DAEWOO KOC910K User Manual

MICROWAVE CONVECTION/GRILL OVEN

KOC-910K

OWNER’S

MANUAL

More Less Clock

Language

Auto Cook

Memory Cake Crusty

M	/W	Gri
M		ll
C		Auto
C		Defrost
o		Defrost
n
v
ec		bi
	tio	bi
	n	Com
		Time
		Wei
		ght

Q u

t i t y

Stop/	Start/
Clear	Speedy Cook

Before operating this oven, please read these manual completely.

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

(a)Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b)Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

(c)WARNING : If the door or door seals are damaged, the oven must not be operated until it has been repaired by a trained person: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

(d)WARNING : It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.

(e)WARNING : Liquids or other foods must not be heated in sealed containers since they are liable to explode.

(f)WARNING : Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

TABLE OF CONTENTS
• INSTALLATION AND EARTHING INSTRUCTIONS............................................................................	2
• IMPORTANT SAFETY INSTRUCTIONS .............................................................................................	3
• WHICH UTENSILS CAN BE USED IN THE OVEN? ...........................................................................	4
• CONTROL PANEL ...............................................................................................................................	5
• ACCESSORIES ...................................................................................................................................	6
• BEFORE OPERATION ........................................................................................................................	7
SETTING THE LANGUAGE................................................................................................................	7
SETTING THE CLOCK .......................................................................................................................	8
CHILD LOCK AND POWER SAVE MODE .........................................................................................	8
OPERATION .......................................................................................................................................	9
MICROWAVE COOKING ....................................................................................................................	9
GRILL COOKING ..............................................................................................................................	10
CONVECTION COOKING (with pre-heat) ........................................................................................	11
CONVECTION COOKING (traditional cooking) ................................................................................	12
COMBINATION COOKING ...............................................................................................................	13
AUTO DEFROST ..............................................................................................................................	16
CAKE.................................................................................................................................................	17
CRUSTY............................................................................................................................................	20
AUTO COOK .....................................................................................................................................	22
MEMORY COOK...............................................................................................................................	24
SPEEDY COOK ................................................................................................................................	24
LESS, MORE.....................................................................................................................................	24
MANUAL COOLING ..........................................................................................................................	25
SCROLL SPEED CONTROL ............................................................................................................	25
TO STOP THE OVEN WHILE THE OVEN IS OPERATING .............................................................	26
ABNORMAL MESSAGES .................................................................................................................	26
• GENERAL GUIDELINES ...................................................................................................................	27
• KEEP THE OVEN CLEAN .................................................................................................................	28
• BEFORE CALLING FOR SERVICE...................................................................................................	29
• QUESTIONS AND ANSWERS ..........................................................................................................	30
• SPECIFICATIONS .............................................................................................................................	30

INSTALLATION AND EARTHING INSTRUCTIONS

How to examine your microwave oven after unpacking.

Unpack oven, remove all packing material, and examine the oven for any damage such as dents, broken door, latches or cracks in the door. Do not remove the film from inside the door. Notify dealer immediately if the oven is damaged. Do not install if the oven is damaged.

Where to place your microwave oven.

1.Place the oven on a flat and stable surface.

2.Surface of the oven is protected by a plastic film which should be removed before using.

3.Leave space behind and sides and upper of the oven. All air vents should be kept a clearance.

If all vents are covered during operation, the oven may overheat and, eventually, lead to oven failure.

4.Keep away from radio and TV sets. If the oven is located close to a TV, radio interference may result.

5.Keep away from heating appliances and water taps. Keep the oven away from hot air, steam or splash when choosing a place to position it, or the insulation might be adversely affected and breakdowns occur.

6.The minimum height of free space necessary above the top surface of the oven is minimum 170mm.

Prior to use (If your oven has a grill element)

In order to protect your oven during transportation and storage, the grill element is covered with a protective coating. To remove this coating the grill element must be heated for 5 minutes. This procedure will produce some bad odours as the protective coating on the element disappears.

To remove the coating, use the following procedures:

1.Place an overproof and microwave safe bowl, containing 200cc of water or more, in the oven.

2.Press the convection button.

3.Set the time to 5 minutes.

4.Press the start button.

5.When the 5 minutes has elapsed, an acoustic signal sounds.

Note:

The protective coating has now been removed and the oven is ready to use. Please be aware that your oven now is very hot.

6.Open the oven door and remove the bowl with water (use oven gloves when removing the bowl).

CHILD LOCK

To prevent child from operating the oven, install the childlock key.

1.Touch more button for 3 seconds.

Indicator lock is indicated and all buttons do not operate.

2.Touch more button for 3 seconds once again, then childlock is canceled.

-WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

Electrical Connection

WARNING-THIS APPLIANCE MUST BE EARTHED.

REFER TO RATING PLATE FOR VOLTAGE AND CHECK THAT THE APPLIANCE VOLTAGE CORRESPONDS WITH THE SUPPLY VOLTAGE IN YOUR HOME.

The flexible mains lead must be correctly connected, as below, to a three pin plug of not less than 13 AMP capacity. You must use a 3 pin plug which should be marked with the number BS 1363 and it should be fitted with 13 AMP fuse marked with the number BS 1362.

We recommend the use of good quality plugs and wall sockets that can be switched off when the machine is not in use.

IMPORTANT-The wires in the mains lead fitted to this appliance are coloured in accordance with the following code

GREEN AND YELLOW-EARTH

BLUE-NEUTRAL

BROWN-LIVE

As the colour of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

Power supply

•Check your local power source. This oven requires a current of approximately 12(8)amperes, 230V 50Hz.

•Power supply cord is about 1.2 meters long.

•The voltage used must be the same as specified on this oven. Using a higher voltage may result in a fire or other accident

causing oven damage. Using low voltage will cause slow cooking. We are not responsible for damage resulting from use of this oven with a voltage of ampere fuse other than those specified.

•If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

The wire which is coloured GREEN AND YELLOW must be connected to the terminal in the plug which is marked with the letter "E" or the earth symbol or coloured GREEN AND YELLOW, or GREEN.

The wire which is coloured BLUE must be connected to the terminal which is marked with the letter "N" or coloured BLACK, or BLUE.

The wire which is coloured BROWN must be connected to the terminal which is marked with the letter "L" or coloured RED , or BROWN.

If the terminals in the plug are unmarked or you are in any doubt as to the correct connections, consult a qualified electrician.

If you do not make the proper electrical connections you will damage your microwave oven and possibly injure yourself. Neither the manufacturer nor the supplier are liable if this happens.

MOULDED PLUGS

Should it be necessary to remove a moulded on plug from the mains cable, it should be cut off and replaced with a suitable replacement.

The moulded plug cannot be used for any other appliance, therefore remove the fuse and dispose immediately and safely to prevent anyone, especially children from plugging it in to a wall socket, which will create a safety hazard.

Should the mains lead ever require replacement, it is essential that this operation be carried out by a qualified electrician and should only be replaced with a flexible cord obtained from the manufacturer.

Applicable only if moulded plug is fitted.

After replacement of a fuse in the plug, the fuse cover must be refitted. If the fuse cover is lost, a replacement cover is obtained. The colour of the correct replacement fuse cover is that of the coloured insert in the base of the plug or the colour that is embossed in words in the base of the plug recess or elsewhere on the plug. Always state this colour when ordering a replacement fuse cover.

Only 13 amp replacement fuses which are ASTA approved to BS 1362 should be fitted

IMPORTANT SAFETY INSTRUCTONS

When using electrical apliances, basic safety precautions should be followed, including the following:

WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy:

1.Read all instructions before using the appliance.

2.Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY", found on page 1.

3.This appliance must be earthed. Connect only to a properly installed wall socket.

4.Install or locate this appliance only in accordance with the provided installation instructions.

5.Some products such as whole eggs and sealed containers for example, closed glass jars-may explode and should not be heated in this oven.

6.Use this appliance only for its intended use as described in this manual.

7.As with any appliance, close supervision is necessary when used by children.

8.Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped.

9.This appliance should be serviced only by qualified service personnel. Contact the nearest authorized service facility for examination, repair or adjustment.

10.Do not cover or block any openings on this appliance.

11.Do not use outdoors.

12.Do not immerse cord or plug in water.

13.Keep cord away from heated surfaces.

14.Do not let cord hang over edge of table or counter.

15.When cleaning surfaces of door and oven that meet when the door closes, use only mild, nonabrasive soaps or detergents with a sponge or soft cloth.

16.To reduce the risk of fire in the oven cavity:

(a)Do not overcook food. Carefully attend appliance if paper, plastic, or other combustible materials are placed inside the oven when cooking food.

(b)Remove wire twist-ties from bags before placing bag in oven.

(c)If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the power cord, or shut off power at the fuse or circuit breaker panel.

17.Do not use this appliance to heat corrosive chemicals (for example, sulfides and chlorides). Vapors from such corrosive chemicals may erode the contacts and springs of the safety interlock switches and render them inoperable.

18.The contents of feeding bottles and baby jars must be stirred or shaken and the temperature is to be checked before consumption to avoid burns.

19.The appliance must be positioned so that the plug is accessible.

SAVE THESE INSTRUCTIONS

General Use

Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven:

1.Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any other nonfood items or for sterilizing purposes.

They may catch on fire.

2.Do not use the oven when empty, this could damage the oven.

3.Do not use the oven cavity for any type of storage, such as papers, cookbook, cookware, etc.

4.Do not operate the oven without the turntable tray in place. Be sure it is properly sitting on the rotating base.

5.Be caution when removing the turntable tray after cooking meats that may have caused an accumulation of grease in the tray.

6.Unlike microwave-only ovens, this oven may become hot on the cabinet and oven door.

Always use hot pads or oven mitts when placing or removing food and/or accessories from the oven.

Be cautions about touching parts other then control panel during or immediately following grill or combination cooking.

7.If the oven is hot from combination cooking, do not use plastic or Styrofoam cookware for microwave cooking.

They may melt.

8. Do not use recycled paper products for cooking.

They may contain impurities which could cause sparks and/or fires when used during cooking.

9.Do not continue to cook with metal utensils if sparking appears. See "Accessories" section on page 6 for proper use of cookware.

10.Do not leave the oven unattended during short cooking times. Overcooking and fire may result.

11.Do not cook eggs in the shelf, as they will explode. Occasionally a poached egg may burst during microwave cooking. Be sure to cook covered, and let stand one minute after cooking before removing the cover.

12.Do not cook any food surrounded by a membrane, such as egg yolks, potatoes, chicken livers, etc., without first piercing them several times with a fork.

13.Do not pop popcorn except in a microwave approved popcorn bag or in a commercial package recommended especially for microwave ovens.

Never try to popcorn in a paper bag. If oil is used while making popcorn, overcooking may cause smoke and, eventually, fire.

14.Do not attempt to operate this appliance with the door open.

15.Do not attempt to remove covers, panels, etc.

16.Look at the oven from time to time when food is heated or cooked in disposable containers of plastic, paper or other combustible materials.

17.If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.

18.Microwave heating of berverages can result in delayed eruptive boiling, therefore care has to be taken when handling the container.

TO AVOID EXPLOSION AND SUDDEN BOILIING

WARNING

When heating liquids, e.g. soups, sauces and beverages in your microwave oven, overheating the liquid beyond boiling point can occur without evidence of bubbling: This could result in a sudden boil over of the not liquid. To prevent this possibility the following steps should be taken:

a.Avoid using straight sided containers with narrow necks.

b.Do not overheat.

c.Stir the liquid before placing the container in the oven and again halfway through the heating time.

d.After heating, allow to stand in the oven for a short time, stir or shake them again carefully and check the temperature of them before consumption to avoid burns (especially, contents of feeding bottles and baby food jars).

1.Eggs

Never cook eggs in their shells. Steam will build up inside the shell during cooking and the egg will explode.

If you want to cook or reheat eggs which have not been broken up by scrambling or mixing, you must always pierce the yolks or these will also explode. You should slice shelled hard boiled eggs before you reheat them in your microwave oven.

2.Piercing

Always pierce food which has a skin or membrane, for example, potatoes, tomatoes, apples, sausages etc. If you don't pierce them, steam will build up inside and they may explode.

3.Lids

Always remove the lids of jars and containers and take away food containers, before you cook using your microwave oven. If you don't, then steam and pressure might build up inside and cause an explosion even after the microwave cooking has stopped.

WHICH UTENSIL CAN BE USED IN THE OVEN?

Before use, the user should check that utensils are suitable for use in microwave ovens.

	Grill &	Microwave	Combined
Material	Convection	Microwave	Combined
	cooking	cooking	cooking
	cooking
Glass (general)	No	Yes (1)	No
Glass (heat resistant)	Yes	Yes	Yes
Glass-ceramic and
ceramic (heat resistant)	Yes	Yes (1)	Yes (1)
Earthenware	Yes	Yes	Yes
China (heat resistant)	Yes	Yes	Yes
Plastic (general)	No	Yes (2)	No
Plastic (heat resistant)	Yes (2)	Yes (2)	Yes (2)
Aluminium foil containers
/aluminium foil	Yes	Yes (3)	Yes
Metal baking tins	Yes (4)	No	Yes (4)
Metal (pots.pans, etc)	Yes	No	No
Paper	No	Yes	No

1.Without metal parts or metal trims.

2.Some plastics are heat-proof only to certain temperatures. Check carefully!

3.It is possible to use aluminium foil to shield deliate areas of food (this prevents over-cooking).

4.Metal tins can be used in the combination methods, however if these are very deep, they will greatly reduce the efficiency, as metal shields the microwave energy from the food.

Microwave function only

Utensils and cooking containers used in a microwave oven should be of a material that does not act as a barrier to microwave energy. Generally this means that you should cook in either (paper), plastic, glass or ceramic. Metal pans reflect microwave energy and inhibit cooking, and should not be used. In addition to material, the shape of the container should also be considered. Round oval shapes give the most even cooking. Square or rectangular containers may over-cook foods in the corners because more energy is absorbed there. Shallow containers give more even cooking results.

Utensils made of china and ceramic excellent to use in your microwave oven. Most types of glass are also very good. Lead crystal glass can crack and should therefore, not be used. Plastics and paper can also be used, provided they can withstand the temperature of the heated food. For cooking only use plastics, which will withstand a temperature of over 120˚C, e.g. polypropene and polyamide. Some plastic materials, e.g. melamine, will be heated by the microwave, and be damaged. To find out if a certain container is suitable, the following simple test can be made:

Place the empty container and a glass of water inside the microwave oven. The water is needed because the oven must not be operated empty or with empty containers only. Let the oven work on full power for one minute. A suitable container will only be lukewarm.

Metal containers, e.g. saucepans or frying pans should not be used in microwave ovens. Nor should plates or vessels with decorations be used since metal e.g. gold, might be part of the decoration and such decorations will be damaged. Small pieces of aluminiuum foil can be

used, but only to shield the areas that would over-cook (e.g. for covering chicken wings, leg tips and fish tails) but

the foil must not touch the side of the oven as damage may occur.

Caution:

•There are a number of accessories available on the market. Before you buy, make sure they are suitable for microwave use.

•When you put food in the microwave oven, make sure that food, food supports or covering do not come in direct contact with any of the internal walls or the ceiling of the cavity since discolouration may take place.

CONTROL PANEL

q 0 p

More Less Clock

Language

Auto Cook

Memory Cake Crusty

	W			G
	W			r
M	/			i
M				l
				l
				Auto
C			Defrost
C
o						i
n					b	i
v				m	b
	c			m
e
	ti			o
		o	n	C
			n
				Time
				W
				ei
						g
						h
						t

Q u

t y

Stop/	Start/
Clear	Speedy Cook

DISPLAY WINDOW

1MICROWAVE indicator, showing microwaving in progress.

2DEFROST indicator, showing defrosting in progress.

3GRILL(upper grill heater) indicator,

	7	showing grilling in progress.
	7	4GRILL(lower grill heater) indicator,
		4GRILL(lower grill heater) indicator,

6showing grilling in progress.

55CONVECTION indicator, showing convectioning in progress.

6CHILD LOCK indicator.

7% percentage microwave power level

8indicator.

oBUTTONS

8Language : Press to select the i language.

9Clock : Use to set clock.

0Less : Use to remove time from

ycooking.

qMore : Use to add time to cooking.

rwM/W : Press to select microwave power level.

eeCombi : Press to select combi cooking mode.

rAuto Defrost : Press to select defrost menu.

tConvection : Press to select convection temperature.

yGrill : Press to select grill.

uCake : Press to select cake menu.

diCrusty : Press to select crusty menu.

oAuto Cook : Press to select auto cook menu.

pMemory : Use to set favorite cooking mode.

aStart/Speedy Cook : Press to start a programme, also for speedy start

a(each press adds 30 seconds microwave cooking time).

sStop/Clear : Press once to stop a programme, and twice to cancel a programme.

dDial knob : Use to set time, weight and quantity.

ACCESSORIES

This oven comes equipped with several accessories. They can be used in various ways to facilitate cooking.

■ Rotating base

This fits over the shaft in the center of the oven’s cavity floor.

This to remain in the oven for all cooking. It should only be removed for cleaning.

Important:

The rotating base must be placed in the center of the oven’s cavity and fitted in the rotating shaft exactly.

In case the rotating base does not fit in the rotating shaft, the rotating base might become as tray and sparks can occur.

■ Turntable tray or turntable

This metal tray fits over the rotating base and locks into place.

This is to be used in the oven for all cooking. It rotates clockwise or counterclockwise during cooking. It is easily removable for cooking and cleaning needs.

■ Metal rack

This metal rack is used with the turntable tray.

■ HOW TO USE THE ACCESSORIES OF COOKING

■ Turntable

■ Metal rack (high)

■ Metal rack (low)


• Microwave cooking	• Grill cooking	• Cake
• Convection cooking		• Grill cooking
• Combination cooking		• Convection cooking
• Auto cooking

BEFORE OPERATION

SETTING THE LANGUAGE

Your new microwave oven comes with a six language word prompt system.

Languages available are English, Deutsch, Nederlands, Francais, Italian and Espanol.

When your oven is plugged in for the first time or when power resumes after a power interruption, the display will show "SELECT LANGUAGE SPRACHE WAEHLEN KIES TALL CHOISIR LA LANGUE SCEGLI LA LINGUA SELECCION IDIOMA"

By pressing "Language" it is possible to select the different languages.

More	Less	Clock	▲
More	Less	Clock
			Language
			Auto Cook
Memory	Cake	Crusty

Stop/		Start/
Clear	▲	Speedy Cook
	▲

To set English

1. Touch Language button once.

The display will show "ENGLISH PRESS START"
