Logic Elements Technical Information
11
14
17
20
8
Spool Type
CP701-1
OPERATION
The CP701-1 is a 12-size, normally-closed, pilot-toclose, spool-type,, spring biased dierential-sensing logic element. It will
modulate ow from 1 to 2 based on the spring control pressure, inlet
pressure at port 1, and pilot pressure at port 3.
APPLICATION
Common applications include load-sensing bypass compensator for a
xed displacement pump with single or multiple actuators as well as
bypass-type pressure-compensated ow control. Eective use of logic
elements is a key to designing cost-eective circuits, and is limited only
by the imagination of the designer.
SPECIFICATION
SCHEMATIC
Rated pressure* 350 bar [5075 psi]
Rated ow at 7 bar
[100 psi]
150 l/min
[40 US gal/min]
2
Weight 0.26 kg [0.57 lb]
Cavity CP12-3S
* Rated Pressure based on NFPA fatigue test standards (at 1 Million Cycles).
3
1
PERFORMANCE CURVE
psi bar
87
58
29
Theoretical performance
154 SUS (33 cSt) hyd. oil @ 100° F (38° C)
14
3
12
4
10
5
8
6
6
Press ure drop
4
2
Pressure drop
Fully opened
BC332375783111en-000101 • February 2020
0
40L/min
80 120 160 200
10.6US gal/min
Flow
21.1 31.7 42.3 52.
LE - 23
Logic Elements Technical Information
[2.20]
[1.00]
Spool Type
CP701-1
DIMENSION
mm [in]
1
EXAMPLE CIRCUITS
Cross-sectional view
2
1-1/16-12 UN
55.9
ht1.25 in
68-75 N.m
[50-55 lbf.ft]
3
25.4
Double Acng Cylinder with
Proporonal Speed Control,
Unloading Valve and Circuit Relief
ORDERING
INFORMATION
Seals
B=Buna-N 120335
V=Viton 120336
0=No housing No housing
4B = AL, 1/2 BSP CP12-3S-4B/2B = 1/4 BSP
6B = AL, 3/4 BSP CP12-3S-6B/2B = 1/4 BSP
= #10 SAE CP12-3S-10S/4S = #4 SAE
= #12 SAE CP12-3S-12S/4S = #4 SAE
rtsHousing P/N Pilot port
AL,
AL,
BC332375783111en-000101 • February 2020
Proporonal Bypass Flow Control
CP701-1-B-12S-080
Seal kit
Dump and Relief Valve for a Fixed Pump
Differential
Control
Pressure
bar[psi]
030=2.1[30]
050=3.5[50]
080=5.5[80]
100=6.9[100]
150=10.3 [150]
170 = 11.7 [170]
LE - 24
