voltage 10 V All set-ups TRUE -2 Uint16 6-12 Terminal 53 Low Current 0.14 mA All set-ups TRUE -2 Uint16 6-13 Terminal 53 High Current 20 mA All set-ups TRUE -2 Uint16

6-14

Terminal 53 Low Ref./Feedb.

Value 0 All set-ups TRUE -3 Int32

6-15

Terminal 53 High Ref./Feedb.

Value 50 All set-ups TRUE -3 Int32 6-16 Terminal 53 Filter Time Constant 0.01 s All set-ups TRUE -2 Uint16 6-19 Terminal 53 mode [0] Voltage mode 1 set-up TRUE - Uint8 6-22 Terminal 60 Low Current 0.14 mA All set-ups TRUE -2 Uint16 6-23 Terminal 60 High Current 20 mA All set-ups TRUE -2 Uint16

6-24

Terminal 60 Low Ref./Feedb.

Value 0 All set-ups TRUE -3 Int32

6-25

Terminal 60 High Ref./Feedb.

Value 50 All set-ups TRUE -3 Int32 6-26 Terminal 60 Filter Time Constant 0.01 s All set-ups TRUE -2 Uint16 6-80 LCP Potmeter Enable 1 1 set-up FALSE - Uint8 6-81 LCP potentiometer Low Ref. 0 All set-ups TRUE -3 Int32 6-82 LCP potentiometer High Ref. 50 All set-ups TRUE -3 Int32 6-90 Terminal 42 Mode [0] 0-20 mA All set-ups TRUE - Uint8 6-91 Terminal 42 Analog Output [0] No operation All set-ups TRUE - Uint8 6-92 Terminal 42 Digital Output [0] No operation All set-ups TRUE - Uint8 6-93 Terminal 42 Output Min Scale 0% All set-ups TRUE -2 Uint16 6-94 Terminal 42 Output Max Scale 100% All set-ups TRUE -2 Uint16

Table 5.14

5.1.12

7-** Controllers

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

7-20 Process CL Feedback 1 Resource [0] No function All set-ups TRUE - Uint8

7-30

Process PI Normal/ Inverse

Control [0] Normal All set-ups TRUE - Uint8 7-31 Process PI Anti Windup [1] Enabled All set-ups TRUE - Uint8 7-32 Process PI Start Speed 0 Hz All set-ups TRUE -1 Uint16 7-33 Process PI Proportional Gain 0.01 All set-ups TRUE -2 Uint16 7-34 Process PI Integral Time 9999 s All set-ups TRUE -2 Uint32 7-38 Process PI Feed Forward Factor 0% All set-ups TRUE 0 Uint16 7-39 On Reference Bandwidth 5% All set-ups TRUE 0 Uint8

Table 5.15

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 59

5 5

5.1.13 8-** Comm. and Options

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

8-01 Control Site [0] Digital and ctrl.word All set-ups TRUE - Uint8 8-02 Control Word Source [1] FC RS485 All set-ups TRUE - Uint8 8-03 Control Word Timeout Time 1 s 1 set-up TRUE -1 Uint16 8-04 Control Word Timeout Function [0] Off 1 set-up TRUE - Uint8 8-06 Reset Control Word Timeout [0] No function 1 set-up TRUE - Uint8 8-30 Protocol [0] FC 1 set-up TRUE 0 Uint8 8-31 Address 1 1 set-up TRUE 0 Uint8 8-32 FC Port Baud Rate [2] 9600 Baud 1 set-up TRUE - Uint8 8-33 FC Port Parity [0] Even Parity 1 Stop Bit 1 set-up TRUE - Uint8 8-35 Minimum Response Delay 0.01 s 1 set-up TRUE -3 Uint16 8-36 Max Response Delay 5 s 1 set-up TRUE -3 Uint16 8-43 FC Port PCD Read Configuration 0 1 set-up TRUE - Uint8 8-50 Coasting Select [3] Logic OR All set-ups TRUE - Uint8 8-51 Quick Stop Select [3] Logic OR All set-ups TRUE - Uint8 8-52 DC Brake Select [3] Logic OR All set-ups TRUE - Uint8 8-53 Start Select [3] Logic OR All set-ups TRUE - Uint8 8-54 Reversing Select [3] Logic OR All set-ups TRUE - Uint8 8-55 Set-up Select [3] Logic OR All set-ups TRUE - Uint8 8-56 Preset Reference Select [3] Logic OR All set-ups TRUE - Uint8 8-94 Bus feedback 1 0 All set-ups TRUE 0 Int16

Table 5.16

5.1.14

13-** Smart Logic

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

13-00 SL Controller Mode [0] Off 1 set-up TRUE - Uint8 13-01 Start Event [39] Start command 1 set-up TRUE - Uint8 13-02 Stop Event [40] Drive stopped 1 set-up TRUE - Uint8 13-03 Reset SLC [0] Do not reset 1 set-up TRUE - Uint8 13-10 Comparator Operand [0] Disabled 1 set-up TRUE - Uint8 13-11 Comparator Operator [1] ApproxEqual 1 set-up TRUE - Uint8 13-12 Comparator Value 0 1 set-up TRUE -1 Int32 13-20 SL Controller Timer 0 s 1 set-up TRUE -1 Uint32 13-40 Logic Rule Boolean 1 [0] False 1 set-up TRUE - Uint8 13-41 Logic Rule Operator 1 [0] Disabled 1 set-up TRUE - Uint8 13-42 Logic Rule Boolean 2 [0] False 1 set-up TRUE - Uint8 13-43 Logic Rule Operator 2 [0] Disabled 1 set-up TRUE - Uint8 13-44 Logic Rule Boolean 3 [0] False 1 set-up TRUE - Uint8 13-51 SL Controller Event [0] False 1 set-up TRUE - Uint8 13-52 SL Controller Action [0] Disabled 1 set-up TRUE - Uint8

Table 5.17

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

60 MG02C602 - VLT® is a registered Danfoss trademark

5.1.15 14-** Special Functions

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

14-01 Switching Frequency [1] 4.0 kHz All set-ups TRUE - Uint8 14-03 Overmodulation [1] On All set-ups FALSE - Uint8 14-12 Function at Mains Imbalance [0] Trip All set-ups TRUE - Uint8 14-20 Reset Mode [0] Manual reset All set-ups TRUE - Uint8 14-21 Automatic Restart Time 10 s All set-ups TRUE 0 Uint16 14-22 Operation Mode [0] Normal operation 1 set-up TRUE - Uint8 14-26 Action At Inverter Fault [0] Trip All set-ups TRUE - Uint8 14-41 AEO Minimum Magnetisation 66 % All set-ups TRUE 0 Uint8

Table 5.18

5.1.16

15-** Drive Information

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conver

sion

Index

Type

15-00 Operating Time 0 1 set-up TRUE 0 Uint32 15-01 Running Hours 0 1 set-up TRUE 0 Uint32 15-02 kWh Counter 0 1 set-up TRUE 0 Uint32 15-03 Power Up's 0 1 set-up TRUE 0 Uint32 15-04 Over Temp's 0 1 set-up TRUE 0 Uint16 15-05 Over Volt's 0 1 set-up TRUE 0 Uint16 15-06 Reset kWh Counter [0] Do not reset 1 set-up TRUE - Uint8 15-07 Reset Running Hours Counter [0] Do not reset 1 set-up TRUE - Uint8 15-30 Fault Log: Error Code 0 1 set-up TRUE 0 Uint8 15-40 FC Type 1 set-up FALSE 0 VisibleString 15-41 Power Section 1 set-up FALSE 0 VisibleString 15-42 Voltage 1 set-up FALSE 0 VisibleString 15-43 SW ID Control Card 1 set-up FALSE 0 VisibleString

15-46

Frequency Converter Ordering No 1 set-up FALSE 0 VisibleString

15-48 LCP Id No 1 set-up FALSE 0 VisibleString

15-51

Frequency Converter Serial Number 1 set-up FALSE 0 VisibleString

Table 5.19

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 61

5 5

5.1.17 16-** Data Readouts

Parameter

Number

Parameter Description Default Value 2 Setup

Change During

Operation

Conversi on Index

Type

16-00 Control Word 0 1 set-up TRUE 0 Uint16 16-01 Reference [Unit] 0 1 set-up TRUE -3 Int32 16-02 Reference % 0 1 set-up TRUE -1 Int16 16-03 Status Word 0 1 set-up TRUE 0 Uint16 16-05 Main Actual Value [%] 0 1 set-up TRUE -2 Int16 16-09 Custom Readout 0 1 set-up TRUE -2 Int32 16-10 Power [kW] 0 1 set-up TRUE -3 Uint16 16-11 Power [hp] 0 1 set-up TRUE -3 Uint16 16-12 Motor Voltage 0 1 set-up TRUE 0 Uint16 16-13 Frequency 0 1 set-up TRUE -1 Uint16 16-14 Motor Current 0 1 set-up TRUE -2 Uint16 16-15 Frequency [%] 0 1 set-up TRUE -1 Uint16 16-18 Motor Thermal 0 1 set-up TRUE 0 Uint8 16-30 DC Link Voltage 0 1 set-up TRUE 0 Uint16 16-34 Heatsink Temp. 0 1 set-up TRUE 0 Uint8 16-35 Inverter Thermal 0 1 set-up TRUE 0 Uint8 16-36 Inv. Nom. Current 0 1 set-up TRUE -2 Uint16 16-37 Inv. Max. Current 0 1 set-up TRUE -2 Uint16 16-38 SL Controller State 0 1 set-up TRUE 0 Uint8 16-50 External Reference 0 1 set-up TRUE -1 Int16 16-51 Pulse Reference 0 1 set-up TRUE -1 Int16 16-52 Feedback [Unit] 0 1 set-up TRUE -3 Int32 16-60 Digital input 18,19,27,33 0 1 set-up TRUE 0 Uint16 16-61 Digital input 29 0 1 set-up TRUE 0 Uint8 16-62 Analog Input 53 (V) 0 1 set-up TRUE -2 Uint16 16-63 Analog Input 53 (mA) 0 1 set-up TRUE -2 Uint16 16-64 Analog Input 60 0 1 set-up TRUE -2 Uint16 16-65 Analog Output 42 [mA] 0 1 set-up TRUE -2 Uint16 16-68 Pulse input 33 20 1 set-up TRUE 0 Uint16 16-71 Relay Output [bin] 0 1 set-up TRUE 0 Uint8 16-72 Counter A 0 1 set-up TRUE 0 Int16 16-73 Counter B 0 1 set-up TRUE 0 Int16 16-86 FC Port REF 1 0 1 set-up TRUE 0 Int16 16-90 Alarm Word 0 1 set-up TRUE 0 Uint32 16-92 Warning Word 0 1 set-up TRUE 0 Uint32 16-94 Ext. Status Word 0 1 set-up TRUE 0 Uint32

Table 5.20

Parameter Lists

VLT® Micro Drive FC 51 Programming Guide

62 MG02C602 - VLT® is a registered Danfoss trademark

6 Troubleshooting

A warning or an alarm is signalled by the relevant LED on the front of the frequency converter and indicated by a code on the display.

A warning remains active until its cause is no longer present. Under certain circumstances operation of the motor may still be continued. Warning messages may be critical, but are not necessarily so.

In the event of an alarm, the frequency converter will have tripped. Alarms must be reset to restart operation once their cause has been rectified.

This may be done in four ways:

1. By pressing [Reset].

2. Via a digital input with the “Reset” function.

3. Via serial communication.

NOTE

After a manual reset press [Reset], [Auto On] or [Hand On] to restart the motor.

If an alarm cannot be reset, the reason may be that its cause has not been rectified, or the alarm is trip-locked (see also Table 6.1).

CAUTION

Alarms that are trip-locked offer additional protection, means that the mains supply must be switched off before the alarm can be reset. After being switched back on, the frequency converter is no longer blocked and may be reset as described above once the cause has been rectified. Alarms that are not trip-locked can also be reset using the automatic reset function in 14-20 Reset Mode (Warning: automatic wake-up is possible!) If a warning and alarm is marked against a code in the Table 6.1, this means that either a warning occurs before an alarm, or it can be specified whether it is a warning or an alarm that is to be displayed for a given fault. This is possible, for instance, in 1-90 Motor Thermal Protection. After an alarm or trip, the motor carries on coasting, and the alarm and warning flash on the frequency converter. Once the problem has been rectified, only the alarm continues flashing.

No. Description Warning Alarm Trip Lock Error Parameter

Reference

2 Live zero error (X) (X) 6-01 4 Mains phase loss (X) (X) (X) 14-12 7 DC over voltage X X 8 DC under voltage X X 9 Inverter overloaded X X 10 Motor ETR over temperature (X) (X) 1-90 11 Motor thermistor over temperature (X) (X) 1-90 12 Torque limit (X) 4-16, 4-17 13 Over Current X X X 14 Earth fault X X X 16 Short Circuit X X 17 Control word timeout (X) (X) 8-04 25 Brake resistor short-circuited X X 27 Brake chopper short-circuited X X 28 Brake Check X 29 Power board over temp X X 30 Motor phase U missing (X) (X) 4-58 31 Motor phase V missing (X) (X) 4-58 32 Motor phase W missing (X) (X) 4-58 38 Internal fault X X 44 Earth fault 2 X X 47 Control Voltage Fault X X

Troubleshooting

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 63

No. Description Warning Alarm Trip Lock Error Parameter

Reference

51 AMT check U

nom

and I

nom

52 AMT low I

nom

X 53 AMT motor too big X 54 AMT motor too small X 55 AMT Parameter out of range X 59 Current limit X 63 Mechanical Brake Low X 80 Drive Initialized to Default Value X 84 The connection between drive and LCP is lost X 85 Button disabled X 86 Copy fail X 87 LCP data invalid X 88 LCP data not compatible X 89 Parameter read only X 90 Parameter database busy X 91 Parameter value is not valid in this mode X 92 Parameter value exceeds the min/max limits X

Table 6.1 Alarm/Warning Code List

(X) Dependent on parameter

A trip is the action when an alarm has appeared. The trip will coast the motor and can be reset by pressing [Reset] or make a reset by a digital input (parameter group 5-1* [1]). The original event that caused an alarm cannot damage the frequency converter or cause dangerous conditions. A trip lock is an action when an alarm occurs, which may cause damage to frequency converter or connected parts. A trip lock situation can only be reset by a power cycling.

LED indication

Warning yellow

Alarm flashing red

Table 6.2

The alarm words, warning words and extended status words can be read out via serial bus or optional fieldbus for diagnosis. See also 16-90 Alarm Word, 16-92 Warning Word and 16-94 Ext. Status Word.

Troubleshooting

VLT® Micro Drive FC 51 Programming Guide

64 MG02C602 - VLT® is a registered Danfoss trademark

6.1.1 Alarm, Warning and Extended Status Word

Par. 16-90 Par. 16-92 Par. 16-94

Bit Hex Dec AlarmWord WarningWord ExtendedStatusWord

0 1 1 Brake check Ramping 1 2 2 Pwr.card temp Pwr.card temp AMT running 2 4 4 Earth Fault Start CW/CCW 3 8 8 Slow down 4 10 16 Ctrl.word TO Ctrl.word TO Catch up 5 20 32 Over Current Over Current Above Feedback High 6 40 64 Torque limit Below Feedback Low 7 80 128 Motor th over Motor th over Output current high 8 100 256 Motor ETR over Motor ETR over Output current low

9 200 512 Inverter overload Inverter overload Above Frequency High 10 400 1024 DC under volt DC under volt Below Frequency Low 11 800 2048 DC over volt DC over volt 12 1000 4096 Short Circuit 13 2000 8192 Braking 14 4000 16384 Mains ph. loss Mains ph. loss 15 8000 32768 "AMT Not OK" OVC active 16 10000 65536 Live zero error Live zero error AC brake 17 20000 131072 Internal fault 18 40000 262144 19 80000 524288 U phase loss Above Reference High 20 100000 1048576 V phase loss Below Reference Low 21 200000 2097152 W phase loss Local Ref./Remote Ref. 22 400000 4194304 23 800000 8388608 Control Voltage Fault 24 1000000 16777216 25 2000000 33554432 Current limit 26 4000000 67108864 Brake resistor short-circuit 27 8000000 134217728 Brake IGBT short-circuit 28 10000000 268435456 M4/M5: Earth Fault (Desat) MotorPhaseMissing 29 20000000 536870912 Drive initialised 30 40000000 1073741824 Undefined 31 80000000 2147483648 Mech. brake low DatabaseBusy

Table 6.3

The alarm words, warning words and extended staus words can be read out via serial bus for diagnose. See also 16-94 Ext. Status Word.

WARNING/ALARM 2, Live zero error Signal on terminal 53 or 60 is less than 50% of value set in 6-10 Terminal 53 Low Voltage, 6-12 Terminal 53 Low Current and 6-22 Terminal 60 Low Current.

WARNING/ALARM 4, Mains phase loss A phase is missing on the supply side, or the mains voltage imbalance is too high. This message also appears for a fault in the input rectifier on the frequency converter.

Troubleshooting: Check the supply voltage and supply currents to the frequency converter. The fault may be caused by mains distortions. Installing Danfoss Line Filter may rectify this problem.

WARNING/ALARM 7, DC overvoltage If the intermediate circuit voltage exceeds the limit, the frequency converter trips after a time.

Troubleshooting

Connect a brake resistor Extend the ramp time Change the ramp type Activate the functions in 2-10 Brake Function Increase 14-26 Trip Delay at Inverter Fault

The fault may be caused by mains distortions. Installing Danfoss Line Filter may rectify this problem.

Troubleshooting

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 65

WARNING/ALARM 8, DC under voltage If the intermediate circuit voltage (DC link) drops below the under voltage limit, the frequency converter checks if a 24 V DC backup supply is connected. If no 24 V DC backup supply is connected, the frequency converter trips after a fixed time delay. The time delay varies with unit size.

Troubleshooting

Check that the supply voltage matches the frequency converter voltage.

Perform input voltage test. Perform soft charge circuit test.

WARNING/ALARM 9, Inverter overload The frequency converter is about to cut out because of an overload (too high current for too long). The counter for electronic, thermal inverter protection issues a warning at 98% and trips at 100%, while giving an alarm. The frequency converter cannot be reset until the counter is below 90%. The fault is that the frequency converter has run with more than 100% overload for too long.

Troubleshooting

Compare the output current shown on the LCP with the frequency converter rated current.

Compare the output current shown on the LCP with measured motor current.

Display the Thermal Drive Load on the LCP and monitor the value. When running above the frequency converter continuous current rating, the counter increases. When running below the frequency converter continuous current rating, the counter decreases.

WARNING/ALARM 10, Motor overload temperature According to the electronic thermal protection (ETR), the motor is too hot. Select whether the frequency converter gives a warning or an alarm when the counter reaches 100% in 1-90 Motor Thermal Protection. The fault occurs when the motor is overloaded by more than 100% for too long.

Troubleshooting

Check for motor overheating. Check if the motor is mechanically overloaded Check that the motor current set in 1-24 Motor

Current is correct. Ensure that Motor data in parameters 1-20

through 1-25 are set correctly. Running AMT in 1-29 Automatic Motor Tuning

(AMT). The inverter peak current limit (approx. 200% of the rated current) is exceeded. The warning will last approx. 8-12 s, then the frequency converter trips and issues an alarm. Turn off the frequency converter and check if the motor shaft can be turned and if the motor size

matches the frequency converter. If extended mechanical brake control is selected, trip can be reset externally. may tune the frequency converter to the motor more accurately and reduce thermal loading.

WARNING/ALARM 11, Motor thermistor over temp The thermistor might be disconnected. Select whether the frequency converter gives a warning or an alarm in 1-90 Motor Thermal Protection.

Troubleshooting

Check for motor overheating. Check if the motor is mechanically overloaded.

WARNING/ALARM 13, Over current The inverter peak current limit (approx. 200% of the rated current) is exceeded. The warning will last approx. 8-12 s, then the frequency converter trips and issues an alarm. Turn off the frequency converter and check if the motor shaft can be turned and if the motor size matches the frequency converter. If extended mechanical brake control is selected, trip can be reset externally.

Troubleshooting:

Remove power and check if the motor shaft can be turned.

Check that the motor size matches the frequency converter.

Check parameters 1-20 through 1-25. for correct motor data.

ALARM 14, Earth (ground) fault There is current from the output phases to earth, either in the cable between the frequency converter and the motor or in the motor itself.

Troubleshooting:

Remove power to the frequency converter and repair the earth fault.

Check for earth faults in the motor by measuring the resistance to ground of the motor leads and the motor with a megohmmeter.

ALARM 16, Short circuit There is short-circuiting in the motor or motor wiring.

Remove power to the frequency converter and repair the short circuit.

WARNING/ALARM 17, Control word timeout There is no communication to the frequency converter. The warning is only active when 8-04 Control Word Timeout Function is NOT set to OFF. If 8-04 Control Word Timeout Function is set to Stop and Trip, a warning appears and the frequency converter ramps down until it trips, while giving an alarm. 8-03 Control Timeout Time could possibly be increased.

Troubleshooting

VLT® Micro Drive FC 51 Programming Guide

66 MG02C602 - VLT® is a registered Danfoss trademark

Troubleshooting:

Check connections on the serial communication cable.

Increase 8-03 Control Word Timeout Time Check the operation of the communication

equipment. Verify a proper installation based on EMC

requirements.

WARNING 25, Brake resistor short circuit The brake resistor is monitored during operation. If a short circuit occurs, the brake function is disabled and the warning appears. The frequency converter is still operational but without the brake function. Remove power to the frequency converter and replace the brake resistor (see 2-15 Brake Check).

WARNING/ALARM 27, Brake chopper fault The brake transistor is monitored during operation and if a short circuit occurs, the brake function is disabled and a warning is issued. The frequency converter is still operational but, since the brake transistor has shortcircuited, substantial power is transmitted to the brake resistor, even if it is inactive. Remove power to the frequency converter and remove the brake resistor.

WARNING/ALARM 28, Brake check failed The brake resistor is not connected or not working.

ALARM 29, Heatsink temp The maximum temperature of the heatsink has been exceeded. The temperature fault will not reset until the temperature falls below a defined heatsink temperature. The trip and reset points are different based on the frequency converter power size.

Troubleshooting

Check for the following conditions.

Ambient temperature too high. Motor cable too long. Incorrect airflow clearance above and below the

frequency converter. Blocked airflow around the frequency converter. Damaged heatsink fan. Dirty heatsink.

ALARM 30, Motor phase U missing Motor phase U between the frequency converter and the motor is missing.

Remove power from the frequency converter and check motor phase U.

ALARM 31, Motor phase V missing Motor phase V between the frequency converter and the motor is missing.

Remove power from the frequency converter and check motor phase V.

ALARM 32, Motor phase W missing Motor phase W between the frequency converter and the motor is missing.

Remove power from the frequency converter and check motor phase W.

ALARM 38, Internal fault

Troubleshooting

Cycle power Check that the option is properly installed Check for loose or missing wiring

It may be necessary to contact the local Danfoss supplier or service department. Note the code number for further troubleshooting directions.

WARNING 47, 24 V supply low The 24 V DC is measured on the control card. The external 24 V DC backup power supply may be overloaded, otherwise contact the Danfoss supplier.

ALARM 51, AMT check U

nom

and I

nom

The settings for motor voltage, motor current, and motor power are wrong. Check the settings in parameters 1-20 to 1-25.

ALARM 55, AMA parameter out of range The parameter values of the motor are outside of the acceptable range. AMA does not run.

ALARM 63, Mechanical brake low The actual motor current has not exceeded the “release brake” current within the “Start delay” time window.

ALARM 80, Drive initialised to default value Parameter settings are initialised to default settings after a manual reset. Reset the unit to clear the alarm.

ALARM 84,The connection between drive and LCP is lost Try to reassemble the LCP gently.

ALARM 85, Button disabled See parameter group 0-4* LCP

ALARM 86, Copy fail An error occurred while copying from frequency converter to LCP or vice versa.

ALARM 87, LCP data invalid Occurs when copying from LCP if the LCP contains erroneous data - or if no data was uploaded to the LCP.

ALARM 88,LCP data not compatible Occurs when copying from LCP if data are moved between frequency converters with major differences in software versions.

WARNING 89, Parameter read only Occurs when trying to write to a read-only parameter.

ALARM 90, Parameter database busy LCP and RS-485 connection are trying to update parameters simultaneously.

Troubleshooting

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 67

ALARM 91, Parameter value is not valid in this mode Occurs when trying to write an illegal value to a parameter.

ALARM 92, Parameter value exceeds the min/max limits Occurs when trying to set a value outside the range. Parameter can only be changed when the motor is stopped. Err. A wrong password was entered, occurs when using a wrong password for changing a passwordprotected parameter.

Troubleshooting

VLT® Micro Drive FC 51 Programming Guide

68 MG02C602 - VLT® is a registered Danfoss trademark

Index

Abbreviations And Standards............................................................ 7

Active Set-up.................................................. 8, 44, 28, 11, 13, 50, 55

Alarm, Warning And Extended Status Word.............................. 65

Alarm/Warning Code List.................................................................. 64

Alarms And Warnings......................................................................... 63

Analog In/Out........................................................................................ 59

Automatic Motor Tuning (AMT)...................................................... 15

Brake

Resistor.................................................................................. 19, 29, 57

Resistor (ohm)................................................................................... 50

Brakes........................................................................................................ 57

Comm. And Options............................................................................ 60

Controllers............................................................................................... 59

Conversion Index.................................................................................. 54

Current Rating....................................................................................... 66

Data Readouts....................................................................................... 62

DC-brake.................................................................................... 17, 19, 28

DC-Brake.................................................................................................. 50

Digital In/Out......................................................................................... 58

Display........................................................................................................ 8

Disposal Instruction............................................................................... 4

Drive

Identification.............................................................................. 46, 47

Information........................................................................................ 61

Earth Leakage Current...................................................................... 3, 4

Edit Set-up.............................................................. 8, 11, 12, 13, 50, 55

Electronic Waste...................................................................................... 4

EMC............................................................................................................ 67

Hand Mode................................................................. 34, 11, 14, 30, 56

Indicator Lights........................................................................................ 9

Isolated Mains Source........................................................................... 4

IT Mains....................................................................................................... 4

LCP

11.............................................................................................................. 8

12.............................................................................................................. 8

Leakage Current...................................................................................... 4

Limits/Warnings.................................................................................... 58

Load

Compensation..................................................................... 16, 50, 56

Compensations................................................................................. 14

Load/Motor............................................................................................. 56

Main Menu.......................................................................................... 9, 10

Maximum Reference........................................................................... 21

MCT 10 Set-up Software....................................................................... 1

Minimum Reference............................................................................ 21

Motor

Current.......................................................................................... 67, 15

Data....................................................................................................... 66

Direction................................................................................................ 9

Frequency........................................................................................... 15

Nominal Speed................................................................................. 15

Overload Protection.......................................................................... 4

Phase............................................................................... 48, 27, 50, 58

Power............................................................................................ 67, 14

Status.................................................................................................... 48

Temperature........................................................................ 18, 19, 50

Voltage................................................................................................. 15

Navigation Keys....................................................................................... 9

Not Changeable During Operation................................................ 12

Operation Keys......................................................................................... 9

Operation/Display................................................................................ 55

Output Current...................................................................................... 66

Over-voltage Control............................................................ 20, 50, 57

Parameter Number................................................................................. 8

Quick Menu........................................................................................ 9, 10

Ramp1

Ramp-down Time............................................................................ 23

Ramp-up Time................................................................................... 23

Rated Magnetizing Current.............................................................. 15

Readout Mode.......................................................................................... 9

Index

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 69

Reference/Ramps................................................................................. 57

Reset................................................................................................... 66, 67

Residual Current Device....................................................................... 4

Serial Communication.......................... 9, 24, 30, 37, 38, 39, 48, 49

Set-up Number........................................................................................ 8

Short Circuit............................................................................................ 66

Slip Compensation................................................................. 17, 50, 56

Smart Logic............................................................................................. 60

Special Functions........................................................................... 45, 61

Status Menu.............................................................................................. 9

Symbols...................................................................................................... 7

Thermal Load.................................................................................. 15, 48

Thermistor

Thermistor............................................................................ 18, 66, 50

Resource.............................................................................................. 56

Trip Reset................................................................................................. 45

Troubleshooting................................................................................... 63

Type Code String..................................................................................... 5

Unit............................................................................................................... 8

Value............................................................................................................ 8

Index

VLT® Micro Drive FC 51 Programming Guide

70 MG02C602 - VLT® is a registered Danfoss trademark

Index

VLT® Micro Drive FC 51 Programming Guide

MG02C602 - VLT® is a registered Danfoss trademark 71

www.danfoss.com/drives

*MG02C602*

132R0001 MG02C602 Rev. 2012-03-17

Danfoss FC 51 Series, VLT Micro Drive, VLT Micro Drive FC 51 Programming Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
