Cub cadet CRC8000 User Manual

Power Cell Rapid Charger

CRC8000

Instruction Manual

PRODUCT SPECIFICATIONS

Use ONLY with Power Cell: CFC6500 20 Volt high energy Li-Ion Charger: Power Cell Rapid Charger Charger input: 100`240 V AC, 60/50 Hz Charger output: 21V DC Weight: 2.5 lb. 40 oz. (1.13 kg)

Need Assistance?

For assistance regarding the assembly, operation or maintenance of the unit, please call 1-877-282-8684 (in the United States) or 1-800-668-1238 (in Canada). Additional information can be found at www.cubcadet.com (in the United States) or

www.cubcadet.ca (in Canada).

769-11434 / 00 01/16

TABLE OF CONTENTS

Product specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

General safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Owner’s Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

General power tool safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Work area safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Personal safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Specific safety rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Charging the Power Cell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . *

* Please refer to the separate Warranty Supplement.

GENERAL SAFETY WARNINGS

CAUTION: Before using this charger, read this manual and follow all

Safety Rules and Operating Instructions.

This instruction manual includes the following:

• General Safety Rules

• Specific Safety Rules and Symbols

• Functional Description

• Assembly

• Operation

WARNING: Retain this manual for future reference.

Provide this manual to all operators and be certain that they have read and understand all the Safety Rules and Operating Instructions prior to their using this tool.

Please register your product online at www.cubcadet.com (in the United States) or www.cubcadet.ca (in Canada).

WARNING: To avoid electrical hazards, fire hazards or damage to

the tool, use proper circuit protection.

The charger for this tool is wired at the factory for 120 V operation. It must be connected to a 120 V, 15 A circuit that is protected by a time-delayed fuse or circuit breaker. To avoid shock or fire, replace the power cord immediately if it is worn, cut or damaged in any way.

OWNER’S REGISTRATION

ELECTRICAL SAFETY

GENERAL POWER TOOL SAFETY WARNINGS

WARNING: Read all safety

warnings and all instructions. Failure

to follow the warnings and instructions may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

General Power Tool Safety Warnings – Work Area Safety

Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create

sparks which may ignite the liquids, fumes or dust.

Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control.

General Power Tool Safety Warnings – Electrical Safety

Power charger plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) chargers.

Unmodified plugs and matching outlets will reduce risk of electric shock.

Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electrical shock if your body is earthed or grounded.

Do not expose power tools, power chargers or Power Cells to rain or wet conditions. Water entering the tool,

chargers or Power Cells will increase the risk of electric shock.

Do not abuse the cord. Never use the power cord for carrying, pulling or unplugging the charger. Keep the power cord away from heat, oil, sharp edges, and moving parts. Damaged or

entangled cords increase the risk of electric shock.

When operating a power charger outdoors, use an extension cord suitable for outdoor use. Use of a cord

suitable for outdoor use reduces the risk of electric shock.

If operating a power charger in a damp location is unavoidable, use a residual current device (RCD) protected supply. An RCD is also known as a ground fault circuit interrupter (GFCI) or earth leakage circuit breaker (ELCB). Use of an RCD

reduces the risk of electric shock.

General Power Tool Safety Warnings – Personal Safety

Stay alert, be aware of your surroundings, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention

while operating a power tool may result in serious personal injury.

GENERAL POWER TOOL SAFETY WARNINGS

SPECIFIC SAFETY RULES

General Power Tool Safety Warnings – Service

Have your power tool or charger serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of

the power tool or charger is maintained.

WARNING: Only use a CRC8000

rapid charger to charge the CFC6500 Power Cell. Using a non-approved charger to charge the CFC6500 Power Cell may damage the Power Cell and / or the charger and cause fires, explosion, hazardous fumes and possibly burns or other serious injury.

WARNING: Fire Hazard.

Do not store or carry the Power Cell in a manner in which metal objects could contact the exposed metal terminals. Do not place the Power Cell in aprons, pockets, drawers, tool boxes, etc. with metal objects, such as, but not limited to, loose nails, screws, bolts, keys, coins, staples, foil, etc. Such metal objects could cause the Power Cell to short circuit causing fire, explosion, and hazardous fumes, resulting in personal injury or property damage.

Never attempt to open, modify, dismantle, reverse polarity, crush, puncture or shred the Power Cell for any reason.

If the housing of the Power Cell breaks, cracks, swells, or is punctured immediately discontinue its use and do not recharge.

Do not charge or use the Power Cell if it has been dropped or has received a sharp blow, a heavy weight has been imposed upon it, has been overheated, or is cracked, crushed, deformed or punctured. If a Power Cell has sustained damage, (as per above, or otherwise) immediately isolate it in a noncombustible, safe outside area, remain a safe distance away but do not leave it unattended. Such a damaged Power Cell should be considered and treated as a potentially thermally unstable, flammable and hazardous material. If the Power Cell ignites use water spray, carbon dioxide, dry chemical or foam extinguishers to suppress. Avoid exposure to and inhalation of hazardous fumes. Contact hazardous materials authorities for guidance as to appropriate handling and prompt safe disposal of damaged Power Cells. Make arrangements for prompt safe disposal of a damaged Power Cell per local hazardous material regulations.

SPECIFIC SAFETY RULES

Do not use or charge the Power Cell if it is wet or shows any evidence of corrosion.

WARNING: Leakage from the

Power Cell may occur under extreme usage, charging or temperature conditions, or if the Power Cell is damaged, crushed or punctured. This leakage indicates a failure of the Power Cell and the Power Cell should be properly disposed of per local hazardous material regulations.

If this leakage gets on your skin, or eyes follow these steps:

1. Wash skin immediately and thoroughly with soap and water.

2. If liquid gets into your eyes, flush immediately with clean water for a minimum of 20 minutes and seek immediate medical attention.

If the liquid gets onto your clothing or shoes, remove, isolate and wash the contaminated clothing thoroughly.

Do not wash, splash or immerse a Power Cell in water or other liquids.

Keep the Power Cell out of the reach of children and away from persons not fully familiar with these instructions.

Do not expose the Power Cell to heat or fire. Do not incinerate the Power Cell. It can explode and emit hazardous fumes.

Do not store or use the Power Cell in locations where the temperature may reach or exceed 105°F (40°C) such as in outside sheds or metal buildings, tool boxes, vehicle interiors or trunks during summer. Avoid storing the Power Cell in direct sunlight.

For air, vessel and ground transport purposes, Lithium ion Power Cells are classified as Class 9 Hazardous Goods, subject to ICAO Technical Instructions and IATA Dangerous Goods Regulations and US Department of Transportation and Transport Canada Hazardous Material Regulations [HMR] [and other applicable national regulations]. Such Power Cells are restricted from being placed in checked in baggage and are subject to shipper declarations, standards, quantity and packaging regulations. Confirm with the ground, vessel, air cargo or passenger air travel service provider as to the most current regulations to determine if your lithium ion Power Cells are prohibited, or subject to restrictions or exemptions prior to shipping or travel with your lithium Power Cells.

Do not remove the Power Cell from its original packaging until it is required for use.

Always keep the Power Cell clean and dry. Wipe the terminals with a clean dry cloth if they become dirty.

Storage Recommendations:

The best storage place for Power Cells is a secure and safe place that is cool and dry and away from direct sunlight and excess heat or cold. Exposure to

excess or prolonged heat will degrade the performance and the life expectancy of the Power Cell.

Do not use an extension cord. Plug the charger cord directly into an electrical outlet.

SPECIFIC SAFETY RULES

Use the charger only in a standard 120 V AC, 60 Hz electrical outlet.

WARNING: Do not use

the charger in wet or damp conditions. The charger is intended for indoor use only. Do not use outdoors. Do not expose to dew, rain or garden sprinklers, frost, or snow. Do not use the charger near sinks or tubs. Do not immerse the charger in water. Water

entering the chargers or Power Cells will increase the risk of electric shock.

Do not operate power chargers in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power chargers can

create sparks which may ignite the liquids, fumes or dust.

Do not use the CRC8000 rapid charger to charge any batteries other than a CFC6500 Power Cell. Charging other batteries may cause the batteries to burst, catch fire, emit hazardous fumes or explode.

Do not allow the charger cord to hang over the edge of a table or counter, to be placed in an area where it can become entangled with moving objects, or be a tripping hazard, or to contact sharp or hot surfaces. The charger should be placed away from sinks and hot surfaces.

Do not leave a Power Cell on a prolonged charge. Remove the Power Cell after attaining a complete recharge and unplug the charger when not in further use.

Do not operate the charger if the cord or plug is damaged. Have a qualified technician replace the damaged cord and plug immediately.

Do not operate the charger if it has received a sharp blow, been dropped, crushed, cracked, punctured, immersed or splashed with water or other liquids, or otherwise damaged in any way. Have a qualified technician examine the charger and repair it if necessary. Do not disassemble or modify the charger.

CAUTION: When the charger is

plugged into the power supply, it can become shorted by foreign conductive material and cause sparks or fires. Foreign conductive material such as, but not limited to, metal shavings / chips, steel wool, aluminum foil, nails, staples, paper clips, should be kept away from charger ventilation openings, Power Cell retaining cavity and output terminals.

Do NOT charge the Power Cell when the work area or the Power Cell temperature is at or below 0° C (32° F) or above 45° C (113° F).

Unplug the charger when it is not in use and before cleaning or maintenance.

POWER CELL RECYCLING

To preserve our natural resources, and reduce landfill please recycle your Power Cells at participating retailers, or dispose of Power Cells properly in accordance with Federal, State, Provincial or local laws.

ASSEMBLY AND OPERATING

CHARGING THE POWER CELL

WARNING: Use only the

CRC8000 rapid charger to charge the CFC6500, 20V Li-Ion Power Cell. Charging any other Power Cells or batteries with this charger may damage the Power Cells, batteries, or charger, and possibly cause serious injury or property damage from fire, explosion or hazardous fumes.

1. To charge the Power Cell, place the charger (1) in a dry location near a 120 V AC, 60 Hz electrical outlet and plug it into the outlet (Fig. 1).

NOTE:

Both the red and green LEDs will turn ON, indicating that power is actively being supplied to the charger and that the charger is ready to charge a Power Cell. If the LEDs do NOT turn ON, the charger is not receiving power from the electrical outlet or the charger is not functioning properly.

2. Insert the Power Cell (2) into the matching cavity (3) in the top of the charger.

NOTES:

a) Make sure the "TOP" marking (4)

on top of the Power Cell is facing toward the LED lights (5 & 6) on the charger.

b) Make sure the Power Cell is

pressed fully into the charger cavity.

ASSEMBLY AND OPERATING

CHARGING THE POWER CELL –

cont’d

3. When the Power Cell is inserted into the charger, the red LED (5) will remain ON and the second LED (6) will turn to red, indicating that the Power Cell is being charged.

4. When the Power Cell is fully charged, the upper LED (5) will remain red and the lower LED (6) will change to green.

5. When the Power Cell is fully charged, remove it from the charger and unplug the charger from the power source.

NOTES:

a) Lithium-Ion Power Cells will continue to provide nearly full power with minimal power fade unlike traditional batteries; when the Power Cell is fully discharged, the Power Cell electronic control circuitry will immediately cut power output to the tool without notice. A discharged Power Cell should be promptly recharged to maintain its operational voltage potential and to be ready for future use.

b) Do NOT charge the Power Cell when the work area or the Power Cell temperature is at or below 32° F (0°C) or above 113° F (45°C). The optimal temperature is 68° F (20°C).

c) Remove the Power Cell from the charger and unplug the charger once the Power Cell has been completely charged.
