Danfoss EV212B Data sheet

Data Sheet

Solenoid valves
Type EV212B

Direct operated with isolated diaphragm for dirt and aggressive uids

The isolating diaphragm design ensures that no
uid enters the armature area which means
valves can be used for

• aggressive uids

• uid with impurities

• uid with risk of lime stone build up

Applications

• Marine ballast water treatment systems

• Dosing systems

• Pump cooling fx. Vacuum systems

• Systems with particles (Dirt) and aggressive

(sample intake)

◦ Washing and cleaning systems (Alkaline)
◦ Filling

media

Features

• Stainless steel body

• Clip on coil

• Viscosity: up to 50 cSt

• Ambient temperature: up to 50 °C

• Coil enclosure: up to IP67

AI279550962374en-000601

Features

EV212B

Body material

Stainless steel

DN [mm]

2-4.5

Connection

G1/8'' - G3/8''

Sealing material

FKM

Function

NC

Kv [m3/h]

0.15-0.55

Dierential pressure range [bar]

0-12

Temperature range [°C]

0-50

Solenoid valves, Type EV212B

1 Portfolio overview

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 2

Danfoss

A32U1178.20

5

1

2

3

4

1.2.3.4.5.

Closing spring

Armature

Isolating diaphragm

Orice

Coil

Solenoid valves, Type EV212B

2 Functions

2.1 Function

Function NC

When voltage is applied to the coil (5), the armature (2) with the isolating diaphragm (3) is lifted clear of the valve
orice (4) and opens for ow through the valve. The valve is open as long as there is voltage to the coil.

When voltage is disconnected, the isolating diaphragm (3) is pressed down against the orice by the spring (1). The
valve will be closed for as long as the voltage to the coil is disconnected. The isolating diaphragm keeps the
medium away from the actuator.

The space above the isolating diaphragm is lled up with silicone oil.

Figure 1: Function NC

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 3

Danfoss

32U1460

ON

OFF

24h

Danfoss

32U9100

Solenoid valves, Type EV212B

3 Applications

It is recommended to use a lter in front of the valve. Recommended lter 50 mesh (297 microns).

Figure 2: Filter

In water applications, exercise the valves at least once every 24 hours, meaning change the state of the valve. The
valve exercise will minimize the risk of the valve sticking due to calcium carbonate, zinc or iron oxide build-up.

Figure 3: Exercise: Valve on/o

To minimize scaling, and corrosion attack it is recommended that the water passing the valve have the following
values:

• Hardness 6-18 °dH to avoid scaling (chalk / lime stone build up).

• Conductivity 50 – 800 µS/cm to avoid brass dezincication and corrosion.

• Above 25°C media temperature avoid stagnant water inside the valve to avoid dezincication and corrosion
attack.

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 4

Media

FKM

Contaminated or aggressive media

Media temperature [°C]

FKM

0-50°C

Ambient temperature [°C]

Max. 50 °C

Kv value [m3/h]

DN2

0.15 m3/h

DN3

0.3 m3/h

DN4

0.38 m3/h

DN4.5

0.55 m3/h

Min. Opening dierential pressure [bar]

0 bar

Max. Opening dierential pressure [bar]

Up to 12 bar

Max. working pressure [bar]

Up to 12 bar (Equal to max. dierential pressure)

Max. test pressure [bar]

DN2 - 4

18 bar

DN 4.5

15 bar

Viscosity [cSt]

Max. 50 cSt

Connection
ISO228/1

Orice size

230 V 50 Hz / 24 V 50 Hz

BB230AS / BB024AS

018F7351 / 018F7358

220-230 V

BB230CS, 018F7363

208-230 V AC
50/60 Hz EEC

BE240CS, 018F6783

12/24 V DC
BB012DS, 018F7396
BB024DS, 018F7397

50 Hz

60 Hz

[mm]

[Bar]

[Bar]

[Bar]

[Bar]

[Bar]

G1/8

212121012

12

G1/4

212121012

12

G1/8

312121012

12

G1/4

312121012

12

G3/8

4

7.5

7.5612

10

G1/4

4.566510

10

G3/8

4.566510

10

Components

Materials

Specications

Valve body

Stainless steel

W.no. 1.4404 / AISI 316L

(1)

Flange for isolating diaphragm

Stainless steel

W.no. 1.4404 / AISI 316L

(1)

Isolating diaphragm

FKM

O-rings

FKM

Fluid above isolating diaphragm

Silicone oil

Type

L

B

B

1

H

1

H

Weight

without coil

Coil type BB/BY/BE

[mm]

[mm]

[mm]

[mm]

[mm]

[kg]

EV212B 2SS G1/8

353546

11, 5850,30

EV212B 2SS G1/4

353546

11, 5850,29

EV212B 3SS G1/8

353546

11, 5850,30

EV212B 3SS G1/4

353546

11, 5850,29

EV212B 4SS G3/8

383846

13870,33

EV212B 4.5SS G1/4

353546

11,5850,29

EV212B 4.5SS G3/8

383846

13870,33

Solenoid valves, Type EV212B

4 Product specication

4.1 Technical data

Table 1: Technical data

Dierential pressure range

Table 2: Dierential pressure range

Materials

Table 3: Materials

(1)

(1)

W. No. according to DIN 17440

W. No. according to DIN 17440

4.2 Dimensions and weight

Table 4: Dimensions and weight

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 5

Danfoss

32U1118.20

HH

1

B

1

BL

9

0

°

M

A

X

.

9

0

°

M

A

X

.

EV212B 2-3

EV212B 4.5

9

0

M

A

X

.

9

0

°

°

M

A

X

.

EV212B 2-3

EV212B 4.

5

360

°

360

Danfoss

80Z823

Solenoid valves, Type EV212B

Figure 4: Dimensions

4.3 Mounting

Figure 5: Mounting angle

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 6

ISO228/1
connection

Orice

Kv value

Function

[mm]

[m3/h]

NC

G1/8

2

0.15

032U3576

G1/4

2

0.15

032U3578

G1/8

3

0.3

032U3581

G1/4

3

0.3

032U3751

G3/8

4

0.38

032U3754

G1/4

4.5

0.55

032U3590

G3/8

4.5

0.55

032U3762

Type

Tambient

Supply voltage

Voltage

variation

Frequency

Control

Power consumption

Code no.

[°C]

[V]

[Hz]

[W]

[VA]

BB024AS

-40 – 80

24

-15%, +10%

50

NO, NC1119

018F7358

BB230AS

-40 – 80

220 - 230

-15%, +10%

50

NO, NC1119

018F7351

BB012DS

-40 – 5012±10%

DC

NC, NO, UN

(Latching)

13

018F7396

BB024DS

-40 – 5024±10%

DC

NC, NO, UN

(Latching)

16

018F7397

Type

Tambient

Supply voltage

Voltage variation

Frequency

Power consumption

Code no.

[°C]

[V]

[Hz]

[W]

[VA]

BR024CS

-40 – 50
24

±10%5014

26

018F4722

24

±10%6012

21

BR120CS

-40 – 50

110

±10%5014

27

018F4723
110 – 120

±10%6014

27

Solenoid valves, Type EV212B

5 Ordering

5.1 Parts program

Table 5: Stainless steel, valve body NC

5.2 Accessories

Coil

BB/BY high performance coil

Figure 6: BB/BY high performance coil

Table 6: High performance coils

BR marine coils, high performance coils

Figure 7: BR marine coils, high performance coils

Table 7: BR marine coils, high performance coils

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 7

Type

Tambient

Supply voltage

Voltage variation

Frequency

Power consumption

Code no.

[°C]

[V]

[Hz]

[W]

[VA]

BR230CS

-40 – 50

220 - 230

±10%5016

31

018F4720

±10%6013

24

BR024DS

-40 – 5024±10%DC16

018F4721

Type

Tambient

Supply voltage

Voltage

variation

Frequency

Control

Power consumption

Code no.

[°C]

[V]

[Hz]

[W]

BE240CS

-25 – 55

208 – 240

±10%60NO, NC

4

018F6783
208 – 240

±10%50NO, NC

4

Cable plug size

Description

Code no

DIN 18

Cable plug IP67

042N1256

Solenoid valves, Type EV212B

EEC Electronic coil controller

Figure 8: EEC Electronic coil controller

Table 8: High performance coils

Cable plug

Figure 9: Cable plug

Table 9: Cable plug

Universal electronic multi-timer Type ET 20 M

Figure 10: Type ET 20 M

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 8

Type

Voltage

Suitable for coil types

Code no.

[V]

BA024A

24 - 240

AL, AM, AS, AZ, BA, BD, BB

042N0185

Solenoid valves, Type EV212B

Table 10: Universal electronic multi-timer Type ET 20 M

© Danfoss | Climate Solutions | 2021.06 AI279550962374en-000601 | 9
