Dacor IF48BNDB, EF48BDCB, EF42BNDB, EF48BNDB, IF42BNDB User Manual

EF42BDCB, EF42BNDB, IF42BDCB, IF42BNDB, EF48BDCB, EF48BNDB, IF48BDCB, IF48BNDB





42” & 48” Wide



PLANNING



112905

Built-In Refrigerator

1/3

GUIDE











Product Dimensions

The depth from the front of the top grill (w/o decorator panel) to the back of the refrigerator chassis is 25 1/4” (641mm).

The depth from the rear of the top grill to the back of the refrigerator chassis is 23 13/16” (605mm).

The power cord is 40” (1016mm) long.

The height from the top of the top grill to floor with the leveling legs in the down position is 83 3/8” (2118mm)

The height from the top of the top grill to floor with the leveling legs in the fully extended position is 84 5/8” (2149mm)

The chassis width from the chassis edge to the chassis edge for 42-inch is model 41 1/4” (1048mm), 48-inch is model 47 1/4” (1200mm).

The overall width from the trim edge to the trim edge for 42inch model is 42 1/16” (1068mm), 48-inch model is 48 1/16” (1221mm).

Door Swing Dimensions

The area to the left and the right of the appliance must permit both doors to open to a minimum of 90°. Allow a minimum of 2 1/2” (64mm) space between the side of the refrigerator doors and a corner wall.

NOTE: More clearance may be required if using an overlay panel or custom handles.

Water Supply Requirements

All installations must meet local plumbing code requirements.

Connect to 1/4” (6mm) copper line to the house cold fresh water supply.

Use a shut off valve between the refrigerator and supply. The shut off valve should be a drilled saddle valve.

Do not use a self-tapping valve which reduces water flow and clogs more easily.

Route the water line within 3-1/2” (89mm) of the rear wall and no higher than 3” (76mm) from the floor.

Allow a minimum of 24” (610mm) dimeter service loop of copper tubing outside the wall or floor for easy connection to the water supply.

Cold water supply

Connect the ice maker to a cold water line with water pressure between 30 and 120 PSI. If you have any questions about your water pressure, call your utility company.

IMPORTANT:

In homes with a Reverse Osmosis water treatment system, remove the water inlet connector from the “yellow” valve and attached to the “blue” valve. Make sure the water filter bypass plug is in place.

Web: http://www.Dacor.com

Corporate Phone: 800-793-0093

“A”





2”





Electrical



7”







4”

83 3/4”







75 1/2”



6”





Water Supply

3”

24”

Model

Rough-In Width “A”

42-Inch

41 1/2”” (1054mm)

48-Inch

47 1/2”” (1207mm)

Electrical Requirements

A 115VAC, 60 Hz, 15 Amp circuit breaker and electrical supply are required. A separate dedicated non-GFCI circuit, servicing only this appliance, is required.

Your Dacor® Built-In refrigerator is equipped with a 40” (1016mm) 3-prong grounded power cord, which must be plugged into a 3-prong grounding-type non-GFCI wall receptacle. Follow the National Electrical Code and local codes and ordinances when installing the receptacle. See “Rough-In Dimensions” for location of the electrical supply.

IMPORTANT: A ground fault circuit interrupter (GFCI) is not recommended and may cause interruption of operation.

Specifications are subject to change without notice.

11.2

See installation instructions for additional details.
