OWNER’S MANUAL /

Danby Products Limited, PO Box 1778, Ontario, Canada N1H 6Z9

Danby Products Inc., PO Box 669, Findlay, Ohio, USA 45839-0669

Version 1 .01.08

ALL REFRIGERATOR

Owner’s Manual . . . . . . . . . . . . . . . . . . . . . . . . 1-5

• Safety Instructions

• Installation & Operation

• Features

• Door Reversal

• Care and Maintenance

• Warranty

TOUS LES RÉFRIGÉRATEURS

GUIDE DU PROPRIÉTAIRE . . . . . . . . . . . . . . .6-10

• Consignes de sécurité

• Installation et utilisation

• Caractéristiques

• Inversion de la porte

• Entretien

• Garantie

R

?

GUIDE DU PROPRIÉTAIRE

Model / Modele

DAR0488W/BL

CAUTION:
Read and Follow All Safety

Rules and Operating
Instructions Before First Use
of this Product.

ATTENTION :
Avant d’employer ce produit,

lisez toutes les règles de
sécurité et les instructions

Remove exterior and interior packaging; wipe the outside
thoroughly with a soft dry cloth and the inside with a wet,
lukewarm cloth. Avoid placing the cabinet in a narrow
recess or near any heat source, direct sunlight, or
moisture. Let air circulate freely around the cabinet. Keep
the rear of the refrigerator 2 inches away from the wall.

Location

1. Select a place with a strong, level floor.

2. Allow 2 inches of space between the back of the
refrigerator and any adjacent wall.

3. Avoid direct sunlight and heat. Direct sunlight may
affect the acrylic coating. Heat sources nearby will
cause higher electricity consumption.

Please note the following clearance area that is required
around the refrigerator:

• Sides: 19mm (3/4”)

• Top: 100mm (4”)

• Back: 50mm (2”)

To start the refrigerator, turn the temperature control to
the position corresponding to the desired cooling (thin
line is least cold, thicker line is most cold).

The refrigerator temperature will vary depending on the
quantity of food stored and on the frequency that the
door is opened.

Setting the Thermostat

The thermostat setting can be adjusted from the thin end
of the graduated blue line (minimum setting) up to the thick
end of the graduated blue line (maximum setting). The
thermostat dial is located inside the refrigerator on the
back top-right corner of the cavity.

1. Temperature Control Knob

2. Light

3. Cold Sink Fan Cover

4. Shelf

5. Light Switch

6. Legs

7. Door Liner

8. Upper Hinge Cover

9. Small Bottle Rack

10. Door Gasket

11. Large Bottle Rack

12. Door

ATTENTION

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electrical shock by providing an escape wire for the
electrical current. This appliance is equipped with a
cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is
properly installed and grounded.

WARNING - Improper use of the grounding plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the grounding instructions
are not completely understood, or if doubt exists as
to whether the appliance is properly grounded.

DO NOT USE AN EXTENSION CORD

Use an exclusive wall outlet. Do not connect your
refrigerator to extension cords or together with any
other appliance in the same wall outlet. Do not splice
the cord.

IMPORTANT WARNING

An empty refrigerator is a very dangerous attraction
to children. Remove either the gasket, latches, lids or
doors from unused appliances, or take some other
action that will guarantee it harmless.

DON’T WAIT! DO IT NOW!

SAVE THESE INSTRUCTIONS !

1

Safety Instructions

Installation & Operation

Features

1

2

3

4

5

6

7

8

9

10

11

12

Least Cold

Coldest

Tools: Phillips #2 Screwdriver

1.

Unplug the refrigerator and empty all of its contents

2. Remove the Plastic Retaining Cap from the top left side of the cabinet.

3. Remove the Top Door Pin Cap from the top left side of the door.

4. Remove the Plastic Hinge Cap from the right side of the cabinet.

5. Unscrew the three screws holding the Top Hinge Assembly to the cabinet (on the right side of the unit) and remove
the hinge.

6. Install the Top Hinge Assembly on the top left side of the cabinet.

7. Insert the Top Door Pin Cap into the top right side of the door.

8. Lay the unit on its back.

9. Unscrew the Three Retaining Screws on the bottom left side of the cabinet.

10. Unscrew the three screws holding the Bottom Hinge to the cabinet and remove the hinge.

11. Install the Bottom Hinge on the bottom left side of the door and cabinet.

12. Install the Three Retaining Screws on the bottom right side of the cabinet (the former bottom hinge location).

Door Reversal Instructions

Plastic Retaining

Cap

Bottom Hinge

Three Retaining Screws

Top Door

Pin Cap

Top Hinge Assembly

(Hinge + Plastic Cap)

2

3

Cleaning

Before cleaning the refrigerator, always disconnect the
refrigerator from the power supply. To clean the
inside, use a soft cloth and a solution of a tablespoon
of baking soda to one quart of water, or a mild soap
suds solution, or some mild detergent. Wash glide out
shelves in a mild detergent solution, then dry and
wipe with a soft cloth. Clean the outside with a soft
damp cloth and some mild detergent or appliance
cleaner.

Vacation Time

For short vacation periods, leave the control knob at
the usual setting. During longer absences;
(a) remove all foods,
(b) disconnect from electrical outlet,
(c) leave door open to avoid possible formations of

condensate, mold or odors.

Power Failure

Most power failures are corrected within an hour or
two and will not affect your refrigerator temperatures.
However, you should minimize the number of door
openings while the power is off. During power failures
of longer duration, take steps to protect your food by
placing dry ice on top of packages.

If You Move

Remove or securely fasten down all loose items inside
the refrigerator. To avoid damaging the leveling legs,
turn them all the way into the base.

Some Important Rules for the
Correct Use of the Refrigerator

• Never place hot foods in the refrigerator.

• Beverages should be stored in sealed containers.

• Foods to be stored for a long time should be
wrapped in cellophane or polyethylene, or kept in
glass containers. Never place spoiled foods in the
cabinet.

• Don’t overload the cabinet.

• Don’t open the door unless necessary.

• Should the refrigerator be stored without use for
long periods it is suggested, after a careful cleaning,
to leave the door ajar to allow the air to circulate
inside the cabinet in order to avoid possible
formations of condensate, mold or odors.

Food Storage Suggestions

Fresh Food Compartment

• Never cover food compartment shelves with
aluminum foil or any other shelf covering material
which may prevent air circulation.

• Allow warm foods to cool to room temperature
before placing them in the refrigerator.

• Always cover open dishes of food, especially
leftovers. Use leftovers within 2 or 3 days.

Care and Maintenance
