Curtis TV1311 User Manual

TV1311

MUTE

POWER

RECALL

SCAN

567

SLEEP

CALENDA

DISPLY

GAME

V-CHIP

CCD

CH+

V+

V-

CH-

CONTENTS

Operation your TV

Tune menu

Parental guide (V-CHIP)and CCD

Menu operation

Television installation

Connecting other external devices

TROUBLE SHOOTING

SPECIFICATIONS

-1-

wall outlet

-2-

1.Power Buttom

2.Remote control sensor

3.Power indicator

4.Channel number up

5.Channel number down

6.Volume increase(+)

7.Volume decrease(-)

8.Menu key

9.TV/AV key

10.AV input sockets

11.Rear AV in/out and RF

-3-

CH- CH +

45678910

key

TV OSD Display key(Toggle on/Toggle off)

TV Picture Mode key

key

TV Channel up key

Volume decrease(-)

TV Channel down key

key

key TV Sleep key TV Calendar key

17:

TV Game key

18:

Volume increase(+)

10 11

8 9

POWER

TV AV/MUTE

123 4

567 8

SCAN RECALL

DISPLY PM SLEEP

CCD V-CHIP GAME CALENDAR

CH+

V+

V-

CH-

15 16

-4-

Battery and replacement for remote control unit

installation The remote control uses two 1.5V AAA batteries.For battery installation and replacement are as following:

1 Remove the sliding Cover of remote control

2 Load two 1.5V AAA size batteries into the compartment,with the +/pol es of bat terie s in line w ith the +/- m arks.

-5-

Operation Your TV

3.Operation Your TV

3.1 Power/Stand-By ON/OFF

With Power status On,you can also turn off the TV using the Remote Control Hand Unit.This status is called Stand-By mode.In this mode,You can also turn on the TV by pressing the Channel.Up/Down keys on the front of the TV set.

The TV has an Automatic Power OFF function. With no signal condition, the TV will automatically turn off after 10 minutes.

3.2 CHANNEL Up/Down

3.3 Direct Access Tuning

Press[CH+]key to change

Channel Up. Press[CH-]key to change Channel Down.

Using the numeric keys on Remote Control,Channels can be selected directly.

3.4 Volume Control

Press [V+] key for Volume Up.

Press [V-] key for Volume Down.

3.5 SCAN

Press this key,channels will change automatically. Each program will be previewed for 2 seconds,and stop at the channel original tuned.

3.6 TV/AV Selection

TV/AV

You can select the AV source which you want by pressing the [AV]key.

AV2

AV1

-6-

3.7 MUTE

( )

Press this key,sound output will be muted. Press [ ] key again,or Volume Up, and sound will return.

3.8 Quick View (RECALL)

RECALL

Press [ RECALL] key to quick return to the previously tuned channel. Press again to come back to the current channel.

3.9 DISPLAY (CALL)

DISPLAY

Press this key,the AV source status will be displayed on screen. if you press this key ,the current menu will exit directly.

3.10 Picture mode(PM)

By repeatedly pressing this key,picture mode will change as follows: STANDARD MILD DYNAMIC USER

3.11 Parental Guide(V-CHIP

Press this key on the remote control and

V-CHIP

enter to V-CHIP mode.With repeatedly pressing this key,the

mode will be changed as:

TV V-CHIP TV

Operation Your TV

Pro gram N0

)

AUTO

10:10

3.12 SLEEP

SLEEP

Repeatedly pressing this key will

make the sleep timer change as follows:

"0 10 20 30 40 50 60 70 80 90 100 110 120

3.13 GAME

GAME

Press[V+]/[V-] keys to enter Another method to enter "Game",please see 6.5

Function.

"GAME".

In game mode,the box will be moved to specific dot. Press [CH+]/[CH-] keys to move the box for up or down. Press[V+]/[V-] keys to move the box for right or left. Press[MENU]key once to restart the game. Press it twice or above to select a more difficult game. Press [DISPLAY] key to exit the Game.

-7-

SETUP

TUNE MENU

3.14 CALENDAR

CALENDAR

4.Tuning procedure

4.1 Auto Search Function:

Automatic Search and Memory (ASM)

A.Press [MENU]key i repeatedly to select "TUNE". B.Press[CH+]/[CH-]key to select "SIGNAL INPUT". By repeatedly pressing [V+] key,signal input mode will change as follows:

AIR CATV(STD) CATV(HRC) CATV(IRC)

For Canada user,recommend CATV(STD) input mode.

C.Press [CH+]/[ ] keys to select "AUTO SEARCH". D.Press[V+]/[V-] keys to start ASM and the tuner will scan for each available channel in order to program it for direct selection.

Using [V+]/[V-] keys enter "CALENDAR". Press [CH+]/[CH-] keys to select year.press [CH+],[CH-] keys to select month.

n the front of the unit or the remote control

CH-

4.2.FINE TUNING Function:Fine Tuning for current setting.

A.Use[CH+]/[CH-]keys to select "PROGRAM".Using [V+]/[V-] keys, to change program Number. B.Use [CH+]/[CH-] keys to select "FINE TUNE". C.Use[V+]/[V-] keys to adjust for best tuning.

4.3.Program Function:Use to change program.

Use [CH+]/[CH-]keys to select"PROGRAM".Use[V+]/[V-] keys to change Program Number.

4.4.SKIP Function:Use to"SKIP"channels.After setting to"on",the

program will not be selected when pressing channel Up/down keys. Use [CH+]/[CH-] keys to select"SKIP".Use[V+]/[V-] keys to select "ON" or "OFF".

-8-

PARENTAL GUIDE(V-CHIP) AND CCD

5 PARENTAL GUIDE(V-CHIP) AND CCD

5.1 SELECT PARENTAL GUIDE (V-CHIP) MODE

Select the channel which is broadcasting the program you want to watch.Press the [V-CHIP]key on the remote. Control and enter to V-CHIP mode press this key repeatedly,the mode will be changed as follows:

5.2

V-CHIP Password

To use V-CHIP setup menu,you must input the password. The default of V-CHIP password is 410000. Password may be changed by "CHANGE PASSWORD" menu. And then Using [CH+]/[CH-]keys to move the cursor. using [V+]/[V-]keys to select each item.

5.3 U.S.PGTV

In the menu "U.S.TV", Use[CH+]/[CH-]keys to move the cursor for up and down. Use [V+]/[V-]keys to move the cursor for right or left. Use [MENU] key to preset view or block.

TV V-CHIP TV

5.4

MPAA RATING

In the menu "MPAA RATING", Use [CH+]/[CH-]keys to move the cursor. Use [V+]/[V-]keys to change setup.

CANADA ENGLISH AND CANADA FRENCH

5.5

In the menu "CANADA ENGLISH" or"CANADA FRENCH", Use [CH+]/[CH-]keys to move the cursor. Use [V+]/[V-] keys to change setup.

-9-
