Curtis PLEDV1945A-C User Manual

PLEDV1945A-C

SSAFETY INSTRUCTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and / or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully before using the product.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the AC Adaptor from being walked on or pinched particularly at the plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightening storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

- 1 -

SSAFETY INSTRUCTIONS

This product is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent the product from being damaged, the following rules should be observed for the installation, use and maintenance of the product. Read the following safety instructions before operating the display. Keep these instructions in a safe place for future reference.

x To avoid the risk of electric shock or

component damage, switch off the power before connecting other components to the TV.

x Unplug the AC Adaptor before cleaning

the TV. Please use the included custom bezel cleaning cloth for cleaning the bezel of the TV only. Do not use a liquid or a spray cleaner for cleaning the product. Do not use abrasive cleaners.

x Always use the accessories

recommended by the manufacturer to insure compatibility.

x When moving the TV from an area of low

temperature to an area of high temperature, condensation may form on the housing. Do not turn on the TV immediately after this to avoid causing fire, electric shock or component damage.

x Do not place the TV on an unstable cart,

stand, or table. If the TV falls, it can injure a person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the TV.

x Any heat source should maintain a

distance of at least 5 feet away from the TV, i.e. radiator, heater, oven, amplifier etc. Do not install the product too close to anything that produces smoke or moisture. Operating the product close to smoke or moisture may cause fire or electric shock.

x Slots and openings in the back and

bottom of the cabinet are provided for ventilation. To ensure reliable operation of the TV and to protect it from overheating,

be sure these openings are not blocked or covered. Do not place the TV in a bookcase or cabinet unless proper ventilation is provided.

x Never push any object into the ventilation

slots of the TV. Do not place any objects on the top of the Product. It could short circuit parts causing a fire or electric shock. Never spill liquids on the TV.

x Do not use the TV in a portrait format (by

rotating 90 degrees) under high temperature environment (25°C or higher), since this would retard heat dissipation and would eventually damage the TV.

x The TV should be operated only from the

type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

x The power cable must be replaced when

using different voltage from that specified in the User Manual. For more information, contact your dealer.

x The TV is equipped with a three-pronged

grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug.

x Do not overload power strips and

extension cords. Overloading can result in fire or electric shock.

- 2 -

x The wall socket should be installed near

the equipment and should be easily accessible.

x Only the marked power source can be

used for the product. Any power source other than the specified one may cause fire or electric shock.

x Do not touch the AC Adaptor during

thunderstorms. To avoid electric shock, avoid handling the AC Adaptor during electrical storms.

x Unplug the unit during a lightning storm or

when it will not be used for a long period of time. This will protect the TV from damage due to power surges.

x Do not attempt to repair or service the

product yourself. Opening or removing the back cover may expose you to high voltages, the risk of electric shock, and other hazards. If repair is required, please contact your dealer and refer all servicing to qualified service personnel.

x Keep the product away from moisture. Do

not expose this appliance to rain or moisture. If water penetrates into the product, unplug the AC Adaptor and contact your dealer. Continuous use in this case may result in fire or electric shock.

x Do not use the product if any abnormality

occurs. If any smoke or odor becomes apparent, unplug the AC Adaptor and contact your dealer immediately. Do not try to repair the product yourself.

x Avoid using dropped or damaged

appliances. If the product is dropped and the housing is damaged, the internal components may function abnormally. Unplug the AC Adaptor immediately and

contact your dealer for repair. Continued use of the product may cause fire or electric shock.

x Do not install the product in an area with

heavy dust or high humidity. Operating the product in environments with heavy dust or high humidity may cause fire or electric shock.

x Hold the power connector when removing

the power cable. Pulling the power cable itself may damage the wires inside the cable and cause fire or electric shocks. When the product will not be used for an extended period of time, unplug the power connector.

x To avoid risk of electric shock, do not

touch the connector with wet hands.

x Insert batteries in accordance with

instructions while using the remote control. Incorrect polarities may cause damage and leakage of the batteries, operator injury and contamination the remote control.

x If any of the following occurs please

contact the dealer:

o The power connector fails or

frays.

o Liquid sprays or any object

drops into the TV.

o The Display is exposed to rain

or other moisture.

o The Display is dropped or

damaged in any way.

o The performance of the

Display changes substantially.

x Operating environment: Temperature: 5°C

~ 35°C, Humidity: 10% to 90% noncondensing, Altitude: 0~10,000 ft.

- 3 -

IIMPORTANT INFORMATION

Television Antenna Connection Protection

External Television Antenna Grounding

If an outside antenna or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges. Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.

Power Lines

Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits.

- 4 -

AAttaching or Removing the Stand

To attach the stand, place the display unit flat on a table. Afterwards match the 3 pins on the neck to the 3 pin holes on the stand.

- 5 -

27 29 30 39 42

IIdentifying Front and Rear Panel

Front View

Indicator light

INDICATOR LIGHT – The light is red when power is plugged in but the TV is not turned on. The light turns green when the TV is turned on. Because of the LED in the panel, the TV might take 10 – 12 seconds to

power on. REMOTE SENSOR – The remote sensor receives all the commands from the remote control.

Remote sensor

Rear View Mounting Pattern

Mounting Specification : 100mm x 100mm using screw size M4. Length of screw should not exceed 8mm. Please Note : The 8mm length of screw refers to how deep the screw can go inside the mounting holes. When you’re buying screws, you should add the original 8mm to the thickness of your mounting plate in order to get the total screw length.

- 7 -

This button switches between all the different sources of the TV. Whe n the OSD is active, this button acts as the enter button and confirms the menu selection.

-12V/

For Service

TV Remote Control

- 11 -

For universal remotes, this TV follows NEC’s universal remote code. You need to find the actual code from your cable or satellite or universal remote provider.

POWER – Turns the TV on or off.

2. GUIDE – Opens the current digital channel information guide (antenna only ).

3. MUTE – Turns the sound off from the TV. To un-mute either press VOL(+) or press the

MUTE button again.

4. NUMBER BUTTONS (0-9) – Press 0-9 to select a TV channel directly when you are

watching TV. The channel will change after 2 seconds.

5. (-) – Inserts the dash for selecting digital channels directly.

6. R – Returns to the previous channel.

7. VOL(+)/VOL(-) – Press the VOL buttons to increase or decrease the sound level.

8. MTS – Selects stereo, mono, or second audio programming.

9. CC – Cycles between different closed captioning modes.

10.Display – Shows the display info.

11. CH(+)/ CH(-)– functions as channel up and down .

12.Ÿ/ź/Ż/Ź/ENTER – These directional buttons allow you to move around in the TV’s

menu. Press the ENTER button when you want to select a particular option.

13.EXIT – Exit the main TV menu on the screen.

14.MENU – Brings up the main TV menu on the screen.

15.INPUT – Press this button to cycle through the INPUT source .

16.ASPECT – Press this button to change the picture’s cropping method.

17.FREEZE – Press this button to freeze current picture.

18.SLEEP – Turns the TV off in a specific set of time dependent on your selection.

19.FAV LIST – Gives you your list of favorite channels.

20.ADD/DEL – Adds or Deletes current channel from the favorite list.

21.FAV(-) – Press this button to change to the previous favorite channel.

22.FAV(+) – Press this button to change to the next favorite channel.

23.CH LIST –channel list

24.AUTO–PC Auto Adjust

25.PMODE – Selects various preset picture settings.

26.SMODE - Selects various preset sound settings.

27.TV – This button select the source TV.

28.AV – This button select the source TV.

29.

YPbPr –This button select the source YPbPr.

PC – This button select the source PC.

30.

31. DVD Function key particular see P33 .

- 12 -

DVD

User User

User

Colo r Temperature

Aspect Ratio

MFCLevel

Set options to MFC

Press button to select(Off/Low/Mediam/High)

User

Audio Language

Selec t the language supported by the chosen di gi tal channel.It is avai lab l e Onl y in DTV . Pres s button to s el ec t(En gl i sh/ Fr en ch/ Sp an i sh) .

Dig ita l Audio Output

RAW RAW

Off Select off Audio Language

Clock Menu

Set year, month, day, hour, minute, day and night. press remote digital key 0-9.

10 15 30 60 90 120 180 240

(5、15、30、45、60 Sec)

DVD

ow do I c lean the TV ?

IMPORTANT

1. The power cable has to be removed from the socket before cleaning the TV.

2. Do not use volatile solvent (alcohol, rosin, and toluene) to clean the TV. These types of chemicals might damage the housing and the LCD glass.

Cleaning the bezel and remote control

1. Use a 100% cotton cloth or micro-fiber cloth for cleaning.

2. If the remote control or bezel is dirty to the point where you cannot simply dry wipe it, please lightly dampen the wiping material (the wiping material cannot

be dripping wet, because if water drips into the panel it will cause malfunction and possible permanent damage to the panel which will not be covered under the warranty) with clean water and wipe again. Wipe the

display with a dry micro-fiber cloth or 100% cotton cloth afterwards.

Please Note :

Cleaning the Screen

1. Use a 100% cotton cloth or micro-fiber cloth for cleaning.

2. The LCD screen glass is extremely fragile. Do not scrape it with any material. Do not press or tap the screen to avoid cracking. When the screen is dirty to the point where you cannot simply dry wipe it, please lightly dampen the wiping material with clean water and wipe again. Wipe the display with a dry microfiber cloth or 100% cotton cloth afterwards.

ENERGY STARENERGY STAR

 Make sure you wring the water out of the cloth before cleaning

the bezel or remote in order to prevent water from penetrating into the electronics.

This HDTV meets the ENERGY STAR

-29 -

DVD Function

DVD.Disp button

DVD.Menu button

DVD PLAYER

DVD.Setup button

YPBPR

- 30 -

GUIDE

Press GUIDE key to G /Close.uide

D.DISP

D.MENU

FR/FF

- 31 -

TITLE

Press TITLE button on remote control during playback. Subtitle: [1] will be displayed on TV monitor that means a kind of language. Press TITLE button on remote control during playback. Subtitle: [1] will be displayed on TV monitor that means a kind of language. Press once more, Subtitle: [2] appeared on TV monitor means another kind of language and accordingly subtitles appear that represents how many kind os language being selected. Subtitle: [OFF] appears that toggle subtitle.Note: This function is valid only for DVD discs with subtitle function. It is invalid for DVD disc with singlesubtitle function.

D.SETUP

- 32 -

- 33 -

DVD PLAYER

SE TUP

Once the initial settings have been completed, the p layer can always be operated under the same conditions (especially with DVD discs). The settings will be retained in the memory even after turning off the power until the settings are changed. We set the initial language to Engl ish when the p layer is out of factory. Yo Operation

1. In stop mode, Press SETUP button to enter setup interface as followed, you can setup Language, Screen, Custom.

2. Press and to choose the desired section and ENT ER button to enter submenu or press SETUP

to leave the setup screen. Following is the language setup screen for your reference where you can set OSD menu, DVD menu, Audio Language and Subtitle Language.

u may change the language into that you preferred.

Language Setup

OSD Menu Audio Subtitle

Language Setup

OSD Menu Audio Subtitle

English French German Italian Spanish

- 34 -

RE FERENCE

Menu, Submenu and Options

DVD PLAYER

LANGUAGE

SUBMENU OPTIONS DESCRIPTION

OSD

Audio

Subtitle

English French German Italian Spanish

English French German Italian Spanish others English French German Italian Spanish others

English French German Italian Spanish others Off

English On Screen Display French On Screen Display German On Screen Display Italian On Screen Displ ay Spanish On Screen Display

- 35 -

Digital out

Normal CVBS+YUV

Reset

- 36 -

DVD PLAYER

REFERENCE

Definition o f terms

Angle

Recorded onto some DVD discs are scenes which have been simultaneously shot from a number of different angles (i. e. The same scene is shot from the from, left side and right side etc. ). With such discs, the ANGLE button can be used to view the scene from dif

Chapter Number

These numbers are recorded on DVD discs, A title is subdivided into many sections. Each of them is number and specific parts of video presentations can be searched quickly using these numbers.

DVD disc

This refers to a high-density optical disc on which high qual ity pictures and sound have been recorded by means of digital signals. I ncorporating a new video compression technology (MPEG2) and highdensity recording technology (for instance, a whole movie can be recorded).

Subtitles

These are the printed lines appearing at the bottom of the screen which translate or transcribe the dialogue. They are recorded on DVD discs and up to 32 languages.

PBC

The l anguage indicates on T V screen to imply operation or disc information.

Audio

Language recorded on discs and the maximum languages are up to 8 .

Time

This indicates the play time e lapsed from the start of a disc or a title . It can be used to find a specific scene quickl y (it may not work with some discs).

tle Number

These numbers are recorded on DVD discs. When a disc contains two or more movies, these movies are numbered as title1, title2, etc.

Track Number

These numbers are assigned to the tracks which are recorded on audio CDS. They enable specific tracks to be located quickl y. RA as audio setting, they must connect a decoder to decode those original audio signals .

, DVD enables full-motion video to be recorded over l ong periods of time

W The original DT S, AC-3 signals non-decoded. If users choose RAW

ferent angles.

- 37 -

DVD PLAYER

TROUB LESHOOTING

Check the chart below for a possible cause of the problem you are ex periencing before requesting service for this unit, Some simpl e checks or minor adjustment on your part may el iminate the problem and restore proper operation. Let the technician m properly before maintenance as loader, key IC are easy to be damaged by it.

aintain the unit. K eep away from static electricity

ouble

No power

Cannot read disc

No picture

No sound

Picture is distorted during fast forward or reverse

No (4 :3)(16:9) picture

Remote control does not function

Unit s or remote control buttons are not functioning or other abnormal phenomena

Audio soundtrack and/ or subtitle language not found in settings

Can not change angle

No pl ayback menu

Miscellaneous

Suggested sol ution

Plug the AC Adaptor into the power outlet tight to turn on/ off once

Disc access time within 10- 20 seconds is normal

The disc is scratched or defiled (change disc) The code of disc is dif PAL to NT SC error (Set video output as AUTO)

If your TV does not have P- Scan function, pressing VIDEO button on the

remote may cause this. Press VI DEO button again to rectify.

Ensure that the equipment is connected properly. Ensure that the TV or audio e quipments are not muted. Ensure that the audio output setting is correct.

The picture will be somewhat distorted at times. This is normal advance or reverse.

Choose the correct setup at T V T YPE item that matches the T V set.

Check the batteries being installed with correct polarities. Replace the batteries depleted. Point at remote control sensor and operate it within 5 meters.

Turn the unit of disconnect the AC AC Adaptor for 5 to 10 minutes and then reconnect it.

If the audio soundtrack and/or subtitle language does not exist in the disc, the language selected at the initial settings will not be seen/ heard. Alternative audio soundtrack (or An alternative l anguage is not selected with discs which contain subtitl e) language cannot be more than one

language sel ected.

This function depends on software availabil ity.

Even if a disc has a number of angl es recorded, these angles may be recorded for specific scenes onl y.

This function is suitable for VCD with playback control disc. In program pl aying mode, no repeat, A-B functions are available .

ferent from the code of unit (change the disc)

f and then back to on. Alternativel y, turn off the unit,

-38-

TTroubleshooting

The following table contains the common problems and the solutions to these problems. Please check this list before you contact the technicians.

Problems Solutions

NO PICTURE

ABNORMAL

COLORS

PICTURE IS TOO

DARK

AUDIO ONLY NO


PICTURE ONLY NO

AUDIO

REMOTE CONTROL

DOES NOT WORK

CANNOT RECEIVE SUFFICIENT CHANNELS THROUGH THE ATSC/NTSC TUNER

NO COLOR

WEAK SIGNAL OR NO PROGRAM SYMBOL ON SCREEN

TV’S UNIVERSAL REMOTE CODE

Connect AC Adaptor correctly. Turn on power. Connect video cable correctly. Select the input signal source with proper cable connection with the source button. Match the colors on the cables to the ports off the back of the television. I.E. red cable to red colored port. Adjust your contrast, brightness and lamp settings from the OSD Menu. For adjust controls, refer to page 27. Make sure you have connected both your video and audio cables. The TV’s tuner signal must not be lower than 65 %. Make sure the audio cable is connected. Readjust your volume via the remote control. The TV’s tuner signal must not be lower than 65 %. Turn off the TV, unplug it from the socket. Remove the batteries out of the remote for 30 minutes. Press the remote buttons and the power button randomly for a good 2 seconds, and then reinstall the batteries. Try the remote to see if it works. For battery removal instructions, refer to page 13. The TV’s remote sensor is also housed in the same place as the power indicator light. Please make sure there is line of sight from the remote control’s front sensor to the remote sensor of the TV. The TV’s tuner signal must not be lower than 65 %. Change the direction of your antenna and rescan your channels. If you have cable call up your cable company and ask about signal strength of your local cable.

Please adjust your picture setup and make sure the saturation and the RGB are not turned all the way down. For adjustment controls refer to page 27. The TV’s tuner signal must not be lower than 65 %. Check your signal. The TV’s tuner signal must not be lower than 65 %. Change the direction of your antenna and rescan your channels. If you have cable call up your cable company and ask about signal strength of your local cable.

This television follows NEC’s universal remote code. To find the actual code you must read through your own universal remote’s guide book.

- 39 -

Problems Solutions

TV CHANNELS ARE

BLOCKED

UNIVERSAL REMOTE

CODE

THE TV TURNS ON

OR OFF SLOWLY

AND THE SCREEN

SHOWS UP SLOWLY

NO SOUND ON PC Make sure you have a 3.5 mm mini-jack cable connected from your

HDCP VIDEO SAYS NO HDCP SUPPORT

HDCP VIDEO HAS NO AUDIO

CANNOT GET 1920X1080 ON PC VGA PICTURE IS DISTORTED OR HAS ABNORMAL SOUND

PICTURE DOES NOT COVER THE ENTIRE SCREEN

PICTURE QUALITY IS HORRIBLE!!

PICTURE HAS PIXELS THAT ARE ALWAYS DISPLAYING THE SAME COLOR I CANNOT CHANGE THE TIME MANUALLY

BIG BLACK BOX IN THE MIDDLE OF SCREEN

Check your auto lock function’s settings inside the OSD. You may have locked up some channels but forgot about them. Refer to page 34 for more instructions. This TV follows NEC’s universal remote code. Please check your hand book for NEC’s codes then apply them. This TV is a High Definition liquid crystal display panel TV. It requires a few more seconds than normal TVs to power up and show the picture.

pc’s sound output to the TV’s VGA STEREO INPUT. Reboot your HDCP video device but turning them off and unplugging the AC Adaptor. Wait up to 8 minutes to plug the power back in to see if it works or not. Make sure you have a 3.5 mm mini-jack cable connected from your HDCP video device’s sound output to the TV’s VGA STEREO INPUT. If your HDCP video device uses RCA AUDIO jacks, you’ll need to obtain a RCA audio converted into 3.5 mm mini-jack cable. Make sure the TV is recognized as plug and play monitor. Try updating your video card’s drivers as well. If that does not help, most likely you’ll need to upgrade your video card to a newer one. This might be from interference from large electrical appliances, cars, motorcycles, or fluorescent lights. If the TV is close to the wall, try moving the TV to another room in your house to see if the problem still occurs. If you’re using HDMI or a TV digital channel make sure you use the ASPECT button to switch to 16:9 format. If you are using VGA, use the AUTO ADJUST function to adjust to the screen. Please Note : If you are using regular analog TV, AV, or component in 480i resolution, use the ASPECT button to switch to 16:9 in order to fill up the screen. Please Note : This note this feature will distort the picture. For best image quality, view HD widescreen programs where possible. If HD content is not available view “Standard Definition” from a digital source. Standard, analog TV will always be noticeable inferior to HD because your TV has video that is many times better than old TV’s and so you can see interference and deficiencies you did not KNOW you had. Your TV is manufactured using an extremely high level of precision technology, however, sometimes some pixels of your TV may not display. Pixels defects within industry specifications are inherent to this type of product and do not constitute a defective product. Your TV syncs time automatically according to your local TV channel. This function only works while the TV’s tuner is connected to an ANTENNA. You have turned on closed captioning and are using TEXT1 – TEXT4. Change the setting to CC1 or turn off closed captioning and the box will disappear. Refer to page 40 for more information.

- 40 -

Problems Solutions

SWITCHING A CHANNEL OR SOURCE CHANGES THE VOLUME

THERE IS NOISE OR TRASH PIXELS ON THE SCREEN TIPS FOR HIGH DEFINITION USERS

TIPS FOR LETTERBOX CONTENT USERS

I CANNOT FIND THE VOLUME AND CHANNEL CHANGING BUTTONS TV TURNS OFF AUTOMATICALLY AFTER 10 MINUTES

Different channels and inputs will sometimes have this effect because the channel signal’s own volume is already loud. There is no way remove this completely. The TV has an AUTO VOLUME LEVEL function that can combat this type of effect. Please make sure that function is turned on. When your TV’s resolution is higher than the digital channel’s broadcast resolution, the signal is up-converted to match your TV’s resolution. Up-converting can cause this type of effect. The TV is an ideal platform for viewing High Definition Content. The best image quality can be achieved by HDMI, YPbPr (Component), then VGA. However, due to variances in broadcast practices, it is possible some image distortions can occur. Letterboxed (Widescreen) versions of DVD movies are most commonly formatted for standard 4:3 TVs. The TV has the capability of expanding this content so the entire screen is filled at the expense of the image proportion. To use this function press the aspect button on the remote control and cycle among the available options. The buttons are represented by the ŸźŻŹ buttons located on the remote control. Ÿź changes the channels and ŻŹ changes the volume.

The TV features a power saving mode which will automatically turn off the TV, if there’s no signal provided for more than 10 minutes.

- 41 -

SSpecification

Panel Specifications

Aspect Ratio Widescreen 16:9

Pixel Pitch 0.36375 (H) x 0.36375 (V) mm per one triad

Max. of Pixels (Resolution) HD (1366 x 768 pixels) ˗FHD˄1920x1080 pixels˅

Brightness 300 nits (Typical)

Contrast 1000:1 (Typical) with Auto Contrast Enhancement

Response Time 5 ms (gray to gray)

Viewing Angle Typical 178/178Degree (Horizontal/Vertical)

Lamp Life of Backlight > 30,000hrs

Functions

(1) Video Functions

De-Interlace 3D

Frame Recover 3:2

Noise Reducing Core Technology 3D

Aspect Ratio Normal, Wide,Zoom,Cinema

Gamma Fixed Gamma

Lamp Adjust Yes

Picture Mode Power Saving,Standard,Dynamic,Soft,user

Video Adjust Brightness / Contrast / Color / Tint / Sharpness

(2) Audio Functions

Sound Mode User,Standard,Music,Movie,Sports

Tone Balance

Spdif Out Yes (coax)

Speakers 3 watt per channel

Surround Sound Yes

Sound Equalizer 5 Band

- 42 -

(3) General Funtions

Hybrid Tv Tuner NTSC / ATSC / QAM (Digital Cable Ready)

Channel Auto Scan Yes

Sleep Timer (Minutes) Off / 5 / 10 / 15 / 30 / 60 / 90 / 120 / 180 / 240

Screen Si ze 19 inch

Power requirement DC12V/3A , 50/60Hz

Power consumption

Standby Power Under 1W

Timing Support-Video 480i / 480p / 720p / 1080i / 1080p

PC Timing

(4) Tuner Functi ons

NTSC

ATSC

(5) Input / Output Connecti ons

Input Ports

Output Ports

˘ 36W

1920x1080@60Hz(Native) 1360*768@60 Hz 1024*768@60, 70, 75Hz 800*600@60, 75Hz 640*480@60, 75Hz

Sound: Mono / Stereo / SAP

Favorite Channel

V-chip

Closed caption (CC1-CC4, Text 1-Text 4)

Favorite Channel

V-chip

Video input format: 1080i, 720p, 480p, 480i

Analog closed caption (CC1-CC4, Text 1-Text 4) Digital closed caption (Service 1-Service 6)

1 input x TV Tuner (NTSC/ATSC) 1 input x AV (audio shared with YPbPr) 1 input x YPbPr (audio shared with AV) 2 inputs x HDMI/HDCP (optional, HDCP audio

shared with VGA Audio In) 1 input x VGA 1 input x VGA Audio In 1 input x USB

1 output x COAXIAL (digital audio) out

*The product’s specifications may change without notice or obligation. **This manual’s pictures and words are for references only and are subject to change without notice or obligation. Inc is not liable for the misuse or misinterpretation of this manual.

-43 -

Curtis PLEDV1945A-C User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
