Cub Cadet Yanmar Lx490 Part List Manual

Part List Manual

Lx Series Compact Tractor

Lx490

Cub Cadet Yanmar LLC

P.O. Box 361052

Cleveland, Ohio 44136-1052

PRINTED IN U.S.A. Form No. 769-06831

March 21, 2011

2

Notes

Lx490Lx Series

3

Engine Section Index

Fig. No. Group Name

1. Cylinder Block

2. Gear Housing

3. Flywheel Housing & Oil Sump

4. Cylinder Head & Bonnet

5. Suction Manifold

6. Exhaust Manifold & Muer

7. Camshaft & Driving Gear

8. Tur bi ne

9. Crankshaft & Piston

10. Balancer

11. Lub. Oil System

12 . Lub. Oil Line

13. Cooling Water System

14. Fuel Injection Pump

15. Governor

16. Fuel Injection Valve

17. Starting Motor

18. Generator

Lx490Lx Series

4

Fig 1. Cylinder Block

Lx490Lx Series

5

Fig 1. Cylinder Block

Lx490Lx Series

Ref.

1 CY-729508-01570 BLOCK ASSY, CYLINDER 1

4 C Y-129 00 1- 0125 0 PLUG, 50 1

5 CY-171051-01921 PLUG, NPTF1 1

6 CY-129150- 02020 BOLT, METAL CAP 10

9 C Y-129 795 - 02412 BUSH, CAMSHAFT A 1

10 CY-27243-300000 PLUG 30 8

11 CY-124 060 -01050 PLUG, PT1/8 1

12 C Y-12416 0- 01910 PLUG, PT1/4 2

13 CY-27241-120000 PLUG, 12 2

23 CY-129150-02931 METAL ASSY, THRUST 2

26 C Y-129 150 - 0120 0 BOLT, CYLINDER HEAD 18

27 C Y-12 950 8 -0 1330 GASKET, HEAD 1

28 C Y-1193 09 -0181 0 PLUG 1

29 CY-129001-02931 MAIN BEARING SET 5

32 CY-129150-02871 MAIN METAL US=0.25 5

35 CY-129150-02941 BEARING, THRUST.25OS 1

Part Number Description Qty

6

0CNP5-G38300

Fig 2. Gear Housing

Lx490Lx Series

7

Fig 2. Gear Housing

Lx490Lx Series

Ref.

1 CY-729008-01500 HOUSING ASSY, GEAR 1

3 CY-11993 4- 018 00 SEAL, OIL 1

4 C Y-129 00 8 -0 1520 FLANGE, GEAR CASE 1

5 CY-1198 02- 01561 STUD, M8X25 3

6 CY-124160-01751 COVER, FILLER 1

7 CY-124240- 01871 COVER, PUMP 1

8 CY-129 795 -019 50 PIPE, KNOCK 2

9 CY-1196 09 -320 40 O-RING P16 2

10 CY-12185 0- 5196 0 O-RING, F.I.PUMP 1

11 CY-2 2190- 0800 02 SEAL WASHER 8S 4

12 C Y-22190 -080 002 SEAL WASHER 8S 1

13 CY-24311-000320 O-RING 1A P-32.0 1

14 CY-26106- 080162 BOLT M 8X 16 PLATED 4

15 C Y-26106-08 0162 BOLT M 8X 16 PLATED 3

16 CY-2 6106 -0 80302 BOLT M 8X 30 PLATED 1

17 C Y-26106 -080552 BOLT M 8X 55 PLATED 10

18 CY-26106-080852 BOLT M 8X 85 PLATED 3

19 CY-26306-080002 NUT, M8 3

20 CY-124240-01871 COVER, PUMP 1

21 CY-124240- 01871 COVER, PUMP 1

22 CY-124240- 01883 GASKET, PUMP 2

23 CY-2 2190- 0800 02 SEAL WASHER 8S 1

24 C Y-26106 -08 0162 BOLT M 8X 16 PLATED 4

25 CY-26106 -0 80202 BOLT M 8X 20 PLATED 1

26 CY-26106-08 0302 BOLT M 8X 30 PLATED 3

27 C Y-121023 -01551 COVER, TACHOMETER 1

28 CY-24341-000240 O-RING 1A S-24.0 1

29 CY-26106 -0 60162 BOLT M 6X 16 PLATED 2

Part Number Description Qty

8

0CNP5-G38300

Fig 3. Flywheel Housing & Oil Sump

Lx490Lx Series

9

Fig 3. Flywheel Housing & Oil Sump

Lx490Lx Series

Ref.

1 CY-12910 0- 01580 PIN, PARALLEL 2

2 C Y-129 558 - 0162 0 HOUSING, FLYWHEEL 1

3 CY-19445 0-11190 PLUG 15 6

4 CY-2620 6-100252 BOLT M10X25 8

5 C Y-12 955 0 -0 1702 SUMP, LUB.OIL 1

6 CY-729429-01721 COVER ASSY, OIL SUMP 1

7 CY-105 425 -0169 0 PLUG, M16 1

9 CY-22190 -160 002 WASHER, 16 1

10 CY-129555- 01750 PIPE, KNOCK 1

11 CY-26106 -0 80122 BOLT M 8X 12 PLATED 20

12 C Y-26106 -08 0502 BOLT M 8X 50 PLATED 8

13 C Y-26106-0810 02 BOLT M 8X100 PLATED 14

14 CY-26106- 081202 BOLT M 8X120 PLATED 4

15 C Y-129100-01580 PIN, PARALLEL 2

16 CY-729402-01650 CASE ASSY, OIL SEAL 1

18 C Y-129 120 -0 178 0 SEAL, OIL 1

19 C Y-129 4 86 - 0167 0 BOLT, M8X30 9

Part Number Description Qty

10

0CNP5-G38300

AAA

Fig 4. Cylinder Head & Bonnet

Notes

Lx490Lx Series

11

Fig 4. Cylinder Head & Bonnet

Lx490Lx Series

Ref.

1 C Y-129 50 8-1124 1 SHAFT ASSY, ROCKER 1

2 C Y-129 50 8-112 50 SHAFT, ROCKER ARM 1

4 C Y-129 50 8-112 60 SUPPORT, ARM A 2

5 C Y-129 50 8-1127 0 SUPPORT, ARM B 3

6 C Y-129 50 8-112 80 WASH ER 8

7 CY-129 508 -11650 ARM KIT, ROCKER 4

8 C Y-129 150 -1123 0 SCREW, VALVE ADJUST 4

10 CY-12915 0-11750 NUT, M8 4

11 CY-129 508 -1166 0 ARM KIT, ROCKER 4

12 C Y-12 9150 -1123 0 SCREW, VALVE ADJUST 4

14 C Y-129150 -11750 NUT, M8 4

15 C Y-1295 08 -11920 PEDESTAL, RETAINER 4

16 CY-26226-080352 STUD M 8X 35 PLATED 3

17 C Y-123 907-1155 0 SEAT, VALVE BRIDGE 8

18 C Y-1295 09 -117 00 HEAD ASSY, CYLINDER 1

24 CY-23876-020000 PLUG PT1/4,SCREW 4

25 CY-27241-400000 PLUG 40 2

26 C Y -12 9 50 8 - 1110 0 VALVE, INTAKE 8

27 C Y -12 9 5 08 -1111 0 VALVE, EXHAUST 8

28 C Y- 12 9 50 8 - 1113 0 SPRING, VALVE 16

29 C Y- 12 9 50 8 - 1118 0 RETAINER, SPRING 16

30 C Y-119717-11190 COT TER 32

31 C Y-119717-113 40 SEAL, VALVE STEM 8

32 C Y-119717-11350 SEAL, VALVE STEM 8

33 C Y-129672-11510 BRIDGE ASSY, VALVE 8

35 C Y-12915 0-11750 NUT, M8 8

36 C Y-1239 07-11830 ADJUSTER, BRIDGE 8

37 C Y-129 508 -11820 GUIDE, VALVE BRIDGE 8

38 C Y-1198 02-1187 0 PROTECTOR, NOZZLE 4

39 C Y-11962 5-1188 0 SEAT, NOZZLE 4

Part Number Description Qty

Ref.

40 C Y-129 508 -1190 0 RETAINER, NOZZLE 4

41 C Y-1299 07-1195 0 BOLT, M8X75 4

42 C Y-2 23 51- 06 00 12 SPRING PIN 6X12 2

43 CY-24311-000120 O-RING 1A P-12.0 4

44 C Y-26106 -08 0252 BOLT M 8X 25 PLATED 3

45 CY-26106-08 0502 BOLT M 8X 50 PLATED 7

46 C Y-124160 -01751 COVER, FILLER 1

47 C Y-129 558 -11350 BONNET ASSY 1

48 C Y-12 95 08 -0 30 10 PLATE, BAFFLE 1

49 C Y-11980 2-0 307 0 BAFFLE, BREATHER 1

50 C Y-129 150 - 030 70 BAFFLE, BREATHER 1

51 CY-129907-03070 BAFFLE, BREATHER 1

52 C Y-1239 07-03100 DIAPHRAGM 1

53 C Y-1239 07-03110 PLATE, CENTER 1

54 C Y-123 907 -0 3120 PLATE, BREATHER 1

55 C Y-12 39 07- 0314 0 SPRING, DIAPHRAGM 1

57 C Y-1295 08 -11310 GASKET, BONNET 1

58 C Y-11910 0-1133 0 ELBOW, BREATHER 1

59 C Y-129 00 9-1134 0 SPRING, PLATE 1

60 CY-22857-50010 0 SCREW, M5X10 1

61 CY-22857-50 0100 SCREW, M5X10 4

62 CY-22857- 50010 0 SCREW, M5X10 6

63 CY-27241-180000 PLUG, 18 1

64 C Y-12416 0-1136 0 KNOB 3

65 CY-24311-000120 O-RING 1A P-12.0 3

66 CY-24311-000320 O-RING 1A P-32.0 1

67 CY-129900-07900 LIFTER, ENGINE 1

68 CY-2610 6- 080162 BOLT M 8X 16 PLATED 2

69 C Y-119717-118 00 GUIDE, VALVE 16

Part Number Description Qty

12

0CNP5-G38300

Lx490Lx Series

Fig 5. Suction Manifold

Notes

13

Fig 5. Suction Manifold

Lx490Lx Series

Ref.

1 C Y-129 50 8-12 110 GASKET, MANIFOLD 1

2 C Y-129 50 8-12 120 MANIFOLD, AIR INTAKE 1

3 CY-26106 -0 80202 BOLT M 8X 20 PLATED 6

4 CY-26106-080802 BOLT M 8X 80 PLATED 1

5 C Y-129 558 -12 09 0 HOSE,INTAKE 1

6 CY-23000-048000 CLAMP 48 1

7 CY-23000-060000 CLAMP 60 1

8 C Y-129 120 -775 02 HEATER, AIR 1

9 CY-129150-77511 GASKET, AIR HEATER 1

10 CY-26106 -0 80352 BOLT M 8X 35 PLATED 4

Part Number Description Qty

14

0CNP5-G38300

Fig 6. Exhaust Manifold & Muer

Notes

Lx490Lx Series

15

Fig 6. Exhaust Manifold & Muer

Lx490Lx Series

Ref.

1 CY-129 550 -13110 GASKET, EXH.MANIFOLD 1

2 C Y-129 558 -1312 0 MANIFOLD, EXHAUST 1

3 CY-1198 02-136 30 BOLT, M8X55 8

4 CY-129 418-18 320 STUD, M8X20 4

5 CY-129 558 -1330 0 BEND, EXHAUST 1

6 CY-129 558 -13310 STIFFENER,EXH. BEND 1

7 CY-129 558 -13530 SILENCER 1

8 CY-1291 07-1355 0 GASKET, NOZZLE 1

9 CY-1198 02-136 30 BOLT, M8X55 2

10 CY-129 659 -136 60 STAY, SILENCER 1

11 CY-129 508 -180 90 GASKET, TURBINE OUT 1

12 C Y-119131-183 20 STUD, M8X22 3

13 CY-26014-080222 BOLT M 8X 22 2

14 CY-26014-080252 BOLT M 8X 25 2

15 C Y-26106-08 0162 BOLT M 8X 16 PLATED 2

16 CY-2 6106 -0 80302 BOLT M 8X 30 PLATED 2

17 CY-26306-080002 NUT, M8 3

Part Number Description Qty

16

0CNP5-G38300

Fig 7. Camshaft & Driving Gear

Lx490Lx Series

Notes

17

Fig 7. Camshaft & Driving Gear

Lx490Lx Series

Ref.

1 CY-12915 0-14 200 TAPPET 8

2 CY-12915 0-14 40 0 ROD, PUSH 8

3 CY-129 508 -14580 CAMSHAFT ASSY 1

4 CY-129150-02450 METAL, THRUST 1

6 CY-12915 0-1410 1 GEAR, CAMSHAFT 1

7 CY-2 2512-070140 KEY, 7X14 1

8 CY-26106 -0 80142 BOLT 8X 14 PLATED 2

9 CY-119803-25050 SHAFT, IDLER 1

10 CY-1198 02-2 5101 GEAR ASSY, IDLE 1

13 C Y-26106-08 0402 BOLT M 8X 40 PLATED 3

14 C Y-129 150 -2 5301 BOLT, PUMP 4

15 C Y-11980 2-25 901 GEAR, PUMP 1

16 C Y-129 150 -0 188 1 GASKET, COVER 1

17 CY-129150-26000 DRIVE ASSY, PUMP 1

18 CY-129150-26050 BRACKET, PUMP 1

20 CY-24105-06 006 4 BALL BEARING 2

21 CY-1198 02-2 5071 BUSH, IDLE GEAR 1

Part Number Description Qty

18

0CNP5-G38300

8. TURBINE

LEV.REF. PARTS NO. DESCRIPTION

Fig 8. Turbine

Lx490Lx Series

Notes

19

Fig 8. Turbine

Lx490Lx Series

Ref.

1 CY-129 558 -18010 TURBINE, RHF4 1

2 CY-129508-18080 GASKET, TURBOCHARGER 1

3 CY-26306-080002 NUT, M8 4

Part Number Description Qty

20

0CNP5-G38300

Fig 9. Crankshaft & Piston

Lx490Lx Series

Notes

21

Fig 9. Crankshaft & Piston

Lx490Lx Series

Ref.

1 CY-129 652-21010 CRANKSHAFT ASSY 1

2 CY-12910 0- 01580 PIN, PARALLEL 1

4 CY-1198 03-2 120 0 GEAR, CRANKSHAFT 1

5 CY-12185 0-21290 PIN 1

6 C Y-129 40 0 -28 121 GEAR, BALANCER 1

7 CY-2 2512-070140 KEY, 7X14 1

9 CY-2 2512-070140 KEY, 7X14 1

10 CY-119852- 21650 V-PULLEY, CRANKSHAFT 1

11 CY-129795 -21661 WASHER 1

12 C Y-121850 -21680 BOLT, V-PULLEY 1

13 C Y -12 1111- 215 0 1 BOLT, FLYWHEEL 6

14 CY-129635-21590 FLYWHEEL ASSY 1

16 CY-124550 -21600 GEAR, RING 1

17 CY-129508-22080 PISTON W/RING 4

19 CY-129004-22500 RING SET, PISTON 4

23 CY-129202-22300 PIN, PISTON(D26,L70) 4

24 CY-22252-000260 CIRCLIP 26 8

25 CY-7294 02-2 3100 ROD ASSY, CONNECTING 4

28 CY-121550-23200 BOLT, CONNECTING ROD 8

29 C Y-129 150 -23 60 1 METAL, CRANKPIN 4

31 CY-129100 -23910 METAL, PISTON PIN 4

32 C Y -12 9 15 0 -2 3 611 METAL.PIN US=0.25 4

34 CY-129508-22900 PISTON W/RING .25OS 4

36 CY-129004-22950 RING SET, PISTON .25 4

Part Number Description Qty

22

0CNP5-G38300

LEV.REF. PARTS NO. DESCRIPTION

Fig 10. Balancer

Notes

Lx490Lx Series

23

Fig 10. Balancer

Lx490Lx Series

Ref.

1 CY-129 795 -019 60 PIPE, KNOCK 2

2 CY-129457-28000 BALANCER ASSY 1

3 CY-12817 0-14150 NUT, CAM 1

4 CY-12185 0-21290 PIN 1

5 CY-129457-28011 CASE ASSY, BALANCER 1

8 CY-129400-28150 GEAR, BALANCER A 1

9 CY-729 490 -28510 SHAFT, BALANCER A 1

14 CY-729490-28520 SHAFT, BALANCER B 1

19 CY-23876-005000 PLUG, PT1/16 1

20 CY-26106 -0 80142 BOLT 8X 14 PLATED 4

21 CY-24311-000140 O-RING 1A P-14.0 1

22 CY-26106-080602 BOLT M 8X 60 PLATED 4

23 CY-26106-080802 BOLT M 8X 80 PLATED 2

Part Number Description Qty

24

0CNP5-G38300

Fig 11. Lub. Oil System

Notes

Lx490Lx Series

25

Fig 11. Lub. Oil System

Lx490Lx Series

Ref.

1 CY-129418-32000 PUMP ASSY, LUB.OIL 1

14 CY-129150-32020 GASKET, PUMP 1

15 CY-26450-060252 BOLT, M6X25 4

16 CY-129 468 -34 810 GUIDE, DIPSTICK 1

17 C Y-12 955 8- 34 82 0 DIPSTICK, LUB.OIL 1

18 CY-129150-35042 GASKET, PIPE 1

19 CY-129550-35090 PIPE ASSY, OIL INLET 1

24 C Y-26106 -08 0122 BOLT M 8X 12 PLATED 1

25 CY-26106 -0 80352 BOLT M 8X 35 PLATED 2

26 C Y-129 50 8- 33 010 COOLER ASSY, LUB.OIL 1

27 CY-129508-33050 O-RING 1

28 CY-129417-33110 NUT, OIL COOLER 1

29 CY-1290 06-3510 0 BRACKET ASSY, FILTER 1

30 CY-119802-35110 BRACKET, FILTER 1

31 C Y-12 9417 -35 150 STUD, L=67 1

32 C Y -12 9 15 0 - 35 111 GASKET, BRACKET 1

34 CY-129648-44400 JOINT, PT1/4 1

35 CY-129645-49030 PIPE, COOLER INLET 1

36 CY-1710 08- 03990 CLIP, HOSE 18.5 1

38 CY-23080-015000 CLAMP 1

39 C Y-26106-08 0202 BOLT M 8X 20 PLATED 3

40 C Y-129150 -3 5153 FILTER 80X80L 1

Part Number Description Qty

26

0CNP5-G38300

LEV.REF. PARTS NO. DESCRIPTION

Y

Fig 12. Lub. Oil Line

Notes

Lx490Lx Series

27

Fig 12. Lub. Oil Line

Lx490Lx Series

Ref.

1 CY-114250-39450 SWITCH, OIL PRESSURE 1

2 CY-129558 -39610 PIPE ASSY, LO RETURN 1

3 CY-123910 -3985 0 RE TAI NER 1

4 CY-129558-39640 LO-T,T/C RETURN 1

5 CY-129558 -396 51 ELBOW,3/8 LO RETURN 1

6 CY-123957-39671 JOINT, PIPE 1

7 CY-23000-025000 CLAMP 25 2

8 CY-2 4316- 000160 O-RING 4D P-16.0 1

9 CY-26106 -0 60122 BOLT M 6X 12 PLATED 2

10 CY-26106 -0 80122 BOLT M 8X 12 PLATED 1

11 C Y-12416 0 -39 140 BOLT, JOINT M10 1

12 C Y-1212 52 -391 50 BOLT, PIPE JOINT 1

13 C Y-12 955 8- 39 48 0 PIPE ASSY, LUB. OIL 1

15 C Y-11980 2-39 50 0 RETAINER, PIPE 1

16 C Y-1242 23 -3 99 00 R ETA IN ER 1

17 CY-129005-59830 BOLT ASSY, JOINT 1

18 CY-22190-08 0002 SEAL WASHER 8S 1

19 CY-23857-030000 JOINT BOLT 3 1

20 CY-22190-08 0002 SEAL WASHER 8S 1

21 CY-22190-100002 WASHER, 10 2

22 CY-23414-100000 GASKET 10, ROUND 2

23 CY-26106 -0 80122 BOLT M 8X 12 PLATED 1

24 CY-26366-060002 NUT M 6 1

25 CY-129792-39 410 VALVE ASSY, CHECK 4

31 C Y-129 553 -3 96 50 NOZZLE, COOLING 4

32 C Y-22351- 030 010 SPRING PIN 3X10 4

Part Number Description Qty

28

0CNP5-G38300

Fig 13. Cooling Water System

Notes

Lx490Lx Series

29

Fig 13. Cooling Water System

Lx490Lx Series

Ref.

1 CY-129263-42000 PUMP ASSY, WATER 1

2 CY-129150-42059 PAC KING 1

4 C Y-129 263 - 42120 PL ATE 1

8 C Y-129 150 -4 23 00 FLAGNE, C. W. PUMP 1

10 C Y-129 05 4- 42 32 0 O-RING 1

12 C Y-12 991 6- 49 740 PLUG, R03 2

13 C Y-24358 -240310 O-RING, 5 24031 1

14 CY-26106- 060202 BOLT M 6X 20 PLATED 2

15 C Y-26116-06 0162 BOLT 6X16 3

16 C Y-265 77- 06 0152 SCREW, M6X15 3

17 CY-129486-42050 GASKET, PUMP 1

18 CY-23414-080000 GASKET 8, ROUND 1

19 CY-26106-08 0122 BOLT M 8X 12 PLATED 1

20 CY-26106 -0 80552 BOLT M 8X 55 PLATED 3

21 CY-26106-080602 BOLT M 8X 60 PLATED 1

22 CY-129403-42380 V-PULLEY, WATER PUMP 1

23 CY-25132-004000 V-BELT A40 1

24 C Y-12 94 36 -4 474 0 FAN, COOLING 1

25 C Y-129 26 6- 4 476 0 SPA CER 1

26 CY-26014 -060162 BOLT M 6X 16 4

27 CY-26014-060302 BOLT W/WASHER 6X 30 4

28 C Y-129 155 -4 98 01 THERMOSTAT 1

29 C Y- 12 91 50 - 4 98 11 GASKET, THERMOSTAT 1

30 CY-129795 -49 551 GASKET, COVER 1

31 C Y-129 350 - 49 56 0 COVER, THERMOSTAT 1

32 C Y-26106 -08 0202 BOLT M 8X 20 PLATED 2

33 CY-121450-42450 PLUG M16 1

34 CY-124465-44950 GASKET, 16 1

35 C Y-124250-49351 THERMOMETER 1

36 C Y-129 150 -4 93 60 GASKET 10 1

37 C Y-129263-49610 PIPE, WATER A 1

39 CY-124722-59050 CLIP, HOSE 2

40 CY-129263-49620 PIPE, WATER B 1

42 CY-124722-59050 CLIP, HOSE 2

Part Number Description Qty

30

0CNP5-G38300

LEV.REF. PARTS NO. DESCRIPTION

Fig 14. Fuel Injection Pump

Notes

Lx490Lx Series

31

Fig 14. Fuel Injection Pump

Lx490Lx Series

Ref.

1 CY-729558 -51310 INJECTION PUMP ASSY 1

9 CY-129 00 8- 5190 0 COVER 1

10 CY-129 00 8- 51920 BOLT M6X10 2

11 CY-119802-5109 0 KEY, WOODRUFF 4X16 1

14 CY-158552-51151 FLANGE 1

38 CY-1586 00-51270 STOPPER, TAPPET 1

39 CY-158563-51281 O-RING 1

40 CY-158563-51281 O-RING 1

41 C Y-129509 -51390 SETTING, DELIVERY 4

50 C Y-158 563 -513 30 SPRING, DELIVERY 4

58 C Y-158 601- 5155 0 PLUG 1

59 C Y-1198 02-515 60 PLUG, BARREL 1

60 CY -1585 52-5 1571 PK(BARREL PLUG 3

61 C Y-158 552- 51571 PK(BARREL PLUG 1

62 C Y-158 557- 51570 PLUG 1

63 C Y-158 601 -5157 0 PLUG, WATER PUMP 1

64 C Y-158 552 -51580 LIFTER 1

65 C Y-1198 02- 51590 TIMER SET 1

66 CY-119 802-51590 TIMER CMP 1

69 CY-158553 -51670 O-RING, 1011 1

70 C Y-11980 2-516 80 BACKUP RING 1

71 C Y-1198 02-5169 0 RING 1

72 C Y-2435 6-19 020 0 PACKING, 19020 1

73 CY-24372-000150 RING, BACKUP T2 P 15 1

74 C Y-158552-516 00 PACKING, HEAD 1

75 C Y-158553-5163 0 SPRING, TIMER 1

77 CY-158553 -5164 0 ELEMENT, THERMO 1

78 C Y-158553-5166 0 O- RING ,P14 1

79 C Y-158553-5168 0 PACKING,TIMER 1

99 CY-158 601-51770 PISTON 1

Part Number Description Qty

Ref.

100 CY-158552-51781 SPRING, ACTUATOR 1

101 CY-1586 01-51790 PLUG 1

103 C Y-15855 3-5193 0 PL UG ,M 12 1

104 C Y-2219 0-1200 02 SEAL WASHER 12 1

105 C Y-2219 0-18 00 02 WASHER, 18 1

106 CY-158553 -51770 BO LT 4

109 CY-158552-52311 O-RING 1

110 CY-158552-52400 O-RING 4E S42 1

111 C Y-2219 0-1200 02 SEAL WASHER 12 2

112 C Y-2219 0-18 00 02 WASHER, 18 2

113 CY-22217-140000 SPRING WASHER 14 1

114 CY-22312-050140 PARALLEL PIN 5X14 2

115 CY-22351- 050010 SPRING PIN 5X10 2

117 CY-24311-000070 O-RING 1A P-7.0 1

118 C Y-2435 6-19 0180 O-RING 4D 19018 1

119 C Y-2435 6-19 020 0 PACKING, 19020 1

120 CY-26106 -0 60102 BOLT 6X 10 PLATED 1

122 CY-26450-080452 BOLT M 8X 45 4

123 CY-26776-140002 LOCK NUT M14 PLATED 1

126 CY-158553 -51551 JOINT, COOLING WATER 1

127 CY-1586 01-51650 JOINT, OVER FLOW 1

128 CY-158552 -51670 JOINT, OVER FLOW 1

130 C Y-158552- 52100 PUMP ASSY, FUEL FEED 1

131 C Y-158552-52500 O-RING, PUMP 1

132 CY-129916-59020 JOINT, PIPE 12 1

133 C Y-22190 -120 00 2 SEAL WASHER 12 2

134 CY-23857-060000 JOINT BOLT 6,PIPE 1

136 C Y-12 95 08 -512 50 RETAINER, PUMP 1

137 C Y-26106 -080202 BOLT M 8X 20 PLATED 1

138 C Y-26106 -080302 BOLT M 8X 30 PLATED 1

Part Number Description Qty

32

Fig 15. Governor

Notes

Lx490Lx Series

33

Fig 15. Governor

Lx490Lx Series

Ref.

3 CY-158 553- 61050 PACKING, CASE 1

5 CY-129155-51280 O-RING, S6 1

6 CY-158 553-519 30 P LUG , M12 1

22 CY-129255 -61410 NUT 1

23 CY-1198 07- 61420 SPRING, RETURN 1

24 C Y-11985 2-614 40 LEVER ASSY,REGULATOR 1

26 C Y-129 155 -61 46 0 BOLT, IDLE 1

61 C Y-1196 60 - 61901 RETAINER, SHAFT 1

65 C Y-2219 0-12 00 02 SEAL WASHER 12 1

68 CY-2610 6- 060102 BOLT 6X 10 PLATED 1

69 CY-26756-060002 LOCK NUT 6 1

78 C Y-1585 52- 6190 0 O-RING 1

84 CY-24341-000360 O-RING 1A S-36.0 1

85 CY-26106 -0 60142 BOLT M 6X 14 PLATED 2

86 CY-2610 6- 060142 BOLT M 6X 14 PLATED 3

87 C Y-26106-06 0202 BOLT M 6X 20 PLATED 10

88 CY-129 044 -610 60 COVER, GOVERNOR CASE 1

89 C Y-1198 52- 6108 0 SUPPORT, WIRE 1

132 C Y-1196 53-7 7950 SOLENOID, STOP 1

133 C Y-26106 -060142 BOLT M 6X 14 PLATED 2

Part Number Description Qty

34

0CNP5-G38300

16. FUEL INJECTION VALVE

LEV.REF. PARTS NO. DESCRIPTION

Y

Fig 16. Fuel Injection Valve

Lx490Lx Series

Notes

35

Fig 16. Fuel Injection Valve

Lx490Lx Series

Ref.

1 CY-729530 -53100 VALVE ASSY,INJECTION 4

2 CY-129937-53000 VALVE ASSY,INJECTION 4

5 CY-114250-53080 NUT, CASE 4

6 CY-12950 8-5310 0 HOLDER ASSY, NOZZLE 4

9 C Y- 114 25 0 - 5 312 0 SPRING, NOZZLE 4

10 C Y- 114 25 0 - 5 313 0 SEAT, SPRING 4

11 CY-114250 -53140 PLATE, STOP 4

12 C Y-1142 50-53210 PIN 8

13 C Y-11980 3-53 40 0 SHIM SET 4

40 C Y-123 907-116 01 SEAL 4

41 C Y-119305 -59 120 R ETA IN ER 2

44 C Y-129150-59131 BOLT M4X14,HEX.SCKT. 2

45 C Y-129 55 0- 5912 0 RETAINER, PIPE 1

48 C Y-129150-59131 BOLT M4X14,HEX.SCKT. 2

50 CY-12950 8-59 910 PIPE ASSY, INJECTION 1

51 CY-129508-59920 PIPE ASSY, INJECTION 1

52 CY-129508-59930 PIPE ASSY, INJECTION 1

53 CY-129508-59940 PIPE ASSY, INJECTION 1

54 C Y-123 907 -59 54 0 BOLT, JOINT M6 5

55 CY-129508-59550 PIPE ASSY, RETURN 1

56 C Y-123 90 7-59 55 0 PA CKI NG 5

57 C Y-12 39 07-5 95 60 JOINT 1

58 CY-129508-59570 PIPE ASSY, RETURN 1

59 CY-124722-59050 CLIP, HOSE 2

60 CY-129508- 59510 PIPE, FUEL RETURN 1

61 CY-22190-08 0002 SEAL WASHER 8S 1

Part Number Description Qty

36

0CNP5-G38300

A

Y

Fig 17. Starting Motor

Notes

Lx490Lx Series

37

Fig 17. Starting Motor

Lx490Lx Series

Ref.

1 CY-129429-77011 STARTER ASSY 1

2 CY-X0283060061 ROLLER 5

3 C Y-X9 49 056 1370 NUT 1

4 C Y-X9 49 120 024 0 BALL 1

5 CY-129 429-7 7210 YOKE ASSY 1

6 CY-129429-77220 ARMATURE ASSY 1

7 CY-129429-77230 BEARING 1

8 C Y-129 129 -77 240 BEARING 1

10 CY-129429-77250 PINION ASSY 1

11 C Y-129 129 -77 26 0 R ETA IN ER 1

13 C Y-12 9129 -77 27 0 PINION 1

14 CY-129429-77270 FRAME 1

15 CY-129429-77280 HOLDER ASSY 1

16 CY-129429-77290 SPRING 4

18 CY-129429-77310 SCREW 2

19 CY-129429-77320 SCREW 2

20 CY-129429-77330 B OLT 2

21 C Y-129 129 -77 34 0 SPRING 1

22 CY-129429-77340 CAP 1

23 C Y-129 129 -77 350 O-RING 2

24 CY-129429-77350 GASKET 1

25 C Y-129 129 -77 362 COVER 1

26 CY-129429-77360 COVER 1

27 C Y-12 9129 -7 737 0 NUT 1

28 CY-129429-77370 PLUNGER 1

29 CY-129429-77380 STARTER KIT 1

30 CY-129429-77390 STARTER KIT 1

31 C Y- 2 6116 -12 0 2 52 BOLT M12X 25 PLATED 2

Part Number Description Qty

38

0CNP5-G38300

A

Fig 18. Generator

Lx490Lx Series

Notes

39

Fig 18. Generator

Lx490Lx Series

Ref.

1 CY-129 795 -019 00 STUD 1

2 CY-119751-77 200 GENERATOR, 12V-40A 1

3 CY-X02155124 40 COVER 1

4 CY-X1214 00143 0 FLAME ASSY, DRIVE 1

5 CY-119620 -792 00 BALL BEARING 1

6 CY-119620 -79210 PLATE, RETAINER 1

7 CY-119620 -792 20 SCREW 4

8 CY-119620 -792 30 STUD 2

9 CY-X1215011050 FLAME ASSY, REAR 1

10 CY-X9 4905 61001 NUT 1

11 CY-119620 -77 380 ROTOR ASSY 1

12 C Y-11962 0-7 9240 BALL BEARING 1

13 C Y-11962 0-7 9250 COVER, BEARING 1

14 C Y-1196 20 -77461 PULLEY 1

15 C Y-11962 0-7 7471 NUT 1

16 C Y-1196 20 -7749 0 COLLAR 1

17 C Y-129423 -77710 REGULATOR ASSY 1

18 C Y-1196 20 -7926 0 HOLDER 1

19 CY-129052-79270 HOLDER, BRUSH 1

20 C Y-1196 20 -7748 0 BRUSH ASSY 2

21 CY-119620 -792 80 SPRING 2

22 C Y-1196 20 -7929 0 SCREW 6

23 CY-119620 -793 00 SCREW 1

24 C Y-11962 0-7 9310 BO LT 3

25 CY-119620 -793 20 SCREW 2

26 C Y-11962 0-7933 0 BO LT 2

27 C Y-11962 0-7 934 0 BUSH, INSULATION 1

28 C Y-1196 20 -7935 0 NUT 2

29 C Y-1196 20 -79360 WASHER, THRUST 1

30 CY-26306-100002 NUT, M10 1

31 CY-129107-77330 ADJUSTER, BELT 1

32 CY-124732-77340 SPAC ER 1

33 C Y-12 997 2-7 73 41 BOLT, ADJUSTER 1

Part Number Description Qty

40

Tractor Section Index

Lx490Lx Series

Fig. No. Group Name

Engine Control Section

2. Engine Related Lx490

4. Engine Accessories Lx490

5. Grommet

6. Accelerator Lever

7. Foot Accel

8. Exhaust

9. Fuel Tank

10. Tank Parts

Front Axle Section

11. Front Axle Bracket

12 . Front Support

13. Tie Rod

14. Ring Gear

15. Dierential Gear

16. Propeller Shaft

17. Front Shaft 1

18. Front Axle Case

19. Front Gear Case

20. Front Shaft 2

21. Front Spindle

22. Front Wheel Tire R1

23. Front Wheel Tire R3

24. Front Wheel Tire R4

25. Hub Bolt

26. Steering Column

27. Steering Wheel

28. Pst Cylinder

29. Pst Valve

30. Pst Piping

31. Pst Hose

Transmission Section

32. Clutch Housing

33. Docking Bolt

34. Damper Disc

35. Clutch Link

36. Transmission Case

37. Center Plate

38. Reverser Valve

Fig. No. Group Name

39. PTO Valve

40. Front Cover

41. Main Shaft

42. Driven Shaft

43. Counter Shaft

44. Reduction Shaft

45. Power Reverser

46. PTO Clutch

47. PTO Drive Shaft

48. PTO Shaft

49. Main Lever

50. Slide Plate

51. Main Change Shift

52. Reverser Wire

53. Range Shift

54. Sub Lever

55. Front Drive

56. Change Arm

57. Front Shift

Rear Axle Section

58. Ring Gear 2

59. Dierential Gear 2

60. Dierential Carrier

61. Rear Housing

62. Dierential Lock

63. Dierential Lock Pedal

64. Final Pinion

65. Final Gear

66. Rear Axle Shaft

67. Rear Wheel Tire R1

68. Rear Wheel Tire R3

69. Rear Wheel Tire R4

70. Hub Bolt 2

71. Brake

72. Pedal

73. Brake Link

Hydraulic Control Section

74. Hydraulic Pump

75. Hyd. Cylinder Housing

41

Tractor Section Index

Lx490Lx Series

Fig. No. Group Name

76. Hyd. Lift Docking

7 7. Piston

78. Lift Crank

79. Control Valve

80. Relief Valve

81. Stop Valve

82. Safety Valve

83. Loader Valve

84. Breather

85. Lever, Scv

86. Hydraulic Operation 1

8 7. Hydraulic Control

88. Hydraulic Operation 2

89. Lift Lever

90. Hydraulic Line

91. Hydraulic Filter

92. Hydraulic Line - Loader

93. Hydraulic Line - Loader PBK Rear Remote

Electrical Parts Section

94. Harness

95. Harness

97. Battery

99. Battery Clamp

100 . Switch

101. Switch 2

102. Switch 3

103. Lamp

104 . Front Lamp

105. Meter

106 . Relay

Fittings Section

10 7. Front Frame

108 . Hood Frame

109. Hood

110 . Dashboard

111. Column Cover

112 . Fender

113 . Fender Parts

114 . Floor

Fig. No. Group Name

115 . Step Stay 1

116 . Insulator

117. Step Stay 2

118 . Floor Attachment

119 . Seat

120 . Label

123 . Label Lx490

124 . Label(Pl)

125 . SMV

HItch Section

126 . 3P Link Kit

12 7. Top Link

128 . Drawbar Hitch

129 . PTO Guard

Safety Frame Section

130 . Roll Guard

Optional Section

132 . Front Hitch

133 . Heater Block

134 . Front Weight

135 . Extra Hitch

136 . Heater TM

13 7. Work Lamp

138 . Rear Remote Kit

139 . Rear Coupler Kit

42

0CNP5-G37900

2. ENGINE RELATED

LEV.REF. PARTS NO. DESCRIPTION

Fig 2. Engine Related Lx490

Lx490Lx Series

43

Fig 2. Engine Related Lx490

Lx490Lx Series

Ref.

1 CY-129509-03080 HOSE ASSY, BREATHER 1

2 CY-129509-03090 HOSE, BREATHER 1

3 CY-129 410- 03990 CLAMP 22 2

4 CY-129263 -44510 TANK ASSY, SUB 1

5 CY-11922 5- 52102 PUMP ASSY, FUEL FEED 1

6 C Y-129 00 4 -55 612 BRACKET, FILTER 1

7 CY-1198 02-5 570 0 SEPARATOR ASSY 1

8 CY-12910 0-55690 RING, RETAINING 1

9 CY-1198 02-5 5710 ELEMENT 1

10 CY-1198 02-5 5730 CUP ASSY 1

11 CY-24311-000160 O-RING 1A P-16.0 1

12 C Y-24321- 000 650 O-RING 1A G-65.0 1

13 C Y-11980 2-55 801 FILTER, FUEL 1

Part Number Description Qty

44

0CNP5-G37900

4. ENGINE ACCESSORIES

LEV.REF. PARTS NO. DESCRIPTION

Fig 4. Engine Accessories Lx490

Lx490Lx Series

45

Fig 4. Engine Accessories Lx490

Lx490Lx Series

Ref.

1 CY-1A7140-00600 RADIATOR ASSY 1

2 CY-1A7180 -01050 RUBBER,RADIATOR 2

3 CY-1A825 0- 01210 TUBE,COOLING WATER A 1

4 C Y-1A7 30 0 -012 20 PIPE, COOLING WATER 1

5 CY-1A7300-01230 PIPE, COOLING WATER 1

6 C Y-1A82 60 -012 41 CW-T, LO COOLER OUT 1

7 CY-1A8250 -01250 SCREEN, RADIATOR 1

8 CY-1A8260-01260 JOINT, WATER COOLING 1

9 CY-194150 -0 1270 SPACER 20 1

10 CY-1A8250 -01500 SHROUD M ASSY, FAN 1

11 CY-198 280 -0 447 0 JOINT 1

12 C Y-1A8 240 - 04 620 CLAMP, FUEL HOSE 1

13 C Y-1A8260 -05100 CLEANER ASSY, 6IN D 1

14 C Y-129 418 -125 30 LABEL, MARK 2

15 C Y-12 99 00 -12 530 COVER ASSY 1

16 C Y-1198 08 -1254 0 VALVE, UNLOADER 1

17 C Y-12 90 62 -125 60 ELEMENT 1

18 C Y-1190 05 -12571 ELEMENT, INNER 1

19 C Y-1A8275 -0553 0 PLATE,SHUTTER,84T 1

20 CY-1A824 0- 05810 COVER, BELT L 1

21 CY-1A8240-05820 COVER, BELT R 1

22 C Y-1A718 0- 06 201 PIPE A,INTAKE 1

23 CY-1A826 0- 06210 HOSE ASSY, INTAKE B 1

24 C Y-129410- 03990 CLAMP 22 1

25 CY-1A8260-06220 HOSE, INTAKE B 1

26 CY-1A8260-06230 JOINT, BREATHER 1

27 CY-1A8260-06240 SPRING, 1

28 C Y-1A8240 -154 60 BRACKET, CLAMP 1

29 C Y-1982 20 -379 00 PIN 8X24 1

Part Number Description Qty

Ref.

30 CY-121750-49150 PIPE, C. WATER 1

31 CY-175022- 49750 CLIP 37, HOSE 2

32 C Y-194 44 0 -5162 0 CLAMP, WIRE HARNESS 1

33 C Y-194 68 0- 51670 BAND 2

34 CY-194 68 0- 51670 BAND 1

35 C Y-1A76 01-5 392 0 URETHANE,SIDE LAMP 1

36 CY-114270 -59010 CLIP, HOSE 2

37 C Y-114270 -59010 CLIP, HOSE 4

38 CY-114270 -59010 CLIP, HOSE 2

39 CY-23000-019000 CLAMP 19 1

40 CY-23000-019000 CLAMP 19 1

41 CY-23000-035000 CLAMP 35 2

42 CY-23000-035000 CLAMP 35 2

43 CY-23000-070000 CLAMP 70 2

44 CY-Y23000080000 CLAMP 80 1

45 C Y-239 80-73020 0 HOSE 7.3X200,BRAIDED 1

46 C Y-239 80 -730 400 FUEL PIPE 7.3X400 2

47 CY-23980-730600 FUEL PIPE 7.3X600 1

48 C Y-26106 -060202 BOLT M 6X 20 PLATED 4

49 CY-26106-08 0122 BOLT M 8X 12 PLATED 2

50 CY-26106 -0 80122 BOLT M 8X 12 PLATED 3

51 CY-26106 -0 80162 BOLT M 8X 16 PLATED 2

52 C Y-26106-08 0162 BOLT M 8X 16 PLATED 3

53 C Y-26106 -08 0162 BOLT M 8X 16 PLATED 1

54 CY-26106 -080302 BOLT M 8X 30 PLATED 2

55 C Y-26106 -100202 BOLT M10X 20 PLATED 1

56 C Y-198071- 61890 NUT 6,SPEED 1

57 C Y-26106-06 0202 BOLT M 6X 20 PLATED 1

Part Number Description Qty

46

0CNP5-G37900

5. GROMMET

LEV.REF. PARTS NO. DESCRIPTION

GROMMET 24194180-6198011 111

Fig 5. Grommet

Lx490Lx Series

Ref.

1 CY-194180 - 6198 0 GROMMET 24 1

Part Number Description Qty

47

0CNP5-G37900

6. ACCEL LEVER

LEV.REF. PARTS NO. DESCRIPTION

Fig 6. Accelerator Lever

Lx490Lx Series

Ref.

1 CY-1A825 0- 0110 0 LEVER ASSY, ACCEL 1

2 CY-19474 0- 0016 0 WASHER 10, CONICAL 3

3 C Y- 1A 8 25 0 - 0 1110 LEVER, ACCEL 1

4 CY-198 20 0- 0126 0 PLATE, FRICTION 1

5 CY-1A8250 -02150 SUPPORT ASSY, ACCEL 1

6 CY-22137-100000 WASHER 10,POLISHED 1

7 CY-22157-100000 WASHER 10 1

8 CY-26716-100002 NUT 10 2

9 CY-1A8250 -01150 CABLE ASSY, HAND 1

10 CY-198 071- 01160 RUBBER,WIRE RETAING 1

11 CY-198 253 -01190 KNOB, THROTTLE LEVER 1

12 C Y-198245 -51210 GROMMET 25 1

13 CY-1C6281-52310 PIN 6,COME-OFF SNAP 1

14 C Y-198 071-5 8810 GROMMET 8 1

15 CY-22137-060000 WASHER 6, POLISHED 1

16 CY-2 6106 -0 80162 BOLT M 8X 16 PLATED 2

Part Number Description Qty

48

0CNP5-G37900

7. FOOT ACCEL

LEV.REF. PARTS NO. DESCRIPTION

Fig 7. Foot Accel

Lx490Lx Series

Ref.

1 CY-198 20 0- 01210 CABLE, CONTROLE 1

2 C Y-1A8 240 - 0130 0 CONTROL UNIT, FOOT 1

3 CY-165001-22950 RUBBER 1

4 CY-1949 90 -2213 0 NUT W/WASHER 6 1

5 CY-1A830 0-51210 BAND, REPEAT 1

6 CY-1946 80 -516 70 BAND 1

7 CY-198 36 0-556 30 SPRING,RETURN 1

8 CY-26106 -0 60122 BOLT M 6X 12 PLATED 1

9 CY-26116-060404 BOLT M 6X 40 PLATED 1

Part Number Description Qty

49

0CNP5-G37900

8. EXHAUST

LEV.REF. PARTS NO. DESCRIPTION

Fig 8. Exhaust

Lx490Lx Series

Ref.

1 CY-1A825 0- 03100 MUFFLER PIPE 1

2 CY-129 052 -13550 GASKET 1

3 CY-26106 -0 80202 BOLT M 8X 20 PLATED 3

Part Number Description Qty

50

0CNP5-G37900

9. FUEL TANK

LEV.REF. PARTS NO. DESCRIPTION

TANK, FUEL ASSY1A8250-0410011 111 TANK, FUEL1A8250-0411022 111 CAP, FUEL TANK1A8160-0413023 111

SCREW, 5 X 141A7180-0418024 555 FUEL SENDER ASSY1A8275-5660025 111 GASKET194420-5662036 111

BAND, TANK REAR L1A8250-0421017 111 BAND, TANK REAR R1A8250-0422018 111 BUFFER, BAND1A8250-0423019 222 CLAMP198153-04670110 222 WASHER 822157-080000111 222 U-NUT M 826347-080002112 444 U-NUT M 826347-080002113 222

Fig 9. Fuel Tank

Lx490Lx Series

51

Fig 9. Fuel Tank

Lx490Lx Series

Ref.

1 C Y-1A82 50 -0 4100 TANK, FUEL ASSY 1

2 C Y-1A82 50 -0 4110 TANK, FUEL 1

3 C Y-1A816 0- 0413 0 CAP, FUEL TANK 1

4 C Y-1A718 0- 041 80 SCREW, 5 X 14 5

5 C Y-1A82 75- 566 00 FUEL SENDER ASSY 1

6 CY-194420 -5 662 0 GASKET 1

7 CY-1A825 0- 04210 BAND, TANK REAR L 1

8 CY-1A8250-04220 BAND, TANK REAR R 1

9 CY-1A8250-04230 BUFFER, BAND 2

10 CY-198 153- 04 670 CLAMP 2

11 CY-22157-080000 WASHER 8 2

12 CY-26346-080002 U-NUT M 8 4

13 CY-26346-080002 U-NUT M 8 2

Part Number Description Qty

52

0CNP5-G37900

10. TANK PARTS

LEV.REF. PARTS NO. DESCRIPTION

A

Y

Fig 10. Tank Parts

Lx490Lx Series

53

Fig 10. Tank Parts

Lx490Lx Series

Ref.

1 CY-1A8250 -04250 ANGLE ASSY, TANK 2

2 C Y-1A82 50 -0 44 30 HOSE, FUEL 1

3 C Y-1A82 50 -0 428 0 TUBE, CORRUGATE 13 2

4 C Y-1A82 50 -0 48 70 CLAMP, HOSE 1

5 CY-1A825 0-21180 COVER, HOUSING 1

6 CY-1949 90 -2214 0 NUT W/WASHER 8 2

7 CY-1A7130 -48110 CLAMP, PIPE 1

8 C Y-1A82 50 -0 428 0 TUBE, CORRUGATE 13 2

9 CY-1A830 0-51210 BAND, REPEAT 1

10 CY-1946 80 -516 70 BAND 2

11 CY-1946 80 -516 70 BAND 5

12 C Y-194 68 0- 51670 BAND 1

13 C Y-114270-59 010 CLIP, HOSE 2

14 CY-114270 -59010 CLIP, HOSE 2

15 C Y-114270- 59010 CLIP, HOSE 2

16 CY-114270 -59010 CLIP, HOSE 2

17 CY-1A8250-63890 SEAL,FENDER 2

18 CY-1A8250-63800 BRACKET ASSY, TANK 1

19 C Y-1A825 0- 65 870 BRACKET, SMV ASSY 1

20 CY-22157-080000 WASHER 8 2

21 CY-22157-080000 WASHER 8 2

22 CY-23980-730550 HOSE 7.3* 550 1

23 C Y-2 39 80 -7 3170 0 HOSE, 7.3X1700 2

24 C Y-26106 -06 0122 BOLT M 6X 12 PLATED 2

25 CY-26106 -0 80162 BOLT M 8X 16 PLATED 2

26 CY-26106-08 0162 BOLT M 8X 16 PLATED 1

27 C Y-26106 -08 0202 BOLT M 8X 20 PLATED 2

28 CY-26106 -0 80702 BOLT M 8X 70 PLATED 1

29 CY-26346-080002 U-NUT M 8 2

30 CY-1A7882-85630 HOLDER, SMV 1

31 CY-26106 -0 80202 BOLT M 8X 20 PLATED 2

32 C Y-1A8 250 - 042 90 CUSHION,TANK 1

Part Number Description Qty

54

0CNP5-G37900

11. FRONT AXLE BRACKET

LEV.REF. PARTS NO. DESCRIPTION

Fig 11. Front Axle Bracket

Lx490Lx Series

Ref.

1 C Y- 1A 8 25 0 - 1110 0 BRACKET ASSY, F AXLE 1

2 CY-1A8160 -11520 BOLT, M12X34 14

3 CY-1A8 275 -1745 0 GUARD, PST CYLINDER 1

4 CY-1A6680-85980 BOLT 14*45 8

5 CY-26106 -0 80162 BOLT M 8X 16 PLATED 1

6 CY-2 6116 -16060 4 BOLT M16X 60 PLATED 1

7 CY-2 6716-16 0002 NUT M16 1

Part Number Description Qty

55

0CNP5-G37900

12. FRONT SUPPORT

LEV.REF. PARTS NO. DESCRIPTION

Fig 12. Front Support

Lx490Lx Series

Ref.

1 CY-1A8 275 -11 600 SUPPORT ASSY,FRONT F 1

2 CY-1A7 180 -1162 0 BUSH, 60X65X40 1

3 CY-1A7 180 -1163 0 SEAL, VB607005 1

4 CY-24761-010000 NIPPLE M6F, GREASE 1

5 CY-1A7 180 -1165 0 WASHER, 60X4 1

6 CY-1A8 275 -117 00 SUPPORT ASSY,FRONT R 1

7 CY-194181-1156 0 SEAL VB75 85 6.5,OIL 1

8 CY-1946 41-1163 0 BUSH 75X80X25 1

9 CY-24761-010000 NIPPLE M6F, GREASE 1

10 CY-198 283 -134 80 WASHER 62X75X3 1

Part Number Description Qty

56

0CNP5-G37900

13. TIE ROD

LEV.REF. PARTS NO. DESCRIPTION

Fig 13. Tie Rod

Lx490Lx Series

57

Fig 13. Tie Rod

Lx490Lx Series

Ref.

1 CY-1A8 275 -12310 TIE-ROD ASSY, L 1

2 CY-1A8 275 -123 30 END ASSY, ROD L 1

3 CY-1A8 275 -124 40 COVER, DUST 1

4 CY-1A8 275 -12450 RING, COVER 1

5 CY-1A8 275 -124 60 GREASE NIPPLES 1

6 CY-1A8 275 -1251 0 END ASSY, RACK L 1

7 CY-1A8 275 -125 80 COVER, DUST 1

8 CY-1A8 275 -125 90 RING, COVER 1

9 CY-1A8 275 -126 00 C L I P, 1

10 CY-1A8 275 -12610 NUT, M20 1

11 CY-1A8 275 -123 20 TIE-ROD ASSY, R 1

12 C Y-1A8 275-12 34 0 END ASSY, ROD R 1

13 C Y-1A8275 -12440 COVER, DUST 1

14 C Y-1A82 75-124 50 RING, COVER 1

15 C Y-1A82 75-124 60 GREASE NIPPLES 1

16 C Y-1A8275 -125 20 END ASSY, RACK R 1

17 C Y-1A8 275-125 80 COVER, DUST 1

18 C Y-1A8275 -1259 0 RING, COVER 1

19 C Y-1A82 75-126 00 CL I P, 1

20 C Y-1A82 75-12610 NUT, M20 1

21 CY-1A8 275 -1247 0 NUT,CASTLE 2

22 CY-22417-400400 COTTER PIN 4.0X40 2

Part Number Description Qty

58

0CNP5-G37900

14. RING GEAR

LEV.REF. PARTS NO. DESCRIPTION

Fig 14. Ring Gear

Lx490Lx Series

Ref.

1 CY-1A8 275 -1310 0 GEAR ASSY, RING 1

2 CY-1A7 180 -13150 COLL AR, 1

3 CY-1A7 180 -1338 0 COLLAR 58X62X4.8 1

4 CY-1A7 180 -13390 COLLAR 58X62X4.9 1

5 CY-1A7 180 -1340 0 COLLAR 58X62X5.0 2

6 C Y-1A718 0-13 410 COLLAR 58X62X5.1 1

7 CY-1A7 180 -13420 COLLAR 58X62X5.2 1

8 CY-198 251-13 670 COLLAR 1

9 C Y-24141-3 20070 ROLLER BEARING 2

10 CY-24341-000315 O-RING, 1A S31.5 1

Part Number Description Qty

59

0CNP5-G37900

15. DIFFERENTIAL GEAR

LEV.REF. PARTS NO. DESCRIPTION

HOUSING ASSY, DIFF.1A7180-1320111 111 HOUSING,DIFFERENTIAL1A7180-1321122 111 PINION, DIFFERENTIAL194321-1323023 222

LINER, DIFFERENTAIL194465-1324024 222 GEAR, DIFF. SIDE194321-1325025 222 WASHER194465-1326026 222

SHAFT, DIFF. PINION194321-1327027 111 SPRING PIN 6X4022351-06004028 111 COLLAR, DIFFERENTIAL1A7180-1325019 111 SHIM, A DIFF1A7180-13260110 222 SHIM, B DIFF1A7180-13270111 333 BOLT M 8X 20 PLATED198165-21490112 888 BALL BEARING24101-060174113 222

Fig 15. Dierential Gear

Lx490Lx Series

Ref.

Part Number Description Qty

1 CY-1A7 180 -13201 HOUSING ASSY, DIFF. 1

2 CY-1A7 180 -13211 HOUSING,DIFFERENTIAL 1

3 CY-194321-132 30 PINION, DIFFERENTIAL 2

4 CY-19446 5-132 40 LINER, DIFFERENTAIL 2

5 CY-194321-132 50 GEAR, DIFF. SIDE 2

6 CY-19446 5-132 60 WASHER 2

7 CY-194321-13270 SHAFT, DIFF. PINION 1

8 CY-2 2351- 060 040 SPRING PIN 6X40 1

9 CY-1A7 180 -13250 COLLAR, DIFFERENTIAL 1

10 CY-1A7 180 -13260 SHIM, A DIFF 2

11 CY-1A7 180 -13270 SHIM, B DIFF 3

12 C Y-198165 -2149 0 BOLT M 8X 20 PLATED 8

13 C Y-24101-060174 BALL BEARING 2

60

0CNP5-G37900

16. PROPELLER SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 16. Propeller Shaft

Lx490Lx Series

61

Fig 16. Propeller Shaft

Lx490Lx Series

Ref.

1 CY-1A7 180 -1330 0 SHAFT, PROPELLER 1

2 CY-1A7 140 -14610 COVER,SHAFT FRONT 1

3 CY-198 241-14 650 BOOT, RUBBER 1

4 CY-1A8 275 -1465 0 COVER, SHAFT 1

5 CY-1946 40 -2613 0 COUPLING 3

6 C Y-1A82 75-2 8410 SHAFT, DRIVE 1

7 C Y-1A82 75-2 842 0 RETAINER, BEARING 1

8 C Y-1A82 75-2 843 0 COVER, SHAFT REAR 1

9 CY-1E9170-54811 BOLT,REAMER 8X25 2

10 CY-22217-080000 WASHER, 8 2

11 CY-22242-000300 CIRCLIP 30 2

12 CY-22242-000300 CIRCLIP 30 2

13 CY-22252-000550 CIRCLIP 55 1

14 CY-23000-060000 CLAMP 60 2

15 C Y-24104- 0600 64 BALL BEARING 1

16 CY-24321-000500 O-RING 1A G-50.0 1

17 CY-24321-000500 O-RING 1A G-50.0 2

18 CY-24321-000500 O-RING 1A G-50.0 1

19 CY-26106-08 0122 BOLT M 8X 12 PLATED 1

20 CY-26106 -0 80122 BOLT M 8X 12 PLATED 2

Part Number Description Qty

62

0CNP5-G37900

17. FRONT SHAFT(1

LEV.REF. PARTS NO. DESCRIPTION

Fig 17. Front Shaft 1

Lx490Lx Series

Ref.

1 CY-1A7 180 -13520 PINION, 1ST SHAFT 12 2

2 CY-1A7 180 -1356 0 SHAFT L,FRONT 1ST 1

3 CY-1A7 180 -13570 SHAFT R,FRONT 1ST 1

4 CY-1A7 180 -1358 0 BEARING, HR6209UR 4

Part Number Description Qty

63

0CNP5-G37900

18. FRONT AXLE CASE

LEV.REF. PARTS NO. DESCRIPTION

Fig 18. Front Axle Case

Lx490Lx Series

Ref.

1 CY-1A8 275 -13610 CASE , FRONT AXLE 1

2 CY-22252-000620 CIRCLIP 62(H) 1

3 CY-24421-45620 9 SEAL TC 456209, OIL 1

Part Number Description Qty

64

0CNP5-G37900

19. FRONT GEAR CASE

LEV.REF. PARTS NO. DESCRIPTION

Fig 19. Front Gear Case

Lx490Lx Series

65

Fig 19. Front Gear Case

Lx490Lx Series

Ref.

1 CY-1940 66 -136 40 PLUG 20 1

2 CY-1A7180137101 HOUSING, FRONT GEAR 1

3 CY-1A8 275 -137 20 HOUSING, FRONT GEAR 1

4 CY-198 072 -13760 SEAL QLF709521.5 2

5 CY-1A8 275 -1376 0 BOLT, 10X28 4

6 CY-1A8 275 -137 70 GEARBOX, FRONT L 1

7 CY-1A8 275 -1378 0 GEARBOX, FRONT R 1

8 CY-1C7100-15100 CAP,SEALING 90 2

9 C Y-1C6 90 0 -2312 0 BOLT M14X10,DRAIN 2

10 C Y-1C690 0 -2315 0 WASHER 2

11 CY-194151-3 667 0 PLUG PT02 2

12 CY-22252-000850 CIRCLIP 85 2

13 CY-22252-000900 CIRCLIP 90 2

14 CY-22252-000950 CIRCLIP 95 2

15 C Y-22312-10018 0 PARALLEL PIN 10X 18 2

16 CY-24101-06 0124 BALL BEARING 2

17 C Y-24101-0 6209 4 BALL BEARING 2

18 CY-24311-000180 O-RING 1A P-18.0 1

19 CY-24321-001300 O-RING 1A G-130.0 2

20 CY-26106 -1003 02 BOLT M10X 30 PLATED 16

21 CY-26450-080122 BOLT 8X 12 2

22 CY-26756-100002 LOCK NUT M10 PLATED 4

Part Number Description Qty

66

0CNP5-G37900

20. FRONT SHAFT(2

(C)=LX490

(B)=LX450

(A)=LX410

LEV.REF. PARTS NO. DESCRIPTION

GEAR, 2ND SHAFT 151A7180-1382011 222 PINION, FAINAL 111A7180-1383012 222 SHAFT, FRONT 2ND1A7180-1387013 222

BEARING, TM207UR1A7180-1388014 222 BALL BEARING24104-06210415 222

Fig 20. Front Shaft 2

Lx490Lx Series

Ref.

Part Number Description Qty

1 CY-1A7 180 -1382 0 GEAR, 2ND SHAFT 15 2

2 CY-1A7 180 -1383 0 PINION, FAINAL 11 2

3 CY-1A7 180 -13870 SHAFT, FRONT 2ND 2

4 CY-1A7180-13880 BEARING, TM207UR 2

5 CY-24104 -062104 BALL BEARING 2

67

0CNP5-G37900

21. FRONT SPINDLE

LEV.REF. PARTS NO. DESCRIPTION

Fig 21. Front Spindle

Lx490Lx Series

Ref.

1 CY-1A7180137901 CASE, FRONT BEARING 2

2 CY-1A7 180 -1384 0 GEAR, FAINAL 49 2

3 C Y-1A718 0141101 SPINDLE, FRONT 2

4 CY-198 20 0-1421 0 RING, HALF TIMBER 4

5 CY-198 475 -3266 0 SEAL QLNY527514.5 2

6 CY-24101-062084 BALL BEARING 2

7 CY-24101-062094 BALL BEARING 2

8 CY-24321- 002 300 O-RING, 1A G230.0 2

9 CY-26106 -100302 BOLT M10X 30 PLATED 16

Part Number Description Qty

68

0CNP5-G37900

22. FRONT WHEEL TIRE R1

LEV.REF. PARTS NO. DESCRIPTION

Fig 22. Front Wheel Tire R1

Lx490Lx Series

Ref.

1 CY-1A8170 -1430 0 R1 TIRE KIT,FRONT L 1

2 CY-1A8170 -14310 R1 TIRE 8-16 1

3 CY-1A8170 -1433 0 R1 WHEEL F 1

4 CY-1A8170 -14350 VALVE, FRONT TIRE 1

5 CY-1A8170 -144 00 R1 TIRE KIT,FRONT R 1

6 CY-1A8170 -14310 R1 TIRE 8-16 1

7 CY-1A8170 -1433 0 R1 WHEEL F 1

8 CY-1A8170 -14350 VALVE, FRONT TIRE 1

Part Number Description Qty

69

0CNP5-G37900

23. FRONT WHEEL TIRE R3

LEV.REF. PARTS NO. DESCRIPTION

R3 TIRE KIT,FRONT1A8170-1450011 222 VALVE, FRONT TIRE1A8170-1435022 222 R3 TIRE 27X10.5-151A8170-1451023 222

R3 WHEEL F1A8170-1453024 222

Fig 23. Front Wheel Tire R3

Lx490Lx Series

Ref.

1 CY-1A8170 -1450 0 R3 TIRE KIT,FRONT 2

2 CY-1A8170 -14350 VALVE, FRONT TIRE 2

3 CY-1A8170 -14510 R3 TIRE 27X10.5-15 2

4 CY-1A8170 -1453 0 R3 WHEEL F 2

Part Number Description Qty

70

0CNP5-G37900

24. FRONT WHEEL TIRE R4

LEV.REF. PARTS NO. DESCRIPTION

Fig 24. Front Wheel Tire R4

Lx490Lx Series

Ref.

1 CY-1A8 250 -1470 0 TIRE KIT,L R4 FRONT 1

2 CY-1A8 250 -14710 TIRE,R4 10-16.5-6PR 1

3 CY-1A8 250 -1473 0 WHEEL,R4 16.5X8.25 1

4 CY-1A8 250 -1474 0 VALVE,TIRE R4 FRONT 1

5 CY-1A8 250 -1480 0 TIRE KIT,R R4 FRONT 1

6 CY-1A8 250 -14710 TIRE,R4 10-16.5-6PR 1

7 CY-1A8 250 -1473 0 WHEEL,R4 16.5X8.25 1

8 CY-1A8 250 -1474 0 VALVE,TIRE R4 FRONT 1

Part Number Description Qty

71

0CNP5-G37900

25. HUB BOLT

LEV.REF. PARTS NO. DESCRIPTION

Fig 25. Hub Bolt

Lx490Lx Series

Ref.

1 C Y-19813 3- 3413 0 BOLT 14X30 12

Part Number Description Qty

72

0CNP5-G37900

26. STEERING COLUMN

LEV.REF. PARTS NO. DESCRIPTION

A

Y

Fig 26. Steering Column

Lx490Lx Series

73

Fig 26. Steering Column

Lx490Lx Series

Ref.

1 CY-1A8 240 -1550 0 COLUMN UNIT,STEERING 1

2 CY-1A8 240 -1524 0 BEARING, 6904LLU 1

3 CY-1A8 240 -1532 0 SHAFT, STEERING 1

4 CY-1A8 240 -156 00 COLUMN ASSY, STG 1

5 CY-24550-015080 BEARING, 15 X 8 2

6 C Y-1A82 40 -270 30 COLLAR, 8.2X14X5.3 2

7 CY-1A8240-27050 COLLAR, 12X8X10 1

8 C Y-1A82 40 -270 90 PIN, CONNECTING 1

9 CY-198 20 0-27 240 SPRING, RETURN 1

10 CY-1A8240-27250 ARM ASSY, REVERSER 1

11 CY-24550-012080 BUSH 12X 8 1

12 CY-1A8240-27400 SHAFT, REVERSER 1

13 C Y-1A8 240 -274 60 LEVER, REVERSER 1

14 CY-22137-080000 WASHER 8, POLISHED 2

15 CY-22242-000200 CIRCLIP 20 2

16 CY-22252-000370 CIRCLIP 37 1

17 C Y-26106 -080352 BOLT M 8X 35 PLATED 2

18 CY-26346-080002 U-NUT, M8 2

19 C Y-1A718 0-15 710 PIN,TILT LOCK 1

20 C Y-1A76 40 -15710 BUSSING,TILT 4

21 CY-1A8 240 -15720 COLLAR, 17.3X10X22 2

22 C Y-1A824 0 -157 30 WASHER, 10.5X44X2.3 2

23 CY-1A8 250 -17470 BOOT, STEERING 1

24 C Y-198 200 -183 50 KNOB;REVERSER LEVER 1

25 CY-198 273 -1836 0 KNOB, ORANGE 1

26 C Y-19820 0-18 370 LABEL, 1

27 C Y-198290-37510 SPRING,RETURN 1

28 CY-22217-100000 SPRING WASHER 10 1

29 CY-26106 -100402 BOLT M10X 40 PLATED 2

Part Number Description Qty

74

THIS PAGE INTENTIONALLY LEFT BLANK

Lx490Lx Series

75

0CNP5-G37900

27. STEERING WHEEL

LEV.REF. PARTS NO. DESCRIPTION

Fig 27. Steering Wheel

Lx490Lx Series

Ref.

1 CY-198 133-157 10 WHEEL, STEERING 1

2 CY-198 133-157 50 CAP, STEERING 1

3 CY-22137-160000 WASHER 16,POLISHED 1

4 CY-26356-160002 U-NUT, M16 1

Part Number Description Qty

76

0CNP5-G37900

28. PST CYLINDER

LEV.REF. PARTS NO. DESCRIPTION

Fig 28. Pst Cylinder

Lx490Lx Series

77

Fig 28. Pst Cylinder

Lx490Lx Series

Ref.

1 CY-198 220 -11520 BOLT 12X38 2

2 CY-198 240 -1164 0 BOLT M12X 46 2

3 CY-1A8 275 -1710 0 CYLINDER ASSY, PST 1

4 CY-1A8 275 -172 60 BEARING, 35 X 15 2

5 CY-1A8 275 -17310 CAP, CYLINDER L 1

6 CY-1A8 275 -17320 CAP, CYLINDER R 1

7 CY-1A8 275 -17330 PACKING, 35 2

8 CY-1A8 275 -173 40 RING, BACKUP 2

9 CY-1A8 275 -17350 TUBE, CYLINDER 1

10 CY-1A8 275 -173 60 ELBOW ASSY 2

11 CY-24315- 000110 O-RING 1B P-11.0 2

12 C Y-1A8 275-174 00 ROD ASSY, PST 1

13 CY-22242-000300 CIRCLIP 30 2

14 C Y-1A82 75-1743 0 SCRAPER,35 2

15 C Y-1A82 75-174 40 PACKING, 60 2

16 C Y-1A8275 -1748 0 RING, BACKUP 55 2

17 C Y-1A8 275-1749 0 PACKING,RGU 55 1

18 CY-22312-10 0200 PARALLEL PIN, M10X20 2

Part Number Description Qty

78

0CNP5-G37900

29. PST VALVE

LEV.REF. PARTS NO. DESCRIPTION

VALVE, PST1A8275-1750011 111 JOINT172730-7514112 111 CONNECTOR172124-7616013 222

JOINT 90-3/8 ASSY172142-7618114 111 O-RING 1B P-14.024315-00014025 111 O-RING 1B P-14.024315-00014016 333

BOLT M10X 20 PLATED26106-10020217 333

Fig 29. Pst Valve

Lx490Lx Series

Ref.

Part Number Description Qty

1 CY-1A8 275 -1750 0 VALVE, PST 1

2 CY-172730 -75141 JOINT 1

3 C Y-172 124 -761 60 CONNECTOR 2

4 CY-172142-76181 JOINT 90-3/8 ASSY 1

5 CY-24315-000140 O-RING 1B P-14.0 1

6 CY-24315-000140 O-RING 1B P-14.0 3

7 CY-26106 -100202 BOLT M10X 20 PLATED 3

79

Fig.30. PST PIPING

0CNP5-G37900

30. PST PIPING

LEV.REF. PARTS NO. DESCRIPTION

HOSE,P1A8275-1782011 111 HOSE,T1A8275-1784012 111 CLAMP1A8275-1789013 111

FLANGE ASSY1A8275-4916014 111 BAND194680-5167015 333 GROMMET 24194180-6198016 222

O-RING 1A P-18.024311-00018017 111 O-RING 1A P-22.024311-00022018 111 BOLT M 6X 12 PLATED26106-06012219 111 BOLT M 6X 40 PLATED26106-060402110 333 CONNECTOR PF1/2-3/8933160-01370111 111

Fig 30. Pst Piping

Lx490Lx Series

Ref.

Part Number Description Qty

1 CY-1A8 275 -17820 HOSE,P 1

2 CY-1A8 275 -178 40 HOSE,T 1

3 CY-1A8 275 -178 90 CLAMP 1

4 C Y-1A82 75- 4916 0 FLANGE ASSY 1

5 CY-1946 80 -516 70 BAND 3

6 CY-194180 - 6198 0 GROMMET 24 2

7 CY-24311-000180 O-RING 1A P-18.0 1

8 CY-24311-000220 O-RING 1A P-22.0 1

9 CY-26106 -0 60122 BOLT M 6X 12 PLATED 1

10 CY-26106 -0 604 02 BOLT M 6X 40 PLATED 3

11 C Y-9 33160 - 0137 0 CONNECTOR PF1/2-3/8 1

80

0CNP5-G37900

31. PST HOSE

LEV.REF. PARTS NO. DESCRIPTION

Fig 31. Pst Hose

Lx490Lx Series

Ref.

1 CY-1A8 275 -17870 HOSE,CYLINDER 1

2 CY-1A8 275 -178 80 HOSE,CYLINDER 1

3 CY-1A8 240 -1795 0 SUPPORT, HOSE 1

4 CY-1946 80 -516 70 BAND 2

5 CY-1E6213- 83410 CLIP 18,HARNESS 1

6 CY-26106 -0 80162 BOLT M 8X 16 PLATED 1

7 CY-26106 -0 80162 BOLT M 8X 16 PLATED 1

Part Number Description Qty

81

0CNP5-G37900

32. CLUTCH HOUSING

LEV.REF. PARTS NO. DESCRIPTION

Fig 32. Clutch Housing

Lx490Lx Series

Ref.

1 CY-1A8275 -21130 HOUSING, CLUTCH 1

2 CY-194146 -21150 COVER, SIDE 1

3 CY-19446 4- 4592 0 PLUG 3/4-16UNF 1

4 CY-19446 4- 4593 0 O-RING 8-1 1

5 CY-26106 -0 80162 BOLT M 8X 16 PLATED 2

6 CY-26106 -120402 BOLT, M12X 40 PLATED 5

7 CY-26106 -120852 BOLT 12X 85 1

8 CY-27260-550000 PLUG 55 1

Part Number Description Qty

82

0CNP5-G37900

33. DOCKING BOLT

LEV.REF. PARTS NO. DESCRIPTION

Fig 33. Docking Bolt

Lx490Lx Series

Ref.

1 CY-198 448 -2128 0 BOLT M12X 50 1

2 CY-198 442-2 1310 BO LT 4

3 CY-198 448 -2132 0 BOLT, 12X 60 4

4 CY-2 2312-100180 PARALLEL PIN 10X 18 2

Part Number Description Qty

83

0CNP5-G37900

34. DAMPER DISC

LEV.REF. PARTS NO. DESCRIPTION

Fig 34. Damper Disc

Lx490Lx Series

Ref.

1 CY-198 448 -2219 0 PARALLEL PIN 10X18 3

2 CY-1A8275 -22810 DAMPER, DISK 1

3 CY-26106 -0 80162 BOLT M 8X 16 PLATED 6

Part Number Description Qty

84

0CNP5-G37900

35. CLUTCH LINK

LEV.REF. PARTS NO. DESCRIPTION

Fig 35. Clutch Link

Lx490Lx Series

85

Fig 35. Clutch Link

Lx490Lx Series

Ref.

1 CY-1949 90 -2214 0 NUT W/WASHER 8 2

2 CY-1A8240-22500 TURNBUCKLE ASSY 1

3 CY-1943 00 -222 60 TURNBUCKLE M10 1

4 CY-194150 -2248 0 NUT M10 1

5 CY-1A8240-22540 ROD, L.H. SCREW 1

6 CY-1A8240-22550 ROD ASSY, R SCREW 1

7 CY-26716-100002 NUT 10 1

8 CY-1A8240-22520 LINK, CLUTCH 1

9 CY-1C6281-52320 PIN 8,COME-OFF SNAP 2

10 CY-22137-080000 WASHER 8, POLISHED 1

11 CY-22157-080000 WASHER 8 1

Part Number Description Qty

86

0CNP5-G37900

36. TRANSMISSION CASE

LEV.REF. PARTS NO. DESCRIPTION

Fig 36. Transmission Case

Lx490Lx Series

87

Fig 36. Transmission Case

Lx490Lx Series

Ref.

1 CY-194197-21170 PLUG 17,BORE 1

2 CY-198 535 -24120 NUT 16 2

3 CY-198 212-2414 0 GASKET, TRANS. 1

4 C Y-1A73 50-2416 0 RETAINER, BEARING 1

5 CY-1A8275-24220 HOUSING ASSY, TRANS. 1

6 CY-198 240 -2412 0 STUD 16*45 2

7 C Y-1A82 75-2 4230 HOUSING, TRANS 1

8 CY-198 240 -24 530 STUD 12*45 2

9 CY-2 2312-100180 PARALLEL PIN 10X 18 2

10 CY-26216-080802 STUD M 8X 80 PLATED 2

11 CY-2 6218-1205 02 STUD,BOLT 12 X 50 2

12 CY-27260-300000 COVER, BLIND 1

13 C Y-198 218-2424 0 COVER, REAR 1

14 C Y-198212-24 320 GASKET, REAR COVER 1

15 C Y-198 071-243 40 COLLAR 13X17X14 2

16 C Y-198133 -243 80 COUPLING 140=3 1

17 C Y-198 255 -24 460 PLATE, OIL SEAL 1

18 C Y-1982 4024 48 03 COVER 1

19 CY-198212-24510 COVER, REAR COVER 1

20 C Y-1982 40246 902 CAP ASSY 1

21 CY-198 240 249 003 COVER, STRAINER 1

22 CY-1A8275-24960 GAUGE ASSY, OIL 1

23 C Y-1A82 75-2 498 0 GAUGE, OIL 1

24 C Y-194 850 -249 90 TUBE 1

25 CY-19432 2-24 980 PLUG 1/2-NPT 1

Part Number Description Qty

Ref.

26 C Y-19413 0-2635 0 SEAL TC 426009, OIL 1

27 C Y-119860 -3 4810 GUIDE, DIPSTICK 1

28 C Y-194 850 -4 250 0 CAP, OIL 33 1

29 C Y-194312 4675 02 PLUG PF3/8 1

30 C Y-194 64 0-73180 PIN, LOWER LINK 2

31 C Y-1945 55-7 7910 GASKET 1

32 CY-22217-120000 SPRING WASHER 12 2

33 CY-22217-160000 SPRING WASHER 16 2

34 CY-22312-100180 PARALLEL PIN 10X 18 2

35 CY-23491-140002 PLUG 14 2

36 CY-24311-000160 O-RING 1A P-16.0 2

37 CY-24311-000500 O-RING 1A P-50.0 1

38 CY-24321- 00 0650 O-RING 1A G-65.0 1

39 C Y-24321-00 0750 O-RING 1A G-75.0 1

40 C Y-24351-24 0300 O-RING 1A 2030 1

41 C Y-26 013 -140 352 BOLT W/WASHER 14X35 4

42 C Y-26106 -080162 BOLT M 8X 16 PLATED 2

43 C Y-26106-08 0202 BOLT M 8X 20 PLATED 2

44 C Y-26106 -08 0202 BOLT M 8X 20 PLATED 2

45 CY-26106-08 0302 BOLT M 8X 30 PLATED 10

46 C Y-26106 -080 402 BOLT M 8X 40 PLATED 2

47 C Y-26106 -100252 BOLT M10X 25 PLATED 4

48 C Y-26106 -1205 02 BOLT M12X50 2

49 CY-26106-120652 BOLT, 12 X 65 2

50 CY-26716-120002 NUT 12 2

Part Number Description Qty

88

THIS PAGE INTENTIONALLY LEFT BLANK

Lx490Lx Series

89

0CNP5-G37900

37. CENTER PLATE

LEV.REF. PARTS NO. DESCRIPTION

Fig 37. Center Plate

Lx490Lx Series

Ref.

1 CY-198 071- 2434 0 COLLAR 13X17X14 2

2 CY-198 212-24 360 PLATE, CENTER 1

3 CY-26106 -120502 BOLT M12X50 3

Part Number Description Qty

90

Fig.38. REVERSER VALVE

0CNP5-G37900

38. REVERSER VALVE

LEV.REF. PARTS NO. DESCRIPTION

Y

AAA

Fig 38. Reverser Valve

Lx490Lx Series

91

Fig 38. Reverser Valve

Lx490Lx Series

Ref.

1 CY-198 212-24281 GASKET, PR VALVE 1

2 C Y-1A745 0- 2430 1 VALVE ASSY, REVERSE 1

3 CY-168201- 01011 VALVECASE CMP 1

4 CY-168201- 01350 ARM CLUTCH,CMP 1

5 CY-168201- 01550 DRV CMP 1

6 CY-16 8201- 01600 CLUTCH VALVE CMP 1

7 CY-198 213-243 41 PLATE,VALVE 1

8 CY-198 213-2435 0 GASKET, VALVE CASE 1

9 CY-198 213-243 60 COVER, SPOOL 1

10 CY-198 213-2437 0 COVER, RELIEF 1

11 CY-198 213-2439 0 VALVE, RELIEF 1

12 C Y-198 213-24 40 0 SPRING, RELIEF 1

13 C Y-198 213-24 420 SPRING, CUT-OF 1

14 C Y-198213-2 44 41 SHIFT ARM CMP 1

15 C Y-19218 0-2 4730 ORIFICE 1

16 C Y-192180 -2474 0 SPRING 2

17 C Y-192157-26 46 0 PLUG 1/2-20 UNF 1

18 C Y-1945 21-415 70 PIN 11X7 2

19 C Y-194556 - 422 20 STRAINER A 1

20 C Y-194 850 -492 40 PLUG 9/16 1

21 CY-1948 50 -4 929 0 PACKING 6-1 1

22 CY-23871-010000 PLUG PT1/8,SCREW 3

23 CY-24190-100003 BALL 5/16, STEEL 2

24 CY-24311-000125 O-RING 1A P-12.5 1

25 CY-24311-000180 O-RING 1A P-18.0 1

26 CY-24311-000220 O-RING 1A P-22.0 1

27 CY-24311-000290 O-RING 1A P-29.0 1

28 CY-24311-000320 O-RING 1A P-32.0 1

29 CY-24341-000220 O-RING, 1A S22.0 1

30 CY-24341-000224 O-RING 1A S-22.4 2

31 C Y-2435 1-19014 0 O-RING, 1A 19014 2

32 CY-24361-090500 PACKING 1A AS 905 1

33 C Y-26016 -0 60162 BOLT M 6X 16 9

34 CY-26016-080302 BOLT M 8X 30 4

35 C Y-1A8 275 -244 20 ARM, SHIFT 1

36 C Y-1A82 75-2 447 0 ARM, SHIFT 1

37 C Y-194 440 -51 620 CLAMP, WIRE HARNESS 1

38 CY-22351- 060 036 SPRING PIN 6X36 2

39 CY-26106-080802 BOLT M 8X 80 PLATED 10

40 C Y-26106 -080 952 BOLT M 8X 95 PLATED 2

Part Number Description Qty

92

Fig.39. PTO VALVE

0CNP5-G37900

39. PTO VALVE

LEV.REF. PARTS NO. DESCRIPTION

Y

Fig 39. PTO Valve

Lx490Lx Series

93

Fig 39. PTO Valve

Lx490Lx Series

Ref.

1 CY-16 82D2- 00010 PTO VALVE CMP 1

2 CY-16 82D2- 01010 VALVEBODY(A CMP 1

3 CY-16 82D2- 01020 VALVE BO DY(A 1

4 CY-16 82D1-01100 ORIFICE 1

5 CY-23871-010000 PLUG PT1/8,SCREW 5

6 CY-16 82D1-01050 MODULATION VALVE 1

7 CY-16 82D1-0106 0 PISTON(ACCUMULATOR 1

8 CY-16 82D1-01070 SP(INNER 1

9 CY-16 82D1-0108 0 SP(OUTER 1

10 C Y-178 07 6- 0 243 0 VALVE ASSY, SOLENOID 1

11 CY-198 213-2475 0 COVER, DRV 1

12 C Y-1A6770 -26610 SOLENOID CMP 1

13 C Y-192159 -27 780 GASKET, SOLENOID 1

14 C Y-192159 -278 30 SPRING,SOLENOID 1

15 C Y-194170 - 45370 PLUG 1

16 CY-22351-060060 PIN 6.0AX60,SPRING 1

17 CY-24311-000070 O-RING 1A P-7.0 1

18 CY-24311-000240 O-RING 1A P-24.0 1

19 CY-24341-000112 O-RING 1A S-11.2 1

20 CY-26016 -06 0162 BOLT M 6X 16 3

21 C Y-1A82 75-2 4160 PLUG ASSY 1

22 C Y-1A82 75-2 454 0 GASKET, PTO VALVE 1

23 C Y-1A82 75-2 4550 VALVE ASSY, 1

24 C Y-1A8 275 -2457 0 CASE, PLATE PTO 1

25 C Y-1A82 75-2 4590 VALVE, RELIEF 1

26 CY-1A8275-24600 PLUG, RELIEF 1

27 C Y-194 555- 24610 SPRING, RELEASE 1

28 CY-1A8275 -24610 PLUG, R1/4 1

29 C Y-1945 55-2 462 0 SPRING, RELEASE 1

Part Number Description Qty

Ref.

30 CY-1A8275-24620 SHIM, 0.5 2

31 CY-1A8275-24650 SLEEVE, 1

32 C Y-194 556 -4 222 0 STRAINER A 1

33 C Y-24351-24 0230 O-RING, 1A 24023 1

34 CY -1A827 5-24 56 0 PK, VALVE PLATE 1

35 C Y-198 44 8-2 843 0 BOLT M14,PIPE JOINT 1

36 C Y-1A82 75- 48 010 HOLDER,RELIEF ASSY 1

37 C Y-1A8 275 -4 802 0 HOLDER,RELIEF 1

38 CY-1A8275-48050 SPRING,CHECK 1

39 CY-23414-160000 GASKET 16, ROUND 1

40 CY-23887-160002 PLUG 16,HEX. 1

41 C Y-2419 0-16 00 01 BALL 1/2 1

42 CY-1A8275- 48260 HP PIPE 1

43 C Y-1A8 275- 485 40 LP PIPE,REAR HOUSING 1

44 C Y-1A8 275 -4 8570 PIPE,PTO LUB 1

45 C Y-194 44 0- 51620 CLAMP, WIRE HARNESS 1

46 C Y-172730 -75141 JOINT 1

47 CY-23414-140000 GASKET 14, ROUND 2

48 C Y-23414 -200 026 GASKET 20 5

49 C Y-23414-220 029 GASKET 22 2

50 CY-23857-150000 BOLT, JOINT M15 1

51 CY-23857-180000 JOINT BOLT 18 1

52 CY-23871-010000 PLUG PT1/8,SCREW 1

53 CY-24311-000070 O-RING 1A P-7.0 1

54 CY-24311-000140 O-RING 1A P-14.0 1

55 CY-26106-080802 BOLT M 8X 80 PLATED 3

56 CY-2 6106 -0 81002 BOLT M 8X100 PLATED 1

57 C Y-26106-100202 BOLT M10X 20 PLATED 1

58 CY-26366-080002 NUT M 8 2

Part Number Description Qty

94

Lx490Lx Series

THIS PAGE INTENTIONALLY LEFT BLANK

95

0CNP5-G37900

40. FRONT COVER

LEV.REF. PARTS NO. DESCRIPTION

COVER ASSY, FRONT1A8275-2470011 111 CASE, REVERSE198448-2474022 111 GASKET, CASE198212-2475023 111

PLUG PT1/8,SCREW23871-01000024 222 SEAL TC30520824423-30520825 111 BOLT M 8X 50 PLATED26106-08050226 555

GASKET, FRONT COVER198212-2572017 111 PARALLEL PIN, M8X1622312-08018018 222 O-RING 1A S-35.024341-00035019 111 BOLT M 8X 35 PLATED26106-080352110 999 BOLT M 8X110 PLATED26106-081102111 222

Fig 40. Front Cover

Lx490Lx Series

Ref.

Part Number Description Qty

1 C Y-1A82 75-2 4700 COVER ASSY, FRONT 1

2 CY-198 448 -2474 0 CASE, REVERSE 1

3 CY-198 212-247 50 GASKET, CASE 1

4 CY-23871-010000 PLUG PT1/8,SCREW 2

5 CY-24423 -3052 08 SEAL TC305208 1

6 CY-26106 -0 80502 BOLT M 8X 50 PLATED 5

7 CY-198 212-25720 GASKET, FRONT COVER 1

8 CY-22312-080180 PARALLEL PIN, M8X16 2

9 CY-24341-000350 O-RING 1A S-35.0 1

10 CY-26106 -0 80352 BOLT M 8X 35 PLATED 9

11 CY-26106 -0 81102 BOLT M 8X110 PLATED 2

96

0CNP5-G37900

41. MAIN SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 41. Main Shaft

Lx490Lx Series

97

Fig 41. Main Shaft

Lx490Lx Series

Ref.

1 CY-1A8275 -25130 SHAFT, PTO DRIVE 1

2 CY-198 212-25150 COUPLING 13*16/32 1

3 CY-198212-25210 SHAFT, MIN 1

4 CY-198 212-25220 GEAR 21 1

5 CY-198 212-2524 0 GEAR 31, MAIN 1

6 CY-198 535 -252 60 GEAR 36 1

7 CY-198 212-25290 GEAR 27, MAIN 1

8 CY-194312- 2547 0 SPACER 30X40X2 1

9 CY-194250 -25 520 SPACER 35X45X2 1

10 CY-198 212-26 09 0 BEARING 63/22NR 1

11 CY-22242-000340 CIRCLIP 34 4

12 CY-22252-000190 CIRCLIP 19 1

13 C Y-24101-0620 64 BALL BEARING 1

14 CY-24101- 062074 BALL BEARING 1

Part Number Description Qty

98

0CNP5-G37900

42. DRIVEN SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 42. Driven Shaft

Lx490Lx Series

99

Fig 42. Driven Shaft

Lx490Lx Series

Ref.

1 CY-194250 -25 240 NEEDLE BEARING 3

2 CY-198 212-254 00 HUB ASSY, SYNCHRO 2

3 CY-198 212-254 60 HUB, SYNCHRO 2

4 CY-198 121-2 583 0 SLIDER 2

5 C Y-1A82 75-2 542 0 SHAFT, DRIVEN 1

6 CY-198535 -25510 GEAR 39, DRIVEN 1

7 CY-198 212-2552 0 GEAR 44, DRIVEN 1

8 CY-194150 -25530 WASHER 20X43X2.5 1

9 CY-198 212-2553 0 GEAR 49, DRIVEN 1

10 CY-198 212-255 40 GEAR 53, DRIVEN 1

11 CY-198 121-2 58 40 SYNCHRONIZER RING 4

12 C Y-198121 -258 50 KEY A SYNCHRONIZER 6

13 C Y-194 64 0-2 58 60 WASHER 30.3X45X3 1

14 C Y-198121-25 870 SPRING ( SYNCHRONIZE 4

15 CY-22292-000340 CIRCLIP S-34 4

16 CY-24101-062064 BALL BEARING 1

17 C Y-24101-0 6305 4 BEARING #6305 1

18 C Y-24161- 30352 0 NEEDLE BEARING 1

19 C Y-2416 3-3 052 00 COLLAR 30X35X20 1

20 CY-24165-000402 CIRCLIP 3

Part Number Description Qty

100

Fig.43. COUNTER SHAFT

0CNP5-G37900

43. COUNTER SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 43. Counter Shaft

Lx490Lx Series

Cub Cadet Yanmar Lx490 Part List Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
