Service Manual
CHASSIS : CP-380
MODEL :21T1ST
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Electrical Parts List
Components marked with this symbol must only be replaced by a component having
identical physical characteristics.
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
ZTR10 48B3228B03
30 47P7500001 BATTERY AAM 1.5V
ZCG10 48519A5210 CRT GROUND AS 2101H-1015-1P
ZDC10 58G0000074 COIL DEGAUSING DC-2070
10000 48586A1617 MANUAL INSTRUCTION ALL
V901 48A96321P1 CRT BARE A51JSW90X
ZMP10 PSMPMS0027 PCB MAIN MANUAL AS DTT-21T1TF
A001 4859801693 PCB MAIN 330X246 S1B
C101 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C102 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C103 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C104 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C106 CEXF1E330V C ELECTRO 25V RSS 33MF (5X11) TP
C107 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C301 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C302 CCXB1H152K C CERA 50V B 1500PF K (TAPPING)
C303 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C401 CCXB3D221K C CERA 2KV B 220PF K (TAPPING)
C402 CMYH3C602J C MYLAR 1.6KV BUP 6000PF J
C403 CEXF2C339V C ELECTRO 160V RSS 3.3MF (8X16) TP
C404 CMYE2D304J C MYLAR 200V PU 0.3MF J
C405 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C406 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C407 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C408 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C409 CXSL2H470J C CERA 500V SL 47PF J (TAPPING)
C410 CCXB3A102K C CERA 1KV B 1000PF K (TAPPING)
C411 CEXF2E330V C ELECTRO 250V RSS 33MF (13X25) TP
C412 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C413 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C414 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C415 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C417 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C501 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C502 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C503 CMXM2A223J C MYLAR 100V 0.022MF J TP
C504 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C505 CMXM2A223J C MYLAR 100V 0.022MF J TP
C506 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
TRANSMITTER REMOCON
R-28B03
7
Page 8
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
C507 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C508 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C509 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C510 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C511 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C512 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C513 CMXM2A223J C MYLAR 100V 0.022MF J TP
C514 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C515 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C516 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C517 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C518 CMXM2A223J C MYLAR 100V 0.022MF J TP
C519 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C520 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C521 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C522 CMXB1H224J C MYLAR 50V EU 0.22MF J (TP)
C523 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C524 CMXM2A223J C MYLAR 100V 0.022MF J TP
C525 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C601 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C602 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C603 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C604 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C605 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C606 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C607 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C609 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C610 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C611 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C612 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C614 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C615 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C616 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C617 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C618 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C619 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C620 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C621 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C622 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C623 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C625 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C626 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C627 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
8
Page 9
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
C628 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C629 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C630 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C631 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C701 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C702 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C703 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C704 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C705 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C706 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C707 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C708 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C709 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C710 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C711 CMXM2A333J C MYLAR 100V 0.033MF J (TP)
C712 CMXB1H224J C MYLAR 50V EU 0.22MF J (TP)
C713 CXCH1H309C C CERA 50V CH 3PF C
C801 CL1JB3474K C LINE ACROSS AC250V 0.47MF U/C/SNDF/SV
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C804 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C805 CEYM2G121T C ELECTRO 400V LWF 120MF (25X50)
C806 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
C807 CCXB3A102K C CERA 1KV B 1000PF K (TAPPING)
C808 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C809 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C810 CEXF1V221V C ELECTRO 35V RSS 220MF (10X12.5)TP
C812 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP
C814 CCXR3A102K C CERA HIKR 1KV 1000PF K 125C
C815 CCXB3A681K C CERA 1KV B 680PF K (TAPPING)
C816 CEXF2C101C C ELECTRO 160V RUS 100MF (16X25) TP
C817 CEXF2C101C C ELECTRO 160V RUS 100MF (16X25) TP
C818 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP
C819 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C820 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C821 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C822 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C823 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C824 CH1FFE472M C CERA AC 4.0KV 4700PF M KD AC250V
C825 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C904 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C905 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C906 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C907 CCXB1H561K C CERA 50V B 560PF K (TAPPING)
9
Page 10
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
C908 CCXB1H561K C CERA 50V B 560PF K (TAPPING)
C909 CCXB1H561K C CERA 50V B 560PF K (TAPPING)
C910 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C911 CCYB3D472K C CERA 2KV B 4700PF K
CC01 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC02 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC03 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC04 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC05 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC06 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC07 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC08 HCQK151JCA C CHIP CERA 50V CH 150PF J 2012
CC09 HCQK820JCA C CHIP CERA 50V CH 82PF J 2012
CC10 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC11 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC12 HCQK100DCA C CHIP CERA 50V CH 10PF D 2012
CC13 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC14 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC15 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC16 HCQK221JCA C CHIP CERA 50V CH 220PF J 2012
CC17 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012
CC18 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC19 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC20 HCBK222KCA C CHIP CERA 50V X7R 2200PF K 2012
CC21 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC22 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC23 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC24 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC26 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC27 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC28 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC29 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC30 HCBK153KCA C CHIP CERA 50V X7R 0.015MF K 2012
CC31 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC32 HCBK153KCA C CHIP CERA 50V X7R 0.015MF K 2012
CC33 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC34 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC36 HCQK471JCA C CHIP CERA 50V CH 470PF J 2012
CC37 HCQK331JCA C CHIP CERA 50V CH 330PF J 2012
CC38 HCQK471JCA C CHIP CERA 50V CH 470PF J 2012
CC39 HCQK391JCA C CHIP CERA 50V CH 390PF J 2012
CC40 HCQK391JCA C CHIP CERA 50V CH 390PF J 2012
CC41 HCQK471JCA C CHIP CERA 50V CH 470PF J 2012
10
Page 11
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
CC42 HCQK471JCA C CHIP CERA 50V CH 470PF J 2012
CC43 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
CC44 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC45 HCQK509DCA C CHIP CERA 50V CH 5PF D 2012
CC46 HCQK509DCA C CHIP CERA 50V CH 5PF D 2012
CC47 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC48 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC49 HCQK470JCA C CHIP CERA 50V CH 47PF J 2012
CC50 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC52 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC53 HCQK680JCA C CHIP CERA 50V CH 68PF J 2012
CC54 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
CC55 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC56 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC57 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC58 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC59 HCQK391JCA C CHIP CERA 50V CH 390PF J 2012
CC60 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC61 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC62 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC65 HCBK333KCA C CHIP CERA 50V X7R 0.033MF K 2012
CC66 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
CC67 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC68 HCQK390JCA C CHIP CERA 50V CH 39PF J 2012
CC69 HCQK360JCA C CHIP CERA 50V CH 36PF J 2012
CC70 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC71 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC72 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC73 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC74 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC75 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC76 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC77 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC78 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC79 HCBQ561JCA C CHIP CERA 50V CH 560PF J 2012
CC80 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC81 HCQK561JCA C CHIP CERA 50V CH 560PF J 2012
CC82 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC83 HCQK121JCA C CHIP CERA 50V CH 120PF J 2012
CC84 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC86 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC88 HCQK121JCA C CHIP CERA 50V CH 120PF J 2012
CC89 HCQK331JCA C CHIP CERA 50V CH 330PF J 2012
11
Page 12
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
CC90 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC91 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC92 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC93 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC94 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC96 HCBK152KCA C CHIP CERA 50V X7R 1500PF K 2012
CC97 HCBK152KCA C CHIP CERA 50V X7R 1500PF K 2012
CC98 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC99 HCQK150JCA C CHIP CERA 50V Y5V 15PF J 2012
CV01 CMXM2A102J C MYLAR 100V 1000PF J (TP)
CV02 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
D101 D1N4148--- DIODE 1N4148 (TAPPING)
D301 DUZ5R1BM-- DIODE ZENER UZ-5.1BM
D401 DBYV95C--- DIODE BYV95C (TAPPING)
D402 DBYV95C--- DIODE BYV95C (TAPPING)
D403 DBYV95C--- DIODE BYV95C (TAPPING)
D404 DBYV95C--- DIODE BYV95C (TAPPING)
D405 DUZ5R1BM-- DIODE ZENER UZ-5.1BM
D406 D1N4148--- DIODE 1N4148 (TAPPING)
D407 D1N4148--- DIODE 1N4148 (TAPPING)
D408 DBY228---- DIODE BY228 (TAPPING)
D501 DMTZ5R1B-- DIODE ZENER MTZ 5.1-B (TAPPING)
D503 D1N4148--- DIODE 1N4148 (TAPPING)
D504 D1N4148--- DIODE 1N4148 (TAPPING)
D701 D1N4148--- DIODE 1N4148 (TAPPING)
D702 D1N4148--- DIODE 1N4148 (TAPPING)
D703 D1N4148--- DIODE 1N4148 (TAPPING)
D704 D1N4148--- DIODE 1N4148 (TAPPING)
D705 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
D706 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
D709 DKLR114L-- LED KLR114L
D711 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
D712 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
D801 D1S1888--- DIODE 1S1888 (TAPPING)
D802 D1S1888--- DIODE 1S1888 (TAPPING)
D803 D1S1888--- DIODE 1S1888 (TAPPING)
D804 D1S1888--- DIODE 1S1888 (TAPPING)
D805 DBYV95C--- DIODE BYV95C (TAPPING)
D806 DBYV95C--- DIODE BYV95C (TAPPING)
D807 DBYV95C--- DIODE BYV95C (TAPPING)
D808 DBYV95C--- DIODE BYV95C (TAPPING)
D811 DBYV95C--- DIODE BYV95C (TAPPING)
D812 DBYV95C--- DIODE BYV95C (TAPPING)
12
Page 13
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
D813 DBYW95C--- DIODE BYW95C (TAPPING)
D901 D1N4148--- DIODE 1N4148 (TAPPING)
D902 D1N4148--- DIODE 1N4148 (TAPPING)
D903 D1N4148--- DIODE 1N4148 (TAPPING)
D904 D1N4148--- DIODE 1N4148 (TAPPING)
D905 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV01 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV02 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV03 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV04 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV05 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV06 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV07 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV08 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV09 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV11 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV12 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV13 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV14 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV15 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV16 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV17 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DV19 D1N4148--- DIODE 1N4148 (TAPPING)
F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
I301 1TDA8356-- IC VERTICAL TDA8356
I301A 4857024617 HEAT SINK AL EX
I301B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I501 1TDA8374A- IC VCD TDA8374A
I503 1TDA4665V4 IC DELAY TDA4665/V4
I601 1TDA1519B- IC AMP TDA1519B
I601A 4857025401 HEAT SINK A1050P-H24 T2
I601B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I602 1MSP3410D- IC AUDIO MSP3410D
I604 1TDA4445B- IC TDA4445B
I701 1DW5255S2- IC MICOM DW5255S2
I702 124LC08B-- IC MEMORY 24LC08B
I703 1TFMW5380- IC PREAMP TFMW5380
I704 1UPC574J-- IC UPC574J
I801 1STRS5707- IC POWER STR-S5707
I802 1TDA8138-- IC REGULATOR TDA8138
I802A 4857025401 HEAT SINK A1050P-H24 T2
13
Page 14
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
I802B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I803 1KA7808--- IC REGULATOR KA7808
I901 1TDA6106Q- IC AMP TDA6106Q
I902 1TDA6106Q- IC AMP TDA6106Q
I903 1TDA6106Q- IC AMP TDA6106Q
JP01 4859102130 JACK EARPHONE YSC-1537
JV01 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JV02 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JV03 4859108450 JACK PIN BOARD YSC03P-4120-14A
L101 5CPZ470K02 COIL PEAKING 47UH K (AXIAL 3.5MM)
L102 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L103 58C9780027 COIL CHOKE TRF-1201B (0.97 UH)
L301 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
L302 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
L401 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L404 58H0000016 COIL H-LINEARITY L-102 (102UH)
L501 58E0000S39 COIL AFT TRF-A003
L601 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L602 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L603 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L604 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L605 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L607 58M38R9006 COIL DET TRF-1490
L608 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
L609 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
L610 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
L701 5CPZ689K02 COIL PEAKING 6.8UH K (AXIAL 3.5MM)
L801 5PLF24A1-- FILTER LINE LF-24A1
L802 5MC0000100 COIL BEAD MD-5 (HC-3550)
L805 58C9430599 COIL CHOKE AZ-9004Y(94MH)
L806 5MC0000100 COIL BEAD MD-5 (HC-3550)
LV01 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV02 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV03 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV04 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV06 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV07 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV09 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV10 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
LV11 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
M351 4853530901 HOLDER LED HIPS BK
M721 4857235402 SHIELD CASE SPTH-C T0.25
P101 485923162S CONN WAFER YW025-03 (STICK)
14
Page 15
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
P401 4859240120 CONN WAFER YFW500-06
P402 485923172S CONN WAFER YW025-04 (STICK)
P501 485923192S CONN WAFER YW025-06 (STICK)
P601 485923172S CONN WAFER YW025-04 (STICK)
P801 4859242220 CONN WAFER YFW800-02
P802 4859242220 CONN WAFER YFW800-02
P901 4850706S02 CONN AS YH025-06+YST025+ULW=400
P902 4850704S04 CONN AS YH025-04+YST025+ULW=400
P903 4859275220 CONN WAFER YF254-05R (ANGLE)
P904 4859262120 CONN WAFER YFW800-01
PWC1 4859903110 CORD POWER AS CW4232+BL102NG+TUBE=2500
A000 4859903511 CORD POWER CW4232 H03VVH2-F=2250
Q301 TKTC3198Y- TR KTC3198Y
Q401 T2SD1207T- TR 2SD1207-T (TAPPING)
Q402 T2SD2499-- TR 2SD2499
Q501 TKTC3198Y- TR KTC3198Y
Q502 TKTC3198Y- TR KTC3198Y
Q601 TKTC3198Y- TR KTC3198Y
Q602 TKTC3198Y- TR KTC3198Y
Q603 TKTC3198Y- TR KTC3198Y
Q604 TKTC3197-- TR KTC3197 (TP)
Q605 TKTC3198Y- TR KTC3198Y
Q701 TKTC3202Y- TR KTC3202Y (TP)
Q702 TKTC3198Y- TR KTC3198Y
Q703 TKTC3198Y- TR KTC3198Y
Q704 TKTC3198Y- TR KTC3198Y
Q705 TKTC3198Y- TR KTC3198Y
Q706 TKTC3198Y- TR KTC3198Y
Q707 TKTA1266Y- TR KTA1266Y (TP)
Q708 TKTA1266Y- TR KTA1266Y (TP)
Q709 TKTA1266Y- TR KTA1266Y (TP)
Q710 TKTC3198Y- TR KTC3198Y
Q801 TKTC3198Y- TR KTC3198Y
Q802 TKTC3198Y- TR KTC3198Y
Q901 TKTA1266Y- TR KTA1266Y (TP)
QV01 TKTC3198Y- TR KTC3198Y
QV02 TKTA1266Y- TR KTA1266Y (TP)
R101 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R301 RD-2Z153J- R CARBON FILM 1/2 15K OHM J
R302 RD-AZ302J- R CARBON FILM 1/6 3K OHM J
R303 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R304 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R305 RD-2Z271J- R CARBON FILM 1/2 270 OHM J
15
Page 16
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
R306 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R307 RD-4Z822J- R CARBON FILM 1/4 8.2K OHM J
R308 RD-4Z223J- R CARBON FILM 1/4 22K OHM J
R401 RD-4Z272J- R CARBON FILM 1/4 2.7K OHM J
R402 RD-4Z399J- R CARBON FILM 1/4 3.9 OHM J
R404 RD-4Z153J- R CARBON FILM 1/4 15K OHM J
R406 RF01Y109JA R FUSIBLE 1W 1 OHM J A CURVE
R409 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R410 RD-2Z273J- R CARBON FILM 1/2 27K OHM J
R411 RS01Z103J- R M-OXIDE FILM 1W 10K OHM J (TAPPING)
R412 RS01Z561J- R M-OXIDE FILM 1W 560 OHM J (TAPPING)
R413 RD-AZ303J- R CARBON FILM 1/6 30K OHM J
R414 RD-AZ303J- R CARBON FILM 1/6 30K OHM J
R501 RD-4Z109J- R CARBON FILM 1/4 1 OHM J
R502 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R503 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R504 RD-AZ303J- R CARBON FILM 1/6 30K OHM J
R505 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R507 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R508 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R509 RD-AZ335J- R CARBON FILM 1/6 3.3M OHM J
R601 RD-2Z151J- R CARBON FILM 1/2 150 OHM J
R602 RD-2Z151J- R CARBON FILM 1/2 150 OHM J
R603 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R604 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R606 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R608 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R701 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R702 RD-4Z109J- R CARBON FILM 1/4 1 OHM J
R703 RS02Z562J- R M-OXIDE FILM 2W 5.6K OHM J (TAPPING)
R704 RS02Z562J- R M-OXIDE FILM 2W 5.6K OHM J (TAPPING)
R705 RD-4Z333J- R CARBON FILM 1/4 33K OHM J
R706 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R708 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R709 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R710 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R711 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R712 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R713 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R714 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R716 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R717 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R718 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
16
Page 17
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
R719 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R720 RD-AZ391J- R CARBON FILM 1/6 390 OHM J
R801 DEC180M290 POSISTOR ECPCC180M290
R802 RX10B339JN R CEMENT 10W 3.3 OHM J BENCH 4P
R803 RS02Z473J- R M-OXIDE FILM 2W 47K OHM J (TAPPING)
R804 RF02Z568J- R FUSIBLE 2W 0.56 OHM J (TAPPING)
R805 RS01Z360J- R M-OXIDE FILM 1W 36 OHM J (TAPPING)
R806 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R807 RD-4Z222J- R CARBON FILM 1/4 2.2K OHM J
R808 RD-4Z220J- R CARBON FILM 1/4 22 OHM J
R809 RD-4Z104J- R CARBON FILM 1/4 100K OHM J
R822 RS01Z473J- R M-OXIDE FILM 1W 47K OHM J (TAPPING)
R824 RS01Z120J- R M-OXIDE FILM 1W 12 OHM J (TAPPING)
R825 RC-2Z565J- R CARBON COMP 1/2 5.6M OHM J
R826 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R827 RD-4Z362J- R CARBON FILM 1/4 3.6K OHM J
R828 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R829 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R830 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R831 RS02Z620J- R M-OXIDE FILM 2W 62 OHM J (TAPPING)
R832 RS02Z620J- R M-OXIDE FILM 2W 62 OHM J (TAPPING)
R901 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
R902 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
R903 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
R904 RD-AZ162J- R CARBON FILM 1/6 1.6K OHM J
R905 RD-AZ162J- R CARBON FILM 1/6 1.6K OHM J
R906 RD-AZ162J- R CARBON FILM 1/6 1.6K OHM J
R907 RD-4Z104J- R CARBON FILM 1/4 100K OHM J
R908 RD-4Z104J- R CARBON FILM 1/4 100K OHM J
R909 RD-4Z104J- R CARBON FILM 1/4 100K OHM J
R910 RC-2Z152J- R CARBON COMP 1/2 1.5K OHM J
R911 RC-2Z152J- R CARBON COMP 1/2 1.5K OHM J
R912 RC-2Z152J- R CARBON COMP 1/2 1.5K OHM J
R913 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RC01 HRFT183JCA R CHIP 1/10 18K OHM J 2012
RC02 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC03 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC04 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC05 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC06 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC07 HRFT479JCA R CHIP 1/10 4.7 OHM J 2012
RC08 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC09 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
17
Page 18
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
RC100 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC101 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC102 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC10 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC11 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RC12 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC13 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC14 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC15 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RC16 HRFT470JCA R CHIP 1/10 47 OHM J 2012
RC17 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC18 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC19 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC20 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC21 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC22 HRFT479JCA R CHIP 1/10 4.7 OHM J 2012
RC23 HRFT394JCA R CHIP 1/10 390K OHM J 2012
RC24 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC25 HRFT470JCA R CHIP 1/10 47 OHM J 2012
RC26 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC29 HRFT393JCA R CHIP 1/10 39K OHM J 2012
RC30 HRFT100JCA R CHIP 1/10 10 OHM J 2012
RC31 HRFT121JCA R CHIP 1/10 120 OHM J 2012
RC32 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC33 HRFT563JCA R CHIP 1/10 56K OHM J 2012
RC34 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC35 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC36 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC37 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RC38 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC39 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC40 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC41 HRFT683JCA R CHIP 1/10 68K OHM J 2012
RC42 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC43 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC44 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC45 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC46 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC47 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC48 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC49 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC50 HRFT751JCA R CHIP 1/10 750 OHM J 2012
RC51 HRFT101JCA R CHIP 1/10 100 OHM J 2012
18
Page 19
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
RC52 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC53 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RC54 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC55 HRFT622JCA R CHIP 1/10 6.2K OHM J 2012
RC56 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RC57 HRFT100JCA R CHIP 1/10 10 OHM J 2012
RC58 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC59 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC60 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC61 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC62 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC63 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC64 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC65 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC66 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC67 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC68 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC69 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC70 HRFT912JCA R CHIP 1/10 9.1K OHM J 2012
RC71 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC72 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC73 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RC74 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC75 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC76 HRFT100JCA R CHIP 1/10 10 OHM J 2012
RC77 HRFT913JCA R CHIP 1/10 91K OHM J 2012
RC78 HRFT564JCA R CHIP 1/10 560K OHM J 2012
RC79 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC80 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC81 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC82 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC83 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC84 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC85 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC86 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC87 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC88 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC89 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC90 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC91 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC92 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC93 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC94 HRFT223JCA R CHIP 1/10 22K OHM J 2012
19
Page 20
LOC. P ART-CODE P ART-NAME P ART-DESCRIPTION REMARK
RC95 HRFT121JCA R CHIP 1/10 120 OHM J 2012
RC96 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC97 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC98 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC99 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RV06 RD-4Z750J- R CARBON FILM 1/4 75 OHM J
RV07 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RV08 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RV09 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RV10 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RV11 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RV12 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RV13 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RV14 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RV15 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RV16 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RV17 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
SCT1 4859303030 SOCKET CRT ISMM03S
SF01 5PG3962M-- FILTER SAW G 3962-M
SF03 5PG9251M-- FILTER SAW G 9251-M
SP01 4858305220 SPEAKER 3W 8 OHM MSF-2D30SB02U
SP01A 4850704S13 CONN AS YH025-04+YST025+USW=600
SP02 4858305220 SPEAKER 3W 8 OHM MSF-2D30SB02U
SW01 5S50101090 SW TACT SKHV17910A
SW02 5S50101090 SW TACT SKHV17910A
SW03 5S50101090 SW TACT SKHV17910A
SW04 5S50101090 SW TACT SKHV17910A
SW05 5S50101090 SW TACT SKHV17910A
SW801 5S40101143 SW PUSH PS3-22SP (P.C.B)
T401 50D10A2--- TRANS DRIVE TD-10A2
T402 50H0000177 FBT HST1142.5057
T802 50M0000099 TRANS SMPS SMT2084.0014D
TU01 4859714430 TUNER VARACTOR 3303KHC-3X1289
X501 5XE4R4336E CRYSTAL QUARTZ HC-49/U 4.433619MHZ 30PPM
X502 5XE3R5795E CRYSTAL QUARTZ HC-49/U 3.579545MHZ 30PPM
X601 5XE18R432E CRYSTAL QUARTZ HC-49/U 18.43200MHZ 30PPM
X701 5XE18R000E CRYSTAL QUARTZ HC-49/U 18.000MHZ 30PPM
Z101 5PMKT40MA- FILTER CERA MKT40MA100P
ZSP10 PSSPPW0027 SPEAKER AS DTT-21T1TF
20
Page 21
The Different Parts for CRT(CP-380)
NO LOC. NAME 20 (ORION) 21 (ORION) 21 (PHILIPS) 21
1 V901 CRT A48JLL90X01 A51JSW90X02 A51EAL55X01 A51EBV13X9
48A96420P1 48A96321P1 4859607660 485962160
2 C401 C CERA 2KV 470PF 2KV 220PF 2KV 470PF 2KV 220PF
CCXB3D471K CCXB3D221K CCXB3D471K CCXB3D221K
3 C402 C MYLAR 1.6KV 7500PF 1.6KV 6000PF 1.6KV 7500PF 1.6KV 6900PF
CMYH3C752J CMYH3C602J CMYH3C752J CMYH3C692J
4 C404 C MYLAR 200V 0.47MF 200V 0.3MF 200V 0.51MF 200V 0.27MF
CMYB2D474K CMYE2D304J CMYE2D514J CMYE2D274J
5 L404 COIL L-102 TRL-341G
H-LINEARITY 58H0000016 58H0000040
6 L806 COIL BEAD MD-5
5MC0000100
7 L807 COIL BEAD MD-5 MD-5
5MC0000100 5MC0000100
8 P401A CONN AS 35135-06+HS
(POLKOLOR)
30052+ULW=500
4850706S10
9 R302 R C-FILM 1/6W 2.4K 1/6W 3K 1/6W 3.3K 1/6W 2.7K
RD-AZ242J- RD-AZ302J- RD-AZ332J- RD-AZ272J-
10 R406 R FUSIBLE 1W 2.4A(F) 1W 1A(F) 1W 2.7A(F) 1W 1.2A(F)
RF01Y249JA RF01Y109JA RF01Y279JA RF01Y129JA
11 R827 R C-FILM 1.4W 4.7K 1.4W 3.6K 1.4W 4.7K
RD-4Z472J- RD-4Z362J- RD-4Z472J-
12 SCT1 SOCKET CRT ISMM03S
4859303030
13 SCT2 SOCKET CRT ISHS-09S
4859302930
14 ZCG10 CRT GND AS 2001H-1015P-1P 2101H-1015-1P
48519A5010 48519A5210
15 ZDC10 COIL DC-2050 DC-2070
DEGAUSSING 58G0000086 58G0000074
21
Page 22
The Different Parts for System(CP-380)
NO LOC. NAME TF TK TU TA
1 J501 WIRE COPPER AWG22 1/0.65TIN
COATING
85801065GY
2 J502 WIRE COPPER AWG22 1/0.65TIN
COATING
85801065GY
3 J054 WIRE COPPER AWG22 1/0.65 TIN
COATING
85801065GY
4 J055 WIRE COPPER AWG22 1/0.65 TIN
COATING
85801065GY
5 J805 C ELECTRO 400V 120MF 450V 150MF 400V 120MF
CEYM2G121T CEYM2G151P CEYM2G121T
6 D601 DIODE 1SS85TA
D1SS85TA
7 D902 DIODE 1SS85TA
D1SS85TA
8 I501 IC VCD TDA8374A TDA8374
1TDA8374A-- 1TDA8374A--
9 I502 IC TDA8395 TDA8375
1TDA8395-- 1TDA8395--
10 I603 IC TDA4445B
1TDA4445B--
11 PWC1
12 SF01 FILTER SAW G3962M K3953M G3962M
13 SF02 FILTER SAW L9461M
14 SF03 FILTER SAW G9251M K9260M G925M
15 TU01 TUNTER 3303KHC DT2-1V17D 3303KHC
16 Z101 FILTER CERA MKT40MA100P MKT40MA100P
CORD POWER
AS +TUBE=2500 +TUBE=2100 +HOUS=2200 +TUBE=2500
VARACTOR 4859714430 4859716130 4859714430
CW4232+BL102NG KKP419C+BL102NG
4859903110 4859902910 4859905110 4859903110
5PG3962M-- 5PK3953M-- 5PG3962M--
5PG9251M-- 5PK9260M-- 5PG9251M--
5PMKT40MA 5PMKT40MA
CW3222/240V 5A
CW4232+BL102NG
5PL9461M--
22
Page 23
CP-380 CHASSIS SCHEMATIC DIAGRAM
23
Page 24
WAVE FORMS
24
Loading...
