Cub Cadet Yanmar Ex32002 Part List Manual

Parts List
Manual

Ex Series Compact Tractor

Cub Cadet Yanmar LLC
P.O. Box 361052
Cleveland, OH 44136-1052

PRINTED IN U.S.A.

Version 1.0

Code No: NPC-4832P110

Ex Series Ex32002

INSTRUCTIONS FOR PARTS LIST MANUAL

ENGINE SECTION - PAGES 3 THROUGH 26

TRACTOR SECTION - PAGES 27 THROUGH 181

EXAMPLE - FIGURE & REFERENCE NUMBERS

Ex Series Ex320

0

3

ENGINE SECTION INDEX

FIG. NO. GROUP NAME

1 CYLINDER BLOCK
2 GEAR HOUSING
3 OIL PAN & REAR ENGINE PLATE
4 CYLINDER HEAD & VALVE COVER
5 INTAKE MANIFOLD
6 EXHAUST MANIFOLD & MUFFLER
7 CAMSHAFT & TIMING PARTS
8 CRANKSHAFT & PISTON

9 HYDRAULIC PUMP
10 LUBRICATING PARTS
11 COOLING WATER SYSTEM
12 FUEL INJECTION PUMP
13 GOVERNOR
14 FUEL SUPPLY PARTS
15 STARTER
16 ALTERNATOR

TRACTOR SECTION STARTS ON PAGE 27

Ex Series Ex32004

NOTES:

Ex Series Ex3200

5

FIG. 1. CYLINDER BLOCK

REF

NO.

1 CY-729005-01562 BLOCK ASSY, CYLINDER 1
4 CY-124060-01050 PLUG PT1/8 1
5 CY-129001-01250 PLUG 50 1
6 CY-124160-01910 PLUG PT1/4 2
7 CY-124160-01910 PLUG PT1/4 1
8 CY-171051-01921 PLUG 1

9 CY-129150-02020 BOLT, METAL CAP 8
12 CY-129795-02412 BUSH, CAMSHAFT 1
13 CY-27241-120000 PLUG 12 2
14 CY-27241-300000 PLUG 30 6
24 CY-129001-02931 MAIN BEARING SET 4
27 CY-129150-02931 METAL, THRUST 2
30 CY-129150-01200 STUD, CYL. HEAD 14
31 CY-129001-01340 GASKET, (NON-ASB.) 1
32 CY-129150-02871 MAIN METAL US=0.25 UNDER-SIZE 4
35 CY-129150-02941 METAL,THRUST.25 (2PIE) OVER-SIZE 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

6

FIG. 2. GEAR HOUSING

REF

NO.

1
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
23
24

PART NUMBER DESCRIPTION QTY

CY-729008-01500 GEAR CASE ASSY W/SEAL 1
CY-119934-01800 SEAL, OIL 1
CY-129008-01520 FLANGE, GEAR CASE 1
CY-119802-01561 STUD, M8X25 3
CY-129150-01580 STUD 8 X 30 1
CY-124160-01751 COVER, FILLER 1
CY-124240-01871 COVER, HO-P 1
CY-129795-01950 PIPE, KNOCK L=18 2
CY-119609-32040 O-RING P16 2
CY-121850-51960 O-RING, F.I.PUMP 1
CY-129001-91841 BOLT, M8X85 3
CY-22190-080002 SEAL WASHER 8S 4
CY-22190-080002 SEAL WASHER 8S 1
CY-24311-000320 O-RING 1A P-32.0 1
CY-26106-080162 BOLT M 8X 16 PLATED 4
CY-26106-080162 BOLT M 8X 16 PLATED 3
CY-26106-080302 BOLT M 8X 30 PLATED 1
CY-26106-080552 BOLT M 8X 55 PLATED 10
CY-26306-080002 NUT 3
CY-129150-91400 GEAR UNIT, TACHOMETER 1
CY-24341-000240 O-RING 1A S-24.0 1
CY-26106-060162 BOLT M 6X 16 PLATED 2

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

7

FIG. 3. OIL PAN & REAR ENGINE PLATE

REF

NO.

1 CY-129100-01580 PARALLEL PIN 8X16 2

2 CY-129129-01600 PLATE, REAR MOUNTING 1

3 CY-26206-100202 BOLT M10X20 6

4 CY-26206-100202 BOLT M10X20 4

5 CY-129129-01550 PAN ASSY, ENGINE OIL 1

6 CY-129129-01540 COVER ASSY, OIL PAN 1

7 CY-105425-01690 PLUG M16 1

8 CY-129150-01721 COVER, OIL PAN 1

9 CY-22190-160002 SEAL WASHER 16S 1
11 CY-26106-080122 BOLT M 8X 12 PLATED 8
12 CY-129001-91841 BOLT, M8X85 8
13 CY-129001-91910 BOLT, M8X120 4
14 CY-26106-080252 BOLT M 8X 25 PLATED 6
15 CY-26106-080502 BOLT M 8X 50 PLATED 4
16 CY-129100-01580 PARALLEL PIN 8X16 2
17 CY-729402-01650 CASE ASSY, OIL SEAL 1
19 CY-129120-01780 SEAL, OIL 1
20 CY-129486-01670 BOLT M8X30, COLLAR HD 9

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

8

FIG. 4. CYLINDER HEAD & VALVE COVER

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

9

FIG 4. CYLINDER HEAD & VALVE COVER

REF

NO.

1 CY-129004-11241 SHAFT ASSY, ROCKER 1

2 CY-129004-11251 SHAFT, ROCKER ARM 1

4 CY-119802-11260 SUPPORT, ROCKER ARM 2

5 CY-119802-11270 SUPPORT, ROCKER ARM 2

6 CY-119802-11280 STUD, 8X18 3

7 CY-129150-11280 SPRING 3

8 CY-129004-11650 ARM ASSY, ROCKER 6

9 CY-129150-11230 SCREW, VALVE 6
11 CY-129150-11750 NUT M8XP1.0 6
12 CY-129150-11370 CAP, VALVE 6
13 CY-129008-11700 HEAD ASSY, CYLINDER 1
16 CY-120130-11860 GUIDE, VALVE 3
18 CY-129150-11810 GUIDE, VALVE 3
20 CY-27241-400000 PLUG 40 2
21 CY-129005-11100 VALVE, INTAKE 3
22 CY-129100-11112 VALVE, EXHAUST 3
23 CY-129795-11120 SPRING, VALVE 6
24 CY-129795-11180 RETAINER, SPRING 6
25 CY-121400-11340 SEAL, VALVE STEM 3
26 CY-124460-11340 SEAL, VALVE STEM 3
27 CY-27310-080001 COTTER 8 6
29 CY-119802-11870 PROTECTOR, NOZZLE 3
30 CY-119625-11880 SEAT, NOZZLE 3
31 CY-129004-11900 RETAINER, NOZZLE 3
32 CY-120270-54410 WASHER 3
33 CY-22351-060012 SPRING PIN 6X12 2
34 CY-26106-080252 BOLT M 8X 25 PLATED 2
35 CY-26106-080352 BOLT M 8X 35 PLATED 3
36 CY-26106-080502 BOLT M 8X 50 PLATED 6
37 CY-129055-11350 COVER ASSY, VALVE 1
38 CY-129004-03010 PLATE, BAFFLE 1
39 CY-129150-03070 BAFFLE, BREATHER 1
40 CY-119802-03110 PLATE, DIAPHRAGM 1
41 CY-119802-03121 COVER, DIAPHRAGM 1
42 CY-119802-03130 DIAPHRAGM 1
43 CY-119802-03141 SPRING, DIAPHRAGM 1
45 CY-129004-11310 GASKET, VALVE COVER 1
46 CY-22857-500100 SCREW 5X10,TAPPING 4
47 CY-22857-500100 SCREW 5X10,TAPPING 4
48 CY-124160-11360 KNOB 3
49 CY-24311-000120 O-RING 1A P 12.0 3
50 CY-129900-07900 LIFTER, ENGINE 1
51 CY-26106-080162 BOLT M 8X 16 PLATED 2
52 CY-119803-77830 HARNESS, GLOW PLUG 1
53 CY-129008-77800 PLUG, GLOW 3
54 CY-129008-77820 CONNECTOR, GLOW PLUG 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

10

FIG. 5. INTAKE MANIFOLD

REF

NO.

1 CY-129005-03080 PIPE, BREATHER 1

2 CY-129410-03990 CLAMP 22 2

3 CY-129005-12100 MANIFOLD, INTAKE 1

4 CY-129001-12110 GASKET,INT. MANIFOLD 1

5 CY-26106-080202 BOLT M 8X 20 PLATED 4

6 CY-26106-080802 BOLT M 8X 80 PLATED 1

7 CY-129486-12581 PIPE, INTAKE 1

8 CY-129150-77511 GASKET, (NON-ASB.) 1

9 CY-26106-080202 BOLT M 8X 20 PLATED 4

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

11

FIG. 6. EXHAUST MANIFOLD & MUFFLER

REF

NO.

1 CY-129269-13100 MANIFOLD, EXHAUST 1

2 CY-129150-13110 GASKET, MANIFOLD 1

3 CY-119131-18320 BOLT M 8X 22 4

4 CY-123900-13630 BOLT 8X80 4

5 CY-129263-13220 BOLT M8X95 2

6 CY-26306-080002 NUT 2

7 CY-129004-13200 GASKET, MUFFLER 1

8 CY-129055-13521 MUFFLER 1

9 CY-26306-080002 NUT 4

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

12

FIG. 7. CAMSHAFT & TIMING PARTS

REF

NO.

1 CY-129150-14200 TAPPET 6

2 CY-129150-14400 ROD, PUSH 6

3 CY-129129-14580 CAMSHAFT ASSY 1

4 CY-129150-02450 METAL, THRUST CAM 1

6 CY-129150-14101 GEAR, CAMSHAFT 1

7 CY-22512-070140 KEY 7X 14 1

8 CY-26106-080142 BOLT 8X 14 PLATED 2

9 CY-119803-25050 SHAFT, IDLE GEAR 1
10 CY-119802-25101 GEAR ASSY, IDLE 1
13 CY-119802-25071 BUSH, IDLE GEAR 1
14 CY-26106-080402 BOLT M 8X 40 PLATED 3
15 CY-129150-25301 BOLT, INJECTION PUMP GEAR 4
16 CY-119802-25901 GEAR, PUMP 1
17 CY-129150-01881 GASKET, (NON ASB.) 1
18 CY-129150-26000 GEAR ASSY, HYD PUMP CAM 1
19 CY-129150-26050 BRACKET, HYD PUMP GEAR 1
21 CY-24105-060064 BALL BEARING 2
22 CY-158552-51151 FLANGE 1
23 CY-22217-140000 SPRING WASHER 14 1
24 CY-26776-140002 LOCK NUT M14 PLATED 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

13

FIG. 8. CRANKSHAFT & PISTON

REF

NO.

1 CY-129008-21000 CRANKSHAFT ASSY 1
2 CY-129100-01580 PARALLEL PIN 8X16 1
4 CY-119803-21200 GEAR, CRANKSHAFT 1
5 CY-22512-070140 KEY 7X 14 1
7 CY-22512-070140 KEY 7X 14 1
8 CY-129055-21650 V-PULLEY, CRANKSHAFT 1

9 CY-129795-21661 WASHER 1
10 CY-121850-21680 BOLT, V-PULLEY 1
11 CY-124160-21501 BOLT, FLYWHEEL 6
12 CY-129269-21590 FLYWHEEL ASSY 1
14 CY-119865-21600 GEAR, RING 1
15 CY-121820-21690 BEARING 1
16 CY-129005-22080 PISTON ASSY 3
18 CY-129005-22500 RING SET, PISTON 3
22 CY-129202-22300 PIN, PISTON 3
23 CY-22252-000260 CLIP, PISTON PIN 6
24 CY-729402-23100 ROD ASSY, CONNECTING 3
27 CY-129100-23910 BUSH, PISTON PIN 3
28 CY-121550-23200 BOLT, CONNECTING ROD 6
29 CY-129150-23601 BEARING SET, CON-ROD 3
31 CY-129150-23611 BEARING SET, CON-ROD US=0.25 3
33 CY-129005-22900 PISTON W/RING OS=.25 3
35 CY-129005-22950 RING SET OS=0.25 3

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

14

FIG. 9. HYDRAULIC PUMP

REF

NO.

1 CY-124240-01883 GASKET, (NON-ASB.) 2
2 CY-178070-16000 PUMP, HYDRAULIC 1
4 CY-178070-10401 SQUARE RING 1

13 CY-194521-41570 PIN 11X7 2
15 CY-22252-000320 CIRCLIP 32 1
16 CY-24421-153207 SEAL TC15 32 07, OIL 1
17 CY-26016-080352 BOLT M 8X 35 4
18 CY-178070-44000 PUMP, HYDRAULIC 1
20 CY-178070-10401 SQUARE RING 1
26 CY-194521-41570 PIN 11X7 2
31 CY-22252-000320 CIRCLIP 32 1
32 CY-24421-153207 SEAL TC15 32 07, OIL 1
33 CY-26016-080352 BOLT M 8X 35 4
34 CY-26106-080802 BOLT M 8X 80 PLATED 2
35 CY-26106-080952 BOLT M 8X 95 PLATED 2
36 CY-26216-080222 STUD M 8X 22 PLATED 2
37 CY-26216-080402 STUD M 8X 40 PLATED 1
38 CY-26306-080002 NUT 4

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

15

FIG. 10. LUBRICATING PARTS

REF

NO.

1 CY-129001-32001 PUMP ASSY, ENGINE OIL 1

14 CY-129150-32020 GASKET, ENGINE OIL PUMP 1
15 CY-26450-060252 BOLT M 6X 25 4
16 CY-121520-34810 TUBE, DIPSTICK 1
17 CY-119265-34830 DIPSTICK, ENGINE OIL 1
18 CY-129150-35042 GASKET, (NON-ASB.) 1
19 CY-129129-35090 PICK-UP ASSY, ENGINE OIL 1
20 CY-129129-35010 INLET 1
21 CY-129129-35080 PIPE, ENGINE OIL PICK-UP 1
22 CY-26106-080122 BOLT M 8X 12 PLATED 1
23 CY-26106-080352 BOLT M 8X 35 PLATED 2
24 CY-119802-35100 BRACKET ASSY, FILTER 1
25 CY-119802-35110 BRACKET, FILTER 1
26 CY-129100-35140 STUD 1
27 CY-129150-35111 GASKET, (NON-ASB.) 1
28 CY-129150-35160 FILTER 80X80L 1
29 CY-26106-080202 BOLT M 8X 20 PLATED 3
30 CY-114250-39450 SWITCH,(0.5KG) ENGINE OIL 1
31 CY-124160-39140 BOLT, BANJO 1
32 CY-119802-39450 PIPE ASSY, INJECTION PUMP 1
33 CY-129005-59830 BOLT WITH SEAL 1
34 CY-22190-080002 SEAL WASHER 8S 1
35 CY-23857-030000 BOLT, BANJO 1
36 CY-22190-080002 SEAL WASHER 8S 1
37 CY-22190-100002 SEAL WASHER 10S 2
38 CY-26366-060002 NUT M 6 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

16

FIG. 11. COOLING WATER SYSTEM

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

17

FIG. 11. COOLING WATER SYSTEM

REF

NO.

1 CY-129403-42380 V-PULLEY(D=110) 1
2 CY-129211-42290 V-BELT 1
3 CY-129120-44741 FAN, COOLING (D=360) 1
4 CY-129030-44760 SPACER 1
5 CY-26106-060502 BOLT M 6X 50 PLATED 4
6 CY-129155-49801 THERMOSTAT (71) 1
7 CY-129150-49811 GASKET, (NON-ASB.) 1
8 CY-129795-49551 GASKET, (NON-ASB.) 1

9 CY-129350-49560 COVER, THERMOSTAT 1
10 CY-26306-080002 NUT 2
11 CY-129263-49610 PIPE, COOLING WATER 1
12 CY-129263-49710 PIPE, COOLING WATER 1
13 CY-124722-59050 CLAMP 9 2
14 CY-129263-49620 PIPE, COOLING WATER 1
15 CY-129263-49720 PIPE, COOLING WATER 1
16 CY-124722-59050 CLAMP 9 2
17 CY-119620-49290 DRAIN ASSY 1/4 1
21 CY-121450-42450 PLUG M16 1
22 CY-129054-42450 PLUG, M12X1.5 1
23 CY-124465-44950 GASKET 16 1
24 CY-124250-49351 THERMOMETER 1
25 CY-129150-49360 GASKET 10 1
26 CY-22190-120002 SEAL WASHER 12 1
27 CY-129486-42050 GASKET 1
28 CY-23414-080000 GASKET 8, ROUND 1
29 CY-26106-080122 BOLT M 8X 12 PLATED 1
30 CY-26106-080552 BOLT M 8X 55 PLATED 2
31 CY-26106-080602 BOLT M 8X 60 PLATED 1
32 CY-26106-080702 BOLT M 8X 70 PLATED 1
33 CY-129269-42000 PUMP ASSY, WATER 1
34 CY-129457-42050 PACKING 1
35 CY-129457-42121 PLATE 1
39 CY-129150-42301 FLANGE, PUMP 1
40 CY-24358-240310 O-RING 5 24031 1
42 CY-129054-42320 O-RING 1
43 CY-26577-060152 SCREW M 6X 15 3
44 CY-26106-060202 BOLT M 6X 20 PLATED 2
45 CY-26116-060162 BOLT 6X16 5
46 CY-119802-49113 JOINT 2
47 CY-23875-030000 PLUG PT3/8,STEEL 2
49 CY-129555-44750 STUD 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

18

FIG. 12. FUEL INJECTION PUMP

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

19

FIG. 12. FUEL INJECTION PUMP

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-729269-51300

7 CY-119802-51090 KEY, WOODRUFF 4X16 1 95 CY-22190-120002 SEAL WASHER 12 1
32 CY-158600-51270
33 CY-158563-51281
34 CY-158563-51281
35 CY-129008-51300 VALVE ASSY, DELIVERY 3 100 CY-158552-52310 O-RING 1
43 CY-158563-51330
44 CY-129008-51340
51 CY-158601-51550
52 CY-119802-51560
53 CY-158552-51570
54 CY-158552-51570
55 CY-158557-51570
56 CY-158601-51570 PLUG, WATER PUMP 1 109 CY-24356-010180 O-RING 1
57 CY-158552-51580
58 CY-119802-51590
59 CY-119802-51600
62 CY-158553-51670 O-RING, 1011 1 116 CY-26776-140002 LOCK NUT M14 PLATED 1
63 CY-119802-51680 BACKUP RING 1 119 CY-158553-51551 JOINT, COOLING WATER 1
64 CY-119802-51690
65 CY-24356-010200
66 CY-24372-000150
67 CY-158552-51600
68 CY-158553-51630
70 CY-158553-51640
71 CY-158553-51660
72 CY-158553-51680
92 CY-158601-51770
93 CY-158552-51781

INJECTION PUMP ASSY

STOPPER
O-RING
O-RING

SPRING
HOLDER, DELIVERY
PLUG
BARREL PLUG
GASKET
GASKET
PLUG

LIFTER
TIMER SET
TIMER CMP

O RING
PACKING, 1020
RING, BACKUP T2 P 15
PACKING, HEAD
SPRING, TIMER
ELEMENT, THERMO
O-RING,P14
PACKING, TIMER
PISTON
DAMPER ASSY

REF

NO.

PART NUMBER DESCRIPTION QTY

1 94 CY-158601-51790

1 96 CY-22190-180002
1 97 CY-23887-120002
1 99 CY-158553-51770

3 101 CY-158552-52400
3 102 CY-22190-120002
1 103 CY-22190-180002
1 104 CY-22217-140000
3 105 CY-22312-050140
1 106 CY-22351-050010
1 108 CY-24311-000070

1 110 CY-24356-010200
1 111 CY-26106-060102
1 115 CY-26450-080452

1 120 CY-158601-51650
1 121 CY-158552-51670
1 123 CY-158552-52100
1 124 CY-158552-52500
1 125 CY-129916-59020
1 127 CY-22190-120002
1 128 CY-23857-060000
1 129 CY-119802-51250
1 130 CY-26106-080162
1 131 CY-26106-080202

PLUG

SEAL WASHER 18
PLUG M12, HEX.
BOLT

O-RING 4E S42
SEAL WASHER 12
SEAL WASHER 18
SPRING WASHER 14
PARALLEL PIN 5X14
SPRING PIN 5X10
O-RING 1A P-7.0

PACKING, 1020
BOLT 6X 10 PLATED
BOLT M 8X 45

JOINT
JOINT
PUMP ASSY, FEED
O-RING, FEED P INNER
JOINT 12, PIPE
SEAL WASHER 12
JOINT BOLT 6,PIPE
BRACKET, PUMP
BOLT M 8X 16 PLATED
BOLT M 8X 20 PLATED

1

1
1
4

1
2
2
1
2
2
1

1
1
4

1
1
1
1
1
2
1
1
1
1

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

20

FIG. 13. GOVERNOR

REF

NO.

1 CY-194150-01370 ADJUSTER 1
4 CY-158553-61050 PACKING, CASE 1
5 CY-158553-61070 PACKING 1

7 CY-129155-51280 O-RING S6 1
23 CY-129255-61410 NUT 1
24 CY-119807-61420 SPRING 1
25 CY-158552-61441 LEVER, REGULATOR 1
26 CY-129155-61460 BOLT, IDLE LIMIT 1
60 CY-119660-61901 RETAINER, SHAFT 1
64 CY-22190-120000 SEAL WASHER 12(BOLT) 1
66 CY-23887-120002 PLUG M12,HEX. 1
68 CY-26106-060102 BOLT 6X 10 PLATED 1
69 CY-26756-060002 LOCK NUT 6 1
78 CY-158552-61900 O-RING 1
83 CY-26106-060142 BOLT M 6X 14 PLATED 2
84 CY-26106-060142 BOLT M 6X 14 PLATED 4
85 CY-26106-060202 BOLT M 6X 20 PLATED 10
87 CY-129642-61060 COVER, CASE 1

130 CY-119653-77950 SOLENOID, STOP 1
131 CY-22137-080000 WASHER 8, POLISHED 1
132 CY-22417-160180 COTTER PIN 1.6X18 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

21

FIG. 14. FUEL SUPPLY PARTS

REF

NO.

10 CY-114250-53120 SPRING, NOZZLE 3
11 CY-114250-53130 SEAT, NOZZLE SPRING 3
12 CY-114250-53140 PLATE, STOP 3
13 CY-114250-53210 PIN 6
14 CY-114250-53400 SHIM PACK 3
26 CY-129150-59120 RETAINER, INJ. PIPE 2
29 CY-129150-59131 BOLT M4X14,HEX.SCKT. 4
31 CY-129004-59811 PIPE ASSY, INJECTION 1
35 CY-129004-59821 PIPE ASSY, INJECTION 1
39 CY-129004-59831 PIPE ASSY, INJECTION 1
44 CY-119802-59550 PIPE ASSY, RETURN 1
45 CY-124722-59050 CLAMP 9 2
46 CY-119802-59560 PIPE, FUEL RETURN 1
47 CY-129486-59551 PIPE, FUEL RETURN 2
48 CY-124722-59050 CLAMP 9 4
50 CY-119593-59581 CAP 1
51 CY-124060-77680 CLAMP 10 1

PART NUMBER DESCRIPTION QTY

1 CY-729008-53100 FUEL INJECTOR 3
2 CY-129008-53000 NOZZLE ASSY 3
5 CY-114250-53080 NUT, NOZZLE CASE 3
6 CY-119802-53100 HOLDER ASSY, NOZZLE 3

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

22

FIG. 15. STARTER

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

23

FIG. 15. STARTER

REF

NO.

1 CY-129129-77010 STARTER ASSY 1
2 CY-X0283060061 ROLLER 5
3 CY-129129-77460 SCREW 2
4 CY-X9490561370 NUT 1
5 CY-X9491200240 BALL 1
6 CY-129129-77210 YOKE ASSY 1
7 CY-129129-77220 ARMATURE ASSY 1
8 CY-129129-77230 BEARING 1

9 CY-129129-77240 BEARING 1
10 CY-129129-77250 STARTER ASSY 1
11 CY-X0280210230 NUT 1
12 CY-X0283270140 RETAINER 1
13 CY-X9491703371 SPRING, COIL 1
14 CY-129129-77390 CLUTCH ASSY, STARTER 1
17 CY-129129-77400 SHAFT 1
18 CY-129129-77410 SPRING, COIL 1
19 CY-129129-77420 PINION 1
20 CY-129129-77430 RING 1
21 CY-129129-77260 RETAINER 1
22 CY-129129-77270 PINION 1
23 CY-129129-77280 HOUSING 1
24 CY-129129-77290 FRAME 1
25 CY-129129-77300 HOLDER ASSY 1
26 CY-X9491730461 SPRING 4
27 CY-129129-77310 SWITCH ASSY 1
28 CY-129129-77320 BOLT 2
29 CY-129129-77330 BOLT 2
30 CY-129129-77340 SPRING 1
31 CY-129129-77350 O-RING 2
32 CY-129129-77362 COVER 1
34 CY-129129-77380 CAP 1
35 CY-129155-77060 BOLT, STARTER 1
36 CY-26116-120202 BOLT M12X 20 PLATED 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

24

FIG. 16. ALTERNATOR

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

25

FIG. 16. ALTERNATOR

REF

NO.

1 CY-129795-01900 STUD 1
2 CY-119620-77201 ALTERNATOR 1
3 CY-X9490561001 NUT 1
4 CY-119620-77380 ROTOR ASSY 1
5 CY-123501-79240 BEARING, BALL 1
6 CY-119620-79250 COVER, BEARING 1
7 CY-119620-79360 THRUST WASHER 1
8 CY-119620-77421 FLAME ASSY, DRIVE 1

9 CY-119620-79200 BALL BEARING 1
10 CY-119620-79210 PLATE 1
11 CY-119620-79220 SCREW 4
12 CY-119620-79230 BOLT, STUD 2
13 CY-119620-77440 FLAME ASSY, REAR 1
14 CY-119620-77450 COVER 1
15 CY-119620-77461 PULLEY 1
16 CY-119620-77471 NUT 1
17 CY-119620-77490 COLLAR 1
18 CY-119620-77710 REGULATOR ASSY 1
19 CY-119620-79260 HOLDER 1
20 CY-119620-79270 HOLDER, BRUSH 1
21 CY-119620-77480 BRUSH ASSY 2
22 CY-119620-79280 SPRING 2
23 CY-119620-79290 SCREW 6
24 CY-119620-79300 SCREW 1
25 CY-119620-79310 BOLT 3
26 CY-119620-79320 SCREW W/WASHER 2
27 CY-119620-79330 BOLT 2
28 CY-119620-79340 INSULATION BUSH 1
29 CY-119620-79350 NUT 2
30 CY-26306-100002 NUT 1
31 CY-129107-77330 ADJUSTER, BELT 1
32 CY-124732-77340 SPACER 1
33 CY-129972-77341 BOLT, ADJUSTING 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

26

THIS PAGE INTENTIONALLY LEFT BLANK

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

K

K

K

T

T

T

27

TRACTOR SECTION INDEX

FIG. NO

ENGINE CONTROL SECTION

1 ENGINE ACCESSORIES 49 P.T.O. SHIFTER
2 ENGINE ACCESSORIES MOUNTING 50 P.T.O. LEVER
3 ACCELERATOR LEVER 51 FRONT DRIVE
4 EXHAUST 52 HYDROSTATIC (HST)
5 FUEL TAN
6 FUEL TANK MOUNTING
7 EXHAUST MANIFOLD PLATE

FRONT AXLE SECTION

8 FRONT FRAME 56 DIFFERENTIAL CARRIER

9 FRONT WEIGHT BRACKET 57 REAR HOUSING
10 CENTER PIN 58 DIFFERENTIAL LOC
11 TIE ROD 59 FINAL PINION
12 RING GEAR 60 FINAL GEAR & REAR AXLE SHAF
13 DIFFERENTIAL GEAR 61 REAR WHEEL TIRE (BAR)
14 PROPELLER SHAFT 62 REAR WHEEL TIRE (TURF)
15 FRONT DRIVE SHAFT 63 REAR WHEEL TIRE
16 FRONT AXLE CASE 64 HUB BOLT(REAR)
17 FRONT GEAR CASE 65 HYDRAULIC PEDAL
18 FRONT SHAFT 66 SHOCK ABSORBER
19 FRONT SPINDLE 67 BRAKE
20 SHAFT COVER 68 BRAKE PEDAL
21 FRONT WHEEL TIRE (BAR)
22 FRONT WHEEL TIRE (TURF)
23 FRONT WHEEL TIRE 69 HYDRAULIC CYLINDER CASE
24 HUB BOLT (FRONT) 70 PISTON
25 STEERING WHEEL 71 LIFT CRANK
26 POWER STEERING CYLINDER 72 CONTROL VALVE
27 POWER STEERING VALVE 73 RELIEF VALVE
28 POWER STEERING LINES 74 STOP VALVE

TRANSMISSION SECTION

29 CLUTCH HOUSING 77 HYDRAULIC CONTROL
30 DOCKING BOLT 78 HYDRAULIC PIPING
31 SINGLE CLUTCH 79 OIL FILTER
32 CLUTCH SHAFT 80 OIL COOLER
33 CLUTCH RELEASE 81 HYDROSTATIC (HST) LINES & FILTER
34 BEARING SLEEVE
35 CLUTCH PEDAL
36 TRANSMISSION CASE 82 WIRE HARNESS
37 CENTER PLATE 83 BATTERY
38 BEARING RETAINER 84 SWITCHES
39 OIL STRAINER 85 SEAT SWITCH
40 INPUT GEAR 86 LAMPS
41 REDUCTION SHAFT 87 FRONT LAMPS
42 COUNTER SHAFT 88 INSTRUMENT PANEL
43 P.T.O. DRIVE SHAF
44 P.T.O. SHAF
45 P.T.O. SHIELD continued on page 29…..
46 RANGE LEVER
47 RANGE LEVER PARTS
48 CRUISE CONTROL

GROUP NAME FIG. NO GROUP NAME

53 HST LIN

REAR AXLE SECTION

54 RING GEAR
55 DIFFERENTIAL GEAR

HYDRAULIC CONTROL SECTION

75 SAFETY VALVE
76 HYDRAULIC SUB CONTROL VALVE

ELECTRICAL PARTS SECTION

89 RELAY

Ex Series Ex320028

NOTES:

Ex Series Ex3200

Y

K

K

29

TRACTOR SECTION INDEX

FIG. NO

FITING SECTION

90 FRONT FRAME
91 HOOD
92 FRONT GRILLE
93 SIDE COVER
94 HOOD FRAME
95 DASHBOARD
96 FENDER
97 FENDER STAY
98 STEP
99 STEP AUXILIAR

100 SEAT
101 SEAT BELT
102 LABELS
103 LABELS (SAFETY)

HITCH SECTION

104 THREE POINT LIN
105 DRAFT PIN & TOP HOO
106 CHECK CHAIN BRACKET
107 DRAW BAR HITCH
108 SAFETY FRAME
109 REAR BRACKET

GROUP NAME

continued from page 27

OPTIONAL SECTION

110
111
112
113
114 WORK LAMP (OPTIONAL)

MID P.T.O. KIT 59A40014727 (OPTIONAL)
MID P.T.O. KIT 59A40014727 CONTROLS (OPTIONAL)
FRONT WEIGHT BRACKET EXTENSIONS (OPTIONAL)
POWER BEYOND KIT 59A40022727 (OPTIONAL)

Ex Series Ex3200

30

FIG. 1. ENGINE ACCESSORIES

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

31

FIG. 1 ENGINE ACCESSORIES

REF

NO.

1 CY-129269-12500 CLEANER ASSY, AIR 1
2 CY-129051-12530 ELEMENT, INNER 1
3 CY-129087-12510 ELEMENT 5INCH 1
4 CY-119866-12540 COVER ASSY 1
5 CY-119808-12540 VALVE, UNLOADER 1
6 CY-129418-12530 MARK 2
7 CY-129612-12650 MARKING,(W) 1
8 CY-129263-44500 RADIATOR T=36 CMP 1

9 CY-129107-44590 CAP, RADIATOR 1
10 CY-129467-44580 MOUNT RUBBER 2
11 CY-129467-44590 COLLAR 2
12 CY-129263-44510 TANK ASSY, SUB 1
13 CY-121450-44531 CAP 1
14 CY-23065-070180 PIPE 7X 180 1
15 CY-124450-44560 CLAMP 1
16 CY-121470-44581 GASKET 1
17 CY-119255-44660 RUBBER 2
18 CY-124764-44810 LABEL, SUB-TANK 1
19 CY-129550-49101 COCK ASSY, 2-WAY 1
20 CY-129150-49081 COCK, DRAIN 1
21 CY-119852-55611 BRACKET, FILTER 1
22 CY-119802-55700 SEPARATOR ASSY 1
23 CY-129100-55690 RING, RETAINING 1
24 CY-119802-55710 ELEMENT 1
25 CY-24311-000160 O-RING 1A P-16.0 1
26 CY-24321-000650 O-RING 1A G-65.0 1
27 CY-119802-55801 FILTER, FUEL 1
28 CY-129211-77920 TIMER 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

32

FIG. 2. ENGINE ACCESSORIES MOUNTING

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

33

FIG. 2. ENGINE ACCESSORIES MOUNTING

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-1A7260-01030 RAIL, RADIATOR L 1 28 CY-1A7260-60211 STAY ASSY, L.H. 1
2 CY-1A7260-01040 RAIL, RADIATOR R 1 29 CY-1A7260-60221 STAY ASSY, R.H. 1
3 CY-1A8160-01210 HOSE, UPPER 1 30 CY-1A8160-60720 GROMMET SHROUD 1
4 CY-1A7260-01220
5 CY-194180-01240 GROMMET 13 1 32 CY-1A7260-61860 WEATHER-STRIP, A 1
6 CY-1A7260-01250 SCREEN, RADIATOR 1 33 CY-1A7260-61970 WEATHER-STRIP, B 1
7 CY-1A8160-01300 SHROUD, FAN 1 34 CY-174570-63620 WEATHER-STRIP, 195 2
8 CY-1A7260-03151 HOSE ASSY, OVERFLOW 1 35 CY-23000-070000 CLAMP 70 2

9 CY-1A7260-03160 HOSE, OVERFLOW A 1 36 CY-23980-730270

10 CY-1A7260-03170 HOSE, OVERFLOW B 1 36 CY-23980-730250

11 CY-1A7260-03180 ELBOW, 1 37 CY-23980-730270 HOSE, 7.3 X 270 1
12 CY-124766-59050 CLAMP 12 2 38 CY-23980-730330 HOSE 7.3,BRAIDED 1

13 CY-1A8160-04430 HOSE A,FUEL 1 39 CY-23980-730850

14 CY-1A8160-04440 HOSE B,FUEL 1 39 CY-23980-730890

15 CY-1A8160-06200 INTAKE PIPE 1 40 CY-26106-060122 BOLT M 6X 12 PLATED 4
16 CY-1A8160-11240 BRACKET, SEPARETOR 1 41 CY-26106-060122 BOLT M 6X 12 PLATED 2
17 CY-1A8160-11270 BRACKET A, FILTER 1 42 CY-26106-060252 BOLT M 6X 25 PLATED 2
18 CY-1A8160-11290 BRACKET B, FILTER 1 43 CY-26106-080122 BOLT M 8X 12 PLATED 2
19 CY-124766-59050 CLAMP 12 4 44 CY-26106-080162 BOLT M 8X 16 PLATED 4
20 CY-121267-49500 BAND, HOSE 38 2 45 CY-26106-080162 BOLT M 8X 16 PLATED 2
21 CY-175022-49750 CLIP 37, HOSE 2 46 CY-26106-080162 BOLT M 8X 16 PLATED 2

22 CY-194440-51620 CLAMP, WIRE HARNESS 1 47 CY-26106-080252

23 CY-194440-51620 CLAMP, WIRE HARNESS 1 47 CY-26106-080302

24 CY-194680-51670 BAND 1 48 CY-26106-080252 BOLT M 8X 25 PLATED 2
25 CY-124766-59050 CLAMP 12 2 49 CY-26106-080252 BOLT M 8X 25 PLATED 2
26 CY-124766-59050 CLAMP 12 2 50 CY-26106-080702 BOLT M 8X 70 PLATED 1
27 CY-124766-59050 CLAMP 12 8 51 CY-26106-100202 BOLT M10X 20 PLATED 2

HOSE, LOWER

REF

NO.

PART NUMBER DESCRIPTION QTY

1 31 CY-1A7260-60860 URETHANE, RADIATOR 1

HOSE, 7.3 X 270 - S/N
F000155 & BELOW
HOSE, 7.3 X 250 - S/N
F000156 & ABOVE

HOSE, 7.3 X 850 - S/N
F000155 & BELOW
HOSE, 7.3 X 890 - S/N
F000156 & ABOVE

BOLT M 8X 25 PLATED ­S/N F000155 & BELOW
BOLT M 8X 30 PLATED ­S/N F000156 & ABOVE

52 CY-26106-100202 BOLT M10X 20 PLATED 2

53 CY-29622-140001

BAND 140 - S/N F000156
& ABOVE

1

1

1

1

1

1

1

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

34

FIG. 3. ACCELERATOR LEVER

REF

NO.

1 CY-798220-01111 LEVER KIT, ACCELERATOR 1

2 CY-194740-00160 WASHER 10, CONICAL 4

3 CY-198220-01110 LEVER, CONTROL 1

4 CY-198165-01130 PLATE, FRICTION 1

5 CY-198220-01140 BRACKET, LEVER 1

6 CY-194150-01270 SPACER 20 1

7 CY-198220-01350 LEVER, ACCELERATOR 1

8 CY-194145-61570 WASHER 10 1

9 CY-22157-100000 WASHER 10 1
10 CY-26756-100002 LOCK NUT M10 PLATED 1
11 CY-26986-100002 LOCK NUT 10 1
12 CY-198253-01190 KNOB, THROTTLE LEVER 1
13 CY-1A8160-01320 ROD, ACCELERATOR 1
14 CY-22137-080000 WASHER 8, POLISHED 1
15 CY-22417-250300 COTTER PIN 2.5X30 1
16 CY-26106-080162 BOLT M 8X 16 PLATED 2
17 CY-26716-080002 NUT M 8 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

35

FIG. 4. EXHAUST

REF

NO.

1 CY-1A8160-03100 PIPE, EXHAUST 1

2 CY-129052-13550 GASKET, EXHAUST 1

3 CY-26106-080202 BOLT M 8X 20 PLATED 2

4 CY-26106-080252 BOLT M 8X 25 PLATED 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

36

FIG. 5. FUEL TANK

REF

NO.

1 CY-1A8160-04100 FUEL TANK WITH SENDER 1

2 CY-1A7335-04070 INSULATOR, TANK R.H. 1

3 CY-1A7335-04080 INSULATOR, TANK LOWER 1

4 CY-1A7335-04110 TANK, FUEL 1

5 CY-1A8160-04260 GROMMET 2

6 CY-198220-04290 PAD 2

7 CY-194990-22120 NUT W/WASHER 5 5

8 CY-198220-56600 SENDER ASSY, FUEL GAUGE 1

9 CY-198220-56610 SENDER, FUEL GAUGE 1
10 CY-194420-56620 GASKET 1
11 CY-198220-56630 WIRE 1
12 CY-1A8160-04130 CAP, FUEL TANK 1
13 CY-1A8160-04150 TRAY, TANK 1
14 CY-194680-51670 BAND 2
15 CY-23065-160850 HOSE, 16 X 850 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

37

FIG. 6. FUEL TANK MOUNTING

REF

NO.

1 CY-1A8160-04210 SUPPORT, TANK 1

2 CY-194555-04270 PACKING, RUBBER 4

3 CY-1A7335-04280 BOLT, M8X30 4

4 CY-194990-22140 NUT W/WASHER 8 4

5 CY-1E6102-83230 CLAMP, BATTERY CABLE 1

6 CY-22157-120000 WASHER 12 4

7 CY-26106-080162 BOLT M 8X 16 PLATED 4

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

38

FIG. 7. EXHAUST MANIFOLD PLATE

REF

NO.

1 CY-1A8160-05510 PLATE/HEAT SHIELD 1

2 CY-194990-22140 NUT W/WASHER 8 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

39

FIG. 8. FRONT FRAME

REF

NO.

1 CY-1A8160-11110 FRONT FRAME 1

2 CY-194450-11190 PLUG 15 4

3 CY-198220-11510 BOLT 12X27 4

4 CY-1A8160-11520 BOLT, M12X34 6

5 CY-198220-11530 BOLT 12X38 2

6 CY-194150-21910 PLUG 11.2 8

7 CY-1A7260-60661 STRIP 1

8 CY-1A7260-60750 WEATHER-STRIP 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

40

FIG. 9. FRONT WEIGHT BRACKET

REF

NO.

1 CY-1A8160-11120 BRACKET, FRONT 1

2 CY-194197-11140 PIN, LOCK 1

3 CY-194990-22160 NUT W/WASHER 12 6

4 CY-22372-160000 SNAP PIN 16 2

5 CY-26116-120352 BOLT M12X 35 PLATED 6

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

41

FIG. 10. CENTER PIN

REF

NO.

1 CY-194515-13220 SPACER 25X42X14 1

2 CY-1A8160-13230 SHIM PIN, CENTER 1

3 CY-1A7450-13230 SHIM 4

4 CY-1A8160-13270 SHIM 0.25 4

5 CY-1A8160-13240 PIN, CENTER 1

6 CY-22157-140000 WASHER 14 1

7 CY-26116-140302 BOLT M14X 30 PLATED 1

8 CY-26108-120252 BOLT 12* 25 4

9 CY-22217-140000 SPRING WASHER 14 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

42

FIG. 11. TIE ROD

REF

NO.

1 CY-198220-12310 TIE-ROD 1

2 CY-198291-18120 END L.H. COMP., TIE-ROD 1

3 CY-194990-22831 NUT, L. 17 1

4 CY-194730-57220 COVER, DUST 1

5 CY-24761-060000 FITTING, 6 1

6 CY-194730-57242 NUT, M12 1

7 CY-22417-300250 COTTER PIN 3.0X 25 1

8 CY-198291-18130 END R.H. COMP., TIE-ROD 1

9 CY-194990-22841 NUT, R. 17 1
10 CY-194730-57220 COVER, DUST 1
11 CY-24761-060000 FITTING, 6 1
12 CY-194730-57242 NUT, M12 1
13 CY-22417-300250 COTTER PIN 3.0X 25 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

43

FIG. 12. RING GEAR

REF

NO.

1 CY-1A8160-13100 GEAR ASSY, RING 1

2 CY-198221-13130 COLLAR 25*34*4.5 1

3 CY-194306-13140 CIRCLIP 24-S 1

4 CY-194855-25290 SLEEVE SI 202513 1

5 CY-194850-31380 BALL BEARING 1

6 CY-22242-000200 CIRCLIP 20 1

7 CY-24101-060044 BALL BEARING #6004 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

44

FIG. 13. DIFFERENTIAL GEAR

REF

NO.

1 CY-1A8160-13200 HOUSING ASSY, DIFF. 1

2 CY-1A8160-13210 CASE, DIFFERENTIAL 1

3 CY-194300-31550 GEAR, DIFFERENTIAL 2

4 CY-194300-31560 GEAR, DIFFERENTIAL 2

5 CY-194300-31570 SHAFT, DIFFERENTIAL 1

6 CY-194300-31610 WASHER, DIFFERENTIAL 2

7 CY-194300-31620 WASHER, DIFFERENTIAL 2

8 CY-22351-040030 SPRING PIN 4X30 1

9 CY-794447-13570 SHIM SET 1
10 CY-1D4110-36430 BOLT, 1 2 8 X 10
11 CY-24101-060084 BALL BEARING 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

45

FIG. 14. PROPELLER SHAFT

REF

NO.

1 CY-1A8160-13340 PROPELLER SHAFT CMP 1

2 CY-198221-13410 BOLT 1

3 CY-22217-080000 SPRING WASHER 8 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

46

FIG. 15. FRONT DRIVE SHAFT

REF

NO.

1 CY-1A8160-13510 SHAFT, DRIVE L.H. 1

2 CY-1A8160-13520 SHAFT, DRIVE R.H. 1

3 CY-1A8160-13560 PINION, FRONT 1ST 2

4 CY-24101-062084 BALL BEARING 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

47

FIG. 16. FRONT AXLE CASE

REF

NO.

1 CY-194447-13490 CAP W/DIPSTICK 1

2 CY-194274-13570 SPRING WASHER 10 12

3 CY-1A8160-13600 FRONT AXLE CASE CMP 1

4 CY-194850-13660 BUSHING 2

5 CY-1A8160-13650 CARRIER, DIFFERENTIAL 1

6 CY-1A8160-13660 GASKET, CARRIER 1

7 CY-194850-13690 NIPPLE M6F, GREASE 1

8 CY-22190-080000 SEAL WASHER 8(BOLT) 1

9 CY-22252-000621 CIRCRIP 62 1
10 CY-22252-000680 CIRCLIP 68 2
11 CY-22312-080160 PARALLEL PIN 8X 16 2
12 CY-24311-000180 O-RING 1A P-18.0 1
13 CY-24321-000800 O-RING 1A G-80.0 2
14 CY-24421-254208 SEAL TC25 42 08, OIL 1
15 CY-26108-100302 BOLT M10X 30 PLATED 12
16 CY-26108-100302 BOLT M10X 30 PLATED 8
17 CY-26116-080122 BOLT M 8X 12 PLATED 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

48

FIG. 17. FRONT GEAR CASE

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

49

FIG. 17. FRONT GEAR CASE

REF

NO.

1 CY-1A8160-13680 BOX, FRONT GEAR UNIT 1

2 CY-1A8160-13720 BOX, FRONT GEAR L CMP 1

3 CY-1A8160-13920 STUD, BOLT 10X30 2

4 CY-1A8160-13730 BOX, FRONT GEAR R CMP 1

5 CY-1A8160-13920 STUD, BOLT 10X30 2

6 CY-1A8160-13750 CASE, FRONT GEAR 2

7 CY-1A8160-13800 SUPPORT, KING PIN CMP 1

8 CY-1A8160-13820 ARM, STEERING L.H. 1

9 CY-1A8160-13861 ARM, STEERING R.H. 1
10 CY-1A8160-13880 WASHER, 52X75X3 2
11 CY-1A8160-13890 WASHER 36X52X2 2
12 CY-1A8160-13930 NUT 10 4
13 CY-198266-28390 BOLT, 10X35 2
14 CY-198475-32660 SEAL QLNY527514.5 2
15 CY-194151-36670 PLUG PT02 2
16 CY-1E6190-54080 SLEEVE SI25X30X13 2
17 CY-22252-000520 CIRCLIP 52 2
18 CY-22351-080020 SPRING PIN 8X20 4
19 CY-23491-140002 PLUG 14 2
20 CY-24101-060094 BALL BEARING 2
21 CY-24104-063044 BALL BEARING 4
22 CY-24311-000160 O-RING 1A P-16.0 2
23 CY-24421-305208 SEAL TC30 52 08, OIL 2
24 CY-26108-100452 BOLT M10X 45 PLATED 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

50

FIG. 18. FRONT SHAFT

REF

NO.

1 CY-1A8160-13830 PINION, FRONT FINAL 2

2 CY-1A8160-13870 SHAFT, FRONT 2ND 2

3 CY-1A8160-13980 GEAR FRONT 2ND 2

4 CY-192180-25980 BEARING 304RSH2 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

51

FIG. 19. FRONT SPINDLE

REF

NO.

1 CY-194556-13790 O-RING 190X2.7 2

2 CY-198200-14110 SPINDLE, FRONT 2

3 CY-198200-14120 GEAR, FRONT FINAL 2

4 CY-1A8160-14130 COVER, GEAR BOX 2

5 CY-194447-14140 SEAL TC6Y 57 75 12 2

6 CY-1A8160-14180 SLEEVE 2

7 CY-198200-14210 RING, HALF TIMBER 4

8 CY-24101-060084 BALL BEARING 2

9 CY-24101-062094 BALL BEARING 2
10 CY-26106-100252 BOLT M10X 25 PLATED 12

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

52

FIG. 20. SHAFT COVER

REF

NO.

1 CY-1A8160-14610 COVER, SHAFT 1

2 CY-198221-14650 BOOT, RUBBER 1

3 CY-23000-080000 CLAMP 80 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

53

FIG. 21. FRONT WHEEL TIRE (BAR)

REF

NO.

1 CY-1A8160-14300 R1 TIRE KIT, FRONT L 1

2 CY-1A8160-14310 R1 TIRE 7X14 1

3 CY-1A8160-14330 R1 WHEEL F 1

4 CY-1A8160-14350 R1 VALVE F 1

5 CY-1A8160-14400 R1 TIRE KIT, FRONT R 1

6 CY-1A8160-14310 R1 TIRE 7X14 1

7 CY-1A8160-14330 R1 WHEEL F 1

8 CY-1A8160-14350 R1 VALVE F 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

54

FIG. 22. FRONT WHEEL TIRE (TURF)

REF

NO.

1 CY-1A8160-14500 R3 TIRE KIT, FRONT 2

2 CY-1A8160-14350 R1 VALVE, F 2

3 CY-1A8160-14510 TIRE 25X8.50-14 2

4 CY-1A8160-14530 R3 WHEEL F 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

55

FIG. 23. FRONT WHEEL TIRE

REF

NO.

1 CY-1A8160-14700 R4 TIRE KIT, FRONT L 1

2 CY-1A8160-14530 R3 WHEEL F 1

3 CY-1A8160-14710 R4 TIRE 25X8.50-14 1

4 CY-1A8160-14750 VALVE 1

5 CY-1A8160-14800 R4 TIRE KIT, FRONT R 1

6 CY-1A8160-14530 R3 WHEEL F 1

7 CY-1A8160-14710 R4 TIRE 25X8.50-14 1

8 CY-1A8160-14750 VALVE 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

56

FIG. 24. HUB BOLT (FRONT)

REF

NO.

1 CY-194881-12650 BOLT M14X 24 12

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

57

FIG. 25. STEERING WHEEL

REF

NO.

1 CY-198220-15650 COVER 1

2 CY-1A8160-15700 WHEEL, STEERING COMPLETE 1

3 CY-198133-15710 WHEEL, STEERING 1

4 CY-1A8160-15740 CAP STEERING W/LABEL 1

5 CY-1A8160-15780 LABEL, NAME 1

6 CY-22137-160000 WASHER 16, POLISHED 1

7 CY-26356-160002 U-NUT M16 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

58

FIG. 26. POWER STEERING CYLINDER

REF

NO.

1 CY-194180-12471 NUT, CASTLE 2

2 CY-1A8160-17400 CYLINDER ASSY 1

3 CY-1A7335-17310 CAP, CYLINDER 1

4 CY-1A7335-17410 ROD ASSY 1

5 CY-1A7335-17500 ROCK NUT 1

6 CY-1A7335-17520 CIRCLIP 120 1

7 CY-1A7335-17530 CIRCLIP 120 1

8 CY-1A7335-17550 SEAL KIT 1

9 CY-1A7335-17750 PISTON 1
10 CY-22417-400250 COTTER PIN 4.0X25 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

59

FIG. 27. POWER STEERING VALVE

REF

NO.

1 CY-198230-17301 COLUMN, STEERING 1

2 CY-198230-17311 COLUMN ASSY 1

3 CY-194640-17340 BUSH, COLUMN 1

4 CY-198230-17340 SHAFT ASSY 1

5 CY-22242-000200 CIRCLIP 20 1

6 CY-22252-000420 CIRCLIP 42 1

7 CY-24104-060040 BALL BEARING 1

8 CY-1A8160-17500 VALVE ASSY, STEERING 1

9 CY-1A8160-17510 SEAL KIT 1
10 CY-198153-17630 BEARING COMP., NEEDLE 1
11 CY-26106-100202 BOLT M10X 20 PLATED 4
12 CY-26106-100202 BOLT M10X 20 PLATED 4

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

60

FIG. 28. POWER STEERING LINES

REF

NO.

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

61

FIG. 28. POWER STEERING LINES

REF

NO.

1 CY-1A8160-17460 BRACKET (PIPE CLAMP) 1

1-1 CY-1A8160-17461 BRACKET (PIPE CLAMP) - S/N F000155 & BELOW 1

2 CY-1A8160-17700 LINE, PST L.H. 1
3 CY-1A8160-17720 LINE, PST PUMP 1
4 CY-1A8160-17740 LINE, PST TANK 1
5 CY-1A8160-17780 LINE, PST R.H. 1
6 CY-198268-17790 CLAMP, PIPE 12 - S/N F000155 & BELOW 1
7 CY-198230-17850 HOSE 2
8 CY-1A8160-17950 BAR, CLAMP 1

9 CY-194990-22130 NUT W/WASHER 6 1
10 CY-198220-46560 CLAMP COMP - S/N F000155 & BELOW 1
11 CY-198245-46680 BOLT 3/4-16 1
12 CY-198245-46680 BOLT 3/4-16 1
13 CY-198245-46680 BOLT 3/4-16 1
14 CY-198245-46680 BOLT 3/4-16 1
15 CY-198220-48140 FLANGE 1
16 CY-23414-190000 PACKING -19 2
17 CY-23414-190000 PACKING -19 2
18 CY-23414-190000 PACKING -19 2
19 CY-23414-190000 PACKING -19 2
20 CY-24311-000200 O-RING 1A P-20.0 1
21 CY-24311-000200 O-RING 1A P-20.0 1
22 CY-26018-060352 BOLT M 6X 35 4
23 CY-26106-060202 BOLT M 6X 20 PLATED 1
24 CY-26106-060402 BOLT M 6X 40 PLATED 2
25 CY-26106-080122 BOLT M 8X 12 PLATED 2
26 CY-26106-080352 BOLT M 8X 35 PLATED - S/N F000155 & BELOW 1
27 CY-26106-060122 BOLT M 6X 12 PLATED 1
28 CY-1E6102-84970 BAND 140, WIRE LOCK 1
29 CY-1A8160-17440 BRACKET, CLAMP KIT - S/N F000156 & ABOVE 1
30 CY-1A8160-17450 BRACKET COMP - S/N F000156 & ABOVE 1
31 CY-1A8160-17461 BRACKET (PIPE CLAMP) - S/N F000156 & ABOVE 1
32 CY-195616-24930 TRIM - S/N F000156 & ABOVE 1
33 CY-198268-17790 CLAMP, PIPE 12 - S/N F000156 & ABOVE 2
34 CY-26106-080252 BOLT M 8X 25 PLATED - S/N F000156 & ABOVE 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

62

FIG. 29. CLUTCH HOUSING

REF

NO.

1 CY-194450-11190 PLUG 15 6
2 CY-1A8160-21100 HOUSING, CLUTCH CMP 1
3 CY-194740-06080 BUSH 25X30X18 4
4 CY-194190-22250 PIN 2
5 CY-194130-22280 BUSH 20X25X25 2
6 CY-26216-100802 STUD M10X 80 PLATED 2
7 CY-26716-100002 NUT 10 2
8 CY-22217-100000 SPRING WASHER 10 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

63

FIG. 30. DOCKING BOLT

REF

NO.

1 CY-194150-21910 PLUG 11.2 2
2 CY-22217-120000 SPRING WASHER 12 1
3 CY-22351-080018 SPRING PIN 8X18 2
4 CY-24761-020000 NIPPLE PT1/8,GREASE 2
5 CY-26013-120352 BOLT M12X 35 1
6 CY-26013-121052 BOLT M12X105 3
7 CY-26013-121152 BOLT M12X115 2
8 CY-26013-121402 BOLT M12X140 2

9 CY-26716-120002 NUT 12 1
10 CY-198240-21180 COVER 1
11 CY-26106-080162 BOLT M 8X 16 PLATED 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

64

FIG. 31. SINGLE CLUTCH

REF

NO.

1 CY-198287-21510 DISK, CLUTCH 225 1

2 CY-198287-21700 PLATE, PRESSURE 1

3 CY-22351-080018 SPRING PIN 8X18 3

4 CY-26106-080162 BOLT M 8X 16 PLATED 6

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

65

FIG. 32. CLUTCH SHAFT

REF
NO.

1 CY-1A8160-22110 SHAFT, MAIN DRIVE 1
2 CY-1A8160-22120 JOINT, 25X50 1
3 CY-22242-000240 CIRCLIP 24 1
4 CY-22252-000220 CIRCLIP 22 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

66

FIG. 33. CLUTCH RELEASE

REF

NO.

1 CY-1A8160-22240 SHAFT, RELEASE 1

2 CY-198220-22310 YOKE, CLUTCH RELEASE 1

3 CY-1A8160-27400 PLATE, CRUISE ASSY 1

4 CY-24550-020200 BUSH 20X20,DRY 1

5 CY-22272-000150 CIRCLIP E-15 1

6 CY-22351-035040 SPRING PIN 3.5X40 1

7 CY-22351-060040 SPRING PIN 6X40 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

67

FIG. 34. BEARING SLEEVE

REF

NO.

1 CY-1A8160-21180 COVER, HOUSING 1

2 CY-1A8160-22150 SLEEVE, ASSY 1

3 CY-194130-22160 BUSH 25X30X31 2

4 CY-194130-22170 FELT 2

5 CY-194990-42710 BEARING, CLUTCH 1

6 CY-198327-22230 SPRING, RETURN 2

7 CY-26106-080162 BOLT M 8X 16 PLATED 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

68

FIG. 35. CLUTCH PEDAL

REF

NO.

1 CY-194990-22140 NUT W/WASHER 8 1

2 CY-798220-22350 ROD KIT, CLUTCH PEDAL 1

3 CY-198220-22350 ROD 1

4 CY-198220-22470 ROD, CLUTCH 1

5 CY-194150-22480 NUT M10 1

6 CY-194300-22260 TURNBUCKLE M10 1

7 CY-1A8160-22410 CLUTCH PEDAL 1

8 CY-198133-22510 RIVET, PEDAL HEAD 1

9 CY-198220-22520 SPRING, CLUTCH 1
10 CY-198133-22530 WASHER, RIVET 1
11 CY-198071-37510 COVER, PEDAL HEAD 1
12 CY-22137-100000 WASHER 10,POLISHED 2
13 CY-22417-250300 COTTER PIN 2.5X30 2
14 CY-24761-010000 NIPPLE M6F, GREASE 1
15 CY-26106-080502 BOLT M 8X 50 PLATED 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

69

THIS PAGE INTENTIONALLY LEFT BLANK

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

70

FIG. 36. TRANSMISSION CASE

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

71

FIG. 36. TRANSMISSION CASE

REF

NO.

1 CY-1A8160-13930 NUT 10 2

2 CY-194855-24020 SEALANT, TUBE 1

3 CY-1A8160-24100 CASE, MISSION CMP 1

4 CY-26216-100252 STUD M10X 25 PLATED 1

5 CY-26216-100252 STUD M10X 25 PLATED 2

6 CY-198220-24211 COVER, MISSION CASE 1

7 CY-198220-24341 COVER, REAR COMP. 1

8 CY-119860-34810 GUIDE, DIPSTICK 1

9 CY-198220-24360 GASKET, REAR COVER 1
10 CY-1A8160-24390 BOLT, 10X75 2
11 CY-198220-24480 COVER, BOTTOM 1
12 CY-1A8160-24920 FLANGE, STRAINER 1
13 CY-194850-24960 GAUGE COMP, OIL 1
14 CY-194180-26690 O-RING 2035 1
15 CY-198266-28390 BOLT, 10X35 4
16 CY-194440-51620 CLAMP, WIRE HARNESS 1
17 CY-22217-100000 SPRING WASHER 10 1
18 CY-22217-100000 SPRING WASHER 10 2
19 CY-22312-080160 PARALLEL PIN 8X 16 2
20 CY-22312-100180 PARALLEL PIN 10X 18 4
21 CY-24321-000950 O-RING 1A G-95.0 1
22 CY-24421-405508 SEAL TC40 55 08, OIL 1
23 CY-26013-080202 BOLT W/WASHER M8X20 2
24 CY-26013-080202 BOLT W/WASHER M8X20 7
25 CY-26013-100302 BOLT M10X 30 3
26 CY-26013-080352 BOLT M 8X 35 10
27 CY-26716-100002 NUT 10 1
28 CY-26716-100002 NUT 10 2
29 CY-27260-200000 PLUG 20, BORE 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

72

FIG. 37. CENTER PLATE

REF

NO.

1 CY-194197-21170 PLUG 17,BORE 1

2 CY-1A8160-24300 CENTER PLATE COMP 1

3 CY-1A8160-24400 STUD, BOLT 10X75 2

4 CY-26216-120552 STUD M12X 55 PLATED 1

5 CY-26013-100802 BOLT 10X80 6

6 CY-26366-120002 U-NUT M12 1

7 CY-22312-100180 PARALLEL PIN 10X 18 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

73

FIG. 38. BEARING RETAINER

REF

NO.

1 CY-1A8160-24160 RETAINER, BEARING 1

2 CY-1A8160-24200 SHIM, SET 1

3 CY-1A8160-24250 SHIM, SET 1

4 CY-22252-000470 CIRCLIP 47(H) 1

5 CY-26013-100252 BOLT W/WASHER M10X25 1

6 CY-26013-100352 BOLT M10X 35 3

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

74

FIG. 39. OIL STRAINER

REF

NO.

1 CY-194515-24930 FILTER, SUCTION 1

2 CY-198220-24970 COVER, OIL STRAINER 1

3 CY-194322-24980 PLUG 1/2-NPT 1

4 CY-22217-080000 SPRING WASHER 8 3

5 CY-24321-000500 O-RING 1A G-50.0 1

6 CY-26116-080202 BOLT M 8X 20 PLATED 3

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

75

FIG. 40. INPUT GEAR

REF

NO.

1 CY-1A8160-24330 RETAINER, A 1

2 CY-1A8160-25310 PINION 33 1

3 CY-24101-060064 BALL BEARING 2

4 CY-24311-000380 O-RING 1A P-38.0 1

5 CY-24351-310750 PACKING, 31075 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

76

FIG. 41. REDUCTION SHAFT

REF

NO.

1 CY-194305-25160 BALL BEARING 1

2 CY-1A8160-25320 GEAR 30 1

3 CY-1A8160-25350 SHAFT, REDUCTION 1

4 CY-1A8160-25380 PINION 33 1

5 CY-22242-000340 CIRCLIP 34 1

6 CY-24101-063044 BALL BEARING 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

77

FIG. 42. COUNTER SHAFT

REF

NO.

1 CY-1A8160-25360 GEAR 27 1

2 CY-1A8160-25370 GEAR 22 1

3 CY-1A8160-25390 GEAR 21 1

4 CY-194150-25530 WASHER 20X43X2.5 1

5 CY-1A8160-25650 BUSH 25X30X25 1

6 CY-1A8160-25810 COLLAR, SPLINE 1

7 CY-198220-25830 NUT 16, LOWER 1

8 CY-194515-25840 WASHER 35X45X3 1

9 CY-198220-25840 NUT16, UPPER 1
10 CY-198415-25840 WASHER 16X38X4.5 1
11 CY-1A8160-25990 BEARING, 4T32005X 1
12 CY-1A8160-28190 PINION 27 1
13 CY-194191-28350 WASHER 30X45X2.5 1
14 CY-22242-000340 CIRCLIP 34 1
15 CY-24101-063074 BEARING 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

78

FIG. 43. P.T.O. DRIVE SHAFT

REF

NO.

1 CY-194310-25100 JOINT 1

2 CY-1A8160-26110 CONNECTING SHAFT 1

3 CY-198220-26110 SHAFT, PTO DRIVE 1

4 CY-198220-26130 BEARING HR6303NR 1

5 CY-1A8160-26300 WASHER, 17X25X3 1

6 CY-198220-26380 SPRING, CAM 1

7 CY-198220-26410 CLUTCH (A), 1-WAY 1

8 CY-198220-26430 CAM B KIT 1

9 CY-194446-26280 BUSH 14X18X15 1
10 CY-194405-83910 BEARING TMB204 1
11 CY-22252-000170 CIRCLIP 17 1
12 CY-24101-060044 BALL BEARING #6004 1
13 CY-24101-062044 BALL BEARING #6204 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

79

FIG. 44. P.T.O. SHAFT

REF

NO.

1 CY-194515-25780 WASHER 30X38X2.3 1

2 CY-194555-25870 BALL BEARING 2

3 CY-198220-26460 CAM (C) 1

4 CY-198220-26470 CAM (D 1

5 CY-198220-26500 SHAFT, PTO 1

6 CY-198220-26510 SLEEVE 35*40*13 1

7 CY-198220-26530 SLEEVE, SLIDER 1

8 CY-198220-26560 GEAR, PTO 53 1

9 CY-194197-26680 SLIDER 1
10 CY-194197-26710 SPRING 1
11 CY-194190-26840 SPACER 25X36X1.6 1
12 CY-198220-26920 SPACER 5*60.5* 6 1
13 CY-22242-000300 CIRCLIP 30 1
14 CY-22252-000620 CIRCLIP 62(H) 1
15 CY-22292-000350 CIRCLIP S-35 1
16 CY-22292-000450 CIRCLIP S-45 2
17 CY-24101-060074 BALL BEARING 1
18 CY-24101-062054 BEARING #6205 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

80

FIG. 45. P.T.O. SHIELD

REF

NO.

1 CY-198220-26582 SHIELD, PTO KIT 1

2 CY-1A8160-26630 BRACKET L.H., PTO 1

3 CY-1A8160-26640 BRACKET,R.H., PTO 1

4 CY-26013-120202 BOLT W/WASHER M12X20 4

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

81

FIG. 46. RANGE LEVER

REF

NO.

1 CY-26716-100002 NUT 10 1

2 CY-198253-27510 KNOB 1

3 CY-22351-035040 SPRING PIN 3.5X40 1

4 CY-22351-060040 SPRING PIN 6X40 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

82

FIG. 47. RANGE LEVER PARTS

REF

NO.

1 CY-194191-13350 SPACER 20X30X1.6 1

2 CY-1A8160-27360 SHAFT, RANGE SHIFT 1

3 CY-1A8160-27380 ARM, RANGE SHIFT 1

4 CY-1A8160-27430 SHIFT FORK, RANGE 1

5 CY-1A8160-27440 FORK SHAFT, RANGE 1

6 CY-1A8160-27450 BOLT, SWITCH 2

7 CY-194680-27540 SPRING, FORK LOCK 1

8 CY-22190-080002 SEAL WASHER 8S 1

9 CY-22242-000200 CIRCLIP 20 1
10 CY-22351-035032 SPRING PIN 3.5X32 1
11 CY-22351-035032 SPRING PIN 3.5X32 1
12 CY-22351-060032 SPRING PIN 6X32 1
13 CY-22351-060032 SPRING PIN 6X32 1
14 CY-24190-080001 BALL 1/4, STEEL 1
15 CY-24311-000150 O-RING 1A P-15.0 1
16 CY-26106-080162 BOLT M 8X 16 PLATED 1
17 CY-1A8160-27350 LEVER, RANGE SHIFT 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

83

FIG. 48. CRUISE CONTROL

REF

NO.

1 CY-198220-22230 SPRING, RETURN 1

2 CY-1A8160-27500 LEVER, CRUISE CMP 1

3 CY-1A8160-27520 LEVER B, CRUISE 1

4 CY-1A8160-27530 CAP NUT 5, BK 1

5 CY-1C6980-56250 GRIP 10X25 1

6 CY-22137-100000 WASHER 10, POLISHED 1

7 CY-22417-250300 COTTER PIN 2.5X30 1

8 CY-26559-050162 SCREW 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

84

FIG. 49. P.T.O. SHIFTER

REF

NO.

1 CY-194145-27450 SPRING 1

2 CY-198220-27630 FORK, SHIFTER PTO 1

3 CY-198220-27640 SHAFT, FORK PTO 1

4 CY-198220-27650 ARM, SHIFT PTO 1

5 CY-198220-27700 SHAFT 1

6 CY-198220-27990 PLATE 1

7 CY-22190-100000 SEAL WASHER 10(BOLT) 1

8 CY-22351-060032 SPRING PIN 6X32 1

9 CY-22351-060032 SPRING PIN 6X32 1
10 CY-24190-100001 BALL 5/16, STEEL 1
11 CY-24311-000150 O-RING 1A P-15.0 2
12 CY-26106-080162 BOLT M 8X 16 PLATED 1
13 CY-26106-100252 BOLT M10X 25 PLATED 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

85

FIG. 50. P.T.O. LEVER

REF

NO.

1 CY-198220-26990 HOSE, PROTECTION 1

2 CY-198220-27290 KNOB 1

3 CY-19822027810F LEVER, P.T.O. SHIFT 1

4 CY-22351-060032 SPRING PIN 6X32 1

5 CY-26756-100002 LOCK NUT M10 PLATED 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

86

FIG. 51. FRONT DRIVE

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

87

FIG. 51. FRONT DRIVE

REF

NO.

1 CY-198220-26790 SHOE. SHIFTER 1

2 CY-198119-27150 COLLAR 1

3 CY-198212-27990 PLATE, KEEP 1

4 CY-1A8160-28210 SHAFT, MFWD 1

5 CY-1A8160-28220 GEAR, FRONT 35 1

6 CY-1A8160-28230 SHIFTER, FRONT 1

7 CY-194301-28280 SPRING 25.8 1

8 CY-1A8160-28310 SHAFT, MFWD SHIFT 1

9 CY-1A8160-28320 SHIFT ARM, MFWD 1
10 CY-1A8160-28360 CHANGE ARM, FRONT 1
11 CY-22252-000520 CIRCLIP 52 1
12 CY-22351-060032 SPRING PIN 6X32 1
13 CY-22351-060032 SPRING PIN 6X32 1
14 CY-24101-062054 BEARING #6205 1
15 CY-24101-063034 BALL BEARING 1
16 CY-24190-080001 BALL 1/4, STEEL 2
17 CY-24311-000160 O-RING 1A P-16.0 1
18 CY-24421-255210 OIL SEAL TC255210 1
19 CY-26106-080162 BOLT M 8X 16 PLATED 1
20 CY-198273-28520 KNOB, P BRAKE 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

88

FIG. 52. HYDROSTATIC (HST)

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

89

FIG. 52. HYDROSTATIC (HST)

REF

NO.

1 CY-198280-24340 COLLAR, 12X16X17 2

2 CY-1A8160-27200 ARM, TRUNNION CMP 1

3 CY-1A8160-29540 COLLAR, TRUNNION 1

4 CY-1A8160-29550 PIN,TRUNNION 1

5 CY-1A8160-29560 ROD END ASSY, HST 1

6 CY-198280-29570 ROD END 1

7 CY-1A8160-29580 BOLT,ROD END 1

8 CY-1E8080-64710 ROD END 1

9 CY-26716-120002 NUT 12 2
10 CY-22137-080000 WASHER 8, POLISHED 1
11 CY-22217-120000 SPRING WASHER 12 1
12 CY-24311-000160 O-RING 1A P-16.0 2
13 CY-24321-000600 O-RING 1A G-60.0 1
14 CY-26106-080552 BOLT M 8X 55 PLATED 1
15 CY-26106-120552 BOLT, 12 X 55 3
16 CY-26346-080002 U-NUT M 8 PLATED 1
17 CY-26366-080002 NUT M 8 1
18 CY-26716-120002 NUT 12 1
19 CY-1A8160-25150 HST UNIT 1
20 CY-1A6750-29850 PLUG 5
21 CY-158802-85421 OIL SEAL 2
22 CY-158805-85420 SEAL 25*45*8.OIL 1
23 CY-158830-85960 PLUG 1
24 CY-168HJ1-85500 NCR, VALVE+0.7 2
25 CY-168HJ1-85580 PLUG 2
26 CY-168HP1-85570 SPRING (CHECK VALVE) 2
27 CY-168HJ1-85490 O RING S58.2 1
28 CY-22252-000360 CIRCLIP 36 2
29 CY-24315-000140 O-RING 1B P-14.0 5
30 CY-24315-000180 O-RING 1B P-18.0 3
31 CY-26450-080202 BOLT M 8X 20 4

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

90

FIG. 53. HST LINK

REF

NO.

1 CY-1A8160-29000 NEUTRAL, HST ASSY 1

2 CY-194990-22140 NUT W/WASHER 8 2

3 CY-1A8160-29150 BRACKET, NEUTRAL CMP 1

4 CY-1A8160-29270 BOLT, STOPPER 2

5 CY-1A8160-29280 TURNBUCKLE, NEUTRAL 1

6 CY-1A8160-29300 ARM, RETURN ASSY 1

7 CY-24550-015120 BUSH 15X12 2

8 CY-1A8160-29440 BRACKET, ROLLER ASSY 1

9 CY-22272-000070 CIRCLIP E- 7 1
10 CY-24104-060000 BEARING 6000UUC3 1
11 CY-24550-015120 BUSH 15X12 2
12 CY-198280-29490 SPRING, 1
13 CY-1A8160-29800 PLATE,ADJUST CMP 1
14 CY-22137-140000 WASHER 14,POLISHED 2
15 CY-22272-000120 CIRCLIP E-12 2
16 CY-26106-100302 BOLT M10X 30 PLATED 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

91

FIG. 54. RING GEAR

REF

NO.

1 CY-1A8160-31300 GEAR, RING ASSY 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

92

FIG. 55. DIFFERENTIAL GEAR

REF

NO.

1 CY-194321-13230 PINION, DIFFERENTIAL 2

2 CY-198230-31510 GEAR, DIFFERENTIAL 2

3 CY-194430-31610 WASHER, DIFFERENTIAL 2

4 CY-194430-31820 SHAFT, DIFFERENTIAL 1

5 CY-194430-31850 WASHER, DIFFERENTIAL 2

6 CY-198230-32110 CASE, DIFFERENTIAL 1

7 CY-22351-050030 SPRING PIN 5X30 1

8 CY-24101-060104 BALL BEARING 2

9 CY-26013-080202 BOLT W/WASHER M8X20 8

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

93

FIG. 56. DIFFERENTIAL CARRIER

REF

NO.

1 CY-1A8160-32300 RETAINER 2

2 CY-794197-32350 SHIM SET 1

3 CY-26013-080252 BOLT M 8X 25 10

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

94

FIG. 57. REAR HOUSING

REF

NO.

1 CY-194465-11920 BOLT M10X 40 12

2 CY-194447-14140 SEAL TC6Y 57 75 12 2

3 CY-194447-14180 SLEEVE SL525718 2

4 CY-1A8160-24390 BOLT, 10X75 4

5 CY-1A8160-32600 REAR AXLE HOUSING, LH 1

6 CY-1A8160-32610 REAR AXLE HOUSING, RH 1

7 CY-198290-32750 SEAL TC253506,OIL 2

8 CY-1A8160-32810 BOLT, 10X55 8

9 CY-194197-34310 CASE, OIL SEAL 2
10 CY-194197-34320 COVER, OIL SEAL 2
11 CY-198220-34340 GASKET 2
12 CY-22252-000750 CIRCLIP 75 2
13 CY-22312-100180 PARALLEL PIN 10X 18 4
14 CY-23491-140002 PLUG 14 2
15 CY-24311-000160 O-RING 1A P-16.0 2
16 CY-26013-080402 BOLT M 8X 40 6

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

95

FIG. 58. DIFFERENTIAL LOCK

REF

NO.

1 CY-194197-33100 SLIDER, DIFFERENTIAL 1

2 CY-194197-33110 SLIDER, DIFFERENTIAL 1

3 CY-194197-33120 RING 58 1

4 CY-198220-33140 FORK,DIFF 1

5 CY-1A8160-33160 PEDAL, DIFFERENTIAL 1

6 CY-194300-33190 SPRING 1

7 CY-194300-33200 SPACER 20X32X3.2 1

8 CY-198220-33210 PIN 8*56 1

9 CY-22351-035040 SPRING PIN 3.5X40 1
10 CY-22351-050040 SPRING PIN 5X40 1
11 CY-22351-060040 SPRING PIN 6X40 1
12 CY-22351-080032 SPRING PIN 8X32 1
13 CY-22351-080040 SPRING PIN 8X40 1
14 CY-24311-000150 O-RING 1A P-15.0 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

96

FIG. 59. FINAL PINION

REF

NO.

1 CY-1A8160-33400 FINAL PINION 2

2 CY-24101-063064 BALL BEARING 2

3 CY-24121-062064 BALL BEARING 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

97

FIG. 60. FINAL GEAR & REAR AXLE SHAFT

REF

NO.

1 CY-198230-33500 GEAR, FINAL DRIVE 2

2 CY-194440-32580 COLLAR 45X55X20 2

3 CY-198230-34050 SHAFT, REAR AXLE 1

4 CY-198230-34101 SHAFT, REAR AXLE 1

5 CY-198230-34111 SHAFT, REAR AXLE 1

6 CY-22242-000400 CIRCLIP 40 2

7 CY-22242-000450 CIRCLIP 45 4

8 CY-24101-060094 BALL BEARING 2

9 CY-24101-062084 BALL BEARING 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

98

FIG. 61. REAR WHEEL TIRE (BAR)

REF

NO.

1 CY-1A8160-34300 R1 TIRE KIT, WHEEL LEFT 1

2 CY-1A8160-34310 R1 TIRE 11.2X24 1

3 CY-1A8160-34330 R1 WHEEL 1

4 CY-1A8160-34340 R1 RIM ASSY 1

5 CY-1A8160-34360 R1 DISC ASSY 1

6 CY-1A8160-34370 R1 BOLT 4

7 CY-1A8160-34380 R1 NUT 4

8 CY-1A8160-34390 R1 WASHER 4

9 CY-1A8160-34350 R1 VALVE,R 1
10 CY-1A8160-34400 R1 TIRE KIT, WHEEL RIGHT 1
11 CY-1A8160-34310 R1 TIRE 11.2X24 1
12 CY-1A8160-34330 R1 WHEEL 1
13 CY-1A8160-34340 R1 RIM ASSY 1
14 CY-1A8160-34360 R1 DISC ASSY 1
15 CY-1A8160-34370 R1 BOLT 4
16 CY-1A8160-34380 R1 NUT 4
17 CY-1A8160-34390 R1 WASHER 4
18 CY-1A8160-34350 R1 VALVE, R 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

99

FIG. 62. REAR WHEEL TIRE (TURF)

REF

NO.

1 CY-1A8160-34500 R3 TIRE KIT, WHEEL 2

2 CY-1A8160-34350 R1 VALVE, R 2

3 CY-1A8160-34510 R3 TIRE 13.6X16 2

4 CY-1A8160-34530 R3 WHEEL R 2

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200

100

FIG. 63. REAR WHEEL TIRE

REF

NO.

1 CY-1A8160-34700 R4 TIRE KIT, WHEEL L 1

2 CY-1A8160-34710 TIRE 15X19.5 1

3 CY-1A8160-34730 R4 WHEEL R 1

4 CY-1A8160-34750 VALVE 1

5 CY-1A8160-34800 R4 TIRE KIT, WHEEL R 1

6 CY-1A8160-34710 TIRE 15X19.5 1

7 CY-1A8160-34730 R4 WHEEL R 1

8 CY-1A8160-34750 VALVE 1

PART NUMBER DESCRIPTION QTY

Copyright 2007 Cub Cadet Yanmar LLC
