1.0 System overview
DANFOSS AIR4
1.0 System overview
Congratulations on purchasing Danfoss Air. One of
the most advanced, efficient and quietest ventilation
system with heat recovery on the market. On the
follow ing pages, we will take you through the steps
needed to operate your system successfully as well as
showing you how to maintain the system.
Your system is operated from a single control panel,
the Danfoss Air Dial. You can control the entire system
by rolling and pushing the dial, whilst the necessary
information is shown in the display.
Wireless Air Dial
CCM
Power
supply
HRV
unit
DANFOSS HEATING 5
UK
2.0 Main functions
2.1 Away
2.2 Bypass
Main menu > Away
Use this command when you leave your house for a
prolonged period of time. The away command reduces
the ventilation rate of the system to an absolute minimum, inside a defined interval. The unit will automatically assume normal operation when the away period is
over. Note: if a heating surface is installed (optional) it
is turned off during away mode. If the heating surface
is used for heating the house, the room temperature is
reduced to 15 ˚C during away period.
Main menu > Bypass
The bypass function opens a passage parallel to the heat
exchanger, which stops the heat exchanging process.
When the bypass is open, outdoor air is led directly into
the house. The bypass can be activated in two ways:
1. Manually, by pressing the bypass command. This
will start the bypass function for 3 hours (the run
time can be changed in the settings menu). The
bypass will not activate if the outdoor temperature
is lower than +5˚C.
2 . Automatically, if the outdoor air is warmer than
16 ˚C (activation temperature can be changed in
settings menu). The bypass will automatically close
again, when the outdoor air temperature drops
below 15 ˚C.
Automatic activation of bypass is not possible in the
manual run mode.
PROG
%
”away icon”
PROG
%
”bypass icon”
DANFOSS AIR6
Main menu > Info
The info command shows a list, indicating the present
status of your unit. Here you can see all measured temperatures, fan steps, relative humidity in the room, and
much more...
Main menu > boost
The boost command can be used in situations where
you require a higher airflow than normal. Use it if you
and your friends are having a party, if you’re cooking
something with a strong odour, if somebody is smoking,
etc. The boost function is timer based, and as default
runs for 3 hours (boost duration can be changed in the
settings menu). In boost, the unit runs at 100% speed.
Main menu > mode
Using the mode command, you can change how the
ventilation system is controlled. Each mode has it’s
unique traits - choose the one that suits you best:
Mode > demand
In demand mode a humidity sensor integrated in the Air
Mode > manual mode
In manual mode, the automatic bypass function is disabled, the week program is not active, and the humidity
sensor is not used - you control the air flow rate yourself
by setting the desired fan speed 1-10. Try different
steps, until you find the one that gives you the air quality you like (the command fan speed is only visible in
main menu, when manual mode is chosen).
PROG
%
”Manual icon”
2.0 Main functions
2.5 Mode
2.3 Info
2.4 Boost
%
”Demand icon”
DANFOSS HEATING 7
UK
2.0 Main functions
unit controls the air flow. At times when the moisture
content of the outdoor air is low, typically in the heating
season, choosing demand mode will help prevent that
the air in your house becoming too dry in the winter.
In demand mode the airflow is automatically reduced,
whenever the relavtive humidity in the room becomes
too low. In demand mode, the system automatically
detects if you shower, which triggers a short term
automatic boost.
Note: Outside the heating season, when the outdoor
air contains more moisture than in the winter period,
the air flow will remain more or less constant, at a rate
equivalent to the stored basic step - this ensures maximum comfort in the part of the season where heat loss
is neglible.
Mode > Program mode
In program mode a pre-defined family profile is chosen.
Based on the profile, the system then concentrates air
flow to periods when occupants of the house are actually present, or where it makes the most sense, from
a ventilation point of view. If none of the five predefined family profiles suits your requirements, you can
download (as freeware) a PC tool that, allows you to
make your own user profile (see installation manual for
more info, or go to www.air.danfoss.com).
The default profile is no. 1, so this profile is active if you
choose ”program mode”.
PROG
%
”Program icon”
DANFOSS AIR8
2.0 Main functions
2.6 Settings
Main menu > settings
In the settings menu, you can access a range of default
settings, and thus customize the system to your demands.
Here are the settings that can be changed, and a short
description of the effect of changing the setting has:
Main menu > settings > program > choose profile 1-5
Tell the system what kind of family you have, and it will
react accordingly.
Profile 1 = Family with children, both adults working
normal working hours.
Profile 2 = Family with children, one working adult, normal working hours, one adult at home during the day.
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P1 – WEEKDAYS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P1 – WEEKENDS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P2 – WEEKDAYS
DANFOSS HEATING 9
UK
2.0 Main functions
Profile 3 = Couple without children, both working
adults, normal working hours
Profile 4 = Single person (working adult), no one at
home during work hours
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P3 – WEEKDAYS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P3 – WEEKENDS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P4 – WEEKDAYS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P2 – WEEKDAYS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P2 – WEEKENDS
DANFOSS AIR10
2.0 Main functions
Profile 5 = Small commercial office- or sales outlet area.
Opening hours 08:00 to 16:00, weekend closed.
Main menu > settings > program > choose profile 1-5
If you did not find a profile that matches your demands,
or if you simply like to experiment with the profiles,
please download the PC tool from
www.air.danfoss.com which will allow you to customize
a program to suit your demands. If a custom program was
made using the PC tool, it will be visible in the menu as:
Main menu > settings > choose profile > user defined.
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P4 – WEEKDAYS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P4 – WEEKENDS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P5 – WEEKDAYS
00:00
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
11:00
12:00
13:00
14:00
15:00
16:00
17:00
18:00
19:00
20:00
21:00
22:00
23:00
24:00
0
20
40
60
80
100
120
Fan step
(% of basic step) Prole P5 – WEEKENDS
DANFOSS HEATING 11
UK
Main menu > settings > bypass °C
Here you can set the activation temperature of the automatic bypass function. When the outdoor air reaches the
defined temperature, the bypass function will automatically begin. When the temperature drops below the
defined outdoor air temperature, the automatic bypass
function will stop again. A highly insulated house can
benefit from a lower than normal setting (default 16 °C)
- but be aware that setting the bypass activation too low,
can cause draught risk.
Main menu > settings > bypass dura.
Here you can adjust the run time of the ”manual bypass”
function (default run time is 3 hours from activation).
Main menu > settings > boost duration
Here you can adjust the run time of the ”boost” function
(default run time is 3 hours from activation).
Main menu > settings > time & date
Here you can adjust the time and date of your system.
Main menu > settings > night cooling
Here you can define whether or not you will allow night
cooling (disabled as default). Night cooling is a form of
automatic bypass, that can be used in the summertime.
The system automatically detects if it was a warm day
and only then will it be activated. The night cooling
function will allow the supply air to be +10 °C or higher.
The function runs from 24:00 until 06:00 am, and automatically stops if the outdoor air fall below +10 °C or if
exhaust air temperature drops below +18 °C.
Main menu > settings > restore default
Restores all user settings to factory default values. The stored
basic step will not be affected by using this function.
2.0 Main functions
DANFOSS AIR12
3.0 Maintenance
3.1 Maintenance,
changeing the
air filters
Your Danfoss Air unit was designed to ensure an absolute minimum of maintenance. In day-to-day operation,
you will only need to change the air filters 1-2 times a
year, depending on your air flow rate, and the pollutant
level where you live. In industrial areas, and in areas
with a high pollen content in the outdoor air, the filters
will clogg faster than in a typical surburban environment.
When the unit gives the filter alarm (audible alarm from
the Air Dial + message in display)
If you have bought the
optional pollen filter, it
should be fitted in the
filter slot to the right
(on all models) - as this
is the filter that filters
the outdoor air
- Go to the air unit
- Remove the front cover plate - no tools are needed,
just pull the handle and lift cover of unit
- Pull out the filters and
inspect visually (if the
filter is only lightly fouled
/ discolored, you can attempt to clean it, using a
vacuum cleaner equipped
with a brush - but generally
this is not worthwhile nor
advisable)
- Change filter as required,
use the arrows to align
- Push the filter reset button,
located next to the filter
DANFOSS HEATING 13
UK
3.2 Replacing the
Air Dial batteries
An audible alarm indicates that the Air Dial’s batteries
need replacing. Lift the Air Dial off the wall bracket,
remove the batteries and replace with new batteries.
The Air Dial utilizes 4 x AAA batteries.
Please do not neglect to change the air filters as this will
prevent you from obtaining optimum indoor air quality.
Furthermore, failure to change the filters will cause the
fans to use more power, so ultimately it will not save
you any money.
Standard filters and optional pollen filters (F7 class) can
be purchased from your installer.
3.0 Maintenance
DANFOSS AIR14
3.0 Maintenance
3.3 Cleaning
the unit
You should clean the inside of the unit once every two
years. To do this, unplug the power, remove the front
cover plate, unscrew the six screws holding the three
metal braces (using correct size torx wrench). Now,
remove the foam front panel, to gain access to the
inside.
Gently pull out the aluminum heat exchanger, and pour
a mild soapy solution through the 4 open sides of the
heat exchanger (use normal dishwasher detergent).
Leave to soak for 5-10 minutes and rinse under running
water. Dry off the exterior of the heat exchanger, and
gently slide the heat exchanger into the unit again.
1
3
5 6
4
2
DANFOSS HEATING 15
UK
3.0 Maintenance
Clean interior surfaces of the unit with a wet sponge or
cloth (use a mild soapy solution).
UNDER NO CIRCUMSTANCES use solvents to clean the
foam parts as solvents can dissolve the special foam
material.
Avoid spraying water onto the main circuit board. If you
do happen to spill water onto the circuit board, tap the
circuit board lightly using a dry cloth. Leave to air dry
for min. 24 hours before reconnecting the power.
Reassemble unit in reverse order, put foam front panel
back in place, fix it with the three metal braces and
tighten the torx screws. Replace front cover panel, and
you are ready for years of trouble free service again!
DANFOSS AIR16
• Freeware:downloadtheprogramforfreeat
www.air.danfoss.com
• ControlyourDanfossAirsystemfromyouPCscreen
via Ethernet (Standard for all Danfoss Air units, at no
extra cost!)
• Makecustomizedweekprogramswiththeeasy-to-
use week program editor
• Monitorsanddisplaysalltemperaturesandrelative
humidity in the house, in a single screenshot
4.2 Controlling the
system by PC
4.0 Options
4.1 Replacement
filters
Replacement filters for your Danfoss Air unit can be
purchased from your installer.
G4 class filters are used as standard for both supply air
and exhaust air. A G4 filter will provide basic filtration of
particles larger than 10 μm. Use this filter for supply air
and exhaust, if you do not suffer from allergies.
Filter ordering, standard filters
w1, G4: 089F0238
w2, G4: 089F0239
a2, G4: 089F0236
a3, G4: 089F0237
If you or members of your family suffers from allergies,
choose the optional F7 filter, which will effectively filter
out pollen. The exhaust air filter does not affect the
indoor air quality, so should remain G4 class.
Filter ordering, pollen filters
w1, F7: 089F0242 (pollen filter)
w2, F7: 089F0243 (pollen filter)
a2, F7: 089F0240 (pollen filter)
a3, F7: 089F0241 (pollen filter)
(for supply air only)
Standard G4 filter
Optional F7 filter
DANFOSS HEATING 17
UK
4.0 Options
Home Clever Home
User manuel
Status Settings Week program Trends Advanced
Fresh air - Any time
Danfoss Air
System status
Manuel mode
Run mode
Status
Fan speed
Filter life
Power
Room temp.: 21 C
Room RH%: 45%
-7 C
2 C
20 C
18 C
Basic step: 6/10
Current step: 10/10
Filter life remaining: 73%
Change filters
Remaining power: 54%
Change battery
Boost
Defrost
User manuel
Home Clever Home
Status Settings Week program Trends Advanced
Fresh air - Any time
Danfoss Air
00 01 02 03 04 05 06 07 08 09 10 1 1 12 13 14 15 16 17 18 19 20 21 22 23 00
Is anybody
home?
When do
you shower?
When do
you cook?
Create the profile for week days: Press the icons and anwser the questions
Heating
Boost
4 4 4 4 4 4 4 33 3 3 4 4 4 4 4 4 4
18 18 18 18 18 18 18 22 22 22 3 22 22 22 22 22 22 22 22 18
• Seetrendcurvesforthelast14days;allrelevant
sensors are logged hourly (coming feature)
• Easyaccesstoadvancedsettings,allfunctionsare
described in a short and easy-to-understand text.
DANFOSS AIR18
5.0 Trouble shooting
Symptom Cause How to solve
Alarm beeper
active on Air Dial
remote control +
text in display:
The reason for the alarm can be
read in the display - push or rotate
dial to enter alarm screen. The
alarm screen will indicate what
type of alarm is present.
Depending on alarm - follow instructions as given below and sign “OK” for
alarm on the Air Dial remote control.
Alarm: Filter
error
Air filters are dirty Change air filters, see chapter 3.1 for
instructions
Alarm: Battery
low
Battery voltage is too low in the
Air Dial remote control.
Exchange batteries (4 x AAA) in Air
Dial, see instructions in chapter 3.2
Alarm: No connection to CCM
The communication between the
Air Dial remote control and the
CCM module has failed. The cause
is typically that a barrier has been
created in the vicinity of the CCM
module. A barrier could be steel
piping, other steel objects, or insulation material clad with aluminum
foil. Another cause can be other
wireless appliances that does not
conform to wireless standards
(radio noise).
If a barrier has been identified, move
it, if possible. If this is not practical,
relocate the CCM module to a better
location with a free “line of sight”. If
the error occurs due to other wireless
appliances in your house, try switching these off in turn, to identify the
faulty device.
If none of the above helps, please
contact your installer.
Alarm: No
connection via
modbus
The cable from the CCM module to
the unit has been unplugged or is
defective.
Check cable and reconnect if necessary. If cable is connected, but error
still occurs - contact your installer.
Alarm: Room air
too cold
The central heating system in the
building is not supplying heat. The
room temperature is dropping,
so the unit turn off, to reduce
involuntary heat loss. Alarm active
if the Air Dial measures a room
temperature below +10˚C
Check if heating system is functional.
If the problem can not be solved,
contact the plumber / installer responsible for your heating system.
Alarm: Fire One of the four temperature
sensors in the Danfoss Air unit, or
the temperature sensor in the Air
Dial remote control has detected
a temperature higher than +70˚C!
Unit turns off, and does not
continue operation again until all
the sensors indicate < +70˚C
Check all rooms, leave the premises.
DANFOSS HEATING 19
UK
Alarm: Sensor
error
One of the sensors in the Danfoss
Air unit, or the temperature sensor
in the Air Dial is defective
Contact your installer.
Excessive negative pressure
inside house,
doors binding
Exhaust air flow is larger than supply air flow. Either balancing has
not been carried out correctly during commissioning of the system
(if negative pressure was always
present) or the unit is in extreme
defrost conditions (can occur at
outdoor temperatures < -12˚C).
There should be a flow imbalance of
4-10% (in favour of the exhaust air),
but if you experience a permanent
problem with doors binding, contact
the installer. If the problem only
occurs in extreme winter conditions,
it is due to the integrated defrost
controller that reduces the supply air
(hence not a defect, but an expected,
and very rare occurrence)
Condensation in
window frames
occurs
Condensation occurs as a result of
low surface temperatures (i.e. cold
window frame or window glass)
and humid air. Typically occurs in
areas with local high humidity,
i.e. bathrooms or utility rooms
where clothes are drip drying. A
little condensation in a bathroom
following a shower is normal, but
it should dissappear within half
an hour.
Air exchange rate is too low to remove
excessive humidity. Increase fan step
if in manual mode, or change to either
demand mode or program mode (demand mode has a automatic “shower
detection” function, that boosts
airflow when you shower...
Noise from unit a-type unit: on rare occasions,
vibration can occur if unit is
mounted directly onto the joists.
Unit should be mounted on
suitable platform.
w-type unit: If the rubber spacers
have not been fitted at the rear of
the unit or if the silicone strip was
not fitted onto the wall bracket.
A defective fan bearing will
produce a “grinding noise”.
For a-type models:
Check that unit has platform acc. to
installer manual
For w-type models:
Check that rubber spacers and silicone
strip was fitted.
If you suspect that the fan bearing is
defective, contact your installer.
Noise from air
valves
- Air flow too high
- Pressure too high over valve
- No silencer fitted to main duct
In a correctly sized system, noise will
not be a problem. However, if the air
valves are accidently closed during
cleaning, this can cause a hissing
noise - so avoid turning the valves
when cleaning the ceiling.
5.0 Trouble shooting
VUEWA102 A1.02
INSTALLER´S STAMP
Danfoss A/S
Ulvehavevej 61
DK 7100 Vejle
Tel: +45 74 88 85 00
Direct: +45 74 88 87 13
www.danfoss.com
Loading...
