Page 1
JetSort
®
Automatic Oiler
Setup
Instructions
Page 2
High voltage inside. Risk of electric shock.
OFF
Oil recommended for JetSort® automatic oiler is 10W. Use only recommended motor oil
Machine Preparation
with this machine.
Turn power
Customer must provide grounded power line protected by properly grounded
15-amp circuit breaker in compliance with applicable local electrical code.
Plug three-prong grounded plug (supplied) into properly grounded three-prong
outlet.
Read and understand all instructions before use.
JetSort® Automatic Oiler
and unplug before performing preventive maintenance.
Fill Oil Reservoir
1. Turn off JetSort and unplug the machine from the electrical outlet.
2. Remove inspection tray
3. Locate oil reservoir jar (plastic container with white lid) mounted in the right, rear corner of JetSort
cabinet.
4. Remove jar from holder. Remove lid from oil reservoir jar.
5. Fill jar with recommended oil (eight ounce capacity).
6. Replace reservoir jar lid and return jar to the holder.
JetSort Automatic Oiler | 2
Page 3
Setup
During setup, use a clean, lint-free towel to remove dispensed oil from the
*** Oiler Setup ***
Oiler
Setup:
Coins per Oil:
(Thousands)
(Seconds)
sorting pad. Do not allow oil to remain on sorting disk.
Getting Started
1. Plug the machine into an electrical outlet. Turn on JetSort. The JetSort should be in a Batch
Ended condition. If not in a Batch Ended condition, touch End until Batch Ended appears
onscreen.
2. Press and hold the Red key for five seconds to activate Setup Mode.
3. Select Setup Mode.
4. Select More until the Oiler Setup option appears within the onscreen menu.
5. Select Oiler Setup.
6. Raise the sorting disk.
7. From the Oiler Setup screen, select On to activate automatic oiling.
OFF ON
Oil Pulse Width:
5
.10
1 SHOT PRIME
HELP
EXIT
Prime the System
For proper operation, the automatic oiler must be primed. Priming the machine ensures oil is properly
running through the hose to the exit hole and air is removed from the oil tube. The oil tube exit hole is
located on the sorting disk at the nine-o’clock position.
1. To prime the system, continuously press Prime for three to five seconds or until oil flows evenly
from the exit hole in the sorting disk. Once oil is discharged from the tube exit hole, stop
pressing Prime and wipe off excess oil from the sorting disk with a clean, lint-free towel.
3 | JetSort Automatic Oiler
Page 4
Set Coins per Oil
The frequency setting at which oil is dispensed depends upon the number of coins processed. An
average setting is four or five, which is one drop of oil for every 4,000 or 5,000 coins processed. The
range can be set between one and 99.
2. To change the setting at which oil is dispensed, select Coins per Oil. Then enter the desired
number on the numeric keypad. Select Enter on the keypad to save the setting.
Set Oil Pulse Width
The length of time the oiling motor is active determines the amount of oil dispensed at the set frequency.
The factory default and recommended setting is .10 (one-tenth of a second).
3. To change the setting, select Oil Pulse Width. Then enter the desired number on the numeric
keypad. Select Enter on the keypad to save the setting.
Test Settings
4. To verify settings, watch the oil tube exit hole while selecting 1Shot. One drop of oil should be
discharged from the tube exit hole. Wipe off excess oil with a clean, lint-free towel.
Exit and Save Settings
5. Lower and securely latch sorting disk.
6. Exit the Oiler Setup screen by selecting Exit. Select Exit a second time to return to the Main
Setup screen.
7. To save all settings, select User Defaults then Save to be Current.
8. Select Exit.
9. Replace the inspection tray. The automatic oiler setup is complete.
JetSort Automatic Oiler | 4
Page 5
852 Feehanville Drive
Mt. Prospect, IL 60056
800 786 5528
cumminsallison.com
© 2016 Cummins-Allison Corp. All rights reserved.
All trademarks rem ain
I
This manual contains proprietary informa tion of Cummins
equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to any other parties for a
permission of Cummins Allison. 022-7164-00 REV. D
the property of their respective owners.
nformation is subject to correction or change without prior notice.
