Installation Guide
ECtemp 330 (-10 to +10°C)
Electronic Thermostat
electricheating.danfoss.com
ECtemp 330 (-10 to +10°C)
Danfoss A/S is not liable or bound by warranty if these instructions are not adhered to during installation or service.
The English language is used for the original instructions.
Other languages are a translation of the original instructions.
© 2013 Copyright Danfoss A/S
Installation Guide2
ECtemp 330 (-10 to +10°C)
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . 3
1.1 Technical Specifications . . . . . . . . . . . 4
1.2 Safety Instructions . . . . . . . . . . . . . . . 5
2 Mounting Instructions . . . . . . . . . . . . . . . 6
3 Warranty. . . . . . . . . . . . . . . . . . . . . . . . 8
4 Disposal Instruction . . . . . . . . . . . . . . . . 8
1 Introduction
ECtemp 330 is an electronic thermostat to be installed in
electric cabinets with DIN rail attachment. Used primarily for controlling a lower temperature range as by frost
protection. The thermostat must be installed via an all-pole
disconnection switch. Either a wire sensor or an external air
sensor must be used to measure and control the desired
temperature.
The thermostat has a button to adjust the temperature
setting, with a scale from -10° to +10°C. An LED indicator
shows standby periods (green light) and heating periods
(red light).
More information on this product can also be found at:
ectemp.danfoss.com
3Installation Guide
ECtemp 330 (-10 to +10°C)
1.1 Technical Specifications
Operation voltage 220-240V~, 50Hz
Standby power consumption Max 0.25W
Relay:
Resistive load
Inductive load
Max 16A / 3680W @ 230V
cos φ= 0.3 max1A
Sensing units NTC 15kOhm at 25°C
Sensing values:
0°C
25°C
50°C
42kOhm
15kOhm
6kOhm
Hysteresis ± 0.2°C
Ambient temperature 10°C to +50°C
Lowering in economy periods -5°C
Temperature range -10°C to +10°C
Cable specification max 1x4mm² or x2,5mm²
Ball pressure temperature 75°C
Pollution degree 2 (domestic use)
Type 1C
Storage temperature -20°C to +65°C
IP class 20
Installation Guide4
ECtemp 330 (-10 to +10°C)
Protection class
Class II Dimensions 86 x 36 x 58mm
Weight 83g
The product complies with the EN/IEC Standard “Automatic
electrical controls for household and similar use”:
• EN/IEC 60730-1 (general)
• EN/IEC 60730-2-9 (thermostat)
1.2 Safety Instructions
Make sure the mains supply to the thermostat is turned off
before installation.
Please also note the following:
• The installation of the thermostat must be done by an
authorized and qualified installer according to local
regulations.
• The thermostat must be connected to a power supply
via an all-pole disconnection switch.
• The sensor is to be considered as live voltage. Have
this in mind if the sensor must be extended.
• Always connect the thermostat to continuous power
supply.
• Do not expose the thermostat to moisture, water,
dust, and excessive heat.
5Installation Guide
ECtemp 330 (-10 to +10°C)
2 Mounting Instructions
Please observe the following placement guidelines:
• Install the thermostat in an electric cabinet with DIN
rail attachment or a separate DIN attachment according to local regulation on IP classes.
• Do not place the thermostat in a way that it will be
exposed to direct sunlight.
Follow the steps below to mount the thermostat:
1. Click the thermostat on to the DIN rail attachment.
2. Connect the thermostat according to the connection
diagram.
-10°C to
+10°C
Installation Guide6
ECtemp 330 (-10 to +10°C)
N
L
PE
The screen of the heating cable must be connected
to the earth conductor of the power supply cable by
using a separate connector.
Note: Always install the floor sensor in a conduit in
the floor.
3. Turn on the power supply.
7Installation Guide
3 Warranty
4 Disposal Instruction
ECtemp 330 (-10 to +10°C)
Installation Guide8
ECtemp 330 (-10 to +10°C)
9Installation Guide
ECtemp 330 (-10 to +10°C)
Installation Guide10
ECtemp 330 (-10 to +10°C)
Danfoss A/S
Nordborgvej 81
6430 Nordborg, Syddanmark
Denmark
Produced by Danfoss © 02/2021088L8058 & AQ088786468294en-020302
