1090173, 1090174 Fan Drive Control Temperature Sensors
Technical Bulletin 1090173, 1090174 Fan Drive Control Temperature Sensors
CONTENTS
Description ..........................................................................................................................................................................3
Features ................................................................................................................................................................................3
Technical Data....................................................................................................................................................................3
Dimensions.......................................................................................................................................................................... 4
Repair Information............................................................................................................................................................ 5
Available Models ...............................................................................................................................................................5
Customer Service ..............................................................................................................................................................5
2
BLN-95-9063-1 March 2001
©
Copyrig ht 2001, Sauer-Danfos s (US) Company.
All right s reserved. Co ntents subjec t to change.
Technical Bulletin 1090173, 1090174 Fan Drive Control Temperature Sensors
DESCRIPTION
FEATURES
The Sauer-Danfoss family of analog tem­perature sensors is designed to operate in conjunction with Sauer-Danfoss Fan Drive Control (FDC) electronic modules. The sensors have been engineered to provide years of dependable service while operating in harsh on and off road environments.
Integrated connector and sensor body
Brass body construction
Anti-fouling air temperature sensor design
Two models are available: An air sensor typically used to measure engine charge air temperature and a liquid sensor typi­cally used to measure engine coolant or oil temperature.
50° C to 125° C operating temper- ature range, FDC software confi gu­rable
TECHNICAL DATA
!
For proper operation, air
temperature sensors must
be mounted at the top of
the manifold pipe with the
sensor tip facing down.
The 1090173 and 1090174 are thermistor-type temperature sensors. (See Table A.)
Table A. Temperature Versus Resistance Limits.
MEASURED RESISTANCE, OHMS TEMP. ° C NOM. TOLERANCE
50 810.9 ±5% 80 283.0 5% 100 152.9 ±8% 125 76.9± ±8%
Connector
Delphi Metri-Pack 150 series
Mating Connector
Mating Connector Bag Assembly:
Sauer-Danfoss part number K23436
BLN-95 -9063-1 March 2001
©
Copyrig ht 2001, Sauer-Danfos s (US) Company.
All right s reserved. Co ntents subjec t to change.
3
Technical Bulletin 1090173, 1090174 Fan Drive Control Temperature Sensors
DIMENSIONS OF THE 1090173 FAN DRIVE CONTROL LIQUID TEMPERATURE SENSOR
56,0 mm
2.20 in REF
27,1 - 28,1 mm
1.07 - 1.11 in
16,2 - 17,0 mm
0.64 - 0.67 in
CONNECTOR: METRI-PACK 150 SERIES
HEXAGON: 3/4 in A/F
THREAD: 3/8 in X 18 NPTF
Ø 10,0 - 10,8 mm
0.39 - 0.43 in
2053
DIMENSIONS OF THE 1090174 FAN DRIVE CONTROL AIR TEMPERATURE SENSOR
4
56,0 mm
2.20 in REF
27,1 - 28,1 mm
1.07 - 1.11 in
BLN-95-9063-1 March 2001
16,2 - 17,0 mm
0.64 - 0.67 in
CONNECTOR: METRI-PACK 150 SERIES
HEXAGON: 3/4 in A/F
THREAD: 3/8 in X 18 NPTF
4 X Ø 6,0 mm (0.24 in) CROSS DRILLED HOLES
Ø 10,0 - 10,8 mm (0.39 - 0.43 in)
©
Copyrig ht 2001, Sauer-Danfos s (US) Company.
All right s reserved. Co ntents subjec t to change.
2054
Technical Bulletin 1090173, 1090174 Fan Drive Control Temperature Sensors
REPAIR INFORMATION
Temperature sensors are not repairable and must be replaced if a failure occurs.
AVAILABLE MODELS
Liquid temperature sensor
Sauer-Danfoss part number: 1090173
CUSTOMER SERVICE Order From
Sauer-Danfoss (US) Company Customer Service Department 3500 Annapolis Lane North Minneapolis, Minnesota 55447 Phone: (763) 509-2084 Fax: (763) 559-0108
Air temperature sensor
Sauer-Danfoss part number: 1090174
Sauer-Danfoss (Neumünster) GmbH & Co. Order Entry Department Postfach 2460, D-24531 Neumünster Krokamp 35, D-24539 Neumünster Phone: +49 4321 871 0 Fax: +49 4321 871 284
