Cybex TWINYX User manual
1
twinYx
ENUSER GUIDE | MYPANDUAN PENGGUNA
ENMY
2
3
5 | CONTENT
23 | KANDUNGAN
ENMY
4
ATTENTION: Read these instructions carefully
before use and keep them for future reference. Your
child‘s safety may be affected if you do not follow
these instructions.
5
DEAR CUSTOMER
Thank you very much for purchasing the CYBEX TWINYX. This product is a stroller
for children suitable from birth and up to 2x15 kg. It is suitable for a maximum of two
childs only. The stroller is equipped with a canopy – all features are explained in the
instructions. In developing the CYBEX TWINYX we can assure you that our main focus
was both safety, comfort and easy operation.
The product has been developed under strict quality control and meets all relevant
safety standards. Should you have any questions, please feel free to contact us at any
time.
I. GENERAL INFORMATION & SAFETY ...................................................................6
II. INSTRUCTIONS FOR MAINTENANCE AND SERVICE .................................. 7
III. INSTRUCTIONS FOR USE ....................................................................................... 10
1. Opening the stroller ready for assembly ...................................................................... 10
2. Assembling the handles ...................................................................................................11
3. Assembling the front wheels ...........................................................................................11
4. Assembling the rear wheels ............................................................................................11
5. Folding the stroller ............................................................................................................ 12
6. Opening the stroller ......................................................................................................... 13
7. Using the brakes ............................................................................................................... 13
8. Automatic front wheels swivel locks ............................................................................. 14
9. Extendable Canopy .......................................................................................................... 14
10. Using the harness system ............................................................................................... 15
11. Adjusting the harness system for newborns ............................................................... 16
12. Removing the seatcover ...................................................................................................17
13. Reclining the leg rest ....................................................................................................... 18
14. Reclining the seat ............................................................................................................. 18
15. Attaching The Bumper Bar ............................................................................................. 19
16. Carrying the stroller .......................................................................................................... 19
17. Attaching the raincover .................................................................................................... 19
18. Warranty ............................................................................................................................. 20
19. Care instructions ............................................................................................................... 20
CONTENT
EN
6
Your child´s safety is your responsibility. Always use the harness system to prevent your child from
falling or sliding out of the seat. This vehicle is suitable for a maximum of two children only. Follow all
instructions carefully to avoid incorrect handling as this can impair the stroller’s correct function.
The child should be clear of any moving parts while making adjustments. Prevent children from
grabbing the stroller while folding and unfolding, as fingers can become trapped and scissoring
actions are unavoidable.
To attach an additional full harness system for safety reasons ‘D’ rings (according to EN13210 or
BS6684) are provided.
The harness always needs to be attached and adjusted correctly. If not adjusted correctly
according to the instructions the stability of the stroller will be affected. The harness and seat belt do
not replace the permanent supervision by an adult.
Use of this stroller with a child weighing more than 15 kg will cause excessive wear and tear on the
stroller.
ATTENTION: THE TOTAL LOAD CAPACITY OF THE STROLLER IS 35 KG. IT
IS SUITABLE FOR CHILDREN WITH A WEIGHT OF MAX. 15 KG PER SEAT
UNIT. 2X15 IN THE SEAT + 2X2 IN THE BASKET + 2X0,5 IN THE CANOPY
POCKET.
I. GENERAL INFORMATION & SAFETY
• It may be dangerous to leave your child unattended.
• Always use the crotch strap in combination with the waist belt.
• Use a harness system as soon as the child can sit unaided.
• This product is not suitable for running or skating.
• Any load attached to the handles affects the stability of the stroller.
• Do not let your child play with this product.
• To avoid injury ensure that your child is kept away when unfolding and
folding this product.
• Always use the restraint system.
!
WARNING
7
• Damages caused by the use of accessories not approved by CYBEX, such as rain covers, buggy
boards, bag hooks, etc. will not be covered by the terms of our warranty.
• It may be unsafe to use replacement parts other than those approved by CYBEX.
• Before using the stroller, always check whether the accessories are well secured.
• Please make sure that the brake is locked while placing and removing the children.
• Never lift the stroller with the child inside; never go up or down the stairs or escalators with the child
inside or when traveling on other forms of transport.
• When opening and closing the stroller, do not use force, as incorrect folding can damage or break
the stroller. Check the instruction manual if necessary.
• Drive carefully over curbs and gravel roads. The vehicle will be damaged by repeated impact.
• Make sure your child does not use the footrest to stand on.
• Do not expose the stroller to any artificial heat or direct sunlight.
• For new born babies we recomend to adjust the backreest into the lowest (flattest) recline position.
II. INSTRUCTIONS FOR MAINTENANCE
• The user is responsible for the regular maintenance of the stroller. All connecting parts and rivets
have to be tightened and secured properly. It is particularly important to ensure that the locking
mechanism and swiveling mechanism are treated regularly with Teflon spray (dry lubricant). It is
important that brakes, wheels and tyres are not impaired during use. Inspect them regularly and
repair or replace if necessary. STOP using any product that does not appear structurally sound.
• Do not make any modifications to the product. If you have any complaints or problems, please
contact your supplier or importer.
• A service should be scheduled every 12 months.
• You can also treat the other moving parts with Teflon spray (dry lubricant). After spraying on the
Teflon, wipe the product with a soft cloth.
• Use only original CYBEX replacement parts. It may be unsafe to use substitutes.
• The frame tubes covered by the locking mechanism and turning mechanism should also be regularly
cleaned and sprayed. This will ensure that you enjoy your stroller without any problems.
Do not carry more than two children in the buggy. Do not hang any shopping bags onto the handle
bars. These should be stored in the stroller basket. The load per basket should not exceed 2 kg.
Overloading can result in the stroller becoming unstable. Maximum load allowed per canopy bag is 0,5
kg.
EN
8
CLEANING
• Do not use abrasives to clean the frame! Use a damp cloth and a mild detergent and dry thoroughly.
• Should the stroller be exposed to salt water, please rinse it down with fresh (tap) water as soon as
possible afterwards.
• The seat cover can be machine washed at max. 30°C with a mild detergent on a gentle cycle
setting. The canopy should be washed by hand with a mild detergent (not warmer than 30°C)
• See care labels for details. Do not use the washing machine or tumble drier. Dry thoroughly before
reuse.
• All CYBEX fabrics have been tested, but when the stroller is very wet, the water may permeate the
lining through the bottom edges and seams and leave water stains on the upholstery. We advise
you to use a rain cover to avoid this. Also please do not fold or store the product while wet. If the
stroller is wet, allow to dry with the hood extended. Never store in a damp environment as this can
cause mildew to form.
DISPOSAL
SERVICE
In general a Cybex buggy should run smoothly without any problems. A dry and/or dusty environment
can have a negative effect on the wheel systems. To avoid this it is very important that the wheel
systems will be regularly checked, cleaned and lubricated. This will ensure a smooth operation of the
stroller in daily use. Please follow the instruction below to maintain the wheel systems (wheel axles &
suspension system).
When you are done using your CYBEX TWINYX, a proper disposal is important. Garbage disposal
can be different in every country. Please contact your local waste management company to make
sure you are taking the right steps to dispose of the CYBEX TWINYX. Always follow the disposal
regulations of your country.
Please wash the cover separately before you use it the first time.
Do not tumble dry and do not expose to direct sunlight! Do not iron!
This product conforms and has been certified to safety standard
EN 1888:2012.
!
WARNING
9
c)
II.I CHECK OF WHEEL SYSTEMS
a) Wheel system must be cleaned before applying the lubricant.
b) Wheel system must not be broken or damaged. To avoid squeaking noises on your CYBEX buggy
only use WD 40 and follow the instructions below. Do not use any other kind of lubricant! Before
applying the lubricant, in order to avoid any stains on the fabrics, please protect them by holding a
cloth or carton in front of them. Please pay special
attention to not apply the lubricant on any other part of the stroller (fabrics, tubes, etc.).
II.II APPLYING OF THE LUBRICANT
b)
a)
Rear wheel – Spray from the rear side of the buggy in the space
between the rim and the housing on both sides. Let the lubricant
work its way into the system for approx. 10 seconds and then turn
both rear wheels.
Front wheel – Spray in the space between the rim and the
housing on both sides. Let the lubricant work its way into the
system for approx. 10 seconds and then turn both front wheels.
Should this not avoid the squeaking, please remove the rim cap
and apply the spray on the axle.
Suspension – Apply some lubricant between the suspension
slider and the housings.
EN
10
III. INSTRUCTIONS FOR USE
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE USE
AND KEEP THEM FOR FUTURE REFERENCE. YOUR CHILDREN’S SAFETY
MAY BE AFFECTED IF YOU DO NOT FOLLOW THESE INSTRUCTIONS.
a)
c)
b)
Release both (left & right) fold lock levers.
Push down on both pedals (left & right) of
the primary lock lever until the locking system
is engaged.locking system is engaged.
Open the stroller.
1. OPENING THE STROLLER READY FOR ASSEMBLY
CYBEX TWINYX
ASSEMBLY INSTRUCTION
DELIVERY STATUS
!
6x2x 1x
2x
1x
11
a)
a)
a)
With the locking pins facing you slide the
handle into recepticle.
Push in the locking pins and push handle in
until it makes an audible „click“.
Attention!
The pins on both sides must be fully
engaged.
Attention!
The Wheel system with the brake pedal must
be fitted to the right side of the
buggy (viewed from behind the buggy).
Attention!
The pins on both sides of the wheel system
must be fully engaged. Ensure the bowden
cable is inserted into the clips.
Fit the front wheels to the end of the frame
until they engage with a “click”.
2. ASSEMBLING THE HANDLES
3. ASSEMBLING THE FRONT WHEELS
4. ASSEMBLING THE REAR WHEELS
EN
12
5. FOLDING THE STROLLER
a)
!
c)
d)
Lift both pedals of the primary lock levers to
release both stretching system.
Remove all contents from the
baskets. Close both canopies and
remove the bumperbar.
Push down the third lock lever (extended bar on the right side of
the locking system).
Grip handles and push forward on the stroller in order to fold it.
Press the folded stroller until the fold lock on both sides is
engaged. We recommend to fasten the harness before folding the
stroller.
!
b)
