Product Presentation
Bakesmart
The perfect
product for
small bakeries
and shops
Bakesmart is a baking oven which perfectly
suits the needs of small bakeries and active
service shops. Easy to use, easy to place,
easy to handle and easy to keep clean.
Thanks to Bakesmart you can bake almost
everything in your shop – from black rye
bread, baguettes and rustic bread to tasty
coffee-bread. But Bakesmart is more than
just a smart oven. You can complement
it with a prover, storage chamber and
evacuation system in several combinations.
It is also possible to install two ovens
one above the
other.
“The scent of fresh baked bread is the absolute
strongest buying signal you can give to your
customers when they enter your shop.
And with the smell of fresh baked it is always
easier to sell a bit more than
you had imagined...”
Examples of Bakesmart combinations:
Left: Bakesmart with a high storage chamber.
Middle: Two Bakesmarts with a low storage cabinet.
Right: Bakesmart with condensating unit and prover.
570
1050
855
Compact design
Bakesmart is specially designed for
small bakeries and shops which want
to be able to offer customers fresh
bread from morning to evening.
The oven is of the convection type –
because the guides on the oven sides
can be easily switched – there is place
for 4 or 5 trays. The tray size is
600 x 400 mm.
Bakesmart features the standard
Classic control panel with nine baking
programmes and a possibility to
manually adjust the settings during the
process of baking.
Smart solutions
Bakesmart features a built-in steam
function and lighting inside the oven.
The detachable tray guides and the
possibility to remove the glass door
enables easy cleaning and makes it
easy to supervise the baking process.
The oven also has a number of
accessories, including a panel with
colour display, which makes the
baking more effective and easier.
Provers, storage chambers and
evacuation systems are other practical
accessories which provide a better
working environment and facilitate the
everyday life of the baker.
Accessories
Colour Panel
Programmable
panel with colour
display.
Stores up to 99
recipes, displaying
names and
temperature curves.
Prover
With time and alarm functions. Easy
temperature settings and a steam function.
Capacity for 2 x 8 shelves 400 x 600 mm.
Storage chamber (low and high)
Lower cabinet, available in 2 sizes;
for 2 x 4 or 2 x 8 trays 400 x 600 mm.
Technical information, oven
Power Weight Tray size
7,5 kW 135 kg 600 x 400
Technical
Power
info. prover
Weight Tray size
2 kW 110 kg 600 x 400
Measures
Panels
CLASSIC PANEL
Programmable panel
with a digital display of
time and temperature
as a standard. Can
store nine recipes.
Evacuation system
The evacuation system is available with
a built-in condensation unit and a fan
leading out the heat when the oven door is
opened. Does not need to be connected to
the ventilation.
COLOUR PANEL
Bakesmart can be
equipped with a control panel with colour
display.
Programmable, storing up to 99 recipes,
displaying names and
temperature curves.
BAKESM ART OVEN
1000
CONDEN SATING UNIT
1450
600
STORAGE LOW
2020
350
1850
600
920
STORAGE HIGH
1850
920
Subject to alteration
without notice
PROVER
We have the oven
for your bakery
IllustratIon & InformatIon, Borås
Sveba-Dahlen develop, market and manufacture rack,
deck and tunnel ovens, proving chambers and
fermentation lines for professional baking.
We also supply supplementary bakery equipment which makes the
work more efcient in both large and small bakeries world wide.
Visit our website!
www.sveba-dahlen.com
Sveba-Dahlen AB, SE-513 82 Fristad
Phone: +46 (0)33-15 15 00, Fax: +46 (0)33-15 15 99, info@sveba-dahlen.com
1427-324
Scandinavian know-how – worldwide
