Master Control Panel
Installation Manual
E F F I C I E N C Y I N D E N T I S T R Y
®
Table of Contents
Section I Installation Instructions
Main Control Box............................................................................................ 2
Single/Dual Vacuum Pump Relay Box Connection .................................. 3
Vacuum Pump Relay Box Wiring Diagram ................................................ 4
Master Water Control Valve Connection .................................................. 5
Air Compressor Remote Connections...................................................... 6
®
RAMVAC
Section II Schematics
Rocker Switch Installation ........................................................ 7
Master Control Panel Wiring Diagrams Index ........................................ 8
Product Support Services ....................................................................19
Installation Manual
Master Control Panels
1
Section I Installation
All wiring between the main control box and equipment should be Class B, low-
voltage. In most cases, a conduit is
Before proceeding with any electrical installation, comply with and
maintain all applicable local electrical code(s) and regulations.
1. Position the main control mounting box, so that the master control panel switches
can be eye level, in a convenient location (near the office's entrance/exit).
2. Once the main control mounting box is in position, secure it using the brackets
provided.
IMPORTANT NOTE: To ensure proper installation of the finished master control
panel, the mud flange must be recessed by dry wall thickness.
Main Control Box
— NOTICE —
not
required when using this type of wiring.
— WARNING —
Master Control Panels
3. Install the main control box wires as follows:
a. Using a hammer and pliers, remove the appropriate knock-out from the main
control mounting box.
b. Fit a nylon grommet in the knock-out. (This protects the wires from chaffing and
shorting out.)
c. Run the appropriate wires to their respective equipment location. Then
connect the wires according to the instructions on the following pages.
4. After all wiring connections are completed correctly, position the master control
panel over the main control box and secure using the screws provided.
WIRING CHART
Model No. No. of Wires Wire Under 150 ft. Wire Over 150 ft.
CV-101 3 18 AWG 16 AWG
CV-102 3 18 AWG 16 AWG
DV-301 3 18 AWG 16 AWG
DV-302 3 18 AWG 16 AWG
MC-201 6 18 AWG 16 AWG
MC-202 6 18 AWG 16 AWG
Air Compressor 3 18 AWG 16 AWG
MWCV Solenoid Valve 2 18 AWG 16 AWG
MWCV Transformer 2 18 AWG 16 AWG
2
Installation Manual
Section I Installation
Single/Dual Vacuum Pump Relay Box Connection
(All Panels, Except Turbine)
Before making any wiring connections to the main control box, the vacuum unit
Before proceeding with the single/dual vacuum pump relay box connection, make
sure the electrical power supply to the vacuum pump is turned OFF.
All pumps (single or dual) must have three, low-voltage wires installed from the
top of each relay box going to the main control box in order to operate the master
control panel lighted ON/OFF switches.
— CAUTION —
should be completely installed.
— WARNING —
— NOTICE —
IMPORTANT NOTE:
control box, Steps 1 through 8 listed below must be performed for each vacuum pump.
Refer to the vacuum pump relay box wiring diagram on the next page.
For dual vacuum pump relay box connection to the main
NOTE: For vacuum pump relay boxes with factory-installed yellow, black and brown
wires, it is not necessary to perform Steps 1 through 8.
1. Loosen the top and bottom retainer screws from the vacuum pump relay box and
remove the cover.
2. Remove the black strain relief grommet from the top of the vacuum pump relay
box.
3. Place the tap connector slot over the yellow transformer wire, and insert the
brown wire into the end of the tap connector.
4. Squeeze the metal connector tight, and snap the attached cover in place.
5. Route the brown wire out through the strain relief grommet hole along with the
yellow and black wires.
6. Reinstall the strain relief grommet around the yellow, black and brown wires.
7. Reinstall the relay box cover and tighten the top and bottom retainer screws.
8. Run and connect the low-voltage wires to the main control panel mounting box
according to the applicable wiring diagram in Section II Schematics. (Refer to the
index on Page 8 for the location of the appropriate diagram.)
Master Control Panels
3
Section III Installation
Vacuum Pump Relay Box Wiring Diagram
Yellow
Brown
Fuse
Holder
Black
Yellow
Brown/White
Master Control Panels
Black
Alt. Voltage
Fuse Holder
Yellow
Blue
Terminal
Block
Black/White
Brown
Black
Purple
Transformer
654321
Yellow
Relay
White
Blue
Black
Green
4
Installation Manual
Red
Section IV Operation & Care
Master Water Control Valve Connection
(With 24-Volt Lighted Control Switch)
— NOTICE —
When using low voltage to operate the master water control valve (MWCV), a 115-
volt electrical receptacle for the MWCV “plug-in” transformer must be supplied.
1. Remove the MWCV from the shipping container or locate a previously installed
MWCV in the office.
— WARNING —
Before proceeding to Step 2, make sure all power is properly disconnected.
2. Dismantle the coil assembly.
3. Replace the 115-volt coil with the 24-volt coil included in the kit.
4. Provide power to the coil assembly using the “Plug-In” 115V/24V transformer
supplied with the kit.
5. Connect the two low-voltage wires from the transformer according to the
applicable master control panel wiring diagram in Section II.
— WARNING —
Do not plug in the transformer until all electrical connections are complete.
6. Test the MWCV and transformer as follows:
a. Turn the light switch to the OFF position. (The light should be off.)
b. Turn the light switch to the ON position. (The light should be on.)
c. When the switch is activated, the MWCV should make a clicking sound, which
indicates the valve is working properly.
d. If the light fails to come on, or if the MWCV fails to function, check all
connections referring to the applicable master control panel wiring diagram in
Section II.
NOTE: If a light stays
wires numbered 2 and 3 on the switch. The light should then operate correctly.
ON
while the switch is in the
Off
position, simply reverse the
Master Control Panels
5
Section I Installation
Air Compressor Remote Connection
1. Turn OFF all power to the air compressor at the source.
2. Mount the compressor relay box near the junction box on the air compressor.
3. Connect the power source supply lines to L1 and L2 on the compressor relay box
for new installation.
NOTE: For existing installation, first remove the power source supply lines from
the junction box.
4. Connect conduit from the compressor relay box to the junction box.
5. Connect the two lines from T1 and T2 to the two compressor power lines in the
junction box.
6. Run and connect low-voltage wires to the main control box according to the
applicable master control panel wiring diagram in Section II.
Master Control Panels
6
Installation Manual
RAMVAC Rocker Switch Installation
When connecting a RAMVAC pump, replace the VAC switch in the Master Control Panel
with the loose switch supplied.
Please use this schematic for RAMVAC rocker switch installation in the following panels:
PANEL PART #
MP300 64652017
MP1000 64568077
MP2000 64568110
MP1000A 64568171
MP2000A 64568174
Connect to an S1 Electrols as follows:
Terminal #4 - connect to S1 terminal “G”
Terminal #3 - connect to S1 terminal “H”
Terminal #2 - connect to S1 terminal “F”
S1 Electrols Terminals
F
H
G
3
2
4
VAC Switch
Master Control Panels
7
Section II Schematics
Master Control Panel Wiring Diagrams Index
MP - 100 / 300 ................................................................................ 9
MP - 400 ....................................................................................... 10
MP - 700 ........................................................................................1 1
MP - 900 ....................................................................................... 12
MP - 1000 ..................................................................................... 13
MP - 1100 ..................................................................................... 14
MP - 1200 / 1300 .......................................................................... 15
MP - 1800 ..................................................................................... 16
Master Control Panels
MP - 2000 ..................................................................................... 17
MP - 2200 ..................................................................................... 18
8
Installation Manual
Section II Schematics
One Switch, Single Vacuum
MP - 100 / 300
Brown
Yellow
Black
Line Voltage
(To Source)
L1
T1
L2
T2
Load
(To Vacuum Pump)
Vacuum Pump
Relay Box
Wall-Mounted Switches
Shown from
Back of Switch Plate
Vacuum
Junction Box
Master Control Panels
9
Section II Schematics
Two Switch, Dual Vacuum
Master Control Panels
MP - 400
ON/OFF Switches
Mounted on Dual Cabinet
Brown
Yellow
Black
Line Voltage
(To Source)
L1
T1
L2
T2
(To Vacuum
ON
OFF
Load
Pump)
Vacuum
Pump
Relay
Box
Brown
Yellow
Black
Line Voltage
(To Source)
L1
T1
L2
T2
(To Vacuum
ON
OFF
Vacuum
Pump
Relay
Box
Load
Pump)
10
NOTE: Using the circuit depicted in the
diagram above, either switch will turn
the vacuum pumps on. To wire pumps
so that either switch will turn the
vacuum pumps off, use the circuit shown
in the diagram to the right.
Installation Manual
Vacuum 1
Junction Box
Brown
Yellow
Black
Vacuum 2
ON
OFF
Vacuum Pump
Relay Box
Wall-Mounted
Switches
Shown from
Back of
Switch Plate
Vacuum Unit Panel Mounted Switches
(Same Connection as Back View)
Brown
Yellow
Black
ON
OFF
Section II Schematics
One Switch, Air Compressor
MP - 700
Brown
Yellow
Black
Red
L1
T1
L2
T2
Black
Load
(To Air Compressor)
Compressor
Relay Box
Wall-Mounted Switches
Shown from
Back of Switch Plate
Line Voltage
(To Source)
Air Compressor
Junction Box
Master Control Panels
11
Section II Schematics
Three Switch, (Dynamic Dry) Single Vacuum, Air Compressor,
Solenoid Valve
Main Water Control
MP - 900
Water
24V
Master Control Panels
In
AC
24V
Coil
Coil
Plug In Transformer
Yellow
Brown
Dynamic Dry
Black
Relay Box
213
Air Comp. Water
Line Voltage (To Source)
Load (To Compressor)
Compressor Relay Box
Red
T1
L1
Black
T2
L2
23123
Air
Out
In
43143
Air
1
Vac
Out
In
1
Vac
Vacuum
Shown from
Back of Switch Plate
Wall-Mounted Switches
Load
T1
T2
L2
L1
(To Dynamic Dry)
12
(Wall Mount Near Dynamic Dry)
Installation Manual
Brown
Yellow
Black
(To Source)
Line Voltage
Section II Schematics
Three Switch, Single Vacuum, Air Compressor, Water
Solenoid Valve
Main Water Control
Plug In Transformer
MP - 1000
AC
24V
213
In
24V
Coil
Coil
Water
Brown
Brown
Yellow
Yellow
Black
Black
Air Comp.
Line Voltage (To Source)
Load (To Compressor)
Compressor Relay Box
Red
T1
L1
Black
T2
L2
23123
Air
Out
In
43143
Air
1
Vac
Out
In
1
Vac
Vacuum
Shown from
Back of Switch Plate
Wall-Mounted Switches
Relay Box
Vacuum Pump
Master Control Panels
13
Section II Schematics
Four Switch, Dual Vacuum, Water, Air Compressor
Red
Black
MP - 1100
Load (To
Compressor)
Master Control Panels
Main Water Control
Relay Box
Compressor
Air Comp - In
1 2 3 4
to the Numbers on
the Side of the Switches
These Numbers Correspond
4 1 3 2
Air Comp - Out
Shown from
Back of Switch Plate
Wall-Mounted Switches
Brown
T1
T2
L1
L2
Black
Yellow
(To Source)
Line Voltage
3
on Valve
From Coil
Jumper
Solenoid Valve
Plug In
24V Trans.
Power from
Water Control - Out
Water Control - In
Transformer
ON
OFF
Vac. #2 - In
1 3 4 1 3 4
Vac. #1 - In
Vac. #2 - Out
4 3 2 4 3 2 2 4
Vac. #1 - Out
Vacuum 1 Vacuum 2 Water Air Comp.
Black
Yellow
Brown
(Same Connection as Back View Below)
Vacuum Unit Panel Mounted Switches
ON
OFF
Black
Yellow
Brown
14
Installation Manual
Relay Box
Vacuum Pump
to the Numbers on the
Terminal in the Relay Box
These Numbers Correspond
NOTE: Using the circuit depicted in the
diagram above, either switch will turn the
vacuum pumps on. To wire pumps so that
either switch will turn the vacuum pumps off,
ON
OFF
Black
Yellow
Brown
(Same Connection as Back View)
Vacuum Unit Panel Mounted Switches
ON
OFF
Black
Yellow
Brown
use the circuit shown in the diagram below.
Relay Box
Vacuum Pump
Section II Schematics
(For Dual Starter Kits Only)
MP - 1200 / 1300
One Switch
Lift Post
Yellow #1
POWER
3 PHASE
L1 L2 L3
9
T1 T2 T3
White
2
Black
Connect Per
Voltage
Requirements
2
(See Figure 1)
H1 H2 H3 H4 H5 H6
PRIMARY
SECONDARY
X2 F1 X1
1
Black #3
POWER
3 PHASE
L1 L2 L3
Yellow #2
9
T1 T2 T3
Brown #4
TURBINE 1
2
Fuse Type FNM - 6 1/4 AMP
Fuse Type KLK - 12-2 AMP
1
Switch 1
Wall-Mounted Switches
Shown from
Back of Switch Plate
H1
X2
208V
Switch 2
277V
240V
24V
Figure 1
TURBINE 2
480V
380V
H3
H2
H6
H5
H4
X1
Master Control Panels
15
Section II Schematics
Two Switch, (Dynamic Dry) Single Vacuum, Air Compressor
Master Control Panels
MP - 1800
Brown
Yellow
Black
Relay Box
Compressor
Relay Box
Dynamic Dry
Load (To
Red
T1
L1
Load (To
Black
Compressor)
Black
T2
L2
Dynamic Dry
White
(To Source)
Line Voltage
Air
Out
In
Air
(To Source)
Line Voltage
23123
43143
Vacuum Air Comp.
1
Vac
Out
In
1
Vac
Shown from
Back of Switch Plate
Wall-Mounted Switches
16
Installation Manual
Brown
Yellow
Black
T1
T2
L1
L2
Section II Schematics
Two Switch, Single Vacuum, Air Compressor
MP - 2000
Brown
Yellow
Black
Load (To
Compressor)
Relay Box
Compressor
Red
Black
T1
T2
L2
L1
Load (To
Vacuum Pump
Relay Box
Vacuum Pump
Blue
Blue
(To Source)
Line Voltage
Air
Out
In
Air
(To Source)
Line Voltage
23123
43143
Vacuum Air Comp.
1
Vac
Out
In
1
Vac
Shown from
Back of Switch Plate
Wall-Mounted Switches
Brown
Yellow
Black
T1
T2
L1
L2
Master Control Panels
17
Section II Schematics
Three Switch, Dual Vacuum, Air Compressor
Master Control Panels
MP - 2200
Brown
ON
Brown
OFF
Relay Box
Compressor
Load (To
Red
Compressor)
Black
(To Source)
Line Voltage
Shown from
23123
Air
Out
T1
T2
L1
L2
In
43143
Air
Black
Yellow
1
Vac
Out
In
1
Vac
Back of Switch Plate
Wall-Mounted Switches
Vacuum 1 Vacuum 2 Air Comp.
231
Vac
Out
Black
Yellow
431
In
Vac
ON
OFF
(Same Connection as Back View Below)
Vacuum Unit Panel Mounted Switches
ON
OFF
Black
Yellow
Brown
18
Installation Manual
Relay Box
Vacuum Pump
Black
Yellow
Brown
(Same Connection as Back View)
Vacuum Unit Panel Mounted Switches
ON
OFF
Relay Box
Vacuum Pump
Black
Yellow
Brown
NOTE: Using the circuit depicted in the diagram above,
either switch will turn the vacuum pumps on. To wire
pumps so that either switch will turn the vacuum pumps
off, use the circuit shown in the diagram below.
Product Support Services
DentalEZ® Group
CustomAir® Division
Master Control Panels
The DentalEZ Group and its employees are proud of the products we provide to the dental community. We stand
behind these products with a warranty against defects in material and workmanship as provided below.
In the event that you experience difficulty with the application or operation of any of our products, please contact our
customer service department at our expense at 1-866-DTE-INFO (1-866-383-4636).
If we cannot resolve the issue by telephone, we will arrange for a representative to contact you or suggest that the
product be returned to our factory for inspection.
If product return or repair is required, we will provide you with a Return Authorization number and shipping
instructions to return the product to the proper facility. If the product is under warranty, we will ask you to provide
proof of purchase, such as a copy of your invoice. Please be sure to include the Return Authorization number on the
package you are returning. Products returned without a Return Authorization number cannot be repaired.
Freight costs for product returns are the responsibility of the customer. Products under warranty will be repaired or
replaced, at our sole discretion, and returned at our expense. Products outside the warranty limits will be repaired and
returned with costs invoiced to the customer. We are not responsible for shipping damages. We will, however, help you
file a claim with the freight carrier Written repair estimates are available.
DentalEZ warrants the CustomAir Master Control Panels to be free of defects in material and workmanship, under
normal usage, for a period of 2 years from date of installation.*
Please note the following additional terms of our warranty and return policy:
• Warranties cover manufacturing defects only and do not co
cleaning, care or maintenance, normal wear and tear or non-observance of operating, maintenance or installation
instructions. Failure to use authorized parts or an authorized repair facility voids this warranty.
• Liability is limited to repair or replacement of the defective product at our sole discretion. All other
liabilities, in particular liability for damages, including, without limitation, consequential or incidental
damages are excluded.
• THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUD-
ING ANY IMPLIED W
PURPOSE. NO EMPLOYEE, REPRESENTATIVE OR DEALER IS AUTHORIZED TO CHANGE THIS
WARRANTY IN ANY WAY OR TO GRANT ANY OTHER WARRANTY.
WARRANTY REPAIRS: Parts repaired or replaced on a product that is in warranty will be warranted for the duration
of that product's original warranty.
NON-WARRANTY REPAIRS: The warranty on parts either repaired or replaced on an out-of-warranty product
will cover the repaired part only and will be for the time frame of a new parts warranty period.
PRODUCT RETURN: Opened products or product returns more than a year old cannot be returned for credit.
There will be a 15% ($25.00 Minimum) restocking charge on all items authorized for return.
ARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
ver defects resulting from abuse, improper handling,
* Provided conditions defined in instruction manual are met.
CustomAir, RAMVAC and DentalEZ are registered trademarks of DentalEZ, Inc.
© 2008 DentalEZ Alabama, Inc.
Master Control Panels
19
2500 Highway 31 South
Bay Minette, Alabama 36507
1-866-DTE-INFO
Fax: (251) 937-0461
www.dentalez.com
© DentalEZ Alabama, Inc.
Printed in USA
PN: 64710071C
October, 2008
Loading...
