Cub Cadet Yanmar Lx410 Part List Manual

Part List Manual

Lx Series Compact Tractor

Lx410

Cub Cadet Yanmar LLC

P.O. Box 361052

Cleveland, Ohio 44136-1052

PRINTED IN U.S.A. Form No. 769-07033

March 21, 2011

2

Notes

Lx410LX Series

3

Engine Section Index

Fig. No. Group Name

1. Cylinder Block

2. Gear Housing

3. Flywheel Housing & Oil Sump

4. Cylinder Head & Bonnet

5. Suction Manifold

6. Exhaust Manifold & Muer

7. Camshaft & Driving Gear

8. Crankshaft & Piston

9. Balancer

10. Lub. Oil System

11. Cooling Water System

12 . Fuel Injection Pump

14. Governor

15. Fuel Injection Valve

17. Starting Motor

18. Generator

Lx410LX Series

4

Fig 1. Cylinder Block

Lx410LX Series

5

Fig 1. Cylinder Block

Lx410LX Series

Ref.

1 C Y-72965 9- 0157 0 BLOCK ASSY, CYLINDER 1

4 CY-124 060 -01050 PLUG, PT1/8 1

5 C Y-129 00 1- 0125 0 PLUG, 50 1

6 CY-124160 - 01910 PLUG, PT1/4 2

7 CY-171051-01921 PLUG, NPTF1 1

8 CY-129150- 02020 BOLT, METAL CAP 10

11 C Y-129 795 - 02412 BUSH, CAMSHAFT A 1

12 CY-27241-120000 PLUG, 12 2

13 CY-27243-300000 PLUG 30 8

23 CY-129150-02931 METAL ASSY, THRUST 2

26 C Y-129 150 - 0120 0 BOLT, CYLINDER HEAD 18

27 CY-129407-01340 GASKET, CYL.HEAD 1

28 C Y-1193 09 -0181 0 PLUG 1

29 CY-129001-02931 MAIN BEARING SET 5

32 CY-129150-02871 MAIN METAL US=0.25 5

35 CY-129150-02941 BEARING, THRUST.25OS 1

Part Number Description Qty

6

0CNP5-G38200

LEV.REF. PARTS NO. DESCRIPTION

Fig 2. Gear Housing

Lx410LX Series

7

Fig 2. Gear Housing

Lx410LX Series

Ref.

1 CY-729008-01500 HOUSING ASSY, GEAR 1

3 CY-1199 34 -018 00 SEAL, OIL 1

4 C Y-129 00 8 -0 1520 FLANGE, GEAR CASE 1

5 CY-1198 02- 01561 STUD, M8X25 3

6 CY-124160- 01751 COVER, FILLER 1

7 CY-124240- 01871 COVER, PUMP 1

8 CY-12979 5- 0195 0 PIPE, KNOCK 2

9 CY-1196 09 -32 04 0 O-RING P16 2

10 CY-121850 -519 60 O-RING, F.I.PUMP 1

11 CY-2 2190- 080002 SEAL WASHER 8S 4

12 C Y-22190 -0800 02 SEAL WASHER 8S 1

13 CY-24311-000320 O-RING 1A P-32.0 1

14 CY-26106 -08 0162 BOLT M 8X 16 PLATED 4

15 C Y-26106-080162 BOLT M 8X 16 PLATED 3

16 CY-2 6106 -0 80302 BOLT M 8X 30 PLATED 1

17 C Y-26106 -080552 BOLT M 8X 55 PLATED 10

18 CY-26106-080852 BOLT M 8X 85 PLATED 3

19 CY-26306-080002 NUT, M8 3

20 CY-124240-01871 COVER, PUMP 1

21 CY-124240- 01871 COVER, PUMP 1

22 CY-124240- 01883 GASKET, PUMP 2

23 CY-2 2190- 080002 SEAL WASHER 8S 1

24 C Y-26106 -08 0162 BOLT M 8X 16 PLATED 4

25 CY-26106-080202 BOLT M 8X 20 PLATED 1

26 CY-26106 -080302 BOLT M 8X 30 PLATED 3

27 C Y-121023 -01551 COVER, TACHOMETER 1

28 CY-24341-000240 O-RING 1A S-24.0 1

29 CY-26106-060162 BOLT M 6X 16 PLATED 2

Part Number Description Qty

8

0CNP5-G38200

LEV.REF. PARTS NO. DESCRIPTION

Fig 3. Flywheel Housing & Oil Sump

Lx410LX Series

9

Fig 3. Flywheel Housing & Oil Sump

Lx410LX Series

Ref.

1 CY-12910 0- 01580 PIN, PARALLEL 2

2 C Y-129 558 - 0162 0 HOUSING, FLYWHEEL 1

3 CY-194 450 -11190 PLUG 15 6

4 CY-26206 -100252 BOLT M10X25 8

5 C Y-12 955 0 -0 1702 SUMP, LUB.OIL 1

6 CY-729429-01721 COVER ASSY, OIL SUMP 1

7 CY-105425 -016 90 PLUG, M16 1

9 CY-2219 0-16 00 02 WASHER, 16 1

10 CY-129555- 01750 PIPE, KNOCK 1

11 CY-26106-080122 BOLT M 8X 12 PLATED 20

12 C Y-26106 -08 0502 BOLT M 8X 50 PLATED 8

13 C Y-26106-081002 BOLT M 8X100 PLATED 14

14 CY-26106 -081202 BOLT M 8X120 PLATED 4

15 C Y-129100- 0158 0 PIN, PARALLEL 2

16 CY-729402-01650 CASE ASSY, OIL SEAL 1

18 C Y-129 120 -0 178 0 SEAL, OIL 1

19 C Y-129 4 86 - 0167 0 BOLT, M8X30 9

Part Number Description Qty

10

0CNP5-G38200

LEV.REF. PARTS NO. DESCRIPTION

A

Fig 4. Cylinder Head & Bonnet

Lx410LX Series

11

Fig 4. Cylinder Head & Bonnet

Lx410LX Series

Ref.

1 C Y-129 60 1-11241 SHAFT ASSY, ROCKER 1

2 C Y-129 60 1-11251 SHAFT, ROCKER ARM 1

4 CY-1198 02-1126 0 SUPPORT, ARM A 2

5 CY-1198 02-11270 SUPPORT, ARM B 3

6 C Y-129 150 -1128 0 SPRING, SHAFT 4

7 CY-1290 04 -11650 ARM KIT, ROCKER 8

8 C Y-129 150 -1123 0 SCREW, VALVE ADJUST 8

10 CY-129150 -11750 NUT, M8 8

11 CY-26226-080182 STUD M 8X 18 PLATED 3

12 C Y-12915 0-11370 CAP, VALVE 8

13 C Y-129 604 -11700 HEAD ASSY, CYLINDER 1

18 CY-27241-400000 PLUG 40 2

19 C Y -12 9 0 0 5 -1110 0 VALVE, INTAKE 4

20 C Y- 12 91 0 0 -1111 2 VALVE, EXHAUST 4

21 C Y- 12 97 9 5 -1112 0 SPRING, VALVE 8

22 C Y- 12 97 9 5 -1118 0 RETAINER, SPRING 8

23 CY-12140 0-1134 0 SEAL, VALVE STEM 4

24 C Y-124 460-1134 0 SEAL, VALVE STEM 4

25 CY-27310- 080 001 COTTER, 8 8

27 C Y-119802-11870 PROTECTOR, NOZZLE 4

28 C Y-1196 25-1188 0 SEAT, NOZZLE 4

29 C Y-1290 04 -1190 0 RETAINER, NOZZLE 4

30 CY-120270- 54410 WASHER, INJECTOR 4

Part Number Description Qty

Ref.

31 C Y-2 2351 -0 6 0012 SPRING PIN 6X12 2

32 C Y-26106 -08 0252 BOLT M 8X 25 PLATED 3

33 C Y-26106-080352 BOLT M 8X 35 PLATED 4

34 CY-26106- 080502 BOLT M 8X 50 PLATED 7

35 C Y-129 652-1135 0 BONNET CMP 1

36 C Y-129 00 4 - 030 10 PLATE, BAFFLE 1

37 C Y-12 9150 - 03 070 BAFFLE, BREATHER 1

38 C Y- 119 8 02 - 0 311 0 PLATE, CENTER 1

39 C Y-11980 2- 03121 COVER, DIAPHRAGM 1

40 C Y-1198 02- 03130 DIAPHRAGM 1

41 C Y-11980 2-03141 SPRING, DIAPHRAGM 1

43 C Y-129601-11310 GASKET, BONNET 1

44 C Y-22857-500100 SCREW, M5X10 4

45 CY-22857-500100 SCREW, M5X10 4

46 C Y-12416 0-1136 0 KNOB 3

47 CY-24311-000120 O-RING 1A P-12.0 3

48 CY-129900-07900 LIFTER, ENGINE 1

49 CY-26106 -080162 BOLT M 8X 16 PLATED 2

50 C Y-1198 03-778 30 HARNESS, GLOW PLUG 1

51 CY-129008-77800 PLUG, GLOW 4

52 CY-129604-77821 CONNECTOR, GLOW 1

53 C Y-12013 0-1186 0 GUIDE, VALVE 4

54 CY-129150 -11810 GUIDE, EXHAUST VALVE 4

Part Number Description Qty

12

0CNP5-G38200

LEV.REF. PARTS NO. DESCRIPTION

Fig 5. Suction Manifold

Lx410LX Series

13

Fig 5. Suction Manifold

Lx410LX Series

Ref.

1 CY-129005-03080 PIPE, BREATHER 1

2 CY-129 410- 03990 CLAMP 22 2

3 C Y-129 60 2-1210 1 MANIFOLD, AIR INTAKE 1

4 C Y-129 40 7-12110 GASKET, MANIFOLD 1

5 CY-26106-080202 BOLT M 8X 20 PLATED 6

6 CY-26106-080802 BOLT M 8X 80 PLATED 1

7 C Y-129 48 6 -125 81 JOINT, MANIFOLD 1

8 CY-129150-77511 GASKET, AIR HEATER 1

9 CY-26106-080202 BOLT M 8X 20 PLATED 4

Part Number Description Qty

14

0CNP5-G38200

LEV.REF. PARTS NO. DESCRIPTION

Fig 6. Exhaust Manifold & Muer

Lx410LX Series

15

Fig 6. Exhaust Manifold & Muer

Lx410LX Series

Ref.

1 CY-129411-1310 0 MANIFOLD, EXHAUST 1

2 CY-12955 0-13110 GASKET, EXH.MANIFOLD 1

3 CY-12926 3-132 20 STUD, M8X95 2

4 CY-1239 00 -1363 0 BOLT, M8X80 6

5 CY-119131-18 320 STUD, M8X22 4

6 CY-26306-080002 NUT, M8 2

7 CY-1299 30 -13201 GASKET, SILENCER 1

8 CY-1296 59-13 521 SILENCER 1

9 CY-1296 59-13 66 0 STAY, SILENCER 1

10 CY-26014-080222 BOLT M 8X 22 2

11 CY-26014-080252 BOLT M 8X 25 2

12 CY-26306-080002 NUT, M8 4

Part Number Description Qty

16

0CNP5-G38200

Fig 7. Camshaft & Driving Gear

Lx410LX Series

17

Fig 7. Camshaft & Driving Gear

Lx410LX Series

Ref.

1 CY-129150 -14200 TAPPET 8

2 CY-129150 -14 400 ROD, PUSH 8

3 CY-729402-14580 CAMSHAFT ASSY 1

4 CY-129150-02450 METAL, THRUST 1

6 CY-129150 -14101 GEAR, CAMSHAFT 1

7 CY-2 2512-070140 KEY, 7X14 1

8 CY-26106-080142 BOLT 8X 14 PLATED 2

9 CY-119803-25050 SHAFT, IDLER 1

10 CY-1198 02-2 5101 GEAR ASSY, IDLE 1

13 C Y-26106-0804 02 BOLT M 8X 40 PLATED 3

14 C Y-129 150 -2 5301 BOLT, PUMP 4

15 C Y-11980 2-25 901 GEAR, PUMP 1

16 C Y-129 150 -0 188 1 GASKET, COVER 1

17 CY-129150-26000 DRIVE ASSY, PUMP 1

18 CY-129150-26050 BRACKET, PUMP 1

20 CY-24105- 060 064 BALL BEARING 2

21 CY-1198 02-2 5071 BUSH, IDLE GEAR 1

Part Number Description Qty

18

0CNP5-G38200

Fig 8. Crankshaft & Piston

Lx410LX Series

19

Fig 8. Crankshaft & Piston

Lx410LX Series

Ref.

1 CY-129 652-21010 CRANKSHAFT ASSY 1

2 CY-12910 0- 01580 PIN, PARALLEL 1

4 CY-1198 03 -21200 GEAR, CRANKSHAFT 1

5 CY-12185 0-21290 PIN 1

6 C Y-129 40 0 -28 121 GEAR, BALANCER 1

7 CY-2 2512-070140 KEY, 7X14 1

9 CY-2 2512-070140 KEY, 7X14 1

10 CY-1198 52-216 50 V-PULLEY, CRANKSHAFT 1

11 CY-129795-21661 WASHER 1

12 C Y-121850 -21680 BOLT, V-PULLEY 1

13 C Y -12 1111- 215 0 1 BOLT, FLYWHEEL 6

14 CY-129635-2159 0 FLYWHEEL ASSY 1

16 CY-124550-21600 GEAR, RING 1

17 CY-129005-22080 PISTON W/RINGS 4

19 CY-129005-22500 RING SET, PISTON 4

25 CY-129202-22300 PIN, PISTON(D26,L70) 4

26 CY-22252-000260 CIRCLIP 26 8

27 C Y-729 402 -23100 ROD ASSY, CONNECTING 4

31 CY-121550 -2320 0 BOLT, CONNECTING ROD 8

32 C Y-12 9150 -2 36 01 METAL, CRANKPIN 4

34 CY-12910 0-23 910 METAL, PISTON PIN 4

35 C Y -12 9 15 0 -2 3 611 METAL.PIN US=0.25 4

37 CY-129005-22900 PISTON W/RINGS OS.25 4

39 CY-129005-22950 RING SET, PISTON .25 4

Part Number Description Qty

20

0CNP5-G38200

9. BALANCER

LEV.REF. PARTS NO. DESCRIPTION

Fig 9. Balancer

Lx410LX Series

21

Fig 9. Balancer

Lx410LX Series

Ref.

1 CY-12979 5- 0196 0 PIPE, KNOCK 2

2 CY-129457-28000 BALANCER ASSY 1

3 CY-128170 -14150 NUT, CAM 1

4 CY-12185 0-21290 PIN 1

5 CY-129457-28011 CASE ASSY, BALANCER 1

8 CY-129400-28150 GEAR, BALANCER A 1

9 CY-729490-28510 SHAFT, BALANCER A 1

14 CY-729490-28520 SHAFT, BALANCER B 1

19 CY-23876-005000 PLUG, PT1/16 1

20 CY-26106-080142 BOLT 8X 14 PLATED 4

21 CY-24311-000140 O-RING 1A P-14.0 1

22 CY-26106-080602 BOLT M 8X 60 PLATED 4

23 CY-26106-080802 BOLT M 8X 80 PLATED 2

Part Number Description Qty

22

0CNP5-G38200

Fig 10. Lub. Oil System

Lx410LX Series

23

Fig 10. Lub. Oil System

Lx410LX Series

Ref.

1 CY-129407-32000 PUMP ASSY, LUB.OIL 1

14 CY-129150-32020 GASKET, PUMP 1

15 CY-26450-060252 BOLT, M6X25 4

16 CY-129 468 -34 810 GUIDE, DIPSTICK 1

17 C Y-12 955 8- 34 82 0 DIPSTICK, LUB.OIL 1

18 CY-129150-35042 GASKET, PIPE 1

19 CY-129550-35090 PIPE ASSY, OIL INLET 1

24 C Y-26106 -08 0122 BOLT M 8X 12 PLATED 1

25 CY-26106-080352 BOLT M 8X 35 PLATED 2

26 CY-119 802-35100 BRACKET ASSY, FILTER 1

27 C Y-119802-35110 BRACKET, FILTER 1

28 CY-129100-35140 STUD 1

29 C Y- 12 91 50 - 3 5111 GASKET, BRACKET 1

31 CY-26106-080202 BOLT M 8X 20 PLATED 3

32 CY-114250-39450 SWITCH, OIL PRESSURE 1

33 C Y-124 160 -3 914 0 BOLT, JOINT M10 1

34 CY-1198 02-394 50 PIPE ASSY, LUB.OIL 1

35 CY-129005-59830 BOLT ASSY, JOINT 1

36 CY-2 2190-08 0002 SEAL WASHER 8S 1

37 CY-23857-030000 JOINT BOLT 3 1

38 CY-22190 -08 0002 SEAL WASHER 8S 1

39 CY-22190-100002 WASHER, 10 2

40 CY-26366-060002 NUT M 6 1

41 C Y-12915 0- 35153 FILTER 80X80L 1

Part Number Description Qty

24

0CNP5-G38200

LEV.REF. PARTS NO. DESCRIPTION

Fig 11. Cooling Water System

Lx410LX Series

25

Fig 11. Cooling Water System

Lx410LX Series

Ref.

1 CY-129263-42000 PUMP ASSY, WATER 1

2 CY-129150-42059 PAC KING 1

4 C Y-129 263 - 42120 PL ATE 1

8 C Y-129 150 -4 23 00 FLAGNE, C. W. PUMP 1

10 C Y-129 05 4- 42 32 0 O-RING 1

12 C Y-12 991 6- 49 740 PLUG, R03 2

13 C Y-24358 -240310 O-RING, 5 24031 1

14 CY-26106 -06 0202 BOLT M 6X 20 PLATED 2

15 C Y-26116-060162 BOLT 6X16 3

16 C Y-265 77- 06 0152 SCREW, M6X15 3

17 CY-129486-42050 GASKET, PUMP 1

18 CY-23414-080000 GASKET 8, ROUND 1

19 CY-26106 -08 0122 BOLT M 8X 12 PLATED 1

20 CY-26106-080552 BOLT M 8X 55 PLATED 3

21 CY-26106-080602 BOLT M 8X 60 PLATED 1

22 C Y-129 120 -4 235 0 V-PULLEY, WATER PUMP 1

23 CY-2 5152- 004100 V- BE LT 1

24 C Y-12 94 36 -4 474 0 FAN, COOLING 1

25 C Y-129 26 6- 4 476 0 SPA CER 1

26 CY-26014- 060162 BOLT M 6X 16 4

27 CY-26014-060302 BOLT W/WASHER 6X 30 4

28 C Y-129 155 -4 98 01 THERMOSTAT 1

29 C Y- 12 91 50 - 4 9 8 11 GASKET, THERMOSTAT 1

30 CY-129795- 49551 GASKET, COVER 1

31 C Y-129 350 - 49 56 0 COVER, THERMOSTAT 1

32 C Y-26106 -08 0202 BOLT M 8X 20 PLATED 2

33 C Y-11962 0- 492 90 COCK ASSY 1

37 CY-121450-42450 PLUG M16 1

38 CY-124465-44950 GASKET, 16 1

39 C Y-124250- 49351 THERMOMETER 1

40 C Y-12 9150 - 49 36 0 GASKET 10 1

41 C Y-129263-49610 PIPE, WATER A 1

43 CY-124722-59050 CLIP, HOSE 2

44 CY-129263-49620 PIPE, WATER B 1

46 CY-124722-59050 CLIP, HOSE 2

Part Number Description Qty

26

0CNP5-G38200

13. FUEL INJECTION PUMP

LEV.REF. PARTS NO. DESCRIPTION

Fig 12. Fuel Injection Pump Lx410

Lx410LX Series

27

Fig 12. Fuel Injection Pump Lx410

Lx410LX Series

Ref.

1 CY-729652-51560 INJECTION PUMP ASSY 1

4 CY-158 553-51551 JOINT, COOLING WATER 1

5 CY-158 601-51650 JOINT, OVER FLOW 1

6 CY-158 552-51670 JOINT, OVER FLOW 1

14 C Y-1290 08 -519 00 COVER 1

15 C Y-129 008 -519 20 BOLT M6X10 2

16 CY-119802-51090 KEY, WOODRUFF 4X16 1

19 CY-158552-51151 FLANGE 1

41 C Y-1586 00 -51270 STOPPER, TAPPET 1

42 CY-158563-51281 O-RING 1

43 CY-158563-51281 O-RING 1

44 C Y-129008 -51390 SETTING, DELIVERY 4

53 C Y-15 856 3- 51330 SPRING, DELIVERY 4

61 C Y-158 601 -5155 0 PLUG 1

62 C Y-11980 2-515 60 PLUG, BARREL 1

63 C Y-158 552- 51571 PK(BARREL PLUG 3

64 C Y-158 552 -5157 1 PK(BARREL PLUG 1

65 C Y-158 557- 51570 PLUG 1

66 CY -1586 01- 51570 PLUG, WATER PUMP 1

67 C Y-158 552 -51580 LIFTER 1

68 CY-119 802 -5159 0 TIMER SET 1

69 C Y-1198 02- 51590 TIMER CMP 1

72 CY-158553-51670 O-RING, 1011 1

73 C Y-1198 02- 5168 0 BACKUP RING 1

74 C Y-11980 2-516 90 O RING 1

75 C Y-24356 -1902 00 PACKING, 19020 1

76 CY-24372-000150 RING, BACKUP T2 P 15 1

77 CY-158552-516 00 PACKING, HEAD 1

78 C Y-158553-5163 0 SPRING, TIMER 1

80 CY-158553-516 50 ELEMENT, THERMO 1

Part Number Description Qty

Ref.

81 CY-158553-51660 O -R IN G,P 14 1

82 CY-158553-516 80 PACKING,TIMER 1

102 C Y-158601-51770 PISTON 1

103 C Y-158552- 51781 SPRING, ACTUATOR 1

104 C Y-158601-51790 PLUG 1

106 C Y-158 553-5193 0 P LUG , M12 1

107 C Y-22190 -120002 SEAL WASHER 12 1

108 C Y-22190 -180 002 WASHER, 18 1

109 C Y-158553-51770 BO LT 4

112 CY-158552-52311 O-RING 1

113 CY-158552-52400 O-RING 4E S42 1

114 C Y-2219 0-12 00 02 SEAL WASHER 12 2

115 C Y-2219 0-18 00 02 WASHER, 18 2

116 CY-22217-140000 SPRING WASHER 14 1

117 CY-22312-050140 PARALLEL PIN 5X14 2

118 CY-22351- 050 010 SPRING PIN 5X10 2

120 CY-24311-000070 O-RING 1A P-7.0 1

121 C Y-24 356 -19018 0 O-RING 4D 19018 1

122 C Y-24 356 -1902 00 PACKING, 19020 1

123 C Y-26106 -060102 BOLT 6X 10 PLATED 1

125 CY-26450-080452 BOLT M 8X 45 4

126 CY-26776-140002 LOCK NUT M14 PLATED 1

128 C Y-158552- 52100 PUMP ASSY, FUEL FEED 1

129 CY-158552-52500 O-RING, PUMP 1

130 CY-129916-59020 JOINT, PIPE 12 1

131 C Y-2219 0 -120 002 SEAL WASHER 12 2

132 CY-23857-060000 JOINT BOLT 6,PIPE 1

134 C Y-12 96 01- 5125 0 RETAINER, PUMP 1

135 C Y-26106 -08 0162 BOLT M 8X 16 PLATED 1

136 C Y-26106 -08 0202 BOLT M 8X 20 PLATED 1

Part Number Description Qty

28

0CNP5-G38200

Fig 14. Governor

Lx410LX Series

29

Fig 14. Governor

Lx410LX Series

Ref.

3 CY-158 553- 61050 PACKING, CASE 1

4 CY-158 553- 61070 PACKING, COVER 1

6 CY-129155-51280 O-RING, S6 1

7 CY-158553- 51930 P LU G, M12 1

23 CY-129255- 61410 NUT 1

24 C Y-119807- 61420 SPRING, RETURN 1

25 CY-1198 52- 6144 0 LEVER ASSY,REGULATOR 1

26 C Y-129 155 -61 46 0 BOLT, IDLE 1

61 C Y-1196 60 - 61901 RETAINER, SHAFT 1

65 C Y-2219 0-12 00 02 SEAL WASHER 12 1

68 CY-2610 6- 060102 BOLT 6X 10 PLATED 1

69 CY-26756-060002 LOCK NUT 6 1

82 C Y-1585 52- 6190 0 O-RING 1

88 CY-2610 6- 060142 BOLT M 6X 14 PLATED 2

89 CY-26106-060142 BOLT M 6X 14 PLATED 4

90 C Y-26106 -060202 BOLT M 6X 20 PLATED 10

91 C Y-1585 52- 61061 COVER, GOVERNOR CASE 1

92 C Y-11985 2-6108 0 SUPPORT, WIRE 1

135 C Y-11965 3-77 950 SOLENOID, STOP 1

136 C Y-26106 -06 0142 BOLT M 6X 14 PLATED 2

Part Number Description Qty

30

0CNP5-G38200

Fig 15. Fuel Injection Valve Lx410

Lx410LX Series

31

Fig 15. Fuel Injection Valve Lx410

Lx410LX Series

Ref.

1 CY-729604-53200 VALVE ASSY,INJECTION 4

2 CY-129604-53000 VALVE ASSY,INJECTION 4

5 CY-114250-53080 NUT, CASE 4

6 CY-1198 02- 53100 HOLDER ASSY, NOZZLE 4

11 C Y- 114 25 0 - 5 312 0 SPRING, NOZZLE 4

12 C Y -114 2 5 0 - 53 13 0 SEAT, SPRING 4

13 C Y-114250 -53140 PLATE, STOP 4

14 CY-1142 50-53210 PIN 8

15 C Y-11980 3-5 34 00 SHIM SET 4

42 C Y-12 9150 - 59120 RETAINER, PIPE 1

45 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2

46 C Y-12 955 0 -5912 0 RETAINER, PIPE 1

49 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2

51 CY-129601-59810 PIPE ASSY, INJECTION 1

55 CY-129601-59820 PIPE ASSY, INJECTION 1

59 CY-129601-59830 PIPE ASSY, INJECTION 1

63 CY-129601-59840 PIPE ASSY, INJECTION 1

68 CY-119 802 -59550 PIPE ASSY, RETURN 1

69 CY-124722-59050 CLIP, HOSE 2

70 C Y-11980 2-59 560 PIPE, FUEL RETURN 1

71 C Y-129486 -59551 PIPE ASSY, RETURN 3

72 CY-124722-59050 CLIP, HOSE 6

74 C Y-119593 -59 581 CAP 1

75 CY-23080-010000 CLAMP 10 1

Part Number Description Qty

32

0CNP5-G38200

17. STARTING MOTOR

LEV.REF. PARTS NO. DESCRIPTION

A

Y

129407-7722026 11

Fig 17. Starting Motor

Lx410LX Series

33

Fig 17. Starting Motor

Lx410LX Series

Ref.

1 C Y-129 40 7-7 7010 STARTER, RA1.4 1

2 CY-X0283060061 ROLLER 5

3 C Y-X9 49 056 1370 NUT 1

4 C Y-X9 49 120 024 0 BALL 1

5 CY-124795-77 210 YOKE 1

6 C Y-129 40 7-7 722 0 ARMATURE ASSY 1

7 C Y-129 129 -77 23 0 BEARING 1

8 C Y-129 129 -77 240 BEARING 1

9 CY-129407-77250 S TAR TE R 1

10 CY-X0280210230 NUT 1

11 CY-X0283270140 RETAINER, SNAP 1

12 C Y-12 94 07-7 73 90 CLUTCH ASSY, STARTER 1

13 C Y-12 9129 -77 44 0 BALL BEARING 1

14 C Y-129 129 -774 50 BALL BEARING 1

15 C Y-12 9129 -77 40 0 SHAFT 1

16 C Y-129 129 -7741 0 SPRING, COIL 1

17 C Y- X9 4917 03 371 SPRING, COIL 1

18 C Y-129 129 -774 20 PINION, STARTER 1

19 C Y-129 129 -774 30 RING, SNAP 1

20 C Y-129 129 -77 26 0 R ETA IN ER 1

21 C Y-129 129 -77 270 PINION 1

22 CY-129407-77280 HOUSING 1

23 CY-129407-77290 FRAME 1

24 C Y-12 94 07-7 73 00 HOLDER ASSY 1

25 C Y-X 94 9173 0 461 SPRING 4

26 CY-129407-77 310 SWITCH ASSY 1

27 C Y-12 9129 -7 732 0 BO LT 2

28 C Y-129 4 07-7 733 0 B OLT 2

29 C Y-129 129 -77 34 0 SPRING 1

30 C Y-129 129 -77 350 O-RING 2

31 C Y-129 129 -77 36 2 COVER 1

33 C Y-12 9129 -7 738 0 CAP 1

34 C Y-12912 9 -774 60 SCREW 2

35 C Y -2 611 6 -12 0 2 52 BOLT M12X 25 PLATED 2

Part Number Description Qty

34

0CNP5-G38200

18. GENERATOR

LEV.REF. PARTS NO. DESCRIPTION

A

Fig 18. Generator

Lx410LX Series

35

Fig 18. Generator

Lx410LX Series

Ref.

1 CY-12979 5- 0190 0 STUD 1

2 CY-119751-772 00 GENERATOR, 12V-40A 1

3 CY-X021551244 0 COVER 1

4 CY-X12140 01430 FLAME ASSY, DRIVE 1

5 CY-1196 20 -7920 0 BALL BEARING 1

6 CY-1196 20 -79210 PLATE, RETAINER 1

7 CY-1196 20 -79220 SCREW 4

8 CY-1196 20 -79230 STUD 2

9 CY-X1215011050 FLAME ASSY, REAR 1

10 CY-X9490 561001 NUT 1

11 CY-1196 20 -773 80 ROTOR ASSY 1

12 C Y-11962 0-7 9240 BALL BEARING 1

13 C Y-11962 0-7 9250 COVER, BEARING 1

14 C Y-1196 20 -77461 PULLEY 1

15 C Y-11962 0-7 7471 NUT 1

16 C Y-1196 20 -7749 0 COLLAR 1

17 C Y-129423-77710 REGULATOR ASSY 1

18 C Y-1196 20 -7926 0 HOLDER 1

19 CY-129052-79270 HOLDER, BRUSH 1

20 C Y-1196 20 -7748 0 BRUSH ASSY 2

21 CY-1196 20 -7928 0 SPRING 2

22 C Y-1196 20 -7929 0 SCREW 6

23 CY-1196 20 -79300 SCREW 1

24 C Y-11962 0-7 9310 BO LT 3

25 CY-1196 20 -7932 0 SCREW 2

26 C Y-11962 0-79330 BO LT 2

27 C Y-11962 0-7 934 0 BUSH, INSULATION 1

28 C Y-1196 20 -7935 0 NUT 2

29 C Y-1196 20 -79360 WASHER, THRUST 1

30 CY-26306-100002 NUT, M10 1

31 CY-129107-77330 ADJUSTER, BELT 1

32 CY-124732-77340 S PACE R 1

33 C Y-12 997 2-7 73 41 BOLT, ADJUSTER 1

Part Number Description Qty

36

Tractor Section Index

Lx410LX Series

Fig. No. Group Name

Engine Control Section

1. Engine Related Lx410 & Lx450

3. Engine Accessories Lx410 & Lx450

5. Grommet

6. Accelerator Lever

7. Foot Accel

8. Exhaust

9. Fuel Tank

10. Tank Parts

Front Axle Section

11. Front Axle Bracket

12 . Front Support

13. Tie Rod

14. Ring Gear

15. Dierential Gear

16. Propeller Shaft

17. Front Shaft 1

18. Front Axle Case

19. Front Gear Case

20. Front Shaft 2

21. Front Spindle

22. Front Wheel Tire R1

23. Front Wheel Tire R3

24. Front Wheel Tire R4

25. Hub Bolt

26. Steering Column

27. Steering Wheel

28. Pst Cylinder

29. Pst Valve

30. Pst Piping

31. Pst Hose

Transmission Section

32. Clutch Housing

33. Docking Bolt

34. Damper Disc

35. Clutch Link

36. Transmission Case

37. Center Plate

38. Reverser Valve

Fig. No. Group Name

39. PTO Valve

40. Front Cover

41. Main Shaft

42. Driven Shaft

43. Counter Shaft

44. Reduction Shaft

45. Power Reverser

46. PTO Clutch

47. PTO Drive Shaft

48. PTO Shaft

49. Main Lever

50. Slide Plate

51. Main Change Shift

52. Reverser Wire

53. Range Shift

54. Sub Lever

55. Front Drive

56. Change Arm

57. Front Shift

Rear Axle Section

58. Ring Gear 2

59. Dierential Gear 2

60. Dierential Carrier

61. Rear Housing

62. Dierential Lock

63. Dierential Lock Pedal

64. Final Pinion

65. Final Gear

66. Rear Axle Shaft

67. Rear Wheel Tire R1

68. Rear Wheel Tire R3

69. Rear Wheel Tire R4

70. Hub Bolt 2

71. Brake

72. Pedal

73. Brake Link

Hydraulic Control Section

74. Hydraulic Pump

75. Hyd. Cylinder Housing

37

Tractor Section Index

Lx410LX Series

Fig. No. Group Name

76. Hyd. Lift Docking

7 7. Piston

78. Lift Crank

79. Control Valve

80. Relief Valve

81. Stop Valve

82. Safety Valve

83. Loader Valve

84. Breather

85. Lever, Scv

86. Hydraulic Operation 1

8 7. Hydraulic Control

88. Hydraulic Operation 2

89. Lift Lever

90. Hydraulic Line

91. Hydraulic Filter

92. Hydraulic Line - Loader

93. Hydraulic Line - Loader PBK Rear Remote

Electrical Parts Section

94. Harness

96. Battery

98. Battery Clamp

100 . Switch

101. Switch 2

102. Switch 3

103. Lamp

104 . Front Lamp

105. Meter

106 . Relay

Fittings Section

10 7. Front Frame

108 . Hood Frame

109. Hood

110 . Dashboard

111. Column Cover

112 . Fender

113 . Fender Parts

114 . Floor

115 . Step Stay 1

Fig. No. Group Name

116 . Insulator

117. Step Stay 2

118 . Floor Attachment

119 . Seat

120 . Label

121. Label Lx410

124 . Label(Pl)

125 . SMV

HItch Section

126 . 3P Link Kit

12 7. Top Link

128 . Drawbar Hitch

129 . PTO Guard

Safety Frame Section

130 . Roll Guard

Optional Section

132 . Front Hitch

133 . Heater Block

134 . Front Weight

135 . Extra Hitch

136 . Heater TM

13 7. Work Lamp

138 . Rear Remote Kit

139 . Rear Coupler Kit

38

0CNP5-G37900

1. ENGINE RELATED

LEV.REF. PARTS NO. DESCRIPTION

Fig 1. Engine Related Lx410 & Lx450

Lx410LX Series

39

Fig 1. Engine Related Lx410 & Lx450

Lx410LX Series

Ref.

1 CY-129263- 44510 TANK ASSY, SUB 1

2 CY-1192 25- 52102 PUMP ASSY, FUEL FEED 1

3 C Y-129 00 4 -55 612 BRACKET, FILTER 1

4 CY-1198 02- 5570 0 SEPARATOR ASSY 1

5 CY-12910 0-55690 RING, RETAINING 1

6 CY-1198 02- 55710 ELEMENT 1

7 CY-1198 02- 5573 0 CUP ASSY 1

8 CY-24311-000160 O-RING 1A P-16.0 1

9 CY-24321-000 650 O-RING 1A G-65.0 1

10 CY-1198 02- 558 01 FILTER, FUEL 1

Part Number Description Qty

40

0CNP5-G37900

3. ENGINE ACCESSORIES

LEV.REF. PARTS NO. DESCRIPTION

Fig 3. Engine Accessories Lx410 & Lx450

Lx410LX Series

41

Fig 3. Engine Accessories Lx410 & Lx450

Lx410LX Series

Ref.

1 CY-1A7140-00600 RADIATOR ASSY 1

2 CY-1A7180- 01050 RUBBER,RADIATOR 2

3 CY-1A8250 -01210 TUBE,COOLING WATER A 1

4 C Y-1A7 26 0- 012 20 PIPE, COOLING WATER 1

5 CY-1A8250 -01250 SCREEN, RADIATOR 1

6 CY-194150 - 01270 SPACER 20 1

7 CY-1A8250 -01500 SHROUD M ASSY, FAN 1

8 CY-1982 80 -0 44 70 JOINT 1

9 C Y-1A82 40 -0 46 20 CLAMP, FUEL HOSE 1

10 CY-1A8240 -05100 CLEANER ASSY,5.5IN,D 1

11 CY-1A8240 -05110 ELEMENT ASSY, OUTER 1

12 C Y-1A8240-05120 ELEMENT ASSY, INNER 1

13 C Y-1A8240-05130 GASKET, AIR CLEANER 1

14 CY-1A8240-05150 BO DY, 1

15 C Y-1A8240-0516 0 COVER ASSY 1

16 CY-1A8240 -05170 VALVE, UNLOADER 1

17 C Y-1A8240- 05180 CLIP NUT, M8 2

18 CY-1A8275-05510 PLATE,SHUTTER,88 ASS 1

19 CY-1A8240 -05810 COVER, BELT L 1

20 CY-1A8240-05820 COVER, BELT R 1

21 C Y-1A82 40 -0 620 0 PIPE A, INTAKE 1

22 CY-1A8240-06220 HOSE B, INTAKE 1

23 CY-1A82 40 -1546 0 BRACKET, CLAMP 1

24 C Y-194 99 0-2 2140 NUT W/WASHER 8 2

25 CY-1949 90 -2214 0 NUT W/WASHER 8 2

26 C Y-198220 -37 90 0 PIN 8X24 1

Part Number Description Qty

Ref.

27 CY-121750-49150 PIPE, C. WATER 1

28 CY-175022- 49750 CLIP 37, HOSE 2

29 C Y-194 44 0- 51620 CLAMP, WIRE HARNESS 1

30 C Y-194 680 -51 670 BAND 2

31 C Y-194 680- 51670 BAND 1

32 C Y-1A76 01-5392 0 URETHANE,SIDE LAMP 1

33 C Y-114270-59010 CLIP, HOSE 2

34 CY-114270 -59010 CLIP, HOSE 4

35 C Y-114270-59010 CLIP, HOSE 2

36 CY-1A8240-60220 SUPPORT, CLEANER 1

37 CY-23000-035000 CLAMP 35 2

38 CY-23000-070000 CLAMP 70 2

39 CY-23000-070000 CLAMP 70 1

40 C Y-239 80 -7302 00 HOSE 7.3X200,BRAIDED 1

41 C Y-239 80-730 400 FUEL PIPE 7.3X400 2

42 CY-23980-730600 FUEL PIPE 7.3X600 1

43 C Y-26106-060202 BOLT M 6X 20 PLATED 4

44 C Y-26106 -08 0122 BOLT M 8X 12 PLATED 2

45 CY-26106 -080162 BOLT M 8X 16 PLATED 2

46 C Y-26106 -080162 BOLT M 8X 16 PLATED 3

47 C Y-26106 -080162 BOLT M 8X 16 PLATED 1

48 C Y-26106 -080302 BOLT M 8X 30 PLATED 2

49 CY-26106 -100202 BOLT M10X 20 PLATED 1

50 C Y-198071- 6189 0 NUT 6,SPEED 1

51 CY-26106-060202 BOLT M 6X 20 PLATED 1

Part Number Description Qty

42

0CNP5-G37900

5. GROMMET

LEV.REF. PARTS NO. DESCRIPTION

GROMMET 24194180-6198011 111

Fig 5. Grommet

Lx410LX Series

Ref.

1 CY-19418 0- 6198 0 GROMMET 24 1

Part Number Description Qty

43

0CNP5-G37900

6. ACCEL LEVER

LEV.REF. PARTS NO. DESCRIPTION

Fig 6. Accelerator Lever

Lx410LX Series

Ref.

1 CY-1A8250 -01100 LEVER ASSY, ACCEL 1

2 CY-19474 0- 00 160 WASHER 10, CONICAL 3

3 C Y- 1A 8 25 0 - 0 1110 LEVER, ACCEL 1

4 CY-1982 00 -0 126 0 PLATE, FRICTION 1

5 CY-1A8250 -02150 SUPPORT ASSY, ACCEL 1

6 CY-22137-100000 WASHER 10,POLISHED 1

7 CY-22157-100000 WASHER 10 1

8 CY-26716-100002 NUT 10 2

9 CY-1A8250 -01150 CABLE ASSY, HAND 1

10 CY-198 071- 01160 RUBBER,WIRE RETAING 1

11 CY-1982 53- 01190 KNOB, THROTTLE LEVER 1

12 C Y-198245-51210 GROMMET 25 1

13 CY-1C6281-52310 PIN 6,COME-OFF SNAP 1

14 C Y-198 071-5 8810 GROMMET 8 1

15 CY-22137-060000 WASHER 6, POLISHED 1

16 CY-2 6106 -0 80162 BOLT M 8X 16 PLATED 2

Part Number Description Qty

44

0CNP5-G37900

7. FOOT ACCEL

LEV.REF. PARTS NO. DESCRIPTION

Fig 7. Foot Accel

Lx410LX Series

Ref.

1 CY-1982 00 -0 1210 CABLE, CONTROLE 1

2 C Y-1A8 240 - 0130 0 CONTROL UNIT, FOOT 1

3 CY-165001-22950 RUBBER 1

4 CY-1949 90 -2213 0 NUT W/WASHER 6 1

5 CY-1A8300 -51210 BAND, REPEAT 1

6 CY-194 680- 51670 BAND 1

7 CY-1983 60 -55 630 SPRING,RETURN 1

8 CY-26106-060122 BOLT M 6X 12 PLATED 1

9 CY-26116-060404 BOLT M 6X 40 PLATED 1

Part Number Description Qty

45

0CNP5-G37900

8. EXHAUST

LEV.REF. PARTS NO. DESCRIPTION

Fig 8. Exhaust

Lx410LX Series

Ref.

1 CY-1A8250 -0310 0 MUFFLER PIPE 1

2 CY-1290 52-135 50 GASKET 1

3 CY-26106-080202 BOLT M 8X 20 PLATED 3

Part Number Description Qty

46

0CNP5-G37900

9. FUEL TANK

LEV.REF. PARTS NO. DESCRIPTION

TANK, FUEL ASSY1A8250-0410011 111 TANK, FUEL1A8250-0411022 111 CAP, FUEL TANK1A8160-0413023 111

SCREW, 5 X 141A7180-0418024 555 FUEL SENDER ASSY1A8275-5660025 111 GASKET194420-5662036 111

BAND, TANK REAR L1A8250-0421017 111 BAND, TANK REAR R1A8250-0422018 111 BUFFER, BAND1A8250-0423019 222 CLAMP198153-04670110 222 WASHER 822157-080000111 222 U-NUT M 826347-080002112 444 U-NUT M 826347-080002113 222

Fig 9. Fuel Tank

Lx410LX Series

47

Fig 9. Fuel Tank

Lx410LX Series

Ref.

1 C Y-1A82 50 -0 4100 TANK, FUEL ASSY 1

2 C Y-1A82 50 -0 4110 TANK, FUEL 1

3 C Y-1A816 0- 0413 0 CAP, FUEL TANK 1

4 C Y-1A718 0- 041 80 SCREW, 5 X 14 5

5 C Y-1A82 75- 566 00 FUEL SENDER ASSY 1

6 CY-194 420 -56 620 GASKET 1

7 CY-1A8250 -0 4210 BAND, TANK REAR L 1

8 CY-1A8250-04220 BAND, TANK REAR R 1

9 CY-1A8250-04230 BUFFER, BAND 2

10 CY-198153 -0 46 70 CLAMP 2

11 CY-22157-080000 WASHER 8 2

12 CY-26346-080002 U-NUT M 8 4

13 CY-26346-080002 U-NUT M 8 2

Part Number Description Qty

48

0CNP5-G37900

10. TANK PARTS

LEV.REF. PARTS NO. DESCRIPTION

A

Y

Fig 10. Tank Parts

Lx410LX Series

49

Fig 10. Tank Parts

Lx410LX Series

Ref.

1 CY-1A8250 -04250 ANGLE ASSY, TANK 2

2 C Y-1A82 50 -0 44 30 HOSE, FUEL 1

3 C Y-1A82 50 -0 428 0 TUBE, CORRUGATE 13 2

4 C Y-1A82 50 -0 48 70 CLAMP, HOSE 1

5 CY-1A8250 -21180 COVER, HOUSING 1

6 CY-1949 90 -2214 0 NUT W/WASHER 8 2

7 CY-1A7130 -4 8110 CLAMP, PIPE 1

8 C Y-1A82 50 -0 428 0 TUBE, CORRUGATE 13 2

9 CY-1A8300 -51210 BAND, REPEAT 1

10 CY-194 680- 51670 BAND 2

11 CY-194 680- 51670 BAND 5

12 C Y-194 68 0- 51670 BAND 1

13 C Y-114270-59010 CLIP, HOSE 2

14 CY-114270-59010 CLIP, HOSE 2

15 C Y-114270- 59010 CLIP, HOSE 2

16 CY-114270 -59010 CLIP, HOSE 2

17 CY-1A8250- 63890 SEAL,FENDER 2

18 CY-1A8250-63800 BRACKET ASSY, TANK 1

19 C Y-1A8250 - 658 70 BRACKET, SMV ASSY 1

20 CY-22157-080000 WASHER 8 2

21 CY-22157-080000 WASHER 8 2

22 CY-23980-730550 HOSE 7.3* 550 1

23 C Y-2 39 80 -7 3170 0 HOSE, 7.3X1700 2

24 C Y-26106 -06 0122 BOLT M 6X 12 PLATED 2

25 CY-26106-080162 BOLT M 8X 16 PLATED 2

26 CY-26106 -080162 BOLT M 8X 16 PLATED 1

27 C Y-26106 -08 0202 BOLT M 8X 20 PLATED 2

28 CY-26106-080702 BOLT M 8X 70 PLATED 1

29 CY-26346-080002 U-NUT M 8 2

30 CY-1A7882-85630 HOLDER, SMV 1

31 CY-26106-080202 BOLT M 8X 20 PLATED 2

32 C Y-1A8 250 - 042 90 CUSHION,TANK 1

Part Number Description Qty

50

0CNP5-G37900

11. FRONT AXLE BRACKET

LEV.REF. PARTS NO. DESCRIPTION

Fig 11. Front Axle Bracket

Lx410LX Series

Ref.

1 C Y- 1A 8 25 0 - 1110 0 BRACKET ASSY, F AXLE 1

2 CY-1A816 0-1152 0 BOLT, M12X34 14

3 CY-1A82 75-1745 0 GUARD, PST CYLINDER 1

4 CY-1A6680-85980 BOLT 14*45 8

5 CY-26106-080162 BOLT M 8X 16 PLATED 1

6 CY-2 6116 -160604 BOLT M16X 60 PLATED 1

7 CY-2 6716-16 0002 NUT M16 1

Part Number Description Qty

51

0CNP5-G37900

12. FRONT SUPPORT

LEV.REF. PARTS NO. DESCRIPTION

Fig 12. Front Support

Lx410LX Series

Ref.

1 CY-1A82 75-1160 0 SUPPORT ASSY,FRONT F 1

2 CY-1A718 0-1162 0 BUSH, 60X65X40 1

3 CY-1A718 0-1163 0 SEAL, VB607005 1

4 CY-24761-010000 NIPPLE M6F, GREASE 1

5 CY-1A718 0-1165 0 WASHER, 60X4 1

6 CY-1A82 75-1170 0 SUPPORT ASSY,FRONT R 1

7 CY-194181-115 60 SEAL VB75 85 6.5,OIL 1

8 CY-194 641-1163 0 BUSH 75X80X25 1

9 CY-24761-010000 NIPPLE M6F, GREASE 1

10 CY-1982 83-13 48 0 WASHER 62X75X3 1

Part Number Description Qty

52

0CNP5-G37900

13. TIE ROD

LEV.REF. PARTS NO. DESCRIPTION

Fig 13. Tie Rod

Lx410LX Series

53

Fig 13. Tie Rod

Lx410LX Series

Ref.

1 CY-1A82 75-12310 TIE-ROD ASSY, L 1

2 CY-1A82 75-12330 END ASSY, ROD L 1

3 CY-1A82 75-124 40 COVER, DUST 1

4 CY-1A82 75-124 50 RING, COVER 1

5 CY-1A82 75-124 60 GREASE NIPPLES 1

6 CY-1A82 75-12510 END ASSY, RACK L 1

7 CY-1A82 75-12580 COVER, DUST 1

8 CY-1A82 75-12590 RING, COVER 1

9 CY-1A82 75-126 00 C L I P, 1

10 CY-1A82 75-12610 NUT, M20 1

11 CY-1A82 75-12320 TIE-ROD ASSY, R 1

12 C Y-1A8 275-12 34 0 END ASSY, ROD R 1

13 C Y-1A8275-12 44 0 COVER, DUST 1

14 C Y-1A82 75-124 50 RING, COVER 1

15 C Y-1A82 75-124 60 GREASE NIPPLES 1

16 C Y-1A8275-12 520 END ASSY, RACK R 1

17 C Y-1A8 275-125 80 COVER, DUST 1

18 C Y-1A8275-12 590 RING, COVER 1

19 C Y-1A82 75-126 00 CL I P, 1

20 C Y-1A82 75-12610 NUT, M20 1

21 CY-1A82 75-1247 0 NUT,CASTLE 2

22 CY-22417-400400 COTTER PIN 4.0X40 2

Part Number Description Qty

54

0CNP5-G37900

14. RING GEAR

LEV.REF. PARTS NO. DESCRIPTION

Fig 14. Ring Gear

Lx410LX Series

Ref.

1 CY-1A82 75-1310 0 GEAR ASSY, RING 1

2 CY-1A718 0-1315 0 COLLAR , 1

3 CY-1A718 0-133 80 COLLAR 58X62X4.8 1

4 CY-1A718 0-133 90 COLLAR 58X62X4.9 1

5 CY-1A718 0-13 40 0 COLLAR 58X62X5.0 2

6 C Y-1A718 0-13 410 COLLAR 58X62X5.1 1

7 CY-1A718 0-13 420 COLLAR 58X62X5.2 1

8 CY-1982 51-13670 COLLAR 1

9 C Y-24141-3 20070 ROLLER BEARING 2

10 CY-24341-000315 O-RING, 1A S31.5 1

Part Number Description Qty

55

0CNP5-G37900

15. DIFFERENTIAL GEAR

LEV.REF. PARTS NO. DESCRIPTION

HOUSING ASSY, DIFF.1A7180-1320111 111 HOUSING,DIFFERENTIAL1A7180-1321122 111 PINION, DIFFERENTIAL194321-1323023 222

LINER, DIFFERENTAIL194465-1324024 222 GEAR, DIFF. SIDE194321-1325025 222 WASHER194465-1326026 222

SHAFT, DIFF. PINION194321-1327027 111 SPRING PIN 6X4022351-06004028 111 COLLAR, DIFFERENTIAL1A7180-1325019 111 SHIM, A DIFF1A7180-13260110 222 SHIM, B DIFF1A7180-13270111 333 BOLT M 8X 20 PLATED198165-21490112 888 BALL BEARING24101-060174113 222

Fig 15. Dierential Gear

Lx410LX Series

Ref.

Part Number Description Qty

1 CY-1A718 0-132 01 HOUSING ASSY, DIFF. 1

2 CY-1A718 0-13211 HOUSING,DIFFERENTIAL 1

3 CY-1943 21-1323 0 PINION, DIFFERENTIAL 2

4 CY-194 465 -1324 0 LINER, DIFFERENTAIL 2

5 CY-1943 21-1325 0 GEAR, DIFF. SIDE 2

6 CY-194 465 -1326 0 WASHER 2

7 CY-1943 21-13270 SHAFT, DIFF. PINION 1

8 CY-2 2351- 060 040 SPRING PIN 6X40 1

9 CY-1A718 0-132 50 COLLAR, DIFFERENTIAL 1

10 CY-1A718 0-132 60 SHIM, A DIFF 2

11 CY-1A718 0-132 70 SHIM, B DIFF 3

12 C Y-198165-2 1490 BOLT M 8X 20 PLATED 8

13 C Y-24101-060174 BALL BEARING 2

56

0CNP5-G37900

16. PROPELLER SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 16. Propeller Shaft

Lx410LX Series

57

Fig 16. Propeller Shaft

Lx410LX Series

Ref.

1 CY-1A718 0-133 00 SHAFT, PROPELLER 1

2 CY-1A714 0-14 610 COVER,SHAFT FRONT 1

3 CY-1982 41-146 50 BOOT, RUBBER 1

4 CY-1A82 75-14 650 COVER, SHAFT 1

5 CY-194 64 0-2 6130 COUPLING 3

6 C Y-1A82 75-2 8410 SHAFT, DRIVE 1

7 C Y-1A82 75-2 842 0 RETAINER, BEARING 1

8 C Y-1A82 75-2 843 0 COVER, SHAFT REAR 1

9 CY-1E9170-54811 BOLT,REAMER 8X25 2

10 CY-22217-080000 WASHER, 8 2

11 CY-22242-000300 CIRCLIP 30 2

12 CY-22242-000300 CIRCLIP 30 2

13 CY-22252-000550 CIRCLIP 55 1

14 CY-23000-060000 CLAMP 60 2

15 C Y-24104- 06006 4 BALL BEARING 1

16 CY-24321-000500 O-RING 1A G-50.0 1

17 CY-24321-000500 O-RING 1A G-50.0 2

18 CY-24321-000500 O-RING 1A G-50.0 1

19 CY-26106 -08 0122 BOLT M 8X 12 PLATED 1

20 CY-26106-080122 BOLT M 8X 12 PLATED 2

Part Number Description Qty

58

0CNP5-G37900

17. FRONT SHAFT(1

LEV.REF. PARTS NO. DESCRIPTION

Fig 17. Front Shaft 1

Lx410LX Series

Ref.

1 CY-1A718 0-135 20 PINION, 1ST SHAFT 12 2

2 CY-1A718 0-135 60 SHAFT L,FRONT 1ST 1

3 CY-1A718 0-135 70 SHAFT R,FRONT 1ST 1

4 CY-1A718 0-135 80 BEARING, HR6209UR 4

Part Number Description Qty

59

0CNP5-G37900

18. FRONT AXLE CASE

LEV.REF. PARTS NO. DESCRIPTION

Fig 18. Front Axle Case

Lx410LX Series

Ref.

1 CY-1A82 75-13610 CASE , FRONT AXLE 1

2 CY-22252-000620 CIRCLIP 62(H) 1

3 CY-24421- 456209 SEAL TC 456209, OIL 1

Part Number Description Qty

60

0CNP5-G37900

19. FRONT GEAR CASE

LEV.REF. PARTS NO. DESCRIPTION

Fig 19. Front Gear Case

Lx410LX Series

61

Fig 19. Front Gear Case

Lx410LX Series

Ref.

1 CY-194 066-1364 0 PLUG 20 1

2 CY-1A7180137101 HOUSING, FRONT GEAR 1

3 CY-1A82 75-137 20 HOUSING, FRONT GEAR 1

4 CY-198 072-137 60 SEAL QLF709521.5 2

5 CY-1A82 75-1376 0 BOLT, 10X28 4

6 CY-1A82 75-137 70 GEARBOX, FRONT L 1

7 CY-1A82 75-137 80 GEARBOX, FRONT R 1

8 CY-1C7100 -15100 CAP,SEALING 90 2

9 C Y-1C6 90 0 -2312 0 BOLT M14X10,DRAIN 2

10 C Y-1C690 0-2 3150 WASHER 2

11 CY-194151- 366 70 PLUG PT02 2

12 CY-22252-000850 CIRCLIP 85 2

13 CY-22252-000900 CIRCLIP 90 2

14 CY-22252-000950 CIRCLIP 95 2

15 C Y-22312-10018 0 PARALLEL PIN 10X 18 2

16 CY-24101-060124 BALL BEARING 2

17 C Y-24101-0 6209 4 BALL BEARING 2

18 CY-24311-000180 O-RING 1A P-18.0 1

19 CY-24321- 00130 0 O-RING 1A G-130.0 2

20 CY-26106-100302 BOLT M10X 30 PLATED 16

21 CY-26450-080122 BOLT 8X 12 2

22 CY-26756-100002 LOCK NUT M10 PLATED 4

Part Number Description Qty

62

0CNP5-G37900

20. FRONT SHAFT(2

(C)=LX490

(B)=LX450

(A)=LX410

LEV.REF. PARTS NO. DESCRIPTION

GEAR, 2ND SHAFT 151A7180-1382011 222 PINION, FAINAL 111A7180-1383012 222 SHAFT, FRONT 2ND1A7180-1387013 222

BEARING, TM207UR1A7180-1388014 222 BALL BEARING24104-06210415 222

Fig 20. Front Shaft 2

Lx410LX Series

Ref.

Part Number Description Qty

1 CY-1A718 0-13 820 GEAR, 2ND SHAFT 15 2

2 CY-1A718 0-13 830 PINION, FAINAL 11 2

3 CY-1A718 0-13 870 SHAFT, FRONT 2ND 2

4 CY-1A7180-13880 BEARING, TM207UR 2

5 CY-24104 -0 62104 BALL BEARING 2

63

0CNP5-G37900

21. FRONT SPINDLE

LEV.REF. PARTS NO. DESCRIPTION

Fig 21. Front Spindle

Lx410LX Series

Ref.

1 CY-1A7180137901 CASE, FRONT BEARING 2

2 CY-1A718 0-13 84 0 GEAR, FAINAL 49 2

3 C Y-1A718 0141101 SPINDLE, FRONT 2

4 CY-1982 00 -14210 RING, HALF TIMBER 4

5 CY-198 475- 326 60 SEAL QLNY527514.5 2

6 CY-24101- 0620 84 BALL BEARING 2

7 CY-24101- 0620 94 BALL BEARING 2

8 CY-24321-0023 00 O-RING, 1A G230.0 2

9 CY-26106-100 302 BOLT M10X 30 PLATED 16

Part Number Description Qty

64

0CNP5-G37900

22. FRONT WHEEL TIRE R1

LEV.REF. PARTS NO. DESCRIPTION

Fig 22. Front Wheel Tire R1

Lx410LX Series

Ref.

1 CY-1A8170 -14300 R1 TIRE KIT,FRONT L 1

2 CY-1A8170 -14310 R1 TIRE 8-16 1

3 CY-1A8170 -1433 0 R1 WHEEL F 1

4 CY-1A8170 -1435 0 VALVE, FRONT TIRE 1

5 CY-1A8170 -144 00 R1 TIRE KIT,FRONT R 1

6 CY-1A8170 -14310 R1 TIRE 8-16 1

7 CY-1A8170 -1433 0 R1 WHEEL F 1

8 CY-1A8170 -1435 0 VALVE, FRONT TIRE 1

Part Number Description Qty

65

0CNP5-G37900

23. FRONT WHEEL TIRE R3

LEV.REF. PARTS NO. DESCRIPTION

R3 TIRE KIT,FRONT1A8170-1450011 222 VALVE, FRONT TIRE1A8170-1435022 222 R3 TIRE 27X10.5-151A8170-1451023 222

R3 WHEEL F1A8170-1453024 222

Fig 23. Front Wheel Tire R3

Lx410LX Series

Ref.

1 CY-1A8170 -14500 R3 TIRE KIT,FRONT 2

2 CY-1A8170 -1435 0 VALVE, FRONT TIRE 2

3 CY-1A8170 -14510 R3 TIRE 27X10.5-15 2

4 CY-1A8170 -1453 0 R3 WHEEL F 2

Part Number Description Qty

66

0CNP5-G37900

24. FRONT WHEEL TIRE R4

LEV.REF. PARTS NO. DESCRIPTION

Fig 24. Front Wheel Tire R4

Lx410LX Series

Ref.

1 CY-1A82 50 -14700 TIRE KIT,L R4 FRONT 1

2 CY-1A82 50 -14710 TIRE,R4 10-16.5-6PR 1

3 CY-1A82 50 -14730 WHEEL,R4 16.5X8.25 1

4 CY-1A82 50 -14740 VALVE,TIRE R4 FRONT 1

5 CY-1A82 50 -148 00 TIRE KIT,R R4 FRONT 1

6 CY-1A82 50 -14710 TIRE,R4 10-16.5-6PR 1

7 CY-1A82 50 -14730 WHEEL,R4 16.5X8.25 1

8 CY-1A82 50 -14740 VALVE,TIRE R4 FRONT 1

Part Number Description Qty

67

0CNP5-G37900

25. HUB BOLT

LEV.REF. PARTS NO. DESCRIPTION

Fig 25. Hub Bolt

Lx410LX Series

Ref.

1 C Y-19813 3- 3413 0 BOLT 14X30 12

Part Number Description Qty

68

0CNP5-G37900

26. STEERING COLUMN

LEV.REF. PARTS NO. DESCRIPTION

A

Y

Fig 26. Steering Column

Lx410LX Series

69

Fig 26. Steering Column

Lx410LX Series

Ref.

1 CY-1A82 40 -1550 0 COLUMN UNIT,STEERING 1

2 CY-1A82 40 -15240 BEARING, 6904LLU 1

3 CY-1A82 40 -15320 SHAFT, STEERING 1

4 CY-1A82 40 -1560 0 COLUMN ASSY, STG 1

5 CY-24550-015080 BEARING, 15 X 8 2

6 C Y-1A82 40 -270 30 COLLAR, 8.2X14X5.3 2

7 CY-1A8240-27050 COLLAR, 12X8X10 1

8 C Y-1A82 40 -270 90 PIN, CONNECTING 1

9 CY-1982 00 -272 40 SPRING, RETURN 1

10 CY-1A8240-27250 ARM ASSY, REVERSER 1

11 CY-24550-012080 BUSH 12X 8 1

12 CY-1A8240-27400 SHAFT, REVERSER 1

13 C Y-1A8 240-2 746 0 LEVER, REVERSER 1

14 CY-22137-080000 WASHER 8, POLISHED 2

15 CY-22242-000200 CIRCLIP 20 2

16 CY-22252-000370 CIRCLIP 37 1

17 C Y-26106 -080352 BOLT M 8X 35 PLATED 2

18 CY-26346-080002 U-NUT, M8 2

19 C Y-1A718 0-15 710 PIN,TILT LOCK 1

20 C Y-1A76 40 -15710 BUSSING,TILT 4

21 CY-1A82 40 -15720 COLLAR, 17.3X10X22 2

22 C Y-1A824 0 -157 30 WASHER, 10.5X44X2.3 2

23 CY-1A82 50 -17470 BOOT, STEERING 1

24 C Y-198 200 -183 50 KNOB;REVERSER LEVER 1

25 CY-1982 73-18 360 KNOB, ORANGE 1

26 C Y-198200 -183 70 LABEL, 1

27 C Y-198290 -37510 SPRING,RETURN 1

28 CY-22217-100000 SPRING WASHER 10 1

29 CY-26106-1004 02 BOLT M10X 40 PLATED 2

Part Number Description Qty

70

THIS PAGE INTENTIONALLY LEFT BLANK

Lx410LX Series

71

0CNP5-G37900

27. STEERING WHEEL

LEV.REF. PARTS NO. DESCRIPTION

Fig 27. Steering Wheel

Lx410LX Series

Ref.

1 CY-198133 -15710 WHEEL, STEERING 1

2 CY-198133 -1575 0 CAP, STEERING 1

3 CY-22137-160000 WASHER 16,POLISHED 1

4 CY-26356-160002 U-NUT, M16 1

Part Number Description Qty

72

0CNP5-G37900

28. PST CYLINDER

LEV.REF. PARTS NO. DESCRIPTION

Fig 28. Pst Cylinder

Lx410LX Series

73

Fig 28. Pst Cylinder

Lx410LX Series

Ref.

1 CY-1982 20 -11520 BOLT 12X38 2

2 CY-1982 40 -116 40 BOLT M12X 46 2

3 CY-1A82 75-1710 0 CYLINDER ASSY, PST 1

4 CY-1A82 75-172 60 BEARING, 35 X 15 2

5 CY-1A82 75-1731 0 CAP, CYLINDER L 1

6 CY-1A82 75-173 20 CAP, CYLINDER R 1

7 CY-1A82 75-173 30 PACKING, 35 2

8 CY-1A82 75-173 40 RING, BACKUP 2

9 CY-1A82 75-173 50 TUBE, CYLINDER 1

10 CY-1A82 75-173 60 ELBOW ASSY 2

11 CY-24315-000110 O-RING 1B P-11.0 2

12 C Y-1A8 275-174 00 ROD ASSY, PST 1

13 CY-22242-000300 CIRCLIP 30 2

14 C Y-1A82 75-1743 0 SCRAPER ,35 2

15 C Y-1A82 75-174 40 PACKING, 60 2

16 C Y-1A8275-174 80 RING, BACKUP 55 2

17 C Y-1A8 275-1749 0 PACKING,RGU 55 1

18 CY-22312-100200 PARALLEL PIN, M10X20 2

Part Number Description Qty

74

0CNP5-G37900

29. PST VALVE

LEV.REF. PARTS NO. DESCRIPTION

VALVE, PST1A8275-1750011 111 JOINT172730-7514112 111 CONNECTOR172124-7616013 222

JOINT 90-3/8 ASSY172142-7618114 111 O-RING 1B P-14.024315-00014025 111 O-RING 1B P-14.024315-00014016 333

BOLT M10X 20 PLATED26106-10020217 333

Fig 29. Pst Valve

Lx410LX Series

Ref.

Part Number Description Qty

1 CY-1A82 75-175 00 VALVE, PST 1

2 CY-172730-75141 JOINT 1

3 C Y-172 124 -761 60 CONNECTOR 2

4 CY-172142-76181 JOINT 90-3/8 ASSY 1

5 CY-24315-000140 O-RING 1B P-14.0 1

6 CY-24315-000140 O-RING 1B P-14.0 3

7 CY-26106-100202 BOLT M10X 20 PLATED 3

75

Fig.30. PST PIPING

0CNP5-G37900

30. PST PIPING

LEV.REF. PARTS NO. DESCRIPTION

HOSE,P1A8275-1782011 111 HOSE,T1A8275-1784012 111 CLAMP1A8275-1789013 111

FLANGE ASSY1A8275-4916014 111 BAND194680-5167015 333 GROMMET 24194180-6198016 222

O-RING 1A P-18.024311-00018017 111 O-RING 1A P-22.024311-00022018 111 BOLT M 6X 12 PLATED26106-06012219 111 BOLT M 6X 40 PLATED26106-060402110 333 CONNECTOR PF1/2-3/8933160-01370111 111

Fig 30. Pst Piping

Lx410LX Series

Ref.

Part Number Description Qty

1 CY-1A82 75-178 20 HOSE,P 1

2 CY-1A82 75-178 40 HOSE,T 1

3 CY-1A82 75-178 90 CLAMP 1

4 C Y-1A82 75- 4916 0 FLANGE ASSY 1

5 CY-194 680- 51670 BAND 3

6 CY-19418 0- 6198 0 GROMMET 24 2

7 CY-24311-000180 O-RING 1A P-18.0 1

8 CY-24311-000220 O-RING 1A P-22.0 1

9 CY-26106-060122 BOLT M 6X 12 PLATED 1

10 CY-26106-0604 02 BOLT M 6X 40 PLATED 3

11 C Y-9 33160 - 0137 0 CONNECTOR PF1/2-3/8 1

76

0CNP5-G37900

31. PST HOSE

LEV.REF. PARTS NO. DESCRIPTION

Fig 31. Pst Hose

Lx410LX Series

Ref.

1 CY-1A82 75-178 70 HOSE,CYLINDER 1

2 CY-1A82 75-178 80 HOSE,CYLINDER 1

3 CY-1A82 40 -179 50 SUPPORT, HOSE 1

4 CY-194 680- 51670 BAND 2

5 CY-1E6213-8 3410 CLIP 18,HARNESS 1

6 CY-26106-080162 BOLT M 8X 16 PLATED 1

7 CY-26106-080162 BOLT M 8X 16 PLATED 1

Part Number Description Qty

77

0CNP5-G37900

32. CLUTCH HOUSING

LEV.REF. PARTS NO. DESCRIPTION

Fig 32. Clutch Housing

Lx410LX Series

Ref.

1 CY-1A8275-21130 HOUSING, CLUTCH 1

2 CY-19414 6-21150 COVER, SIDE 1

3 CY-194 46 4- 45920 PLUG 3/4-16UNF 1

4 CY-194 46 4- 459 30 O-RING 8-1 1

5 CY-26106-080162 BOLT M 8X 16 PLATED 2

6 CY-26106-120402 BOLT, M12X 40 PLATED 5

7 CY-26106-1208 52 BOLT 12X 85 1

8 CY-27260-550000 PLUG 55 1

Part Number Description Qty

78

0CNP5-G37900

33. DOCKING BOLT

LEV.REF. PARTS NO. DESCRIPTION

Fig 33. Docking Bolt

Lx410LX Series

Ref.

1 CY-198 44 8-212 80 BOLT M12X 50 1

2 CY-198 442 -21310 B OLT 4

3 CY-198 44 8-2132 0 BOLT, 12X 60 4

4 CY-2 2312-100180 PARALLEL PIN 10X 18 2

Part Number Description Qty

79

0CNP5-G37900

34. DAMPER DISC

LEV.REF. PARTS NO. DESCRIPTION

Fig 34. Damper Disc

Lx410LX Series

Ref.

1 CY-198 44 8-2 2190 PARALLEL PIN 10X18 3

2 CY-1A8275-2 2810 DAMPER, DISK 1

3 CY-26106-080162 BOLT M 8X 16 PLATED 6

Part Number Description Qty

80

0CNP5-G37900

35. CLUTCH LINK

LEV.REF. PARTS NO. DESCRIPTION

Fig 35. Clutch Link

Lx410LX Series

81

Fig 35. Clutch Link

Lx410LX Series

Ref.

1 CY-1949 90 -2214 0 NUT W/WASHER 8 2

2 CY-1A8240-22500 TURNBUCKLE ASSY 1

3 CY-1943 00 -22 260 TURNBUCKLE M10 1

4 CY-194150 -2248 0 NUT M10 1

5 CY-1A8240-22540 ROD, L.H. SCREW 1

6 CY-1A8240-22550 ROD ASSY, R SCREW 1

7 CY-26716-100002 NUT 10 1

8 CY-1A8240-22520 LINK, CLUTCH 1

9 CY-1C6281-52320 PIN 8,COME-OFF SNAP 2

10 CY-22137-080000 WASHER 8, POLISHED 1

11 CY-22157-080000 WASHER 8 1

Part Number Description Qty

82

0CNP5-G37900

36. TRANSMISSION CASE

LEV.REF. PARTS NO. DESCRIPTION

Fig 36. Transmission Case

Lx410LX Series

83

Fig 36. Transmission Case

Lx410LX Series

Ref.

1 CY-194197-21170 PLUG 17,BORE 1

2 CY-1985 35-2 4120 NUT 16 2

3 CY-198212-2 4140 GASKET, TRANS. 1

4 C Y-1A73 50-24160 RETAINER, BEARING 1

5 CY-1A8275-24220 HOUSING ASSY, TRANS. 1

6 CY-1982 40 -24120 STUD 16*45 2

7 C Y-1A82 75-2 4230 HOUSING, TRANS 1

8 CY-1982 40 -2453 0 STUD 12*45 2

9 CY-2 2312-100180 PARALLEL PIN 10X 18 2

10 CY-26216-080802 STUD M 8X 80 PLATED 2

11 CY-2 6218-1205 02 STUD,BOLT 12 X 50 2

12 CY-27260-300000 COVER, BLIND 1

13 C Y-198 218-24240 COVER, REAR 1

14 C Y-198212-243 20 GASKET, REAR COVER 1

15 C Y-198 071-2434 0 COLLAR 13X17X14 2

16 C Y-198133 -243 80 COUPLING 140=3 1

17 C Y-198 255 -24 460 PLATE, OIL SEAL 1

18 C Y-1982 4024 48 03 COVER 1

19 CY-198212-24510 COVER, REAR COVER 1

20 C Y-1982 402469 02 CAP ASSY 1

21 CY-1982 402490 03 COVER, STRAINER 1

22 CY-1A8275-24960 GAUGE ASSY, OIL 1

23 C Y-1A82 75-2 498 0 GAUGE, OIL 1

24 C Y-194 850-2499 0 TUBE 1

25 CY-1943 22-2498 0 PLUG 1/2-NPT 1

Part Number Description Qty

Ref.

26 C Y-19413 0-26350 SEAL TC 426009, OIL 1

27 C Y-119860 -34 810 GUIDE, DIPSTICK 1

28 C Y-194 850 -4 250 0 CAP, OIL 33 1

29 C Y-194312 4675 02 PLUG PF3/8 1

30 C Y-194 64 0-73180 PIN, LOWER LINK 2

31 C Y-1945 55-7 7910 GASKET 1

32 CY-22217-120000 SPRING WASHER 12 2

33 CY-22217-160000 SPRING WASHER 16 2

34 CY-22312-100180 PARALLEL PIN 10X 18 2

35 CY-23491-140002 PLUG 14 2

36 CY-24311-000160 O-RING 1A P-16.0 2

37 CY-24311-000500 O-RING 1A P-50.0 1

38 CY-24321-000650 O-RING 1A G-65.0 1

39 C Y-24321-000750 O-RING 1A G-75.0 1

40 C Y-24351-24 0300 O-RING 1A 2030 1

41 C Y-26 013 -140 352 BOLT W/WASHER 14X35 4

42 C Y-26106 -080162 BOLT M 8X 16 PLATED 2

43 C Y-26106-080202 BOLT M 8X 20 PLATED 2

44 C Y-26106 -08 0202 BOLT M 8X 20 PLATED 2

45 CY-26106 -080302 BOLT M 8X 30 PLATED 10

46 C Y-26106 -0804 02 BOLT M 8X 40 PLATED 2

47 C Y-26106 -100252 BOLT M10X 25 PLATED 4

48 C Y-26106 -1205 02 BOLT M12X50 2

49 CY-26106 -120652 BOLT, 12 X 65 2

50 CY-26716-120002 NUT 12 2

Part Number Description Qty

84

THIS PAGE INTENTIONALLY LEFT BLANK

Lx410LX Series

85

0CNP5-G37900

37. CENTER PLATE

LEV.REF. PARTS NO. DESCRIPTION

Fig 37. Center Plate

Lx410LX Series

Ref.

1 CY-198 071-24 340 COLLAR 13X17X14 2

2 CY-198212-2 436 0 PLATE, CENTER 1

3 CY-26106-120502 BOLT M12X50 3

Part Number Description Qty

86

Fig.38. REVERSER VALVE

0CNP5-G37900

38. REVERSER VALVE

LEV.REF. PARTS NO. DESCRIPTION

Y

AAA

Fig 38. Reverser Valve

Lx410LX Series

87

Fig 38. Reverser Valve

Lx410LX Series

Ref.

1 CY-198212-2 4281 GASKET, PR VALVE 1

2 C Y-1A745 0- 2430 1 VALVE ASSY, REVERSE 1

3 CY-168201-01011 VALVECASE CMP 1

4 CY-168201-01350 ARM CLUTCH,CMP 1

5 CY-168201-01550 DRV CMP 1

6 CY-16 8201- 01600 CLUTCH VALVE CMP 1

7 CY-198213-24341 PLATE,VALVE 1

8 CY-198213-24350 GASKET, VALVE CASE 1

9 CY-198213-24360 COVER, SPOOL 1

10 CY-198213-24370 COVER, RELIEF 1

11 CY-198213-24390 VALVE, RELIEF 1

12 C Y-198 213-24 40 0 SPRING, RELIEF 1

13 C Y-198 213-24 420 SPRING, CUT-OF 1

14 C Y-198213-24 441 SHIFT ARM CMP 1

15 C Y-19218 0-2 4730 ORIFICE 1

16 C Y-192180 -2474 0 SPRING 2

17 C Y-192157-26 460 PLUG 1/2-20 UNF 1

18 C Y-1945 21-415 70 PIN 11X7 2

19 C Y-194556 -4222 0 STRAINER A 1

20 C Y-194 850 -4924 0 PLUG 9/16 1

21 CY-194 850 -4929 0 PACKING 6-1 1

22 CY-23871-010000 PLUG PT1/8,SCREW 3

23 CY-24190-100003 BALL 5/16, STEEL 2

24 CY-24311-000125 O-RING 1A P-12.5 1

25 CY-24311-000180 O-RING 1A P-18.0 1

26 CY-24311-000220 O-RING 1A P-22.0 1

27 CY-24311-000290 O-RING 1A P-29.0 1

28 CY-24311-000320 O-RING 1A P-32.0 1

29 CY-24341-000220 O-RING, 1A S22.0 1

30 CY-24341-000224 O-RING 1A S-22.4 2

31 C Y-2435 1-19014 0 O-RING, 1A 19014 2

32 CY-24361-090500 PACKING 1A AS 905 1

33 C Y-26016 -0 60162 BOLT M 6X 16 9

34 CY-26016-080302 BOLT M 8X 30 4

35 C Y-1A8 275 -244 20 ARM, SHIFT 1

36 C Y-1A82 75-2 447 0 ARM, SHIFT 1

37 C Y-194 440 -5162 0 CLAMP, WIRE HARNESS 1

38 CY-22351- 060036 SPRING PIN 6X36 2

39 CY-26106-080802 BOLT M 8X 80 PLATED 10

40 C Y-26106 -080952 BOLT M 8X 95 PLATED 2

Part Number Description Qty

88

Fig.39. PTO VALVE

0CNP5-G37900

39. PTO VALVE

LEV.REF. PARTS NO. DESCRIPTION

Y

Fig 39. PTO Valve

Lx410LX Series

89

Fig 39. PTO Valve

Lx410LX Series

Ref.

1 CY-16 82D2- 00010 PTO VALVE CMP 1

2 CY-16 82D2- 01010 VALVEBODY(A CMP 1

3 CY-16 82D2- 01020 V ALVE BODY(A 1

4 CY-16 82D1-01100 ORIFICE 1

5 CY-23871-010000 PLUG PT1/8,SCREW 5

6 CY-16 82D1-01050 MODULATION VALVE 1

7 CY-16 82D1-01060 PISTON(ACCUMULATOR 1

8 CY-16 82D1-01070 SP(INNER 1

9 CY-16 82D1-01080 SP(OUTER 1

10 C Y-178 07 6- 0 243 0 VALVE ASSY, SOLENOID 1

11 CY-198213-247 50 COVER, DRV 1

12 C Y-1A6770-26 610 SOLENOID CMP 1

13 C Y-192159 -27 780 GASKET, SOLENOID 1

14 C Y-192159 -278 30 SPRING,SOLENOID 1

15 C Y-194170 - 45370 PLUG 1

16 CY-22351-060060 PIN 6.0AX60,SPRING 1

17 CY-24311-000070 O-RING 1A P-7.0 1

18 CY-24311-000240 O-RING 1A P-24.0 1

19 CY-24341-000112 O-RING 1A S-11.2 1

20 CY-26016 -0 60162 BOLT M 6X 16 3

21 C Y-1A82 75-2 4160 PLUG ASSY 1

22 C Y-1A82 75-2 454 0 GASKET, PTO VALVE 1

23 C Y-1A82 75-2 4550 VALVE ASSY, 1

24 C Y-1A8 275 -2457 0 CASE, PLATE PTO 1

25 C Y-1A82 75-2 4590 VALVE, RELIEF 1

26 CY-1A8275-24600 PLUG, RELIEF 1

27 C Y-194 555- 24610 SPRING, RELEASE 1

28 CY-1A8275-24610 PLUG, R1/4 1

29 C Y-1945 55-2 462 0 SPRING, RELEASE 1

Part Number Description Qty

Ref.

30 CY-1A8275-24620 SHIM, 0.5 2

31 CY-1A8275-24650 SLEEVE, 1

32 C Y-194 556 -4 222 0 STRAINER A 1

33 C Y-24351-24 0230 O-RING, 1A 24023 1

34 CY -1A827 5-24 56 0 PK, VALVE PLATE 1

35 C Y-198 44 8-2 843 0 BOLT M14,PIPE JOINT 1

36 C Y-1A82 75- 48 010 HOLDER,RELIEF ASSY 1

37 C Y-1A8 275 -4 802 0 HOLDER,RELIEF 1

38 CY-1A8275-48050 SPRING,CHECK 1

39 CY-23414-160000 GASKET 16, ROUND 1

40 CY-23887-160002 PLUG 16,HEX. 1

41 C Y-2419 0-16 00 01 BALL 1/2 1

42 CY-1A8275-48260 HP PIPE 1

43 C Y-1A8 275-4 854 0 LP PIPE,REAR HOUSING 1

44 C Y-1A8 275 -4 8570 PIPE,PTO LUB 1

45 C Y-194 44 0- 51620 CLAMP, WIRE HARNESS 1

46 C Y-172730-75141 JOINT 1

47 CY-23414-140000 GASKET 14, ROUND 2

48 C Y-23414 -200 026 GASKET 20 5

49 C Y-23414-220029 GASKET 22 2

50 CY-23857-150000 BOLT, JOINT M15 1

51 CY-23857-180000 JOINT BOLT 18 1

52 CY-23871-010000 PLUG PT1/8,SCREW 1

53 CY-24311-000070 O-RING 1A P-7.0 1

54 CY-24311-000140 O-RING 1A P-14.0 1

55 CY-26106-080802 BOLT M 8X 80 PLATED 3

56 CY-2 6106 -0 81002 BOLT M 8X100 PLATED 1

57 C Y-26106-100202 BOLT M10X 20 PLATED 1

58 CY-26366-080002 NUT M 8 2

Part Number Description Qty

90

Lx410LX Series

THIS PAGE INTENTIONALLY LEFT BLANK

91

0CNP5-G37900

40. FRONT COVER

LEV.REF. PARTS NO. DESCRIPTION

COVER ASSY, FRONT1A8275-2470011 111 CASE, REVERSE198448-2474022 111 GASKET, CASE198212-2475023 111

PLUG PT1/8,SCREW23871-01000024 222 SEAL TC30520824423-30520825 111 BOLT M 8X 50 PLATED26106-08050226 555

GASKET, FRONT COVER198212-2572017 111 PARALLEL PIN, M8X1622312-08018018 222 O-RING 1A S-35.024341-00035019 111 BOLT M 8X 35 PLATED26106-080352110 999 BOLT M 8X110 PLATED26106-081102111 222

Fig 40. Front Cover

Lx410LX Series

Ref.

Part Number Description Qty

1 C Y-1A82 75-2 4700 COVER ASSY, FRONT 1

2 CY-198 44 8-24 740 CASE, REVERSE 1

3 CY-198212-2 4750 GASKET, CASE 1

4 CY-23871-010000 PLUG PT1/8,SCREW 2

5 CY-24423 -305208 SEAL TC305208 1

6 CY-26106-080502 BOLT M 8X 50 PLATED 5

7 CY-198212-2 572 0 GASKET, FRONT COVER 1

8 CY-22312-080180 PARALLEL PIN, M8X16 2

9 CY-24341-000350 O-RING 1A S-35.0 1

10 CY-26106-080352 BOLT M 8X 35 PLATED 9

11 CY-26106-081102 BOLT M 8X110 PLATED 2

92

0CNP5-G37900

41. MAIN SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 41. Main Shaft

Lx410LX Series

93

Fig 41. Main Shaft

Lx410LX Series

Ref.

1 CY-1A8275-2 5130 SHAFT, PTO DRIVE 1

2 CY-198212-2 5150 COUPLING 13*16/32 1

3 CY-198212-25210 SHAFT, MIN 1

4 CY-198212-2 522 0 GEAR 21 1

5 CY-198212-2 524 0 GEAR 31, MAIN 1

6 CY-1985 35-2 526 0 GEAR 36 1

7 CY-198212-2 529 0 GEAR 27, MAIN 1

8 CY-194312 -25470 SPACER 30X40X2 1

9 CY-1942 50 -25520 SPACER 35X45X2 1

10 CY-198212-2 6090 BEARING 63/22NR 1

11 CY-22242-000340 CIRCLIP 34 4

12 CY-22252-000190 CIRCLIP 19 1

13 C Y-24101-06206 4 BALL BEARING 1

14 CY-24101-0 62074 BALL BEARING 1

Part Number Description Qty

94

0CNP5-G37900

42. DRIVEN SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 42. Driven Shaft

Lx410LX Series

95

Fig 42. Driven Shaft

Lx410LX Series

Ref.

1 CY-1942 50 -25240 NEEDLE BEARING 3

2 CY-198212-2 54 00 HUB ASSY, SYNCHRO 2

3 CY-198212-2 54 60 HUB, SYNCHRO 2

4 CY-198121-258 30 SLIDER 2

5 C Y-1A82 75-2 542 0 SHAFT, DRIVEN 1

6 CY-198535-25510 GEAR 39, DRIVEN 1

7 CY-198212-2 5520 GEAR 44, DRIVEN 1

8 CY-194150 -25530 WASHER 20X43X2.5 1

9 CY-198212-2 5530 GEAR 49, DRIVEN 1

10 CY-198212-2 554 0 GEAR 53, DRIVEN 1

11 CY-198121-258 40 SYNCHRONIZER RING 4

12 C Y-198121 -258 50 KEY A SYNCHRONIZER 6

13 C Y-194 64 0-2 58 60 WASHER 30.3X45X3 1

14 C Y-198121-258 70 SPRING ( SYNCHRONIZE 4

15 CY-22292-000340 CIRCLIP S-34 4

16 CY-24101-06206 4 BALL BEARING 1

17 C Y-24101-0 6305 4 BEARING #6305 1

18 C Y-24161- 303520 NEEDLE BEARING 1

19 C Y-2416 3-3 052 00 COLLAR 30X35X20 1

20 CY-24165-000402 CIRCLIP 3

Part Number Description Qty

96

Fig.43. COUNTER SHAFT

0CNP5-G37900

43. COUNTER SHAFT

LEV.REF. PARTS NO. DESCRIPTION

Fig 43. Counter Shaft

Lx410LX Series

97

Fig 43. Counter Shaft

Lx410LX Series

Ref.

1 CY-1943 01-1273 0 SHIM T=0.1 2

2 C Y-1A73 50-256 00 BEARING 4T-30306 CMP 1

3 CY-1A7350-25640 GEAR 19L, COUNTER 1

4 CY-198217-2 568 0 BUSHING 34*40*28 3

5 CY-198149-2 570 0 COLLAR ASSY, 1

6 CY-198149-2 570 0 COLLAR, SPLINE 1

7 CY-198149-2 589 0 SHIFTER 1

8 CY-1A8275-25750 GEAR 41, COUNTER 1

9 C Y-1A82 75-2 577 0 GEAR 53,COUNTER 1

10 C Y-1A76 01-25 790 COLLAR, SPLINE B 1

11 CY-1982 20 -258 30 NUT 16, LOWER 1

12 C Y-198 220 -25 84 0 NUT16, UPPER 1

13 C Y-198 415-2 584 0 WASHER 16X38X4.5 1

14 C Y-194 64 0-2 586 0 WASHER 30.3X45X3 1

15 C Y-19814 9-2 589 0 SHIFTER 1

16 C Y-1A82 75-2 598 0 COLLAR, 35 1

Part Number Description Qty

98

Lx410LX Series

THIS PAGE INTENTIONALLY LEFT BLANK

99

0CNP5-G37900

44. REDUCTION SHAFT

LEV.REF. PARTS NO. DESCRIPTION

GEAR, REDUCTION1A8275-2561011 111 COUPLING1A7090-2605012 111 BEARING #630524101-06305413 111

BALL BEARING24101-06306414 111

Fig 44. Reduction Shaft

Lx410LX Series

Ref.

Part Number Description Qty

1 CY-1A8275-2 5610 GEAR, REDUCTION 1

2 CY-1A7090-26050 COUPLING 1

3 CY-24101- 0630 54 BEARING #6305 1

4 CY-24101- 0630 64 BALL BEARING 1

100

0CNP5-G37900

45. POWER REVERSER

LEV.REF. PARTS NO. DESCRIPTION

Fig 45. Power Reverser

Lx410LX Series

Cub Cadet Yanmar Lx410 Part List Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
