Dahua DH-SD42C215-HC-LA User Manual

HDCVI Series | DH-SD42C215-HC-LA

DH-SD42C215-HC-LA

2MP 15x Starlight HDCVI PTZ Camera

· 1/2.8" 2Megapixel STARVIS™ CMOS

· Powerful 15x opcal zoom

· Starlight technology

· 120 dB true WDR, 3D DNR

· Max. 25/30 fps@1080P, 25/30/50/60 fps@720P

· IK10

0.005

Starlight

Day/Night

Lux

Featuring with powerful opcal zoom and accurate pan/lt/zoom perfor­mance, the SD42C series PTZ camera can provide large monitoring range

and great detail. The camera delivers 1080P resoluon at 25/30 fps, with
15x opcal zoom, and has very excellent low light performance due to

the latest starlight technology. SD42C series PTZ camera is equipped with

smooth control, high quality image and good protecon, which makes it
meet small and medium-sized video surveillance applicaons.

Funcons

Simplicity

HDCVI technology inherits the born feature of simplicity from tradional
analog surveillance system, making itself a best choice for investment
protecon. HDCVI system can seamlessly upgrade the tradional
analog system without replacing exisng coaxial cabling. The plug and

play approach enables full HD video surveillance without the hassle of

conguring network.

Starlight Technology

For challenging low-light applicaons, Dahua's Starlight Ultra-low Light
Technology oers best-in-class light sensivity, capturing color details in
low light down to 0.005 Lux. The camera uses a set of opcal features to
balance light throughout the scene, resulng in clear images in dark

environments.

PFA Technology

PFA technology has innovavely introduced new methods of judgment
to ensure the accuracy and predictability of the direcon of subject dis­tance adjustment. The result is a set of advanced focusing algorithms.
PFA ensures clarity of the image throughout the process of zooming
and shortens focus me. The realizaon of PFA technology substanally

improves user experience and increases product value.

Environmental

With a temperature range of -30 °C to +60 °C (-22°F to +140 °F), the

camera is designed for extreme temperature environments. The camera

complies to an IK10 impact rang.

Wide Dynamic Range

The camera achieves vivid images, even in the most intense contrast

lighng condions, using industry-leading wide dynamic range (WDR)
technology. For applicaons with both bright and low lighng condions
that change quickly, True WDR (120 dB) opmizes both the bright and
dark areas of a scene at the same me to provide usable video.

Protecon

This camera suits even the harsh condions for outdoor applicaons.
Its 6KV lightning rang provides protecon against the camera and its
structure from the eects of lightning.

www.dahuasecurity.com

HDCVI Series | DH-SD42C215-HC-LA

Technical Specificaon

Camera

Image Sensor

Pixel

Max. Resolution

ROM

RAM

Electronic Shut ter Speed

Scanning System

Min. Illumination

Lens

Focal Length

Max. Aperture

Field of View

Optical Zoom

Focus Control

Close Focus Distance

Iris Control

DORI Distance

PTZ

Pan/Tilt Range

Manual Control Speed

Preset Speed

Presets

Tour

Pattern

1/2.8" S TARVIS™ CMOS

2MP

1920 (H) x 1080 (V)

16 MB

256 MB

1/3 s–1/100 000 s

Progressive

Color: 0.005 Lux@F1.6
B/W: 0.00 05 Lux@F1.6

5 mm–75 mm

F1.6–F2. 8

H: 58.9–5.1; V: 34.1–2.9; D: 66.6–5.8

15x

Auto/Semi-Auto/Manual

1 m–1.5 m (3.28 ft–4.92 ft)

Auto/Manual

Detect Observe Recognize Identify

1034 m
(3392.39 ft)

Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180°

Pan: 300°/s; Tilt: 20 0°/s

Pan: 300°/s; Tilt: 20 0°/s

300

8 (up to 32 presets per tour)

5

409 m

(1341.86 ft)

205 m

(672.57 ft)

103 m
(337.93 ft)

WDR

HLC

White Balance

Gain Control

Noise Reduction

Motion Detection

Region of Interest (RoI)

Image Stabilization

Defog

Digital Zoom

Flip

Privacy Masking

Audio

Compression

Function

CVI Product Output Mode

Certification

Certifications

Port

Analog Output

RS485

Audio Input

Alarm Input

Alarm Output

Power

Power Supply

Power Consumption

120 dB

Support

Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/
Natural light/Street lamp

Auto/Manual

2D/3D

Support

Support

Electronic

Electronic

16x

0°/180°

Up to 24 areas

G.711 a; G.711Mu

CVI; TVI; AHD; CVB S

CE: EN55032/EN55024/EN50130- 4
FCC: Par t15 subpar tB, ANSI C63.4-2014
UL: UL60 950-1+CAN/CSA C22.2, No.60950-1

1 (CVBS/C VI output, BNC por t)

1 (baud rate ran ge: 1200 bps–9600 bps)

1

2

1

DC 12V/5A ± 10%

Basic: 9.6W
Max: 12W (module zooming, PTZ operations)

Scan

Speed Adjustment

Power-off Memory

Idle Motion

Protocol

Video

Resolution

Frame Rate

Day/Night

BLC

5

Support

Support

Preset/Tour/Pattern/Scanning

DH-SD

Pelco- P/D (auto recogni tion)

1080P (1920 × 1080); 720P (1280 × 720); D1 (704 ×
576/704 × 480)

1080P (25/30 fps); 720P (25/30/50/60 fps)

Support

Support

www.dahuasecurity.com

Environment

Operating Temperature

Operating Humidity

Protection

Structure

Dimensions

Net Weight

Gross Weight

-30°C to +60°C (-22°F to +140°F)

≤ 95%RH

IK10; TVS 6000V lightning protec tion; surge protection

158 mm × Φ198 mm (6.22" × Φ7.80")

2.3 kg (5.07 lb)

3.3 kg (7.28 lb)
