Danfoss CSTFR1 Data sheet

Data Sheet

Programmable controller, 6 relays
Type CSTFR1

Electronic controller suitable for all HVAC/R software application needs.

CSTFR1 is an electronic programmable
controller especially dedicated to refrigeration
market and that allows full multiplexed cabinet
management. Thanks to the software
customisation possibility, it can be used in
several types of application. It’s also available
with optoinsulated Modbus RS485 serial
communication interface.

Features:

• 5 analog and 4 digital inputs

• 1 analog and 5 digital outputs

• Insulated power supply 110 / 230 V AC, 50/60
Hz

• Remote access to data through CANbus
connection for additional display (LCD
available) and keyboard

• Modbus RS485 opto-insulated serial interface

• Available only without display

• Dimensions 8 DIN modules

AI232186439515en-000601

Features

Description

Power supply

85 – 265 V AC, 50/60 Hz. Maximum power consumption: 6 V A

Insulation between power supply and the extra-low voltage: reinforced

Plastic housing

DIN rail mounting complying with EN 60715

Self extinguishing V0 according to IEC 60695-11-10 and glowing / hot wire test at 960 °C according to IEC 60695-2-12

Ball test

125 °C according to IEC 60730-1.
Leakage current: ≥ 250 V according to IEC 60112

Operating conditions

CE: -20T60 / UL: 0T55, 90% RH non-condensing

Storage conditions

-30T80, 90% RH non-condensing

Integration

In Class I and / or II appliances

Index of protection

IP40 only on the front cover

Period of electric stress across insulat­ing parts

Long
Resistance to heat and re

Category D

Immunity against voltage surges

Category II

Software class and structure

Class A

Type

Num

Specications

NTC

4

AI1, AI2, AI3, AI5

NTC temperature probes, 10 kΩ at 25 °C

NTC
0 / 5 V
4 / 20 mA

1

AI4

Pressure transducer with 4 / 20 mA or 0 / 5 V output or NTC temperature probe, default 10 kΩ at 25 °C The input type is
selectable via software

• 12 V+ power supply for 4 / 20 mA transducers: 12 V DC, 120 mA max

• 5 V+ power supply for 0 / 5 V transducers: 5 V DC, 100 mA max

Accuracy of measure: 3% f.s. - resolution: ±50 μA

Type

Num

Specications

Voltage free con­tacts

4

DI1, DI2, DI3, DI4

Current consumption: 5 mA

Type

Num

Specications

PWM
PPM

1

Analog outputs selectable via software between:

• pulsing output, synchronous with the line, at modulation of impulse position (PPM) or modulation of impulse width (PWM)

• pulsing output, at modulation of impulse width (PWM) with range 20 Hz – 1 KHz:

◦ open circuit voltage: 5 V
◦ minimum load: 1 kΩ

Programmable controller, 6 relays, type CSTFR1

Product specication

General features

Table 1: General features

Input/Output

Table 2: Analog inputs

Table 3: Digital inputs

Table 4: Analog outputs

© Danfoss | Climate Solutions | 2021.03 AI232186439515en-000601 | 2

Type

Num

Specications

Relay4Insulation between relays: functional Insulation between relays and the extra-low voltage parts: reinforced

C2-NO2, C3-NO3

Normally open contact relays 8 A
Characteristics of each relay:

• 6 A 250 V AC for resistive load - 100.000 cycles

• 4 A 250 V AC for inductive loads - 100.000 cycles with cos(phi) = 0.6

C1-NO1-NC1

Changeover contacts relay 8 A
Characteristics of each relay:

• 6 A 250 V AC for resistive load - 100.000 cycles

• 4 A 250 V AC for inductive loads - 100.000 cycles with cos(phi) = 0.6

C4-NO4

High inrush current normally open contact relays 16 A
Characteristics of each relay:

•

1000 W incandescent lamp, 250 V AC, NO contact: 80.000 cycles

•

10 A, 240 V AC, NO contact, 85 °C, VDE/UL508: 50.000 cycles

• 21 / 3.5 A, 230 V AC, compressor, cos(phi) = 0.5, NO contact: 230.000

Solid state relay

1

Insulation between SSR and relays: functional
Insulation between SSR and the extra-low voltage parts: reinforced
Type of SSR action: 1C (micro-interruption)

C6-NO6

SSR, with output AC Zero-crossing:

• load current: 1 A

• load voltage: 75 – 250 V AC

CSTFR1

Power

N

POWER SUPPLY

D05

DIGITAL OUTPUT

N0 4

C 4

NO 3

C 3

NO 2

C 2

NO 1

C 1

NC 1

C 6

NO 6

16 A

8 A

8 A

8 A

8 A

1 A

SSR Out

L

*

DI 1

NTC 4

EIA-485

(Modbus)

CANbus

supervisory network

local network

CANbus

pressure transducers

0/5 V

4/20 mA

LED

SERIAL COMM. CAN-RJ

INPUT/OUTPUT

GND

D+

D-

CAN

speed

regulator

AI 2

AI 1

AI 4 12V+

COM

5V+

PWM

DI 4

DI 3

AI 5

COMAI 3

DI 2

DI 1

DI 2

DI 3

DI 4

NTC 3

NTC 2

NTC 1

NTC 5

N0 5

C 5

CAN

R120

CAN H

CAN L

CAN GND

TTL

Danfoss

80G8066.01

Programmable controller, 6 relays, type CSTFR1

Table 5: Digital outputs

Connection diagram

Figure 1: Connection diagram



NOTE:

*Connection has to be made on the rst and last local network units, make the connection as close as possible to
the connector.

© Danfoss | Climate Solutions | 2021.03 AI232186439515en-000601 | 3

Connectors

Type

Dimensions

Power supply connector

2 way screw plug-in connector type

• pitch 5 mm

• section cable 0.2 – 2.5 mm²

Digital output connector

11 way screw plug-in connector type

• pitch 5 mm

• section cable 0.2 – 2.5 mm²

Input/output connector

Molex® Mini-Fit JrTM type or compatible

Female connector

14 way, Molex® code: 39012140 Molex® cod of contact For
the crimping to use the appropriate instrument, Molex®
code 690080724

• 39000077 for cable with section: AWG16, (1.30 mm²)

• 39000038 for cable with section: AWG18, 20, 22, 24 (0.82...0.20 mm²)

• 39000046 for cable with section: AWG22, 24, 26, 28 (0.32...0.08 mm²)

Serial com connector

3 way screw plug-in connector type

• pitch 5 mm

• section cable 0.2 – 2.5 mm²

CAN connector

4 way screw plug-in connector type

• pitch 5 mm

• section cable 0.2 – 2.5 mm²

CAN-RJ connector

6 / 6 way telephone RJ12 plug type

110

140 60

Danfoss

80G8067

Programmable controller, 6 relays, type CSTFR1

Connection

Table 6: Connection

Dimensions

Figure 2: Dimensions

© Danfoss | Climate Solutions | 2021.03 AI232186439515en-000601 | 4

Description

Code No.

CSTFR1, 230 V, RS485, Industrial Pack (24 pieces)

080G0156

File name

Document type

Document topic

Approval authority

080R2096.01

EU Declaration of conformity

EMC directive 2014/30/EU:

EN61000-6-4: 2007 +A1: 2011
EN61000-6-2: 2005

LVD directive 2014/35/EU:

EN60730-1: 2011
EN60730-2-9: 2010

RoHS directive 2011/65/EU and 2015/863/EU:

EN 50581: 2012

Danfoss

Programmable controller, 6 relays, type CSTFR1

Ordering

Product part numbers

Table 7: Product part numbers

 NOTE:

Connectors kit is included in the Industrial Pack.

Certicates, declarations, and approvals

The list contains all certicates, declarations, and approvals for this product type. Individual code number may have
some or all of these approvals, and certain local approvals may not appear on the list.

Some approvals may change over time. You can check the most current status at danfoss.com or contact your local
Danfoss representative if you have any questions.

Table 8: Certicates, declarations, and approvals

© Danfoss | Climate Solutions | 2021.03 AI232186439515en-000601 | 5
