Dacor MCS130S Use And Care Manual

®

Family-Owned.American-Made.

Use & Care

Wall Ovens

SAFETY IS EVERYONE'S RESPONSIBILITY. ALL DACOR APPLIANCES ARE DESIGNED
AND CONSTRUCTED TO GIVE YOU MANY YEARS OF SAFE OPERATION. THE
OPERATION WILL BE FURTHER ENHANCED IF PROPER CARE AND JUDGEMENT ARE

EXERCISED IN THE USE AND MAINTENANCE OF THIS APPLIANCE.

IMPORTANT INFORMATION

• Operating Instructions

• Care and Cleaning Instructions

• Safety Tips

WARNINGS:

NOTEs:MUStbe followed carefully to avoid personal injury or damage, wall ove_,, _

Contains helpful hints and tips.

please p,ead e_ore using"t°ur

Place Serial Number Label Here

Part No. 65031 Rev D

Dear DACOR Consumer,

Congratulations! You have purchased the very latest in kitchen appliances. Your new DACOR product offers features,
styling and performance not found in any other appliance.

Please read this manual before operating your new appliance. It isimperative that you read the IMPORTANT
INSTRUCTIONS sect)on and become faro}liar w)th the controJs and procedures to understand the full potential of this
product.

All DACOR appliances are designed and manufactured to meet the highest quality standards. Each unit is thoroughly
tested. Should you have a problem, howevec please first check the PROBLEM SOLVING section in this manual. This
section contains a checklist of possible problems and solutions that may save you the time and expense of an
unnecessary service call.

ff you cannot readily find the solution to the problem, please contact your nearest DACOR Authorized Service
Representative. In the unlikely event they are unable to solve your problem to your satisfaction, please contact
DACOR Customer Service.

Web site: www,dacor,com

For a Dealer/Service: [phone]
Corporate Phone: [phone]
Fax: [phone]

Business Hours: 7:30 AM. to 4:00 P.M. Pacific Time

DACOR Customer Service
1440 Bridge Gate Dr.

Diamond Bar, CA 91765

Thank you for selecting DACQR for your home. We are dedicated to you and ensure that this appliance in y_ur home
will bring years of outstanding performance for your family and friends.

Sincerel_

Chairman/CEO

TABLE OF CONTENTS .................................... 1

Purpose of this Manual ................................ 1

Product Registration .................................... 1

IMPORTANT INSTRUCTIONS ......................... 1

What To Do .................................................. 1

What Not To Do ............................................ 1

OVEN OPERATION ....................................... 2-7

Getting Started .......................................... 2-3

What is Pure ConvectionTM? ........................ 3

Setting the Time of Day................................ 3

Oven Modes ................................................. 3

Oven Racks & Supports ............................... 3

Oven Mode Selection ................................... 4

Preheating the Oven .................................... 4

Using the Minute Timers .............................. 4

Securing the Controls .................................. 4

Baking/Roasting ........................................ 4-5

Multiple Rack Baking ................................... 5

Oven GlideRack ........................................... 5

Using the Temperature Probe ...................... 6

Timed/Delay Timed Cooking ........................ 7

DehydratinglDefrosting ................................ 7

Broiling ......................................................... 7

CARE AND CLEANING ............................... 7-10

Control Panel ............................................... 7

Door Handle & Control Housing ................... 8

Door Glass ................................................... 8

Stainless Steel Surfaces .............................. 8

Porcelain Surfaces ....................................... 8

Brass and Chrome Surfaces ........................ 8

Broiler Pan and Grill ..................................... 8

Oven Racks ................................................. 8

Convection Fan Filter ................................... 8

Self-Cleaning ............................................ 8-9

Adjusting the Oven Temperature .................. 9

Replacing the Oven Light ........................... 10

PROBLEM SOLVING ................................. 10-12

Troubleshooting .................................... 10-11

Product Maintenance ................................. 12

If You Need Service ................................... 12

ACCESSORIES ...................................... 12

PRODUCT WARRANTY ................................. 12

What Is Covered ........................................ 12

What Is Not Covered .................................. 12

Purpose of This Manual i

This Use & Care Manual is designed to enable
you to properly operate and maintain your new

cooktop. Please keep this manual handy for
easy access and quick reference.

Additional information may be requested by
e-mailing, writing or phoning the DACOR
Customer Service Department. The address

and phone number of this department are listed
on the inside front cover of this manual.

[What,oOo i

1. Begin by ensuring proper installation and
grounding of the appliance by a qualified

technician according to the accompanying

Installation Instructions. Have the installer
show you where the fuse or junction box is

located so that you know how and where

to turn off power.

2. Ensure that the oven is used only by those
individuals who are able to operate it

properly.

3. Use the oven only for cooking tasks
expected of a home oven as outlined in

this manual.

4. Properly clean and maintain the oven as
recommended in this manual.

5. Use only dry potholders to avoid steam
burns when removing hot cookware.

6. Exercise caution when opening the oven

door. Let hot air or steam escape before

looking or reaching into the oven.

7. Allow the oven cool air intake (located
below the door handle) to remain

unobstructed at all times.

8. Position oven racks in desired locations

when the oven is coot. (If a rack must be

repositioned after the oven is already hot,
be certain that the potholder does not

contact a hot heating element in the oven.)
Before Self-Cleaning the oven, remove

the broiler grill and pan, oven racks,

convection fan filter and any other utensils.
Clean only those parts listed in this

manual.

g.

10.

What Not to Do i

3. Do not store items of interest to children
above the oven. Children could be burned
or injured while climbing on the appliance.

4. Do not wear loose or hanging apparel
while using the oven.

5. Do not store combustible, flammable
or explosive materials in the oven or in
adjacent cabinets.

6. CAUTION: DO NOT LEAVE FOOD OR
COOKING UTENSILS, ETC., IN THE

OVEN DURING THE SELF-CLEAN
CYCLE.

7. Do not repair or replace any part of the
oven unless specifically recommended in
literature accompanying this appliance.

All other service should be referred to a
qualified technician.

8. Do not use water on grease fires. A violent
steam explosion may result. Smother any
flames with a lid, cookie sheet or flat tray.

Flaming grease can be extinguished with
baking soda or foam extinguisher.

9. Do not allow potholders to touch hot
surfaces. Do not use towels or bulky cloth

as potholders.

10. Do not use commercial oven cleaners or
oven liner protective coatings on any part

of the oven.

11. Do not clean the door gasket, because
rubbing, moving or in any way damaging

the gasket, may eliminate the required
tight door seal.

12. DO NOT TOUCH INTERIOR SURFACES
OF THE OVEN. During and after use, do

not touch or let clothing or other flammable
materials contact heating elements or

interior surfaces of the oven until they
have had sufficient time to cool.

13. Do not heat unopened food containers,
such as baby food jars and cans. Pressure

build up may cause the container to burst
and cause injury.

14. Do not use abrasive or caustic cleaners
or detergents on this appliance, as these

may cause permanent damage. Do not
use aerosol cleaners, as these may be
flammable or cause corrosion of metal

parts.

15. Do not allow acids (citrus juices, tomato
sauces, etc.) to remain on the oven cell

surfaces. The porcelain finish may stain.

ILProduct Registration 1

1.

2.

Do not use the oven for warming or
heating the room.

Do not leave children alone or unattended
in the area where the oven is in use.

Never allow children to sit or stand on any
part of the oven. Do not let children play

with the oven.

If you received a damaged product,
immediately contact your dealer or builder.

Do not install or use a damaged appliance.

_} Please enter the information requested in the spaces provided below. This information will be required in the unlikely event that a service call

becomes necessary:

Model No. Serial No.

Date Purchased Date Installed

Purchased From

Address

Phone

Getting Started

Before using your oven, become familiar with
the features and control panel layout.

Below the oven mode touch pads are three
touch pads labeled "CANCEL.SECURE,"

"LIGHT" and "COOK TIME". The
"CANCEL.SECURE" touch pad enables the

user to cancel the selection of an oven mode
or Delay Timed program, or disable the control

panel by pressing and holding the pad for
approximately three (3) seconds. Once the

control panel is in the "SECURE" mode, "OFF"
will be displayed on the clock. The "LIGHT"
touch pad turns the interior oven light "on"

and "off." The "LIGHT" touch pad will remain
functional if the control panel has been disabled.

The "COOK TIME" touch pad is used to select
the length of time for a cooking process in Delay
Timed cooking mode.

Clock functions are selected by pressing the
touch pads located below the clock display

and oven mode touch pads. Oven functions
are chosen by pressing the touch pad for the
desired mode. Once a clock or oven function

has been chosen, a description of the selection
will flash in the clock display area.

IMPORTANT:

After choosing a clock function or oven
mode, you have six seconds to perform the

next programming step. If the next step is
not complete within six (6) seconds, the
program selection displayed on the clock

will disappear. Should this occur, just repeat
the initial function selection.

I Control Panel

Cool Air Slots

Smoke Eliminator ....

Broil Element ......

Temperature Probe Socket

Rack Support ...........

Oven Rack

Oven Light

Self-Clean Lock Latch
Self-Clean Instructions

Broil Reflector

Oven Light
Temperature Sensor

......Convection Element

Convection Fan
Convection Baffle
Butterfly Bake Element (patent pending)

Door Hinge

• Door Gasket

Door Handle .....

Lower Exhaust Grill

Oven Features

Oven Window

-- Exhaust Air Grill Slots

P

®/6

Epicure ECD227 and ECD230 Wall Oven Control Panel

Millennia MCD227 and MCD230 Wall Oven Control Panel

ii

_,_ , ....._ _¢_

Millennia MCD227 and MCD230 Wall Oven Control Panel

Epicure ECS227 and ECS230 Wall Oven Control Panel

® ®/_

Millennia Mes227 and MCs230 Wall Oven Control Panel

® ®

Epicure ECS127, ECS130 and ECS136 Wall Oven Control Panel

dacar _;_

Millennia MCS127 and MCSf30 Wall Oven Control Panel

]

3so' 13 nn

I

I L. I_11_1 '_ '_'

Preference PCS f 30 Wall Oven Control Panel

IIWhat is Pure ConvectionTM? I

Your new oven has the best cooking system
available today, "Pure Convection TM''.Pure
Convection TM is a total system approach to

cooking. The heat source is a third element
outside the cooking celI behind a "baffle." Not

only does the baffle separate the food from
the heat source, it channels the air from the
"Convection Fan" evenly into the ceil eliminating

any hot or cool spots in the oven. This system is
what allows multi-rack cooking while achieving

even results from one rack to another.

The other component in Pure Convection TM is
the "Filter." The filter eliminates the transference

of flavors when cooking entire meals and also
keeps the oven cleaner.

_:::;_Direction of Air Flow

Heated Air Circulation Pattern in Convection Modes

Setting the Time of Day

Follow these two steps to set the correct
time of day:

1. Press the "CLOCK" touch pad. The time
of day will flash, "AM" or "PM" will be

displayed, and "TIME" will flash in the
display.

2. Press the touch pad "+" or "-" until the
correct time of day is displayed and

release.

Oven Modes

All oven modes are described below:

_ TANDARD BAKE - In Standard Bake

mode, the bottom heating element

i

provides conventional radiant heat.
Temperatures may be set from 135° to
555°F in 5°F increments. Use Standard

Bake for single rack baking and roasting.
STANDARD BROIL - The high wattage,

top heating element supplies the heat
in Broil mode. The broil temperature is

adjustable from !35°F, to the "H!" setting
(equivalent to 555°F) for greater cooking

flexibility. Broiling is performed with the
door closed.

CONVECTION BROIL - The high
wattage, top heating element supplies

the heat in Broil mode in combination
with the convection fan for better heat

distribution. The broil temperature is
adjustable from !35°F to the "HI" setting

(equivalent to 555°F) for greater cooking
flexibility. Only available in ECD 230,

PCD 230, and MCD230 models. Broiling
is performed with the door closed.

[_ URE CONVECTION TM - In Pure

Convection TM mode a third heating
element, encircling the convection fan

located in the rear of the oven chamber,
acts as the heat source. The convection

fan draws air from the oven chamber,
then forces it across the hot convection

heating element. The heated air is
directed back into the oven chamber

through the convection baffle. The baffle
distributes the heated air evenly to

ensure uniform results. Temperatures
may be set from 135° to 555°F in 5°F

increments. Use this mode for single rack
baking, multiple rack baking, roasting,

and preparation of complete meals.

_ CONVECTION BAKE - In this

combination convection-radiant mode,
the lower element provides the heat.
As in Pure Convection TM mode, the

convection fan and baffle combine to
circulate heated air evenly throughout the

oven chamber. Temperatures may be set
from 135°F to 555°F in 5°F increments.

Use this mode for single rack baking,
multiple rack baking and roasting.

_ TEMPERATURE PROBE - The

Temperature Probe can be use in
combination with Standard Bake, Pure

Convection TM, or Convection Bake
modes. The Temperature Probe takes
the guesswork out of roasting by cooking
food to the exact internal temperature

you desire. The temperature range that
the Probe will read is from 100°F to

200°F.

_ SELF-CLEAN - In the pyrolytic

Self-Clean mode, the oven reaches
temperatures of 850°F, thereby burning
off oven soil automatically. The Self-

Clean time is adjustable up to four hours
so that varying degrees of oven soil can

be successfully removed. Also, the Self-
Clean cycle can be delayed to start at a

later time if desired.

IIOven Racks and Supports

Three chrome-plated convection racks are

provided in the oven. Always remember to
position the racks prior to heating the oven.

Also, remove the oven racks prior to self-
cleaning to prevent permanent discoloration of

the racks.

I

The porcelain rack supports provide six heights
for positioning of the oven racks.

To install a rack, align the left and right edges
of the rack with the horizontal guide rails of the

rack supports, then slide the rack into the oven.

Oven Rack Positions

I Oven Mode Selection I 2.

Follow these steps to manually operate the
oven in Standard Bake, Pure Convection TM or
Convection Bake mode:

1. Position oven rack(s) at the proper
height(s).

2. Press the touch pad for "STANDARD
BAKE", "PURE CONVECTION TM''or

"CONVECTION BAKE". The oven will beep
once, the selected cooking mode will flash,
and _'-- -" will be displayed.

3. Press either the "+" or "-" pad. The default
temperature of 350°F will be displayed.

4. To adjust the cooking temperature from
350F, press and hold the "TIME,TEMP"
pad. (Press "+" key to increase the

temperature setting, "-" to decrease.)
"PRE" and "ON" will appear in the clock
display, and the oven will begin to heat.

The convection fan will turn on to help
stabilize the oven temperature during

preheat. In standard bake mode, the
convection fan will turn off once the desired

temperature is attained. If in a convection
mode, the convection fan will turn on.
Also, the clock display will change from the

desired cooking temperature to the actual
oven temperature, starting with 135°F. The

temperature display will increase in 5°F
increments until the desired temperature
is reached. The cooling fan will turn on

when the oven temperature reaches 200°F.
When the desired temperature is attained,
the Preheat cycle is complete. The clock

will beep once and "PRE" and "ON" will
disappear from the display. (From this time

forward, the "ON" display will cycle on and
off with the heating elements.)

5. Carefully place the food onto the desired
rack(s) within the preheated oven.

6. It is recommended that a Minute Timer be
set to time the cooking process.

7. When the time expires and/or the
food is done cooking, press the

"CANCEL,SECURE" pad to turn off the
oven.

I Preheating the Oven

The oven features an automatic Preheat cycle
that rapidly brings the oven chamber up to

temperature. Simply by choosing a cooking
mode and setting a temperature, the oven will

automatically perform the Preheat function. The
Preheat cycle operates in Standard Bake, Pure

Convection TM and Convection Bake modes.
There is no Preheat cycle for the Broil or

Convection Broil modes.

Typically, 7 to 10 minutes are required to
preheat the oven to 350°F, and 11 to 14 minutes

are necessary to reach 425°F. Preheat times will
be greater in those areas in which the electrical

supply is less than 240 volts or 208 volts

_ NOTES:

1. For faster heat up, the broil element
comes on during Preheat. For best

results, allow the oven to preheat prior
to placing food inside.

The Preheat cycle is disabled during
"PROBE" cooking. For best results,

allow the oven to preheat in the desired
mode prior to pressing the "PROBE"
key.

I 3.

I Using the Minute Timers
The clock features twotimers that may be used

to time cooking or otherprocesses up to 11

hours, 50 minutes in length.

To use the Minute Timer function, follow these
steps:

1. Press the touch pad labeled "TIMER !", or
"TIMER 2". The clock will display "00:00",

and "TIMER 1", or "TIMER 2" will flash.

2. Press the "+" pad until the desired time is
displayed on the clock.

3. After "TIMER !" has expired, the clock
will sound off with one second beeps and

"TIMER 1" will appear in the display. After
the "TIMER 2" minute timer has expired,

the clock will sound alternating one and
two second beeps and "TIMER 2" will
appear in the display. The beeper can be

silenced by pressing the "TIMER" touch
pad while the beeper is sounding.

_} IMPORTANT:

Cancellation of the Minute Timer does not
turn off the oven if it is operating. You must

manually shut the oven off by pressing the
"CANCEL,SECURE" touch pad. (See the

Delay Timed Cooking section for automatic

oven turn on and turn off.)

_ NOTES:

1. To view the current time of day rather
than the remaining time on the Minute

timer, just press the "CLOCK" touch
pad. To change back to a Minute Timer
display, press the "TIMER 1" or "TIMER

2" touch pad.

2. To cancel the Minute Timer while in

progress, press the "TIMER 1 or 2"
touch pad two times. The clock display
will return to the time of day.

The Minute timers may be used at the
same time as Delay Timed Cooking or

Self-Clean.

4. The Minute Timers will beep for 2

minutes (if not cancelled) before
automatically shutting off.

5. Pressing the "CANCEL,SECURE"
pad when the beeper is sounding will

cancel both the beeper and the cooking
function.

I Securing the Controls

To avoid accidentaIIy turning the oven on,
activate the "SECURE" feature. Press and hold

the _'CANCEL,SECURE" pad for approximately
three seconds. This will disable the control

panel and allow cleaning the controls without

accidentally starting any functions. Three beeps
will sound and "OFF" will appear in the display

when the control panel has been secured.

To re-activate the control panel, again push
and hold the _'CANCEL,SECURE" pad for three

seconds. Three beeps will sound and the "OFF"

will disappear from the display.

ILBaking,Roasting 1

In addition to the conventional radiant-heat
Standard Bake mode, your DACOR oven

offers two convection baking modes: Pure
Convection TM and Convection Bake. All modes

can be used to successfully prepare meals
using standard recipes or your own personal

favorites.

Because of variations in food density, surface
texture and consistency, there are a few foods

that may be prepared more successfully in the
Standard Bake mode. For this reason, Standard

Bake mode is recommended when preparing
baked goods such as custard. The user may

find other foods that are also prepared more

consistently in Standard Bake mode. This is
perfectly normal.

1. As a general rule, to convert conventional
Standard Bake recipes to convection

recipes, reduce temperature by 25°F and
the cooking time by approximately 10%.

2. Some recipes, especially those that are
homemade, may require adjustment and
testing when converting from standard to

convection modes. If unsure how to convert
a recipe, begin by preparing the recipe

in Standard Bake mode. After achieving
acceptable results this way, follow the

convection guidelines listed. If the food is
not prepared to your satisfaction during
this first convection trial, adjust only one

recipe variable at a time (such as cooking
time, rack position or temperature) and
repeat the convection test. if necessary,

continue adjusting one recipe variable at a
time until satisfactory results are achieved.

Common Baking Problems, for additional
information.

3. Do not open the oven door frequently
during baking. Look through the door

window to check the progress of baking
whenever possible.

4. Use the Minute Timers to time baking
functions

5. Wait until the shortest recommended
baking time before checking food. For

baked goods, a wooden pick placed in the
center should come clean when the food is
done.

6. Bakeware Tips:

• Cakes, quick breads, muffins and
cookies should be baked in shiny,

reflective pans for light, golden crusts.

• Medium gauge aluminum sheets
with low sides should be used when

preparing cookies, biscuits and cream
puffs.

• Bake most frozen foods in their
original foil containers placed on a
flat cookie sheet. Follow the package

recommendations.

PROBLEM

1. Cookies and biscuits burn on the bottom.

PROBABLE CAUSE

Oven door opened too often

CORRECTION
Set Minute Timer to shortest recommended

time and check food at this time. Use door
window to check food.

Incorrect rack position being used. Pan too
close to bake element.

Change rack position. Use Pure Convection TM
mode.

Standard Bake or Convection Bake mode being Use Pure Convection TM mode.
used.

2. Cookies and biscuits are too brown on top. Rack position being used is too high.

Change rack position.

3. Cakes burn on the sides or are not done in
center.

Food was placed in the oven during pre-heat.

Oven was too hot.

Wait until oven is pre-heated

Reduce temperature.

4. Cakes crack on top.

5. Cakes are not level.

Oven temperature was too high.

Oven and/or oven rack was not level.

Reduce oven temperature.

Level oven and rack as needed.

6. Pies burn around edges or are not done
in center.

7. Pies are too light in color on top.

Oven was too hot.

Dark, heat absorbing pan is being used.

Oven was not hot enough.

Reduce temperature.

Use shiny, reflective pans.

Increase oven temperature.

Oven and/or rack over crowded.

Reduce number of pans.

7.

8.

• When using glass bakeware, reduce the
recipe temperature by 25°F, except when
baking pies or yeast breads. Follow the

standard recipe baking time for pies and
yeast breads.

Place pans carefully on the oven racks.

Turn pans on the racks so that the long
sides run left to right, parallel to the door.

Adjustments to recipe times and
temperatures wili have to be made

when baking at high altitudes. Consult a
cookbook on high-altitude cooking.

I Multiple Rack Baking

The uniform air circulation provided by Pure
Convection TM cooking enables the full oven
capacity to be utilized. Many foods, such

as pizzas, cakes, cookies, biscuits, muffins,
rolls and frozen convenience foods can be

successfully prepared on either two or three
racks at the same time. Additionally, complete

meals can be prepared by using multiple racks.

i

See below for specific recommendations.

Follow the steps in the Oven Modes section to
manually operate the oven, or refer to the Delay
Timed Cooking section below for automatic

operation.

Common Baking Problems

[ Oven GlideRack TM

Dacor's Oven GlideRack TM is designed to
install effortlessly and glide at a full extension.

Especially when using Dacor's pizza stone
(model number ABS20), the full extension of the
rack allows you to slide the pizza on and off the

stone with great ease. It is also great for large
roasts in large roasting pans. This easy- slide
rack will allow you to baste more easily and

check temperatures of the food more safely and
quickly.

Proper Installation of the Easy slide Oven
Rack:

1. Fully extend the two side guides. Align two
small clips on the bottom at the rear of the

Oven GlideRack TM with the black porcelain
rack guides in the oven.

2. Begin to slide the rack in, then lift up. The
Oven GlideRack TM must be in between the

two clips on the upper and lower side of
the rack rear.

3. Push the rack all the way to the back.

4. Grasp the rack in the front center and pull.
The rack should come forward while the

side guides remain in place.

Helpful Hints When Using Your Oven

GlideRack TM :

1. This rack works particularly well with
heavier items, although you can use it
during any baking, broiling or roasting in

your Uacor oven.

2. These racks will need to be spaced out
when using more than one in the oven at

a time. For instance, the racks should be
used on rack positions 1,3, & 5 or 2 & 4,

counting up from the bottom, instead of
using racks 2,3, & 4.

3. When using the rack with Dacor's ABS20
baking stone, use rack position 1 for best

results.

4. Heavier roasting pans and dishes will also
cook better on Rack position 1.

5. Do not leave the rack in during self- clean.
The rack will become difficult to slide in
and out if it is self- cleaned. Remove all the

racks and the filter in the back of the oven
before self- cleaning..

6. To clean the rack, use hot, soapy water
and the rough side of a sponge.

Multiple Rack Baking Tips:

1. Typically, when baking on two racks, use
rack positions #2 and #4 or #3 and #5.

When baking on three racks, use rack

positions #!, #3 and #5.

2. When adapting a single rack recipe to
multiple rack baking, it may be necessary

to add to the baking time. This is due to the
extra mass of food in the oven.

/

rack /

Gfide chips /

/

Oven GlideRack TM

[ Using the Temperature Probe 11

For many foods, especially roasts and poultry,
internal food temperature is the best test for

properly cooked food. The Temperature Probe
takes the guesswork out of roasting by cooking

food to the exact temperature you desire.

_ NOTES:
Double Oven models have a Temperature in the

upper oven only.

Plug Probe

Temperature Probe

[_ IMPORTANT

1. Use of probes other than the one

provide with your wall oven may result
in damage to the probe and/or the wall

oven,

2. Use the handles of the Temperature

Probe and plug when inserting and

removing them from the food and outlet.

3. Do not use tongs to pull the cable

when removing the Probe. Do so could

damage the Probe.

4. Make sure the food is completely

defrosted before inserting the Probe to

avoid breaking the Probe.

5. Never leave the Temperature Probe
inside the oven during Self-Clean mode.

6. To prevent the possibility of burns,

unplug the Temperature Probe using hot

pads.

7. Do not store the Probe inside the oven.

Proper Temperature Probe Placement:

1. Lay the Probe on the outside of the meat
along the top or side and mark with your

finger where the edge of the meat comes
to on the Probe. The point should rest in

the center of the thickest meaty part of the
roast.

2. Insert the Probe to the point marked by
your finger into the meat. The Probe should

not touch the bone, fat, gristle or the
bottom of the pan.

• For roasts with no bone, insert the Probe
into the side of the roast in the center.

For bone-in ham or lamb, insert the
Probe into the center of the lowest large

muscle or joint.

• For dishes such as meat loaf or
casseroles, insert the Probe into the
center of the dish. When cooking fish,
insert the Probe from just above the gill

into the meatiest area, parallel to the
backbone.

• Insert the Probe into the meatiest part of
the inner thigh from below, and parallel

to the leg of a whole turkey.

Minimum Safe Internal Temperatures for Various Foods

Type & Cut Internal Temp. (F)

Pork, ham, sausage and bacon 180
All foods previously served and cooled that are reheated 165 within two hours
All poultry and game birds (turkey, chicken, cornish game hen, duck, etc.) 180

Stuffed meats 165

Stuffing 165

Ground beef and ground pork 165

Fish and most other potentially hazardous food not listed in this table 145

Beef roasts (rare) 145

Beef steaks (rare) 145

Minit_Turn Safe Internal Temperatures

Setting the Oven When Using the
Temperature Probe:

1. Preheat the oven to the desired
temperature. (Convection Roasting

Guide for Meats, Poultry and Fish)

2. Insert the Temperature Probe into the
food. (See Proper Temperature Probe

Placement above.)

3. After the oven cell has reached the desired
temperature, place the food into the oven.

4. Wearing an oven mitt, lift the probe outlet
cover and plug the Temperature Probe into

the outlet in the oven. (The outlet is located
on the left inside oven wail near the front

of the oven.) Make sure it is pushed all the
way into the outlet. Close the oven door.

5. r-----Q Press the "PROBE" button. The

Display will flash and beep "PRB" if
the Probe is not inserted properly.

6. Adjust the temperature to the desired
setting using the TIME.TEMPERATURE
buttons. A jump-in temperature of 160 ° will

appear when the TIME•TEMPERATURE
key is first pressed. To change to the

desired temperature, just press the
TIME.TEMPERATURE key until you reach
the desired temperature. The temperature

can be set from 100-200 °.

• After the temperature has been set,

the control panel temperature readout
will default to 95°F, even if the food

has not reached that temperature. The
temperature readout will increase in 1°F

increments until the food reaches the set
temperature.

7. The oven will go to the "HOLD" mode for 2
hours after the internal temperature of the

food has reached the desired temperature
and will hold the oven temperature at

150°F. The residual heat of the oven will

cause the internal temperature of the
food to continue to climb. Use hot pads

to remove the Temperature Probe from
the food. Do not use tongs to pull on the

Probe, it might be damaged.

_ NOTES:

After meat is pulled out of the oven, it will

continue to cook. Carry-over cooking affects

all foods. The larger the item, the longer
the carry-over. It is best to let the meat rest

after it comes out of the oven for 10 to 15
minutes. This will allow the meat to retain its

juices and continue to set, making it easier
to carve.

If the Probe is left inserted in the oven outlet

when not in use, the control will beep and
flash PRB until the Probe is unplugged.

Unplugging the Probe from the oven turns

the oven off.

I Timed/Delayed Timed Cooking

This function allows the user to finish and/
or start a cooking cycle automatically. It

is especially useful for preparing meals in
advance, or cooking while you are at work

or play. Timed Cooking can only be used
with Standard Bake, Pure Convections and
Convection Bake modes. It will not function in
the Broil modes.

350° r_7.1_!C

o_,._ _ . I_1

OVEr,, STOP TIM

Setting the Oven for Delayed Timed Cooking

_ NOTE:

For the double ovens, both the upper and
lower chambers can be set for Delay Timed
Cooking. However, both chambers must

have the same "COOK TIMES" and "STOP
TIMES".

[_ WARNING:
Food safety is an important consideration

when using delayed cooking modes. To
avoid potential sickness and spoiling of

food, take the following steps:

i

1. Avoid using foods that will spoil
while waiting for the cooking cycle

to begin. Typical foods to avoid
include those containing eggs and

dairy products, cream soups, and
cooked or uncooked meats, poultry

and fish stand in the oven for more
than two hours before cooking

begins.

2. If cooking will not begin
immediately, place only very cold

or frozen food into the oven. Most
unfrozen foods should never stand

in the oven for more than two
hours before cooking begins.

3. Do not allow foods to remain in
the oven more than one hour after

completion of the cooking cycle.
When the temperature drops below

140 °, bacteria can develop.

To use Timed Cooking, follow these steps:
(This mode will begin cooking immediately

and turn off at the desired time.)

1. Position oven rack(s) at the proper
height(s).

2. Place the food onto the center of the oven
rack(s).

3. Select the desired cooking mode and
temperature.

4. Press the "COOK TIME" pad and "TIME"
will appear in the clock display. Press the

"TIME,TEMP" "+" pad to set the length
of time that the food will be cooked. The

"COOK TIME" can be set from 5 minutes to

11 hours, 50 minutes.

5. After the "COOK TIME" has expired, the
clock will beep three times, and "Hold" will

be displayed. If cooking in a convection
mode, the convection fan will also turn

off at this time. While in "Hold" mode, the
oven temperature will be maintained at

150°F for a period of two hours. "Hold"

mode can be cancelled by pressing the
"CANCEL,SECURE" touch pad. The

cooling fan will continue to run depending
upon the length and temperature of the

cooking process.

To use Timed Cooking, follow these steps:
(This mode allows the cooking process to

start at a later time and finish at the desired
time.)

1. Follow steps ! thru 4 in the previous
instructions for Timed Cooking.

2. Press the "STOP TIME" touch pad, and
"STOP" will appear in the clock display.

Press the "TIME,TEMP" "+" pad to enter

the time of day that you wish the oven to
shut off. "DELAY" will now be displayed.

The oven will calculate the correct "START
TIME." After the "COOK TIME" has expired,

the clock will beep three times, and "Hold"
will be displayed. If cooking in a convection

mode, the convection fan will also turn

off at this time. While in "Hold" mode, the
oven temperature will be maintained at

150°F for a period of two hours. "Hold"
mode can be cancelled by pressing the

"CANCEL,SECURE" touch pad. The
cooling fan will continue to run depending

upon the length and temperature of the

cooking process.

DELAYED TIMED COOKING TIPS:

1. Do not use foods containing baking powder
or yeast in Delay Timed Cooking. These

foods will not rise properly.

2. Remember that "COOK TIME" refers to
the length of the cooking cycle. It does not

refer to the start time!

3. The time required to preheat the oven must
be included in the "COOK TIME." Thus,

the "COOK TIME" should be increased by
about 8 to 12 minutes depending upon the

temperature setting. The top element does
not come on to preheat in the Delay Mode,

so you will not pre-maturety brown foods.

iI Dehydratin g/Defrosting

The oven can be used to dehydrate or
defrost foods at low heat settings in "Pure
Convection TM''mode.

Follow these steps to dehydrate or defrost

foods:

1. Position oven rack(s) at the proper
height(s).

2. Place the food onto the center of the oven
rack. (For dehydrating, prepare food as

recommended then place food onto a
drying rack.)

3. Press the "PURE CONVECTION TM''pad.

4. Set the temperature to 135°F. This is the
minimum temperature that can be set. (For

dehydrating, a higher temperature setting
may be required. Follow the recommended

temperature for the type of food being
prepared.)

5. It is recommended that the user set the
Minute Timer(s) to time the process.

I Br°iling i

Broiling is a quick and flavorful way to prepare
many foods, including steaks, chicken, chops,

hamburgers and fish. Broiling in the oven is
completed with the oven door completely

shut, It is normal and necessary for some
smoke to be present to give the food a broiled

flavor. The broil temperature may be adjusted in

5°F increments from 135°F up to the maximum
setting of "HI". The "HI" setting is equivalent to

555°R

Snn0 '1-I. I-!1-!

ON ON

Clock Displaying Broil (double oven)

Follow these steps to operate the oven in
Standard Broil or Convection Broil modes:

1. Close the door tightly.

2. Press the "BROIL" or "CONVECTION
BROIL" pad.

3. Press the "TIME,TEMP" "+" or "-" pad and
the default temperature setting "H!" will be

displayed. "HI" is equivalent to 555°F.

4. If a temperature other than "HI" is desired,
press the "TIME,TEMP" "-" pad to reduce

the temperature. Six seconds after setting
the temperature, the "ON" indicator will
light up in the clock display, the broiler

element will begin heating, and the cooling
fan will turn on.

5. It is recommended that the user set
the Minute Timer(s) to time the broiling

process.

6. When the Minute Timer expires
and/or the food is cooked, press the

"CANCEL,SECURE" touch pad to turn off
the oven. The cooling fan will continue to
run for 30 to 45 minutes depending upon

the length and temperature of the broiling
process.

BROILING TIPS:

1. Always use a broiler pan and grill to
provide drainage for excess fat and grease.

This will reduce spatter, smoke and flare-
ups.

2. Pre-heat the broiler for 10 minutes prior to
cooking.

3. Begin with a room temperature broiler pan
for even cooking.

4. Use tongs or a spatula to turn and remove
meats. Never pierce meat with a fork as
this allows juices to escape.

5. Broil food on the first side for slightly more
than half of the recommended time, then

season and turn. Season the second side
just before removing.

6. To prevent sticking, lightly grease the
broiler grill. Excess grease will result in

heavy smoke. For easier cleaning, remove
the broiler pan and grill when the food is

removed. While the pan and grill are still
warm, soak the pan and grill in a solution

of hot water and dishwashing liquid, then
scrub them with an abrasive pad.

7. To prevent sticking, lightly grease the
broiler grill. Excess grease will result in
heavy smoke.

[_ WARNINGS:

1. To avoid electrical shock or burns, turn
off all controls and ensure the oven is

cool before cleaning.

2. Do not use harsh or abrasive cleaning
agents, waxes, polishes, or commercial

oven cleaners to clean the oven.

Read and follow the CARE AND CLEANING
INSTRUCTIONS to ensure that proper oven

operation and appearance will be maintained
throughout the lifetime of the product.
Several materials and finishes are used in
the oven. Each material and finish must be

properly cleaned according to the following
recommendations. Failure to follow these

recommendations may result in permanent

damage to the oven.

I[Control Panel i

To avoid accidentally turning the oven on while
cleaning the control panel, activate the "Secure"

feature. Press and hold the "CANCEL,SECURE"

pad for approximately three seconds. This will

disable the control panel and allow cleaning
the controls without accidentally starting any

functions. "OFF" will appear in the display when
the control panel has been secured.

Tore-activatethecontrolpanel,againpush
andholdthe"CANCEUSECURE"padforthree

seconds."OFF"willdisappearfromthedisplay.
Cleanthecontrolpanelwithasolutionofmild

detergentandwarmwater.DONOTUSE
ABRASIVECLEANERS OR SCRUBBERS.

THEY WILL PERMANENTLY DAMAGE THE
FINISH, Dry the control panel completely with a

soft, lint-free cloth.

I Door Handle & Control Housing I

Clean the door handle and control panel
housing with a solution of mild detergent and

hot water. Rinse and dry with a soft cloth.

DO NOT USE ABRASIVE CLEANERS OR
SCRUBBERS. THEY WILL PERMANENTLY
DAMAGE THE FINISH

JDoor Glass I

Clean all glass surfaces with a solution of mild
detergent and hot water. Use a mild glass

cleaner to remove fingerprints or smears. Dry
completely with a soft, lint-free cloth.

I Stainless Steel Surfaces I

On stainless steel ovens, the control panel,
door(s) and exhaust grill are covered with

stainless steel panels. Clean these surfaces with
a solution of mild detergent and warm water.

Rinse and dry with a soft, lint-free cloth.

If commercially available stainless steel
cleaners are used, it is important to read the

labels for chlorine compounds. Chlorine is a
corrosive substance. If these compounds are
present, rinse thoroughly and dry with a soft,

lint-free cloth.

Always wipe stainless steel surfaces with the
grain.

I Porcelain Surfaces

The oven interior and inner door liners are
finished in porcelain enamel. Clean these

surfaces with a solution of mild detergent and
hot water. Rinse and dry with a soft cloth.

Do not use abrasives or commercial oven
cleaners. Always remove excess grease and

soil from the oven interior and door prior to
using the Self-Cleaning cycle.

I

I Brass, Chrome & Copper SurfacesI

Clean these surfaces with a solution of mild
detergent and warm water. Rinse, dry and polish

with a soft, lint-free cloth.

If a commercially available polish is used,
it is important to read the label for chlorine

compounds. Chlorine is a corrosive substance
and is not recommended for use with brass,

copper or chrome finishes. If these compounds
are present, rinse surface thoroughly and dry

with a soft, lint-free cloth.

Follow manufacturer's instructions for
application of polish.

I Broiler Pan and Grill

The oven broiler pan and grill is finished in

porcelain enamel. Clean both components in a

solution of detergent and hot water. For heavy
soil conditions, use a scouring pad such as
steel wool with plenty of water. Rinse well after

cleaning

I Oven Racks i

Oven racks are chrome-plated For everyday
cleaning, apply a solution of detergent and hot

water. To clean heavy soil, use a scouring pad
such as steel wool with plenty of water, or use a

solution of 1 cup ammonia to 2 gallons of water.

Remove racks during Self-Cleaning If racks

are left in the oven during self-cleaning, they will

permanently discolor.

I Convection Fan Filter

_ WARNING:

Remove the filter only when it is cool.

i ILse"C'ean'ng 1

The electric door latch is a convenient safety

feature. The door latch is automatically activated

after selecting the Self-Clean mode. The latch
ensures that the oven door cannot be opened

while the interior oven temperatures are unsafe

to the user.

The convection fan filter is made of stainless
steel. Remove the filter regularly for cleaning,

as a clogged filter will reduce the effectiveness
of convection cooking modes. Soak the filter

in hot soapy water. Dry the filter completely
before re-installing Remove the filter during

Self-Cleaning. If the filter is left in the oven
during Self-Cleaning it will permanently discolor.

Re-install the filter before cooking in the

oven again. Failure to do so will expose the
convection fan blade that rotates at high

speed during convection modes.

Step 1: Orient the filter so that the two

mounting tabs are towards the rear, open

end down.

Removing and Installing the Convection Fan Filter

Step r

Step 2: Hook the two mounting tabs over the
center horizontal bar.

Removing and Installing the Convection Fan Filter

Step 2

i

The oven features an automatic pyrolytic
Self-Cleaning cycle to eliminate the need for

difficult and time-consuming manual scrubbing
of interior surfaces. During this cycle, the oven
reaches temperatures of 850°F to burn off soil

and deposits. A powder ash residue is left in the
bottom of the oven after completion of the Self-

Clean cycle.
The Self-Clean time is variable from 2 to 4

hours to offer flexibility in handling various soil
conditions. A 2-hour cycle normally handles a

moderately soiled oven, whereas a 4-hour cycle
is recommended for a heavily soiled condition.

The Self-Clean cycle can also be delayed to
start at a later time if desired.

_ IMPORTANT:

1. It is normal for some smoke to be
emitted during the first few Self-Clean

cycles.

2. Popping sounds are normal during Self-
Clean cycles. These sounds are caused

by the expansion and contraction of
metal surfaces during heat-up and cool-

down.

3. Do not line the oven with aluminum
foil or other materials. These items can

melt or burn during a Self-Clean cycle,
causing permanent damage to the oven.

_ WARNINGS:

1. DO NOT OPERATE THE OVEN LIGHTS
IN THE SELF-CLEAN MODE.

2. Do not touch the outside surfaces of the
oven during the Self-Clean cycle

3. Do not use commercial oven cleaners
inside the oven. Use of these cleaners

can produce hazardous fumes or can
permanently damage the porcelain

finishes.

Prepare the oven for Self-Cleaning by

following these steps:

1. Clean soil from the oven front frame area
and the oven door outside of the door

gasket. Do not clean the door gasket.
Cleaning the door gasket by hand can
cause it to bend or move. A tight door

seal is essential for proper baking and
Self-Cleaning Rinse surfaces well with a

solution of vinegar and water, then wipe
dry. Heavily soiled areas may be cleaned

with a non-scratching scouring pad.

2. Removethebroilerpanandgrill,all
cookware,utensilsandotherlooseitems
fromtheovenchamber.Also,removeall
ovenracksandtheconvectionfanfilterto

preventthemfrompermanentlydiscoloring.
However,tocleanstubbornparticlesinthe

convectionfilteryoumayelecttosimply

leaveitinplaceduringself-clean.Thefilter

willdiscolorduetothehighheat,butthis
willnotharmthefilteringcapabilities

3. Wipeupexcessgreaseandotherfood
spillswithadampcloth.Thiswillminimize

smokeandincreasetheefficiencyofthe
Self-Cleancycle.

4. Turnonkitchenfansorventstohelp

removeodorsduringtheSelf-Cleancycle.

[_ IMPORTANT:

If racks are left in the oven during a Self-
Clean cycle, it will affect their ability to slide

in and out easily. Polish the rack edges with
a soapy steel wool pad, then apply a small
amount of vegetable oil to the edges so that

the racks will slide more easily.

Follow these steps to Self-Clean the oven:
1 Complete all steps listed above for

preparing the oven for Self-Cleaning.

2 Close the oven door completely
3 Press the "SELF-CLEAN" touch pad The

oven will beep once, "CLEAN" will flash,
and "- -:--" will be displayed.

4. Press the "TIME,TEMP" "+" pad and
the default time of "2:00" hours will be

displayed.

5. Increase the self-clean time up to 4 hours

(depending upon the amount of oven soil)
by holding the "TIME,TEMP" "+" pad.

6. To delay the self-clean start to a more
convenient time, press the "STOP TIME"

touch pad. Then, press the "TIME,TEMP"
"+" pad to set the time of day for the

cycle to be complete. "DELAY TIMED" will
appear in the clock display. The cycle can

be delayed up to 11 hours and 50 minutes.

7. Approximately 30 to 60 seconds after
selecting Self-Clean, the automatic door

latch will lock the door. "LOCK" and "ON"

will appear in the clock display. The oven
will begin heating. The "ON" indicator will

cycle on and off with the burner.

_ NOTE:

If Delay Timed mode has been set, the "ON"
display and the oven heat will not turn

on until the programmed time has been
reached.

[_ IMPORTANT:

If the door is not closed completely, the
automatic door latch will not be able to

lock the door when the Self-Clean mode
is selected. In this case, "door" will flash
in the clock display. If this occurs, press
the "CANCEL.SECURE" pad and wait

approximately 1 minute. Repeat the Self-
Clean steps from the beginning, being
certain to close the door completely. Do

not try to force the door open after it is
locked, as the automatic latch can be

damaged. If you need to unlock the door,
turn off the Self-Clean cycle by pressing the
"CANCEL.SECURE" pad. After approximately

1 minute, "LOCK" will disappear from the
clock display, and the door will unlock.

The door will remain locked until the oven

temperature falls below 390°F, Do not select
any cooking function until the oven door is

unlocked,

8. About 50 to 60 minutes will be required
for the oven to reach the Self-Clean

temperature of 850°F.

9. The Self-Clean cycle can be stopped at

any time by pressing "CANCEL,SECURE"

10. After completion of the Self-Clean cycle,

the oven will stop heating and the "ON"
and "CLEAN" indicators will disappear

from the clock display. Press the

"CANCEL,SECURE" pad.

11. After the interior oven temperature falls

below 390°F, the door latch will release
and "LOCK" will disappear from the clock

display. The door can now be opened.

12. Open the door. After ensuring that the

oven has cooled sufficiently to be safe, use
a damp cloth or sponge to wipe out the
powder residue found in the bottom of the

oven. If white spots remain in the oven,
remove them with a non-scratch scouring
pad before using the oven again. These

spots are normally salt that cannot be
removed by a Self-Clean cycle.

13. Re-install the oven racks and convection
fan filter before cooking in the oven.

.I--IN
.UU

CLEAN LOCK ON CLEAN TIME

Clock Display in Self-Cleaning Mode

_ IMPORTANT:

With the oven at room temperature, if the
Self-Clean mode is accidentally selected and

the oven enters Self-Clean mode (indicated
by "LOCK" and "ON" in the clock display),

the user must cancel out of this mode before
attempting to select a different mode. To

cancel, press the "CANCEL.SECURE" pad.
Wait at least 60 seconds before attempting to
select another mode. This allows the door
latch time to unlock.

SELF-CLEANING TIPS:
1 If any soil remains in the oven after

completion of a Self-Cleaning cycle, repeat
the cycle if desired. Increase the cleaning

time during future cycles.

2. Clean the oven regularly to prevent

excessive soil build-up. This will increase
the efficiency of the Self-Clean cycle and

reduce the amount of smoke and odors
generated.

3. Self-Clean in the cooler evening hours after
cooking is complete and when electricity

rates are lower.

4. In the double oven, if one oven is in
the Self-Clean mode the other oven is

inoperable.

IIAdjusting the Oven Temperature i

_ IMPORTANT:

The user may find the temperature in their

new oven to be different from that of their
previously-owned appliance. Familiarity

with the old appliance sometimes makes it
difficult to get used to a new oven. If you feel

that the oven temperature is consistently

high or low, the temperature of the new oven
can be adjusted. The adjustment needs to be
done only once.

The oven temperature may be adjusted
(calibrated) by following these steps:

1. Press "BAKE" selector pad

2. Press the "TIME.TEMP" "+" pad to set a

temperature of 500°F or higher.

3. Press and hold the "BAKE" selector

pad. After approximately 5 seconds the
temperature display is replaced by "00".
The "BAKE" pad can now be released. The

calibration mode has been accessed.

4. Press the "TIME.TEMP" "+" or "-" pad to
set the amount of temperature adjustment.

The temperature can be changed a

maximum of 35°F higher or lower. Set

the adjustment to positive (+) numbers
to increase the oven temperature; set

the adjustment to negative (-) numbers
to reduce the oven temperature.

Temperatures can be adjusted in

increments of 5°F.

5. After setting the desired temperature
adjustment, press the "CANCEL.SECURE"

pad to exit the calibration mode and to
reset the clock display.

2, .NN

.UU

CLEANt_K ON CLEAN TIME

oLoo.IIs.o..o0II- q

Clock Display When Adjusting (Calibrating) the Oven

Temperature

_ NOTES:

1. If "CANCEL,SECURE" is not pressed
after setting the adjustment, the clock

display will automatically reset in 6

seconds.

2. The amount of temperature adjustment
may be changed again by repeating

the calibration procedure. The oven
will only retain the amount of the most

recent temperature adjustment.

3. The temperature adjustment is not
affected by an electrical power failure

4. The temperature adjustment only
affects Standard Bake and Convection

Bake modes, Broil and Self-Clean

temperatures cannot be adjusted.

Replacing the Oven Light(s) I 1.

The light assembly consists of a removable lens 2.
cover and 10-watt 120VAC halogen bulb, as well

as a light fixture housing. Light bulb replacement
is considered to be a homeowner maintenance

operation.

_ WARNINGS:

To prevent electrical shock and/or personal
injury:

1. Make certain that the appliance and
light bulb are cool and that power to the

appliance has been turned off before
replacing the light bulb.

2. Always ensure that the lens cover is
in place when using the appliance.

The lens cover protects the bulb from
breakage caused by high temperatures

or mechanical shock.

To replace a light bulb, follow these steps:

Turn off the power at the main power
supply.

Remove the lens cover from the housing

by pulling straight out.

_Lens Cover

Oven Light Assembly

Troubleshooting I

NOTE:

In some cases the lens cover may be tight
enough to require the use of your light lens

pry stick. This prying tool should be used

with caution. Do not cause uneven stress on
the lens cover. Gently insert the point end

of the pry stick under the center edge of the
lens cover on the side facing the oven door.

Hold your hand under the lens for support

then pry out to remove the lens cover.

3. Pull the light bulb out and replace it with a
specia! !0-watt halogen bulb rated for use

in a Self-Cleaning oven. Use DACOR Part
No. 86364 available from any authorized
DACOR parts distributor or dealer.

4. Reinstall the lens cover by aligning the
cover over the opening and gently pressing

it into its original position.

5. Turn the power back on at the main power
supply.

Unnecessary service calls may be expensive, frustrating and time-consuming. Before you call for service, please review the potential problems, possible
causes and remedies shown below. Also, refer to the table on page !1 to view various oven failure codes that can be displayed by the clock. Failure

Codes will appear where the temperature is normally displayed.

IMPORTANT:

If a Failure Code is displayed, the oven will beep continuously until the user presses the "CANCEL,SECURE" button. The oven will not heat
after a failure. Call a qualified appliance technician to repair the oven.

Problem

1. Nothing works

Possible Cause

Oven is not connected to electrical power

Remedy

Have oven connected to a properly sized
electrical power supply by a qualified

electrician.

Power supply is not energized. Have an electrician check power supply,

including the house circuit breaker, wiring and
fuses

2. Oven wiii not heat..

Time of day is not set. Press "CLOCK" touch pad, then press

"TIME.TEMP" pad to set correct time of day.

Oven settings are not correct Follow mode selection and clock settings as

specified in OVEN OPERATION section.

Oven is set for Delay Timed Cooking. Oven will turn on automatically at preset time. I1

desired, press "CANCEL.SECURE" touch pad
to cancel out of Delay Timed Cooking.

Change rack position.

3. Clock displays incorrect time of day. Time of day is not set. Press "CLOCK" touch pad, then press
"TIME.TEMP" pad to set correct time of day.

Power supply has been interrupted. Reset time of day.

4. Foods over-cook.

Incorrect cooking time, temperature, or rack
position being used.

Adjust time or temperature.

Oven temperature calibration differs from your

previous oven.

Adjust oven temperature as per ADJUSTING
THE OVEN TEMPERATURE section.

5. Foods under-cook.

Incorrect cooking time, temperature, or rack
position being used.

Adjust time or temperature.

Oven temperature calibration differs from your

previous oven.

Adjust oven temperature as per ADJUSTING
THE OVEN TEMPERATURE section.

6. Oven does not Self-Clean.

Door is not shut tight, so automatic door latch

will not lock.

Close door tightly.

Troubleshooting Guide

10

Oven settings are not correct. Follow mode selection and clock settings as

specified in the SELF-CLEANING section.

Oven is set for Delay Timed Cleaning. Oven will turn on automatically at preset time. If

desired, press "CANCEL.SECURE" touch pad
to cancel out Delay Timed Cleaning.

7. Oven light will not work.

8. Door will not open.

Light bulb is burned out

Oven is in Self-Clean mode.

Follow REPLACING THE OVEN LIGHT section

If oven is hot, door latch wilI release
automatically when oven temperature falls betov
390°F at end of cycle.

9. Oven will not heat after Self Cleaning.
Time of day is not set due to power failure.

If Self-Clean was just selected and the oven

is still cool, press "CANCEL.SECURE" to turn
off Self-Clean. The door will open in about 30
seconds.

Press "CLOCK" touch pad, then press
"TIME.TEMP" pad to set correct time of day.

Oven settings are not correct. Follow mode selection and clock settings as

specified in the OVEN OPERATION section.

Troubleshooting Guide (Continued)

Oven will turn on automatically at preset time. If
desired, press "CANCEL.SECURE" touch pad

to cancel out of Delay Timed mode.

Clock Display Cause

F0. Touch pad is stuck in depressed position.
F1. Relay circuit failure.
F2. Oven temperature exceeded the clean runaway temperature (Self-Clean mode

only) or the cooking runaway temperature (cooking modes only).
F3. Short circuit in the oven temperature sensor.
F4. Open circuit in the oven temperature sensor.
F6. Failure in the EEPROM check comparison. (Only time of day and timer will

operate.)
F7 Failure of the Self-Clean automatic door latch circuit.

F8. Failure of the door latch motor. Occurs when the motor runs for two minutes

without the door locking in Self-Clean mode.

Oven Failure Codes

11

I Product Maintenance

No maintenance, other than the CARE AND
CLEANING INSTRUCTIONS identified in this

Use & Care Manual, should be attempted
by the owner/operator. All other maintenance

and service must be performed by a qualified
appliance technician.

I If You Need Service...

First, review the recommended checks listed in
the preceding Troubleshooting Guide. Then,

be certain that the appliance has been installed
properly and is being operated correctly.

Familiarize yourself with the warranty terms and
conditions listed in the PRODUCT WARRANTY

section.

I I What is Covered

CERTIFICATE OF WARRANTIES

DACOR WALL OVENS

If the above checks have been completed
and the problem has not yet been remedied,

call your local authorized DACOR service
representative. Your dealer can normally provide

the name and telephone number of the nearest
service company.

DACOR works diligently to ensure your
satisfaction when service is necessary.

However, if you are not completely satisfied with
the service provided, contact the company that

performed the service and express why you are
not pleased. Normally, they will be willing and
abte to resolve the problem.

If the service agency is not able to respond
effectively, call or write the DACOR Customer

Service Department. The phone number and
address of this department are listed on the

inside front cover of this manual. Please include
your telephone number if you choose to write.

We will then do our utmost to assure your
happiness and satisfaction.

I

I Accessories I

For accessories call your local Dacor dealer.

Accessory Cookiesheets (3 in a carton): These
Full sized cookie sheets maximunize oven rack

baking capabilities by utilizing the total useable
rack space

• 27" Oven Model No. ACS273

• 30" Oven Model No. ACS303

• 36" Oven Model No. ACS363

Replacement Oven Light Bulb

• lOW Halogen Part No. 86364

Stainless Steel Cleaner

• Elco Cleaner Part No A302

WITHIN THE FIFTY STATES OF THE

U.S.A., THE DISTRICT OF COLUMBIA

AND CANADA*:

FULL ONE YEAR WARRANTY
If your DACOR product fails to function within

one year of the original date of purchase, due
to a defect in material or workmanship, DACOR
will remedy the defect without charge to you

or subsequent users. The owner must provide

proof of purchase upon request and have the

appliance accessible for service.

* Warranty is null and void if non-CSA approved

product is transported from the U.S.

OUTSIDE THE FIFTY STATES OF THE

U.S.A., THE DISTRICT OF COLUMBIA

AND CANADA:

LIMITED FIRST YEAR WARRANTY
If your DACOR product fails to function within

one year of the original date of purchase, due
to a defect in material or workmanship, DACOR

will furnish a new part, F.O.B. factory, to replace
the defective part. All delivery, installation

and labor costs are the responsibility of the

purchaser. The owner must provide proof of
purchase upon request and have the appliance

accessible for service.

i

l What is Not Covered

Failure of the product caused by faulty

installation, improper usage, or neglect of
required maintenance.

Service calls to educate the customer in
the proper use and care of the product.

Failure of the product when used for

commercial, business, rental or any
application other than for residential

consumer use.

Replacement of house fuses or fuse boxes,

or resetting of circuit breakers.

Damage to the product caused by accident,

fire, flood or other acts of God.

Breakage, discoloration or damage to

glass, metal surfaces, plastic components,
trim, paint, porcelain or other cosmetic
finish, caused by improper usage or care,

abuse, or neglect.

THE REMEDIES PROVIDED FOR THE ABOVE
EXPRESS WARRANTIES ARE THE SOLE

AND EXCLUSIVE REMEDIES. THEREFORE,

NO OTHER EXPRESS WARRANTIES ARE
MADE, AND OUTSIDE THE FIFTY STATES

OF THE UNITED STATES AND THE DISTRICT
OF COLUMBIA, ALL IMPLIED WARRANTIES,

INCLUDING BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR USE OR

PURPOSE ARE LIMITED IN DURATION TO
ONE YEAR FROM THE DATE OF ORIGINAL

PURCHASE. IN NO EVENT SHALL DACOR
BE LIABLE FOR INCIDENTAL EXPENSE
OR CONSEQUENTIAL DAMAGES. NO

WARRANTIES, EXPRESSED OR IMPLIED,
ARE MADE TO ANY BUYER FOR RESALE.

Some states do not allow limitations on how
long an implied warranty lasts or do not allow

the exclusion or limitation of incidental or
consequential damages, so the above limitations

or exclusions may not apply to you. This

warranty gives you specific legal rights, and you

may also have other rights that vary from state
to state.

12

fold here

IIl1

NO POSTAGE

NECESSARY

IF MAILED

IN THE

UNITED STATES

IFB_US_/NESSM,REoPLYDMoA!RLcAI

POSTAGEWILL BE PAIDBYADDRESSEE

ATTN: WARRANTY PROCESSING DEPT

DACOR
1440 BRIDGEGATE DR STE 200

PO BOX 6532
DIAMOND BAR CA 91765-9861

I1,1,,,,,111,,,I,I1,,,I,1,1,1,,I,,I,,11,,,,,111,,I,I

Pleasevisitwww.dacor.comto activateyourwarrantyonline.

WARRANTYINFORMATION

IMPORTANT:

Yourwarrantyfor this productCANNOTBEACTIVATEDuntilthisformhasbeenreturnedto Dacor,Ifyou have

purchasedmorethanoneDacorproduct,Pleasereturnallforms inoneenvelope,

Pleaserestassuredthatundernoconditionswill Dacorsellyournameoranyd the informationonthisformformailinglist purposes.We
are verygratefulthatyouhavechosenDacorproductsforyourhomeanddo notconsiderthesaleof suchinformationtobea properway
ofexpressingourgratitude!

(Phase Print or Type)

Owner'sName:

Last First Middb

Street:
City: State: Zip:

PurchaseDate: Email: Telephone:

Dealer:
City: State: Zip:

Yourwillingnessto takeafewsecondstofillin thesectionbelowwillbesincerelyappreciated.Thankyou.

1.Howwereyoufirst exposedto Dacorproducts?(Pleasecheckoneonly.)
[] A. T.V.CookingShow [] F Builder
[] B. Magazine [] G. Architect/Designer
[] C. ApplianceDealerShowroom [] H. AnotherDacorOwner

[] D. KitchenDealerShowroom [] I. ModelHome
[] E. HomeShow [] J. Other

2.Wheredidyoubuyyour Dacorappliances?
[] A. ApplianceDealer [] D. Builder

[] B. KitchenDealer [] E. Other
[] C. BuilderSupplier

3. For what purpose was the product purchased?
[] A. Replacementon/y [] C. New Home

[] B. Part of a Remodeled [] D. Other

4.Whatis yourhouseholdincome?
[] A. Under$75,000 [] D. $150,000-$200,000
[] B. $75,000-$100,000 [] E. $200,000-$250,000
[] C. $100,000-$150,000 [] F. Over$250,O00

5.Whatotherbrandsofappliancesdoyouhaveinyourkitchen?

A. Cooktop C. Dishwasher

B.Oven D.Refrigerator

6.Wouldyoubuyor recommendanotherDacorproduct?
[] Yes

Comments:

[] No

Thankyouverymuchforyourassistance.Theinformationyouhaveprovidedwillbeextremelyvaluableinhelpingusplanforthefuture
andgivingyouthesupportyoudeserve.

Web Site: www.dacor.com
For a DeaIer/Service: [phone]
Corporate Phone: [phone]

®

PlaceSerialNumberLabelHere

I
I
I
I
I
I
I
I
I
I
I
I

°I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I

*d

°I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
