Before operating this oven, please read these instructions completely.

OPERATING INSTRUCTIONS

MICROWAVE OVEN

KOG-392G

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`2

PRECA UTIONS T O A V OID POSSIBLE EXPOSURE T O EXCESSIVE MICRO W A VE ENERGY

(a) Do not attempt to operate this oven with the door open since open-door operation can result in

harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow soil or cleaner

residue to accumulate on sealing surfaces.

been repaired by a trained person : (1) door (bent), (2) hinges and latches(broken or loosened), (3) door seals and sealing surfaces.

(d) WARNING : It is hazardous for anyone other than a trained person to carry out any service or

repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.

(e) WARNING : Liquids or other foods must not be heated in sealed containers since they are

liable to explode.

(f) WARNING : Only allow children to use the oven without supervision when adequate instructions

have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

PRECAUTIONS

....................................................................................................................................

EARTHING INSTRUCTIONS

..............................................................................................................

INSTALLATION

.....................................................................................................................................

SPECIFICATIONS

................................................................................................................................

IMPORTANT

.........................................................................................................................................

IMPORTANT SAFETY INSTRUCTIONS

............................................................................................

FEATURES DIAGRAM

.........................................................................................................................

OPERATION PROCEDURE

................................................................................................................

CONTROLS

...........................................................................................................................................

SETTING THE CLOCK

..................................................................................................................

TIME DEFROSTING

.......................................................................................................................

WEIGHT DEFROSTING

................................................................................................................

COOKING IN ONE STAGE

..........................................................................................................

COOKING IN TWO STAGES

......................................................................................................

GRILL COOKING

..........................................................................................................................

COMBI COOKING

........................................................................................................................

KITCHEN TIMER MODE

..............................................................................................................

SPEEDY COOK

............................................................................................................................

ONE TOUCH COOKING

..............................................................................................................

AUTO COOK

.................................................................................................................................

LESS, MORE

................................................................................................................................

CHILD SAFETY LOCK

.................................................................................................................

TO STOP THE OVEN WHILE THE OVEN IS OPERATING

.....................................................

COOKING UTENSILS

..................................................................................................................

CARE AND CLEANING

...............................................................................................................

BEFORE YOU CALL FOR SERVICE

.........................................................................................

QUESTIONS AND ANSWERS

....................................................................................................

TABLE OF CONTENTS

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`1

EARTHING INSTR UCTIONS

This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed.

WARNING: Improper use of the earthing plug can result in a risk of electric shock. Consult a qualified

electrician or serviceman if the earthing instructions are not completely understood, or if doubt exists as to whether the appliance is properly earthed. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade earthing plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord should be equal to or greater than the electrical rating of the appliance.

INSTALLATION

Steady, flat location

This oven should be set on a steady, flat surface. This oven is designed for counter top use only.

Leave space behind and side

All air vents should be kept a clearance. If all vents are covered during operation, the oven may overheat and, eventually, oven failure.

Away from radio and TV sets

Poor television reception and radio interference may result if the oven is located close to a TV, Radio antenna, feeder and so on. Position the oven as far from them as possible.

Away from heating appliance and water taps

Keep the oven away from hot air, steam or splash when choosing a place to position it, or the insulation might be adversely affected and breakdowns occur.

Power supply

• Check your local power source. This oven requires a current of approximately 11 amperes, 230V 50Hz.

• Power supply cord is about 0.8 meters long.

• The voltage used must be the same as specified on this oven. Using a higher voltage may result in a fire or other accident causing oven damage. Using low voltage wil cause slow cooking. We are not responsible for damage resulting from use of this oven with a voltage of ampere fuse other than those specified.

• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

Examine the oven after unpacking for any damage such as:

A misaligned door, Broken door, A dent in cavity. If any of the above are visible, DO NOT INSTALL, and notify dealer immediately.

Do not operate the oven if it is colder than room temperature.

(This may occur during delivery in cold weather.) Allow the oven to become room temperature before operating.

The minimum height of free space necessary above the top surface of the oven is 100mm.

1 2

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`2

POWER SUPPLY 230V~50Hz, SINGLE PHASE WITH EARTHING

POWER

MICROWAVE 1350 W

CONSUMPTION

GRILL 1050 W

COMBINATION 2350 W MICROWAVE ENERGY OUTPUT 900W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (WXHXD) 495X294X388mm CAVITY DIMENSIONS (WXHXD) 320X244X338mm NET WEIGHT APPROX. 15.8Kg TIMER 59 min. 90 sec. POWER SELECTIONS 10 LEVELS CAVITY VOLUME 0.9 Cu.Ft.

* Specifications are subject to change without notice.

SPECIFICATIONS

IMPORTANT

The wires in this mains lead are coloured in accordance with the following code.

Green-and-yellow : Earth Blue : Neutral

Brown : Live As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with the letter ‘E’ or by the earth symbol or green-and-yellow. The wire which is coloured blue must be connected to the terminal which is marked with the letter 'N' or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the letter ‘L’ or coloured red.

WARNING: This appliance must be earthed.

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`3

IMPORTANT SAFETY INSTRUCTIONS

WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven:

1. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any other nonfood items or for sterilizing purposes.

2. Do not use the oven when empty, this could damage the oven.

3. Do not use the oven cavity for any type of storage, such as papers, cookbook, cookware, etc.

4. Do not operate the oven without the glass tray in place. Be sure it is properly sitting on the rotating base.

5. Make sure you remove caps or lids prior to cooking when you cook food sealed in bottles.

6. Do not put foreign material between the oven surface and door. It could result in excessive leakage of microwave energy.

7. Do not use recycled paper products for cooking. They may contain impurities which could cause sparks and/or fires when used during cooking.

8. Do not pop popcorn unless popped in a microwave approved popcorn popper or unless it’s commercially packaged and recommended especially for microwave ovens. Microwave popped corn produces a lower yield than conventional popping; there will be a number of unpopped kernels. Do not use oil unless specified by the manufacturer.

9. Do not cook any food surrounded by a membrane, such as egg yolks, potatoes, chicken livers, etc., without first piercing them several times with a fork.

10. Do not pop popcorn longer than the manufacturer’s

directions. (popping time is generally below 3 minutes). Longer cooking does not yield more popped corn, it can cause scorchings and fire. Also, the cooking tray can become too hot to handle or may break.

11. If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.

12. When heating food in plastic or paper containers, check the oven frequently due to the possibility of ignition.

13. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to be checked before consumption, in order to avoid burns.

14. Always test the temperature of food or drink which has been heated in a microwave oven before you give it to somebody, especially to children or elderly people. This is important because things which have been heated in a microwave oven carry on getting hotter even though the microwave oven cooking has stopped.

15. Eggs in their shell and whole hard-boiled eggs shall not be heated in microwave ovens since they may explode.

16. Keep the waveguide cover clean at all times. Wipe the oven interior with a soft damp cloth after each use. If you leave grease or fat anywhere in the cavity it may overheat, smoke or even catch fire when next using the oven.

17. Never heat oil or fat for deep frying as you cannot control the temperature and doing so may lead to overheating and fire.

18. Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling the container.

19. a) Be cautions about touching parts other than

control panel during or immediately following grill or combi cooking.

b) Always use hot pads or oven mitts when placing

or removing food and/or accessories from the oven.

SAVE THESE INSTRUCTIONS

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`4

1. Door seal - Door seal maintains the microwave energy within the oven cavity and prevents microwave leakage.

2. Reflector (Insulator Heater)

3. Heating Element

4. Oven cavity

5. Safety interlock system

6. Control panel

7. Metal Rack

8. Coupler - This fits over the shaft in the

center of the ovens cavity floor. This is to remain in the oven for all cooking.

9. Roller guide - This must always be used for cooking together with the glass cooking tray.

10. Glass cooking tray - Made of special heat

resistant glass. Food in a proper receptacle is placed on this tray for cooking.

11. Door viewing screen - Allows viewing of

food. The screen is designed so that light can pass through, but not the microwave.

12. Door hook - When the door is closed, it will

automatically shut off. If the door is opened while the oven is operating, the magnetron will immediately stop operating.

FEATURES DIA GRAM

3 4

8101112 9

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`5

13. Time set pad-Used to set the cooking time and the present time.

14. Display-Cooking time, power level, indicators and present time are displayed.

15. One touch-Used to cook or reheat specific quantities of food.

16. Auto Cook-Used to cook or reheat.

17. More-Used to add time to cooking.

18. Less-Used to remove time from cooking.

19. Auto Defrost-Used to defrost foods.(for weight)

20. Combi-Used to cook COMBI.

21. Grill-Used to cook GRILL.

22. Power-Used to set power level.

23. Defrost-Used to defrost foods.(for time)

24. Kitchen Timer-Used as a minute timer, to delay the start of cooking, or to set a holding time after cooking.

25. Clock-Used to set clock.

26. Stop/Clear-Used to stop the oven operation or to delete the cooking data.

27. Start/Speedy cook-Used to start the oven and also used to set a reheat time.

FEATURES DIA GRAM (continued)

a d

M/W Def. Grill Combi Timer/g

Pasta

Frozen Pizza

Auto Defrost

Fish

Poultry

Meat

1min.

10S

10min.

1hour

10M

STOP/

CLEAR

START/

SPEEDY COOK

Beverage

GRILL DefrostCOMBI

Kitchen

Timer

ClockPower

1. BREAD

2. SOUP

3. BAKED POTATO

4. FRESH VEGETABLE

5. FROZEN VEGETABLE

Auto

Cook

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`6

The oven light is on only when the microwave oven is operating.

The oven door can be opened at any time during operation by touching the door release button on the control panel. The oven will automatically shut off.

Each time a pad is touched, a BEEP will sound to acknowledge the touch.

The oven automatically cooks on full power unless set to a lower power level.

The display will show “ : 0” when the oven is plugged in. Time clock returns to the present time when the

cooking time ends. When the STOP/CLEAR pad is touched during the

oven operation, the oven stops cooking and all information retained. To erase all information(except the present time), touch the STOP/CLEAR pad once more. If the oven door is opened during the oven operation, all information is retained.

If the START pad is touched and the oven does not operate, check the area between the door and door seal for obstructions and make sure the door is closed securely. The oven will not start cooking until the door is completely closed or the program has been reset.

NOTE : When using the GRILL or COMBI mode;

• Do not open the door so often, the temperature inside the oven decrease and the cooking may not be completed in setting time.

• Never touch the oven window and metal interior of the oven when taking food in and out, because the temperature inside the oven and door is very high.

• When using these modes, be careful as the tray will be hot to touch, use oven gloves or pot holders while handling tray.

OPERATION PROCEDURE

This section includes useful information about oven operation. a. Plug power supply cord into a 230V 50Hz power outlet. b. After placing the food in a suitable container, open the oven door and put it on the glass tray.

The glass tray and roller guide must always be in place during cooking.

c. Shut the door. Make sure that it is firmly closed.

1 2

3 4

5 6

Make sure the oven is properly installed and plugged into the electrical outlet.

W ATT AGE OUTPUT CHART

•

The power-level is set by pressing the Power pad. The chart shows the display, the power level and the percentage of power.

Touch Power pad Power level (Display) Approximate Percentage of Power

once P-HI 100%

twice P-90 90% 3 times P-80 80% 4 times P-70 70% 5 times P-60 60% 6 times P-50 50% 7 times P-40 40% 8 times P-30 30% 9 times P-20 20%

10 times P-10 10% 11 times P-00 0%

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`7

CONTROLS

SETTING THE CLOCK

When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever goes off, the display shows “ : 0” when the power comes back on.

1. Touch Clock pad. This is a 12 hour clock system.

2. Touch Clock pad once more.

This is a 24 hour clock system.

3. Enter the correct time of day by touching the time set pads.

4. Touch Clock pad.

NOTE: If you attempt to enter an incorrect time, the time will not be set and a error signal tone will sound.

Touch the Clock pad and re-enter the time.

The display stops blinking, and the colon starts blinking. If you selected 12 hour clock system, this digital clock allows you to set from 1:00 to 12:59. If you selected 24 hour clock system, this digital clock allows you to set from 0:00 to 23:59.

TIME DEFROSTING

When Defrost is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off.

When you touch START pad, the Def. indicator starts blinking to show the oven is in the DEFROST mode. The display counts down the time to show you how much defrosting time is left in the DEFROST mode. The oven beeps during the defrosting cycle to signal that the food needs to be turned or rearranged. When the defrosting time ends, you will hear 3 beeps.

NOTE : This oven has multiple clock

systems. If you want 12 hour clock system, omit this step.

1. Touch Defrost pad.

2. Touch the time set pads for the desired time.

3. Touch START pad.

The Def. indicator lights and “ : 0” is displayed. The display will show what you touched.

Clock

Defrost

Note : Your oven can be programmed for

59 minutes 90 seconds. ( 59 : 90 )

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`8

WEIGHT DEFROSTING

Auto Defrost lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting.

1. Touch Meat pad.

2. Select the desired defrosting weight. (Refer to the weight defrost chart below.)

3. Touch START pad.

The Timer/g indicator light and “ 500 ” is displayed.

The display will show what you touched.

MEAT DEFROSTING begins.

The defrosting time is automatically determined by the weight selected. When you touch START pad, the Timer/g indicator goes off and the Def. indicator blinks and the defrosting time counts down in the display window. The oven beeps during the defrosting cycle to signal that the food needs to be turned or rearranged. When the defrosting time ends, you will hear 3 beeps.

Meat

1. Touch Poultry pad.

2. Select the desired defrosting weight. (Refer to the weight defrost chart below.)

3. Touch START pad.

The Timer/ g indicator light and “ 800 ” is displayed.

The display will show what you touched.

POULTRY DEFROSTING begins.

Poultry

1. Touch Fish pad.

2. Select the desired defrosting weight. (Refer to the weight defrost chart below.)

3. Touch START pad.

Touch pad MEAT POULTRY FISH

once 500g 800g 300g

twice 800g 1000g 500g

3 times 1000g 1200g 800g

4 times 1200g 1500g 1000g

WEIGHT DEFROST CHART

The Timer/g indicator light and “ 300 ” is displayed.

The display will show what you touched.

FISH DEFROSTING begins.

Fish

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`9

COOKING IN TWO STAGES

All recipes require frozen foods to be defrosted fully before cooking. This oven can be programmed to automatically defrost foods before cooking.

When you touch START pad, the Def. and M/W indicators come on to confirm the power levels selected. The Def. indicator starts blinking to show you that the oven is in DEFROST mode. The display counts down the time remaining in DEFROST mode. When the oven beeps, turn over,break apart and/or redistribute the food. At the end of DEFROST mode, the oven will beep and start M/W cook. The Def. indicator goes off and the M/W indicator starts blinking. The display counts down the time remaining in M/W mode. When M/W cook ends, you will hear 3 beeps.

1. Touch Defrost pad.

2. Touch the time set pads for the defrosting time you want.

4. Touch the time set pads for the desired cooking time.

5. Touch START pad.

The Def. indicator lights and “ : 0” is displayed.

The display will show what you touched. The M/W indicator lights and “P-HI” is displayed.

The display will show what you touched. This example shows power level 5.

The display will show what you touched.

COOKING IN ONE STAGE

When you touch START pad, the M/W indicator starts blinking to show the oven is cooking. The display counts down the time to show how much cooking time is left. When the cooking time ends, you will hear 3 beeps.

1. Touch Power pad. (Select the desired power level.)

X 6

2. Touch the time set pads for the cooking time.

3. Touch START pad.

The M/W indicator lights. The display will show what you touched. This example shows power level 5.

The display will show what you touched.

NOTE: Using lower power levels increases the cooking time which is recommended for foods such

as cheese, milk and slow cooking of meats.

Note : If steps 1 and 2 are omitted,

the oven will cook at full power.

Note : Your oven can be programmed for

59 minutes 90 seconds. ( 59 : 90 )

Power

Defrost

Power

3.Touch Power pad.

(Select the desired power level. )

X 6

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`10

Note : Time can be set up to 29 minutes

90 seconds.

GRILL COOKING

This function allows you to brown food quickly. The heating element is located in the top of the oven. There is no pre-heating the oven for grill cooking. Place food inside the oven when setting the controls.

1. Touch GRILL pad.

2. Touch the time set pads for the cooking time.

3. Touch START pad.

The Grill indicator lights and “ : 0” is displayed.

The display will show what you touched.

GRILL

Note : Time can be set up to 59 minutes

90 seconds.

COMBI COOKING

The oven has combination mode which cooks food with heater and microwave at the same time. The combination mode accelerates the cooking process.

1. Touch COMBI pad.

2. Touch the time set pads for the cooking time.

3. Touch START pad.

The Combi indicator lights and “ : 0” is displayed.

The display will show what you touched.

COMBI

When you touch START pad, the Grill indicator starts blinking to show the oven is cooking. The display counts down the time to show how much cooking time is left. When the cooking time ends, you will hear 3 beeps.

When you touch START pad, the Combi indicator starts blinking to show the oven is cooking. The display counts down the time to show how much cooking time is left. When the cooking time ends, you will hear 3 beeps.

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`11

1. Program the desired cooking time.

3. Press the amount of time you want the oven to hold.

4. Touch START pad. The M/W indicator starts blinking and the display counts down the time remaining in M/W mode. When

the M/W cook ends, the oven will beep. The M/W indicator goes off and Timer/g indicator starts blinking. The display counts down the time remaining in KITCHEN TIMER mode. When the KITCHEN TIMER mode ends, you will hear 3 beeps.

1. Touch Kitchen Timer pad.

2. Press the amount of time you want to delay.

3. Program the desired power level and cooking time for food to

be cooked.

4. Touch START pad. When you touch START pad, the Timer/g indicator starts blinking and the display counts down the

time remaining in KITCHEN TIMER mode. When KITCHEN TIMER mode ends, the oven will beep. The Timer/g indicator goes off and M/W indicator starts blinking. The display counts down the time remaining in M/W mode. When M/W cook ends, you will hear 3 beeps.

The Timer/g indicator lights and “ : 0 ” is displayed.

The display will show what you touched. The M/W indicator lights and the selected

power level & cooking time are displayed.

The M/W indicator lights and the selected time is displayed.

The Timer/g indicator lights and “ : 0” is displayed.

The display will show what you touched.

Note : Your oven can be programmed for 59 minutes 90 seconds. ( 59 : 90 )

Kitchen

Timer

KITCHEN TIMER MODE

Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after cooking. However delay cooking can not be programmed for defrost. Timer operates without microwave energy.

1. Touch Kitchen Timer pad.

2. Press the amount of time you want to count down.

3. Touch START pad.

The Timer/g indicator starts blinking and the display counts down the time remaining in KITCHEN TIMER mode. When KITCHEN TIMER mode ends, you will hear 3 beeps.

The Timer/g indicator lights and “ : 0” is displayed.

The display will show what you touched.

Kitchen

Timer

HOW T O USE AS A MINUTE TIMER

HOW T O USE T O DELAY THE ST AR T OF COOKING

2. Touch Kitchen Timer pad.

Kitchen

Timer

HOW T O USE T O SET A HOLDING TIME

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`12

ONE TOUCH COOKING

One touch cook allows you to cook or reheat many of your favorite foods by touching just one pad. To increase quantity, touch chosen pad until number in display is same as desired quantity to cook.

SPEEDY COOK

SPEEDY COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the SPEEDY COOK pad. By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments.

1. Touch SPEEDY COOK pad. When you touch SPEEDY COOK, ":30" is displayed.

After 1.5 seconds, the oven starts reheating.

Pasta

SPEEDY

COOK

1. Touch Pasta pad once for 1 serving or twice for 2 serving.

When you touch Pasta pad once, “ 1” is displayed. After 1.5 seconds, the display is changed into cooking time and the oven starts cooking.

Froz en

Pizza

1. Touch Frozen Pizza pad once for 200g pizza or twice 400g pizza.

When you touch Frozen Pizza pad once, “ 200 ” is displayed. After 1.5 seconds, the display is changed into the cooking time and the oven starts cooking.

* PASTA *

• 1 serving : Touch Pasta once.

• 2 serving : Touch Pasta twice within 1.5 seconds.

NOTE: 1. Place pasta into a deep casserole and double quantity of water.

2. Cover with lid or plastic wrap. After cooking, stir.

3. If possible, let stand 3 to 5 minutes or until liquid has been absorbed.

* FROZEN PIZZA *

• 200 g : Touch Frozen Pizza once.

• 400 g : Touch Frozen Pizza twice within 1.5 seconds.

NOTE: 1 Use only one frozen pizza at a time

2. Use only frozen pizza made for microwave ovens.

3. If the cheese of frozen pizza does not melt sufficiently, cook a few seconds longer.

4. Some brands of frozen pizza may require more or less cooking time.

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`13

ONE TOUCH COOKING (continued)

A UTO COOK

Auto Cook allows you to cook or reheat many of your favorite foods by repeatedly touching auto cook pad.

1. Touch Beverage pad once for 1 cup, twice for 2 cups or three times for 3 cups.

Bever age

When you touch Beverage pad once, “ 1 ” is displayed. After 1.5 seconds, the display is changed into cooking time and the oven starts cooking.

1. Touch Auto Cook pad.

Auto

Cook

When you touch Auto Cook pad once, “AC1” is displayed. By repeatedly touching this pad, you can select other food category as shown in the chart below.

2. Touch START pad.

START

When you touch START pad, the display is changed into cooking time and the oven starts cooking.

* BEVERAGE(200ml/cup) *

• 1 cup (mug): Touch Beverage once.

• 2 cups (mugs): Touch Beverage twice within 1.5 seconds.

• 3 cups (mugs): Touch Beverage three times within 1.5 seconds.

CATEGORY FOOD WEIGHT TOUCH PAD

AC-1 BREAD 4 slices(40-50g each) Touch Auto Cook once AC-2 SOUP 350g Touch Auto Cook twice AC-3 BAKED POTATO 3 potatoes(200~250g each) Touch Auto Cook three times AC-4 FRESH VEGETABLE 200g Touch Auto Cook four times AC-5 FROZEN VEGETABLE 200g package Touch Auto Cook five times

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`14

LESS, MORE

To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE.(except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 seconds. The overall one touch cooking time can be increased to a maximum of 59 minutes 50 seconds. Press LESS/MORE to decrease/increase the cooking time in multiples of 1 minute. The overall cooking time can be increased to a maximum of 59 minutes.

CHILD SAFETY LOCK

The safety lock prevents unwanted oven operation such as by small children. To set, press and hold STOP/CLEAR for 3 seconds, and a beep sounds. Each time a pad(except STOP/CLEAR) is touched, “LOC” is displayed. To cancel, press and hold STOP/CLEAR for 3 seconds, and a beep sounds.

TO STOP THE OVEN WHILE THE OVEN IS OPERATING

1. Press STOP/CLEAR pad.

• You can restart the oven by touching START pad.

• Touch STOP/CLEAR once more to erase all instructions.

• You must enter in new instructions.

2. Open the door.

• You can restart the oven by closing the door and touching START.

NOTE: Oven stops operating when door is opened.

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`15

COOKING UTENSILS

Utensils should be checked to ensure that they are suitable for use in microwave ovens. Microwave energy is produced by high frequency radio waves. They are reflected from metal, but will pass through most cooking utensils without heating them. As the waves come into contact with the food, they are converted into heat energy. Listed below are the suggested cooking utensils for this microwave oven and when to use them.

CARE AND CLEANING

Although your oven is provided with safety features, it is important to observe the following:

1. It is important not to defeat or tamper with safety interlocks.

2. Do not place any object between the oven front face and the door or allow residue to accumulate on sealing surfaces. Wipe the sealing area frequently with a mild detergent, rinse and dry. Never use abrasive powders or pads.

3. When opened, the door must not be subjected to strain, for example, a child hanging on an opened door or any load could cause the oven to fall forward to cause injury and also damage to the door. Do not operate the oven if it is damaged, until it has been repaired by a trained service technician. It is particularly important that the oven closes properly and that there is no damage to the: i) Door(bent) ii) Hinges and Hookes(broken or loosened) iii) Door seals and sealing surfaces.

4. The oven should not be adjusted or repaired by anyone except a properly trained service technician.

Material Grill cooking Microwave cooking Combined cooking

1. Without metal parts or metal trims.

2. Some plastics are heat-proof only to certain temperature. Check carefully!

3. It is possible to use aluminum foil to shield delicate areas of food.(This prevents over-cooking.)

4. Metal tins can be used in the combination methods, however if these are very deep, they will greatly reduce the efficiency, as metal shields the microwave energy from the food.

Glass (general) Glass (heat resistant) Glass-ceramic and

ceramic (heat resistant) Earthenware China (heat resistant) Plastic (general) Plastic (heat resistant) Aluminum foil containers/

Aluminum foil Metal baking tins Metal (pots. pans, etc.) Paper

Yes Yes

Yes(2)

Yes

Yes(4)

Yes

Yes(1)

Yes

Yes(1)

Yes

Yes Yes(2) Yes(2)

Yes(3)

No No

Yes

Yes(1)

Yes Yes

Yes(2)

Yes

Yes(4)

No No

Before use, the user should check that utensils are suitable for use in microwave ovens.

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`16

BEFORE YOU CALL FOR SERVICE

Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn’t work :

1. Check that the power cord is securely plugged in.

2. Check that the door is firmly closed.

3. Check that the cooking time is set.

4. Check for a blown circuit fuse or tripped main circuit breaker in your house.

* Sparking in the cavity;

1. Check utensils. Metal containers or dishes with metal trim should not be used.

2. Check that metal skewers or foil does not touch the interior walls.

If there is still a problem, contact the service station. A list of these stations is included in the oven.

QUESTIONS AND ANSWERS

* Q: I accidentally ran my microwave oven without any food in it. Is it damaged?

* A: Running the oven empty for a short time will not damage the oven. However, it is not

recommended.

* Q: Can the oven be used with the glass tray or roller guide removed?

* A: No. Both the glass tray and roller guide must always be used in the oven before

cooking.

* Q: Can I open the door when the oven is operating?

* A: The door can be opened anytime during the cooking operation. Then microwave

energy will be instantly switched off and the time setting will maintain until the door is closed.

* Q: Why do I have moisture in my microwave oven after cooking?

* A: The moisture on the side of your microwave oven is normal. It is caused by steam

from cooking food hitting the cool oven surface.

* Q: Does microwave energy pass through the viewing screen in the door?

* A: No. The metal screen bounces back the energy to the oven cavity. The holes are

made to allow light to pass through. They do not let microwave energy pass through.

DO NOT ATTEMPT TO SERVICE THE OVEN YOURSELF !

KOG-392GOS(¿ ) 01.10.9 4:20 PM ˘`17

Daewoo KOG-392GOS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
