Daewoo ST140W User Manual

VIDEO CASSETTE PLAYER

ST140W

OWNER’S MANUAL

IMPORTANT SAFEGUARDS

DAEWOO Video Cassette Player 2

For your protection, please read these safety instructions completely before operating
the appliance, and keep this manual for future reference.
Carefully observe all warnings, precautions, and instructions on the appliance, or the
ones described in the operating instructions and adhere to them.

DRAWING YOUR ATTENTION

DAEWOO Video Cassette Player1

Thank you purchasing this VCP, developed to provide advanced features and functions for
high quality performance.
To obtain the best results and to avoid malfunction, PLEASE CAREFULLY READ THE
DESCRIPTIONS AND OPERATING PROCEDURE CONTAINED IN THIS OWNER’S
MANUAL PRIOR TO OPERATING THIS VCP.

Caution : To prevent electric shock do not use this polarized plug with an extension

cord receptacle or other outlet unless the blades can be fully inserted to
prevent blade exposure.

Warning : This video cassette player should be used with AC 90-250V~, 50/60Hz.

To prevent electric shocks and fire hazards, do NOT use any other power
source.

Caution : Any changes or modification in construction of device which are not

expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
When you are not using the VCP for along period, it is recommended that
you disconnect the power cord from the AC outlet.

WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE OF THE
ENCLOSURE.
DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED
PERSONNEL ONLY.

The exclamation point within an equilateral triangle is intend to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.

The lightning flash wish arrowhead symbol an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.

RISK OF ELECTRIC SHOCKS

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

THE COVER )OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

USE

Power Sources – This set should be operated

only from the type of power source indicated on
the marking label. If you are not sure of the type
of electrical power supply at your home, consult
your dealer or local power company. For those
sets designed to operate from AC90-250V~,
50/60Hz.

Overloading – Do not overload wall outlets,
extension cords or convenience receptacle
beyond their capacity, since this can result in fire
or electric shock.

Grounding or Polarization – This set is
equipped with a polarized AC power cord plug (
a plug having one blade wider than the other), or
with a threewire grounding type plug (a plug
having a third pin for grounding).
Follow the instructions below.

Attachments – Do not use attachments not
recommended by the manufacturer, as they
may cause hazards.

Cleaning – Unplug the set from the wall out let
before cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth lightly
dampened with water for cleaning the exterior of
the set.

Object and Liquid Entry – Never push objects
of any kind into the set through openings as
they may touch dangerous voltage points or
short out parts that could result in a fire or
electric shock. Never spill liquid of any kind on
the set.

Water and Moisture – Do not use powerline
operated sets near water- for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in
a wet basement, or near a swimming pool, etc.

Accessories – Do not place the set on an
unstable cart, stand, tripod, bracket, or table. The
set may fall, causing serious injury to a child or
an adult, and serious damage to the set. Use
only a cart, stand, tripod, bracket, or table
recommended by the manufacturer.

DAEWOO Video Cassette Player 4

SERVICE

DAEWOO Video Cassette Player3

MOISTURE CONDENSATION

Ventilation – The slots and openings in the

cabinet are provided for necessary ventilation. To
ensure reliable operation of the set, and to
protect it from overheating, these slots and
openings must never be blocked or covered.

– Never cover the slots and openings with a cloth

or other materials.

– Never block the slots and openings by placing

the set on a bed, sofa, rug or other similar
surface.

Damage Requiring Service – Unplug the set
from the wall outlet and refer servicing to
qualified service personnel under the following
conditions:

– When the power cord or plug is damaged or

frayed.

– If the set has been subjected to excessive

shock by being dropped, or the cabinet has
been damaged.

– If liquid has been spiled or objects have fallen

into the set.

– If the set does not operate normally When

following the operating instructions, adjust only
those controls that are specified in the
operating instructions. Improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the set to normal
operation.

– If the set has been exposed to rain or water.

– When the set exhibits a distinct change in

performance, this indicates a need for service.

Servicing – Do not attempt to service the set
yourself as opening or removing covers may
expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.

Safety Check – Upon completion of any service
or repairs to the set, ask the service technician
to perform routine safety checks (as specified by
the manufacturer) to determine that the set is in
safe operating condition.

Replacement of parts – When replacement of
parts is required, be sure the service technician
has used replacement parts specified by the
manufacturer that have the same characteristics
as the original parts. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.

Power-Cord Protection – Route the power cord
in order not to be walked on or pinched by items
placed upon or against them, paying particular
attention to the plugs, receptacles, and the point
where the cord exits from the appliance.

– Do not place the set over a radiator or heat

register, or where it is exposed to direct
sunlight.

In the normal temperature, if you
pour a cold liquid into a glass,
water vapour in the air will
condense on the surface of the
glass.
This is moisture condensation.
The moisture condensation may
occur inside of VCPs, if used in this
condition, it will cause damage to
the head and the tape.

In case of moving the VCP from a
cold place to heated place.
Or the temperature of surroundings
goes up due to room heating
switched on.
Or moving the VCP suddenly from
airconditioned room to a place of
high temperature of humidity in
summer.

When the moisture condensation
occurs inside of the VCP, NEVER
insert the cassette into the cassette
compartment.
Remove the cassette, if loaded, by
pressing the STOP/EJECT key.
Only operate the VCP after the
moisture condensation has
completely dried out.
Normally, it takes about 2 hours.

Portable Cart Warning – An appliance and
cart combination should be moved with care.
Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.

– Never place the set in a confined space such as

a bookcase, or built-in cabinet unless proper
ventilation is provided.

DAEWOO Video Cassette Player 6DAEWOO Video Cassette Player5

IMPORTANT NOTES

• Audio-visual material may include works of copyright which must NOT be recorded
without the authority of the owner of copyright.

• Note that main voltage is supplied to the unit whenever the main plug is connected to
the supply socket.

• To avoid the risk of fire or electric shock, do not expose the unit to rain or moisture.

• Do not attempt to open the cabinet. There are no user-serviceable parts inside.
Refer all servicing to qualified service personnel.

• Keep the unit away from radiators or other sources of heat.

• Do not operate or store the unit close to strong magnetic fields.

• Do not spill liquid if any kind onto the unit. If liquid is accidentally spilled onto the unit,
immediately remove the main plug from the supply socket, and consult a qualified
service engineer.

• Avoid places subjected to strong vibration.

• Do not place anything heavy on the VCP.

• Use the video cassette player in a horizontal (flat) position only.

• Before operating, remove any paper wrapping which may have been affixed to the
player during manufacturing.

• DO NOT COVER VENTILATION OPENINGS ON TOP AND SIDES OF THE

PLAYER DURING OPERATION.

• When a cassette is inserted into the loading compartment, the power is switched on
automatically as long as the power cord is plugged into an AC outlet. DO NOT force
a cassette into the compartment when the power cord is unplugged.

• Keep the player and video cassette away from strong magnetic fields.

• After playing a video cassette, remove it from the player. DO NOT move the player
with a cassette in the compartment.

• Store video cassettes in their sleeves or cases and position vertically.

• If a cassette has been subjected to cold temperature, allow it to warm to room
temperature before recording or playback.

Model Number :
Serial Number :
Date Purchased :
Store’s Name and Address :

For your protection, record the model and serial numbers of your video cassette
player here.
In the event your player requires servicing or is stolen, you may need this information.
You may also wish to clip or staple your sales receipt to this page.

TABLE OF CONTENTS

NOTE : This Video Cassette Player is compatible with any Video Player bearing the

VHS mark. The VCP is designed to expand your opportunities for home
viewing and not for any usage which might violate the copyright laws.

Save the original shipping carton and packing materials; they will come in handy if you
ever have to ship your VCP. For maximum protection, repack the set as it was
originally packed at the factory.

DRAWING YOUR ATTENTION
IMPORTANT SAFEGUARDS
TABLE OF CONTENTS
INTRODUCTION
IDENTIFICATION
TO GET STARTED
VIDEO CHANNEL SETTING
BASIC OPERATION
SPECIAL OPERATION
VIDEO SYSTEM
RECORDING TV PROGRAMS
BEFORE CALLING SERVICE PERSONNEL
SPECIFICATIONS

1
2
6
7

8
12
13
14
16
18
19
21
22

ACCESSORIES

Carefully remove the VCP from the carton. Check that the VCP has not been
damaged. The following accessories are included.

1. Wireless Remote
Control NOTE:Required
2 ‘AAA’ batteries.

2. Coaxial cable for
connecting the VCP to
your TV’s VHF terminal.

3. Batteries for Remote
Control.

DAEWOO Video Cassette Player 8DAEWOO Video Cassette Player7

IDENTIFICATION

This section summarizes the buttons, controls, and terminals that you will use with
your VCP.

STANDBY/ON

Press to turn the VCP on or off

STOP/EJECT

Press to stop tape movement and to eject a video cassette.

TRACKING

Press to adjust the tracking of tape automatically during
playback

AUTO REPEAT

Press to re-playback after rewinding

REW

Press to rewind a video cassette.

PLAY

Press to play a video cassette or press to during video
cassette playback to temporarily stop playback.

FF

Press to fast forward a video cassette.

REC/OTR

Press to record the program currently airing on the channel.
Press multiple times to process one-touch-recording (OTR)
time options.

VIDEO/AUDIO

Front input sockets for connecting a camcorder.

INTRODUCTION

CONGRATULATIONS on your purchase of a new VHS VCP.
This VCP is an existing, new VCP designed to satisfy all your VHS tape play and
recording needs.
And, with proper used and care, your new VCP will offer many year of viewing
enjoyment.
Just a few of the feature include.

• NTSC PLAYBACK ON PAL TV:

• You can playback not only PAL tape but NTSC tape on PAL TV.

• LINE RECORDING

• NTSC 3.58/4.43 RECORDING & PLAYBACK

• You can record not only PAL/MESECAM but NTSC (3.58/4.43)

• QUICK START

• Various operation keys operate quickly when each of them is pressed.

• DIGITAL AUTO TRACKING

• This VCP plays clear pictures without special operations.

• AC POWER SUPPLY (AC 90-250V~)

• COMPLETE SAFETY DEVICE

• When this VCP is not in normal condition, it stops operating automatically for self-

protection.

• SELF PICTURE ADJUSTMENT

• Since the HEAD DRUM rotates regularly depending on the voltage change or tape

condition, the picture is always stable.

• ENCORE FUNCTION

• Press the ENCORE key on the remote control to watch the desired picture once

more during playback.

• BUILT-IN WIDE RANGE MODULATOR (CH. 21 - CH. 40)

• BUILT-IN MULTI RF OUT MODULATOR (PAL-G/K/I)

• AUTO REPEAT SEARCH FUNCTION

• If you press the A.REPEAT key during playback, the tape will be replayback after

rewinding.

• 2 STEP PICTURE SEARCH

• CHILD LOCK

• COMMERCIAL SKIP

• OTR

When the power indicator is blinking on the display panel,
the VCP is in the child lock mode.

DAEWOO Video Cassette Player

10

IDENTIFICATION (continued)

REMOTE CONTROL BASIC FUNCTION

TV/VCR(not used)

TURN ON/OFF

CM SKIP

AUTO REPEAT

ENCORE

FAST FORWARD/CUE

PLAYBACK

TRACKING -/+

CHANNEL -/+

RF OUTPUT SELECTION

SPEED

VISS

SLOW

EJECT

DISPLAY

PAUSE/STILL FRAME

REWIND/REVIEW

STOP

RETRACKING

RECORD/OTR
INPUT

SYSTEM SELECT (PAL/NTSC)

IDENTIFICATION(continued)

DAEWOO Video Cassette Player9

FRONT PANEL DISPLAY

1. POWER

Indicates that the VCP Power is on.

2. RECORD

Indicates that the VCP is recording a program.

3. PLAY

Indicates that the VCP is in PLAY mode.

4. A. REPEAT

lndicates that the VCP is in Auto Repeat mode.

BACK PANEL

1. VIDEO IN/OUT

Attach the VCP’s video input/output
at there terminals.

2. AUDIO IN/OUT

Attach the VCP’s audio input/output
at there terminals.

3. ANT IN TERMINAL

Connect the TV antenna to the
terminal.

4. ANT OUT TERMINAL

Connect to the antenna terminal of
the TV receiver through the RF
cable (Provided).

TO GET STARTED

ANTENNA CONNECTION

1. Remove the Antenna Cable from the TV set. Connect it to the “ANT.IN” terminal of
the VCP.

2. Connect one end of the RF cable to the “ANT.OUT” terminal of the VCP.

3. Connect the other end to the “ANT.IN” terminal of the TV.

REMOTE CONTROL OPERATION RANGE

IDENTIFICATION(continued)

DAEWOO Video Cassette Player11

7m

1. Any object between the remote
control and VCP will block the path
of beam when it is being used.
Dark walls, direct sunshine or very
bright (incandescent) light will reduce
the remote control sensitivity.

2. Hold the remote control within an
angle range of about 30ofrom either
side of the remote sensor center as
shown.

3. When the remote control is vertical to
the remote Sensor, it will work within
about 23feet (7m) from the VCP.

4. Point the front of the remote control
directly at the front of the VCP.

30o30

o

BATTERY INSTALLATION

1. Remove the battery cover on the reverse side of the remote control.

2. Install 2 batteries (“AAA” size) into the remote control. (Carefully install batteries to
match the polarity diagrams)

3. Close the battery cover.

• It is advisable to take batteries out of the remote control when it is not in use for a

long time.

DAEWOO Video Cassette Player

12

1 Turn on your TV.
2 Connect the ANT.IN jack on the rear

panel of TV by using the RF cable.

3 Turn on the VCP to display the “ ”

red color indicator on the panel.

4 Tune the TV in to the UHF

channel 36.

5 Press the “RF OUT CH” key on the

remote control. The “PR:36” display
will blink on screen

6 Change the RF out channel by

pressing the “CH/TRK+/-” key on the
remote control

7 Press the “RF OUT CH” key to memory

the changed RF out channel

8 Tune our TV in to the changed UHF

channel

1 Turn on your TV.
2 Connect the ANT.IN jack on the rear

panel of TV by using the RF cable.

3 Playback the tape.
4 Tune the UHF channel 36. If the

sound is poor, set the RF OUT

system by pressing the “RF OUT

SYS” key on the remote control, the

system will be rotated as follows.

PAL-G PAL-K PAL-I

BASIC OPERATION

CASSETTE LOADING/UNLOADING

LOADING UNLOADING

• An inverted cassette cannot be inserted.

• Upon inserting the cassette, the power
is on even if the power is off as long as
the AC power cord is plugged in.

• When you press the STOP/EJECT key
even if the power is off, the cassette will
be ejected.

1 Push the cassette into the cassette

compartment gently.

(Arrow mark at the top)

2 The cassette indicator LED is lit up.

1 Press the STOP/EJECT key twice on the

VCP (in the PLAYBACK mode) or press
EJECT key once on the remote control.
This first press will stop the tape in any
mode except AUTO REPEAT. The
second press will eject the tape. The
cassette indicator LED will be lit out.

2 Pull the cassette out gently.

DAEWOO Video Cassette Player13

VIDEO CHANNEL SETTING

The built-in RF converter permits
playback of video and audio recordings
through a TV receiver. The signals
from the RF converter are viewed
through a vacant channel not used for
broadcasting in your viewing area.

The converter channel of all units is set
to UHF channel 36 prior to shipment.
Setting your TV receiver to UHF
channel 36 may provide video
playback. But, to obtain the best
possible reproduction on your TV
receiver, accurate adjustment to the
RF converter output is required.

VCP RF OUT CHANNEL SETTING VCP RF OUT SYSTEM SETTING

ERASURE PROTECTION

Video cassettes are equipped with a safety tab to prevent accidental erasure.
When the tab is removed, recording can not be performed.

• TO PREVENT ACCIDENTAL
ERASURE

• After recording, break off the safety tab
with a screwdriver if you don’t want to
record over the tap.

• TO RECORD AGAIN

• Cover the hole with cellophane tape.

DAEWOO Video Cassette Player

14

SPECIAL OPERATION

* CAUTION : In the Search +/- X1/2 mode, the picture can be flowed in a certain TV. In

this time you can steady it by using the TRK +/- keys on the remote control.

The VCP enters into the PLAYBACK mode during special
operations as soon as pressing the PLAY key.

• Press the FF key once in the
PLAYBACK mode. And then the
tape advances rapidly with the
pictures. Pressing this key once
more makes the VCP advance more
rapidly.

• Press the REW key once in the
PLAYBACK mode. And then the
tape will be rewound rapidly with
the pictures. Pressing this key once
more makes the VCP rewound
more rapidly.

• Press the SLOW key during playback.
You can watch the desired frame in detail.

• Press the FF/REW key during slow.
It allows you to control the slow motion
speed of picture.

• Press the P/S key during
playback. If this key is pressed
on during still the picture
advances frame by frame.

1 TO VISUALLY SEARCH FORWARD

3 TO WATCH SLOW PICTURE 4 TO WATCH A STILL PICTURE

2 TO VISUALLY SEARCH REVERSE

DAEWOO Video Cassette Player15

BASIC OPERATION (continued)

DAEWOO Video Cassette Player 16

The power is on automatically when the
cassette is inserted even if the power is
off.

Press the PLAY key, then
pictures will appear within 1
second and PLAY indicator will
display.
The tape is rewound
automatically to the beginning
after playing to the end.

Press the STOP/EJECT key
once. The tape will stop but
remain fully loaded and ready
to play.

Press the FF key in the STOP
mode and then FF indicator will
appear. The tape advances at
high speed without any picture
and sound.

Press the REW key in the STOP
mode and then REW indicator will
appear. The tape is rewound at
high speed without any picture
and sound.

Press the STOP/EJECT key
once more (in the STOP mode)
on the frond panel or press the
EJECT key once on the remote
control.

1 LOADING 2 PLAYBACK

3 STOP

4 FAST FORWARDING

5 REWINDING 6 EJECTING

AUTO TRACKING ADJUSTMENT

RETRACKING

• Since this VCP has the Auto Tracking Adjustment function, it can play clear pictures
without special operations.

• Auto Tracking Adjustment operates automatically when the cassette is inserted.

• If noise bars appear in the picture during playback, press the TRK+/- keys on the
remote control to reduce the noise bars.

• Press the R.TRK key when the playback picture is noisy. This VCP will control the
state of playback image automatically.

BASIC PLAYBACK

Each key of remote control functions identically with the keys on the front panel.
NOTE : This VCP has Full Auto Function.

NOTE : If the cassette without the safety tab is inserted, the VCP will operate

automatically

: “TURN ON PLAYBACK REWINDING STOP EJECT POWER OFF.”

CAUTION : When loading this VCP with double step, the audio noise may be appeared.

VIDEO SYSTEM

RECORDING / PLAYBACK VIDEO SYSTEM

•

RECORDING

This VCP is possible to record not only PAL signal, but NTSC.
In Case of Auto Mode, This VCP select the system automatically
according to the input signal (PAL or NTSC) in the record mode.

* The OSD will be display according to lnput signal.

(PAL AUTO:PAL)

If video signal is different input signal from record signal in the record mode.
The picture will be no color in the play mode.

ONE TOUCH TIMER RECORDING(OTR)

3. To stop the recording in progress, press and hold STOP approximately
3 seconds.

•

PLAYBACK

This VCP is possible to playback not only PAL tape, but NTSC tape.
In case of Auto Mode, This VCP select the system automatically according
to the inserted tape(PAL or NTSC).

* The OSD will be display according to the tape

(PAL TAPE AUTO:PAL).

When inserting the PAL tape, it will playback the PAL signal.
When inserting the NTSC tape, it will playback the NTSC signal on PAL TV.
(If you have NTSC TV, the picture will be black and white then you can take
color picture by pressing PAL/NTSC key on the remote control.)
If you want to playback the NTSC tape on NTSC TV, connect the NTSC TV to
this VCP with the line.

INPUT SIGNAL

PAL
SECAM
NTSC

RECORD SIGNAL

PAL
MESECAM
NTSC

DAEWOO Video Cassette Player17

SPECIAL OPERATION (continued)

DAEWOO Video Cassette Player 18

AUTO REPEAT

ENCORE FUNCTION

If you press the A.REPEAT key during playback, the tape will be re-playback after
rewinding.
In the A.REPEAT mode, only A.REPEAT and (power) key will be operated.
If you release the Auto Repeat mode, repress the A.REPEAT key on the remote control.

VISS

•

when you press the VISS - Key, the VCP will rewind the tape to the viss marked
point and will start to playback

•

when you press the VISS + Key, the VCP will advance the tape to the viss
marked point and will start to playback

Press the ENCORE key on the remote control to watch the desired picture once more
during playback.
The VCP rewinds the tape for about 15 seconds and will play the picture want to watch
again.

INPUT

• Press the INPUT key to select the Rear AUDIO/VIDEO in or the front AUDIO/VIDEO IN.

DISPLAY (O.S.D)

COMMERCIAL SKIP

• Press Display key to find the tape speed, system and status mode on the TV screen.

• This is useful for skipping commercials or program segments.

• Press CM SKIP once during playback to advance the tape approximately 30 seconds.

•

Each press of the CM SKIP adds an additional 30 seconds up to 5 minutes.

CHILD LOCK

•

To disable to usage of the VCP, or to protect your timer recordings, you can lock
the VCP so that the buttons on the VCP or remote won’t work.

• To lock : Press and hold Power on the remote for approximately six seconds.

• To release : Press and hold Power on the remote for approximately six seconds.

One touch timer records a program for a preset recording time
(30 minutes to 8 hours).

1. Press REC to begin recording.

2. Continue to press REC to increase the time length of the recording.

Press REC To record
One time normal(no recording time limit) eight time 5 hours
two times 30 mins. nine times 6 hours
three times 1 hour ten times 7 hours
four times 1 hour 30 mins. eleven times 8 hours
five times 2 hours twelve times Normal
six times 3 hours (no recording
seven times 4 hours time limit)

OPERATION

• Please do not turn off the power until recording is finished.

DAEWOO Video Cassette Player 20

OPERATION

PREPARATION (TV) LOADING

Turn on the TV and select the
desired CH Number to record.

Insert a blank cassette tape gently.

Press the SPEED key to select
the recording speed (SP or LP).

To finish the recording,
press the STOP key.

Press the REC key.
Recording will start.
The REC lndicator will
display.

* Upon inserting the cassette,

the power will be on even
if the power is off.

* In NTSC record mode, select

the SP/EP mode.

• You can record only the same program which you are watching as follows the above
steps.

• You can record the TV programs only by the TV having the Phone A/V jacks.

• Please do not turn off the power until recording is finished.

1 2

4 5

3

DAEWOO Video Cassette Player19

RECORDING TV PROGRAMS

Since this VCP has no its own TUNER, this has no function to receive TV broadcasting
signals.
To record TV programs, please use the another TV or VCP having the function to receive
TV broadcasting signals with own TUNER.

CONNECTION

1. DIRECT RECORDING (BY TV)

•

Connect the phone A/V jack on the TV set to the Phone A/V jack on the rear or
Front panel of VCP by using phone cable.

CONNECTION

2. INDIRECT RECORDING (BY VCR WITH TUNER)

•

Connect the Phone A/V jack on the another VCP set to the Phone A/V jack on the
rear or Front panel of VCP by using Phone cable.

SPEED SELECTION RECORDING STOP

PREPARATION (TV) LOADING

Turn on the power of TV.

Press the SPEED key to select
the recording speed (SP or LP).

* Upon inserting the cassette,

the power will be on even
if the power is off.

* In NTSC record mode, select

the SP/EP mode.

1 2

4 5

3

SPEED SELECTION RECORDING STOP

Insert a original tape to
playback VCP. Insert the blank
tape to recording VCP.

Press the PLAY key on
the playback VCP.
Press the REC key on
the recording VCP.
The REC lndicator will
display.

To interrupt the
recording, press the
STOP key.

SPECIFICATIONS

General

Power requirement
Power consumption
Weight
Temperature

: AC90-250V~, 50/60Hz
: 14 watts
: 3.8 kg
: Operating: 5

O

C to 35OC

Storage: –20

O

C to 60OC

: VHS standard
: PAL/MESECAM/NTSC(3.58/4.43) color signal
: Rotary, slant azimuth, two-head helical scan system
: 12.65 mm
: SP:23.39 mm/sec, LP:11.70mm/sec,

NTSC(3.58):33.35mm/sec
: 180 minutes with E-180 (SP)
: 21-40 CH (adjustable) 73 3 dBuV
: 1.0Vp-p, 75 ohms unbalanced, sync. negative

(Phone Jack)
: 1.0Vp-p, 75 ohms unbalanced, sync. negative

(Phone Jack)
: More than 43dB (with Rohde & Schwarz noise meter)

- PAL SP standard
: More than 240 lines - PAL SP standard
: Phone-type connector more than 47K ohms,

–8dBm, unbalanced

: Phone-type connector more than 1K ohms,

–5.8dBm, unbalanced
: More than 40 dB - PAL SP standard
: Instruction Manual, Remote control, 2 Batteries,

RF cable

Tape deck section

Format
Video signal system
Scanning system
Tape width
Tape speed

Playing time
RF output
Video input

Video output

Video S/N

Resolution of picture
Audio input

Audio output level

Audio S/N
Accessories provided

* Design and specifications are subjected to change without notice.

DAEWOO Video Cassette Player21

BEFORE CALLING SERVICE PERSONNEL

DAEWOO Video Cassette Player 22

Before calling service personnel, check the following points for a possible cause of the
trouble. A minor adjustment on your part may eliminate the trouble.

SYMPTOMS POSSIBLE CAUSES

There is no power to the VCP.
Operation key does not function.

Tape does not run in the record mode.

Picture does not appear in the playback
mode.

Tape cannot be rewinded or fast
forwarded.

Playback picture is partially noisy.
Cassette cannot be inserted into

the VCP.

Is the power cord connected?
Is the POWER switch ON?

Has a cassette been inserted?
Has a cassette been inserted?

Is the safety tab on the cassette still
intact?

Is the TV receiver channel selector
set to an occupied channel?
Set to the RF converter channel?

Is the tape already rewound or fast
forwarded to the end?

Is the TRK + or – properly adjusted?
Is the cassette correctly inserted?

Is there a cassette already in the VCP?

k
k

k

k
k

k
k
