Data Sheet
PLUS+1® Mobile Machine Displays
DP211 Series
Danfoss DP211 Series Displays are elements of the
PLUS+1® family of mobile machine management
products.
The DP211 Series provide high quality, cost effective
performance solutions to fit the needs of today’s
mobile machines.
The DP211 Series features a USB mini-B connection at
the front of the display. This port allows full access to
all devices on the machine CAN network via the PLUS
+1® GUIDE Service Tool.
Large function-programmable buttons provide tactile
feedback. The high resolution display is viewable in a
wide range of lighting conditions. Backlight and
contrast settings are adjustable.
The DP211 Series feature robust mechanical, electrical
and ingress protection specifications that meet the
demands of mobile machine operation.
Features
Model dependent
•
3.8” high resolution grayscale LCD
display
•
4 programmable soft keys
•
2 red, 2 green, 2 amber software
controlled LEDs
•
2 CAN 2.0B ports
•
1 fixed-range analog input
•
2 digital/analog/frequency/current/
rheostat inputs
•
1 (0.5A) digital output
•
Real time clock
•
USB 2.0 port with mini-B connector
•
PLUS+1® GUIDE programmable
•
J1939 engine monitor software package
(requires application key)
•
Data logging capability
•
Rugged IP 54 rated housing
•
Integrated DEUTSCH connector
•
Extended temperature performance
range
•
CE and E marked
•
Mounting hardware and panel seal
gasket included
Comprehensive technical literature is
online at www.danfoss.com
©
Danfoss | Jul 2019 L1426132 | AI00000196en-000301 | 1
115.90 [4.56]
59.10 [2.33]
111.40 [4.39]
104.00 [4.09]
99.00
[3.90]
34.00 [1.33]
25.00 [0.98]
41.50 [1.63]
32.50 [1.27]
P200120
1 52 43
P200 129
Data Sheet
Mobile Machine Displays DP211 Series
Dimensions
mm [in]
This display series is recommended for incab installation only.
Pin assignments
USB mini-B pin connector
1 VBUS
2 D-
3 D+
4 NC
5 GND
Specifications
Processor ARM 7 core, 16/32 bit, 72 MHz
RAM 64 KB on-chip, 8 MB on board
FRAM 8 KB
Supply voltage 9 to 63 V dc/6.5 Watts
Connector DEUTSCH DTM-12
Type LCD with 32 grayscale levels
Resolution 240 × 160 pixels
Viewable area 80 mm × 55 mm [3.15 x 2.16]
IP Rating IP 54
*
Operation temperature –40° C to +70° C [–40° F to +158° F]
Storage temperature –40° C to +85° C [–40° F to +176° F]
Weight 250 g [0.5 lb]
Vibration/shock 5 g / 50 g
EMC/ESD 100 V/m / 15 kV
Digital output (0.5A) 1
*
USB in front display carries a full IP54 rating only if the USB mating
connector or seal plug cover is in place.
Use care when wiring mating connector.
Diagram shows device pins.
DEUTSCH 12-pin connector
1 Power ground-
2 Power supply+
3 CAN 0 High
4 CAN 0 Low
5 AIN/CAN Shield
6 N/A
7 N/A
8 CAN 1 High
9 CAN 1 Low
10 DIN/AIN/FREQ IN/CURRENT IN, RHEOSTAT
11 DIN/AIN/FREQ IN/CURRENT IN, RHEOSTAT
12 DOUT (0.5A)
Model features
A B C D E F Part number
DP211 04 01 02 04 01 11134226
04 01 03 04 01 11134227
2 | © Danfoss | Jul 2019 L1426132 | AI00000196en-000301
Data Sheet
Mobile Machine Displays DP211 Series
A: Model name
DP211 PLUS+1® Mobile Machine Displays
B: Input/output options
04 2 CAN, 2 DIN/AIN/Freqin/Rheo/4-20mA In, 1 AIN/CAN
Shield
C: Real time clock
01 RTC
D: Flash memory/application key
02 2 MB without Application Key
03 2 MB with Application Key
E: Application log (vault memory)
04 2 MB
F: USB port type
01 USB device
Related product Part number
DEUTSCH Mating Connector Bag Assembly (16-20 AWG) 10102025
DEUTSCH Mating Connector Bag Assembly (20-34 AWG) 10100944
DP211 Mounting Hardware Kit 10107264
PLUS+1® GUIDE Single User License 10101000
DP211 Panel Seal Replacement Gasket 11053020
©
Danfoss | Jul 2019 L1426132 | AI00000196en-000301 | 3
