Dual Zone Wine Cellar
Use, Care and Installation Manual
Models: RNF242WCL, RNF242WCR
Part No. 107940 Rev. D
Table of Contents
Important Safety Instructions ................................................ 1
Getting to Know Your Wine Cellar .......................................3
Operating Your Wine Cellar ................................................3
Care and Cleaning ............................................................ 6
Specifications and Installation .............................................. 7
Before You Call for Service .................................................. 8
Warranty ........................................................................ 10
Warranty Card .................................................... Back Cover
© 2014 Dacor, all rights reserved
Important Safety Instructions
INSTALLER: Leave these instructions with the appliance.
CUSTOMER: Read this use and care manual completely before
using your appliance. Save it for future reference. It contains
important use and care information. Retain your sales receipt or
canceled check. Proof of original purchase date is required for
warranty service.
For warranty and service information, see page 10.
If you have any questions, call:
Dacor Customer Service
(800) 793-0093 (U.S.A. and Canada)
Monday — Friday 6:00
Web site: www.dacor.com
Have the complete model and serial number identification of
your appliance ready. These numbers are found on the serial
number label located inside the door, at the back bottom of the
refrigeration compartment. Record these numbers below for
easy access.
Model number _______________________________________
Serial number _______________________________________
Date of purchase _____________________________________
Since we continually improve the quality and performance of
our products, we may make changes to the appliance without
updating this manual. Visit www.dacor.com to download the
latest version of this manual.
a.m. to 5:00 p.m. Pacific Time
About Safety Instructions
The Important Safety Instructions and warnings in this
manual are not meant to cover all possible problems and
situations that can occur. Use common sense and caution when
installing, maintaining or operating this or any other appliance.
Always contact the Dacor Customer Service Team about
problems or situations that you do not understand.
DANGER
IMPORTANT: To prevent child entrapment and suffocation
when discarding an old appliance:
• Take off the door(s).
• Leave the racks in place so children cannot easily climb
inside.
• Cut the prongs off the power plug and discard them.
• Cut the power cable off and discard it separately from the
old appliance.
IMPORTANT: To avoid the possibility of explosion or fire, do
not store or use combustible, flammable or explosive vapors
and liquids (such as gasoline) inside or in the vicinity of this
or any other appliance.
WARNING
IMPORTANT: This appliance is equipped with a three
prong grounding electric plug for protection against possible
electric shock hazards. It must be plugged into a dedicated,
grounded, electrical outlet. If only a two prong electrical outlet
is available, it is the responsibility of the customer to have
it replaced with a dedicated, properly grounded three prong
electrical outlet.
• DO NOT cut or remove the third (ground) prong from the
power cord.
• DO NOT use an adapter plug.
• DO NOT use a power cord that is frayed or damaged.
• DO NOT connect the appliance to an extension cord.
• Keep the power cord away from heated surfaces.
NOTE: Use of an electrical outlet with a ground fault
interrupter (GFI) is not recommended.
Safety Symbols and Labels
DANGER
DANGER – Immediate hazards that WILL result in severe
personal injury or death.
WARNING
WARNING – Hazards or unsafe practices that COULD result
in severe personal injury or death.
CAUTION
CAUTION – Hazards or unsafe practices that COULD result
in minor personal injury or property damage.
Power cord with three
prong grounding plug
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals
known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals
known to the State of California to cause birth defects or
other reproductive harm.
Grounded type
electrical outlet
READ AND SAVE THESE INSTRUCTIONS
1
Important Safety Instructions
General Safety Precautions
To reduce the risk of fire, electric shock, serious injury or death when installing and using your appliance, follow basic safety
precautions, including the following:
WARNING
• If you receive a damaged product, immediately contact
your dealer or builder. Do not install or use a damaged
appliance.
• Make sure that this appliance has been properly installed
according to the installation section. Make sure you know
the location of the electrical outlet so that you know where
and how to disconnect power. Making sure the appliance
is properly installed is the responsibility of the customer.
• This appliance is not designed for installation in a
recreational vehicle or boat.
• To prevent personal injury, property damage or damage to
the unit, this appliance should only be unpacked and set
up by two people according to the installation section.
• Refrigeration equipment must be properly disposed of in
a professional and appropriate way, in accordance with
the current local regulations and laws which protects the
environment. This applies to your old appliance and to
your new unit once it has reached the end of its service
life. DO NOT dispose of the appliance in a landfill as the
insulation (Cyclopentane) and refrigerant gas (R600a)
contained in these appliances are flammable.
• Do not install or use outdoors or in wet conditions.
• Do not place another appliance on top of the appliance.
• Keep packaging materials away from children. Plastic
sheets and bags can cause suffocation.
• Connect this appliance to a 115 Vac, 15 Amp. circuit that
is controlled by a circuit breaker or fuse. This appliance
should have its own separate grounded circuit.
• Do not kink or pinch the power supply cord of the
appliance. Never unplug the appliance by pulling on the
power cord. Always grip the plug firmly and pull straight
out from the electrical outlet.
• To avoid and electric shock hazard, do not operate this
appliance with wet hands, or while standing in water or on
a wet surface.
• Disconnect this appliance when not in use.
• Do not install, repair or replace any part of the appliance
unless specifically recommended in the literature
accompanying it. A qualified service technician should
perform all other service.
• Before performing any type of service, disconnect the unit
from the electrical outlet.
• Use this appliance only for its intended purpose, the
storage of wine and beverage products. Do not use it to
store perishable food, medicine or other medical products.
It is not intended for commercial or industrial use.
• Never allow children to operate, play with or crawl inside
the appliance.
• Never allow anyone, including children to sit, stand or
climb on any part of the appliance, including the door.
Doing so may cause damage, serious injury or death.
• If the power cord is damaged, it must be replaced by the
manufacturer or a qualified service technician in order to
avoid a safety hazard.
WARNING
• Do not tamper with the controls.
• This appliance is CFC and HFC free and contains small
quantities of Isobutane (R600a) which is environmentally
friendly, but flammable. Care must be taken during
transportation and setting up of the appliance so that no
parts of the cooling system are damaged. Leaking coolant
can ignite and may damage the eyes. In the event of any
damage:
- Avoid open flames and anything which creates a spark.
- Disconnect the power cord from the electrical outlet.
- Air the room in which the appliance is located for several
minutes and contact Dacor Customer Service for advice.
• The more coolant there is in an appliance, the larger the
room it should be installed in. In the event of a leakage,
if the appliance is in a small room, there is the danger
of combustible gases building up. For every ounce of
coolant, at least 325 cubic feet of room space is required.
The amount of coolant in the appliance is stated on the
data label inside the door. It is hazardous for anyone
other than factory authorized service personnel to carry
out service or repairs on this appliance.
• All service and replacement of component parts shall be
performed by factory authorized service personnel, so as
to minimize the risk of possible ignition due to incorrect
parts or improper service.
• Take care when handling, moving and using the appliance
to avoid either damaging the refrigerant tubing or
increasing the risk of a leak.
• Keep fingers out of the “pinch point” areas. Clearances
between the doors and between the doors and cabinet
are necessarily small. Be careful closing doors when
children are in the area.
• Do not cover shelves with aluminum foil or any other shelf
material which may prevent air circulation.
CAUTION
• In the event of a power outage, minimize opening the
door.
• Do not allow the ventilation grill below the door to become
obstructed. Make sure there is always good ventilation in
front of the appliance.
2
Getting to Know Your Wine Cellar
Features
The right environment for your wines...
A vine is an extremely sensitive plant. Grape quality is
dependent on three factors: light, air humidity and ambient
temperature. This sensitivity continues even after the wine is
bottled. To allow a wine’s flavor to fully develop and to preserve
the excellent aroma, it has to be properly stored. Your wine
cellar offers the best storage environment:
A wide temperature range: The unit has two separate
cooling compartments, or zones. Each zone has a wide
temperature adjustment range. You can set one zone to
store wine at low temperature for superb aging and set the
other to a higher temperature for serving wine lightly chilled.
High storage capacity: High storage capacity allows you
to preserve the flavor of your favorite wines. Your wine
cellar can store up to 46 bottles of wine (750 mL each). The
capacity of the upper zone is 16 bottles. The lower zone can
hold up to 30 bottles.
Low Vibration Cooling System and Storage: Wines
require a tranquil environment. The latest technology of your
wine cellar provides virtually vibration free cooling, helping
to preserve wine taste. In addition, the sliding beech wood
storage shelves also provide additional vibration absorption.
Additional Features
• Automatic defrosting system
• Soft white LED interior lighting with on/off switch
• Open-door and malfunction warning system
• Double-layer, UV resistant, tempered glass door, shields
wines from UV rays harmful to wine.
• Door lock
Model RNF242WCL: Hinges on left, handle on right
Model RNF242WCR: Hinges on right, handle on left
Racks/Shelves (see diagram above)
Wood slide-out racks, upper zone: Hold up to eight bottles of
wine each.
Wood slide-out racks, lower zone: Hold up to eight bottles of
wine each.
Bottom shelf (lower zone): Holds up to six bottles of wine.
Door Lock
To lock the door:
1. With the door closed, insert the key into the lock.
2. Push in and turn the key 90° clockwise to lock.
3. Remove the key.
To unlock the door:
1. Insert the key into the lock.
2. Push in and turn the key 90° counterclockwise to unlock.
To unlockTo lock
3
Loading...
