Data Sheet
Micro Plate Heat Exchanger
Type C22 & H22
For more ecient Chillers & Heat Pumps
20% reduction in refrigerant charge
compared with a traditional BPHE, the ideal
solution to help you meet the world`s
climate and energy aspirations.
The C22 & H22 are families of Condensers and
Evaporators optimized for high-eciency
chillers and heat pumps.
The heat exchanger features innovative Micro
Plate technology that improves heat transfer
and reduces the amount of material used.
To meet demands for higher COPs in heat
pumps, the evaporator H22(L)-E and the
condenser H22(L)-C are designed to work
eciently with close temperature approaches,
while a low pressure drop on the brine side
reduces the pump power and keeps the overall
COP high. H22 can cover a capacity range from
2 to 10kW.
H22(L)-C represent the ideal choice for the Semi
Plug-in systems, also operating with ammable
refrigerants.
The C22(L)-E and the C22(L)-C are respectively
evaporator and condenser designed to work
eciently and increase comfort in modern
buildings without increasing the carbon
footprint. Helping chillers perform more
eciently achieving higher seasonal eciency
levels, it reduces both energy costs and
environmental impact. C22 can cover a capacity
range from 3 to 20kW.
The low hold-up volume reduces the system
refrigerant charge and oers valuable savings.
AI364313920129en-000101
a
Applications
C: chiller
H: heat pump
HDW: heat pump double wall
d
Specic duty
E= evaporator
C= condenser
Plate design
Omit
L: L-type
M: M-type
H: H-type
W: W-type
X: Asymmetric
Z: Z ow
Conguration
Omit: single
D: Dual circuit
U: Mixing chamber
e
Distributor version
Omit
B
F
Plate stacking sequence
Omit: a-b-a…
R: b-a-b…
b
Platform* 22,30,55,62,118…
*heat exchanging surface per plate 1/1000 m²
c
Pressure Service
Omit: 30bar
L: 45/49bar
f
Number of plates**
**Rule:
-Single: even number
-Dual: even number not multiple of 4
Micro plate heat exchanger, Type C22 & H22
Features
• Minimal hold-up volume: Less refrigerant charge
• Reduced pressure drop: For a more ecient system
• Smaller footprint: Enabling more compact system
• Reduced CO2 footprint: Environmentally friendly with high heat transfer and minimal refrigerant charge
Portfolio overview
C22L-E: Evaporator optimized for R410A in chiller application, from 3 to 20kW.
C22-E: Evaporator for medium density refrigerants in chiller application, from 3 to 20kW.
C22L-C: Condenser optimized for high density refrigerants in chiller application, from 3 to 20kW.
C22-C: Condenser optimized for medium density refrigerants in chiller application, from 3 to 20kW.
H22L-C: Condenser optimized for high density refrigerants in heat pump application, from 2 to 10kW.
H22-C: Condenser optimized for medium density refrigerants in heat pump application, from 2 to 10kW.
H22L-E: Evaporator optimized for R410A in heat pump application, from 2 to 10kW.
H22-E: Evaporator for medium density refrigerants in heat pump application, from 2 to 10kW.
Table 1: Designation
Application
The C22 & H22 are families of Condensers and Evaporators specically optimized for high-eciency chillers and
heat pumps, dedicated to comfort applications, cooling-industrial process and semi plug-in systems in food retail
industry. The evaporators are design to operate also in reversable systems in condenser mode, in co or counter
current ow conguration; as well as the condensers are optimized and fully in regard to the defrost operation
cycle.
Media
Refrigerants
R410A, R407C, R452B, R454B, R290
For other refrigerants please contact your Danfoss Sales representative.
© Danfoss | Climate Solutions | 2021.02 AI364313920129en-000101 | 2
Micro plate heat exchanger, Type C22 & H22
Product specication
Dimensions
Figure 1: Dimensions
A:
C22-C / C22-E / H22-E / H22-C: 8 + 1.19 x N [0.31 + 0.047 x N]
C22L-C / C22L-E / H22L-E / H22L-C: 10 + 1.19 x N [0.39 + 0.047 x N]
N: Number of Plate
Operating conditions
Preconditions:
N = number of plates
Max number of plates: 60
Pressure and temperature data*:
Min. working temperature: -196 °C (-320 °F)
Max. working temperature: 200 °C (390 °F)
Max. working pressure:
C22-C / C22-E / H22-C / H22-E: 30 bar (435psi)
C22L-C / C22L-E / H22L-E: 45 bar (653psi)
H22L-C:48 bar (696psi) [UL: 45 bar (653psi)]
For details, refer to the Third party approvals chapter.
Weight
C22-C / C22-E / H22-E / H22-C: 0.58 + 0.045 x N [kg] / 1.28 + 0.099 x N [lb]
C22L-C / C22L-E / H22L-E / H22L-C: 0.77 + 0.045 x N [kg] / 1.70 + 0.099 x N [lb]
N: Number of Plate
*without connections
© Danfoss | Climate Solutions | 2021.02 AI364313920129en-000101 | 3
Item
Material
Specication
Cover plates
Stainless steel
AISI 304L
Plates
Stainless steel
AISI 316L
Connections
Stainless steel
AISI 304L
Brazing ller
Pure copper
Cu
Micro plate heat exchanger, Type C22 & H22
Material specication
Table 2: Standard materials
Other material combinations are available on request. Please contact your Danfoss sales representative for more
information.
Conguration ow
Figure 2: Conguration ow
Parallel ow:
Q1 - Q2 [H1 - H2]: brine/secondary side
Q3 - Q4 [H3 - H4]: refrigerant/primary side
Hold up volume
C/H22(L)-C/E
Q1-Q2: 0.21xN/2 [l]
Q3-Q4: 0.21x(N-2)/2 [l]
N: Number of Plate
Ordering
Global or local standard code numbers can be accessed via Store.Danfoss.com on local subsites, with full set of
technical data as well as relevant assets such as documentation and drawings. Since the portfolio may contain
dierent types depending on country, this document contains only a summarized list of standard code numbers
with a few data relevant for the product selection.
Conguring and calculating products
The C22 & H22 can be easily customized based on the application needs; model size can be evaluated using Hexact
software.
For details, product conguration and code creation please contact your Danfoss Sales representative.
© Danfoss | Climate Solutions | 2021.02 AI364313920129en-000101 | 4
Circuits
Connection type options
Connection size option
Q1 - Q2 (water-brine side)
BSP Gas male
½, ¾
BSP Gas female
½
DIN R male
½, ¾
NPT
½, ¾
Q3-Q4 (refrigerant side)
Soldering
¼, ½,
5
⁄8, ¾, 7⁄8
Stud bolt position
Bolt sizes
151mm, middle
M6x20mm
Pressure Equipment Directive (PED)
Underwriters Laboratory Inc (UL)
Micro plate heat exchanger, Type C22 & H22
Mechanical connections
Table 3: Mechanical connections
Accessories and spare parts
MPHE products are not serviceable, i.e. cannot be taken apart and repaired, and there are no spare parts program.
As for accessories, stud bolts, feet on front and/or back cover plates for mounting support and handling are
available upon request.
Table 4: Stud bolts:
Contact your Danfoss sales representative for further information.
Certicates, declarations, and approvals
The list contains all certicates, declarations, and approvals for this product type. Individual code number may have
some or all of these approvals, and certain local approvals may not appear on the list.
Some approvals may change over time. You can check the most current status at danfoss.com or contact your local
Danfoss representative if you have any questions.
Third party approvals
All MPHE and BPHE are certied to European Pressure Equipment Directive (PED) and are approved by Underwriters
Laboratories (UL).
Other certications are available upon request: Kraia, EAC, UA, AS; for others and more details please contact your
local Danfoss representative.
© Danfoss | Climate Solutions | 2021.02 AI364313920129en-000101 | 5
